Hovertech HMSLING-39-B, HMSLING-50, HMSLING-50-B, HMSLING-34, HMSLING-39 User Manual
...
User Manual
TABLE OF CONTENTS
Symbol Reference ...............................................................................................2
Intended Use and Precautions .............................................................................2
Part Identification – HoverSling® Split-Leg ...........................................................3
HoverSling® Split-Leg Product Specifications/Required Accessories ....................3
HoverSling® Split-Leg Instructions for Use as a Transfer Mattress .........................4
HoverSling® Split-Leg Instructions for Use as a Sling .........................................4-5
Part Identification – HoverSling® Repositioning Sheet .........................................6
HoverSling® Repositioning Sheet Product Specifications/Required Accessories ...6
HoverSling® Repositioning Sheet Instructions for Use as a Transfer Mattress .......7
HoverSling® Repositioning Sheet Instructions for Use as a Sling .......................7-8
Part Identification – HT-Air® 1200 Air Supply ....................................................... 9
HT-Air® 1200 Air Supply Keypad Functions..........................................................9
Cleaning, Preventive Maintenance/Infection Control ........................................10
Warranty Statement...........................................................................................10
Returns and Repairs ...........................................................................................11
User Manual
Symbol Reference
DECLARATION OF CONFORMITY
TO MEDICAL DEVICE DIRECTIVE
Intended Use and Precautions
INTENDED USE
The HoverSling® Split-Leg and HoverSling® Repositioning Sheet are
combination air-assisted transfer mattresses and lift slings. When used
as an air-assisted transfer mattress, the HoverTech Air Supply inflates the
HoverSling to cushion and cradle the patient, while air simultaneously
escapes from the holes on the underside, reducing the force needed to
move the patient by 80-90%. In this capacity,
to assist caregivers with lateral patient transfers,
proning. The HoverSling can also be used for vertical patient lifts with a
loop style hanger bar.
the HoverSling can be used
positioning, turning and
INDICATIONS
• Patients unable to assist in their own lateral or vertical transfer.
• Patients whose weight or girth poses a potential health risk for the
caregivers responsible for repositioning, vertically transferring or
laterally transferring said patients.
CONTRAINDICATIONS
• Patients who are experiencing thoracic, cervical or lumbar fractures
that are deemed unstable, unless using in conjunction with a spinal
board on top of the HoverSling (follow your state’s protocol regarding
use of spinal boards) for lateral transfers.
INTENDED CARE SETTINGS
• Hospitals, long term or extended care facilities
PRECAUTIONS FOR USE AS A
TRANSFER MATTRESS
• Caregivers must verify that all brakes have been engaged prior to
transfer.
• For safety, always use two people during patient transfers.
• Additional caregivers are recommended when moving a patient over
750 lbs./340kg.
• Never leave patient unattended on an inflated HoverSling.
• Only use the HoverSling for its intended purpose as described in this
manual.
• Only use attachments and/or accessories that are authorized by
HoverTech International.
• When transferring to a low air loss bed, set the bed mattress air flow to
the highest level for a firm transfer surface.
• Never attempt to move a patient laterally on an uninflated HoverSling.
• Ensure patient is centered on HoverSling before inflating.
PRECAUTIONS FOR USE AS A SLING
• Always use a minimum of two caregivers when operating
the HoverSling.
• The HoverSling should only be used by trained personnel.
• Only use attachments and/or accessories that are authorized by
HoverTech International.
• Before use, a risk assessment must be carried out to ensure that the
correct size HoverSling is being used for the patient.
• A clinical assessment should be carried out by a qualified nurse and
therapist before lifting patients with the HoverSling.
• Do not use the HoverSling lateral transfer handles to lift. Excessive
force on the lateral transfer handles can cause the HoverSling to tear.
• Make sure the HoverSling is not attached to any object other than the
loop style hanger bar.
• When connecting to loop style hanger bar, ensure shoulder strap loop
colors match on the patient’s left and right side and leg strap loop
colors match on the patient’s left and right side.
• Once the sling support straps are fully extended, make sure they are
properly connected to the hanger bar before the patient is lifted.
• For seated lifts, make sure the patient is sitting securely in the
HoverSling® Split-Leg before transferring or lifting.
• Never lift a patient higher than is necessary to complete the
lift/transfer.
• Never leave the patient unattended while using the HoverSling.
• Use the HoverSling according to both the lift and HoverSling
instructions.
• If the weight limit diers among the patient lift, hanger bar,
and HoverSling, then the lowest weight limit applies.
WARNING: If using the HoverSling® Repositioning Sheet for bed to chair
transfer, the chair MUST be reclined. If the chair does not recline, then
using the HoverSling Repositioning Sheet is not recommended.
WARNING: If there is any indication of damage, remove the HoverSling
from service and discard.
WARNING: In the OR: To prevent the patient from slipping, always deflate the
HoverSling and secure the patient and HoverSling to the OR table prior to moving
the table into an angled position.
PRECAUTIONS AIR SUPPLY
• Route the power cord in a manner to ensure freedom from hazard.
Avoid blocking the air intakes of the air supply.
• When using the HoverSling in the MRI environment, a 25 ft. specialty
MRI hose is required (available for purchase).
• CAUTION: Avoid electric shock. Do not open air supply.
• Reference product specific user manuals for operating instructions.
2 | HoverTech International HSManual Rev. C
User Manual
Part Identification – HoverSling® Split-Leg
Patient Safety Strap (1)
(DO NOT USE TO TRANSFER)
Air Supply Hose Inlets (2)
Sling Support Straps (6)
(white, beige and blue color coded
straps for easy identification)
Lateral Transfer Handles (4)
Strap Pockets (6)
Label Includes Model #,
Serial #, and Instructions for Use.
Product Specifications/Required Accessories
HOVERSLING SPLITLEG®
Material:
Construction: Sewn
Width:
Length: 75" (190 cm) inflated
Model #: HMSLING-34 – 34" W x 75" L (10 per box)
Model #: HMSLING-34-B* – 34" W x 75" L (10 per box)
WEIGHT LIMIT 700 LBS/ 318 KG
Model #: HMSLING-39 – 39" W x 75" L (5 per box)
Model #: HMSLING-39-B* – 39" W x 75" L (5 per box)
Model #: HMSLING-50 – 50" W x 75" L (5 per box)
Model #: HMSLING-50-B* – 50" W x 75" L (5 per box)
WEIGHT LIMIT 1000 LBS/ 454 KG
*Breathable model
Top: Polyester knit
Bottom: Nylon Twill
34" (86 cm) inflated
39" (99 cm) inflated
50" (127cm) inflated
REQUIRED ACCESSORY FOR USE
AS A TRANSFER MATTRESS:
Model #: HTAIR1200 (North American Version) – 120V~, 60Hz, 10A
Model #: HTAIR2300 (European Version) – 230V~, 50 Hz, 6A
Model #: HTAIR1000 (Japanese Version) – 100V~, 50/60 Hz, 12.5A
Model #: HTAIR2356 (Korean Version) – 230V~, 50/60 Hz, 6A
Model #: AIR200G (800 W) – 120V~, 60Hz, 10A
Model #: AIR400G (1100 W) – 120V~, 60Hz, 10A
REQUIRED ACCESSORY FOR USE AS A SLING:
Any patient lift with 2, 3, or 4-point loop style hanger bars intended for
use with:
• Mobile hoists with sling seats
• Hoist trolleys
• Stationary hoists fixed to the wall/walls, floor and/or ceiling
• Stationary free-standing hoists
HSManual Rev. C www.HoverMatt.com | 3
User Manual
HoverSling® Split-Leg Instructions for Use as a Transfer Mattress
1. Ensure sling support straps are stowed in strap pockets and the four
(4) snaps located at the center leg and foot sections are connected.
2. Patient should preferably be in a supine position.
3. Place HoverSling Split-Leg underneath patient using a log-rolling
technique and secure patient safety strap loosely.
4. Plug the HoverTech Air Supply power cord into an electrical outlet.
5. Insert the hose nozzle into one of two hose entries at foot end of
HoverSling Split-Leg and snap into place.
6. Ensure that transfer surfaces are as close as possible and lock all
wheels.
7. If possible, transfer from a higher surface to a lower surface.
8. Turn on HoverTech Air Supply.
9. Push inflated HoverSling Split-Leg at an angle, either headfirst or feetfirst. Once half-way across, opposite caregiver should grasp closest
handles and pull to desired location.
10. Ensure patient is centered on receiving equipment prior to deflation.
11. Turn o Air Supply and employ the bed/stretcher rails. Unbuckle
patient safety strap.
NOTE: When using the 50” HoverSling Split-Leg, two air supplies may be
used for inflation.
HoverSling® Split-Leg Instructions for Use as a Sling
INSTRUCTIONS FOR USE PATIENT IN BED
Note: HoverSling Split-Leg has six (6) sling support straps that need to be
attached.
1. Option 1– Place the HoverSling Split-Leg
underneath patient using log-rolling
technique with the apex of the sling’s
horseshoe at the coccyx of the patient.
Elevate the head of the bed.
Option 2 – Elevate the head of the bed.
Lean patient forward and slide sling
behind patient’s back until the apex of
the horseshoe reaches the coccyx of the
patient. Have patient lean back to hold
sling in place.
3. Attach outside leg support straps to hanger
bar.
2. Release inside leg snaps. Cross inside leg
support straps by taking one leg support
strap and passing it through the other on
the opposite side. Attach inside leg supports to hanger bar.
4 | HoverTech International HSManual Rev. C
4. Attach shoulder straps to the hanger bar
for the proper safety and comfort of the
patient. [Color coded strap loops provide
easy identification to match strap placement
on the left and right side of the patient.
Shorter strap loops at shoulder (blue/
beige) create a more upright sitting position, while longer shoulder and leg strap
loops (white) increase recline angle and
reduce hip flexion].
