HHHHP
PLUG
PLAY
&
P DDDD8888999900
P P
HHHHP
17-inch Color Monitor
16.0-inch Viewable Image
Moniteur couleur 17 pouces
Pantalla de color de 17 pulgadas
16.0 pulgadas de imagen visualizada
Manual del Usario Léase esto primero
Video a colori da 17 pollici
Immagine visibile da 16 pollici
Monitor Colorido de 17 polegadas
Imagem Visível de 16.0 polegadas
User’s Guide
17-Zoll-Farbbildschirm
16,0 Zoll-Bildanzeige
Benutzerhandbuch
Affichage 16,0 pouces
Guide de l’utilisateur
Manuale dell’utente
Guia do Usuário
00AAAA
0000
P 77775555
P P
NNNNoooottttiiiicccceeee
The information contained in this document is subject to change without notice.
Hewlett-Packard makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose.
Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the
furnishing, performance, or use of this material.
Hewlett-Packard assumes no responsibility for the use or reliability of its software on equipment that is not furnished by Hewlett-Packard.
This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be
photocopied, reproduced, or translated to another language without the prior written consent of Hewlett-Packard Company.
HHHHiiiinnnnwwwweeeeiiiissss
Inhaltliche Änderungen vorbehalten.
Hewlett-Packard übernimmt keine Garantie welcher Art auch immer für diese Ausrüstung, einschließlich der (doch nicht begrenzt auf
die) Qualitätsgarantie und die Garantie bezüglich Eignung für einen bestimmten Zweck.
Hewlett-Packard haftet nicht für in dieser Dokumentation enthaltene Fehler oder für unbeabsichtigte oder indirekte Schäden in
Verbindung mit der Lieferung, der Leistung oder der Benutzung der Ausrüstung.
Hewlett-Packard übernimmt keine Haftung fur den Betrieb oder die Zuverlässigkeit seiner Software, wenn diese auf Hardware benutzt
wird, die nicht von Hewlett-Packard geliefert wurde.
Dieses Dokument enthalt proprietäre Informationen, die durch das Copyright geschützt sind. Alle Rechte vorbehalten. Dieses Dokument
darf ohne vorherige schriftliche Genehmigung der Hewlett-Packard Company weder ganz noch teilweise fotokopiert, reproduziert oder
übersetzt werden.
AAAAvvvveeeerrrrttttiiiiss
sseeeemmmmeeeennnntttt
ssss
Les informations contenues dans ce document peuvent être modifiées sans préavis.
Hewlett-Packard ne donne aucune garantie de quelque sorte que ce soit concernant, sans que ce soit limitatif, les garanties implicites de
qualité commerciale de ce matériel, ou la bonne adaptation de celui-ci à un usage particulier.
Hewlett-Packard n’est pas responsable des erreurs pouvant apparaître dans ce manuel et n’est pas non plus responsable des dommages
directs ou indirects résultant de l’équipement, des performances et de l’utilisation de ce matériel.
Hewlett-Packard ne saurait être tenu pour responsable de l’utilisation et de la fiabilité de son logiciel sur des matériels non fournis par
Hewlett-Packard.
Les informations contenues dans ce document sont originales et protégées par copyright. Tous droits réservés. L’acheteur s’interdit en
conséquence de les photocopier, de les reproduire ou de les traduire dans toute autre langue, sauf accord préalable et écrit de HewlettPackard.
AAAAvvvviiiissssoooo....
La información contenida en este documento está sujeta a cambios sin previo aviso.
Hewlett-Packard no ofrece ningún tipo de garantía con respecto a este material, incluyendo, pero sin limitarse a, las garantías implícitas
de comerciabilidad e idoneidad para un fin determinado.
Hewlett-Packard no asume responsabilidad alguna por los posibles errores contenidos o por los daños casuales o emergentes relacionados
con el suministro, funcionamiento o uso de este material.
Hewlett-Packard no asume responsabilidad alguna por el uso o fiabilidad de su software en equipos que no hayan sido fabricados por
Hewlett-Packard.
Este documento contiene información patentada, protegida por las leyes del copyright. Reservados todos los derechos. Ninguna parte de
este documento puede ser fotocopiada, reproducida o traducida a otro idioma sin la autorización previa y por escrito de Hewlett-Packard
Company.
AAAAvv
vviiiissssoooo
vvvv
Le informazioni contenute in questo documento sono soggette a cambiamento senza preavviso.
Hewlett-Packard non rilascia garanzie di alcun tipo riguardo a questo materiale, comprese le garanzie implicite di commerciabilità e di
idoneità per uno scopo particolare.
Hewlett-Packard non sarà ritenuta responsabile per errori contenuti in questo documento, né per danni accidentali o conseguenti alla
fornitura, alle prestazioni o all’uso di questo materiale.
Hewlett-Packard non si assume alcuna responsabilità riguardo all’uso o all’affidabilità del proprio software su apparecchiature di altri
produttori.
Questo documento contiene informazioni di proprietà protette da copyright. Tutti i diritti sono riservati. Nessuna parte di questo
documento può essere fotocopiata, riprodotta o tradotta in un’altra lingua senza un precedente consenso scritto di Hewlett-Packard
Company.
Nota
As informações contidas neste documento estão sujeitas a alteração sem notificação prévia.
A Hewlett-Packard não oferece nenhum tipo de garantia com relação a este material, incluindo, mas não limitada às, garantias implícita s
de comercialização e conveniência para um propósito específico.
A Hewlett-Packard não será responsável por erros aqui contidos ou por danos incidentais ou conseqüenciais relacionados ao
fornecimento, desempenho ou utilização deste material.
A Hewlett-Packard não se responsabiliza pelo uso ou confiabilidade se seu software em equipamentos que não sejam fornecidos pela
Hewlett-Packard.
Este documento contém informações proprietárias protegidas por direitos autorais. Todos os direitos são reservados. Nenhuma parte
deste documento pode ser fotocopiada, reproduzida ou traduzida para outro idioma sem o consentimento prévio por escrito da HewlettPackard Company
Hewlett-Packard France 38053 Grenoble Cedex 9 France© 1999 Hewlett-Packard Company
English .............................................................. Chapter 1
Deutsch ............................................................. Kapitel 2
Français ............................................................ Chapitre 3
Español ............................................................. Capítulo 4
Italiano.............................................................. Capitolo 5
Português.......................................................... Capítulo 6
English iii
iv English
1
Main Features
• High resolution, multi-synchronous color monitor
• 0.26 mm dot pitch for excellent graphics
• Anti-glare, multilayer coating to minimize
reflection
• Image adjustment by on screen display menus
• Recommended video mode of
1024×768 at 85 Hz
HP D8900A HP 75
17-inch Color Monitor
16.0-inch Viewable Image
User’s Guide
HP 17” Color Monitor User’s Guide
Important Safety Instructions
Important Safety Instructions
Before you plug in your new monitor, read these important safety
instructions.
WARNING
Connect the monitor only to a grounded power outlet. Use the power
cord supplied with the monitor or one with a properly grounded plug.
Ensure the cable meets your country’s standards for safety.
To completely disconnect power at the monitor, remove the power cord
from the power outlet. Ensure that the power outlet is easily accessible.
Make sure the power to your computer is “off” before connecting or
disconnecting any monitor peripheral.
To reduce the risk of electric shock, do not remove cover (or back).
There are no user serviceable parts inside. Refer servicing to qualified
service personnel.
The monitor is quite heavy (the weight is shown in the technical
specifications). We recommend you ask the assistance of a second
person when lifting or moving it.
Safety Warning for USA
If the power cord is not supplied with your monitor, select the proper
power cord according to your national electric safety codes.
• USA: use a UL Listed Type SVT or Type SJT detachable power cord.
2 EnglishEnglish
Setting Up Your Monitor
HP 17” Color Monitor User’s Guide
Setting Up Your Monitor
CAUTION
Before you connect any cables, or install your HP monitor, refer to
the safety instructions at the beginning of this manual. Refer to the
user manual which accompanies your computer and video adapter to
ensure this equipment is correctly installed.
2222
1111
3333
Supported Video Modes
Your monitor supports the video modes shown in the table below.
Screen Resolution Image Refresh Rate
640×400 70 Hz
640×480 75 Hz, 85 Hz
800×600 75 Hz, 85 Hz
1024×768 70 Hz, 75 Hz, 85 Hz
1280×1024 75 Hz
CAUTION
Selecting a video mode on your computer with a screen
resolution/image refresh rate combination higher than 1280×1024 at
75Hz can damage your monitor.
EnglishEnglish 3
HP 17” Color Monitor User’s Guide
Supported Video Modes
Using Your Monitor
Access the
brightness and
contrast features
directly using the
and buttons
respectively, and
adjusting as
required.
Advanced
Access Function
Exit Menu
1 Press the button to activate the on screen menu (OSD).
2 Use the or buttons to scroll to the menu item you require. (For
menu items refer to the table on the next page)
3 Press the button to access the selected menu.
4 Use or to make your adjustments as required.
5 Press to save the new settings and return to the previous menu.
NOTE Your monitor is automatically demagnetized each time it is switched ON.
This ensures color purity. To maintain color purity, we recommend that
each week you switch the monitor off for at least 30 minutes before
switching it on again.
4 EnglishEnglish
HP 17” Color Monitor User’s Guide
Supported Video Modes
Use the table below to determine which menu item you require:
Menu Item Use to Adjust...
Brightness
Contrast
H-Position
V-Position
H-Size
V-Size
Pincushion
Display Timing
Color
Advanced
Moire V-Moire
Degauss
Recall
Geometry Pinbalance
Trapezoid
Temperature
Language
Halftone
H-Moire
Parallelogram
Rotation
V-Linearity
Brightness (image black level)
Contrast (image white level)
Horizontal Position
Vertical Position
Horizontal Size
Vertical Size
If the vertical edges appear to curl inwards or outwards
Displays current setting for horizontal frequency, refresh
rate and resolution when highlighted.
Press to display supported resolutions and refresh
rates.
Color temperature of your monitor
Language setting of the OSD
Set your monitor’s OSD to semi-transparent mode
Reduce the effects of vertical screen ripple in the
displayed image
Reduce the effects of horizontal screen ripple in the
displayed image
Remove unwanted magnetism that can result in color
1
impurity
YYYYeeees
Revert to preset factory settings. Select
s
s s
when
prompted.
If the vertical edges appear to curl to the left or right.
If the vertical edges appear to be tilted to the left or
right.
If the displayed image appears to be rotated.
If the displayed image appears to be compressed at the
top or the bottom.
If the vertical edges do not appear parallel.
1. Degaussing is accompanied by a brief instability of the displayed image and a slight humming sound.
EnglishEnglish 5
HP 17” Color Monitor User’s Guide
Supported Video Modes
Technical Specifications
Size 17-inch flat screen/ high contrast/
PICTURE TUBE
INTERFACE
SCANNING FREQUENCY
MAX. RESOLUTION
×V)
(H
WARM-UP TIME
PIXEL CLOCK
IMAGE SIZE
POWER MANAGEMENT
POWER SOURCE
OPERATING
ENVIRONMENT
STORAGE
ENVIRONMENT
CABINET DIMENSIONS
WEIGHT
TILT/SWIVEL STAND
HARDWARE
WARRANTY
1. See terms and conditions in the HP Hardware Warranty booklet provided separately.
Dot pitch 0.26 mm
Face Plate Anti-glare, anti-static, multi-layer coating
Fixed Video Cable With 15-pin mini D-SUB Connector
Horizontal 30 to 86kHz
Vertical 50 to 160 Hz
1600 × 1200 (60Hz)
30 minutes to reach optimum performance level
150 MHz
Standard Size: 306(H) × 230(V)mm
Maximum Size: 325(H) × 242(V)mm
On 100W (max) Constant green LED
Standby mode 45W (max) Green blinking LED
Suspend mode 7W (typical)
15W (max)
Active Off 5W (max) Green blinking LED
Off 5W (max) LED is Off
AC 100 to 240 V, 50/60Hz
Current 1.2 A
Temperature
Humidity 10% RH through 80% RH (without
Temperature -20 °C to 45 °C
Humidity 5% RH through 95% RH (without
420(W) × 452(H) × 432(D) mm (with Stand)
16.2 kg (Net)
Tilt Angle - 5° to +13
Swivel Angle +45°/-45
3 years - unless the original end-
user customer has otherwise
1
agreed to a shorter of warranty
at the time of purchase.
16.0-inch viewable image
Green blinking LED
0 °C to 40 °C
condensation)
condensation)
°
°
On-site service for first year, and return to
an HP or repair-authorized service center
for the following two years.
6 EnglishEnglish
WARNING
HP 17” Color Monitor User’s Guide
Regulatory Information
Regulatory Information
Notice for the USA: FCC Statement
Federal Communications Commission (FCC) Radio
Frequency Interference Statement (USA Only)
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protections
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try one of more of the following measures:
Relocate the radio or television antenna.
•
Move the computer away from the radio or television.
•
Plug the computer into a different electrical outlet, so that the computer and the radio or
•
television are on separate electrical circuits.
Make sure that all your peripheral devices are also FCC Class B certified.
•
Make sure you use only shielded cables to connect peripheral devices to your computer.
•
Consult your computer dealer, Hewlett-Packard, or an experienced radio/television technician
•
for help.
Hewlett-Packard’s system certification tests were conducted with HP-supported peripheral
devices and HP shielded cables, such as those you received with your system. Cables used with this
computer must be properly shielded to comply with the requirements of the FCC.
Changes or modifications not expressly approved by Hewlett-Packard could void the user’s
authority to operate the equipment.
Notice for MPR
Your HP 17.0-inch Color Monitor has been tested according to MPR 1990:8 for Emission properties
and meets the guidelines as given by MPR 1990:10 (2.01 - 2.04)
Notice for Korea
Notice for Japan
Notice for Canada
This Class “B” digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la Classe B est conforme a la norme NMB-003 du Canada.
EnglishEnglish 7
HP 17” Color Monitor User’s Guide
Regulatory Information
8 EnglishEnglish
According to ISO/IEC Guide 22 and CEN/CENELEC 45014
DECLARATION OF CONFORMITY
Manufacturer’s Name: HEWLETT-PACKARD France
Manufacturer’s Address: 5, Avenue Raymond Chanas - EYBENS
declares, that the product:
Product Name: HP 75 17-inch Color Monitor
Model Number: D8900A
conforms to the following product specifications:
38053 GRENOBLE CEDEX 09
FRANCE
•SAFETY - International: IEC 60950:1991 + A1 + A2 +A3 +A4 / GB4943-1995
- Europe: EN 60950:1992 + A1 + A2+A3 + A4
•
EMC - CISPR 22:1993+A1 + A2 / EN 55022:1994 + A1 +A2 Class B
- EN 50082-1:1992
IEC 801-2:1992 / prEN 55024-2:1992 - 4kV CD, 8 kV AD
IEC 801-3:1984 - 3V/m
IEC 801-4:1988 / prEN 55024-4:1992 - 1 kV Power Lines
- IEC 555-2:1982 + A1:1985 / EN 60555-2:1987
- IEC 61000-3-3:1994 / EN 61000-3-3:1995
- GB9254-1988
- FCC Title 47 CFR, Part 15 Class B
- ICES-003, Issue 2
- VCCI-B
- AS/NZ 3548:1992
Supplementary information:
CE-marking accordingly:
EMC Directive 89/336/EEC and the Low Voltage Directive 73/23/EEC, both amended by the Directive 93/68/EEC.
1)
The product was tested in a typical configuration with Hewlett-Packard Personal Computer Systems.
2)
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:
The product herewith complies with the requirements of the following Directives and carries the
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
2)
1)
Grenoble, July 1999 Quality Manager
For Compliance Information ONLY, contact:
USA contact: Hewlett Packard Company, Corporate Product Regulations Manager, 3000 Hanover Street, Palo Alto, CA 94304.
(Phone (415) 857-1501)
Jean Marc JULIA
Paper Not Bleached with Chlorine
Part Number: D8900-90030
Printed 05/99 in Korea
Loading...
