HP 1500 Datasheet

hp color LaserJet
1500 series
hp color LaserJet 1500/L printer
HP’s most affordable colour laser printer – designed for Windows®and Macintosh®environments. It is compact, light and as easy to operate as most black and white laser printers.
Ideal for professionals in small businesses, home offices, or demanding personal users working in Windows®or Macintosh®environments who need to create professional black and white and colour documents to promote their business.
An affordable, reliable, entry level colour laser printer for Windows
®
and Macintosh®environments.
•Print everyday documents in black and white at 16 ppm, adding colour when you need to at 4 ppm.
• Instant-on fuser for fast first page out with no warm-up time means your documents print without delay.
• HP Imageret 2400 and chemically grown toner deliver superior print quality with sharp, clear detail.
•Supports Microsoft
®
Windows®(98, Me, 2000, XP) and Macintosh®(9.x and higher) environments.
As easy to operate as most black and white laser printers.
•Easily connect directly to your Windows
®
or Macintosh®computer using the Hi-Speed USB port.
• One-door access to five easy to use printing supplies.
•See printing supplies status at a glance on the simple control panel.
•Software toolbox for all printer information (including printer status, documentation and help videos) and printer configuration.
•Cost per page for black only printing equivalent to personal black and white laser printers.
Compact and light enough to fit in any working environment – even on the desktop.
•Use less office space and therefore save money.
•Add additional paper trays to expand paper input capacity and media handling flexibility while keeping the same compact design.
•Add an optional HP Jetdirect external print server for sharing the HP Color LaserJet 1500 printer on a network.
hp color LaserJet 1500 printer
hp color LaserJet 1500L printer
hp color LaserJet
1500 series
technical specifications
print speed document type plain paper transparency
Black A4 up to 16 ppm up to 16 ppm Colour A4 up to 4 ppm
First page out black: 16 secs from “Ready” and “Standby” First page out colour: 29 secs from “Ready” and “Standby”
Exact speed varies depending on the system configuration, software application, and document complexity.
processor 150 MHz, Oak OTI-4110 memory 16 MB, no additional memory required using Memory Enhancement technology (MEt) print technology 4-pass colour laser printing technology print resolution HP Imageret 2400 economical printing Manual duplexing, N-up printing (multiple pages per sheet) languages Host-based (Windows®and Macintosh®) print margins (A4) Top 4.2 mm, left: 4.2 mm, right: 4.2 mm, bottom: 4.2 mm duty cycle Up to 30,000 pages per month media handling input capacity weight size
Tray 1: 125 sheets, 60 to 177 g/m
2
minimum size: 76 x 127 mm,
50 transparencies, 10 envelopes maximum size: 216 x 356 mm
Tray 2*: 250 sheets 60 to 105 g/m
2
A4, Letter, Legal, Executive, A5, B5 (JIS/ISO), 8.5" x 13"
Tray 3**: 500 sheets 60 to 105 g/m
2
A4, Letter
output: 125 sheets, 50 transparencies, 10 envelopes; straight through paper path duplex printing: Manual (driver support provided) media types: Paper (plain, letterhead, prepunched, recycled), transparencies (printed in greyscale), envelopes,
labels, cardstock.
*Standard with the HP Color LaserJet 1500 printer **Optional - tray 2 must be installed to add tray 3
interface and connectivity Standard: 1 Hi-Speed USB port
Optional: HP Jetdirect external print servers: HP Jetdirect 175x external print server for Ethernet/Fast Ethernet, HP Jetdirect 310x external print server for Ethernet/Fast Ethernet, HP Jetdirect 380x 802.11b external wireless print server
operating systems compatibility Microsoft
®
Windows®(98, Me, 2000, XP (32-bit)), Mac®OS (9.x, OS X)
Current drivers and software are available from the internet.
minimum system requirements Windows
®
: Microsoft®Windows 98, Me, 2000: Pentium®166 MHz with 32 MB RAM; Microsoft Windows XP: 233 MHz processor with 64 MB RAM; 150 MB free hard disk space, CD-ROM drive, USB or Hi-Speed USB systems and cables Macintosh: Mac
®
OS 9.x, OS X; 150 MB free hard disk space, CD-ROM drive, USB or Hi-Speed USB systems
and cables
control panel Simplified control panel with LED lights for printer status, status of each print cartridge (CMYK) and the imaging
drum; “Rotate Carousel” button, “Cancel Job” button, “Go” button.
printer management HP Color LaserJet 1500 Toolbox, HP Web Jetadmin, HP Printer Status and Alerts power requirements 220-volt model: 220 to 240 V (+/-10%), 50/60 Hz (+/-2 Hz), 6 amps; 110-volt model: 115 to 127 V (+/-10%),
50/60 Hz (+/-2 Hz), 12 amps
power consumption 220 V model (maximum): 0 watts (off), 31 watts (ready/standby), 403 watts (printing); 110 V model (maximum):
0 watts (off), 30 watts (ready/standby), 400 watts (printing)
dimensions (w x d x h) Out of package: HP Color LaserJet 1500L printer: 482 x 451 x 325 mm, HP Color LaserJet 1500 printer: 482 x
451 x 376 mm
product weight Out of package: HP Color LaserJet 1500L printer: 21.5 kg (with supplies), HP Color LaserJet 1500 printer: 23.9 kg
(with supplies)
operating environment Environmental ranges: operating temperature: 15 to 32.5° C; operating humidity: 10 to 80% RH; recommended
operating humidity: 20 to 70% RH; recommended operating temperature: 20 to 27° C; storage temperature:
-20 to 40° C; storage humidity: 0 to 95% RH; noise level per ISO 9296: sound power LWAd: 6.7 B(A) printing, 0 B(A) standby; sound pressure LpAm: 52 dB(A) printing, 0 dB(A) standby
ENERGY STAR Yes certifications Technical Regulations: Carries CE marking for EU & EFTA countries (Compliant to Low Voltage Directive
73/23/EEC / EMC Directive 89/336/EEC, Class 1 Laser/LED). For additional details, see Declaration of Conformity. Further compliances include USA FCC/UL, Russia GOST, Poland B-Mark, Czech Republic (CSN *), Estonia (EEI *), Hungary (MEEI *), Lithuania (LS *), Slovakia (STN *), Slovenia (SQI *), South Africa (SASB *) (* = IEC 60950, IEC 60825); Voluntary Certifications: TÜV-GS approved; EPA ENERGY STAR compliant
warranty Standard 1 year return to HP/vendor. Optional HP Supportpacks.
ordering information
q2488a hp color LaserJet 1500L printer,
hp color LaserJet print cartridges (black
up to 5,000 pages
; cyan, yellow,
magenta up to 4,000 pages
), one hp color LaserJet imaging drum, getting started guide, printer software and user guide on CD-ROM, power cord, tray 1:
125-sheet multipurpose feeder
q2489a hp color LaserJet 1500 printer,
includes same as above plus:
tray 2: 250-sheet input tray
accessories
c9698a hp 250-sheet tray and feeder unit c9699a hp 500-sheet tray and feeder unit
hp jetdirect external print servers
j6035b hp jetdirect 175x Ethernet/
Fast Ethernet external print server
j6038a hp jetdirect 310x Ethernet/
Fast Ethernet external print server
j6061a hp jetdirect 380x 802.11b
external wireless print server
cables
c6518a USB cable, 2 m
supplies
C9700A hp color LaserJet print cartridge,
black (up to 5,000 pages†)
C9701A hp color LaserJet print cartridge,
cyan (up to 4,000 pages†)
C9702A hp color LaserJet print cartridge,
yellow (up to 4,000 pages†)
C9703A hp color LaserJet print cartridge,
magenta (up to 4,000 pages†)
C9704A hp color LaserJet imaging drum,
(up to 20,000 black/5,000 colour pages)
service & support
u2893a hp supportpack, next business
day on-site response, 3 years
u2894a hp supportpack, same business
day on-site response within 4 hours
of call, 3 years
h2872a hp supportpack, installation
and network configuration for
1 network printer
based on 5% coverage
http://www.hp.com
For more information, please call your local HP sales office or representative: Austria: 0810/006080 (local rate call), Algeria: (0)61 56 45 43, Bahrain: 800 728, Belgium: (078) 15 20 30 (0.0496 /min), Luxembourg: (+352) 263 160 34, Bulgaria: (+359) 2960 1940, Croatia and Slovenia: (+385 1) 60 60 200, Czech Republic: +420 261 307 111 (Prague), Denmark: 45991700 or 70101125, Egypt: 532 5222, Estonia: (+372) 6505 263, Finland: (09) 88721, France: (1) 69 82 6060, Germany: 0180 532 6222 (12 Cent/min), Greece: (01) 678 96 00, Hungary: (+36) 1 382-1111, Iceland: (354) 570 1000, Ireland: + 353 1 6158200, Israel: (972) 9 8304848, Italy: (02) 92121, Kazakhstan: +7 (3272) 980 824, Latvia: (371) 800 80 12, Lithuania: (370) 2 787 333, Middle East: 00971 4 883 4427, Morocco (African Region): +212 22 40 47 47, Netherlands: (020) 5476666, Norway: 22 735600,
Poland: infolinia: 0-800 122 622, Portugal: 0-800 122 622, Romania: (+401) 205 3300, RSA: (27)11 785 1000, Russia: +7 (095) 797 35 00, Saudi Arabia: 800 124 4646, Slovakia: +421-2-50205611, Spain: (91) 6311600, Sweden: (08) 444 2000, Switzerland: 0848 88 44 66, Tunisia: 71 891
222, Tu rkey: +90 (216) 579 71 71, UAE: 8004910, UK: 08705 474747, Ukraine: +380 44 490 61 20, Yugoslavia: +381 11 322 80 14.
The information contained in this document is subject to change without notice. Energy Star is a U.S. registered mark of the United States Environmental Protection Agency. All other products mentioned herein may be trademarks of their respective companies. Microsoft, Windows and MS Windows are U.S. registered trademarks of Microsoft Corporation.
© Copyright Hewlett-Packard 2003 Printed in the EU XX/XX 5981-5297EEE
