HP 15-AB032AX, 15-AB113UR, 15-AB115UR Schematics

5

www.schematic-x.blogspot.com

4

3

2

1

Chocolate_AMD Carrizo(L) DIS/UMA (14.0"/15.6"/17.3")

01

25MHz

DDR3L SODIMM1
Maxima 8GBs

RVS

PAGE 11

DDR3L SO-DIMM2
Maxima 8GBs

STD

RTL8166EH-CG
RTL8111HSH-CG

PAGE 12

LAN CHIP

on DB

NS892407

TRANSFORMER

on DB

SATA - HDD

PAGE 27

SATA - ODD

PAGE 27

System BIOS
SPI ROM

TPM SLB9665

Keyboard

Touch Pad

G-sensor

FAN

PAGE 06

PAGE 29

PAGE 28

PAGE 27

PAGE 29

PAGE 27

DDR3 800 ~ 1600 MT/s

DDR3 800 ~ 1600 MT/s

PCIE Gen 1 x 1 Lane

M2230

WLAN / BT Combo

PAGE 29

SATA0 6GB/s

SATA0 6GB/s

SPI Interface

LPC Interface

ENE KB9028Q C

Embedded Controller
TOP
Power :
Package : LQFP 128P
Size : 14 x 14 (mm)

N

PAGE 30

Processor : Carrizo

Power : 15 (Wat t)

Package : FP4 BGA

E

ALC3227

Audio Codec

Power :

ackage : MQFN

P
Size : 6 x 6 (mm)

Speaker

PAGE 23

AMD APU

PAGE 02-07

48MHz

Azalia

PAGE 23

Digital MIC

PAGE 21

VRAM DDR3L x 8 (900 MHz)
256 x 16 x 4

256 x 16 x 8
Max 4GBs

27MHz
PAGE 14

Gen3 x 8 Lane
Gen2 x4 Lane

AMD Meso-XT 64 bit

P

ower : 25 (Wat t)
Package : S3
Size : 23 x 23 (mm)

PAGE 10-14

DP Port1

HDMI Conn

PAGE 22

DP Port0

RTD2136R
DP to LVDS

Translator

P

AGE 20

LCD Conn

PAGE 21

eDP

PAGE 21

on DBU

on MB

2
3

USB3 PORT2,3

SB3 x1USB3.0 Interface

USB3 x1

USB2.0 Interface

Camera External USB BT USB2.0 x 2

4 0,657

PAGE 21 PAGE 28 PAGE 29

Touch screen

1

PAGE 29

HPA022642RTJR

Headphone amplif i er

PAGE 24 Combo Jack

Hp

MIC

PAGE 24

PAGE 18.19

on DB

PCB 6L/10L STACK UP

LAYER 1 : TOP
LAYER 2 : SGND
LAYER 3 : IN1
LAYER 4 : IN2
LAYER 5 : SVCC
LAYER 6 : BOT

Power Source

BQ2472 8H

System Charge Power (+BATCHG)

RT7238B / RT7238C

ystem Power (+3VPCU/+5VPCU/

S
+3VS5/ +5VS5)

RT8231BG QW

System Memory Power (+1.35VSUS/
+0.65V_DDR_VTT)

ISL62 771

Processor Power
(+VCC_CORE/+VDDNB_CORE)

AOZ1267QI-02 / A PW8824

Processor Power
(+0.95V/++0. 95VS5/+1.5V S5)

RT889 9AGQW

DGPU Power
(+VGA_CORE/+1.35V_ VGA)

RT8068 / APL3523A

DGPU Power

+0.95V_VGA/+3V _VGA/+1.8V_VGA )

(

LAYER 1 : TOP
LAYER 2 : SGND
LAYER 3 : IN1
LAYER 4 : IN2
LAYER 5 : VCC
LAYER 6 : GND
LAYER 7 : IN3
LAYER 8 : IN4
LAYER 9 : GND
LAYER 10 : BOT

D D

Realtek RTS5239

Card Reader

Power :
P

ackage : LQPF24

C C

Size : 4 x 4 (mm)

on DB

RJ45 Conn

PAGE 25

B B

A A

5

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v

Block Diagram

Block Diagram

Block Diagram

NB5

NB5

4

3

2

NB5

RD

Date: Sheet of

Date: Sheet of

Date: Sheet of

1

1 43Friday, October 17, 2014

1 43Friday, October 17, 2014

1 43Friday, October 17, 2014

1A

1A

1A

5

4

3

2

1

QBCON TOPBSQ

Carrizo

Carrizo DB phase use AJ1802CUT00

D D

AJ1802CUT01

AJ1802CUT02

U2B

U10

PCIE_RXP2_CARD23
PCIE_RXN2_CARD23

PCIE_RXP1_LAN23
PCIE_RXN1_LAN23

PCIE_RXP0_WLAN29
PCIE_RXN0_WLAN29

U9
T6

T5
T9

T8
P7

P6
U7

P_GPP_RXP[0]
P_GPP_RXN[0]

P_GPP_RXP[1]
P_GPP_RXN[1]

P_GPP_RXP[2]
P_GPP_RXN[2]

P_GPP_RXP[3]
P_GPP_RXN[3]

P_ZVDDP

PCIE

P_GPP_TXP[0]
P_GPP_TXN[0]

P_GPP_TXP[1]
P_GPP_TXN[1]

P_GPP_TXP[2]
P_GPP_TXN[2]

P_GPP_TXP[3]
P_GPP_TXN[3]

P_ZVSS/P_RX_ZVDDP

PCIE_TXP2_C

R1

PCIE_TXN2_C

R2

PCIE_TXP1_LAN_C

R4

PCIE_TXN1_LAN_C

R3

PCIE_TXP0_WLAN_C

N1

PCIE_TXN0_WLAN_C

N2
N4

N3

P_ZVSS_P_RX_ZVDD_095P_ZVDDP_P_TX_ZVDD_095

U6

C6 0.1U/10V_4
C7 0.1U/10V_4

C4 0.1U/10V_4
C5 0.1U/10V_4

C2 0.1U/10V_4
C3 0.1U/10V_4

PCIE_TXP2_CARD 23
PCIE_TXN2_CARD 23

PCIE_TXP1_LAN 23
PCIE_TXN1_LAN 23

PCIE_TXP0_WLAN 29
PCIE_TXN0_WLAN 29

CZ support GFX 0~7 & Gen3

02

CZ-L only support GFX 0~3 & Gen2

P10

L10

P9
N6

N5
N9

N8
L7

L6

L9
K6

K5
K9

K8

J7
J6

P_GFX_RXP[0]
P_GFX_RXN[0]

P_GFX_RXP[1]
P_GFX_RXN[1]

P_GFX_RXP[2]
P_GFX_RXN[2]

P_GFX_RXP[3]
P_GFX_RXN[3]

P_GFX_RXP[4]
P_GFX_RXN[4]

P_GFX_RXP[5]
P_GFX_RXN[5]

P_GFX_RXP[6]
P_GFX_RXN[6]

P_GFX_RXP[7]
P_GFX_RXN[7]

PEG_RXP013
PEG_RXN013

PEG_RXP113
PEG_RXN113

PEG_RXP213

C C

PEG_RXN213
PEG_RXP313

PEG_RXN313
PEG_RXP413

PEG_RXN413
PEG_RXP513

PEG_RXN513
PEG_RXP613

PEG_RXN613
PEG_RXP713

PEG_RXN713

P_GFX_TXP[0]
P_GFX_TXN[0]

P_GFX_TXP[1]
P_GFX_TXN[1]

P_GFX_TXP[2]
P_GFX_TXN[2]

P_GFX_TXP[3]
P_GFX_TXN[3]

P_GFX_TXP[4]
P_GFX_TXN[4]

P_GFX_TXP[5]
P_GFX_TXN[5]

P_GFX_TXP[6]
P_GFX_TXN[6]

P_GFX_TXP[7]
P_GFX_TXN[7]

M2
M1

L1
L2

L4
L3

J1
J2

J4
J3

H2
H1

G1
G2

G4
G3

GFX_TX0P_C
GFX_TX0N_C

GFX_TX1P_C
GFX_TX1N_C

GFX_TX2P_C
GFX_TX2N_C

GFX_TX3P_C
GFX_TX3N_C

GFX_TX4P_C
GFX_TX4N_C

GFX_TX5P_C
GFX_TX5N_C

GFX_TX6P_C
GFX_TX6N_C

GFX_TX7P_C
GFX_TX7N_C

C10 0.22U/10V_4
C11 0.22U/10V_4

C12 0.22U/10V_4
C13 0.22U/10V_4

C14 0.22U/10V_4
C15 0.22U/10V_4

C16 0.22U/10V_4
C17 0.22U/10V_4

C18 0.22U/10V_4
C19 0.22U/10V_4

C20 0.22U/10V_4
C21 0.22U/10V_4

C22 0.22U/10V_4
C23 0.22U/10V_4

C24 0.22U/10V_4
C25 0.22U/10V_4

PEG_TXP0 13
PEG_TXN0 13

PEG_TXP1 13
PEG_TXN1 13

PEG_TXP2 13
PEG_TXN2 13

PEG_TXP3 13
PEG_TXN3 13

PEG_TXP4 13
PEG_TXN4 13

PEG_TXP5 13
PEG_TXN5 13

PEG_TXP6 13
PEG_TXN6 13

PEG_TXP7 13
PEG_TXN7 13

Platform

Carrizo CH4222K9B04

arrizo-L

Gen 3
Gen 1/Gen 2

For DIS GPU

FP4 REV 1.0

FP4

P/NType

CH4102K1B03C

B B

+0.95V +0.95V

+0.95V

R3
196/F_4

R4
*1.69K/F_4

C26

0.1U/10V_4

R554
*1K/F_4

P_ZVSS_P_RX_ZVDD_095 P_ZVDDP_P_TX_ZVDD_095

R5
196/F_4

CZ: R5 & R3
CZ-L: R4 & R554

A A

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size

Size

Size

Document Number Re v

Document Number Re v

Document Number Re v

Carrizo 1/7 (PCIE)

Carrizo 1/7 (PCIE)

NB5

NB5

5

4

3

2

NB5

Date: Sheet of

Date: Sheet of

Date: Sheet of

Carrizo 1/7 (PCIE)

Friday, October 17, 2014 2 43

Friday, October 17, 2014 2 43

Friday, October 17, 2014 2 43

1

1A

1A

1A

5

4

3

2

1

03

D D

C C

B B

M_A_A[15:0]11

M_A_BS#[2..0]11

M_A_DM[7..0]11

TP2

M_A_DQSP011
M_A_DQSN011
M_A_DQSP111
M_A_DQSN111
M_A_DQSP211
M_A_DQSN211
M_A_DQSP311
M_A_DQSN311
M_A_DQSP411
M_A_DQSN411
M_A_DQSP511
M_A_DQSN511
M_A_DQSP611
M_A_DQSN611
M_A_DQSP711
M_A_DQSN711

M_A_CLKP011
M_A_CLKN011
M_A_CLKP111
M_A_CLKN111

M_A_RST#11
M_A_EVENT#11

M_A_CKE011
M_A_CKE111

M_A_ODT011
M_A_ODT111

M_A_CS#011
M_A_CS#111

M_A_RAS#11
M_A_CAS#11
M_A_WE#11

M_A_VREFDQ11 M_B_VREFDQ12

M_VREF

+1.35VSUS

R8
1K/F_4

M_A_A0
M_A_A1
M_A_A2
M_A_A3
M_A_A4
M_A_A5
M_A_A6
M_A_A7
M_A_A8
M_A_A9
M_A_A10
M_A_A11
M_A_A12
M_A_A13
M_A_A14
M_A_A15

M_A_BS#0
M_A_BS#1
M_A_BS#2

M_A_DM0
M_A_DM1
M_A_DM2
M_A_DM3
M_A_DM4
M_A_DM5
M_A_DM6
M_A_DM7
M_A_DM8

M_VREF

AE28

MA_ADD[0]

Y27

MA_ADD[1]

Y29

MA_ADD[2]

Y26

MA_ADD[3]

W28

MA_ADD[4]

W29

MA_ADD[5]

W26

MA_ADD[6]

U29

MA_ADD[7]

W25

MA_ADD[8]

U26

MA_ADD[9]

AG29

MA_ADD[10]

U27

MA_ADD[11]

T28

MA_ADD[12]

AK26

MA_ADD[13]

T26

MA_ADD[14]/MA_BG[1]

T25

MA_ADD[15]/MA_ACT_L

AG26

MA_BANK[0]

AG27

MA_BANK[1]

T29

MA_BANK[2]/MA_BG[0]

E19

MA_DM[0]

D21

MA_DM[1]

K21

MA_DM[2]

F29

MA_DM[3]

AP28

MA_DM[4]

AV26

MA_DM[5]

AR22

MA_DM[6]

BC22

MA_DM[7]

K29

MA_DM[8]

H19

MA_DQS_H[0]

G19

MA_DQS_L[0]

B22

MA_DQS_H[1]

A22

MA_DQS_L[1]

F23

MA_DQS_H[2]

E23

MA_DQS_L[2]

G27

MA_DQS_H[3]

F27

MA_DQS_L[3]

AP25

MA_DQS_H[4]

AP26

MA_DQS_L[4]

AW27

MA_DQS_H[5]

AV27

MA_DQS_L[5]

AV22

MA_DQS_H[6]

AU22

MA_DQS_L[6]

BA21

MA_DQS_H[7]

AY21

MA_DQS_L[7]

L27

MA_DQS_H[8]

L26

MA_DQS_L[8]

AE25

MA_CLK_H[0]

AE26

MA_CLK_L[0]

AD26

MA_CLK_H[1]

AD27

MA_CLK_L[1]

AB28

MA_CLK_H[2]

AB29

MA_CLK_L[2]

AB25

MA_CLK_H[3]

AB26

MA_CLK_L[3]

N29

MA_RESET_L

AE29

MA_EVENT_L

P27

MA_CKE0

P29

MA_CKE1

AK27

MA0_ODT[0]

AL26

MA0_ODT[1]

AH25

MA1_ODT[0]

AL25

MA1_ODT[1]

AH26

MA0_CS_L[0]

AL29

MA0_CS_L[1]

AH29

MA1_CS_L[0]

AL28

MA1_CS_L[1]

AG24

MA_RAS_L/MA_RAS_L_ADD[16]

AK29

MA_CAS_L/MA_CAS_L_ADD[15]

AH28

MA_WE_L/MA_WE_L_ADD[14]

B19

MA_VREFDQ

T32

M_VREF

U2A

MEMORY A

FP4 REV 1.0

MA_DATA[0]
MA_DATA[1]
MA_DATA[2]
MA_DATA[3]
MA_DATA[4]
MA_DATA[5]
MA_DATA[6]
MA_DATA[7]

MA_DATA[8]

MA_DATA[9]
MA_DATA[10]
MA_DATA[11]
MA_DATA[12]
MA_DATA[13]
MA_DATA[14]
MA_DATA[15]

MA_DATA[16]
MA_DATA[17]
MA_DATA[18]
MA_DATA[19]
MA_DATA[20]
MA_DATA[21]
MA_DATA[22]
MA_DATA[23]

MA_DATA[24]
MA_DATA[25]
MA_DATA[26]
MA_DATA[27]
MA_DATA[28]
MA_DATA[29]
MA_DATA[30]
MA_DATA[31]

MA_DATA[32]
MA_DATA[33]
MA_DATA[34]
MA_DATA[35]
MA_DATA[36]
MA_DATA[37]
MA_DATA[38]
MA_DATA[39]

MA_DATA[40]
MA_DATA[41]
MA_DATA[42]
MA_DATA[43]
MA_DATA[44]
MA_DATA[45]
MA_DATA[46]
MA_DATA[47]

MA_DATA[48]
MA_DATA[49]
MA_DATA[50]
MA_DATA[51]
MA_DATA[52]
MA_DATA[53]
MA_DATA[54]
MA_DATA[55]

MA_DATA[56]
MA_DATA[57]
MA_DATA[58]
MA_DATA[59]
MA_DATA[60]
MA_DATA[61]
MA_DATA[62]
MA_DATA[63]

MA_CHECK[0]
MA_CHECK[1]
MA_CHECK[2]
MA_CHECK[3]
MA_CHECK[4]
MA_CHECK[5]
MA_CHECK[6]
MA_CHECK[7]

MA_ZVDDIO_MEM_S

FP4

J17
F20
H20
E17
F17
K18
E20

A21
C21
C23
D23
B20
B21
B23
A23

G22
H22
E25
G25
J20
E22
H23
J23

F26
E27
J26
J27
H25
E26
G28
G29

AN26
AP29
AR26
AP24
AN29
AN27
AR29
AR27

AU26
AV29
AU25
AW25
AU29
AU28
AW26
AT25

AV23
AW23
AV20
AW20
AR23
AT23
AR20
AT20

BB23
BB22
BB20
AY19
BA23
BC23
BC21
BB21

K26
K28
N26
N28
J29
K25
L29
N25

AD29

M_A_DQ1
M_A_DQ2
M_A_DQ3
M_A_DQ4
M_A_DQ5
M_A_DQ6
M_A_DQ7

M_A_DQ8
M_A_DQ9
M_A_DQ10
M_A_DQ11
M_A_DQ12
M_A_DQ13
M_A_DQ14
M_A_DQ15

M_A_DQ16
M_A_DQ17
M_A_DQ18
M_A_DQ19
M_A_DQ20
M_A_DQ21
M_A_DQ22
M_A_DQ23

M_A_DQ24
M_A_DQ25
M_A_DQ26
M_A_DQ27
M_A_DQ28
M_A_DQ29
M_A_DQ30
M_A_DQ31

M_A_DQ32
M_A_DQ33
M_A_DQ34
M_A_DQ35
M_A_DQ36
M_A_DQ37
M_A_DQ38
M_A_DQ39

M_A_DQ40
M_A_DQ41
M_A_DQ42
M_A_DQ43
M_A_DQ44
M_A_DQ45
M_A_DQ46
M_A_DQ47

M_A_DQ48
M_A_DQ49
M_A_DQ50
M_A_DQ51
M_A_DQ52
M_A_DQ53
M_A_DQ54
M_A_DQ55

M_A_DQ56
M_A_DQ57
M_A_DQ58
M_A_DQ59
M_A_DQ60
M_A_DQ61
M_A_DQ62
M_A_DQ63

M_A_ZVDDIO

R6 39.2/F_4

M_A_DQ0

H17

M_A_DQ[0..63] 11

+1.35VSUS +1.35VSUS

M_B_A[15:0]12

M_B_BS#[2..0]12

M_B_DM[7..0]12

TP1

M_B_DQSP012
M_B_DQSN012
M_B_DQSP112
M_B_DQSN112
M_B_DQSP212
M_B_DQSN212
M_B_DQSP312
M_B_DQSN312
M_B_DQSP412
M_B_DQSN412
M_B_DQSP512
M_B_DQSN512
M_B_DQSP612
M_B_DQSN612
M_B_DQSP712
M_B_DQSN712

M_B_CLKP012
M_B_CLKN012
M_B_CLKP112
M_B_CLKN112

M_B_RST#12
M_B_EVENT#12

M_B_CKE012
M_B_CKE112

M_B_ODT012
M_B_ODT112

M_B_CS#012
M_B_CS#112

M_B_RAS#12
M_B_CAS#12
M_B_WE#12

M_B_A0
M_B_A1
M_B_A2
M_B_A3
M_B_A4
M_B_A5
M_B_A6
M_B_A7
M_B_A8
M_B_A9
M_B_A10
M_B_A11
M_B_A12
M_B_A13
M_B_A14
M_B_A15

M_B_BS#0
M_B_BS#1
M_B_BS#2

M_B_DM0
M_B_DM1
M_B_DM2
M_B_DM3
M_B_DM4
M_B_DM5
M_B_DM6
M_B_DM7
M_B_DM8

AG31

MB_ADD[0]

AC30

MB_ADD[1]

AC31

MB_ADD[2]

AB32

MB_ADD[3]

AA32

MB_ADD[4]

AA33

MB_ADD[5]

AA31

MB_ADD[6]

Y33

MB_ADD[7]

AA30

MB_ADD[8]

W32

MB_ADD[9]

AG32

MB_ADD[10]

Y32

MB_ADD[11]

W33

MB_ADD[12]

AL31

MB_ADD[13]

W30

MB_ADD[14]/MB_BG[1]

V32

MB_ADD[15]/MB_ACT_L

AH32

MB_BANK[0]

AG33

MB_BANK[1]

W31

MB_BANK[2]/MB_BG[0]

D25

MB_DM[0]

D29

MB_DM[1]

E33

MB_DM[2]

J33

MB_DM[3]

AR30

MB_DM[4]

AW30

MB_DM[5]

BC30

MB_DM[6]

BC26

MB_DM[7]

N33

MB_DM[8]

B26

MB_DQS_H[0]

A26

MB_DQS_L[0]

B30

MB_DQS_H[1]

A30

MB_DQS_L[1]

F32

MB_DQS_H[2]

E32

MB_DQS_L[2]

K32

MB_DQS_H[3]

J32

MB_DQS_L[3]

AR32

MB_DQS_H[4]

AR33

MB_DQS_L[4]

AW32

MB_DQS_H[5]

AW33

MB_DQS_L[5]

BA29

MB_DQS_H[6]

AY29

MB_DQS_L[6]

BA25

MB_DQS_H[7]

AY25

MB_DQS_L[7]

P32

MB_DQS_H[8]

N32

MB_DQS_L[8]

AE33

MB_CLK_H[0]

AE32

MB_CLK_L[0]

AE30

MB_CLK_H[1]

AE31

MB_CLK_L[1]

AD32

MB_CLK_H[2]

AD33

MB_CLK_L[2]

AC33

MB_CLK_H[3]

AC32

MB_CLK_L[3]

T33

MB_RESET_L

AG30

MB_EVENT_L

U32

MB_CKE0

U33

MB_CKE1

AL30

MB0_ODT[0]

AM32

MB0_ODT[1]

AJ32

MB1_ODT[0]

AM33

MB1_ODT[1]

AJ33

MB0_CS_L[0]

AL32

MB0_CS_L[1]

AJ30

MB1_CS_L[0]

AL33

MB1_CS_L[1]

AH33

MB_RAS_L/MB_RAS_L_ADD[16]

AK32

MB_CAS_L/MB_CAS_L_ADD[15]

AJ31

MB_WE_L/MB_WE_L_ADD[14 ]

A19

MB_VREFDQ

CR-L only channel B

MEMORY B

FP4 REV 1.0

U2I

MB_DATA[0]
MB_DATA[1]
MB_DATA[2]
MB_DATA[3]
MB_DATA[4]
MB_DATA[5]
MB_DATA[6]
MB_DATA[7]

MB_DATA[8]

MB_DATA[9]
MB_DATA[10]
MB_DATA[11]
MB_DATA[12]
MB_DATA[13]
MB_DATA[14]
MB_DATA[15]

MB_DATA[16]
MB_DATA[17]
MB_DATA[18]
MB_DATA[19]
MB_DATA[20]
MB_DATA[21]
MB_DATA[22]
MB_DATA[23]

MB_DATA[24]
MB_DATA[25]
MB_DATA[26]
MB_DATA[27]
MB_DATA[28]
MB_DATA[29]
MB_DATA[30]
MB_DATA[31]

MB_DATA[32]
MB_DATA[33]
MB_DATA[34]
MB_DATA[35]
MB_DATA[36]
MB_DATA[37]
MB_DATA[38]
MB_DATA[39]

MB_DATA[40]
MB_DATA[41]
MB_DATA[42]
MB_DATA[43]
MB_DATA[44]
MB_DATA[45]
MB_DATA[46]
MB_DATA[47]

MB_DATA[48]
MB_DATA[49]
MB_DATA[50]
MB_DATA[51]
MB_DATA[52]
MB_DATA[53]
MB_DATA[54]
MB_DATA[55]

MB_DATA[56]
MB_DATA[57]
MB_DATA[58]
MB_DATA[59]
MB_DATA[60]
MB_DATA[61]
MB_DATA[62]
MB_DATA[63]

MB_CHECK[0]
MB_CHECK[1]
MB_CHECK[2]
MB_CHECK[3]
MB_CHECK[4]
MB_CHECK[5]
MB_CHECK[6]
MB_CHECK[7]

MB_ZVDDIO_MEM_S

FP4

A25
C25
C27
D27
B24
B25
B27
A27

A29
C29
B32
D32
B28
B29
A31
C31

E30
E31
G33
G32
C33
D33
G30
G31

J30
J31
L33
L32
H32
H33
L30
L31

AN31
AP32
AT32
AU32
AN33
AN32
AR31
AT33

AU30
AV32
BA33
AY32
AU33
AU31
AW31
AY33

BC31
BB30
BB28
AY27
BB32
BA31
BC29
BB29

BB27
BB26
BB24
AY23
BA27
BC27
BC25
BB25

N30
N31
R33
R32
M32
M33
R30
R31

AF32

M_B_DQ0
M_B_DQ1
M_B_DQ2
M_B_DQ3
M_B_DQ4
M_B_DQ5
M_B_DQ6
M_B_DQ7

M_B_DQ8
M_B_DQ9
M_B_DQ10
M_B_DQ11
M_B_DQ12
M_B_DQ13
M_B_DQ14
M_B_DQ15

M_B_DQ16
M_B_DQ17
M_B_DQ18
M_B_DQ19
M_B_DQ20
M_B_DQ21
M_B_DQ22
M_B_DQ23

M_B_DQ24
M_B_DQ25
M_B_DQ26
M_B_DQ27
M_B_DQ28
M_B_DQ29
M_B_DQ30
M_B_DQ31

M_B_DQ32
M_B_DQ33
M_B_DQ34
M_B_DQ35
M_B_DQ36
M_B_DQ37
M_B_DQ38
M_B_DQ39

M_B_DQ40
M_B_DQ41
M_B_DQ42
M_B_DQ43
M_B_DQ44
M_B_DQ45
M_B_DQ46
M_B_DQ47

M_B_DQ48
M_B_DQ49
M_B_DQ50
M_B_DQ51
M_B_DQ52
M_B_DQ53
M_B_DQ54
M_B_DQ55

M_B_DQ56
M_B_DQ57
M_B_DQ58
M_B_DQ59
M_B_DQ60
M_B_DQ61
M_B_DQ62
M_B_DQ63

M_B_ZVDDIO

R7 39.2/F_4

M_B_DQ[0..63] 12

R9 0_4

R10

A A

1K/F_4

C27
1000P/50V_4

C28

0.1U/10V_4

1 2

C29

0.47U/10V_4

Place within 1000mil of the APU

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size

Size

Size

Document Number Re v

Document Number Re v

Document Number Re v

Carrizo 2/7 (MEM)

Carrizo 2/7 (MEM)

NB5

NB5

5

4

3

2

NB5

Carrizo 2/7 (MEM)

Date: Sheet o f

Friday, October 17, 2014 3 43

Date: Sheet o f

Friday, October 17, 2014 3 43

Date: Sheet o f

Friday, October 17, 2014 3 43

1

1A

1A

1A

5

4

3

2

1

+1.8V

R11 301/F_4
R12 301/F_4

CZ18V_CZL30V

D D

C C

R555 1K/F_4
R14 1K/F_4
R15 1K/F_4
R16 1K/F_4

MBCLK212,20,30

MBDATA212,20,30

CZ: Q1, R53, R54
CZ-L: R37, R40

CZ: Q2, R17, R7109
CZ-L: R578, R572

APU_PROCHOT#5

APU_DPST_PWM20

APU_DPST_PWM

EC new option

VRHOT36,38

H_PROCHOT#30

B B

APU_RST#
APU_PWRGD

APU_PROCHOT#_R
APU_ALERT#
APU_SIC
APU_SID

+3V +1.8V

R53

2.2K_4

MBCLK2

MBDATA2

+3V +1.8V

APU_PROCHOT#

APU_DPST_PWM

R578 *0_4
R572 *0_4

R20 0_4

R557 0_4

C37
220P/50V_4

R54

2.2K_4

R17

2.2K_4

APU_PROCHOT#_RAPU_PROCHOT#
APU_DPST_PWM_R

+3V CZ18V_CZL30V

+1.8V

5

6

2

+1.8V

R7109

2.2K_4

6

+1.8V

APU_PROCHOT#

R29 *0_4

R33 0_4

CZ: R33
C

Z-L: R29

43

1

Q1
DMN5L06DWK/50V_0.302A

5

43

1

Q2
DMN5L06DWK/50V_0.302A

2

APU_SIC

APU_SID

APU_PROCHOT#_R

APU_DPST_PWM_R

U2C

DP2_TXP[0]
DP2_TXN[0]

DP2_TXP[1]
DP2_TXN[1]

DP2_TXP[2]
DP2_TXN[2]

DP2_TXP[3]
DP2_TXN[3]

DP1_TXP[0]
DP1_TXN[0]

DP1_TXP[1]
DP1_TXN[1]

DP1_TXP[2]
DP1_TXN[2]

DP1_TXP[3]
DP1_TXN[3]

DP0_TXP[0]
DP0_TXN[0]

DP0_TXP[1]
DP0_TXN[1]

DP0_TXP[2]
DP0_TXN[2]

DP0_TXP[3]
DP0_TXN[3]

SVT0
SVC0
SVD0

SVT1
SVC1
SVD1

SIC
SID

RESET_L
PWROK

PROCHOT_L
ALERT_L

TDI
TDO
TCK
TMS
TRST_L
DBRDY
DBREQ_L

DISPLAY/SVI2/JTAG /TEST

FP4 REV 1.0

FP4

TEMPINRETURN

DP_STEREOSYNC/TEST36

VDDCR_GFX_SENSE

VDDCR_NB_SENSE

VDDCR_CPU_SENSE

B6
A6

D7
C7

A7
B7

9/10: EMI request place near CONN

DPB_LANE0_P
DPB_LANE0_N

DPB_LANE1_P
DPB_LANE1_N

DPB_LANE2_P
DPB_LANE2_N

DPB_LANE3_P
DPB_LANE3_N

SVT
SVC
SVD

GFX_SVT_R
GFX_SVC_R
GFX_SVD_R

APU_SIC
APU_SID

APU_RST#
APU_PWRGD

APU_PROCHOT#_R
APU_ALERT#

APU_TDI
APU_TDO
APU_TCK
APU_TMS
APU_TRST#
APU_DBRDY
APU_DBREQ#

MBCLK2
MBDATA2

C48
*150P/50V_4

APU_RST#
APU_PWRGD

C30 0.1U/10V_4
C31 0.1U/10V_4

C32 0.1U/10V_4
C33 0.1U/10V_4

C34 0.1U/10V_4
C35 0.1U/10V_4

C36 0.1U/10V_4
C38 0.1U/10V_4

R37 *0_4
R40 *0_4

R26 0_4

IN_D222
IN_D2#22

IN_D122
IN_D1#22

DMI

H

eDP

IN_D022
IN_D0#22

IN_CLK22
IN_CLK#22

INT_eDP_TXP020
INT_eDP_TXN020

INT_eDP_TXP120
INT_eDP_TXN120

Thermal Sensor

CPU_PWRGD_SVID_REG36,38

TP17

C47
*150P/50V_4

D9
C9

A2
A3

B4
A4

D5
C5

A5
B5

E2
E1

E3
E4

D1
D2

C1
B1

C15
D17
D19

B15
B16
A18

B18
C17

D15
C19

A15
B17

H15
H14
D13
G15
J14
C13
A11

DP_ZVSS

DP_ZVSS

DP_AUX_ZVSS

DP_BLON

DP_DIGON

DP_VARY_BL

DP2_AUXP
DP2_AUXN

DP2_HPD

DP1_AUXP
DP1_AUXN

DP1_HPD

DP0_AUXP
DP0_AUXN

DP0_HPD

RSVD_1

TEMPIN0
TEMPIN1
TEMPIN2

TEST410
TEST411

TEST28_H
TEST28_L

TEST4
TEST5
TEST6

TEST9
TEST10
TEST14
TEST15
TEST16
TEST17
TEST11
TEST18
TEST19

TEST31

TEST37

A9

DP_AUX_ZVSS

B9

APU_LVDS_BLON_R

G5

APU_DISP_ON_R

G6

APU_DPST_PWM_R

F11

H9
G9
E9

F7
E7
F5

INT_eDP_AUXP

F8

INT_eDP_AUXN

E8
G8

K24

CORETYPE
APU_TEMPIN0

E15

APU_TEMPIN1

E14

APU_TEMPIN2

E12

APU_TEMPRETURN

F14

APU_TEST410

AK24

APU_TEST411

AL24

APU_THERMDA

P24

APU_THERMDC

N24

APU_TEST6

AN24

APU_TEST9

AB8

APU_TEST10

Y9

APU_TEST14

B10

APU_TEST15

D11

APU_TEST16

A10

APU_TEST17

C11

APU_TEST11

B11

APU_TEST18

A14

APU_TEST19

B14

APU_TEST28_H

A13

APU_TEST28_L

B13

APU_TEST31

P26

DP_STEREOSYNC

E11

APU_TEST37

A17

R18 2K/F_4
R13 150/F_4

TP3
TP4
TP5
TP6

TP7
TP8
TP9
TP10
TP11

TP13
TP14

TP15
TP16

DP_STEREOSYNC: HDMI enable pin.

VDDCR_GFX_SENSE

VDDP_SENSE

VSS_SENSE

H11

VDDCR_NB_SENSE

J12

VDDCR_CPU_SENSE

G12

VDDP_SENSE

AY18

VSS_SENSE

H12

VDDCR_CPU_SENSE
VDDCR_NB_SENSE
VDDCR_GFX_SENSE

R43 0_4
R45 0_4
R46 0_4

TP7003

R562 0_4
R49 0_4
R50 0_4

CZ: R43, R562 Stuff
CZ-L: R43, R562 No Stuff

INT_HDMI_AUXP 22
INT_HDMI_AUXN 22

HDMI_HPD_Q 22

INT_eDP_AUXP 20
INT_eDP_AUXN 20
EDP_HPD 20,21

R24 0_4

R25 *1K/F_4
R27 *1K/F_4

R28 *1K/F_4
R30 *1K/F_4
R31 1K/F_4
R32 1K/F_4

R558 *1K/F_4
R559 *1K/F_4
R36 1K/F_4
R39 *1K/F_4
R41 *1K/F_4
R42 *1K/F_4

TP7004
TP7005
TP7006

DIFFERENTIAL ROUTING

APU_VDDGFX_RUN_FB_H 38
CPU_VDDNB_RUN_FB_H 36
CPU_VDD0_RUN_FB_H 36

APU Serial VID

CZ: 1.8V interface (level-shifter)
CZ-L: 3.3V interface

CZ: Q3, R57, R565, R57
CZ-L: R564, R568,

APU_LVDS_BLON_R

APU_DISP_ON_R

DMN5L06DWK/50V_0.302A

TP12

APU_DISP_ON_R

+1.8V
CZ18V_CZL30V
+1.8V

APU_VDDGFX_RUN_FB_L 38
CPU_VDDNB_RUN_FB_L 36
CPU_VDD0_RUN_FB_L 36

+1.8V

4 3

1

Q3

R564 *0_4
R568 *0_4

+1.8V

+1.8V

+3V

R565

5

2

R57

2.2K_4

6

APU_LVDS_BLONAPU_LVDS_BLON_R
APU_DISP_ON

2.2K_4

APU_LVDS_BLON

APU_DISP_ON

04

APU_LVDS_BLON 21

APU_DISP_ON 21

HDT+ Connector for Debug only

Can remove on MP

CPU_LDT_RST_HTPA#

A A

APU_RST#
APU_PWRGD

1
2

74LVC2G07GW

U3
TC7SH08FU

4

U4

A1
GND

VCC

A23Y2

5

C52

0.1U/10V_4

Y1

+3V

+1.8V

C51

0.1U/10V_4

APU_RST#

2
1

3 5

+3V

+1.8V

1K/F_4

+1.8V

R72

R71

1K/F_4

R69

R68

*0_4

0_4

APU_RST_L_BUF

6
5

APU_PWROK_BUF

4

APU_TEST18
APU_TEST19
APU_RST_L_BUF
CPU_LDT_RST_HTPA#

INT

TP26

APU_DBREQ#
APU_DBRDY
APU_TCK
APU_TMS
APU_TDI
APU_TRST#
APU_TDO
APU_PWROK_BUF

Close to HDT & No remove.

APU_TDI
APU_TCK
APU_TMS
APU_TRST#

APU_DBREQ#

R573 1K/F_4
R574 1K/F_4
R75 1K/F_4
R79 1K/F_4

R82 1K/F_4

4

J1

20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1

*HDT CONN

88511-2001-20p-l

+1.8V

IO Thermal Protect

+3VPCU

R560

16.5K/F_4

For 65 degree, 1.8V limit, (SW)

R44

3.3K/F_4

For 75 degree, 1.2v limit, (HW)

R52
0_4

R56
100K_4 NTC

9/2: Del by Talant's mail 22:01

C49

0.1U/10V_4

1 2

C50

0.1U/10V_4

1 2

CPU_SVT36
CPU_SVC36

CPU_SVD36

GFX Serial VID

THRM_MONITOR1 30

3

GFX_SVT38
GFX_SVC38

GFX_SVD38

Place near APU within 500mil

R569 0_4
R65 0_4
R571 0_4

Place near APU within 500mil

R80 0_4
R81 0_4
R83 0_4

R566
*1K/F_4

R76
*1K/F_4

2

R62

R567

*1K/F_4

*1K/F_4

SVT
SVC
SVD

+1.8V

9/2: confirm setting with AMD Ronald

R78

R77

*1K/F_4

1K/F_4

GFX_SVT_R
GFX_SVC_R
GFX_SVD_R

VFIX MODE

0
0
110 0.9V

VID Override table (VDD)

NB5

NB5

NB5

SVDSVC

0

11

Boot Voltage

1.1V

1.0V

0.8V

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size

Size

Size

Document Number Re v

Document Number Re v

Document Number Re v

Carrizo 3/7 (DIS/MISC)

Carrizo 3/7 (DIS/MISC)

Carrizo 3/7 (DIS/MISC)

Date: Sheet o f

Friday, October 17, 2014 4 43

Date: Sheet o f

Friday, October 17, 2014 4 43

Date: Sheet o f

Friday, October 17, 2014 4 43

1

1A

1A

1A

5

D D

PCIE_RST#_R113,23,29

+3V

R99 2.2K_4
R100 2.2K_4

+3VS5

+3VS5

R196 10K/F_4
R7044 10K/F_4
R576 *1K/F_4

1 2

G2

*SOLDERJUMPER-2

R104 2.2K_4
R107 2.2K_4
R110 10K/F_4
R113 10K/F_4
R114 *10K/F_4

C C

PCIE_RST#_R1

RSMRST#30

to DDR3 SMBUS

SMB_RUN_CLK
SMB_RUN_DAT

PCIE_CLKREQ_CARD#

SYS_RST# internal 10K pull up

to TP SMBUS

SMB_ALW_CLK
SMB_ALW_DAT

DNBSWON#
PCIE_WAKE#

DGPU_PWROK

CLKREQG#

SYS_RST#

D2 RB501V-40

Only CZ Stuff

PCIE_WAKE# PU & LAN use 0 ohm to open.

B B

To Azalia

ACZ_SDOUT_AUDIO23

ACZ_SYNC_AUDIO23

BIT_CLK_AUDIO23

ACZ_RST#_AUDIO23

A A

DGPU_PR_EN30,41,43

C59 *10P/50V_4

ACZ_SDIN023

5

R123 33_4
R124 33_4

For EMI

R125 33_4
R126 33_4

Pure UMA can remove

R469

30K/F_4

Q31

METR5213-G

C589

0.47U/6.3V_4

2

1 3

U5

*MC74VHC1G08DFT2G

4

R96 0_4

+1.8VS5

21

for GPIO145~148
CZ pop those resistor
CZ-L can NC them

ACZ_SDOUT_R
ACZ_SYNC_R

ACZ_BCLK_R
ACZ_RST#_R
ACZ_SDIN0

VGA_REQ

D12 RB500V-40

35

R97
47K/F_4

C55
1U/6.3V_4

21

4

+3V

+3VS5+3VS5

R92
*4.7K/F_4

1
2

KBC_RST#29,30

DNBSWON#30

SYS_RST#6
PCIE_WAKE#23,29

DGPU_PWROK30,41,43

APU_S5_MUX_CTRL40

ODD_PLUGIN#27
PCI_SERR#30

PCIE_CLKREQ_CARD#23
PCIE_CLKREQ_LAN#23
PCIE_CLKREQ_WLAN#29

ODD_PWR27

C57 18P/50V_4

C58 18P/50V_4

CLKREQG#

4

R84 10K/F_4
R86 *10K/F_4
R88 *10K/F_4
R90 *10K/F_4
R93 *10K/F_4
R7103 10K/F_4
R7105 *10K/F_4
R7107 *10K/F_4

C53 150P/50V_4

SUSB#30

SUSC#30

EC_RCIN#30
EC_A20GATE30
SIO_EXT_SCI#30
SIO_EXT_SMI#30

R105 *10K/F_4
R106 *10K/F_4
R7091 10K/F_4
R7092 10K/F_4

BOARD_ID0
BOARD_ID1
BOARD_ID2
BOARD_ID3
BOARD_ID4
BOARD_ID5
BOARD_ID6
BOARD_ID7

PCIE_RST#_R PCIE_RST#

TP30

TP35
TP36
TP37
TP39

23

4 1

R98 33_4

C56 *100P/50V_4

TP27

R7053 10K/F_4
R7054 10K/F_4
R7055 10K/F_4
R7056 10K/F_4

RTC_CLK6,30

R116

Y1

20M_4

32.768KHZ

R95 33_4

SYS PWRGD

CPU_VRM8380_PG36

ECPWROK30

TP41

R575 *10K/F_4
R87 10K/F_4
R89 10K/F_4
R91 10K/F_4
R94 10K/F_4
R7104 *10K/F_4
R7106 10K/F_4
R7108 10K/F_4

C54150P/50V_4

LPC_RST#_R
PCIE_RST#

RSMRST#_R

DNBSWON#
SYS_PWRGD

SYS_RST#
PCIE_WAKE#

DGPU_PWROK

APU_TEST0
APU_TEST1
APU_TEST2

EC_RCIN#
EC_A20GATE
SIO_EXT_SCI#
SIO_EXT_SMI#

R102 0_4

LLB#

PCIE_CLKREQ_CARD#
PCIE_CLKREQ_LAN#
PCIE_CLKREQ_WLAN#

CLKREQG#
JTAG_TRST#

JTAG_TDI
JTAG_TCK
JTAG_TDO

ACZ_BCLK_R
ACZ_SDIN0
ACZ_SDIN1
ACZ_SDIN2
ACZ_RST#_R
ACZ_SYNC_R
ACZ_SDOUT_R

GPIO145
GPIO146
GPIO147

GPIO148

32K_X1

32K_X2

D1 BAT54AW-L

Model

CZ 14" UMA

CZ 14" SG

CZ 15" UMA

CZ 15" SG

CZ 17" UMA

CZ 17" SG

BB12

LPC_RST_L

AN7

PCIE_RST_L/EGPIO26

AE4

RSMRST_L

AE1

PWR_BTN_L/AGPIO0

BC9

PWR_GOOD

AF2

SYS_RESET_L/AGPIO1

AG2

WAKE_L/AGPIO2

AK7

SLP_S3_L

AH5

SLP_S5_L

AE8

S0A3_GPIO/AGPIO10

AH8

S5_MUX_CTRL/EGPIO42

AH6

TEST0

AK8

TEST1/TMS

AE3

TEST2

AY15

ESPI_RESET_L/KBRST_L/AGPIO129

BC19

GA20IN/AGPIO126

AD7

LPC_PME_L/AGPIO22

BB13

LPC_SMI_L/AGPIO86

AG3

AC_PRES/USB_OC4_L/IR_RX0/AGPIO23

AD5

IR_TX0/USB_OC5_L/AGPIO13

AL8

IR_TX1/USB_OC6_L/AGPIO14

AN8

IR_RX1/AGPIO15

AE2

IR_LED_L/LLB_L/AGPIO12

BC15

CLK_REQ0_L/SATA_IS0_L/ SATA_ZP0_L/AGPIO92

BB17

CLK_REQ1_L/AGPIO115

BC17

CLK_REQ2_L/AGPIO116

BB18

CLK_REQ3_L/SATA_IS1_L/SATA_ZP1_L/EGPIO131

BB16

CLK_REQG_L/OSCIN/EGPIO132

AH9

USB_OC0_L/TRST_L/AGPIO16

AG1

USB_OC1_L/TDI/AGPIO17

AH2

USB_OC2_L/TCK/AGPIO18

AL9

USB_OC3_L/TDO/AGPIO24

AU6

AZ_BITCLK/I2S_BCLK_MIC

AR8

AZ_SDIN0/I2S_DATA_MIC[0]

AP6

AZ_SDIN1/I2S_LR_PLAYBACK

AR5

AZ_SDIN2/I2S_DATA_PLAYBACK

AU9

AZ_RST_L/I2S_LR_MIC

AT9

AZ_SYNC/I2S_BCLK_PLAYBACK

AR7

AZ_SDOUT/I2S_DATA_MIC1

BB10

I2C0_SCL/EGPIO145

BB9

I2C0_SDA/EGPIO146

BB7

I2C1_SCL/EGPIO147

BC7

I2C1_SDA/EGPIO148

AG7

RTCCLK

AT1

X32K_X1

AT2

X32K_X2

3

ID0

0

1

0

1

0 0 0

1 0 0

ACPI/SD/AZ/GPIO/RTC/I2C/ UART/MISC

S5

X

X

S5

S5
X

S5

S5

S5

X

S5

Power Domain

CZ CZ-L

S0

S0

S0

S0

S5

S5

S0

X

S5

S5

S5

S5
S5

S5

S5

S5

S5
S5

S5
S0

S0

S0

S0

S0

S0

S0

S0

S0

S5

S5

S5

S5

S5

S5
S5

S5

S0

X

S0

S0
S0

S0

S0

S0

FP4 REV 1.0

BOARD ID TABLE

ID1 ID2 ID3 ID4 ID5 ID6

0

0

0

0

SD0_CD/AGPIO25

AGPIO3

S5

AGPIO4

S5

AGPIO5

S5

AGPIO8
AGPIO9

AGPIO40
AGPIO64
AGPIO65

SPKR/AGPIO91

FANIN0/AGPIO84

BB2
BB5
BC2
BB4
AY5

BC3
BA3
BC5
BA5
BB6

BA15
AY17

AG5
AG4

AL5
AL6
AJ1
AJ3
AH1
AJ4
AK5
AD8
AG8
AW15
AU15

AT15
AU12
AT14
AR14
BC13

BA17
AN5
BB14

BA19
BC18

BB19
AY9

AW8
AV5
AV8
AW9

AV11
AU7
AT11
AR11
AP9

0

0

0

0

0
0

R111 *0_4
R112 0_4

U2D

S0

S0
S0
S0
S0
S5

FP4

0

0

0

0

0

1

0

1

1

1

S0

S0

SD0_PWR_CTRL/AGPIO102

X

S0
S0

S5

S0

S0
S0

S0

S0

S0
S0

S0
S0S5S0
S0S5S0

S0

S0

SCL0/I2C2_SCL/EGPIO113

S0

S0

SDA0/I2C2_SDA/EGPIO114

S0

S0

S5

S5

SDA1/I2C3_SDA/AGPIO20

S5

S5

S5

S5

S5

S5

S5

S5

S5

S5

X

S5

X
S0

S0

S0

S0

S0

S0

S0

S0
S0

S0

AGPIO71/SGPIO_DATAOUT

S0

S0

AGPIO72/SGPIO_DATAIN

S0

S0

S0

S0

S5

S0

S0

S0

S0

S0

S0

S0
S0

S0
S0

X

S0

X

S0

X
X

S0

X

S0

UART1_CTS_L/BT_I2S_BCLK/EGPIO140

X

UART1_RXD/BT_I2S_SDI/EGPIO141

S5
X

UART1_TXD/BT_I2S_SDO/EGPIO143

X

UART1_INTR/BT_I2S_LRCLK/AGPIO144

S0

SD0_WP/EGPIO101

SD0_CLK/EGPIO95

SD0_CMD/EGPIO96

SD0_DATA0/EGPIO97
SD0_DATA1/EGPIO98
SD0_DATA2/EGPIO99

SD0_DATA3/EGPIO100

SD0_LED/EGPIO93

SCL1/I2C3_SCL/AGPIO19

S5
S5
S5

AGPIO6/LDT_RST_L

AGPIO7/LDT_PWROK

VDDGFX_PD/AGPIO39

AGPIO66/SHUTDOWN_L

AGPIO68/SGPIO_CLK

AGPIO69/SGPIO_LOAD

BLINK/USB_OC7_L/AGPIO1 1

GENINT1_L/AGPIO89
GENINT2_L/AGPIO90

FANOUT0/AGPIO85

UART0_CTS_L/EGPIO135

UART0_RXD/EGPIO136

UART0_RTS_L/EGPIO137

UART0_TXD/EGPIO138

UART0_INTR/AGPIO139

UART1_RTS_L/EGPIO142

1

1

1

1

1

1

BOARD_ID5

BOARD_ID6
BOARD_ID0

BOARD_ID1
BOARD_ID2
BOARD_ID3
BOARD_ID4
BOARD_ID7

SMB_RUN_CLK
SMB_RUN_DAT

SMB_ALW_CLK
SMB_ALW_DAT

AGPIO4

AGPIO8

PROCHOT#_CTRL
BT_COMBO_OFF

AGPIO66

AGPIO69

2

0

0

0

0

0

0

R103 0_4

TP7002

ID7

0

0

0

0

0

0

SMB_RUN_CLK 11,12,20
SMB_RUN_DAT 11,12,20

SMB_ALW_CLK 27

SMB_ALW_DAT 27

AGPIO3 6

ODD_DA#_FCH 27

VDDGFX_PD 38

APU_VRM_GFX_PWRGD 38

BT_COMBO_OFF 29

ACC_LED# 27

VGA_RSTB 13
VGA_ON_SB 30

ACZ_SPKR 23

AGPIO11 6

ACCEL_INTH# 29

RF_OFF 29

TP40

APU_PROCHOT# 4

GENINT1: HVB function
V

ss:e nabke

NC: disable

+3VS5

R117 *2.2K_4
R119 *1K/F_4
R121 *2.2K_4

1

BOARD ID SETTING

Board ID 0 De finition

AGPIO66

UMA

SG

Definition

14"

15"

Definition

Pavi lion

Rese rve

Definition

CZ/C Z-L0/1

Rese rve00

R197 *10K/F_4
R198 10K/F_4

R201 10K/F_4
R7051 *10K/F_4
R7052 *10K/F_4

R118 15K/F_4
R120 15K/F_4
R122 15K/F_4

0

1

Board ID [2:1]

00

01

10 17"

Board ID [4:3]

00

01

10 Rese rve

Board ID [5]

Board ID [7:6] Definit ion

AGPIO4
AGPIO8

AGPIO69

BT_COMBO_OFF

Only CZ Stuff if no used

Only CZ-L Stuff if no used

APU_TEST0

APU_TEST1

APU_TEST2

05

+3VS5

+3V

Follow AMD checklist 53537_1_03 suggestion to stuff R118/R120/R122

TEST2 TEST1 TEST0 Description

0

+1.8V +3V

R127

R128

*10K/F_4

C60
*2.2U/6.3V_6

3

10K/F_4

R129 0_4

CZ: R128
CZ-L: R127

SYS_PWRGD

2

2

3

1

0 0

0

0

0

1

1

TMS

1 TMS

FCH TAP accessible from APU when TAPEN is asserted
FCH JTAG pins are overloaded for multiple
functions, in this configuration the FCH JTAG are
used as non-JTAG pins

1

Reserved

X

Reserved

FCH JTAG multi-function pins are configured as

0

JTAG pins, in this configuration the FCH TAP
can be accessed from FCH JTAG pins

Use on ATE only

1

Yuba JTAG enabled

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size

Size

Size

Document Number Re v

Document Number Re v

Document Number Re v

Carrizo 4/7 (GPIO/AZ/UARTH)

Carrizo 4/7 (GPIO/AZ/UARTH)

NB5

NB5

NB5

Carrizo 4/7 (GPIO/AZ/UARTH)

Date: Sheet o f

Friday, October 17, 2014 5 43

Date: Sheet o f

Friday, October 17, 2014 5 43

Date: Sheet o f

Friday, October 17, 2014 5 43

1

1A

1A

1A

5

4

3

2

1

Only CZ Stuff if no used

+3V

R202 10K/F_4
R203 10K/F_4

R204 10K/F_4

D D

C C

R580 10K/F_4

C66

5.6P/50V_4

C67

5.6P/50V_4

SATA_LED#27

1

2

4

3

EGPIO67
EGPIO70

AGPIO76
EGPIO119

Y2

48MHZ +-10PPM

U6

*MC74VHC1G08DFT2G

4

R140
1M/F_4

+3V

3 5

R132 0_4

48M_X1

48M_X2

CLK_33M_KBC30

CLK_PCI_TPM29

CLK_33M_DEBUG29

SATA_TXP027
SATA_TXN027

HDD

SATA_RXN027
SATA_RXP027

SATA_TXP127
SATA_TXN127

ODD

SATA_RXN127

R131 *560_4/F

RP2

0_4P2R_4

RP3

0_4P2R_4

RP1

0_4P2R_4

RP4

0_4P2R_4

R138 22_4
R137 *22_4
R139 22_4

SATA_RXP127

2
4

2
4

2
4

2
4

TP59
TP60

LFRAME#29,30

CLKRUN#30

R130 1K/F_4
R134 1K/F_4

1
3

1
3

1
3

1
3

TP44

TP45

LAD029,30
LAD129,30
LAD229,30
LAD329,30

TP46

SERIRQ29,30

R7110

TP48
TP49

TP51
TP52

TP53

TP54

TP42

TP43

CLK_GFX_P_R
CLK_GFX_N_R

CLK_PCIE_CARDP_R
CLK_PCIE_CARDN_R

CLK_PCIE_LANP_R
CLK_PCIE_LANN_R

CLK_PCIE_WLAN_R
CLK_PCIE_WLAN#_R

GPP_CLK3P
GPP_CLK3N

10K/F_4

C61
*0.1U/10V_4

+0.95V

2
1

CLK_GFX_P13
CLK_GFX_N13

CLK_PCIE_CARDP23
CLK_PCIE_CARDN23

CLK_PCIE_LANP23
CLK_PCIE_LANN23

CLK_WLAN_P29
CLK_WLAN_N29

C62 *10P/50V_4
C64 *10P/50V_4

C65 *10P/50V_4

+3V

Integrated Clock Mode:
Leave unconnected.

SATA_CALRN
SATA_CALRP

EGPIO67
EGPIO70

SB_SATA_LED#

48M_X1

48M_X2

LPC_CLK0
LPC_CLK1

LFRAME#
LDRQ#0

LPC_PD#

SPI_CLK
SPI_CS0#

EGPIO119
SPI_SI

SPI_SO
SPI_WP
SPI_HOLD#

AGPIO76

AU3

SATA_TX0P

AU4

SATA_TX0N

AV1

SATA_RX0N

AV2

SATA_RX0P

AY2

SATA_TX1P

AY1

SATA_TX1N

AW4

SATA_RX1N

AW3

SATA_RX1P

AW1

SATA_ZVSS

AW2

SATA_ZVDDP

AT17

DEVSLP[0]/EGPIO67

AT12

DEVSLP[1]/EGPIO70

BB15

SATA_ACT_L/AGPIO1 30

AU2

SATA_X1

AU1

SATA_X2

U4

GFX_CLKP

U3

GFX_CLKN

U1

GPP_CLK0P

U2

GPP_CLK0N

W4

GPP_CLK1P

W3

GPP_CLK1N

W1

GPP_CLK2P

W2

GPP_CLK2N

Y2

GPP_CLK3P

Y1

GPP_CLK3N

BC10

X25M_48M_OSC

T2

X48M_X1

T1

X48M_X2

AW14

LPCCLK0/EGPIO74

AY13

LPCCLK1/EGPIO75

BB11

LAD0

BA11

LAD1

AY11

LAD2

BA13

LAD3

AV14

LFRAME_L

BA1

ESPI_ALERT_L/LDRQ 0_L

BC14

SERIRQ/AGPIO87

BC11

LPC_CLKRUN_L/AGPIO88

AE9

LPC_PD_L/AGPIO21

BC6

SPI_CLK/ESPI_CLK /EGPIO117

BB8

SPI_CS1_L/EGPIO1 18

AW7

SPI_CS2_L/ESPI_C S_L/EGPIO119

BA9

SPI_DI/ESPI_DAT A/EGPIO120

AY7

SPI_DO/EGPIO121

AW11

SPI_WP_L/EGPIO1 22

BA7

SPI_HOLD_L/EGPIO133

AW12

SPI_TPM_CS_L/AGPIO76

U2E

CLK/SATA/USB/SPI/LPC

FP4 REV 1.0

FP4

USBCLK/25M_48M_OSC

USB_ZVSS

USB_HSD0P
USB_HSD0N

USB_HSD1P
USB_HSD1N

USB_HSD2P
USB_HSD2N

USB_HSD3P
USB_HSD3N

USB_HSD4P
USB_HSD4N

USB_HSD5P
USB_HSD5N

USB_HSD6P
USB_HSD6N

USB_HSD7P
USB_HSD7N

USB_SS_ZVSS

USB_SS_ZVDDP

USB_SS_0TXP
USB_SS_0TXN

USB_SS_0RXP
USB_SS_0RXN

USB_SS_1TXP
USB_SS_1TXN

USB_SS_1RXP
USB_SS_1RXN

USB_SS_2TXP
USB_SS_2TXN

USB_SS_2RXP
USB_SS_2RXN

USB_SS_3TXP
USB_SS_3TXN

USB_SS_3RXP
USB_SS_3RXN

AP8

USB_ZVSS

AP5
AR2

AR1
AR3

AR4
AN2

AN1
AN3

AN4
AM1

AM2
AL2

AL1
AL3

AL4
AK2

AJ2

R133 11.8K/F_4

USBP0+ 23
USBP0- 23

USBP1+ 29
USBP1- 29

USBP4+ 21
USBP4- 21

USBP5+ 29
USBP5- 29

USBP6+ 23
USBP6- 23

USBP7+ 28
USBP7- 28

Left side USB2.0 port

TOUCH SCREEN

Camera USB

WLAN Min-Card
Left side USB Combo 3.0/2.0.

Right side USB Combo 3.0/2.0.
CZ: Maximum 8 devices (Ex: 8 USB2.0 – OR-- 4 USB2.0 + 4 USB3.0 external, etc…)
CZ-L: Maximum 8 devices (Ex: 8 USB2.0 – OR-- 6 USB2.0 + 2 USB3.0 external, etc…)

+0.95VS5

Support S3~S5 wake up

+0.95V

No support S3~S5 wake up

+3VS5 +3VS5 +3VS5+3VS5+3V +3V +3V

AD2
AD1

AA3
AA4

W9
W8

AA2
AA1

W5
W6

AC1
AC2

Y6
Y7

AC4
AC3

AB5
AB6

USBSS_CALRN
USBSS_CALRP

R1351K/F_4
R1361K/F_4

USB30_TX2+ 23

USB30_TX2- 23

USB30_RX2+ 23

USB30_RX2- 23
USB30_TX3+ 28

USB30_TX3- 28

USB30_RX3+ 28

USB30_RX3- 28

R579 0_4

R194 *0_4

Left side USB Combo 3.0/2.0.

Right side USB Combo 3.0/2.0.

06

STRAPS PINS

R142

LFRAME#

SPI ROM

DEFAULT

LPC ROM

2

R141

10K/F_4

*10K/F_4

R150

R151

2K/F_4

*2K/F_4

Follow FAE comment: R154 change to 2K, R147 to 10k, R146 is NC

AGPIO3

Int Pull-Up

CZ-L C Z

1.8V SPI ROM

3.3V SPI ROM

DEFAULT

B B

R7102 *0_4

R149

10K/F_4

+3VS5+1.8V_ROM

CZ:1.8V

CZ-L use 3.3V ROM

CZ use 1.8V ROM(Default)

APU SPI ROM

A A

Vender

Socket

GGD

EON

Size

8M
8M
8M

P/N (3.3V)

AKE3EFP0N07WND
AKE3EGN0Q01

AKE3EZN0Q01

EC_SPI_WP_R30

EC_BIOS_CS#30

EC_BIOS_SPI_CLK_I30

EC_BIOS_WR#30
EC_BIOS_RD#30

DFHS08FS023

5

P/N (1.8V)

EC_SPI_WP_R
EC_BIOS_CS#
EC_BIOS_SPI_CLK_I
EC_BIOS_WR#
EC_BIOS_RD#

SPI_CS0#
SPI_CLK
SPI_SO
SPI_SI

SPI_WP

+3VS5

+1.8V_ROM

SPI_HOLD#

SPI_CLK

EC50
*22P/50V_4

10K/F_4

EMI

R157 33_4
R158 33_4
R159 33_4
R160 0_4

R161 *0_4
R162 *10K/F_4

1K/F_4

R7072

R163 0_4

4

R7100

+1.8V_ROM

R148

*10K/F_4

EC_BIOS_CS#
EC_BIOS_SPI_CLK_I
EC_BIOS_WR#
EC_BIOS_RD#

EC_SPI_WP_R

CZ-L: R162
CZ: R7072

+3VS5

CZ-L:3.3V

R7101 0_4

C68 0.1U/10V_4

U7

1

CE#

VDD

6

SCK

5

SI

2

SO

HOLD#

3

WP#

VSS

A25QE32M-F/Q

DFHS08FS023

91960-0084L-8P-SOCKET

8

7
4

OVERLAP COMMON PADS WHERE
POSSIBLE FOR DUAL-OP RESISTORS.

AGPIO35
RTC_CLK5,30
AGPIO115
SYS_RST#5

REQUIRED STRAPS

LPC_CLK0

BOOT FAIL TIMER

PULL

ENABLED

HIGH

BOOT FAIL TIMER

PULL

DISABLED

LOW

3

DEFAULT

LPC_CLK0
LPC_CLK1

LFRAME#

CZ: pop R144
CZ-L:pop R153

LPC_CLK1

Use 48Mhz crystal clock
and generate both internal
and external clocks

DEFAULT

Use 100Mhz PCIE clock as
reference clock and generate
internal clocks only

R144

R577

10K/F_4

10K/F_4

R153

R152

*2K/F_4

*2K/F_4

Enhanced reset logic
(for quicker S5 resume)

DEFAULT DEFAULT DEFAULT

Default to
traditional reset logic

NB5

NB5

NB5

R146

R145
10K/F_4

R154
*2K/F_4

RTC_CLK

Int Pull-Up Int Pull-Up Int Pull-Up

Coin battery is
on board.

Coin battery is
not on board.

Size

Size

Size

Date: Sheet o f

Date: Sheet o f

Date: Sheet o f

R147

*10K/F_4

10K/F_4

R156

R155

*2K/F_4

*2K/F_4

AGPIO11

BLINK

LDT_RST#/LDT_PWRGD
output to APU

LDT_RST#/LDT_PWRGD
output to Pads

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Document Number Re v

Document Number Re v

Document Number Re v

Carrizo 5/7 (SATA/USB/SPI)

Carrizo 5/7 (SATA/USB/SPI)

Carrizo 5/7 (SATA/USB/SPI)

Friday, October 17, 2014 6 43

Friday, October 17, 2014 6 43

Friday, October 17, 2014 6 43

1

SYS_RST#

normal reset mode

DEFAULT

short reset mode

1A

1A

1A

5

4

3

2

1

07

U8
W7
W12
W15
W18
W21
Y8
Y10
Y13
Y16
Y19
Y22
AB7
AB9
AB12
AB15
AB18
AB21
AD6
AD10
AD13
AD16
AD19
AD22
AE7
AE12
AK9
AG10
AK10
AG13
AK13
AG16
AK16
AG19
AK19
AG22
AK22
AH7
AE18
AE21
AH21
AG6
AH12
AN6
AH15
AH18
AL7
AK6
AE15

L8
L13
L16
L19
L22
N7
N12
N15
N18
N21
P8
P13
P16
P19
P22
T7
F12
F15
G11
G14
J8
J9
J11
K7
K12
K13
K15
K16
T12
T15
T18
T21
U13
U16
U19
U22
K19

+1.5V_RTC

+VCC_CORE

C76
22U/6.3VS_6

C97

0.22U/10V_4

C91
22U/6.3VS_6

C98

0.22U/10V_4

C77
22U/6.3VS_6

C99

0.22U/10V_4

C75
22U/6.3VS_6

C96

0.22U/10V_4

BOTTOM SIDE DECOUPLING UNDER APU

+APU_VDDGFX

C122
22U/6.3VS_6

C131

0.22U/10V_4

+0.95V

BOTTOM SIDE DECOUPLING UNDER APU

C112

C111

10U/6.3VS_6

10U/6.3VS_6

C116

C115

0.22U/10V_4

0.22U/10V_4

C123

C124
22U/6.3VS_6

C133

0.22U/10V_4

C125
22U/6.3VS_6

C134

0.22U/10V_4

22U/6.3VS_6

C132

0.22U/10V_4

BOTTOM SIDE DECOUPLING UNDER APU

CZ: All +APU_VDDGFX_RUN cap Stuff.
CZ-L: All +APU_VDDGFX_RUN cap No Stuff.

CN18

1
2

88266-020L

form BAT coin --> stuff CN13/R527/D15

form BAT pack --> unstuff CN13/R527/D15

R166 470/F_4

+3VPCU

--> unstuff R529

--> stuff R529

C78
22U/6.3VS_6

C100

0.22U/10V_4

C113
10U/6.3VS_6

C117

0.22U/10V_4

C126
22U/6.3VS_6

C135

0.22U/10V_4

2 1

D3 RB500V-40

2 1

D4 RB500V-40

C92
22U/6.3VS_6

C101

0.22U/10V_4

C114
10U/6.3VS_6

C118

0.22U/10V_4

C127
22U/6.3VS_6

C136

0.22U/10V_4

C663

0.1U/10V_4

C79
22U/6.3VS_6

C102

0.22U/10V_4

C119

0.22U/10V_4

C128
22U/6.3VS_6

C137

0.22U/10V_4

20MIL

+3VRTC+BAT

C163

1U/10V_4

12

C93
22U/6.3VS_6

C103

0.22U/10V_4

C120

0.22U/10V_4

C129
22U/6.3VS_6

C138

0.22U/10V_4

U8

3

VIN

IC AP2138N-1.5TRG1

VOUT

GND

C80
22U/6.3VS_6

C104
180P/50V_4

C121
180P/50V_4

C130
22U/6.3VS_6

C139

0.22U/10V_4

2

1

C140
180P/50V_4

+1.5V_RTC

C161
10U/6.3V_6

+1.35VSUS

3A

P25

VDDIO_MEM_S3_1

P28

VDDIO_MEM_S3_2

T24

VDDIO_MEM_S3_3

T27

VDDIO_MEM_S3_4

C69
22U/6.3VS_6

C87
22U/6.3VS_6

C88
22U/6.3VS_6

C86

D D

22U/6.3VS_6

C70
22U/6.3VS_6

C81

0.22U/10V_4

C71
22U/6.3VS_6

C82

0.22U/10V_4

C72
22U/6.3VS_6

C83

0.22U/10V_4

C89
22U/6.3VS_6

C94

0.22U/10V_4

C73
*22U/6.3VS_6

C84

0.22U/10V_4

C90
*22U/6.3VS_6

C85

0.22U/10V_4

BOTTOM SIDE DECOUPLING UNDER APU

C106

C105

0.22U/10V_4

DECOUPLING BETWEEN PROCESSOR AND DIMMs
ACROSS VDDNB AND VSS SPLIT

C665

0.22U/10V_4

+VDDP_GFX

R582
CZ: always pop

C C

CZ-L PX: Stuff

UMA: No Stuff

+0.95V +VDDP_GFX

R582 0_6

C664
10U/6.3VS_6

0.22U/10V_4

R7047

R7047

only pop on

*0_4

CZ-L UMA SKU.

C107

0.22U/10V_4

+VDDCR_FCH_S5 +VDDCR_FCH_S5_R

+VDDCR_FCH_S5
R174
CZ: Stuff
CZ-L: No Stuff

R174 0_4

C141

0.22U/10V_4

C142

0.22U/10V_4

C177
10U/6.3VS_6

C143

0.22U/10V_4

C178
10U/6.3VS_6

C144

0.22U/10V_4

C179

0.22U/10V_4

C145

0.22U/10V_4

C146
22U/6.3VS_6

C108

0.22U/10V_4

C147
22U/6.3VS_6

C109
180P/50V_4

+APU_VDDIO_AZ

+VDDP_GFX

+APU_VDD_33

+1.8V_ROM

+APU_VDD_18_S5

+APU_VDD_33_S5

+VDDP_S5

+VDDCR_FCH_S5_R

+0.95V

C148
22U/6.3VS_6

+VDDNB_CORE

ACROSS VDDNB AND VSS SPLIT

B B

C150

0.22U/10V_4

C151

0.22U/10V_4

C152

0.22U/10V_4

C153

0.22U/10V_4

C154

0.22U/10V_4

C155

0.22U/10V_4

C156

0.22U/10V_4

C157

0.22U/10V_4

BOTTOM SIDE DECOUPLING UNDER APU

12

G1

*SHORT_ PAD1

+1.5V

+APU_VDDIO_AZ

U25

C74
*22U/6.3VS_6

C95
180P/50V_4

C110
180P/50V_4

C149
22U/6.3VS_6

C158
180P/50V_4

VDDIO_MEM_S3_5

U28

VDDIO_MEM_S3_6

V30

VDDIO_MEM_S3_7

V33

VDDIO_MEM_S3_8

W24

VDDIO_MEM_S3_9

W27

VDDIO_MEM_S3_10

Y25

VDDIO_MEM_S3_11

Y28

VDDIO_MEM_S3_12

Y30

VDDIO_MEM_S3_13

AB24

VDDIO_MEM_S3_14

AB27

VDDIO_MEM_S3_15

AB30

VDDIO_MEM_S3_16

AB33

VDDIO_MEM_S3_17

AD25

VDDIO_MEM_S3_18

AD28

VDDIO_MEM_S3_19

AD30

VDDIO_MEM_S3_20

AE24

VDDIO_MEM_S3_21

AE27

VDDIO_MEM_S3_22

AF30

VDDIO_MEM_S3_23

AF33

VDDIO_MEM_S3_24

AG25

VDDIO_MEM_S3_25

AG28

VDDIO_MEM_S3_26

AH24

VDDIO_MEM_S3_27

AH27

VDDIO_MEM_S3_28

AH30

VDDIO_MEM_S3_29

AK25

VDDIO_MEM_S3_30

AK28

VDDIO_MEM_S3_31

AK30

VDDIO_MEM_S3_32

AK33

VDDIO_MEM_S3_33

AL27

VDDIO_MEM_S3_34

AM30

VDDIO_MEM_S3_35

0.2A

AR19

VDDIO_AUDIO

1.5A

AE6

VDDP_GFX_2

AE5

VDDP_GFX_1

0.2A

AP19

VDD_33_1

AP21

VDD_33_2

1.5A

AP16

VDD_18_1

AP18

VDD_18_2

0.5A

AP10

VDD_18_S5_1

AR9

VDD_18_S5_2

0.2A

AP15

VDD_33_S5_1

AR15

VDD_33_S5_2

0.8A

AN12

VDDP_S5_1

AP12

VDDP_S5_2

0.2A

AP13

VDDCR_FCH_S5_1

AR12

VDDCR_FCH_S5_2

7A

AW19

VDDP_6

AU17

VDDP_1

AU19

VDDP_2

AV17

VDDP_3

AV19

VDDP_4

AW17

VDDP_5

12A

AL12

VDDCR_NB_1

AL13

VDDCR_NB_2

AL15

VDDCR_NB_3

AL18

VDDCR_NB_4

AL21

VDDCR_NB_5

AN13

VDDCR_NB_6

AN16

VDDCR_NB_7

AN19

VDDCR_NB_8

AN22

VDDCR_NB_9

AR17

VDDBT_RTC_G

E

20MIL

VDDBT_RTC +VCCRTC_2

C159

0.22U/10V_4

12

C160
1U/10V_4

U2F

POWER

FP4 REV 1.0

FP4

R165 1K/F_4

22~39A

VDDCR_CPU_1
VDDCR_CPU_2
VDDCR_CPU_3
VDDCR_CPU_4
VDDCR_CPU_5
VDDCR_CPU_6
VDDCR_CPU_7
VDDCR_CPU_8

VDDCR_CPU_9
VDDCR_CPU_10
VDDCR_CPU_11
VDDCR_CPU_12
VDDCR_CPU_13
VDDCR_CPU_14
VDDCR_CPU_15
VDDCR_CPU_16
VDDCR_CPU_17
VDDCR_CPU_18
VDDCR_CPU_19
VDDCR_CPU_20
VDDCR_CPU_21
VDDCR_CPU_22
VDDCR_CPU_23
VDDCR_CPU_24
VDDCR_CPU_25
VDDCR_CPU_26
VDDCR_CPU_42
VDDCR_CPU_31
VDDCR_CPU_43
VDDCR_CPU_32
VDDCR_CPU_44
VDDCR_CPU_33
VDDCR_CPU_45
VDDCR_CPU_34
VDDCR_CPU_46
VDDCR_CPU_35
VDDCR_CPU_47
VDDCR_CPU_36
VDDCR_CPU_28
VDDCR_CPU_29
VDDCR_CPU_40
VDDCR_CPU_30
VDDCR_CPU_37
VDDCR_CPU_49
VDDCR_CPU_38
VDDCR_CPU_39
VDDCR_CPU_48
VDDCR_CPU_41
VDDCR_CPU_27

22~30A

VDDCR_GFX_14
VDDCR_GFX_15
VDDCR_GFX_16
VDDCR_GFX_17
VDDCR_GFX_18
VDDCR_GFX_19
VDDCR_GFX_20
VDDCR_GFX_21
VDDCR_GFX_22
VDDCR_GFX_23
VDDCR_GFX_24
VDDCR_GFX_25
VDDCR_GFX_26
VDDCR_GFX_27
VDDCR_GFX_28
VDDCR_GFX_29

VDDCR_GFX_1

VDDCR_GFX_2

VDDCR_GFX_3

VDDCR_GFX_4

VDDCR_GFX_5

VDDCR_GFX_6

VDDCR_GFX_7

VDDCR_GFX_8

VDDCR_GFX_9
VDDCR_GFX_10
VDDCR_GFX_11
VDDCR_GFX_12
VDDCR_GFX_30
VDDCR_GFX_31
VDDCR_GFX_32
VDDCR_GFX_33
VDDCR_GFX_34
VDDCR_GFX_35
VDDCR_GFX_36
VDDCR_GFX_37
VDDCR_GFX_13

+1.8VS5 +APU_VDD_18_S5

1.5V For HDA Only

A A

C164
1U/10V_4

C165
1U/10V_4

C166
1U/10V_4

R168 0_4

R173 0_4

C175
10U/6.3VS_6

C176

0.22U/10V_4

+3V +APU_VDD_33

R169 0_4

C167
10U/6.3VS_6

5

+3VS5 +APU_VDD_33_S5 +0.95VS5 +VDDP_S5

R170 0_4

4

C168
10U/6.3VS_6

C169

0.22U/10V_4

R171 0_6

C170
10U/6.3VS_6

C172

0.22U/10V_4

3

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size

Size

Size

Document Number Re v

Document Number Re v

Document Number Re v

Carrizo 6/7 (POWER)

Carrizo 6/7 (POWER)

Carrizo 6/7 (POWER)

RD

NB5

NB5

NB5

Date: Sheet o f

Friday, October 17, 2014 7 43

Date: Sheet o f

Friday, October 17, 2014 7 43

Date: Sheet o f

2

Friday, October 17, 2014 7 43

1

1A

1A

1A

5

4

3

2

1

08

VSS_1
VSS_2
VSS_3
VSS_4
VSS_5
VSS_6
VSS_7
VSS_8
VSS_9
VSS_10
VSS_11
VSS_12
VSS_13
VSS_14
VSS_15
VSS_16
VSS_17
VSS_18
VSS_19
VSS_20
VSS_21
VSS_22
VSS_23
VSS_24
VSS_25
VSS_26
VSS_27
VSS_28
VSS_29
VSS_30
VSS_31
VSS_32
VSS_33
VSS_34
VSS_35
VSS_36
VSS_37
VSS_38
VSS_39
VSS_40
VSS_41
VSS_42
VSS_43
VSS_44
VSS_45
VSS_46
VSS_47
VSS_48
VSS_49
VSS_50
VSS_51
VSS_52
VSS_53
VSS_54
VSS_55
VSS_56
VSS_57
VSS_58
VSS_59
VSS_60
VSS_61
VSS_62

U2G

GND

FP4 REV 1.0

FP4

VSS_63
VSS_64
VSS_65
VSS_66
VSS_67
VSS_68
VSS_69
VSS_70
VSS_71
VSS_72
VSS_73
VSS_74
VSS_75
VSS_76
VSS_77
VSS_78
VSS_79
VSS_80
VSS_81
VSS_82
VSS_83
VSS_84
VSS_85
VSS_86
VSS_87
VSS_88
VSS_89
VSS_90
VSS_91
VSS_92
VSS_93
VSS_94
VSS_95
VSS_96
VSS_97
VSS_98

VSS_99
VSS_100
VSS_101
VSS_102
VSS_103
VSS_104
VSS_105
VSS_106
VSS_107
VSS_108
VSS_109
VSS_110
VSS_111
VSS_112
VSS_113
VSS_114
VSS_115
VSS_116
VSS_117
VSS_118
VSS_119
VSS_120
VSS_121
VSS_122
VSS_123
VSS_124

L28
M4
M30
N10
N13
N16
N19
N22
N27
P1
P2
P4
P5
P12
P15
P18
P21
P30
P33
T4
T10
T13
T16
T19
T22
T30
U5
U12
U15
U18
U21
U24
V1
V2
V4
W10
W13
W16
W19
W22
Y4
Y5
Y12
Y15
Y18
Y21
Y24
AB1
AB2
AB4
AB10
AB13
AB16
AB19
AB22
AD4
AD9
AD12
AD15
AD18
AD21
AD24

AE10
AE13
AE16
AE19
AE22

AF1
AF4

AG9
AG12
AG15
AG18
AG21

AH4
AH10
AH13
AH16
AH19
AH22

AK1

AK4
AK12
AK15
AK18

AL16
AL19
AL22

AM4

AN9
AN10
AN15
AN18
AN21
AN25
AN28

AP1

AP2

AP4

AP7
AP22
AP27
AP30
AP33

AR6
AR25
AR28

AT4
AT19
AT22
AT30

AU5

AU8
AU11
AU14
AU20
AU23
AU27

AV4

AV7

AV9
AV12
AV15
AV25

D D

ORIENT_APU#

TP55

C C

B B

A12
A16
A20
A24
A28
A32

B12
B33

D10
D12
D14
D16
D18
D20
D22
D24
D26
D28
D30

F19
F22
F25
F30
F33

G17
G20
G23
G26

H30

J15
J19
J22
J25
J28

K10
K22
K27
K30
K33

L12
L15
L18
L21
L25

A8

B2
B8

C3
D4
D6
D8

F1
F2
F4
F9

G7

H4

J5

K1
K2
K4

L5

VSS_125
VSS_126
VSS_127
VSS_128
VSS_129
VSS_130
VSS_131
VSS_132
VSS_133
VSS_134
VSS_135
VSS_136
VSS_137
VSS_138
VSS_139
VSS_140
VSS_141
VSS_142
VSS_143
VSS_144
VSS_145
VSS_146
VSS_147
VSS_148
VSS_149
VSS_150
VSS_151
VSS_152
VSS_153
VSS_154
VSS_155
VSS_156
VSS_157
VSS_158
VSS_159
VSS_160
VSS_161
VSS_162
VSS_163
VSS_164
VSS_165
VSS_166
VSS_167
VSS_168
VSS_169
VSS_170
VSS_171
VSS_172
VSS_173
VSS_174
VSS_175
VSS_176
VSS_177
VSS_178
VSS_179
VSS_180
VSS_181
VSS_182
VSS_183
VSS_184
VSS_185
VSS_186

U2H

GND

FP4 REV 1.0

FP4

VSS_187
VSS_188
VSS_189
VSS_190
VSS_191
VSS_192
VSS_193
VSS_194
VSS_195
VSS_196
VSS_197
VSS_198
VSS_199
VSS_200
VSS_201
VSS_202
VSS_203
VSS_204
VSS_205
VSS_206
VSS_207
VSS_208
VSS_209
VSS_210
VSS_211
VSS_212

VSS_213
VSS_215
VSS_214

AV30
AV33
AW22
AY4
AY6
AY8
AY10
AY12
AY14
AY16
AY20
AY22
AY24
AY26
AY28
AY30
BB1
BB33
BC4
BC8
BC12
BC16
BC20
BC24
BC28
BC32

L24
AL10
AK21

TP56
TP57
TP58

APU_U30
APU_U31
APU_AN30

U30
U31

AN30

RSVD_2
RSVD_3
RSVD_4

U2J

FP4 REV 1.0

FP4

A A

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size

Size

Size

Document Number Re v

Document Number Re v

Document Number Re v

Carrzio 7/7 (GND)

Carrzio 7/7 (GND)

NB5

NB5

5

4

3

2

NB5

Date: Sheet of

Date: Sheet of

Date: Sheet of

Carrzio 7/7 (GND)

Friday, October 17, 2014 8 43

Friday, October 17, 2014 8 43

Friday, October 17, 2014 8 43

1

1A

1A

1A

5

4

3

2

1

08

D D

C C

B B

A A

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size

Size

Size

Document Number Re v

Document Number Re v

Document Number Re v

C

C

C

DDR3 A0/B0 STD (4.0H)

DDR3 A0/B0 STD (4.0H)

NB5

NB5

5

4

3

2

NB5

DDR3 A0/B0 STD (4.0H)

Date: Sheet o f

Date: Sheet o f

Date: Sheet o f

1

9 43Friday, October 17, 2014

9 43Friday, October 17, 2014

9 43Friday, October 17, 2014

1A

1A

1A

5

4

3

2

1

08

D D

C C

B B

A A

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size

Size

Size

Document Number Re v

Document Number Re v

Document Number Re v

C

C

C

DDR3 A0/B0 STD (4.0H)

DDR3 A0/B0 STD (4.0H)

NB5

NB5

5

4

3

2

NB5

DDR3 A0/B0 STD (4.0H)

Date: Sheet o f

Date: Sheet o f

Date: Sheet o f

1

10 43Friday, October 17, 2014

10 43Friday, October 17, 2014

10 43Friday, October 17, 2014

1A

1A

1A

5

4

3

2

1

M_A_A[15:0]3

D D

M_A_BS#03
M_A_BS#13
M_A_BS#23
M_A_CS#03
M_A_CS#13
M_A_CLKP03
M_A_CLKN03
M_A_CLKP13
M_A_CLKN13
M_A_CKE03
M_A_CKE13
M_A_CAS#3
M_A_RAS#3
M_A_WE#3

SMB_RUN_CLK5,12,20
SMB_RUN_DAT5,12,20

M_A_ODT03

M_A_DM[7..0]3

C C

B B

M_A_ODT13

M_A_DM0
M_A_DM1
M_A_DM2
M_A_DM3
M_A_DM4
M_A_DM5
M_A_DM6
M_A_DM7

M_A_DQSP[7:0]3

M_A_DQSN[7:0]3

M_A_A0
M_A_A1
M_A_A2
M_A_A3
M_A_A4
M_A_A5
M_A_A6
M_A_A7
M_A_A8
M_A_A9
M_A_A10
M_A_A11
M_A_A12
M_A_A13
M_A_A14
M_A_A15

DIMM0_SA0
DIMM0_SA1
SMB_RUN_CLK
SMB_RUN_DAT

M_A_DQSP0
M_A_DQSP1
M_A_DQSP2
M_A_DQSP3
M_A_DQSP4
M_A_DQSP5
M_A_DQSP6
M_A_DQSP7
M_A_DQSN0
M_A_DQSN1
M_A_DQSN2
M_A_DQSN3
M_A_DQSN4
M_A_DQSN5
M_A_DQSN6
M_A_DQSN7

Place these Caps near So-Dimm0.

+1.35VSUS +0.65V_DDR_VTT

C520 1U/6.3V_4
C519 1U/6.3V_4
C366 1U/6.3V_4
C452 1U/6.3V_4
C457 10U/6.3VS_6
C412 10U/6.3VS_6
C414 10U/6.3VS_6
C416 10U/6.3VS_6
C458 10U/6.3VS_6

A A

C456 10U/6.3VS_6
C422 *10U/6.3VS_6
C417 10U/6.3VS_6
C448 10U/6.3VS_6

+VREF_DQ0

+VREF_CA0

5

C3570 1U/6.3V_4
C372 1U/6.3V_4
C439 1U/6.3V_4
C408 1U/6.3V_4
C3830 10U/6.3VS_6
C423 *10U/6.3VS_6

C358 0.1U/10V_4

C373 1000P/50V_4

C420 0.1U/10V_4

C419 1000P/50V_4

C418 *0.047U/10V_4

JDIM1A

98

A0

97

A1

96

A2

95

A3

92

A4

91

A5

90

A6

86

A7

89

A8

85

A9

107

A10/AP

84

A11

83

A12/BC#

119

A13

80

A14

78

A15

109

BA0

108

BA1

79

BA2

114

S0#

121

S1#

101

CK0

103

CK0#

102

CK1

104

CK1#

73

CKE0

74

CKE1

115

CAS#

110

RAS#

113

WE#

197

SA0

201

SA1

202

SCL

200

SDA

116

ODT0

120

ODT1

11

DM0

28

DM1

46

DM2

63

DM3

136

DM4

153

DM5

170

DM6

187

DM7

12

DQS0

29

DQS1

47

DQS2

64

DQS3

137

DQS4

154

DQS5

171

DQS6

188

DQS7

10

DQS#0

27

DQS#1

45

DQS#2

62

DQS#3

135

DQS#4

152

DQS#5

169

DQS#6

186

DQS#7

DDR3-DIMM1_H=4.0_RVS

ddr-ddrrk-20401-tp4b-204p-smt

DGMK0000158

SOCKET DDR3 SODIMM(204P,H4.0,RVS)QBCON

+1.35VSUS

EC63 180P/50V_4
EC14 180P/50V_4
EC18 180P/50V_4
EC25 220P/50V_4
EC24 220P/50V_4
EC17 220P/50V_4
EC29 220P/50V_4
EC28 220P/50V_4
EC30 220P/50V_4
EC26 220P/50V_4
EC21 220P/50V_4
EC27 0.1U/10V_4
EC22 2200P/50V_4

+0.65V_DDR_VTT

EC31 *120P/50V_4
EC19 *120P/50V_4

DQ0
DQ1
DQ2
DQ3
DQ4
DQ5
DQ6
DQ7
DQ8

DQ9
DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46
DQ47

(204P)

PC2100 DDR3 SDRAM SO-DIMM

DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63

4

M_A_DQ0

5

M_A_DQ4

7

M_A_DQ7

15

M_A_DQ3

17

M_A_DQ1

4

M_A_DQ5

6

M_A_DQ2

16

M_A_DQ6

18

M_A_DQ13

21

M_A_DQ9

23

M_A_DQ14

33

M_A_DQ10

35

M_A_DQ12

22

M_A_DQ8

24

M_A_DQ11

34

M_A_DQ15

36

M_A_DQ21

39

M_A_DQ17

41

M_A_DQ19

51

M_A_DQ18

53

M_A_DQ20

40

M_A_DQ16

42

M_A_DQ23

50

M_A_DQ22

52

M_A_DQ25

57

M_A_DQ24

59

M_A_DQ30

67

M_A_DQ26

69

M_A_DQ28

56

M_A_DQ29

58

M_A_DQ31

68

M_A_DQ27

70

M_A_DQ36

129

M_A_DQ37

131

M_A_DQ34

141

M_A_DQ38

143

M_A_DQ32

130

M_A_DQ33

132

M_A_DQ35

140

M_A_DQ39

142

M_A_DQ41

147

M_A_DQ45

149

M_A_DQ47

157

M_A_DQ46

159

M_A_DQ40

146

M_A_DQ44

148

M_A_DQ42

158

M_A_DQ43

160

M_A_DQ49

163

M_A_DQ48

165

M_A_DQ54

175

M_A_DQ50

177

M_A_DQ53

164

M_A_DQ52

166

M_A_DQ55

174

M_A_DQ51

176

M_A_DQ61

181

M_A_DQ60

183

M_A_DQ59

191

M_A_DQ63

193

M_A_DQ56

180

M_A_DQ57

182

M_A_DQ62

192

M_A_DQ58

194

M_A_DQ[63:0] 3

3

+1.35VSUS

R7049
1K/F_4

M_A_EVENT#

M_A_EVENT#3

M_A_RST#3

+VREF_DQ0
+VREF_CA0

DDR_VTTREF12,33

M_A_VREFDQ3

R609 0_6

3mA

R610 *0_6

3mA

2.48A

+3V

+VREF_DQ0
+VREF_CA0

2

+1.35VSUS

M_A_EVENT#

+1.35VSUS

+1.35VSUS

JDIM1B

75

VDD1

76

VDD2

81

VDD3

82

VDD4

87

VDD5

88

VDD6

93

VDD7

94

VDD8

99

VDD9

100

VDD10

105

VDD11

106

VDD12

111

VDD13

112

VDD14

117

VDD15

118

VDD16

123

VDD17

124

VDD18

199

VDDSPD

77

NC1

122

NC2

125

NCTEST

198

EVENT#

30

RESET#

1

VREF_DQ

126

VREF_CA

2

VSS1

3

VSS2

8

VSS3

9

VSS4

13

VSS5

14

VSS6

19

VSS7

20

VSS8

25

VSS9
VSS10
VSS11
VSS12
VSS13
VSS14
VSS15

PC2100 DDR3 SDRAM SO-DIMM

NB5

NB5

NB5

26
31
32
37
38
43

DDR3-DIMM1_H=4.0_RVS

ddr-ddrrk-20401-tp4b-204p-smt

DGMK0000158

SOCKET DDR3 SODIMM(204P,H4.0,RVS)QBCON

R606
*1K/F_4

+VREF_CA0

R612
*1K/F_4

53537_105 change:
Type 1: and Type 2: from 1K/2 voltage

R294
1K/F_4

+VREF_DQ0

R296
1K/F_4

44

VSS16

48

VSS17

49

VSS18

54

VSS19

55

VSS20

60

VSS21

61

VSS22

65

VSS23

66

VSS24

71

VSS25

72

VSS26

127

VSS27

128

VSS28

133

VSS29

134

VSS30

138

VSS31

139

VSS32

144

VSS33

145

VSS34

150

VSS35

151

VSS36

155

VSS37

156

VSS38

161

VSS39

162

VSS40

167

VSS41

168

VSS42

172

VSS43

173

VSS44

178

VSS45

179

VSS46

184

VSS47

185

VSS48

189

VSS49

190

VSS50

195

VSS51

196

VSS52

(204P)

203

VTT1

204

VTT2

205

GND

206

GND

207

GND

208

GND

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v
Custom

Custom

Custom
Date: Sheet of

Date: Sheet of

Date: Sheet of

+0.65V_DDR_VTT

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

System Memory 1/2 (4H)

System Memory 1/2 (4H)

System Memory 1/2 (4H)

1

11

+3V4,5,6,7,12,20,21,22,23,24,27,28,29,30,36,38,40

+1.35VSUS3,7,12,33

+0.65V_DDR_VTT12,33

1A

1A

1A

11 43Friday, October 17, 2014

11 43Friday, October 17, 2014

11 43Friday, October 17, 2014

5

4

3

2

1

M_B_A[15:0]3

D D

M_B_BS#03
M_B_BS#13
M_B_BS#23
M_B_CS#03
M_B_CS#13
M_B_CLKP03
M_B_CLKN03
M_B_CLKP13
M_B_CLKN13
M_B_CKE03
M_B_CKE13
M_B_CAS#3
M_B_RAS#3

R339 4.7K_4

+3V

C C

B B

M_B_DM[7..0]3

M_B_WE#3

SMB_RUN_CLK5,11,20
SMB_RUN_DAT5,11,20

M_B_ODT03
M_B_ODT13

M_B_DM0
M_B_DM1
M_B_DM2
M_B_DM3
M_B_DM4
M_B_DM5
M_B_DM6
M_B_DM7

M_B_DQSP[7:0]3

M_B_DQSN[7:0]3

M_B_A0
M_B_A1
M_B_A2
M_B_A3
M_B_A4
M_B_A5
M_B_A6
M_B_A7
M_B_A8
M_B_A9
M_B_A10
M_B_A11
M_B_A12
M_B_A13
M_B_A14
M_B_A15

DIMM1_SA0
DIMM1_SA1

M_B_DQSP0
M_B_DQSP1
M_B_DQSP2
M_B_DQSP3
M_B_DQSP4
M_B_DQSP5
M_B_DQSP6
M_B_DQSP7
M_B_DQSN0
M_B_DQSN1
M_B_DQSN2
M_B_DQSN3
M_B_DQSN4
M_B_DQSN5
M_B_DQSN6
M_B_DQSN7

Place these Caps near So-Dimm1.

+VREF_CA1

5

+0.65V_DDR_VTT

C433 1U/6.3V_4
C454 1U/6.3V_4
C453 1U/6.3V_4
C463 1U/6.3V_4
C429 10U/6.3VS_6
C399 *10U/6.3VS_6

+VREF_DQ1

C459 0.1U/10V_4

C471 1000P/50V_4

C504 0.1U/10V_4

C505 1000P/50V_4

C503 *0.047U/10V_4

+1.35VSUS

C449 1U/6.3V_4
C523 1U/6.3V_4
C368 1U/6.3V_4
C451 1U/6.3V_4
C517 10U/6.3VS_6
C497 10U/6.3VS_6
C515 10U/6.3VS_6
C518 10U/6.3VS_6

A A

C450 10U/6.3VS_6
C516 10U/6.3VS_6
C521 *10U/6.3VS_6 Q27B
C367 10U/6.3VS_6
C507 10U/6.3VS_6

JDIM2A

98

A0

97

A1

96

A2

95

A3

92

A4

91

A5

90

A6

86

A7

89

A8

85

A9

107

A10/AP

84

A11

83

A12/BC#

119

A13

80

A14

78

A15

109

BA0

108

BA1

79

BA2

114

S0#

121

S1#

101

CK0

103

CK0#

102

CK1

104

CK1#

73

CKE0

74

CKE1

115

CAS#

110

RAS#

113

WE#

197

SA0

201

SA1

202

SCL

200

SDA

116

ODT0

120

ODT1

11

DM0

28

DM1

46

DM2

63

DM3

136

DM4

153

DM5

170

DM6

187

DM7

12

DQS0

29

DQS1

47

DQS2

64

DQS3

137

DQS4

154

DQS5

171

DQS6

188

DQS7

10

DQS#0

27

DQS#1

45

DQS#2

62

DQS#3

135

DQS#4

152

DQS#5

169

DQS#6

186

DQS#7

DDR3-DIMM0_H=4.0_STD

ddr-ddrsk-20401-tp4b-204p-smt

DGMK0000160

SOCKET DDR3 SODIMM(204P,H4.0,STD)QBCON

+1.35VSUS

EC20 180P/50V_4
EC62 180P/50V_4
EC41 220P/50V_4
EC37 220P/50V_4
EC40 220P/50V_4
EC38 220P/50V_4
EC34 220P/50V_4
EC36 220P/50V_4
EC39 220P/50V_4
EC35 220P/50V_4

53537_105 change:
Type 1: and Type 2: from 1K/2 voltage

+3V

C445 0.1U/10V_4
C374 2.2U/6.3V_6
C3590 1000P/50V_4

DQ0

DQ1

DQ2

DQ3

DQ4

DQ5

DQ6

DQ7

DQ8

DQ9
DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46
DQ47

(204P)

PC2100 DDR3 SDRAM SO-DIMM

DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63

4

M_B_DQ5

5

M_B_DQ4

7

M_B_DQ3

15

M_B_DQ2

17

M_B_DQ0

4

M_B_DQ1

6

M_B_DQ6

16

M_B_DQ7

18

M_B_DQ9

21

M_B_DQ13

23

M_B_DQ14

33

M_B_DQ10

35

M_B_DQ8

22

M_B_DQ12

24

M_B_DQ11

34

M_B_DQ15

36

M_B_DQ20

39

M_B_DQ21

41

M_B_DQ18

51

M_B_DQ22

53

M_B_DQ17

40

M_B_DQ16

42

M_B_DQ19

50

M_B_DQ23

52

M_B_DQ25

57

M_B_DQ29

59

M_B_DQ27

67

M_B_DQ26

69

M_B_DQ28

56

M_B_DQ24

58

M_B_DQ31

68

M_B_DQ30

70

M_B_DQ36

129

M_B_DQ37

131

M_B_DQ35

141

M_B_DQ34

143

M_B_DQ33

130

M_B_DQ32

132

M_B_DQ39

140

M_B_DQ38

142

M_B_DQ44

147

M_B_DQ40

149

M_B_DQ42

157

M_B_DQ43

159

M_B_DQ45

146

M_B_DQ41

148

M_B_DQ46

158

M_B_DQ47

160

M_B_DQ49

163

M_B_DQ48

165

M_B_DQ54

175

M_B_DQ55

177

M_B_DQ52

164

M_B_DQ53

166

M_B_DQ50

174

M_B_DQ51

176

M_B_DQ61

181

M_B_DQ56

183

M_B_DQ63

191

M_B_DQ62

193

M_B_DQ57

180

M_B_DQ60

182

M_B_DQ58

192

M_B_DQ59

194

DDR_VTTREF11,33

M_B_VREFDQ3

M_B_DQ[63:0] 3

R615 0_6

3mA

R616 *0_6

3mA

+1.35VSUS

R613
*1K/F_4

R618
*1K/F_4

+1.35VSUS

R617
1K/F_4

R614
1K/F_4

3

+1.35VSUS

R7050
1K/F_4

+VREF_CA1

+VREF_DQ1

M_B_EVENT#

M_B_EVENT#3

M_B_RST#3

+VREF_DQ1
+VREF_CA1

Local Thermal Sensor

+3V

MBDATA2

MBCLK2

R7113 *0_4

R7114 *0_4

Main:AL 000781 039 G781-1P8( 9Ah)

2nd:AL 00141200 5 EMC1412-2-ACZL-TR( 9Ah)

Main:AL 001412 003 EMC1412-1-ACZ L-TR(98h)

2nd:AL 00043101 4 TMP431A DGKR(98h)

DDR_THRMSEN_DATA

DDR_THRMSEN_CLK

+1.35VSUS

2.48A

+3V

M_B_EVENT#

+VREF_DQ1
+VREF_CA1

DDR_THRMSEN_CLK
DDR_THRMSEN_DATA
M_B_EVENT#

R407 *10K/F_4

MBDATA24,20,30

MBCLK24,20,30

2

JDIM2B

75

VDD1

76

VDD2

81

VDD3

82

VDD4

87

VDD5

88

VDD6

93

VDD7

94

VDD8

99

VDD9

100

VDD10

105

VDD11

106

VDD12

111

VDD13

112

VDD14

117

VDD15

118

VDD16

123

VDD17

124

VDD18

199

VDDSPD

77

NC1

122

NC2

125

NCTEST

198

EVENT#

30

RESET#

1

VREF_DQ

126

VREF_CA

2

VSS1

3

VSS2

8

VSS3

9

VSS4

13

VSS5

14

VSS6

19

VSS7

20

VSS8

25

VSS9

26

VSS10

31

VSS11

32

VSS12

37

VSS13

38

VSS14

43

VSS15

DDR3-DIMM0_H=4.0_STD

ddr-ddrsk-20401-tp4b-204p-smt

DGMK0000160

SOCKET DDR3 SODIMM(204P,H4.0,STD)QBCON

VSS16
VSS17
VSS18
VSS19
VSS20
VSS21
VSS22
VSS23
VSS24
VSS25
VSS26
VSS27
VSS28
VSS29
VSS30
VSS31
VSS32
VSS33
VSS34
VSS35
VSS36
VSS37
VSS38
VSS39
VSS40
VSS41
VSS42
VSS43
VSS44
VSS45
VSS46
VSS47
VSS48
VSS49
VSS50
VSS51
VSS52

(204P)

PC2100 DDR3 SDRAM SO-DIMM

VTT1
VTT2

GND
GND
GND
GND

DDR3 Thermal Sensor

8
7
6
4

MBDATA2

MBCLK2

U18

SCLK
SDA
ALERT#
OVERT#

*G781-1P8

Du al

Du al

1

VCC

2

DXP

3

DXN

5

GND

If use internal thermal IC, C9007 use 0ohm.

Q27A *2N7002KDW

DDR_THRMSEN_DATA

3 4

R392 *4.7K_4

5
2

R393 *4.7K_4

DDR_THRMSEN_CLK

6 1

*2N7002KDW

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v
Custom

Custom

Custom

NB5

NB5

NB5

Date: Sheet of

Date: Sheet of

Date: Sheet of

44
48
49
54
55
60
61
65
66
71
72
127
128
133
134
138
139
144
145
150
151
155
156
161
162
167
168
172
173
178
179
184
185
189
190
195
196

203
204

205
206
207
208

C565 *0.01U/50V_4

+0.65V_DDR_VTT

+1.35VSUS3,7,11,33

+0.65V_DDR_VTT11,33

+3V

DDR_THERMDA

C579
*2200P/50V_4

DDR_THERMDC

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

System Memory 2/2 (4H)

System Memory 2/2 (4H)

System Memory 2/2 (4H)

2

+3V

1

12

+3V4,5,6,7,11,20,21,22,23,24,27,28,29,30,36,38,40

Q28
*METR3904-G

1 3

12 43Friday, October 17, 2014

12 43Friday, October 17, 2014

12 43Friday, October 17, 2014

1A

1A

1A

PEG_TXP02
PEG_TXN02

PEG_TXP12
PEG_TXN12

PEG_TXP22
PEG_TXN22

PEG_TXP32
PEG_TXN32

PEG_TXP42
PEG_TXN42

PEG_TXP52
PEG_TXN52

PEG_TXP62
PEG_TXN62

PEG_TXP72
PEG_TXN72

CLK_GFX_P6

CLK_GFX_N6

R4001 1K/F_4

PEG_TXP0
PEG_TXN0

PEG_TXP1
PEG_TXN1

PEG_TXP2
PEG_TXN2

PEG_TXP3
PEG_TXN3

PEG_TXP4
PEG_TXN4

PEG_TXP5
PEG_TXN5

PEG_TXP6
PEG_TXN6

PEG_TXP7
PEG_TXN7

CLK_GFX_P
CLK_GFX_N

TEST_PG

PEGX_RST#

AF30

AE31

AE29
AD28

AD30
AC31

AC29
AB28

AB30
AA31

AA29

W31

W29

AK30
AK32

AL27

M28

M30

Y28

Y30

V28

V30
U31

U29
T28

T30
R31

R29
P28

P30
N31

N29

L31

L29

K30

N10

U4000A

PCIE_RX0P
PCIE_RX0N

PCIE_RX1P
PCIE_RX1N

PCIE_RX2P
PCIE_RX2N

PCIE_RX3P
PCIE_RX3N

PCIE_RX4P
PCIE_RX4N

PCIE_RX5P
PCIE_RX5N

PCIE_RX6P
PCIE_RX6N

PCIE_RX7P
PCIE_RX7N

NC#V30
NC#U31

NC#U29
NC#T28

NC#T30
NC#R31

NC#R29
NC#P28

NC#P30
NC#N31

NC#N29
NC#M28

NC#M30
NC#L31

NC#L29
NC#K30

CLOCK

PCIE_REFCLKP
PCIE_REFCLKN

TEST_PG

PERSTB

Meso_S3

PCI EXPRESS INTERFACE

CALIBRATION

PCIE_CALR_TX

PCIE_CALR_RX

PCIE_TX0P
PCIE_TX0N

PCIE_TX1P
PCIE_TX1N

PCIE_TX2P
PCIE_TX2N

PCIE_TX3P
PCIE_TX3N

PCIE_TX4P
PCIE_TX4N

PCIE_TX5P
PCIE_TX5N

PCIE_TX6P
PCIE_TX6N

PCIE_TX7P
PCIE_TX7N

NC#W24
NC#W23

NC#V27

NC#U26

NC#U24
NC#U23

NC#T26
NC#T27

NC#T24
NC#T23

NC#P27
NC#P26

NC#P24
NC#P23

NC#M27
NC#N26

9/2: CZ use 0.22u(Gen 3) ; CZ-L use 0.1u(Gen 2)

C_PEG_RXP0

AH30
AG31

AG29
AF28

AF27
AF26

AD27
AD26

AC25
AB25

Y23
Y24

AB27
AB26

Y27
Y26

W24
W23

V27
U26

U24
U23

T26
T27

T24
T23

P27
P26

P24
P23

M27
N26

Y22
AA22

PCIE_RST#_R15,23,29

C_PEG_RXN0

C_PEG_RXP1
C_PEG_RXN1

C_PEG_RXP2
C_PEG_RXN2

C_PEG_RXP3
C_PEG_RXN3

C_PEG_RXP4
C_PEG_RXN4

C_PEG_RXP5
C_PEG_RXN5

C_PEG_RXP6
C_PEG_RXN6

C_PEG_RXP7
C_PEG_RXN7

SUN_PCIE_CALRP
SUN_PCIE_CALRN

VGA_RSTB5

C4000 0.22U/10V_4
C4001 0.22U/10V_4

C4002 0.22U/10V_4
C4003 0.22U/10V_4

C4004 0.22U/10V_4
C4005 0.22U/10V_4

C4006 0.22U/10V_4
C4007 0.22U/10V_4

C4010 0.22U/10V_4
C4011 0.22U/10V_4

C4012 0.22U/10V_4
C4013 0.22U/10V_4

C4017 0.22U/10V_4
C4018 0.22U/10V_4

C4019 0.22U/10V_4
C4020 0.22U/10V_4

R4000 1.69K/F_4

R4002 1K/F_4

C4022 *0.1U/10V_4

R4004 0_4

*MC74VHC1G08DFT2G

DGPU_HIN_RST#

+1.0V_VGA

+3V_VGA

U4001

2
1

Platform
Carrizo
Carrizo-L

PEG_RXP0 2
PEG_RXN0 2

PEG_RXP1 2
PEG_RXN1 2

PEG_RXP2 2
PEG_RXN2 2

PEG_RXP3 2
PEG_RXN3 2

PEG_RXP4 2
PEG_RXN4 2

PEG_RXP5 2
PEG_RXN5 2

PEG_RXP6 2
PEG_RXN6 2

PEG_RXP7 2
PEG_RXN7 2

4

3 5

Gen 3

Gen 1/Gen 2

C4021

*0.1U/10V_4

PEGX_RST#

R4005
100K/F_4

Type

CH4222K9B04
CH4102K1B03

+1.8V_VGA

+1.0V_VGA

PCIE_RST#_R1

DGPU_HIN_RST#

PEGX_RST# 14

P/N

1.8V ( 40mA)

C4008
10U/6.3VS_6

1.0V ( 32mA)

C4014
*10U/6.3VS_6

2

1

D4000

BAT54AW-L

C4009

1U/10V_4

C4016

C4015

1U/10V_4

0.1U/10V_4

12/10:reserve for verify

+3V_VGA

R4003
1K/F_4

3

PEGX_RST#

U4000G

AG15

NC_DP_VDDR#1

AG16

NC_DP_VDDR#2

AF16

NC_DP_VDDR#3

AG17

NC_DP_VDDR#4

AG18

NC_DP_VDDR#5

AG19

NC_DP_VDDR#6

AF14

DP_VDDR

AG20

NC_DP_VDDC#1

AG21

NC_DP_VDDC#2

AF22

NC_DP_VDDC#3

AG22

NC_DP_VDDC#4

AD14

DP_VDDC

AG14

NC_DP_VSSR#1

AH14

NC_DP_VSSR#2

AM14

NC_DP_VSSR#3

AM16

NC_DP_VSSR#4

AM18

NC_DP_VSSR#5

AF23

NC_DP_VSSR#6

AG23

NC_DP_VSSR#7

AM20

NC_DP_VSSR#8

AM22

NC_DP_VSSR#9

AM24

NC_DP_VSSR#10

AF19

NC_DP_VSSR#11

AF20

NC_DP_VSSR#12

AE14

DP_VSSR

AF17

NC_UPHYAB_DP_CALR

Meso_S3

13

NC/DP POWERDP POWER

+3V_VGA14,16,40,43
+1.8V_VGA14,16,40,41,43
+1.0V_VGA16,40,43

NC#AE11
NC#AF11
NC#AE13
NC#AF13

NC#AG8

NC#AG10

NC#AF6
NC#AF7
NC#AF8
NC#AF9

NC#AE1
NC#AE3
NC#AG1
NC#AG6
NC#AH5

NC#AF10

NC#AG9
NC#AH8
NC#AM6
NC#AM8
NC#AG7

NC#AG11

NC#AE10

AE11
AF11
AE13
AF13
AG8
AG10

AF6
AF7
AF8
AF9

AE1
AE3
AG1
AG6
AH5
AF10
AG9
AH8
AM6
AM8
AG7
AG11

AE10

PROJECT : Y23

PROJECT : Y23

PROJECT : Y23

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v

TOPAZ S3 PCIE/DP power

TOPAZ S3 PCIE/DP power

NB5

NB5

NB5

TOPAZ S3 PCIE/DP power

Date: Sheet of

Date: Sheet of

Date: Sheet of

1A

1A

1A

13 43Friday, October 17, 2014

13 43Friday, October 17, 2014

13 43Friday, October 17, 2014

+3V_VGA

+3V_VGA

VGA_ALERT

+3V_VGA

R4011 10K/F_4
R4013 *10K/F_4
R4015 *10K/F_4
R4016 *10K/F_4
R4017 *10K/F_4
R4019
R4021 *10K/F_4

R4027 10K/F_4

+3V_VGA

R4007
10K/F_4

DGPUT_CLK
DGPUT_DATA GPU_THERMDA

R4008 *10K/F_4

DGPU_OVT#30

*10K/F_4

TEMP_FAIL

VGA_ALERT_R

GPU_AC_BATT
DGPU_TDI
DGPU_TMS
DGPU_TDO
DGPU_TRSTB
PCIE_REQ_GPU#
DGPU_PROCHOT#

R4006 0_4

AMD recommend

GPUT_DATA30

GPUT_CLK30

R4041
*5.1K/F_4

TESTEN

R4047
1K/F_4

Thermal Solution(Close to GPU)

8
7
6
4

U4002

SCLK
SDA
ALERT#
OVERT#

*G781-1P8

C4023 *0.01U/25V_4

1

VCC

2

DXP

3

DXN

5

GND

Main:AL 000781 039 G781-1P8 (9Ah)

R4012 *10K/F_4

9/4: change to 47K ohm for CRB

R4031 0_4

Q4000A *2N7002KDW

Dua l

3 4

R4196 *0_4

5

R4036 *4.7K_4

GPUT_CLK

2

6 1

Dua l

Q4000B*2N7002KDW

R4039 0_4

C4026 12P/50V_4

1

2

27MHZ +-10PPM

4

3

C4029 12P/50V_4

Y4000

9/2: follow Ref SCH by FAE

HCB1608KF-121T30(120+-25%,3A)

+1.8V_VGA

9/2: modify to +3V_VGA

+3V_VGA

C4024
*2200P/50V_4

GPU_THERMDC

+3V_VGA

+3V_VGA

DGPUT_DATAGPUT_DATA

9/9: follow AMD CRB design

+3V_VGA

DGPUT_CLK

EVGA-XTALI

R4045
1M_4

EVGA-XTALO

L4000

9/11: follow CRB change to 10K

R4018 4.7K_4
R4020 4.7K_4

R4023 47K/F_4
R4024 47K/F_4

DGPUT_DATA
DGPUT_CLK

GPU_AC_BATT30

TP4027

PEGX_RST# 13

1.8V(13mA TSVDD)

C4030

1U/10V_4

TEMP_FAIL30

GPIO22_ROMCS

10/2 : remove TP for no use

+1.8V_VGA

R4009
10K_4

TP4017
TP4019

R4025 0_4
R4026 0_4
R4028 0_4

GPU_GPIO6

GPIO8_ROMSO

TP4020

GPIO9_ROMSI

TP4022

GPIO10_ROMSCK

TP4023
TP4024
TP4025
TP4026

R4033 *0_4

TP4028

PCIE_REQ_GPU#

TP4029

TP4030
TP4031
TP4032
TP4033

TP4034

R4049 10K/F_4
R4050 10K/F_4

R4010
10K_4

DGPUT_DATA_R
DGPUT_CLK_R
GPU_GPIO5

VGA_ALERT

TEMP_FAIL

DGPU_PROCHOT#_RDGPU_PROCHOT#

DGPU_TRSTB

DGPU_TDI
DGPU_TCK
DGPU_TMS
DGPU_TDO

TESTEN

PX_EN

EVGA-XTALI
EVGA-XTALO

GPU_THERMDA
GPU_THERMDC

+1.8V_TSVDD

U4000B

DVO

N9

DBG_DATA16

L9

DBG_DATA15

AE9

DBG_DATA14

Y11

DBG_DATA13

AE8

DBG_DATA12

AD9

DBG_DATA11

AC10

DBG_DATA10

AD7

DBG_DATA9

AC8

DBG_DATA8

AC7

DBG_DATA7

AB9

DBG_DATA6

AB8

DBG_DATA5

AB7

DBG_DATA4

AB4

DBG_DATA3

AB2

DBG_DATA2

Y8

DBG_DATA1

Y7

DBG_DATA0

W6

NC#W6

V6

NC#V6

AC5

NC#AC5

AC6

N#CAC6

AA5

NC#AA5

AA6

NC#AA6

U1

NC#U1/BP_0

U3

NC#U3/BP_1

Y6

NC#Y6

R1

SCL

R3

I2C

SDA

GENERAL PURPOSE I/O

U6

GPIO_0

U8

SMBDATA

U7

SMBCLK

T9

GPIO_5_AC_BATT

T8

PCC/GPIO_6

T7

NC_GPIO_7

P10

GPIO_8_ROMSO

P4

GPIO_9_ROMSI

P2

GPIO_10_ROMSCK

N6

NC_GPIO_11

N5

NC_GPIO_12

N3

NC_GPIO_13

N1

GPIO_15_PWRCNTL_0

M4

GPIO_16

R6

GPIO_17_THERMAL_INT

M2

GPIO_19_CTF

P8

GPIO_20_PWRCNTL_1

P7

GPIO_21

N8

GPIO_22_ROMCSB

AK10

GPIO_29

AM10

GPIO_30

N7

CLKREQB

L6

JTAG_TRSTB

L5

JTAG_TDI

L3

JTAG_TCK

L1

JTAG_TMS

K4

JTAG_TDO

K7

TESTEN

AF24

NC#AF24

W8

NC_GENERICB

W7

NC_GENERICD

AD10

NC_GENERICE_HPD4

AJ9

NC#AJ9

AL9

DBG_CNTL0

AB16

PX_EN

AC16

NC_DBG_VREFG

PLL/CLOCK

AM28

XTALIN

AK28

XTALOUT

AC22

XO_IN

AB22

XO_IN2

T4

DPLUS

THERMAL

T2

DMINUS

R5

GPIO28_FDO

AD17

TSVDD

AC17

TSVSS

E

Meso_S3

+1.8V_VGA 13,16,40,41,43
+1.0V_VGA 13,16,40,43

NC#AF2
NC#AF4

NC#AG3

DPA

NC#AG5
NC#AH3

NC#AH1
NC#AK3

NC#AK1
NC#AK5

NC#AM3
NC#AK6

NC#AM5

DPB

NC#AJ7

NC#AH6
NC#AK8

NC#AL7

DPC

NC#V4
NC#U5

NC#V2

NC#Y4

NC#W5

NC#Y2
NC#J8

NC#AA1/PLL_ANALOG_IN

NC#AA3/PLL_ANALOG_OUT

DCM/NC_R

NC_AVSSN#AK26

NC_AVSSN#AJ25

NC_AVSSN#AG25

DAC1

NC_HSYNC

NC_VSYNC/WAKEb

NC_RSET
NC_AVDD

NC_AVSSQ
NC_VDD1DI

NC_VSS1DI

NC_SVI2#1/GPIO_SVD

NC_SVI2#2/GPIO_SVT

NC_SVI2#3/GPIO_SVC

NC_GENLK_CLK

NC_GENLK_VSYNC

DAC2

NC_SWAPLOCKA
NC_SWAPLOCKB

DDC/AUX

NC_DDC1CLK

NC_DDC1DATA

NC_AUX1P
NC_AUX1N

NC_AUX2P
NC_AUX2N

NC#AE16
NC#AD16

NC_DDCVGACLK

NC_DDCVGADATA

AF2
AF4

AG3
AG5

AH3
AH1

AK3
AK1

AK5
AM3

AK6
AM5

AJ7
AH6

AK8
AL7

V4
U5

V2
Y4

W5

Y2
J8

AA1
AA3

AM26
AK26

AL25

NC_G

AJ25
AH24

NC_B

AG25
AH26

AJ27

AD22
AG24

AE22
AE23

AD23

AM12

NC

AK12
AL11
AJ11

AL13
AJ13

AG13
AH12

AC19

PS_0

AD19

PS_1

AE17

PS_2

AE20

PS_3

AE19

TS_A

AE6
AE5

AD2
AD4

AD13
AD11

AE16
AD16

AC1
AC3

For AMD tuning
timing purpose

+1.8V_VGA

R4043

8.45K/F_4

PS_0 PS_1

R4046
2K/F_4

+1.8V_VGA +1.8V_VGA

R4051
*0_4

PS_2 PS_3

R4053

4.75K/F_4

TP4018

R4014 16.2K/F_4

Follow AMD check list

R4022 *10K/F_4

+3V_VGA

R4105 *4.7K_4

R4029
*4.7K_4

9/4: follow CRB design by FAE

R4030

4.7K_4

GPU_SVD
GPU_SVT
GPU_SVC

PS_0
PS_1
PS_2
PS_3

R4042 *0_4

TP4035
TP4036

GPU_SVD
GPU_SVC
GPU_SVT

Reserved. Do not connect on the PCB

S_3[3:1]

000

001
010 Micron
011
100
101

+1.8V_VGA

10/1 : Gen 3 support or not

Carrizo : PU 8.45K ; PD 2K
Carrizo-L : PU NC ; PD 4.75K

R4044

8.45K/F_4

Beema : PU NC ; PD 4.75K

C4027
*0.01U/25V_4

C4031
*0.68U/4V_4

R4048
2K/F_4

R4052

8.45K/F_4

R4054
2K/F_4

C4028

*0.082U/16V_4

C4032
*0.01U/25V_4

BIT5 => BIT0
PS0 => 11001

PS1 => 11000

PS2 => 11000

PS3 => 11000

2

Q4004

3

1

GPU_GPIO6

C4025

0.1U/10V_4

*2N7002K

1K/F_4
R4038

R4032 0_4
R4034 0_4
R4035 0_4

+3V_VGA

R4037
10K/F_4

DGPU_OCP_L 41

TP4021

SVI2_DATA 41
SVI2_CLK 41
SVI2_SVT 41

GPU_SVD

R4197 10K/F_4
R4199 10K/F_4
R4201 10K/F_4 R4202 10K/F_4

GPU_SVC
GPU_SVT

R4198 10K/F_4
R4200 10K/F_4

+1.8V_VGA

9/11: Add for SR Tool review result

Vendor Type Vendor P/NP

Hynix H5TC4G63CFR-N0C256Mx16 *4, 900Mhz NC 4.75K

amsung

S

256Mx16 *4, 900Mhz

56Mx16 *4, 900Mhz

2

K4W4G1646E-BC1A
MT41J256M16HA-093G:E

4.53K

CS24532FB08

4.75K

CS24752FB12

8.45K

CS28452FB12

2K

CS22002FB19

PU PD

8.45K 2K

4.53K 2K

PROJECT : Y23

PROJECT : Y23

PROJECT : Y23

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v

TOPAZ_S3_Main

TOPAZ_S3_Main

TOPAZ_S3_Main

RD

NB5

NB5

NB5

Date: Sheet of

Date: Sheet of

Date: Sheet of

14

14 43Friday, October 17, 2014

14 43Friday, October 17, 2014

14 43Friday, October 17, 2014

1A

1A

1A

AA27
AB24

AB32
AC24
AC26
AC27
AD25
AD32

AE27

AF32
AG27
AH32

M32
N25
N27

R27

U25
U27

W25
W26
W27

N11
N13

N16
N18
N21

R12
R15
R17
R20

U15
U17
U20

AA11

M12

K28
K32
L27

P25
P32

T25
T32

V32

Y25
Y32

T13
T16
T18
T21

V13
V16
V18
Y10
Y15
Y17
Y20

V11

M6

P6
P9

T6

U9

U4000E

PCIE_VSS#1
PCIE_VSS#2
PCIE_VSS#3
PCIE_VSS#4
PCIE_VSS#5
PCIE_VSS#6
PCIE_VSS#7
PCIE_VSS#8
PCIE_VSS#9
PCIE_VSS#10
PCIE_VSS#11
PCIE_VSS#12
PCIE_VSS#13
PCIE_VSS#14
PCIE_VSS#15
PCIE_VSS#16
PCIE_VSS#17
PCIE_VSS#18
PCIE_VSS#19
PCIE_VSS#20
PCIE_VSS#21
PCIE_VSS#22
PCIE_VSS#23
PCIE_VSS#24
PCIE_VSS#25
PCIE_VSS#26
PCIE_VSS#27
PCIE_VSS#28
PCIE_VSS#29
PCIE_VSS#30
PCIE_VSS#31

GND#56
GND#57

GND#58
GND#59
GND#60
GND#61
GND#62
GND#63
GND#64
GND#65
GND#66
GND#67
GND#68
GND#69
GND#70
GND#71
GND#72
GND#73
GND#74
GND#75
GND#76
GND#77
GND#78
GND#79
GND#80
GND#81
GND#82
GND#83
GND#86
GND#87
GND#88

GND

GND#1
GND#2
GND#3
GND#4
GND#5
GND#6
GND#7
GND#8

GND#9
GND#10
GND#11
GND#12
GND#13
GND#14
GND#15
GND#16
GND#17
GND#18
GND#19
GND#20
GND#21
GND#22
GND#23
GND#24
GND#25
GND#26
GND#27
GND#28
GND#29
GND#30
GND#31
GND#32
GND#33
GND#34
GND#35
GND#36
GND#37
GND#38
GND#39
GND#40
GND#41
GND#42
GND#43
GND#44
GND#45
GND#46
GND#47
GND#48
GND#49
GND#50
GND#51
GND#52
GND#53
GND#54
GND#55
GND#84
GND#85

VSS_MECH#1
VSS_MECH#2
VSS_MECH#3

A3
A30
AA13
AA16
AB10
AB15
AB6
AC9
AD6
AD8
AE7
AG12
AH10
AH28
B10
B12
B14
B16
B18
B20
B22
B24
B26
B6
B8
C1
C32
E28
F10
F12
F14
F16
F18
F2
F20
F22
F24
F26
F6
F8
G10
G27
G31
G8
H14
H17
H2
H20
H6
J27
J31
K11
K2
K22
K6
T11
R11

A32
AM1
AM32

U4000F

LVDS CONTROL

NC_UPHYAB_TMDPA_TX0N
NC_UPHYAB_TMDPA_TX0P

NC_UPHYAB_TMDPA_TX1N
NC_UPHYAB_TMDPA_TX1P

NC_UPHYAB_TMDPA_TX2N
NC_UPHYAB_TMDPA_TX2P

NC_UPHYAB_TMDPA_TX3N
NC_UPHYAB_TMDPA_TX3P

TMDP

NC_UPHYAB_TMDPB_TX0N
NC_UPHYAB_TMDPB_TX0P

NC_UPHYAB_TMDPB_TX1N
NC_UPHYAB_TMDPB_TX1P

NC_UPHYAB_TMDPB_TX2N
NC_UPHYAB_TMDPB_TX2P

NC_UPHYAB_TMDPB_TX3N
NC_UPHYAB_TMDPB_TX3P

Meso_S3

NC_TXOUT_L3P
NC_TXOUT_L3N

NC_TXOUT_U3P
NC_TXOUT_U3N

AL15
AK14

AH16
AJ15

AL17
AK16

AH18
AJ17

AL19
AK18

AH20
AJ19

AL21
AK20

AH22
AJ21

AL23
AK22

AK24
AJ23

15

RECOMMENDED SETTINGS

CONFIGURATION STRAPS-- SEE EACH DATABOOK FOR STRAP DETAILS

ALLOW FOR PULLUP PADS FOR THESE STRAPS AND IF THESE GPIOS ARE USED,

TX_PWRS_ENB

RSVD GPIO2 RESERVED 0
RSVD GPIO8 RESERVED 0

RSVD GPIO21 RESERVED 0

BIOS_ROM_EN

VIP_DEVICE_STRAP_ENA V2SYNC IGNORE VIP DEVICE STRAPS (Removed on Seymour/Whistler)

RSVD H2SYNC RESERVED 0

RSVD GENERICC RESERVED 0

THEY MUST NOT CONFLICT DURING RESET

STRAPS DESCRIPTION OF DEFAULT SETTINGSPIN

GPIO0 PCIE FULL TX OUTPUT SWING
GPIO1TX_DEEMPH_EN PCIE TRANSMITTER DE-EMPHASIS ENABLED

GPIO_22_ROMCSB

GPIO[13:11]ROMIDCFG(2:0) SERIAL ROM TYPE OR MEMORY APERTURE SIZE SELECT

VSYNC 0AUD[0]

ENABLE EXTERNAL BIOS ROM

SEE DATABOOK FOR DETAILHSYNC 0AUD[1]
SEE DATABOOK FOR DETAIL

NOTE1: AMD RESERVED CONFIGURATION STRAPS

ALLOW FOR PULLUP PADS FOR THESE STRAPS BUT DO NOT INSTALL RESISTOR. IF THESE GPIOS ARE USED,
THEY MUST KEEP "LOW" AND NOT CONFLICT DURING RESET.

H2S YNC GENERICCGPIO21

GPIO2GPIO8

0= DO NOT INSTALL RESISTOR
1 = INSTALL 3K RESISTOR

X = DESIGN DEPENDANT
NA = NOT APPLICABLE

0

X

0GPIO9 VGA ENABLEDBIF_VGA DIS

0

0 10

0

Meso_S3

NB5

NB5

NB5

PROJECT : Y23

PROJECT : Y23

PROJECT : Y23

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v

TOPAZ_S3_GND/LVDS/Strap

TOPAZ_S3_GND/LVDS/Strap

TOPAZ_S3_GND/LVDS/Strap

Date: Sheet of

Date: Sheet of

Date: Sheet of

1A

1A

1A

15 43Friday, October 17, 2014

15 43Friday, October 17, 2014

15 43Friday, October 17, 2014

+1.35V_VGA

+1.8V_VGA

+1.8V_VGA

1.35V ( DDR3, MVDDQ = 1.35V@2A)

C4037
10U/6.3VS_6

C4033

0.1U/10V_4

Memory Phase Lock Loop Power :

L4001 BLM18PG181SN1D(180,1.5A)_6\S

L4002 HCB1608KF-121T30(120+-25%,3A)

1.8V @ 90mA

Engine Phase Lock Loop Power :
analog power pin for engine PLL

1.8V @ 75mA

+1.0V_VGA

C4038

2.2U/6.3V_4

C4034

0.01U/25V_4

C4075

1U/10V_4

C4078

1U/10V_4

C4076
10U/6.3VS_6

C4079
10U/6.3VS_6

L4003 HCB1608KF-121T30(120+-25%,3A)

C4039

2.2U/6.3V_4

C4040

2.2U/6.3V_4

+1.8V_VGA

C4058

1U/10V_4

MPV18

C4077
10U/6.3VS_6

SPV18

Engine Phase Lock Loop Power :
digital power pin for engine PLL

0.95V @ 100mA

C4041

2.2U/6.3V_4

C4042

2.2U/6.3V_4

VDD_GPIO18 @13mA

+3V_VGA

VDD_GPIO33@25mA

C4059

1U/10V_4

+1.0V_VGA_SPV10

C4087

0.1U/10V_4

C4088

1U/10V_4

MPV18

SPV18

H13
H16
H19

K10
K23
K24

AA20
AA21
AB20
AB21

AA17
AA18
AB17
AB18

V12
Y12
U12

J10
J23
J24

L11
L12
L13
L20
L21
L22

H7

H8

U4000D

J9

K9

L8

J7

Meso_S3

MEM I/O

VDDR1#1
VDDR1#2
VDDR1#3
VDDR1#4
VDDR1#5
VDDR1#6
VDDR1#7
VDDR1#8
VDDR1#9
VDDR1#10
VDDR1#11
VDDR1#12
VDDR1#13
VDDR1#14
VDDR1#15
VDDR1#16
VDDR1#17

LEVEL
TRANSLATION

VDD_CT#1
VDD_CT#2
VDD_CT#3
VDD_CT#4

I/O

VDDR3#1
VDDR3#2
VDDR3#3
VDDR3#4

NC_VDDR4#1
NC_VDDR4#2
NC_VDDR4#3

PLL

MPLL_PVDD

SPLL_PVDD

SPLL_VDDC

SPLL_PVSS

PCIE_PVDD

PCIE

NC#AB23
NC#AC23
NC#AD24
NC#AE24
NC#AE25
NC#AE26

NC#AF25

NC#AG26

PCIE_VDDC#1
PCIE_VDDC#2
PCIE_VDDC#3
PCIE_VDDC#4
PCIE_VDDC#5
PCIE_VDDC#6
PCIE_VDDC#7
PCIE_VDDC#8

PCIE_VDDC#9
PCIE_VDDC#10
PCIE_VDDC#11
PCIE_VDDC#12

VDDC#1

CORE

VDDC#2
VDDC#3

POWER

VDDC#4
VDDC#5
VDDC#6
VDDC#7
VDDC#8

VDDC#9
VDDC#10
VDDC#11
VDDC#12
VDDC#13
VDDC#14
VDDC#15
VDDC#16
VDDC#17
VDDC#18
VDDC#20
VDDC#21
VDDC#22
VDDC#23
VDDC#24
VDDC#25
VDDC#26

VDDC/VARY_BL

VDDC/DIGON
VDDC/GENERICA
VDDC/GENERICC

VDDC/DDC2CLK

VDDC/DDC2DATA

VDDC/HPD1
VDDC/GPIO_1
VDDC/GPIO_2

VDDC/GPIO_18

VDDC/GPIO_14_HPD2

BIF_VDDC_1
BIF_VDDC_2

VDDCI#1

ISOLATED

VDDCI#2

CORE I/O

VDDCI#3
VDDCI#4
VDDCI#5
VDDCI#6
VDDCI#7
VDDCI#8

NC#W1/FB_VDDCI

NC#W3/FB_VSS

NC#FB_VDDC

NC#FB_VSS

AM30
AB23

AC23
AD24
AE24
AE25
AE26
AF25
AG26

L23
L24
L25
L26
M22
N22
N23
N24
R22
T22
U22
V22

AA15
N15
N17
R13
R16
R18
Y21
T12
T15
T17
T20
U13
U16
U18
V21
V15
V17
V20
Y13
Y16
Y18
AA12
M11
N12
U11
AB11
AB12
AB13
W9
AC11
AC13
AC14
U10
T10
W10
Y9

R21
U21

M13
M15
M16
M17
M18
M20
M21
N20

W1
W3

AC20
AD20

PCIE_VDDR : 1.8V @ 100mA

C4035
1U/10V_4

PCIE_VDDC : 0.95V @ 2.5A (GEN3.0)

C4043

C4044

1U/10V_4

1U/10V_4

TDP=25W/TDC=36A/EDC=TDCx1.5=54A(1ms)/EDP=35W(sustained)/Peak=53W(1ms)

VDDC+VDDCI

.85~1.1V(36A peak )( Ripple < 87.2mV)

0

C4051

C4050

2.2U/6.3V_4

2.2U/6.3V_4

C4060

2.2U/6.3V_4

2.2U/6.3V_4

C4068

10U/6.3VS_6

0.95V~1.1V(0.8A)

+1.0V_VGA

C4061

C4069

10U/6.3VS_6

C4052

2.2U/6.3V_4

C4062

2.2U/6.3V_4

10U/6.3VS_6

1U/10V_4

2.2U/6.3V_4

2.2U/6.3V_4

C4070

10U/6.3VS_6

C4036

C4045

C4053

C4063

+1.8V_VGA

C4046

1U/10V_4

C4054

2.2U/6.3V_4

C4064

2.2U/6.3V_4

C4071

10U/6.3VS_6

C4047

1U/10V_4

C4055

2.2U/6.3V_4

C4065

2.2U/6.3V_4

C4072

10U/6.3VS_6

+1.0V_VGA

C4048

1U/10V_4

C4056

2.2U/6.3V_4

C4066

2.2U/6.3V_4

C4073

10U/6.3VS_6

0.95V~1.1V(5A VDDCI)

C4082

R4055 *0_4
R4056 *0_4

R4057 0_4
R4058 0_4

C4080

0.1U/10V_4

C4081

0.1U/10V_4

+VGA_CORE

C4083

1U/10V_4

1U/10V_4

VGPU_CORE_SENSE 41
VSS_GPU_SENSE 41

C4084

1U/10V_4

C4085

10U/6.3VS_6

10U/6.3VS_6

+VGA_CORE

C4086

10U/6.3VS_6

C4049

C4057

2.2U/6.3V_4

C4067

2.2U/6.3V_4

12

+

C4074
330U_2.5V_3528

16

+VGA_CORE

+1.35V_VGA 17,18,40,41
+1.8V_VGA 13,14,40,41,43
+1.0V_VGA 13,40,43
+VGA_CORE 40,41,42

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v

NB5

NB5

NB5

Date: Sheet of

Date: Sheet of

Date: Sheet of

PROJECT : Y23

PROJECT : Y23

PROJECT : Y23

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

TOPAZ S3 Power

TOPAZ S3 Power

TOPAZ S3 Power

16 43Friday, October 17, 2014

16 43Friday, October 17, 2014

16 43Friday, October 17, 2014

1A

1A

1A

C4090

1U/10V_4

VMA_CSA0#_018
VMA_CSA1#_018

VMA_WDQS[7..0]18
VMA_RDQS[7..0]18

VMA_DQ[63..0]18
VMA_MA[15..0]18

+1.35V_VGA

R4064

40.2/F_4

R4066

100/F_4

1U/10V_4

VMA_DM[7..0]18

C4091

VMA_ODT018
VMA_ODT118

VMA_RAS0#18
VMA_RAS1#18

VMA_CAS0#18
VMA_CAS1#18

VMA_WE0#18
VMA_WE1#18

VMA_CKE018
VMA_CKE118

VMA_CLK018
VMA_CLK0#18

VMA_CLK118
VMA_CLK1#18

VMA_BA018
VMA_BA118

VMA_BA218

+1.35V_VGA

VMA_ODT0
VMA_ODT1

VMA_RAS0#
VMA_RAS1#

VMA_CAS0#
VMA_CAS1#

VMA_WE0#
VMA_WE1#

VMA_CSA0#_0
VMA_CSA1#_0
VMA_CKE0

VMA_CKE1
VMA_CLK0

VMA_CLK0#
VMA_CLK1

VMA_CLK1#
VMA_WDQS[7..0]
VMA_RDQS[7..0]

VMA_DM[7..0]
VMA_DQ[63..0]
VMA_MA[15..0]

VMA_BA0
VMA_BA1
VMA_BA2

support 1Gbit
VRAM ( 64M X 16 )

MVREFD

R4068

40.2/F_4

MVREFS

R4070

100/F_4

Rd

R4067 120/F_4

C4092

*0.1U/10V_4

U4000C

VMA_DQ0
VMA_DQ1
VMA_DQ2
VMA_DQ3
VMA_DQ4
VMA_DQ5
VMA_DQ6
VMA_DQ7
VMA_DQ8
VMA_DQ9
VMA_DQ10
VMA_DQ11
VMA_DQ12
VMA_DQ13
VMA_DQ14
VMA_DQ15
VMA_DQ16
VMA_DQ17
VMA_DQ18
VMA_DQ19
VMA_DQ20
VMA_DQ21
VMA_DQ22
VMA_DQ23
VMA_DQ24
VMA_DQ25
VMA_DQ26
VMA_DQ27
VMA_DQ28
VMA_DQ29
VMA_DQ30
VMA_DQ31
VMA_DQ32
VMA_DQ33
VMA_DQ34
VMA_DQ35
VMA_DQ36
VMA_DQ37
VMA_DQ38
VMA_DQ39
VMA_DQ40
VMA_DQ41
VMA_DQ42
VMA_DQ43
VMA_DQ44
VMA_DQ45
VMA_DQ46
VMA_DQ47
VMA_DQ48
VMA_DQ49
VMA_DQ50
VMA_DQ51
VMA_DQ52
VMA_DQ53
VMA_DQ54
VMA_DQ55
VMA_DQ56
VMA_DQ57
VMA_DQ58
VMA_DQ59
VMA_DQ60
VMA_DQ61
VMA_DQ62
VMA_DQ63

DRAM_RST_C VMA_WE1#

CLKTESTA
CLKTESTB

C4093
*0.1U/10V_4

H30
H32
G29

C30

G26
D26

A25
C25
E25
D24
E23

D22
E21

D20
A19

D18
A17

C17
E17
D16

A15
D14

A13
C13
E11
A11
C11

K26

K25

K27
J29

F28
F32
F30

F27
A28
C28
E27

F25

F23
F21

F19

F17

F15

F13

F11

J26
J25

L10

A9
C9
F9
D8
E7
A7
C7
F7
A5
E5
C3

E1
G7
G6
G1
G3

J6

J1

J3

J5

K8

L7

DQA0_0
DQA0_1
DQA0_2
DQA0_3
DQA0_4
DQA0_5
DQA0_6
DQA0_7
DQA0_8
DQA0_9
DQA0_10
DQA0_11
DQA0_12
DQA0_13
DQA0_14
DQA0_15
DQA0_16
DQA0_17
DQA0_18
DQA0_19
DQA0_20
DQA0_21
DQA0_22
DQA0_23
DQA0_24
DQA0_25
DQA0_26
DQA0_27
DQA0_28
DQA0_29
DQA0_30
DQA0_31
DQA1_0
DQA1_1
DQA1_2
DQA1_3
DQA1_4
DQA1_5
DQA1_6
DQA1_7
DQA1_8
DQA1_9
DQA1_10
DQA1_11
DQA1_12
DQA1_13
DQA1_14
DQA1_15
DQA1_16
DQA1_17
DQA1_18
DQA1_19
DQA1_20
DQA1_21
DQA1_22
DQA1_23
DQA1_24
DQA1_25
DQA1_26
DQA1_27
DQA1_28
DQA1_29
DQA1_30
DQA1_31

MVREFDA
MVREFSA

NC
MEM_CALRP0

DRAM_RST
CLKTESTA

CLKTESTB

Meso_S3

MAA0_0
MAA0_1
MAA0_2
MAA0_3
MAA0_4
MAA0_5
MAA0_6
MAA0_7
MAA0_8
MAA0_9

MAA1_0
MAA1_1
MAA1_2
MAA1_3
MAA1_4
MAA1_5
MAA1_6
MAA1_7

MMA1_8

MAA1_9

WCKA0_0

WCKA0B_0

WCKA0_1

WCKA0B_1

WCKA1_0

WCKA1B_0

WCKA1_1

WCKA1B_1

MEMORY INTERFACE

EDCA0_0
EDCA0_1
EDCA0_2
EDCA0_3
EDCA1_0
EDCA1_1
EDCA1_2
EDCA1_3

DDBIA0_0
DDBIA0_1
DDBIA0_2
DDBIA0_3
DDBIA1_0
DDBIA1_1
DDBIA1_2
DDBIA1_3

ADBIAO

ADBIA1

CLKA0

CLKA0B

CLKA1

CLKA1B

RASA0B
RASA1B

CASA0B
CASA1B

CSA0B_0
CSA0B_1

CSA1B_0
CSA1B_1

CKEA0
CKEA1

WEA0B
WEA1B

K17
J20
H23
G23
G24
H24
J19
K19
G20
L17

J14
K14
J11
J13
H11
G11
J16
L15
G14
L16

E32
E30
A21
C21
E13
D12
E3
F4

H28
C27
A23
E19
E15
D10
D6
G5

H27
A27
C23
C19
C15
E9
C5
H4

L18
K16

H26
H25

G9
H9

G22
G17

G19
G16

H22
J22

G13
K13

K20
J17

G25
H10

VMA_MA0
VMA_MA1
VMA_MA2
VMA_MA3
VMA_MA4
VMA_MA5
VMA_MA6
VMA_MA7
VMA_MA13
VMA_MA15

VMA_MA8
VMA_MA9
VMA_MA10
VMA_MA11
VMA_MA12
VMA_BA2
VMA_BA0
VMA_BA1
VMA_MA14

VMA_DM0
VMA_DM1
VMA_DM2
VMA_DM3
VMA_DM4
VMA_DM5
VMA_DM6
VMA_DM7

VMA_RDQS0
VMA_RDQS1
VMA_RDQS2
VMA_RDQS3
VMA_RDQS4
VMA_RDQS5
VMA_RDQS6
VMA_RDQS7

VMA_WDQS0
VMA_WDQS1
VMA_WDQS2
VMA_WDQS3
VMA_WDQS4
VMA_WDQS5
VMA_WDQS6
VMA_WDQS7

VMA_ODT0
VMA_ODT1

VMA_CLK0
VMA_CLK0#

VMA_CLK1
VMA_CLK1#

VMA_RAS0#
VMA_RAS1#

VMA_CAS0#
VMA_CAS1#

VMA_CSA0#_0

VMA_CSA1#_0

VMA_CKE0
VMA_CKE1

VMA_WE0#

25mm (max) 25mm (max)5mm (max)

DRAM_RST_C

From GPU

Place all these components very close to GPU (Within
25mm) and keep all component close to each Other (within
5mm) except Rser2

This basic topology should be used for DRAM_RST for DDR3/GDDR5.These
Capacitors and Resistor values are an example only. The Series R and
|| Cap values will depend on the DRAM load and will have to be
calculated for different Memory ,DRAM Load and board to pass Reset
Signal Spec.

R4059 10/F_4

R4061

4.99K/F_4

R4060 51_4

C4089
120P/50V_4

DRAM_RST_M 18

17

+1.35V_VGA 16,18,40,41

R4072

R4071

*51.1/F_4

route 50ohms
single-ended/100ohms diff
and keep short

*51.1/F_4

NB5

NB5

NB5

PROJECT : Y23

PROJECT : Y23

PROJECT : Y23

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v

TPOAZ_S3_MEM_Interface

TPOAZ_S3_MEM_Interface

TPOAZ_S3_MEM_Interface

Date: Sheet of

Date: Sheet of

Date: Sheet of

1A

1A

1A

17 43Friday, October 17, 2014

17 43Friday, October 17, 2014

17 43Friday, October 17, 2014

5

U4003

M8

VREFCA

H1

VREFDQ

N3

A0

P7

A1

P3

A2

N2

A3

P8

A4

P2

A5

R8

A6

R2

A7

T8

A8

R3

A9

L7

A10/AP

R7

A11

N7

A12/BC

T3

A13

T7

A14

M7

A15

M2

BA0

N8

BA1

M3

BA2

J7

CK

K7

CK

K9

CKE

K1

ODT

L2

CS

J3

RAS

K3

CAS

L3

WE

F3

DQSL

G3

DQSL

E7

DML

D3

DMU

C7

DQSU

B7

DQSU

T2

RESET

L8

ZQ

J1

NC#J1

L1

NC#L1

J9

NC#J9

L9

NC#L9

96-BALL

SDRAM DDR3

K4W4G 1646E-BC1A

VREFC_VMA 1

C4094

0.1U/10V_4

R4101

40.2/F_4

VMA_CLK0 _COMM

R4102

40.2/F_4

R4103

40.2/F_4

VMA_CLK1 _COMM

R4104

40.2/F_4

5

VMA_MA[15..0]

VMA_DQ[63..0]17

VMA_RDQS[7..0]17

VMA_DQ19

E3

DQL0

VMA_DQ18

F7

DQL1

VMA_DQ23

F2

DQL2

VMA_DQ17

F8

DQL3

VMA_DQ22

H3

DQL4

VMA_DQ20

H8

DQL5

VMA_DQ21

G2

DQL6

VMA_DQ16

H7

DQL7

VMA_DQ11

D7

DQU0

VMA_DQ14

C3

DQU1

VMA_DQ9

C8

DQU2

VMA_DQ13

C2

DQU3

VMA_DQ10

A7

DQU4

VMA_DQ15

A2

DQU5

VMA_DQ8

B8

DQU6

VMA_DQ12

A3

DQU7

VDD#B2
VDD#D9
VDD#G7
VDD#K2
VDD#K8
VDD#N1
VDD#N9
VDD#R1
VDD#R9

VDDQ#A1
VDDQ#A8
VDDQ#C1
VDDQ#C9
VDDQ#D2
VDDQ#E9
VDDQ#F1
VDDQ#H2
VDDQ#H9

VSS#A9
VSS#B3
VSS#E1
VSS#G8
VSS#J2
VSS#J8
VSS#M1
VSS#M9
VSS#P1
VSS#P9
VSS#T1
VSS#T9

VSSQ#B1
VSSQ#B9
VSSQ#D1
VSSQ#D8
VSSQ#E2
VSSQ#E8
VSSQ#F9
VSSQ#G1
VSSQ#G9

R4086

4.99K/F_4

R4094

4.99K/F_4

9/4: Dual Rank : 80.6 ohm

ingle Rank : 40.2 ohm

S

+1.35V_V GA +1.35V_V GA

B2
D9
G7
K2
K8
N1
N9
R1
R9

+1.35V_V GA +1.35V_V GA+1.35V_V GA

A1
A8
C1
C9
D2
E9
F1
H2
H9

A9
B3
E1
G8
J2
J8
M1
M9
P1
P9
T1
T9

B1
B9
D1
D8
E2
E8
F9
G1
G9

+1.35V_V GA +1.35V_V GA +1.35V_V GA +1.35V_V GA +1.35V_ VGA +1.35V_VGA +1.35V_VGA

C4118

0.01U/25V_4

C4135

0.01U/25V_4

Should be 240
Ohms +-1%

VREFD_VMA 1 VREFC_VMA 2 VREFD_VMA 2 VREFC_VMA 3 VREFD_VMA3 VREFC_VMA 4 VREFD_VMA4

C4095

0.1U/10V_4

VREFC_VMA 2
VREFD_VMA 2

VMA_MA0
VMA_MA1
VMA_MA2
VMA_MA3
VMA_MA4
VMA_MA5
VMA_MA6
VMA_MA7
VMA_MA8
VMA_MA9
VMA_MA10
VMA_MA11
VMA_MA12

VMA_BA0
VMA_BA1
VMA_BA2

VMA_CLK0
VMA_CLK0 #
VMA_CKE0

VMA_ODT0
VMA_CSA0 #_0
VMA_RAS0 #
VMA_CAS0 #
VMA_WE 0#

VMA_RDQS0

VMA_WDQS0

VMA_DM0
VMA_DM3

VMA_RDQS3

VMA_WDQS3

DRAM_RST_M

VMA_ZQ2 VMA_ZQ3 VMA_ZQ4

R4078
243/F_4

R4087

4.99K/F_4

R4095

4.99K/F_4

1U/6.3V_4

1U/6.3V_4

10U/6.3VS_6

VMA_MA[15..0]17

VMA_DM[7..0]17 VMA_WDQS[7..0]17

VREFC_VMA 1
VREFD_VMA 1

VMA_MA0
VMA_MA1
VMA_MA2
VMA_MA3
VMA_MA4
VMA_MA5

D D

VMA_CSA0 #_017

C C

DRAM_RST_M17

Should be 240
Ohms +-1%

B B

A A

VMA_MA6
VMA_MA7
VMA_MA8
VMA_MA9
VMA_MA10
VMA_MA11
VMA_MA12

VMA_MA15 VMA _MA15 VMA_MA15 VMA_MA15

VMA_BA017
VMA_BA117
VMA_BA217

VMA_CLK017

VMA_CKE017

VMA_ODT017

VMA_CAS0 #17 VMA_CAS1 #17
VMA_WE 0#17

4.99K/F_4

4.99K/F_4

VMA_RDQS2
VMA_WDQS2

VMA_DM2
VMA_DM1

VMA_RDQS1
VMA_WDQS1

VMA_ZQ1

R4077
243/F_4

+1.35V_V GA

R4085

R4093

VMA_CLK0

VMA_CLK0 #
VMA_CLK1

VMA_CLK1 #

0.1U/10V_4

C4102

C4119

C4136

M8
H1

N3

P7
P3

N2

P8

P2
R8
R2

T8
R3

L7
R7
N7

T3

T7
M7

M2
N8
M3

J7

K7

K9

K1

L2

J3

K3

L3

F3
G3

E7
D3

C7

B7

T2

L8

J1

L1

J9

L9

C4096

4

U4004

VREFCA
VREFDQ

A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10/AP
A11
A12/BC
A13
A14
A15

BA0
BA1
BA2

CK
CK
CKE

ODT
CS
RAS
CAS
WE

DQSL
DQSL

DML
DMU

DQSU
DQSU

RESET
ZQ

NC#J1
NC#L1
NC#J9
NC#L9

96-BALL

SDRAM DDR3

K4W4G 1646E-BC1A

R4088

4.99K/F_4

R4096

4.99K/F_4

+1.35V_V GA

C4103

1U/6.3V_4

+1.35V_V GA

C4120

1U/6.3V_4

+1.35V_V GA

C4137

10U/6.3VS_6

4

DQL0
DQL1
DQL2
DQL3
DQL4
DQL5
DQL6
DQL7

DQU0
DQU1
DQU2
DQU3
DQU4
DQU5
DQU6
DQU7

VDD#B2
VDD#D9
VDD#G7
VDD#K2
VDD#K8
VDD#N1
VDD#N9
VDD#R1
VDD#R9

VDDQ#A1
VDDQ#A8
VDDQ#C1
VDDQ#C9
VDDQ#D2
VDDQ#E9

VDDQ#F1
VDDQ#H2
VDDQ#H9

VSS#A9
VSS#B3
VSS#E1
VSS#G8
VSS#J2
VSS#J8
VSS#M1
VSS#M9
VSS#P1
VSS#P9
VSS#T1
VSS#T9

VSSQ#B1

VSSQ#B9
VSSQ#D1
VSSQ#D8

VSSQ#E2

VSSQ#E8

VSSQ#F9
VSSQ#G1
VSSQ#G9

C4104

1U/6.3V_4

C4121

1U/6.3V_4

10U/6.3VS_6

3

1G/2G DDR3L

VMA_DQ7

E3

VMA_DQ5

F7

VMA_DQ3

F2

VMA_DQ2

F8

VMA_DQ6

H3

VMA_DQ0

H8

VMA_DQ4

G2

VMA_DQ1

H7

VMA_DQ28

D7

VMA_DQ29

C3

VMA_DQ30

C8

VMA_DQ24

C2

VMA_DQ27

A7

VMA_DQ26

A2

VMA_DQ31

B8

VMA_DQ25

A3

+1.35V_V GA +1.35V_V GA

B2
D9
G7
K2
K8
N1
N9
R1
R9

+1.35V_V GA

A1
A8
C1
C9
D2
E9
F1
H2
H9

A9
B3
E1
G8
J2
J8
M1
M9
P1
P9
T1
T9

B1
B9
D1
D8
E2
E8
F9
G1
G9

INT

C4097

0.1U/10V_4

C4106

C4105

1U/6.3V_4

1U/6.3V_4

C4123

C4122

1U/6.3V_4

1U/6.3V_4

C4139

C4138

10U/6.3VS_6

1U/6.3V_4

1U/6.3V_4

C4140

10U/6.3VS_6

VMA_CLK117
VMA_CLK1 #17VMA_CLK0 #17
VMA_CKE117

VMA_ODT117

VMA_CSA1 #_017

VMA_RAS1 #17VMA_RAS0#17
VMA_WE 1#17

Should be 240

Ohms +-1%

C4107

C4124

VREFC_VMA 3
VREFD_VMA 3

VMA_MA0
VMA_MA1
VMA_MA2
VMA_MA3
VMA_MA4
VMA_MA5
VMA_MA6
VMA_MA7
VMA_MA8
VMA_MA9
VMA_MA10
VMA_MA11
VMA_MA12

VMA_BA0
VMA_BA1
VMA_BA2

VMA_RDQS7

VMA_WDQS7

VMA_DM7
VMA_DM5

VMA_RDQS5

VMA_WDQS5

DRAM_RST_M DRAM_RST_M

4.99K/F_4

C4108

1U/6.3V_4

C4125

1U/6.3V_4

C4141

10U/6.3VS_6

4.99K/F_4

C4109

1U/6.3V_4

C4126

1U/6.3V_4

+1.35V_V GA

10U/6.3VS_6

+1.35V_V GA 16,17 ,40,41

R4079
243/F_4

R4089

R4097

C4142

U4005

M8

H1
N3

P7
P3
N2
P8
P2
R8
R2
T8
R3
L7
R7
N7
T3
T7

M7

M2

N8

M3

J7
K7
K9

K1
L2
J3
K3
L3

F3

G3

E7
D3

C7
B7

T2
L8

J1
L1
J9
L9

K4W4G 1646E-BC1A

C4110

1U/6.3V_4

C4127

1U/6.3V_4

C4143

10U/6.3VS_6

3

VREFCA
VREFDQ

A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10/AP
A11
A12/BC
A13
A14
A15

BA0
BA1
BA2

CK
CK
CKE

ODT
CS
RAS
CAS
WE

DQSL
DQSL

DML
DMU

DQSU
DQSU

RESET
ZQ

NC#J1
NC#L1
NC#J9
NC#L9

96-BALL

SDRAM DDR3

C4098

0.1U/10V_4

+1.35V_V GA

1U/6.3V_4

+1.35V_V GA

1U/6.3V_4

VDDQ#A1
VDDQ#A8
VDDQ#C1
VDDQ#C9
VDDQ#D2
VDDQ#E9
VDDQ#F1
VDDQ#H2
VDDQ#H9

VSSQ#B1
VSSQ#B9
VSSQ#D1
VSSQ#D8
VSSQ#E2
VSSQ#E8
VSSQ#F9
VSSQ#G1
VSSQ#G9

C4111

C4128

10U/6.3VS_6

DQL0
DQL1
DQL2
DQL3
DQL4
DQL5
DQL6
DQL7

DQU0
DQU1
DQU2
DQU3
DQU4
DQU5
DQU6
DQU7

VDD#B2
VDD#D9
VDD#G7
VDD#K2
VDD#K8
VDD#N1
VDD#N9
VDD#R1
VDD#R9

VSS#A9
VSS#B3
VSS#E1
VSS#G8

VSS#J2

VSS#J8
VSS#M1
VSS#M9
VSS#P1
VSS#P9

VSS#T1

VSS#T9

4.99K/F_4

4.99K/F_4

C4144

R4090

R4098

C4112

1U/6.3V_4

C4129

1U/6.3V_4

E3
F7
F2
F8
H3
H8
G2
H7

D7
C3
C8
C2
A7
A2
B8
A3

B2
D9
G7
K2
K8
N1
N9
R1
R9

A1
A8
C1
C9
D2
E9
F1
H2
H9

A9
B3
E1
G8
J2
J8
M1
M9
P1
P9
T1
T9

B1
B9
D1
D8
E2
E8
F9
G1
G9

1U/6.3V_4

1U/6.3V_4

C4145

10U/6.3VS_6

VMA_DQ60
VMA_DQ58
VMA_DQ62
VMA_DQ57
VMA_DQ61
VMA_DQ56
VMA_DQ63
VMA_DQ59

VMA_DQ43
VMA_DQ46
VMA_DQ40
VMA_DQ47
VMA_DQ41
VMA_DQ45
VMA_DQ42
VMA_DQ44

C4113

C4130

Should be 240
Ohms +-1%

C4099

0.1U/10V_4

C4114

1U/6.3V_4

C4131

1U/6.3V_4

C4146

10U/6.3VS_6

C4115

1U/6.3V_4

C4132

1U/6.3V_4

C4147

10U/6.3VS_6

VREFC_VMA 4
VREFD_VMA 4

VMA_MA0
VMA_MA1
VMA_MA2
VMA_MA3
VMA_MA4
VMA_MA5
VMA_MA6
VMA_MA7
VMA_MA8
VMA_MA9
VMA_MA10
VMA_MA11
VMA_MA12
VMA_MA13VMA_MA13VMA_MA13VMA_MA13
VMA_MA14VMA_MA14VMA_MA14VMA_MA14

VMA_BA0
VMA_BA1
VMA_BA2

VMA_CLK1
VMA_CLK1 #
VMA_CKE1

VMA_ODT1
VMA_CSA1 #_0
VMA_RAS1 #
VMA_CAS1 #
VMA_WE 1#

VMA_RDQS6

VMA_WDQS6

VMA_DM6
VMA_DM4

VMA_RDQS4

VMA_WDQS4

R4080
243/F_4

R4091

4.99K/F_4

R4099

4.99K/F_4

1U/6.3V_4

1U/6.3V_4

C4116

C4133

U4006

M8

VREFCA

H1

VREFDQ

N3

A0

P7

A1

P3

A2

N2

A3

P8

A4

P2

A5

R8

A6

R2

A7

T8

A8

R3

A9

L7

A10/AP

R7

A11

N7

A12/BC

T3

A13

T7

A14

M7

A15

M2

BA0

N8

BA1

M3

BA2

J7

CK

K7

CK

K9

CKE

K1

ODT

L2

CS

J3

RAS

K3

CAS

L3

WE

F3

DQSL

G3

DQSL

E7

DML

D3

DMU

C7

DQSU

B7

DQSU

T2

RESET

L8

ZQ

J1

NC#J1

L1

NC#L1

J9

NC#J9

L9

NC#L9

96-BALL

SDRAM DDR3

K4W4G 1646E-BC1A

C4100

0.1U/10V_4

C4117

1U/6.3V_4

C4134

1U/6.3V_4

2

18

VMA_DQ53

E3

DQL0

VMA_DQ54

F7

DQL1

VMA_DQ49

F2

DQL2

VMA_DQ55

F8

DQL3

VMA_DQ50

H3

DQL4

VMA_DQ51

H8

DQL5

VMA_DQ48

G2

DQL6

VMA_DQ52

H7

DQL7

VMA_DQ37

D7

DQU0

VMA_DQ32

C3

DQU1

VMA_DQ38

C8

DQU2

VMA_DQ33

C2

DQU3

VMA_DQ36

A7

DQU4

VMA_DQ34

A2

DQU5

VMA_DQ39

B8

DQU6

VMA_DQ35

A3

DQU7

B2

VDD#B2

D9

VDD#D9

G7

VDD#G7

K2

VDD#K2

K8

VDD#K8

N1

VDD#N1

N9

VDD#N9

R1

VDD#R1

R9

VDD#R9

A1

VDDQ#A1

A8

VDDQ#A8

C1

VDDQ#C1

C9

VDDQ#C9

D2

VDDQ#D2

E9

VDDQ#E9

F1

VDDQ#F1

H2

VDDQ#H2

H9

VDDQ#H9

A9

VSS#A9

B3

VSS#B3

E1

VSS#E1

G8

VSS#G8

J2

VSS#J2

J8

VSS#J8

M1

VSS#M1

M9

VSS#M9

P1

VSS#P1

P9

VSS#P9

T1

VSS#T1

T9

VSS#T9

B1

VSSQ#B1

B9

VSSQ#B9

D1

VSSQ#D1

D8

VSSQ#D8

E2

VSSQ#E2

E8

VSSQ#E8

F9

VSSQ#F9

G1

VSSQ#G1

G9

VSSQ#G9

R4092

4.99K/F_4

4.99K/F_4

R4100

C4101

0.1U/10V_4

1

TOP BSQQBCON PN

Hynix 2G
Micron 2G
SAMSUNG 2G

2

AKD5PZDTW02
AKD5PZSTL01
AKD5PGDT501

Size

Size

Size

Custom

Custom

Custom

NB5

NB5

NB5

Date: Sheet o f

Date: Sheet o f

Date: Sheet o f

AKD5PZDTW01
AKD5PZSTL00
AKD5PGDT500

PROJECT : Y23

PROJECT : Y23

PROJECT : Y23

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Document Number Rev

Document Number Rev

Document Number Rev

Sun S3 VRAM(DDR3 BGA96P)

Sun S3 VRAM(DDR3 BGA96P)

Sun S3 VRAM(DDR3 BGA96P)

1

18 43Friday, October 17 , 2014

18 43Friday, October 17 , 2014

18 43Friday, October 17 , 2014

1A

1A

1A

5

4

3

2

1

19

D D

C C

B B

A A

PROJECT : Y23

PROJECT : Y23

PROJECT : Y23

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size

Document Number Rev

Size

Document Number Rev

Size

Document Number Rev

Custom

Custom

Custom

Sun S3 VRAM(DDR3 BGA96P)

Sun S3 VRAM(DDR3 BGA96P)

NB5

NB5

5

4

3

2

NB5

Sun S3 VRAM(DDR3 BGA96P)

Date: Sheet o f

Date: Sheet o f

Date: Sheet o f

1

1A

1A

1A

19 43Friday, October 17 , 2014

19 43Friday, October 17 , 2014

19 43Friday, October 17 , 2014

5

14” & 15” only eDP panel SKU , 17” have both LVDS & eDP SKU

SCA_SCL_CFG1
SCA_SDA_CFG0

R6006

R6007

*4.7K_4

*4.7K_4

Reserve

SMB_RUN_CLK 5,11,12

MBCLK2 4,12,30

MBDATA2 4,12,30

SMB_RUN_DAT 5,11,12

R6002 *1K/F_4

R7048
100K/F_4

APU(use this for LVDS)

EC SMBUS

APU(use this for LVDS)

SCL1_2136

SDA1_2136

EDP_HPD4,21

R6004 *4.7K_4
R6005 *4.7K_4

R6010*0_4

R6011 *0_4

R6012 *0_4

R6013*0_4

EDP_HPD EDP_HPD_2136

+3V

D D

C C

4

+TRAVIS1.2V

RTD2136 Dual Channel only

Pine 15/17: keep 20 Mile Trace

R6001 *100k/F_4

EDP_HPD_2136

eDP_AUXN_2136
eDP_AUXP_2136

LANE0P
LANE0N
LANE1P
LANE1N

SCL1_2136
SDA1_2136

EDIDDATA_2136
EDIDCLK_2136
SCA_SDA_CFG0
SCA_SCL_CFG1

IC

󱷞󱷞󱷞󱷞󵀱󵀱󵀱󵀱󵙉󵙉󵙉󵙉 󲋮󲋮󲋮󲋮

GN D V I A * 9

10

13
14

45
46
47
48

49

1
2
3
4

7
8
9

U6000

DP_HPD
TESTMODE
AUX-CH_N
AUX-CH_P

LANE0P
LANE0N
LANE1P
LANE1N

CIICSCL1
CIICSDA1

MIICSDA1
MIICSCL1
MIICSDA0
MIICSCL0

GND

+SWR_LX

17

SWR_LX

DP_GND

6

RTD2136N

GND

16

R6000 use 1%

3

+TRAVIS3.3V_A +3V +3V

Pine 18: keep 80 Mile Trace

+TRAVIS3.3V

reserve for EMI

15

5

11

DP_REXT

12

R6000

*12K/F_4

DP_V12

18

22

43

VCCK

DP_V33

SWR_VDD

SWR_VCCK

PWMOUT19PANEL_VCC20PWMIN

21

Pine 20: keep 80 Mile Trace

DISP_ON_2136

DPST_PWM_2136

R6009

*100K/F_4

TXO0-

PVCC

TXO0+

TXO1-

TXO1+

TXO2-

TXO2+

TXOC-

TXOC+

TXO3-

TXO3+

TXE0-

TXE0+

TXE1-

TXE1+

TXE2­TXE2+
TXEC-

TXEC+

TXE3­TXE3+

BL_EN

R6052 0_4

42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23

44

TXOOUT0-_2136
TXOOUT0+_2136
TXOOUT1-_2136
TXOOUT1+_2136
TXOOUT2-_2136
TXOOUT2+_2136

TXOCLKOUT­TXOCLKOUT+

LVDS_BLON_2136

DISP_ON_2136 21
DPST_PWM_2136 21

APU_DPST_PWM 4

DPST_PWM 21

EC6001
*0.1U/10V_4

TXEOUT0- 21
TXEOUT0+ 21
TXEOUT1- 21
TXEOUT1+ 21
TXEOUT2- 21
TXEOUT2+ 21
TXECLKOUT- 21
TXECLKOUT+ 21

LVDS_BLON_2136 21

EC6000
*0.1U/10V_4

2

keep 80 Mile Trace

+3V +TRAVIS3.3V +TRAVIS3.3V

L6001

*PBY160808T-600Y-N(60,3A)

USING 60R 1A

+SWR_LX

+3V

L6000
*4.7UH20%,0.76A,LVF303010-4R7M-N

R6008 *0_8

C6009
*10U/6.3VS_6

+TRAVIS3.3V_A

L6002

*PBY160808T-600Y-N(60,3A)

+TRAVIS1.2V

Close to Pin17

SWR: Stuff L6000
LDO: Stuff R6008 (default pop this)

L6000: need use CV-4709MN00 for Vendor suggestion

nd CV-4708MN03

2

C6010

*0.1U/10V_4

C6006
*10U/6.3VS_6

C6001
*10U/6.3VS_6

CLOSE TO Pin22

C6011
*0.1U/10V_4

Close to Pin5

C6007
*0.1U/10V_4

C6002
*0.1U/10V_4

Close to Pin43

1

C6004
*0.1U/10V_4

Close to Pin18
within 200-mil

C6008
*0.1U/10V_4

C6003
*0.1U/10V_4

19

C6005
*22U/6.3VS_6

Close to Pin11

C6000
*0.1U/10V_4

INT_eDP_TXP04
INT_eDP_TXN04

B B

From CPU

INT_eDP_TXP14
INT_eDP_TXN14

INT_eDP_TXP0
INT_eDP_TXN0

INT_eDP_TXP1
INT_eDP_TXN1

C6026 *0.1U/10V_4
C6029 *0.1U/10V_4
R6036 0_4
R6035 0_4

C6024 *0.1U/10V_4
C6025 *0.1U/10V_4
R6032 0_4
R6031 0_4

LANE0P
LANE0N

eDP_TXP0
eDP_TXN0

LANE1P
LANE1N

eDP_TXP1
eDP_TXN1

To 2136

To 2136

TXOOUT0+_2136
TXOOUT0-_2136
eDP_TXP1
eDP_TXN1

TXOOUT1+_2136
TXOOUT1-_2136
eDP_TXP0
eDP_TXN0

TXOOUT2+_2136
TXOOUT2-_2136

R6042 *0_4
R6044 *0_4
C6034 0.1U/10V_4
C6033 0.1U/10V_4

R6039 *0_4
R6040 *0_4
C6031 0.1U/10V_4
C6030 0.1U/10V_4

R6048 *0_4
R6049 *0_4

TXLOUT0+ 21
TXLOUT0- 21

Close to LVDS CONN

TXLOUT1+ 21
TXLOUT1- 21

TXLOUT2+_R 21

TXLOUT2-_R 21

For EDP Only: stuf f Resi st or

For LVDS only stuf f Cap

TXOCLKOUT+
TXOCLKOUT-

A A

R6034 *1M/F_4

INT_eDP_AUXN4
INT_eDP_AUXP4

+3V

R6037 *1M/F_4

INT_eDP_AUXN eDP_AUXN_2136

INT_eDP_AUXP

5

C6027 *0.1U/10V_4
C6028 *0.1U/10V_4
R6033 0_4
R6038 0_4

eDP_AUXP_2136

eDP_AUXN
eDP_AUXP

To 2136

EDIDDATA_2136
EDIDCLK_2136
eDP_AUXN
eDP_AUXP

4

R6050 *0_4
R6051 *0_4

R6043 *0_4
R6041 *0_4
C6035 0.1U/10V_4
C6032 0.1U/10V_4

For EDP Only: stuf f Cap

For LVDS only stuf f Resi st or

3

TXLCLKOUT+_R 21
TXLCLKOUT-_R 21

EDIDDATA_R 21

EDIDCLK_R 21

+3V4,5,6,7,11,12,21,22,23,24,27,28,29,30,36,38,40

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v

Custom

Custom

Custom

LVDS converter RTD2136

LVDS converter RTD2136

NB5

NB5

2

NB5

LVDS converter RTD2136

Date: Sheet of

Date: Sheet of

Date: Sheet of

1

20 43Friday, October 17, 2014

20 43Friday, October 17, 2014

20 43Friday, October 17, 2014

1A

1A

1A

1

LVDS conn.

14” & 15” only eDP panel SKU , 17” have bot h LVDS & eDP SKU

EMU_LID30

BRIGHT

+3V

R63
100K/F_4

C660

0.1U/25V_4

LVDS_BLON1

R22

L4 0_8

A A

For LVDS Only

DISP_ON_213620

For EDP Only

B B

C C

DISP_ON

+VIN

C654
1U/6.3V_4

R66 0_4

R58 1K/F_4

R61
100K/F_4

R519
*100K/F_4

U1

5

IN

4

IN

3

ON/OFF

IC(5P) G5243AT11U

AL005243001 GMT:G5243AT11U
AL002821000 BCD:AP2821KTR-G1

1K/F_4

R23

100K/F_4

+VIN_BLIGHT

C637 0.1U/25V_4
C638 0.01U/50V_4
C639 *4.7U/25V_8

C650
*4.7U/6.3V_4

OUT

GND

C644
22P/50V_4

R70 *0_8

1
2

VADJ1

2

PN_BLON

L11 0_6

+VIN_BLIGHT

BLON_CON

D6 RB500V-40

80 mile trace

C649

0.01U/50V_4

2 1

+3VLCD_CON

C653

0.1U/10V_4

2 1

C648 22P/50V_4

R67 100K/F_4

+3VLCD_CON

C645
10U/6.3V_6

2 1

3

4

TXLOUT0+20
TXLOUT0-20

TXLOUT1+20
TXLOUT1-20

TXLOUT2+_R20
TXLOUT2-_R20

TXLCLKOUT+_R20
TXLCLKOUT-_R20

EDIDDATA_R20
EDIDCLK_R20

TXEOUT0-20
TXEOUT0+20
TXEOUT1-20
TXEOUT1+20
TXEOUT2-20
TXEOUT2+20
TXECLKOUT-20
TXECLKOUT+20

TXLOUT0+
TXLOUT0-

TXLOUT1+
TXLOUT1-

TXLOUT2+_R
TXLOUT2-_R

TXLCLKOUT+_R
TXLCLKOUT-_R

EDIDDATA_R
EDIDCLK_R

TXEOUT0­TXEOUT0+
TXEOUT1­TXEOUT1+
TXEOUT2­TXEOUT2+
TXECLKOUT­TXECLKOUT+

For EDP Only(DG show AUX don't require PU/D)

+3V

R35 *100K_4
R34 *100K_4

+3V

R74 *1K_4
R59 *1K_4

EDIDDATA_R
EDIDCLK_R

BRIGHT
LVDS_BLON1

For LVDS Only

DPST_PWM_213620
LVDS_BLON_213620

5

+3V

R73 *0_4
R64 *0_4

C546

*0.01U/50V_4

BRIGHT
LVDS_BLON1

6

For LVDS

+3V_CAM EDIDCLK_R

C641
*4.7U/6.3V_4

For LVDS Only: Stuf f Rc
For EDP Only: Stuf f Rd

+3V

R47 *4.7K_4
R48 *4.7K_4

+3VLCD_CON

EDP_HPD4,20

DIGITAL_CLK23

DIGITAL_D123

C642

*10P/50V_4

USBP4+6
USBP4-6

*0.047U/10V_4

1 2

C646

*10P/50V_4

USBP4­USBP4+

C643

EDIDDATA_R

*0.047U/10V_4

1 2

C647

L3 FCM1005KF-301T03
L2 FCM1005KF-301T03

7

C651

*10P/50V_4

R51 0_6

+3V

R2 *0_4

R1 0_4

Rd

1
4 3

L5
*MCM2012B900GBE

R7093 0_4
R7094 0_4

Rc

EDP_HPD_R

+VIN_BLIGHT

2

C652

*10P/50V_4

C640

1000P/50V_4

USBP4+_R
USBP4-_R

USBP4-_R
USBP4+_R

RF

EDIDCLK_R
EDIDDATA_R

TXLOUT0­TXLOUT0+

TXLOUT1­TXLOUT1+

TXLOUT2-_R
TXLOUT2+_R

TXLCLKOUT-_R
TXLCLKOUT+_R

TXEOUT0­TXEOUT0+

TXEOUT1­TXEOUT1+

TXEOUT2­TXEOUT2+

TXECLKOUT­TXECLKOUT+

+3V_CAM
USBP4-_R
USBP4+_R

DIGITAL_CLK_L
DIGITAL_D1_R

VADJ1
BLON_CON

CN2

DFFC40FR064

lvds-50671-04041-001-40p-l

51519-04041-001

8

40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1

17

G_0 G_1

For EDP Only

DPST_PWM20

APU_LVDS_BLON4

APU_DISP_ON4

R38 10/F_4
R60 0_4
R85 0_4

BRIGHT
LVDS_BLON1

DISP_ON

+3V4,5,6,7,11,12,20,22,23,24,27,28,29,30,36,38,40

+VIN25,27,31,32,33,35,37,39,40,41,42

D D

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v
Custom

Custom

Custom

LCD CONN/Camera/D-MIC

LCD CONN/Camera/D-MIC

NB5

NB5

1

2

3

4

5

6

NB5

7

LCD CONN/Camera/D-MIC

Date: Sheet of

Date: Sheet of

Date: Sheet of

21 43Friday, October 17, 2014

21 43Friday, October 17, 2014

21 43Friday, October 17, 2014

8

1A

1A

1A

HDMI Conn.

5

4

3

2

1

18

D D

C C

+3V

Q10
2N7002K

1 2

R214 *100K/F_4

C268 *0.1U/10V_4

Close to Q10

B B

HDMI SMBus Isolat i on

R213 2.2K_4

+3V

INT_HDMI_AUXP4

INT_HDMI_AUXN4

2

+3V

R221 2.2K_4

Check list recommend 604 ohm

DGPU_CL_HDMIP

3

1

R271 499/F_4
R267 499/F_4

R257 499/F_4
R252 499/F_4

R263 499/F_4
R260 499/F_4

R241 499/F_4
R228 499/F_4

Q9

4 3

1

2N7002KDW

+3V

5

2
6

HDMI_SCLK

HDMI_SDATA

Close to HDMI connector

IN_D2
IN_D2#

IN_D1
IN_D1#

IN_D0
IN_D0#

IN_CLK
IN_CLK#

HDMI_HPD_Q4

HDMI HPD SENSE

IN_D2
IN_D1
IN_D0
IN_CLK

HDMI_HPD_Q

R269 120/F_4
R255 120/F_4
R261 120/F_4
R230 120/F_4

+3V

R191
1K/F_4

Q7B

61

2N7002KDW

Du al

2KV ESD protection

IN_D24

IN_D2#4

C259

0.01U/50V_4

IN_D14

IN_D1#4

IN_D04

IN_D0#4
IN_CLK4

IN_CLK#4

R581 2.2K_4
R193 2.2K_4

C254 *10P/50V_4
C261 *10P/50V_4

IN_D2#
IN_D1#
IN_D0#
IN_CLK#

+5V

+5V

R192
100K/F_4

2

Q7A

34

5

2N7002KDW

R179 200K_4

Du al

D5
BAT54AW-L

3

2

1

HDMI_HPDHDMI_DET_R

R178
100K/F_4

5V_HSMBCK
5V_HSMBDT

L19 0_6

+5VCRT

for EMI request

IN_D2
IN_D2#

IN_D1
IN_D1#

IN_D0
IN_D0#

IN_CLK
IN_CLK#

HDMI_SCLK
HDMI_SDATA

C249

220P/50V_4

+5VCRT

VC1
*AVLC 5S_4

+5V

HDMI_DET_CHDMI_HPD

CN12

SHELL3
SHELL1

1

D2+

2

D2 Shield

3

D2-

4

D1+

5

D1 Shield

6

D1-

7

D0+

8

D0 Shield

9

D0-

10

CK+

11

CK Shield

12

CK-

13

CE Remote

14

NC

15

DDC CLK

16

DDC DATA

17

GND

18

+5V

19

HP DET

SHELL2
SHELL4

HDMI CONN_4 pin GND

DFHD19MR249

dmi-2he1655-001111f-19p

h

F1 FUSE1A6V_POLY

40 mils

C260 0.1U/10V_4

SSM14 spec is 40V 1A

22
20

21
23

12

+5VCRT

+5VCRT

+3V4,5,6,7,11,12,20,21,23,24,27,28,29,30,36,38,40

+3VPCU4,7,23,27,28,30,31,32

+5V23,24,27,28,40

+VIN21,25,27,31,32,33,35,37,39,40,41,42

+5VS523,28,32,33,34,35,36,38,40,41,43

A A

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v
Custom

Custom

Custom

LCD Connector (LVDS)

LCD Connector (LVDS)

NB5

NB5

5

4

3

2

NB5

LCD Connector (LVDS)

Date: Sheet of

Date: Sheet of

Date: Sheet of

1

22 43Friday, October 17, 2014

22 43Friday, October 17, 2014

22 43Friday, October 17, 2014

1A

1A

1A

A

1005KF-181T15

+3V_DVDD

L1002

+3V

C1004
1U/6.3V_4

TO Digital MIC

DIGITAL_D121
DIGITAL_CLK21

ACZ_SDOUT_AUDIO5

BIT_CLK_AUDIO5

Close to PIN7

ACZ_SDIN05

ACZ_SYNC_AUDIO5

ACZ_RST#_AUDIO5

C1026

2.2U/6.3V_6

+3V_DVDD

Close to Pin 34,35,36

+5V_DVDD

L1010

+5V

1005KF-181T15

1 1

+5V_DVDD

VOLMUTE#24,30

Close to PIN1

C1005
10U/6.3VS_6

C1010 10P/50V_4
R1020 0_4
R1002 100/F_4

C1016 10P/50V_4

R1003 0_4

R1005 33_4

C1023 *0.1U/10V_4

C1024 2.2U/6.3V_6

CAP-

CAP+
+3V_DVDD

C10324.7U/6.3V_4

TO Internal Speakers

+5V_DVDD

C10350.1U/10V_4
C103610U/6.3VS_6

C10370.1U/10V_4
C103810U/6.3VS_6

PD#

21

D1000 RB500V-40

C1006

0.1U/10V_4

PV modify to short pad

+1.5V

+3V

DMIC0
DMIC_CLK_R

ACZ_SDOUT_AUDIO
HD_BCLK

C102110U/6.3VS_6

HD_SDIN0

+3V_DVDD-IO

ACZ_SYNC_AUDIO

AMP_BEEP

L_SPK+

L_SPK­R_SPK­R_SPK+

Close to Pin 41

Close to Pin 46

HP_EAPD24

+3V_DVDD

R1000
1K/F_4

PD#

R1017
10K_4

ACZ_SDIN0

ACZ_SDOUT_AUDIO

ACZ_SYNC_AUDIO

BIT_CLK_AUDIO

L1003

L1004

U1001

1

DVDD

2

GPIO0/ DMIC-DATA

3

GPIO1 / DMIC-CLK

4

DVSS

5

SDATA-OUT

6

BCLK

7

LDO3-CAP

8

SDATA-IN

9

DVDD-IO

10

SYNC

11

RESETB

12

PCBEEP

34

CPVEE

35

CBN

37

CBP

36

CPVDD

42

SPK-L+

43

SPK-L-

44

SPK-R-

45

SPK-R+

HP_EAPD

USB 2.0 AND AUDIO COMBO JACK

EC1005 *33P/50V_4

EC1006 *10P/50V_4

EC1007 *10P/50V_4

EC1008 *33P/50V_4

FOR EMI

A

1005KF-181T15

*1005KF-181T15

PVDD1

NC

41

49

Digital

PVDD246SPDIF-OUT/GPIO2

PDB

47

B

48

B

C1007

0.1U/10V_4

>40mils trace

+3V_DVDD-IO

C1008
10U/6.3VS_6

AVDD1
AVDD2

AVSS1
AVSS2

LDO1-CAP
LDO2-CAP

VREF

Analog

HPOUT-L (PORT I)

HPOUT-R (PORT I)

LINE2-L
LINE2-R

LINE1-L (PORTC)

LINE1-R (PORTC)

MIC1-R (PORTB)

MIC1-L (PORTB)

MIC1-VREFO-L

MIC1-VREFO-R

MIC2-R (PORTF)

MIC2-L (PORTF)

MIC2-VREFO

MONO-OUT

SenseA

JDREF

SenseB

13

15

14

R1011 20K/F_4

SENSE_A_1

Close to codec

C42051

220P/50V_4

+5V_AVDD

C1001
10U/6.3VS_6

+1.5V_AVDD

26
40

25
38

27
39

28

C1020 0.1U/10V_4
C1022 2.2U/6.3V_6

OUT_L

32

OUT_R

33

24
23

22
21

20
19

31

MUTE_LED_CNTL_L

30

MIC_R1

18

MIC_L1 EXT_MIC_L

17

VREFOUT_C EXT_MIC_L

29
16

ALC3227 x QFN48

R509 20K/F_4

R1012 39.2K/F_4

AGND

C1009
10U/6.3VS_6

AGND

R1019 100K/F_4

C1017 10U/6.3VS_6

C1030*4.7U/6.3V_6
C10314.7U/6.3V_4

C1045

*1U/6.3V_4

AGND

SENSE_A

EC42037 100P/50V_4
EC42038 100P/50V_4
EC42039 100P/50V_4
EC42040 100P/50V_4
EC42041 100P/50V_4

L1001

1005KF-181T15

C1002

0.1U/10V_4

Close to PIN26

AGND

L1000 *HCB1608KF-181T15_6
L1005

1005KF-181T15

Close to PIN40

AGND

AGND

Close to PIN28

AGND

HPOUT_L 24
HPOUT_R 24

R1022 0_4

R1007 1K/F_4

R1018 2.2K_4

3

SENSE_A 24

PCIE_CLKREQ_CARD#
PCIE_CLKREQ_LAN#
PCIE_RST#_R1
PCIE_WAKE#
USBPW_ON#

FOR EMI, close to connector

C42052

220P/50V_4

C42053

220P/50V_4

NBSWON1#
LID_EC#

DEEP_PWRLED#

+3VPCU

FOR EMI, close to connector

C

Q34

C

2N7002K

2

EC42043

0.1U/10V_4

+1.5V

1

AGND

AGND SHIELD
AGND SHIELD
AGND SHIELD

USB30_TX2+6

USB30_TX2-6

USB30_RX2+6

USB30_RX2-6

PCIE_CLKREQ_CARD#5

PCIE_CLKREQ_LAN#5

12

+3V

MUTE_LED_CNTL 28

EXT_MIC_L 24

R502 0_4

R327 22K/F_4

C447

4.7U/6.3V_4

USBP6+6
USBP6-6

USBP0+6
USBP0-6

PCIE_RST#_R15,13,29

PCIE_WAKE#5,29
USBPW_ON#28,30

NBSWON1#30

LID_EC#30
DEEP_PWRLED#27,30
+3VPCU

+3VLANVCC

+3V

+5VS5

PCIE_TXP1_LAN2
PCIE_TXN1_LAN2

CLK_PCIE_LANP6
CLK_PCIE_LANN6

PCIE_RXP1_LAN2
PCIE_RXN1_LAN2

PCIE_TXP2_CARD2
PCIE_TXN2_CARD2

CLK_PCIE_CARDP6
CLK_PCIE_CARDN6

PCIE_RXP2_CARD2
PCIE_RXN2_CARD2

+5V

*AZ2015-01H
C1003

C581 need check!

+5V_AVDD

C1011
*2.2U/6.3V_6

AGND

AGND

L_SPK+
L_SPK­R_SPK­R_SPK+

SENSE_A

EXT_MIC_L

R325
22K/F_4

C1012
*0.1U/10V_4

PCIE_CLKREQ_CARD#
PCIE_CLKREQ_LAN#
PCIE_RST#_R1
PCIE_WAKE#
USBPW_ON#

NBSWON1#
LID_EC#

DEEP_PWRLED#

EC42035 0.1U/10V_4

EC852 0.1U/10V_4

EC42036 0.1U/10V_4

D

+5V22,24,27,28,40
+3V4,5,6,7,11,12,20,21,22,24,27,28,29,30,36,38,40

+1.5V7,40

U1000

C1018
*1U/6.3V_4C1019 10U/6.3VS_6

5
4

Vout

Vin
BYP
GND2EN

*TPS793475DBVR

HPA01091DBVR

1

3

R1004 10K_4

Vset=1.242V

C1013

0.1U/10V_4

Close to Speaker

Speaker 4 ohm: 40mils

PBY160808T-600Y-N(60,3A)

L1006

PBY160808T-600Y-N(60,3A)

L1007

PBY160808T-600Y-N(60,3A)

L1008

PBY160808T-600Y-N(60,3A)

L1009

C1025
1000P/50V_4

C1000

AMP_BEEP AMP_BEEP_R2AMP_BEEP_L

Check layout
mount location

D

0.1U/10V_4

0.01U/50V_4

CN10 Card LAN 55P

55

55

54

54

53

53

52

52

51

51

50

50

49

49

48

48

47

47

46

46

45

45

44

44

43

43

42

42

41

41

40

40

39

39

38

38

37

37

36

36

35

35

34

34

33

33

32

32

31

31

30

30

29

29

28

28

27

27

26

26

25

25

24

24

23

23

22

22

21

21

20

20

19

19

18

18

17

17

16

16

15

15

14

14

13

13

12

12

11

11

10

10

9

9

8

8

7

7

6

6

5

5

4

4

3

3

2

2

1

1

C1027

1000P/50V_4

C1034

C1014

0.047U/10V_4

+5V

L_SPK+_R
L_SPK-_R
R_SPK-_R
R_SPK+_R

C1028
1000P/50V_4

AGND

+5V

C1015
1U/6.3V_4

INT SPEAKER CONN

4
3
2
1

CN1001

C1029

1000P/50V_4

check value

R1009 100K/F_4

R1010
10K_4

NB5

NB5

NB5

E

22

EC1001 1000P/50V_4

EC1002 1000P/50V_4
EC1003 1000P/50V_4
EC1004 1000P/50V_4
EC1000 1000P/50V_4

AGND

place to near U24 or under U24

AGND

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom
Date: Sheet o f

Date: Sheet o f

Date: Sheet o f

Close to CODEC

R1016 *0_8/s

+5V_AVDD

R1008

2N7002

10K_4

3

2

Q1001

AGND

E

ACZ_SPKR 5

1

23 43Friday, October 17, 2014

23 43Friday, October 17, 2014

23 43Friday, October 17, 2014

C1033

0.1U/10V_4

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Azalia ALC 3227

Azalia ALC 3227

Azalia ALC 3227

1A

1A

1A

5

4

3

2

1

Head Phone out

+5V_AMP

C801 1U/10V_6

R624 *0_4

D D

Rout as differential pair

HPOUT_L23

HPOUT_R23

AGND

AGND

R387 0_4

R388 0_4

R625 *0_4

HPOUT_L1

AGND

HPOUT_R1

C797 2.2U/6.3V_4

R6220 0_4

C7991 2.2U/6.3V_4

R6230 0_4
C8001 2.2U/6.3V_4

HPOUT_L2

C7981 2.2U/6.3V_4

HPOUT_R2

U28

1
2
3
4
5

LEFTINML­LEFTINP+
GND
RIGHTINP+
RIGHTINM-

TEST27TEST18GND9GND

SD#

6

20

TPA6133A2

Placement close the CODEC

VOLMUTE#

HP_EAPD

R6130 100K/F_4

2

1

D13

BAT54A-7-F

AMP_PD#_R

3

HPA022642RTJR

+3V

VOLMUTE#23,30

HP_EAPD23

C C

C803 1U/10V_4

19

18

CPP

VDD

GND

AGND21AGND22AGND23AGND24AGND

10

TPA6133A 2

AMP_CLK
AMP_DAT

17

CPM

AGND

16

CPVSS

HPLEFT

CPVSS

HPRIGHT

25

AGNDAGND

AGND
AGND
AGND
AGND
AGND

15
14
13

GND

12

VDD

11
30

29
28
27
26

HPA022642RTJR

C804 1U/10V_4

LINEOUT_L

LINEOUT_R

R6120

2K/F_4

+5V_AMP

R6110

2K/F_4

AGND

+5V_AMP

AGND

+5V_AMP

C802
1U/25V_6

L47

HCB1005KF-181T15(180,1.5A)_4

R6150 0_4

R6140 0_4

+5V

C806
*1000P/50V_4

R6160 *0_4

R6170 *0_4

bypass AMP path

LINEOUT_R_CLINEOUT_R

LINEOUT_L_CLINEOUT_L

C805
*1000P/50V_4

AGND

LINEOUT_L_CHPOUT_L

LINEOUT_R_CHPOUT_R

26

Audio Combo

EXT_MIC_L23

AGND SHIELD
AGND SHIELD
AGND SHIELD

B B

LINEOUT_L_C

LINEOUT_R_C LINEOUT_R_C1 LINEOUT_R_C2

HCB1608KF-601T10

R7090
*22K/F_4

AGND

R7088 30/F_4

R7086 30/F_4

L6010

SI

EXT_MIC_1EXT_MIC_L

AGND

C42019

100P/50V_4

C42018

100P/50V_4

SENSE_A 23

VC5002
*AVLC 5S_4

AGND

C1
100P/50V_4

AGND

LINEOUT_L_C1 LINEOUT_L_C2

AGND AGND

AGND

L6011 FCM1005KF-301T02

L6009 FCM1005KF-301T02

AGND

SENSE_A

VC5003
*AVLC 5S_4

For EMI

EC42042
100P/50V_4

AGND

R7089 0_4

SENSE_A

CN2001

3
1

5
6
2
4

Audio Jack

7

R7087
*0_4

AGND

A A

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size

Size

Size

Document Number Re v

Document Number Re v

Document Number Re v

C

C

C

Card Reader

Card Reader

NB5

NB5

5

4

3

2

NB5

Card Reader

Date: Sheet o f

Date: Sheet o f

Date: Sheet o f

1

24 43Friday, October 17, 2014

24 43Friday, October 17, 2014

24 43Friday, October 17, 2014

1A

1A

1A

5

+VIN +VIN +VIN +VIN +VIN +VIN +VIN +VIN +VIN +VIN +VIN +VIN +VIN +VIN +VIN +VIN +VIN +VIN +VIN +VIN

4

3

2

1

C42031

C42032

0.1U/25V_4

D D

0.1U/25V_4

C42033

0.1U/25V_4

C42034

0.1U/25V_4

C42037

0.1U/25V_4

C42038

0.1U/25V_4

C42039

0.1U/25V_4

C42036

0.1U/25V_4

0.1U/25V_4

C42035

C42040

0.1U/25V_4

C42041

0.1U/25V_4

C42042

0.1U/25V_4

C42043

0.1U/25V_4

C42044

0.1U/25V_4

C42045

0.1U/25V_4

C42046

0.1U/25V_4

C42047

0.1U/25V_4

C42048

0.1U/25V_4

C42049

0.1U/25V_4

C42050

0.1U/25V_4

Place on 19V path

C C

PAD3
*SPAD-RE315X157NP

B B

A A

H8
*H-TC294BC197D146P2

1

H16
*H-TC276I146BC197D146P2

1

PAD1
*SPAD-Y23X-1

1

H9
*H-TC294BC197D146P2

1

VGA Socket Hole

H17
*H-TC276I146BC197D146P2

1

PAD2
*O-Y16X-3

1

EMI

5

H18
*H-TC276I146BC197D146P2

1

H19
*H-TC276I146BC197D146P2

1

APU Socket Hole

1

12

R337
*64.9K/F_6

C634

12

*Clamp-Diode

R: 64.9K, NC f irst

H3
*H-TC236BC315D110P2

1

H10
*H-TC236BC276D118P2

1

4

H5

H4

*H-TC236BC315D110P2

*O-Y16X-4

1

H11
*H-TC236BC315D118P2

1

3

1

H6
*H-C315D157P2

H12
*H-TC236BC315D118P2

1

H7
*H-TC315BC276D157P2

1

H14
H-TC197BC102D102P2

1

Nut for WLAN

1

H15
*H-C98D98N

PROJECT : X21

PROJECT : X21

1

NB5

NB5

2

NB5

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v
Custom

Custom

Custom
Date: Sheet of

Date: Sheet of

Date: Sheet of

CR SOCKET&HOLE

CR SOCKET&HOLE

CR SOCKET&HOLE

1

25 43Friday, October 17, 2014

25 43Friday, October 17, 2014

25 43Friday, October 17, 2014

1A

1A

1A

1

2

3

4

5

6

7

8

20

A A

B B

C C

D D

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v
Custom

Custom

Custom

AMP TPA6130A2

AMP TPA6130A2

NB5

NB5

1

2

3

4

5

6

NB5

7

AMP TPA6130A2

Date: Sheet of

Date: Sheet of

Date: Sheet of

26 43Friday, October 17, 2014

26 43Friday, October 17, 2014

26 43Friday, October 17, 2014

8

1A

1A

1A

A

Power But t on Connect or ( move t o DB) CPU FAN

4 4

SATA HDD Connector(Cable type)

SATA HDD

10

SATA_TXP0_C

9

SATA_TXN0_C

8
7

SATA_RXN0_C

6

SATA_RXP0_C

5
4

3 3

3
2
1

HD17

SATA_TXP0_C
SATA_TXN0_C

SATA_RXN0_C
SATA_RXP0_C

+5V

C354 10U/6.3VS_6
C348 0.1U/10V_4

+5V: 2 A(4 Pin)
+3V: 2 A(4 Pin)
Gnd : (5 Pin)

+5V

C383 0.01U/50V_4
C381 0.01U/50V_4

C365 0.01U/50V_4
C359 0.01U/50V_4

SATA_TXP0 6
SATA_TXN0 6

SATA_RXN0 6
SATA_RXP0 6

B

FAN1SIG30

+3V

+5V

FAN_PWM30

R409 4.7K_4

FAN_PWM

C545 220P/50V_4

FAN1SIG

C548 220P/50V_4

C544 10U/6.3VS_6
C547 0.1U/10V_4

KB_LED_EN30

FAN1

1

5
2
3
46

FAN Connect

Q11
2N7002

C

D

E

PWR LED

DEEP_PWRLED#23,30

5

6

DEEP_PWRLED#

LED1

3P WHITE LED

C42030 *AVLC 5S_4

21

R7099 75_4

+3VPCU

23

SATA LED

C42029 *AVLC 5S_4

R552
1M_4

ACC_LED#

SATA_LED#

R7097 200/F_6

+3VSUS

+3VSUS

TPDATA30

TPCLK30

2

SATA_R_LED1

3

LED2

1

LED 3P WHITE/AMBER

(Amber)

C42028 *AVLC 5S_4

R336 4.7K_4
R333 4.7K_4

C4520 0.1U/10V_4

C4540 10P/50V_4

L31 BLM15BB470SN1D
L32 BLM15BB470SN1D

C4620 10P/50V_4

TP_SMB_CLK

R3324.7K_4

R3264.7K_4

TP_SMB_DATA

SATA_LED#6

ACC_LED#5

+VIN

3

2

1

R551
2M_4

Q12
AO3404

+5V

3

2

1

C662

0.1U/10V_4

+5V_LED_KBLIGHT

C661

0.1U/10V_4

+5V_LED_KBLIGHT

C808
*0.1U/10V_4

4
3
2
1

CN14

KB_LIGHT_CONN_14_15

4
3
2
1

CN17

*KB_LIGHT_CONN_14

TPCLK
TPDATA

R7098 510_6

1 2

Touch Pad

TPDATA-1
TPCLK-1

TP_SMB_CLK
TP_SMB_DATA

C4450

*33P/50V_4

Dua l

Dua l

+3V

25 mils

C4490

*33P/50V_4

Q19A 2N7002KDW

34

5
2

61

Q19B 2N7002KDW

+VIN21,25,31,32,33,35,37,39,40,41,42

88513-0601-6p-l-smt

DFFC06FR170

TOUCH PAD CONN

1
2
3
4
5
6

CN8

SMB_ALW_CLK 5

+3VSUS+3VSUS

SMB_ALW_DAT 5

SATA ODD CONNECTOR

2 2

OD14

S1

2

TXP

3

TXN

14

14

5

RXN

16

S7
P1

GND1

17

GND2
GND3

15

GND
GND

P6

14 SATA ODD

C584

6

RXP

8

DP

9

+5V

10

+5V

11

MD

1
4
7
12
13

0.1U/10V_4

A

16

17
15

+5V_ODD

10U/6.3VS_6

1 1

Bypass CAP close CONN

SATA_TXP14_C
SATA_TXN14_C

SATA_RXN14_C
SATA_RXP14_C
ZERO_ODD_DP#

ZERO_ODD_DA#

C598 0.01U/50V_4
C594 0.01U/50V_4

C592 0.01U/50V_4
C591 0.01U/50V_4

120 mils

C581

C586

0.1U/10V_4

0.1U/10V_4

+5V_ODD

C585

C582

0.1U/10V_4

SATA_TXP1 6
SATA_TXN1 6

SATA_RXN1 6
SATA_RXP1 6

Reserve for AMD

B

R452
*10K/F_4

R451
10K/F_4

OD1517

1
2
3

19
20

4
5
6
7
8

9
10
11
12
13
14
15

19

16

20

17
18

*15 SATA ODD

2

2

3

Q29
*ME2N7002E

+3V

ME2N7002E
Q280

3

ODD_PLUGIN# 5

ODD_DA#_FCH 5

C

1

1

ZERO_ODD_DA#

ZERO_ODD_DP#
SATA_RXP15_C

SATA_RXN15_C
SATA_TXN15_C

SATA_TXP15_C

+5V_ODD

C283 *0.01U/50V_4
C276 *0.01U/50V_4

C279 *0.01U/50V_4
C278 *0.01U/50V_4

D

SATA_RXP1
SATA_RXN1

SATA_TXN1
SATA_TXP1

ODD_PWR5

+5V

High : ODD power on
Low : ODD power down

R276
1M/F_4

SI to 5%

R281 10K/F_4

3

2

ME2N7002E
Q14

1

Size Document Number R ev

Size Document Number R ev

Size Document Number R ev
Custom

Custom

Custom

NB5

NB5

NB5

Date: Sheet of

Date: Sheet of

Date: Sheet of

C305
1000P/50V_4

1

2

C306

3

0.022U/16V_4

2 1

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

HDD/ODD/TP/FAN/HOLE/LID

HDD/ODD/TP/FAN/HOLE/LID

HDD/ODD/TP/FAN/HOLE/LID

E

Q13
AO3413

R275
*0_8

+5V_ODD

1A

1A

27 43Friday, October 17, 2014

27 43Friday, October 17, 2014

27 43Friday, October 17, 2014

1A

5

KEYBOARD Con.

MY[0..17]30

MX[0..7]30

MUTE_LED_CNTL23

D D

CAPSLED#30

MUTE_LED_CNTL_R1

MY[0..17]
MX[0..7]

MUTE_LED_CNTL_R1

3

2

Q20

2N7002K

R334

1

10K/F_4

R330

12

200/F_6

+3V

R329 200/F_6

KB 14" & 15" KB 17"

MX1
MX7
MX6
MY9
MX4
MX5
MY0
MX2
MX3
MY5
MY1
MX0
MY2
MY4
MY7
MY8
MY6
MY3
MY12
MY13
MY14
MY11
MY10
MY15
MY16
MY17

CAPSLED#_R
MUTE_LED_CNTL_R

12

WIRELESS_ON_R
WIRELESS_OFF_R
LED_PW

32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10

9
8
7
6
5
4
3
2
1

KB CONN

32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1

4

333334

KB14

51586-03241-001-32p-l

34

DFFC32FR043

MX1
MX7
MX6
MY9
MX4
MX5
MY0
MX2
MX3
MY5
MY1
MX0
MY2
MY4
MY7
MY8
MY6
MY3
MY12
MY13
MY14
MY11
MY10
MY15

MY17

CAPSLED#_R
MUTE_LED_CNTL_R
WIRELESS_ON_R
WIRELESS_OFF_R
LED_PW

32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10

9
8
7
6
5
4
3
2
1

*KB CONN

32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1

333334

KB17

51586-03241-001-32p-l

34

DFFC32FR043

3

KEYBOARD PULL-UP

+3VPCU

+3VPCU

10

MY14
MY11
MY10
MY15MY16

10

MY8
MY5
MY0
MY9

R322 *8.2K_4
R324 *8.2K_4

9
8
7 4

9
8
7 4

+3VPCU

RP7

*10P8R-8.2K
RP6

*10P8R-8.2K

2

MY5

C384 220P/50V_4

MY6

C406 220P/50V_4

MY3

C407 220P/50V_4

MY7

C402 220P/50V_4

MY8

C404 220P/50V_4

MY9

C351 220P/50V_4

MY10

C364 220P/50V_4

MY11

C4230 220P/50V_4

MY1

C386 220P/50V_4

MY2

C397 220P/50V_4

MY4

C401 220P/50V_4

MY0

C362 220P/50V_4

MX4

1

MY3

2

MY6

3

MY12
MY13

56

1

MY7

2

MY4

3

MY2
MY1

56

MY16
MY17

C355 220P/50V_4

MX6

C347 220P/50V_4

MX3

C382 220P/50V_4

MX2

C371 220P/50V_4

MX7

C3450 220P/50V_4

MX0

C3870 220P/50V_4

MX5

C3580 220P/50V_4

MX1

C3420 220P/50V_4

MY12

C409 220P/50V_4

MY13

C42010 220P/50V_4

MY14

C4220 220P/50V_4

MY15

C427 220P/50V_4

MY16

C436 220P/50V_4

MY17

C442 220P/50V_4

WIRELESS_OFF30

WIRELESS_ON30

R283 *200/F_6

R292 *200/F_6

1

+5V

R2960

24

*1K/F_4

12

2

Q16
*DRC5144E0L

1 3

12

2

Q15
*DRC5144E0L

1 3

+5V

WIRELESS_OFF_R

R291
*1K/F_4

WIRELESS_ON_R

USB 2.0/3.0 Combo

C C

USB30_RX3-

C343 *Clamp-Diode

1 2

USB30_RX3+

C333 *Clamp-Diode

1 2

B B

USBP7-_C

USBP7+_C

USB30_3-

USB30_3+

C346 *Clamp-Diode

1 2

C349 *Clamp-Diode

1 2

C357 *Clamp-Diode

1 2

C352 *Clamp-Diode

1 2

EMI: if charger IC no use, pop this choke

USBP7­USBP7+

USBP7-

USBP7-6

USBP7+

USBP7+6

USB30_RX3-6
USB30_RX3+6

USB30_TX3-6
USB30_TX3+6

*MCM2012B900GBE

4 3
1

L25

R521 0_4
R523 0_4

C341 0.1U/10V_4

C334 0.1U/10V_4

USBP7-_C

USBP7-_C
USBP7+_C

USBP7+_C

2

VC4 *AVLC 5S_4
C610 470P/50V_4

C611 0.1U/10V_4
C609 1000P/50V_4

+5V_USBP0
USBP7-_C
USBP7+_C

USB30_3­USB30_3+ +5V_USBP0

2.5A

CN15
USB3.0 CONN

1

VBUS

1

2

D-

2

3

D+

3

4

4

GND

5

SSRX-

5

6

6

SSRX+

7

7

GND

8

8

SSTX-

9

SSTX+

9

11111010131312

12

DFHS09FR597

UB3-TNBNRAC70047009-9P

C327
1U/6.3V_4

150 mils (Iout=3.7A)

U14

2

VIN1

OUT3

3

VIN2

OUT2

4

EN

OUT1

1

GND

OC

G547N2P81U

Active Low

8
7
6
5

+5VS5

USBPW_ON#23,30

VC2

*AVLC 5S_4

+5V_USBP0

+

C604 220U 6.3V_6.3*4.2

A A

+5VS523,32,33,34,35,36,38,40,41,43
+3VPCU4,7,23,27,30,31,32

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

NB5

NB5

NB5

Date: Sheet o f

Date: Sheet o f

5

4

3

2

Date: Sheet o f

USB 3.0/KB/TS

USB 3.0/KB/TS

USB 3.0/KB/TS

1

28 43Friday, October 17, 2014

28 43Friday, October 17, 2014

28 43Friday, October 17, 2014

1A

1A

1A

A

WLAN/BT

B

+3V_AOAC

C

D

+3V_AOAC

C510

C513

C511

0.1U/10V_4

C514

0.1U/10V_4

0.1U/10V_4

10U/6.3VS_6

E

+3V

25

CN7

NGFF

1

GND

4 4

PCIE_TXP0_WLAN2
PCIE_TXN0_WLAN2

PCIE_RXP0_WLAN2
PCIE_RXN0_WLAN2

CLK_WLAN_P6
CLK_WLAN_N6

PCIE_CLKREQ_WLAN#5

CLK_33M_DEBUG

3 3

R143
*33_4

C162
*10P/50V_4

CLK_33M_DEBUG6

USBP5+6

USBP5-6 RF_LINK# 30

R205 0_4

LFRAME#6,30

REQ_WLAN#

MINICAR_PME# INT_RF_OFF#

LFRAME#

3
5
7

9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
51
53
55
57
59
61
63
65
67
69
71
73
75

USB_D+
USB_D­GND
SDIO CLK(O)
SDIO CMDIO)
SDIO DAT0(IO)
SDIO DAT1(IO)
SDIO DAT2(IO)
SDIO DAT3(IO)
SDIO Wake(I)
SDIO Reset
KEY1
KEY2
KEY3
KEY4
GND
PETp0
PETn0
GND
PERp0
PERn0
GND
REFCLKP0
REFCLKN0
GND
CLKREQ0#
PEWake0#
GND
PETp1
PETn1
GND
PERp1
PERn1
GND
Reserved1
Reserved2
GND

SUSCLK(32KHz)

NFC I2C SM DATA

NFC I2C SM CLK

UIM_SWP/PERST1#

UIM_POWER_SNK
UIM_POWER_SRC

GND76GND

77

2

3.3Vaux

4

3.3Vaux

6

LED#1

8

PCM_CLK

10

PCM_SYNC

12

PCM_IN

14

PCM_OUT

16

LED#2

18

GND

20

UART Wake

22

UART Rx

24

Key 5

26

Key 6

28

Key 7

30

Key 8

32

UART Tx

34

UART CTS

36

UART RTS

38

Clink RESET

40

CLink DATA

42

CLink CLK

44

COEX3

46

COEX2

48

COEX1

50
52

PERST0#

54

W_DISABLE2#

56

W_DISABLE1#

58
60
62

ALERT#

64

RESERVED

66
68
70
72

3.3Vaux

74

3.3Vaux

WLAN_NGFF CONN (E-Key)

WLAN_LED#

INT_BT_OFF#

LAD0
LAD1
LAD2
LAD3

R239 4.7K_4
R244 0_4

PCIE_RST#_R1 5,13,23

LAD0 6,30
LAD1 6,30
LAD2 6,30
LAD3 6,30

+3V_AOAC

+3V_AOAC

R208
10K_4

R209
10K_4

INT_BT_OFF#

INT_RF_OFF#

Q17A 2N7002KDW

Dua l

3 4

5

2

6 1

Dua l

Q17B
2N7002KDW

BT_COMBO_OFF 5

RF_OFF 5

PCIE_WAKE#5,23

+3VSUS

Q2700
*DRC5144E0L

R457 *10K/F_4

2

13

MINICAR_PME#

FOR EMI

ACCEL_INTH#

C7036
*22P/50V_4

ACCEL_INTH#5

2 2

10U/6.3VS_6

THRMSEN_DATA
THRMSEN_CLK

+3V

MBDATA330

MBDATA3
MBCLK3

MBCLK330

+3V

C7035

0.1U/10V_4

TP7001

R7035 0_4

R7036 0_4 R19 0_4

MBDATA3

R7111 0_4
R7112 0_4

MBCLK3

TPM (2.0)

PN:AL009665K01

LAD0

R246 0_4

LAD1

R247 0_4

LAD2

R250 0_4

LAD3

LFRAME#

R251 0_4
R249 0_4

R248 0_4

KBC_RST#5,30

SERIRQ6,30

1 1

CLK_PCI_TPM6

LAD0_T
LAD1_T
LAD2_T
LAD3_T
CLK_PCI_TPM_R

LFRAME#_T

SERIRQ

A

U12

26

LAD0

23

LAD1

20

LAD2

17

LAD3

21

LCLK

22

LFRAME#

16

LRESET#

28

LPCPD#

27

SERIRQ

9

TEST/BADD

15

CLKRUN#

1

NC

3

NC

12

NC

*SLB9665 T2.0

THRMSEN_DATA
THRMSEN_CLK

VDD
VDD
VDD
VSB

GND
GND
GND
GND

GPIO

GPIO2

TESTI

XTALI/32K IN

XTALO

PP

U7002
HP3DC2TR

1

14

11

9
7

6
4

8

AL003DC2A00

10
19
24
5

4
11
18
25

6
2

7
8

13
14

Vdd_IO
VDD

INT1
INT2

SDO
SDA
SCL

CS

Dua l

Dua l

+3V

Accelerometer Sensor

2

NC

3

NC

10

RESERVED

13

RESERVED

15

RESERVED

16

RESERVED

5

GND

12

GND

Q7002A *2N7002KDW

3 4

R7041 4.7K_4

5
2

R7043 4.7K_4

6 1

Q7002B
*2N7002KDW

C307 0.1U/10V_4

C280

0.1U/10V_4

R277 4.7K_4

TPM_PP

C281

0.1U/10V_4

B

MBDATA3
MBCLK3

+3V

THRMSEN_DATA

THRMSEN_CLK

C308

0.1U/10V_4

+3V

C7039 *33P/50V_4
C7041 *33P/50V_4

+3V

TPM_PP

+3V

R279
*4.7K/F_4

R278
0_4

CLK_PCI_TPM

R225
*33_4

C272
*10P/50V_4

FOR EMI

C

Touch screen

USBP1-6

USBP1+6

TS_ON30

SI for Remove LDO

TS_ON

+3VS55,6,7,30,32,34,40,41,43

+3VPCU4,7,23,27,28,30,31,32

USBP1­USBP1+

Q36

+3V4,5,6,7,11,12,20,21,22,23,24,27,28,30,36,38,40

USBP1­USBP1+

TS_ON

2

R7095 0_4C7034
R7096 0_4

*MCM2012B900GBE

R520
*10K/F_4

R522 *220K_4

3

*ME2N7002E

1

L1

4 3
1

USBP1-_L
USBP1+_L

2

+3VS5+3VS5 +3V+TS

2

C632
*0.022U/16V_4

D

+TS

1

3

USBP1-_L
USBP1+_L

Q37
*ME2303-G

25mil

EC13 0.1U/10V_4

TS_ON_R

EC10
*100P/50V_4

R101 0_6

C633
*0.1U/10V_4

CN3

1
2
3
4
5
6

Touch screen 14

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

WLAN/G-Sensor/GCLK/TPM

WLAN/G-Sensor/GCLK/TPM

NB5

NB5

NB5

WLAN/G-Sensor/GCLK/TPM

Date: Sheet o f

Date: Sheet o f

Date: Sheet

E

1A

1A

1A

of

29 43Friday, October 17, 2014

29 43Friday, October 17, 2014

29 43Friday, October 17, 2014

1

2

3

4

5

6

7

8

+3V4,5,6,7,11,12,20,21,22,23,24,27,28,29,36,38,40

+3VPCU4,7,23,27,28,31,32

A A

U5001

5VS5_ON

C5031
*4.7U/6.3V_4

3

10

12
13
38

20

37
55

56
57
58
59
60
61
62

39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
81
82

83
84
85
86
87
88

119
120
128

89

76
109
110
112
114
115
116
117
118

97

98

99
100
101
102
103
104
105
106
107
108

124

3
4

8
7
5

1
2

KB9028QF C

*22p/50V_4

SERIRQ
LFRAME
LAD0
LAD1
LAD2
LAD3
PCICLK
PCIRST/GPIO5
CLKRUN

SCI/GPIOE
GA20/GPIO0
KBRST/GPIO1
ECRST

KSI0/GPIO30
KSI1/GPIO31
KSI2/GPIO32
KSI3/GPIO33
KSI4/GPIO34
KSI5/GPIO35
KSI6/GPIO36
KSI7/GPIO37

KSO0/GPIO20
KSO1/GPIO21
KSO2/GPIO22
KSO3/GPIO23
KSO4/GPIO24
KSO5/GPIO25
KSO6/GPIO26
KSO7/GPIO27
KSO8/GPIO28
KSO9/GPIO29
KSO10/GPIO2A
KSO11/GPIO2B
KSO12/GPIO2C
KSO13/GPIO2D
KSO14/GPIO2E
KSO15/GPIO2F
KSO16/GPIO48
KSO17/GPIO49

PSCLK1/GPIO4A
PSDAT1/GPIO4B
PSCLK2/GPIO4C
PSDAT2/GPIO4D
PSCLK3/GPIO4E
PSDAT3/GPIO4F

RD/GPIO5B
WR/GPIO5C
SPICS/GPIO5A
SELIO/GPIO50
AD5/GPIO43
D0/GPXD0
D1/GPXD1
D2/GPXD2
D3/GPXD3
D4/GPXD4
D5/GPXD5
D6/GPXD6
D7/GPXD7

A0/GPXA0
A1/GPXA1
A2/GPXA2
A3/GPXA3
A4/GPXA4
A5/GPXA5
A6/GPXA6
A7/GPXA7
A8/GPXA8
A9/GPXA9
A10/GPXA10
A11/GPXA11

VCC_IO2

CRY2

C5033

AD0/GPI38
AD1/GPI39
AD2/GPI3A
AD3/GPI3B

DA0/GPO3C
DA1/GPO3D
DA2/GPO3E
DA3/GPO3F

PWM1/GPIOF

PWM2/GPIO10

FANPWM1/GPIO12
FANPWM2/GPIO13

FANFB1/GPIO14
FANFB2/GPIO15

SCL1/GPIO44
SDA1/GPIO45
SCL2/GPIO46
SDA2/GPIO47

AD6/CIR_RX/GPIO40

AD7/GPIO41
AD4/GPIO42

R5031 *0_4

R5034
*100K/F_4

LAD06,29
LAD16,29
LAD26,29
LAD36,29

MX028
MX128
MX228
MX328
MX428
MX528
MX628
MX728

MY028
MY128
MY228
MY328
MY428
MY528
MY628
MY728
MY828

MY928
MY1028
MY1128
MY1228
MY1328
MY1428
MY1528
MY1628
MY1728

DGPU_PR_EN

AC_LED_ON#

SERIRQ
LFRAME#
LAD0
LAD1
LAD2
LAD3

CLK_33M_KBC
KBC_RST#

CLKRUN#
SIO_EXT_SCI#

EC_A20GATE
EC_RCIN#
3920_RST#

MX0
MX1
MX2
MX3
MX4
MX5
MX6
MX7

MY0
MY1
MY2
MY3
MY4
MY5
MY6
MY7
MY8
MY9
MY10
MY11
MY12
MY13
MY14
MY15
MY16
MY17

GPUT_CLK
GPUT_DATA

MBCLK3
MBDATA3
TPCLK
TPDATA

BIOS_RD#
BIOS_WR#
BIOS_CS#
BIOS_WP#_R

S5_ON

R5025 0_4

MBATLED0#
WIRELESS_ON

WIRELESS_OFF

C5030

0.1U/10V_4

PWR_LED#

C421

0.1U/10V_4

R50200_4

R50220_4

SERIRQ6,29

LFRAME#6,29

POP for CZ

+3VS5

R7073

2

10K/F_4

Q7003A

34

5

R7069 0_4

2N7002KDW

POP for CZ-L

Dua l

+3V

R7063 10K/F_4
R7064 10K/F_4

POP for CZ

close to EC

ACIN

VC5001

*AVLC 5S_4 C5028

THRM_MONITOR1

C5029

0.1U/10V_4

1 2

DEEP_PWRLED#23,27

BIOS_WP#_R

EC_A20GATE
EC_RCIN#

For GPU thermal
For G-sensor

PCI_SERR#5

DGPU_PWROK5,41,43

DGPU_PR_EN5,41,43

USBPW_ON#23,28

SPI_1.8V_ON40

THRM_MONITOR14

DEEP_PWRLED#

2

RF_LINK#29

SUSON33,40

MAINON33,35,40

WIRELESS_ON28
WIRELESS_OFF28

BIOS_WP#

Q7003B

61

2N7002KDW

B B

C C

D D

Dua l

1

ACIN31

S5_ON32,34,35

AC_LED_ON#31

+3VPCU

5VS5_ON32

MBATLED0#31

+1.8V_ROM

+3VPCU

R317
10K/F_4

1 3

CLK_33M_KBC6

GPUT_CLK14
GPUT_DATA14

MBCLK329

MBDATA329

TPCLK27

TPDATA27

2

Q18
METR5213-G

KBC_RST#5,29

CLKRUN#6

SIO_EXT_SCI#5

EC_A20GATE5

EC_RCIN#5

ACIN

USBPW_ON#
SUSON

MAINON

HW_ALERT#

R7057 0_4
R7058 *0_4

CZ: 1.8V
CZ-L: 3.3V

+3VPCU

9

VCCLPC

22

VCC2

33

VCC3

96

VCC4

111

VCC5

125

VCC6

67

AVCC

TEMP_MBAT

63

AD_TYPE

64

AD_AIR

65

SYS_I

66

LAN_POWER

68
70
71
72

21
23

26

R5013 0_4

27
28

FAN1SIG
TS_ON

29
77

MBCLK

78

MBDATA

79

MBCLK2

80

MBDATA2

6

GPIO4
GPIO7

GPIO8

GPIOA
GPIOB
GPIOC

GPIOD
GPIO11
GPIO16
GPIO17
GPIO18

GPIO19
GPIO1A

GPIO52
GPIO53
GPIO54
GPIO55
GPIO56
GPIO57
GPIO58
GPIO59

GPIO5E

GPIO5D

GND1
GND2
GND3
GND4
GND5
AGND

SUSB#

14

H_PROCHOT#_EC

15
16

SUSC#

17
18
19

NBSWON1#

25
30
31

SIO_EXT_SMI#

32
34

VRON

36

73
74
75

GPIO42

90

DNBSWON#

91

CAPSLED#

PWR_LED#

92
93

ECPWROK

95

RSMRST#

121

BIOS_SPI_CLK

126
127

123

122

11
24
35
94
113
69

SI Add 0ohm need to fine tune with ENE

4

500mA

C5003 0.1u/10V_4
C5004 0.1u/10V_4
C5005 0.1u/10V_4
C5006 0.1u/10V_4
C5007 0.1u/10V_4
C5008 0.1u/10V_4
C5011 0.1u/10V_4
C5009 0.1u/10V_4
C5012 0.1u/10V_4

C5013 0.1u/10V_4

GPU_AC_BATT
BATSHIP

KB_LED_EN

HWPG

EMU_LID

EC_DEBUG1
LID_EC#

APU_S5_ON

VGA_ON_SB
APU_S5_ON

CRY2

CRY1

R5027 0_6

RTC_CLK 5,6

4.7U/6.3V_4

+3VPCU_EC

+3VS5

C5002

L5001 BLM15BB470SN1D

TEMP_MBAT 31
AD_AIR 31

SYS_I 31

LAN_POWER 40

GPU_AC_BATT 14

BATSHIP 31

KB_LED_EN 27

FAN_PWM 27

FAN1SIG 27

TS_ON 29

MBCLK 31
MBDATA 31
MBCLK2 4,12,20
MBDATA2 4,12,20

SUSB# 5

HWPG 32,33,34,35

SUSC# 5
VOLMUTE# 23,24

remove AOAC pin

TP7011

NBSWON1# 23

EMU_LID 21

TP7012

LID_EC# 23

SIO_EXT_SMI# 5

VRON 36,38

R525 100K/F_4

VGA_ON_SB 5
APU_S5_ON 34,35

DNBSWON# 5
CAPSLED# 28

ECPWROK 5

TP7008

C5010
*220P/50V_4

500mA

+3VPCU+3VPCU_EC

for Battery
charge/disch arge

for CPU themal/DDR
thermal/LVD S
conve rter

R5008 *4.7K_4
R5009 *4.7K_4

5

MBCLK2
MBDATA2

Q5002
METR3904-G

2

1 3

SYS_SHDN-1#

THERMTRIP#

DGPU Thermal protect

Reserve for ENE hold time issue

H_PROCHOT#_EC

3920_RST#

D5001 RB500V-40

MBCLK2
MBDATA2

GPUT_CLK
GPUT_DATA

MBCLK
MBDATA

0.1U/25V_4

the resistor of WP# path, don't change to short pad

BIOS_RD#
BIOS_WR#
BIOS_CS#

BIOS_SPI_CLK

ECPWROK

R5002 10K/F_4

3

Q5003 *2N7002K

DGPU_PWROK

2

D5002 RB500V-40

TEMP_FAIL14

C5019 *10P/50V_4
C5020 *10P/50V_4
C5021 *10P/50V_4
C5022 *10P/50V_4R7070 *0_4
C5023 *10P/50V_4
C5024 *10P/50V_4

2

R5016
*10K/F_4

BATT+ BATT+

EC5002

R5028 0_4
R5029 0_4
R5030 0_4
R5032 0_4
R5033 0_4

6

1

H_PROCHOT#

3

2N7002K

1

HW_ALERT#

Q5004

EC5001

0.1U/25V_4

+3V

DGPU_OVT# 14

3920_RST#

3

Q5001

2

*2N7002K

1

C5026
*47P/50V_4

BATT+31

EC_BIOS_RD#
EC_BIOS_WR#

EC_BIOS_CS#

EC_SPI_WP_RBIOS_WP#

EC_BIOS_SPI_CLK_I

C5032 *22P/50V_4

H_PROCHOT# 4

7

EC50030.1U/10V_4

HW_ALERT#

NBSWON1#
MBCLK
MBDATA

LID_EC#

RSMRST#

C5014 2.2U/6.3V_4

3920_RST#

C5015 0.1U/10V_4

R5012 *33_4

+3VPCU

+3VS5

+3VPCU

R5003 10K/F_4
R5004 10K/F_4
R5005 4.7K_4
R5006 4.7K_4

R5007 47K/F_4

R5010 *8.2K_4

R5011 47K/F_4

C5016 *15P/50V_4

C5017 0.1U/10V_4

HWPG

C5018 *0.1U/10V_4

FAN1SIG

C5001 *0.1U/10V_4

DGPU_PR_EN

For +VIN noise

C5025 100P/50V_4

SERIRQ

Smart adapter Type check

+3VPCU

Change to 1SS355 as Current loss

D5003
*1SS355

AD_TYPE

R5017 2K/F_4

D5004

PDZ5.6B

2 1

Adapter select

R5023 10K/F_4

+3VPCU

EC_BIOS_RD# 6

EC_BIOS_WR# 6

EC_BIOS_CS# 6

EC_SPI_WP_R 6

EC_BIOS_SPI_CLK_I 6

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

NB5

NB5

NB5

Date: Sheet o f

Date: Sheet o f

Date: Sheet o f

2 1

R5018 100/F_4

C5027

R5019

12.1K/F_4

0.1U/10V_4

GPIO42

R5024 *10K/F_4

GPIO 42
High ==> DIS.
Low ==> UMA

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

EC (KB9028QF C)/ROM

EC (KB9028QF C)/ROM

EC (KB9028QF C)/ROM

100P/50V_4

adapter

8

30

RSMRST# 5

CLK_33M_KBC

65W
45W

30 43Friday, October 17, 2014

30 43Friday, October 17, 2014

30 43Friday, October 17, 2014

AD_ID 31

1A

1A

1A

5

EC1

1000P/50V_4

DC_JACK
90W

D D

LED2
LED1

PC16

*0.1U/25V_4

C C

PC23

*0.1U/25V_4

B B

A A

6

CN6

AD_ID

5

GND

7

ALED0

8

WLED1

DC-IN CONN

+5VPCU

+5VPCU

+3VPCU 4,7,23,27,28,30,32
+5VPCU 32
BATT+ 30
+PRWSRC

VDD
VDD

GND
GND
GND
GND

1 3

1 3

1
2

3
4
9
10

PR11

2.43K/F_6

PR17

2.43K/F_6

5

AD_ID 30

+VA_AC

2

PQ5
METR5213-G

2

PQ8
METR5213-G

PL2
*0_8/S

PL4
*0_8/S

PC1

0.1U/25V_4

+VAD

PR12
220K_4
PR15

220K_4

AC_LED_ON# 30

MBATLED0# 30

+VA

PQ2
EMB20P03V

6
7
8

PC5

0.1U/25V_4

PQ4

4

Q2

2 1

Q1

MMDT2907A

AD_AIR30

PC35

0.1U/10V_4

Place this cap

close to EC

4

PR8

3

IDEA_G

1M_4

65

PR16

1K_6

Place this ZVS close to
Diode away +VIN

PD1

15
2
3

P4SMAJ20A

PC6

0.1U/25V_4

+VA

1N4448WS-7-F

PR39
75K/F_4

PR41

12.4K/F_4

4

Do Not add test pad on BATDIS_G signal

PQ3
AP0203GMT-HF

+VAD

PD7

21

PR6
1M_4

+VAD

PR25

22_8

+VA+VA_AIR

21

4

D

5

PC7
2200P/50V_4

BATDIS_G

PC28

0.47U/25V_6

+PRWSRC

3

S

2
1

G

PC8

4

0.1U/50V_6

PR13

4.02K/F_4

REGN6V

ACIN30

MBDATA BQDATA

MBCLK BQCLK

+VAD

ACDET=13V

MIN. BATV=7.2V

PR37
1M_4

PR40

+VA_AIR

750K/F_4

PR42
127K/F_4

PR38
1M_4

PR14

4.02K/F_4

BQCMSRC

BQACDRV

PR19

100K/F_4

PR22

100K/F_4

PR26

0_4/P
PR29

0_4/P

2

PR30

430K/F_4

PR31

69.8K/F_4

1 3

+PRWSRC

ACIN

BQVCC

3

2

1

PQ11

METR3904-G

PC19

0.1U/25V_4

3

CMSRC

4

ACDRV

5

ACPRES

20

VCC

8

SDA

9

SCL

PR32

88.7K/F_4

PQ9
2N7002K

3

EC3

*1U/25V_4

PR4

RC1206-R010

CSIP

PC20

BQACP

2

0.1U/25V_4

ACP

EC4

*1U/25V_4

21

PR10
*0_2/S

CSINBQACN

REGN6V

PC18

1

0.1U/25V_4

ACN

EC2

*1U/25V_4

PR9
*0_2/S

PU1

BQ24728H

ACDET

ILIM

6

10

PR34

PR33

PC34

100K/F_4

43.2K/F_4

+3VPCU

*0.1U/50V_6

Set MAX charge I to 5A

3

EC5

*1U/25V_4

16

REGN

IOUT

BQIOUT

7

PC21

1U/25V_4

HIDRV

BTST

PHASE

LODRV

GND
GND
GND
GND
GND
GND

SRP
SRN

BATDRV

PR35
10/F_4

PC32

100P/50V_4

Place this cap

close to EC

BQBATDRV

Place this ZVS close to
Far-Far away +VIN

18

BQHIDRV

PR18

BQB_2

0_6

BQPHASE

BQLODRV

BQSRP
BQSRN
BQBATDRV

SYS_I 30

PC33

0.01U/50V_4

BQB_1

PR27 10/F_6
PR28 5.6/F_6

17

19

15

14
21
22
23
24
25

13
12
11

EMB20N03V

21

PD5 RB501V-40

PC22

0.047U/25V_4

EMB20N03V

0.1U/25V_4

0.1U/25V_4

PR1

4.02K/F_4

PQ6

REGN6V

PQ7

PC29

PC31

2

BATT+

B_TEMP_MBAT

15"

PC4

0.1U/25V_4

PR2
330_4

PD3

PDZ5.6B

2 1

2 1

PC15

*100P/50V_4

EC9

*10U/25V_8

PR20
RC1206-R010

F3_2X1_65-2_8

1 2

PR24
*0_2/S

17"

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v
Custom

Custom

Custom

Charger (BQ24728H)

Charger (BQ24728H)

Charger (BQ24728H)

Date: Sheet of

Date: Sheet of

Date: Sheet of

+VIN

G

PC12

4

2

3

S

2
1

0.01U/50V_4

2200P/50V_4

EC7

*10U/25V_8

+BATCHG

3

1

PC2

PC13

PL5

PR36
470_8

PQ10
2N7002K

+BATCHG

PC14

1000P/50V_4

EC8

PC3

*10U/25V_8

CSOP
CSON

0.1U/25V_4

MBDATA30

MBCLK30

0.1U/25V_4

BQLR

NB5

NB5

NB5

PL1
*0_8/S

PL3
*0_8/S

PR23

*0_2/S

PQ1
TPCA8064-H

D

5

BATDIS_ID_DOD

PD2

2 1

*P4SMAJ20A

PC11

4.7U/25V_8

678

EC6

*10U/25V_8

35241

4.7uH/5.5A(PCMC063T-4R7MN)

678

PR21
*2.2_6

PC27
*2200P/50V_4

35241

PC30

0.1U/25V_4

BATSHIP30

2

*PMPCRS-08MLBK2ZZ4H0

SMD
SMC

BATT+
SMD

SMC

+3VPCU

PR3
330_4

PR5
200K_4

PD4

PDZ5.6B

PC17

*100P/50V_4

PC24

10U/25V_8

*196369-20041-3

10
11
12
13
14
15
16
17
18
19
20

1

BAT15

1

1

2

2

3

3

4

4

5

5

6

6

7

7

10

8

8

B_TEMP_MBAT

PR7
1K/F_4

PC9

PC25

10U/25V_8

BAT17

1
2
3
4
5
6
7
8
9

1

4S1 P

10
9

9

PMPCRR-08MLBK2ZZ4H0

14"

PC10

0.01U/50V_4

0.01U/50V_4

Place this cap

close to EC

+BATCHG

PC26

0.1U/25V_4

B_TEMP_MBAT

31 43Friday, October 17, 2014

31 43Friday, October 17, 2014

31 43Friday, October 17, 2014

31

BAT14

1

1

2

2

3

3

4

4

5

5

6

6

7

10

7

10

8

9

8

9

TEMP_MBAT 30

PD6

2 1

RB501V-40

SMC
SMDSMD

BATT+

1A

1A

1A

5

4

3

2

1

DC/DC +3VS5/+5VS5

30

+3VS5 5,6,7,29,30,34,40,41,43

+3VPCU

D D

PC36

4.7U/6.3V_6

PR43 10K/F_4

+3VS5

2

PQ12

SY8208CEN

1 3

HWPG

S5_ON

+VIN

PR45 0_4/P

PR47 0_4/P

PR49
1M_4

PR50 499K/F_4

HWPG30,33,34,35

S5_ON30,32,34,35

+3VPCU

PD8
UDZVTE-173.6B

PR52

4.99K/F_4

PR54

4.02K/F_4

2 1

METR3904-G

C C

SY8208BPG

SY8208BEN

SY8208BLDOEN

PC49
*0.1U/10V_4

PR53
150K/F_4

5

2

1

7

PU2

LDO

PGOOD

EN1

EN2

RT7238B

GND

BST

SW

VOUT

VIN

FB

8

9

6

SY8208BST

10

SY8208BSW

4

SY8208BVOUT

3

SY8208BFB

PR44

PC37

0_6

0.1U/25V_4

PR51
1K/F_4

SY8208BBST_S

PC38

4.7U/25V_8

PC39

PC42

0.1U/25V_4

+VIN_3VS5

4.7U/25V_8

PC40

PR46
*2.2_6

PC50
*2200P/50V_4

+VIN

PL6
*0_8/S

2200P/50V_4

2.2uH/8A(PCMC063T-2R2MN)

PC51

0.01U/50V_4

PC41

PL7

+3.3 Volt +/- 5%
T

DC:8A

EDP:9A

+3VS5

0.1U/25V_4

PR48
*0_2/S

PC43

22U/6.3V_8

+3.3VS5_S

PC47

PJP1
*POWER_JP/S

1 2

PC45

PC46

0.1U/10V_4

*22U/6.3V_8

PC44

22U/6.3V_8

22U/6.3V_8

+5VS5 23,28,33,34,35,36,38,40,41,43

Reserve

PC54

4.7U/25V_8

+VIN_5VS5

PC55

PC56

4.7U/25V_8

PC58

0.1U/25V_4

2200P/50V_4

PR58
*2.2_6 PC59

PC65
*2200P/50V_4PR61

+5VPCU

PC52

B B

HWPG SY8208CPG

Reserve for USB Charge

5VS5_ON30

S5_ON30,32,34,35

USB Charge support

Vine (No support)

Envy (Support)

A A

S5_ON

PR57

1K/F_4

PR59

*1K/F_4

RbRa

NAStuff

StuffNA

4.7U/6.3V_6

PR56 0_4/P

Rb

Ra

1M_4

2.2U/6.3V_6

PC68

SY8208CEN

PC66
*0.1U/10V_4

7

2

1

5

PU3

LDO

PGOOD

EN

VCC

RT7238C

GND

BST

SW

VOUT

VIN

FB

8

9

6

SY8208CBST

10

SY8208CSW

4

SY8208CVOUT

3

SY8208CFB

PR55

0_6

PC53

0.1U/25V_4

SY8208CBST_S

PR62
1K/F_4

+VIN

PL8
*0_8/S

2.2uH/8A(PCMC063T-2R2MN)

PC67
6800P/50V_4

PC57

0.1U/25V_4

PL9

PR60
*0_2/S

+5VS5_S

22U/6.3V_8

PC60

+5 Volt +/- 5%
TDC:8A
EDP:9A

+5VS5

PJP2
*POWER_JP/S

1 2

PC61

22U/6.3V_8

22U/6.3V_8

PC62

PC63

0.1U/10V_4

*22U/6.3V_8

Do Not add test pad on VCC & LDO pin

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v
Custom

Custom

Custom

NB5

NB5

NB5

Date: Sheet of

Date: Sheet of

5

4

3

2

Date: Sheet of

3/5VPCU(SY8208B/SY8208C)

3/5VPCU(SY8208B/SY8208C)

3/5VPCU(SY8208B/SY8208C)

1

32 43Friday, October 17, 2014

32 43Friday, October 17, 2014

32 43Friday, October 17, 2014

1A

1A

1A

1

2

3

4

5

31

HWPG30,32,34,35

A A

( 3mA )

B B

DDR_VTTREF11,12

SUSON30,40

MAINON30,35,40

+0.75V_DDR_VTT

PR69

100/F_4

PC78

0.1U/10V_4

PR63

0_4/P

PR64

0_4/P

PR66

0_4/P

+0.65V_DDR_VTT

PC76
10U/6.3V_6

PC81

0.033U/10V_4

+1.35VSUS

PC69
*0.1U/10V_4

PC70
*0.1U/10V_4

20

19

PC86

*10U/6.3V_6

+5VS5

2

1

4

VTT
VTTSNS

VTTGND

VTTREF
VLDOIN

PR72
*0_2/S
PR73
*0_2/S

1P35V_S5

1P35V_S3

7

RT8231BGQW

LPMB

3

11

PR65
301K/F_4

1P35V_TON

1P35V_CS

1P35V_PGOOD

10

13

9

S58S3

CS

TON

PGOOD

PU4

PGND

VID

14

1P35V_VID

6

FB

1P35V_FB

PR75
10K/F_4

PAD

VDDQ

5

21

1P35V_VDDQ

PR74

10.2K/F_4

UGATE

BOOT1

PHASE

LGATE

VDD

PR67

620K/F_4

1P35V_UGATE

17

1P35V_BOOT

18

1P35V_PHASE

16

1P35V_LGATE

15

1P35V_VDD

12

PC87
1U/6.3V_4

VO=(0.675(R1+R2)/R2)

PR68

2.2_6

+5VS5

PC77

0.1U/25V_4

PQ13

EMB20N03V

35241

PQ14

MDV1595SURH

35241

Rds(on) 14m ohm

PC74

PC73

PC72

PC71

678

4.7U/25V_8

4.7U/25V_8

0.1U/25V_4

PL11

1uH/11A(PCMC063T-1R0MN)

678

PR70
*2.2_6 PR71

PC88
*2200P/50V_4

2200P/50V_4

PL10
*0_8/S

+VIN+VIN_DDR

PC75

+1.35V +/- 5%
Countinue current:6A
Peak current:8A
OCP minimum:12A

0.1U/25V_4

+1.35VSUS_S

*0_2/S

PC82

+1.35VSUS

PJP3
*POWER_JP/S

1 2

PC79

PC83

0.1U/10V_4

22U/6.3V_8

PC84

22U/6.3V_8

*22U/6.3V_8

PC85

12

+

PC80

*22U/6.3V_8

*390U/2.5V_5X5.8ESR10

C C

D D

1

2

3

4

+1.35VSUS 3,7,11,12

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v

DDR3 (RT8231B)/1.8VS5

DDR3 (RT8231B)/1.8VS5

DDR3 (RT8231B)/1.8VS5

NB5

NB5

NB5

Date: Sheet of

Friday, October 17, 2014

Date: Sheet of

Friday, October 17, 2014

Date: Sheet of

Friday, October 17, 2014

5

1A

1A

1A

33 43

33 43

33 43

5

4

3

2

1

34

D D

PR76

+3VS5 +3VS5

*0_6/S

PC89

4.7U/6.3V_4

4

PU5

PC91

*0.1U/10V_4

5

PG

1

EN

APW8824

R2

HWPG30,32,33,35

S5_ON

APU_S5_ON

C C

PR81 0_4/P

PR84 *0_4/P

PR341 0_4/P

3

LX

GND

PR89
10K/F_4

2

8008LX1.5VHWPG

R1

PR87

15K/F_4

VIN

FB

6

8008VFB1.5V 8002VFB0.95VS5

PL12

1uH/2.6A_2520

PR82
*0_2/S

VO=(0.6(R1+R2)/R2)

+1.5V +/- 5%
TDC:1A
EDP:2A

+1.5VS5 +0.95VS5

+1.5VS5_SRC +0.95VS5_SRC

PC92

PR78
*POWER_JP/S

1 2

PC93

10U/6.3V_6

PC329

0.1U/10V_4

10U/6.3V_6

S5_ON30,32,35

APU_S5_ON30,35

PR80 0_4/P

S5_ON

PR85

*0_4/P

PR86

0_4/P

S5_ON

PC96

*0.1U/10V_4

PR77
*0_6/S

PU6

5

PG

1

EN

APW8824

PC90

4

VIN

LX

GND

FB

6

PR90

15.4K/F_4

R2

VO=(0.6(R1+R2)/R2)

4.7U/6.3V_6

3

8002LX0.95VS5HWPG

2

R1

PR88

9.1K/F_4

PL13

1uH/2.6A_2520

+0.95VS5 +/- 5%
TDC:1A
EDP:2A

PR83
*0_2/S

PC94

PR79
*POWER_JP/S

1 2

PC95

10U/6.3V_6

PC330

0.1U/10V_4

10U/6.3V_6

APU_S5_ON

+0.775 Volt +/- 5%
TDC:1A

PC101

0.1U/10V_4

+0.775VS5

1 2

PR91
*POWER_JP/S

+VIN 21,25,27,31,32,33,35,37,39,40,41,42
+3VS5 5,6,7,29,30,32,40,41,43
+5VS5 23,28,32,33,35,36,38,40,41,43
+5VPCU 31,32

+0.95VS5

PQ15

EMB32N03K

6

DRV

5
2
1

PC98

3

4.7U/6.3V_6

6

9334DRV

9334ADJ

PR95

5

ADJ

B B

PC97

0.1U/10V_4

PU7

PC104

0.1U/10V_4

3
4

1

G9336

PGD
EN

VCC

GND

2

HWPG

S5_ON
APU_S5_ON

A A

PR93 0_4/P
PR92 *0_4/P
PR342 0_4/P

PC103

9334EN

+5VS5

*0.1U/10V_4

+0.775VS5_SRC

4

PC99

10U/6.3V_6

PC102

PR94

47/F_4

0.033U/25V_4

54.9/F_4
PR96

100/F_4

Vout1=(1+R1/R2)*0.5

PC100

*10U/6.3V_6

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v
Custom

Custom

Custom

+1.1VS5 (RT8228)/2.5V

+1.1VS5 (RT8228)/2.5V

NB5

NB5

5

4

3

2

NB5

+1.1VS5 (RT8228)/2.5V

Date: Sheet of

Date: Sheet of

Date: Sheet of

1

34 43Friday, October 17, 2014

34 43Friday, October 17, 2014

34 43Friday, October 17, 2014

1A

1A

1A

5

4

3

2

1

35

PR97

D D

+5VS5

PC110
1U/6.3V_4

HWPG

HWPG30,32,33,34

MAINON30,33,40

C C

PR100 0_4/P

PR102 *0_2/S

PR104 0_4/P

1237PFMPCH

1237ENPCH

PC119
*0.1U/10V_4

PR98

*0_4

1237PGPCH

1237SSPCH

PC120

0.1U/10V_4

PU8

7

NC

21

VCC

1

PGOOD

3

PFM

2

EN

23

SS

AOZ1267QI-02

100K/F_4

6

8

IN

9

TON

IN

22

BST

PGND
PGND
PGND
PGND
PGND
AGND

LX
LX
LX
LX
LX

FB

IN

20

1237BSTPCH

10

1237LX

11
16
17
18

12
13
14
15
19
4

5

1237FBPCH

PR99

0_6

PR105

1.91K/F_4

PR106
10K/F_4

PC105

0.1U/25V_4

PC106

1237BSTPCH_S

1237FBPCH_S

+VIN_0.95V +VIN

PC108

PC107

4.7U/25V_8

4.7U/25V_8
PC111

0.1U/25V_4

2200P/50V_4

1uH/11A (PCMC063T-1R0MN)

PR101
*2.2_6

PC118
*2200P/50V_4

Vout1=(1+R1/R2)*0.8

PL14
*0_8/S

PL15

PC109

0.1U/25V_4

PR103
*0_2/S

+0.95V_S2

+0.95V Volt +/- 5%

TDC:8A
EDP:12A

PC112

PC113

PC114

0.1U/10V_4

22U/6.3V_8

22U/6.3V_8

+0.95V

1 2

PJP4
*POWER_JP/S

PC115

*22U/6.3V_8

PC116

*22U/6.3V_8

+

PC117

*220u/2V_7343

1.8VS5 +/- 3%
TDC:3A

B B

PC121

PR107

*2200P/50V_4

PR109

0_4/P

554PG_1.8V

554PVIN_1.8V

PC129

1U/6.3V_4

HWPG

PJP5

*POWER_JP/S

PC127

0.01U/50V_4

12

PR112

10_6

PC128

10U/6.3V_6

+5VS5

A A

5

PU9

4

PG

9

PVIN

10

PVIN

RT8068AZQW

8

SVIN

11

GND

*2.2_6

554LX_1.8V

1

NC

2

LX

3

LX

554NC_1.8V

7

NC

554FB_1.8V554SVIN_1.8V

6

FB

554EN_1.8V

5

EN

PC130

0.1U/10V_4

4

PL16

*22P/50V_4

PC126

*68P/50V_4

PR113

10K/F_4

PR115

*10K/F_4

1uH/11A (PCMC063T-1R0MN)

554FB_1.8V_S

PC122

R1

R2

PR111

20K/F_4

PR114

10K/F_4

S5_ON 30,32,34

APU_S5_ON 30,34

+1.8VS5_S2

PR110
*0_2/S

PC123

V0=0.6*(R1+R2)/R2

3

EDP:4A

+1.8VS5

PC124

PC125

0.1U/10V_4

10U/6.3V_6

*22U/6.3V_8

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v
Custom

Custom

Custom

+1.1VS5 (RT8228)/2.5V

+1.1VS5 (RT8228)/2.5V

NB5

NB5

2

NB5

+1.1VS5 (RT8228)/2.5V

Date: Sheet of

Date: Sheet of

Date: Sheet of

1

35 43Friday, October 17, 2014

35 43Friday, October 17, 2014

35 43Friday, October 17, 2014

1A

1A

1A

5

PR155
1/F_4

PR158

3.65K/F_4

PC141

1000P/50V_4

VSUMN

VSUMP

PR121
1/F_4

PR122

3.65K/F_4

133K/F_4

VRHOT4,38

PR135

VSUMN_NB

VSUMP_NB

+3V

+1.8V

PC142

1000P/50V_4

VRHOT

PUT COLSE
TO VDDNB
Inductor

PR140
1K/F_4

PR144
*10K/F_4

PUT COLSE
TO VCORE
Inductor

11.5K/F_4

11.5K/F_4

PC331
*0.1U/10V_4

VSUMN_1

VSUMP_1

5

VSUMN_NBY

VSUMP_NB_Y

PUT COLSE
TO VDDNB
HOT SPOT

PR134

9.76K/F_4

PC338 *100P/50V_4

CPU_PWRGD_SVID_REG4,38

D D

C C

VRON30,38

B B

A A

VSUMN_NBY37

VSUMP_NB_Y37

PR131

1 2

470K_4 NTC

PR133

27.4K/F_4

PR136 0_4/P

VSUMN_137

VSUMP_137

PR125

PR146

133K/F_4

PR161

4

12

PC139

0.1U/10V_4

CPU_SVC4

CPU_SVD4

CPU_SVT4

PC146

PUT COLSE
TO VCORE
HOT SPOT

12

PC157

0.1U/10V_4

4

PR123

2.05K/F_4

PR127
10K/F_4 NTC

1000P/50V_4

PR147

470K_4 NTC

PR160

2.05K/F_4

PR163

10K/F_4 NTC

PC136

0.068U/10V_4

VSUMN_NB

PR132 0_4/P

PR137 0_4/P
PR138 0_4/P
PR141 0_4/P
PR142 0_4/P
PR143 0_4/P

PR145

9.76K/F_4

1 2

PC153

0.22U/10V_4

VSUMN

PC137

0.01U/50V_4

6277NTC_NB

6277IMON_NB

6277SVD
6277VDDIO
6277SVT
6277VRHOT

6277PWROK

6277IMON

6277NTC

PR148

27.4K/F_4

PC154

*0.1U/10V_4

6277SVC
6277EN

PC147
1000P/50V_4

+5VS5

PR128

1.8K/F_4

PR129

*1K/F_4

*0.1U/10V_4

1

NTC_NB

2

IMON_NB

3

SVC

8

ENABLE

5

SVD

6

VDDIO

7

SVT

4

VR_HOT_L

9

PWROK

10

IMON

11

NTC

PR150 *0_4/S

422/F_4

PR166

*1K/F_4

PC138

41

PR164

GND

*0.1U/10V_4

ISUMN_NB

39

12

PC155

3

PC131

*0_4/S

PC140

0.22U/25V_6

19

PC150

390P/50V_4
PR156

*32.4K/F_4

PC152
*330P/50V_4

BOOTY

31

BOOT_NB

COMP

6277COMP

PR116

2K/F_4

PR119

301/F_4

SWNBY

HNBY

32

33

PHASE_NB

PGOOD

FB

20

18

6277PGOOD

6277FB

PC149

150P/50V_4

PR153

68K/F_4

330P/50V_4

1000P/50V_4

PR126

1.43K/F_4

LGATE_NB

UGATE_NB

UGATE2

BOOT2

PHASE2

LGATE2

VDDP

UGATE1

BOOT1

PHASE1

LGATE1

24

LG1

PC133

VDD

PR157
2K/F_4

PC151
470P/50V_4

PC135

*330P/50V_4

34

29
30
28
27
26

PR139 1_6

25

PC144 1U/6.3V_4

22

HG1
SW1_B

21
23

SW1

PR151

301/F_4

PR154

1.5K/F_4

LGNBY

PC145

0.22U/25V_6

LG1 37

PC148

1000P/50V_4

PR117

*32.4K/F_4

PC132

150P/50V_4

PC134

PR124

33K/F_4

390P/50V_4

PR130

PGOOD_NB

COMP_NB

VSEN_NB

VSUMP_NB

FB_NB

38

35

37

40

36

FB_NB

VSEN_NB

COMP_NB

ISUMP_NB

ISUMN_NB

ISEN2

ISEN1

13

14

ISENS2

ISENS1

PR152 10K/F_4

3

ISUMP

VSUMP

PU10

ISL62771

ISUMN

15

6277ISUMN

PGOOD_NB

VSEN

RTN

16

17

6277RTN

6277VSEN

PC156

0.01U/50V_4

2

PR118
100/F_4

PR120

0_4

CPU_VRM8380_PG 5,36

SWNBY 37

HNBY 37

PC143 1U/6.3V_4

2

+VDDNB_CORE

CPU_VDDNB_RUN_FB_H 4

LGNBY 37

+5VS5+1.8V

CPU_VRM8380_PG 5,36

+VCC_CORE

PR162

0_4

PR165

0_4

PR349

0_4

HG1 37

SW1 37

PR159
100/F_4

CPU_VDD0_RUN_FB_H 4
CPU_VDD0_RUN_FB_L 4

PR167 100/F_4

CPU_VDDNB_RUN_FB_L 4

NB5

NB5

NB5

1

27

PROJECT : Y02

PROJECT : Y02

PROJECT : Y02

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v
Custom

Custom

Custom
Date: Sheet o f

Date: Sheet o f

Date: Sheet o f

CPU Core1 (ISL62771)

CPU Core1 (ISL62771)

CPU Core1 (ISL62771)

1

36 43Friday, October 17, 2014

36 43Friday, October 17, 2014

36 43Friday, October 17, 2014

1A

1A

1A

5

4

3

2

1

28

+VIN_VCC_CORE

PC159

PC160

PC161

PL18

PC173

2200P/50V_4

*4.7U/25V_8

PR171
*0_2/S

VSUMN_1

VSUMP_1

PL19
*0_8/S

PR175
*0_2/S

VSUMN_NBY

VSUMP_NB_Y

PC162

0.1U/25V_4

PC174

0.1U/25V_4

D D

PR168

HG1

HG136

SW1

SW136

LG1

LG136

C C

B B

HG1_G

1_6

HNBY36

SWNBY36

LGNBY36

HNBY

SWNBY

LGNBY

4

PQ16

FDMS7698

4

PQ18

FDMS0310AS

G

G

PR172

5

D

S

213

5

D

S

213

HNBY_G

1_6

PQ20

FDMS3669S

HG1_G

LG1

*FDMS7698

FDMS0310AS

1

G1

S1/D2

9

G2

8

4

PQ17

4

PQ19

765

G

G

PC158

5

D

S

213

5

D

S

213

2

D1D1D1

S2S2S2

4.7U/25V_8

4.7U/25V_8

SW1

PR169
*2.2_6

PC169
*2200P/50V_4

PC170

4.7U/25V_8

SWNBY

PR173
*2.2_6

PC178

0.36U28A(PCME104T-R36MS0R765)

+VIN_VCC_GT +VIN

PC172

PC171

0.1U/25V_4

4.7U/25V_8

0.68uH/15.5A(PCMC063T-R68MN)

DCR=5.5mohm_max

PR174
*0_2/S

*2200P/50V_4

4.7U/25V_8

DCR=0.76mohm

PR170
*0_2/S

PL20

PL17

*0_8/S

PC163

2200P/50V_4

VSUMN_1 36

VSUMP_1 36

VSUMN_NBY 36

VSUMP_NB_Y 36

+VIN

12

+

PC164

PC165

0.1U/25V_4

+

PC175

220u/2V_7343

CPU CORE Volt
Countinue current:22A
Peak current:35A
OCP minimum:40A
LL= -2.1mV/A

100UF/25V

VDDNB Volt
Countinue current:12A
Peak current:17A
OCP minimum:25A
LL= -4mV/A

+VDDNB_CORE

+VCC_CORE

+

+

PC168

PC167

*220u/2V_7343

*220u/2V_7343

PC177

12

+

PC342

*220u/2V_7343

390U/2.5V_5X5.8ESR10

+

12

+

PC48

390U/2.5V_5X5.8ESR10

+

+

PC341

PC64

390U/2.5V_5X5.8ESR10

390U/2.5V_5X5.8ESR10

12

12

A A

PROJECT : Y02

PROJECT : Y02

PROJECT : Y02

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number R ev

Size Document Number R ev

Size Document Number R ev
Custom

Custom

Custom

NB5

NB5

NB5

Date: Sheet o f

Date: Sheet o f

5

4

3

2

Date: Sheet o f

CPU Core2

CPU Core2

CPU Core2

1

1A

1A

1A

37 43Friday, October 17, 2014

37 43Friday, October 17, 2014

37 43Friday, October 17, 2014

5

4

3

2

1

27

CPU

C

PR185

PD9

*RB501V-40

PR182

47K/F_4

arrizo

Carrizo-L

21

3

2

PC181

PQ21
2N7002K

1

1000P/50V_4

PC186
*0.1U/10V_4

PR202
1/F_4

PR205

3.65K/F_4

D D

VRON30,36

VDDGFX_PD5

C C

B B

10K/F_4

VSUMN_GFX_139

VSUMP_GFX_139

Page 38 & Page 39

PC179
*0.47U/6.3V_4

CPU_PWRGD_SVID_REG4,36

VSUMN_GFXVSUMN_GFX_1

VSUMP_GFXVSUMP_GFX_1

Stuff

Unstuff

VRHOT4,36

+1.8V

VRHOT

PR190
*10K/F_4

133K/F_4

GFX_SVC4

6277EN_GFX

GFX_SVD4

GFX_SVT4

PR192

PUT COLSE
TO GFX CORE
HOT SPOT

PR206

2.05K/F_4

PC184
1000P/50V_4

PR193

470K_4 NTC

PR180 100K/F_4
PR181 100K/F_4

PR176 0_4/P

PR183 0_4/P
PR184 0_4/P
PR186 0_4/P
PR188 0_4/P
PR189 0_4/P

PR191

9.76K/F_4

1 2

6277SVC_GFX

6277SVD_GFX
6277VDDIO_GFX
6277SVT_GFX
6277VRHOT_GFX
6277PWROK_GFX
6277IMON_GFX
6277NTC_GFX

PR194

27.4K/F_4

PC185
1000P/50V_4

+5VS5

1

NTC_NB

2

IMON_NB

3

SVC

8

ENABLE

5

SVD

6

VDDIO

7

SVT

4

VR_HOT_L

9

PWROK

10

IMON

11

NTC

41

PR197 *0_4/S

GND

PR199

10K/F_4

+5VS5

PR177

0_4/P

38

35

37

40

39

36

FB_NB

VSEN_NB

COMP_NB

ISUMP_NB

ISUMN_NB

ISEN2

ISEN1

12

13

14

ISENS2_GFX

ISENS1_GFX

ISUMP

VSUMP_GFX

PU11

ISL62771

ISUMN

15

6277ISUMN_GFX

PGOOD_NB

COMP

VSEN

RTN

19

16

17

6277RTN_GFX

6277VSEN_GFX

6277COMP_GFX

PC189

390P/50V_4
PR203

*32.4K/F_4

31

33

BOOT_NB

FB

18

6277FB_GFX

PC188

150P/50V_4

PR178

10K/F_4

32

LGATE_NB

PHASE_NB

UGATE_NB

UGATE2

BOOT2

PHASE2

LGATE2

VDDP

UGATE1

BOOT1

PHASE1

PGOOD

LGATE1

20

24

6277PGOOD_GFX

PR200

68K/F_4

VDD

PR204
2K/F_4

PC190
470P/50V_4

PR179

34

10K/F_4

29
30
28
27
26
25

PR187 1_6

PC182 1U/6.3V_4

HG1_GFX

22

SW1_GFX_B

21

SW1_GFX

23

LG1_GFX 39

PR196 *0_4/S

PC187

PR198

301/F_4

1000P/50V_4

PR201

1.5K/F_4

PC183

0.22U/25V_6

PC180 1U/6.3V_4

PR195

1K/F_4

+5VS5+1.8V

HG1_GFX 39

SW1_GFX 39

+3V

APU_VRM_GFX_PWRGD 5

PC191

0.22U/10V_4

VSUMN_GFX

PC192

*0.1U/10V_4

PR214

*1K/F_4

PR211

422/F_4

PC194

*0.1U/10V_4

3

PR207

11.5K/F_4

PUT COLSE TO
GFX CORE

A A

5

Inductor

12

PC196

0.1U/10V_4

4

PR210

10K/F_4 NTC

PC193
*330P/50V_4

PC195

0.01U/50V_4

PR208
0_4

PR212
0_4

2

PR209
100/F_4

PR213

100/F_4

+APU_VDDGFX

APU_VDDGFX_RUN_FB_H 4
APU_VDDGFX_RUN_FB_L 4

PROJECT : Y02

PROJECT : Y02

PROJECT : Y02

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v
Custom

Custom

Custom

NB5

NB5

NB5

Date: Sheet o f

Date: Sheet o f

Date: Sheet o f

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

CPU Core1 (ISL62771)

CPU Core1 (ISL62771)

CPU Core1 (ISL62771)

1

38 43Friday, October 17, 2014

38 43Friday, October 17, 2014

38 43Friday, October 17, 2014

1A

1A

1A

5

4

3

2

1

28

+VIN_APU_VDDGFX

PC199

PC198

D D

PR215

HG1_GFX38

SW1_GFX

SW1_GFX38

LG1_GFX

LG1_GFX38

C C

HG1_GFX_G

1_6

4

PQ22

FDMS7698

4

PQ24

FDMS0310AS

5

D

G

HG1_GFX_GHG1_GFX

LG1_GFX

4

PQ23

*FDMS7698

4

PQ25

FDMS0310AS

S

213

5

D

G

S

213

PC197

5

D

G

S

213

5

D

G

S

213

4.7U/25V_8

PR216
*2.2_6

PC208
*2200P/50V_4

4.7U/25V_8

PC200

PC201

4.7U/25V_8

0.36U28A(PCME104T-R36MS0R765)

DCR=0.76mohm

PR217
*0_2/S

PL22

*4.7U/25V_8

PR218
*0_2/S

VSUMN_GFX_1

VSUMP_GFX_1

0.1U/25V_4

PC202

*0_8/S

2200P/50V_4

PL21

+VIN

12

+

PC203

0.1U/25V_4

VSUMN_GFX_1 38

VSUMP_GFX_1 38

+APU_VDDGFX Volt
Countinue current:22A
Peak current:35A

PC204

OCP minimum:40A
LL= -2.1mV/A

*100UF/25V

+APU_VDDGFX

+

PC206

220u/2V_7343

+

PC207

12

12

+

+

PC343

PC344

*220u/2V_7343

390U/2.5V_5X5.8ESR10

390U/2.5V_5X5.8ESR10

B B

A A

PROJECT : Y02

PROJECT : Y02

PROJECT : Y02

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number R ev

Size Document Number R ev

Size Document Number R ev
Custom

Custom

Custom

NB5

NB5

NB5

Date: Sheet o f

Date: Sheet o f

5

4

3

2

Date: Sheet o f

CPU Core2

CPU Core2

CPU Core2

1

1A

1A

1A

39 43Friday, October 17, 2014

39 43Friday, October 17, 2014

39 43Friday, October 17, 2014

5

+1.8V_VGA +3V_VGA +0.95V_VGA +VGA_CORE +1.35V_VGA

PC332
*0.1U/10V_4

PC333
*0.1U/10V_4

PC334
*0.1U/10V_4

PC335
*0.1U/10V_4

PC336
*0.1U/10V_4

4

PC253

+VIN_GPU

PC290

0.1U/25V_4

0.1U/25V_4

+VIN_GFX

3

2

+3VLANVCC23

1

+3V4,5,6,7,11,12,20,21,22,23,24,27,28,29,30,36,38
+5V22,23,24,27,28

+VIN21,25,27,31,32,33,35,37,39,41,42
+3VS55,6,7,29,30,32,34,41,43
+5VS523,28,32,33,34,35,36,38,41,43

39

PC213
*10U/6.3V_6

+5VS5

PC234
*10U/6.3V_6

+5VS5

+5VS5

PC214

0.1U/10V_4

PC221

0.1U/10V_4

+1.5VS5

PC235

0.1U/10V_4

PC240

0.1U/10V_4

PC209

0.1U/10V_4

13
14

4

3

PC223
*0.1U/10V_4

1000P/50V_4

PC231

0.1U/10V_4

13
14

4

3

PC241
*0.1U/10V_4

1000P/50V_4

VOUT1
VOUT1

VBIAS

ON1

PC227

VOUT1
VOUT1

VBIAS

ON1

PC243

1

1

VIN12VIN1

PU13

APL3523A

CT1

12

VIN12VIN1

PU14

APL3523A

CT1

12

D D

UMA only

discrete

C C

MAINON

B B

Stuff

Unstuff

2

PQ29

METR5213-G

+3VS5

+3VS5

+5V

PC211

0.1U/10V_4

+3V

1.1V_ONG

PC218

0.1U/10V_4

PC222

0.1U/10V_4

+1.8V_ROM

2

PC217
*10U/6.3V_6

+5VS5

MAINON30,33,35

1 3

PR225 0_4/P

+VIN

PR229
1M_4

PR233
1M_4

13
14

4

3

PC225
*0.1U/10V_4

1000P/50V_4

PR227
*22_8

3

PQ27
*2N7002K

1

VOUT1
VOUT1

VBIAS

ON1

PC229

1

VIN12VIN1

PU12

APL3523A

CT1

12

+VIN

2

3

1

VIN26VIN2

CT2

10

PR228
1M_4

PQ28
2N7002K

7

PC230
1000P/50V_4

OUT2
OUT2

GND
GND

ON2

8
9

11
15

5

1.1V_OND

PR232
2M_4

PC212

0.1U/10V_4

+3VLANVCC_S2

PC219

0.1U/10V_4

PR226 0_4/P

PC226
*0.1U/10V_4

+1.8VS5

3

PQ26

EMB32N03K

65241

PC238

*10U/6.3V_6

0.67A5.2A

+3VLANVCC

PR222
*0_6/S

PC220
*10U/6.3V_6

LAN_POWER 30

PC233

0.2A

0.1U/10V_4

+1.8V

PC239

0.1U/10V_4

3A

+1.5V

MAINON

PR230
*0_6/S

MAINON

PR223 0_4/P

+1.5V_S2

PR234 0_4/P

7

VIN26VIN2

CT2

10

PC228
1000P/50V_4

7

VIN26VIN2

CT2

10

PC244
1000P/50V_4

OUT2
OUT2

OUT2
OUT2

GND
GND

ON2

GND
GND

ON2

+3VS5

PC210

0.1U/10V_4

8
9

11
15

5

PR224 0_4/P

+1.8VS5

PC232

0.1U/10V_4

8
9

11
15

5

PR235 0_4/P

PC224
*0.1U/10V_4

PC242
*0.1U/10V_4

PC215

0.1U/10V_4

PC236

0.1U/10V_4

+3VSUS_S2

PC216
*10U/6.3V_6

+1.8V_S2

PC237
*10U/6.3V_6

0.04A5.1A

+3VSUS

PR221

*0_6/S

SUSON 30,33

1.8A

+1.8V_ROM

PR231

*0_6/S

SPI_1.8V_ON 30

+VIN

+3VS5

PR238
100K/F_4

APU_S5_MUX_CTRL5

A A

PR241

0_4/P

5

PR236
787k_4

PQ30A

34

5

2N7002KDW

2

PR343
1M_4

FCH_S5_POWER

PQ30B

61

2N7002KDW

PR242
100K/F_4

+VDDNB_CORE

FCH_S5_POWER_COMP

PC248

*0.1U/10V_4

4

PR239

0_4/P

+5VS5

3
2

6
5

PQ32

PR240

PR244

EMB32N03K

6
5
2
1

PQ34
EMB32N03K

6
5
2
1

4

3

4

3

+5VS5

PQ46B

+VDDNB_CORE

PR350
*100K/F_4

PC245

0.1U/10V_4

84

PU15A
TLC3702IDR

+

1

-

+VDDCR_+0.775VS5_G

61

2

+5VS5

*2N7002KDW

PR351

-

+

7

PU15B
TLC3702IDR

+VDDCR_VDDNB_G

3

5

*100K/F_4

PQ46A

34

*2N7002KDW

+VDDCR_VDDNB_G

+0.775VS5

+VDDCR_+0.775VS5_G

PR237

0_4/P

PR243

0_4/P

+VDDNB_CORE_POWER

1K/F_4

FCH_S5_POWER

1K/F_4

2

EMB32N03K

4

PC246
*0.1U/10V_4

EMB32N03K

4

PC249
*0.1U/10V_4

NB5

NB5

NB5

PQ31

+VDDCR_FCH_S5

6
5
2
1

3

PQ35

6
5
2
1

3

Size Document Number R ev

Size Document Number R ev

Size Document Number R ev
Custom

Custom

Custom
Date: Sheet of

Date: Sheet of

Date: Sheet of

PC247

0.1U/10V_4

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Load switch IC

Load switch IC

Load switch IC

1

40 43Friday, October 17, 2014

40 43Friday, October 17, 2014

40 43Friday, October 17, 2014

1A

1A

1A

5

4

3

2

1

41 43Friday, October 17, 2014

41 43Friday, October 17, 2014

41 43Friday, October 17, 2014

39

1A

1A

1A

+VIN +VIN_GFX

PL23

+MVDDQ Volt +/- 5%
Countinue current:6A
OCP_TDC=12.6A
OCP_SPIKE=18A(1ms)

D D

Vboot=0.9V
LL=0 V/A
external offset=0.45V

+1.35V_VGA

12

12

+

+

PC264

0.1U/10V_4

C C

PC260

*330U_2V_7343

PC261

390U/2.5V_5X5.8ESR10

VID Override table (VDD)

VC

SVDS

0

0

B B

0

Boot Voltage

110 0.9V

11

+1.8V_VGA

PR303
10K/F_4

A A

PR312
*10K/F_4

5

*0_8/S

PC250

0.1U/25V_4

PL24

1uH/11A (PCMC063T-1R0MN)

DCR=9mohm

PR255

*0_2/S
PR250
*0_2/S

PC269

1U/25V_4

PR263

150/F_4

PR265
845/F_4

PC271

0.1U/10V_4

1.1V

1.0V

0.8V

PC284
PR304

0.1U/10V_4

*10K/F_4

8899SVC
8899SVD

PR313
10K/F_4

PC251

4.7U/25V_8

DGPU_OCP_L14

PR251
*0_2/S

PR260
620/F_4

DGPU_PR_EN5,30,43

PC252

4.7U/25V_8

SVI2_CLK14

SVI2_DATA14
SVI2_SVT14
DGPU_PWROK5,30,43

PR269
0_4

+3VS5

PR256

*2.2_6

PC262

*2200P/50V_4

+3VS5

PC254

2200P/50V_4

678

EMB20N03V

35241

678

AON7752

35241

PC272

*82P/50V_4

PR275

0_4

8899VCC

8899VCC

PD10 RB501V-40

21

PR295 20K/F_4

PR296

*10K/F_4

DGPU_PWROK

DGPU_PWROK

PR319

10K/F_4

8899UGATEA_S

PQ36

PQ37

8899VCC

PR267 0_4/P

PR276

5.1K/F_4

18K/F_4

PR297 0_4/P

+1.8V_VGA

4

PC257

0.1U/25V_4

PR270

0_4

PR282

19.1K/F_4

PR287

330/F_4

PR291

PR293

8.87K/F_4

PC280

0.47U/6.3V_4

PR309 0_2/P
PR310 0_2/P
PR314 0_2/P
PR316 0_2/P
PR318 0_2/P
PR320 0_2/P

PR247

4.7_4

PR252

150K/F_4

PR249

PC265

0.1U/25V_4

PC274

*100P/50V_4

PR283

130/F_4

PR288

150/F_4

PR299

2.2_6

1_6

PR261

10K/F_4

PR271

24.9K/F_4

8899TONA

8899UGATEA1

8899PHASEA18899PHASEA1

8899BOOTA1

8899LGATEA1

8899ISENA1P
8899ISENA1N

8899VSENA

8899COMPA

8899FBA

8899SET2

8899OFSA

1.65V

PC278

0.1U/10V_4

8899EN

8899OCP_L

8899VDDIO

PC282
1U/6.3V_4

8899PWROK

PR245

2.2_6

40

43

44

42

45

33
34

36
35

32

30

31

26

24

37

27

18

8899SVC
8899SVD

8899SVT
8899PGOODA
8899PGOOD

TONSETA

UGATEA1

PHASEA1

BOOTA1

LGATEA1

ISENA2P
ISENA2N

ISENA1P
ISENA1N

VSENA

COMPA

FBA

SET2

OFSA

EN

Vih=2V

OCP_L

VDDIO

PWROK

19

8899VCC

28

SVC

20

PC255

2.2U/6.3V_6

VCC

PU16

RT8899AGQW

SVD

SVT

21

22

38

8899PVCC

50

PVCC

PGOOD39PGOODA

29

3

PR246

PC256

2.2U/6.3V_6

TONSET
UGATE1

BOOT1

PHASE1
LGATE1

UGATE2

BOOT2

PHASE2
LGATE2

ISEN2P

ISEN2N

ISEN1P

ISEN1N

ISEN3P

ISEN3N

VSEN

COMP

RGND

SET1

OFS

GND

PWMA2

PWM3

IMON

IMONA

V064

IBIAS

16

PR311

100K/F_4

PC285

0.47U/6.3V_4

2.2_6

FB

+5VS5+5VS5

4
47
46

48
49
1
2

52
51
5
6
8
7
9
10
11

13

12
14
25

23

0.1U/10V_4

53

41
3

15

17

8899TON
8899UGATE1
8899BOOT1

8899PHASE1
8899LGATE1
8899UGATE2
8899BOOT2

8899PHASE2
8899LGATE2
8899ISEN2P
8899ISEN2N
8899ISEN1P
8899ISEN1N

8899VSEN

8899COMP

8899FB
8899RGND
8899SET1

8899OFS

PC279

8899IMON

8899IMONA

+0.64VREF

PR317
*10K/F_4

PC259

0.1U/25V_4

PC266

0.1U/25V_4

PR266

10K/F_4

PR272
137K/F_4

PR284

340K/F_4

5.6K/F_4

PC283
*100P/50V_4

PR315

*10K/F_4

+VIN_GPU

PR253
140K/F_4

PC275

10P/50V_4

PR289

PR294

6.34K/F_4

18.7K/F_4

PR248

4.7_4
PC258

0.1U/25V_4

8899VCC

PR268 0_4/P

PR273

0_4

PR285

13.7K/F_4
PR290

2.32K/F_4

PR292

*20K/F_4

PR300

PR305

18.7K/F_4

8899VCC

8899UGATE1 42

8899PHASE1 42
8899LGATE1 42
8899UGATE2 42

8899PHASE2 42
8899LGATE2 42

PR277

10K/F_4

PR280

*10K/F_4

8899VCC

8899VCC

PR302
100K/F_4 NTC

1 2

PR307

8.06K/F_4

PUT COLSE
TO MVDDQ
HOT SPOT

PC273

100P/50V_4

PC277

*0.1U/25V_4

PR278

0_4

2

PR254
383/F_4

1U/25V_4

*1K/F_4
PR258
845/F_4

PR298

13.7K/F_4

PC281
*100P/50V_4

16.5K/F_4

PC263

PR257

PC276
*0.1U/25V_4

PR306

PUT COLSE
TO VDDC
HOT SPOT

8899ISEN2P_S
8899ISEN2N_S

PC267

0.1U/10V_4

PR301
100K/F_4 NTC

1 2

PR308
10K/F_4

8899ISEN2P_S 42
8899ISEN2N_S 42

8899ISEN1P_S
8899ISEN1N_S

PR259
383/F_4

PC268

1U/25V_4

PR262

*1K/F_4
PR264
845/F_4

PR279
0_4
PR281
0_4

+VGA_CORE

PR274
10/F_4

PR286
10/F_4

PC270

0.1U/10V_4

Vset1

Delta Vset1

Vset2

Delta Vset2

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v
Custom

Custom

Custom

NB5

NB5

NB5

Date: Sheet of

Date: Sheet of

Date: Sheet of

8899ISEN1P_S 42
8899ISEN1N_S 42

VGPU_CORE_SENSE 16
VSS_GPU_SENSE 16

109.5mV

309.9mV

121.8mV

18.7mV

Vcore( RT8899A)

Vcore( RT8899A)

Vcore( RT8899A)

1

5

4

3

2

1

40

D D

+VIN_GPU

PC287

PR326
*2.2_6

PC308
*2200P/50V_4

PC286

4.7U/25V_8

PC296

4.7U/25V_8

4

4

PQ43

*TPCA8A10-H

8899UGATE2_G

8899LGATE2

G

G

*TPCA8064-H

5

D

S

213

5

D

S

213

4

PQ44

4

PQ45

*TPCA8A10-H

PR322
*2.2_6

PC295
*2200P/50V_4

5

D

G

S

213

5

D

G

S

213

5

D

PQ38

TPCA8064-H

PQ39

TPCA8A10-H

4

PQ40

TPCA8064-H

4

PQ41

TPCA8A10-H

G

4

G

4

5

G

213

5

G

213

8899UGATE1_G

S

213

5

D

S

213

8899LGATE1

PQ42
*TPCA8064-H

D

S

D

S

PR321

PR325

1_6

8899UGATE1_G

1_6

8899UGATE2_G

8899UGATE141

8899PHASE141

8899LGATE141

C C

8899UGATE241

8899PHASE241

8899LGATE241

B B

PC297

PC288

PC289

4.7U/25V_8

4.7U/25V_8

*4.7U/25V_8

DCR=1.1mohm

PR323
*0_2/S

+VIN_GPU

PC299

PC298

4.7U/25V_8

4.7U/25V_8

*4.7U/25V_8

DCR=1.1mohm

PR327
*0_2/S

PL26

0.36uH

PC300

0.1U/25V_4

PL27

0.36uH

PC291

2200P/50V_4

PR324
*0_2/S

8899ISEN1N_S

8899ISEN1P_S

PC301

2200P/50V_4

PR328
*0_2/S

8899ISEN2N_S

8899ISEN2P_S

PL25
*0_8/S

+VIN

PC292

0.1U/25V_4

12

12

+

+

PC293

100U/25V

+VGA_CORE

8899ISEN1N_S 41

8899ISEN1P_S 41

8899ISEN2N_S 41

8899ISEN2P_S 41

PC294

*100U/25V

VGACORE ( Meso XT DDR3_ 35W/53W(1ms) )
Countinue current:36A
OCP_TDC=45A
OCP_SPIKE=75A(1ms)
Vboot=0.9V
LL=1m V/A

+VGA_CORE

12

PC302

0.1U/10V_4

12

+

PC303

390U/2.5V_5X5.8ESR10

12

12

+

+

PC304

PC305

390U/2.5V_5X5.8ESR10

390U/2.5V_5X5.8ESR10

12

+

+

PC306

PC307

*330U_2V_7343

*390U/2.5V_5X5.8ESR10

A A

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

CPU Core2

CPU Core2

NB5

NB5

5

4

3

2

NB5

CPU Core2

Date: Sheet o f

Date: Sheet o f

Date: Sheet o f

42 43Friday, October 17, 2014

42 43Friday, October 17, 2014

42 43Friday, October 17, 2014

1

1A

1A

1A

1

2

3

4

5

6

7

8

41

+0.95V +/- 3%

A A

PC309

PR329

*2200P/50V_4

554PG_1.0V

554PVIN_1.0V

PC316
1U/6.3V_4

PJP6

PC314

12

0.01U/50V_4

PR331 0_4/P

PR334

10_6

PC315

10U/6.3V_6

DGPU_PWROK5,30,41

+3VS5

*POWER_JP/S

B B

PU17

4

PG

9

PVIN

10

PVIN

8

SVIN

11

GND

DGPU_PR_EN5,30,41

RT8068A

PUT COLSE TO
+1.8V power.

+1.8VS5

*2.2_6

NC
LX
LX
NC
FB
EN

DGPU_PR_EN

554LX_1.0V

1
2
3

554NC_1.0V

7

554FB_1.0V554SVIN_1.0V

6
5

Vih=1.6V

PR336

4.7K/F_4

+3VS5

PL28

*22P/50V_4

PC313

*68P/50V_4

PC317

0.47U/6.3V_4

1uH/11A (PCMC063T-1R0MN)

554FB_1.0V_S

PC310

R1

R2

PR332
*0_2/S

PR333

6.65K/F_4

V0=0.6*(R1+R2)/R2

PR335

11.3K/F_4

Countinue current:2A
Peak current:3A
OCP minimum:4A

+1.0V_VGA

+0.95V_VGA

+1.0V_VGA_S2

PC311

PR330
*POWER_JP/S

1 2

PC312

10U/6.3V_6

0.1U/10V_4

PC318

0.1U/10V_4

13

VOUT1

14

VOUT1

4

VBIAS

3

ON1

PC325

0.47U/6.3V_4
PC327

1000P/50V_4

1

4

0.3A

+1.8V_VGA +3V_VGA

C C

DGPU_PR_EN DGPU_PR_ENDGPU_PR_EN

D D

1

2

PR337

*0_6/S

Vih=1.2V

3

+1.8V_VGA_S2

PC320
*10U/6.3V_6

+5VS5

PR339

4.7K/F_4

PC321

0.1U/10V_4

PC324

0.1U/10V_4

VIN12VIN1

PU18

APL3523A

CT1

12

7

VIN26VIN2

CT2

10

PC328
1000P/50V_4

OUT2
OUT2

GND
GND

ON2

8
9

11
15

5

PC319

0.1U/10V_4

PD11 RB501V-40

PR340

20K/F_4

PC326

0.47U/6.3V_4

+3V_VGA_S2

PC322

0.1U/10V_4

21

5

0.06 A

PR338
*0_6/S

PC323
*10U/6.3V_6

+3V_VGA

+1.8V_VGA & +0.95V_VGA

+VGA_CORE & +1.35_VGA

6

PROJECT : X21

PROJECT : X21

PROJECT : X21

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Re v

Size Document Number Re v

Size Document Number Re v
Custom

Custom

Custom

+VGA POWER

+VGA POWER

NB5

NB5

NB5

7

+VGA POWER

Date: Sheet of

Date: Sheet of

Date: Sheet of

1A

1A

43 43Friday, October 17, 2014

43 43Friday, October 17, 2014

43 43Friday, October 17, 2014

8

1A
