HP 10GbE Quickspecs
The HP 10GbE Pass-Thru Module is designed for c-Class BladeSystem and HP Integrity Superdome 2 customers requiring a nonblocking, one -to-one connection between each server and the network. The pass-thru module provides 16 uplink ports that accept
both SFP and SFP+ connectors.
The HP 10GbE Pass-Thru Module can support 1Gb and 10Gb connections on a port by port basis. Optical as well as Direct Attach Copper
(DAC) cables are also supported. Both standard Ethernet as well as Converged Enhanced Ethernet (CEE) traffic to an FCoE capable
switch is possible when using the appropriate NIC or adapter module.
HP 10GbE Pass-Thru Module
1.
UID LED
4.
Reset Button
2.
Health LED
5.
Mini USB RS-232 management port
3.
Ethernet port link status and speed LEDs
6.
Uplinks ports that accept SFP and SFP+ transceiver modules
and Direct Attach Cables (DAC)
What's New
Support for HP ProLiant G7 servers
Support for Converged Network Adapters
At A Glance
Performance
:
16 direct server to network connections
Auto-sense 1Gb or 10Gb operation on a port by port basis
Supports standard Ethernet as well as Converged Enhanced Ethernet
Supports all NICs and mezzanine adapters including Flex Adapters
Management
:
No management required
Module performance monitored by the On-Board Administrator
Front panel or OA access for service and test and firmware updates
QuickSpecs
HP 10GbE Pass-Thru Module
Overview
DA - 13508 North America — Version 8 — August 17, 2012
Page 1
Models
HP 10GbE Ethernet Pass-Thru Module for c-Class BladeSystem
538113-B21
HP Integrity 10GbE Pass-Thru Module
AT084A
QuickSpecs
HP 10GbE Pass-Thru Module
Models and Options
DA - 13508 North America — Version 8 — August 17, 2012
Page 2
HP ProLiant Servers
HP ProLiant BL2x220c G7
HP ProLiant BL2x220c G5
HP ProLiant BL260c G5
HP ProLiant BL280c G6
HP ProLiant BL420 Gen8
HP ProLiant BL460c
HP ProLiant BL460c G5
HP ProLiant BL460c G6
HP ProLiant BL460c G7
HP ProLiant BL460c Gen8
HP ProLiant BL465c
HP ProLiant BL465 G5
HP ProLiant BL465 G6
HP ProLiant BL465 G7
HP ProLiant BL465 Gen8
HP ProLiant BL480c
HP ProLiant BL490c G7
HP ProLiant BL490c G6
HP ProLiant BL495c G5
HP ProLiant BL495c G6
HP ProLiant BL620c G7
HP ProLiant BL660c Gen8
HP ProLiant BL680c
HP ProLiant BL680c G7
HP ProLiant BL685c
HP ProLiant BL685 G5
HP ProLiant BL685 G6
HP ProLiant BL685 G7
NOTE:
Some servers listed above may be discontinue
HP Integrity Severs
HP Integrity BL860c
HP Integrity BL860c i2
HP Integrity BL870c
HP Integrity BL870c i2
HP Integrity BL890c i2
HP Superdome Servers
HP Superdome 2 - 8s Server
HP Superdome 2 - 8s Promotional Server
HP Superdome 2 - 16s Server
ProLiant BL c-Class
Server Blade Enclosures
HP BladeSystem c3000 Enclosure
HP BladeSystem c7000 Enclosure
HP c-Class Mezzanine
Adapters
HP NC325m PCI Express Quad Port 1Gb Server Adapter
HP NC326m PCI Express Dual Port 1Gb Server Adapter
HP NC360m Dual Port 1GbE BL-c Adapter
HP NC364m Quad Port 1GbE BL-c Adapter
HP NC373m PCI Express Dual Port Multifunction Gigabit Server Adapter
HP NC382m PCI Express Dual Port Multifunction Gigabit Server Adapter
HP NC522m Dual Port Flex-10 10GbE Multifunction BLc Adapter
HP NC530m HP Flex-10 10Gb 2-port 530M Adapter
HP NC532m Dual Port Flex-10 10GbE Multifunction BLc Adapter
QuickSpecs
HP 10GbE Pass-Thru Module
Compatibility
DA - 13508 North America — Version 8 — August 17, 2012
Page 3
