Hoshizaki FH2-SSB User Manual

Hoshizaki

“A Superior Degree

of Reliability”

www.hoshizaki.com

Models

FH2-SSB(-HD)

Commercial Freezers
TempGuard Series

Hoshizaki America, Inc.

Number: 71230
Issued: 3-8-1999
Revised: 9-3-2008

PARTS LIST

®

CONTENTS

Auxiliary Codes ...................................................................................................................... 3

Note About Ordering Parts .................................................................................................... 3

Material Abbreviations ........................................................................................................... 4

A. Reach-In ............................................................................................................................ 5

FH2-SSB(-HD) .................................................................................................................. 5

B. Refrigeration System ......................................................................................................... 8

FH2-SSB(-HD) .................................................................................................................. 8

C. Control Panel Assembly .................................................................................................. 11

FH2-SSB(-HD) ................................................................................................................ 11

D. Body-Final ....................................................................................................................... 12

FH2-SSB ......................................................................................................................... 12

FH2-SSB-HD ................................................................................................................... 15

E. Panel-Front Hinged Assembly ......................................................................................... 18

FH2-SSB(-HD) ................................................................................................................ 18

F. Label Location .................................................................................................................. 19

FH2-SSB(-HD) ................................................................................................................ 19

G. Evaporator Fan Shroud Assembly .................................................................................. 20

FH2-SSB(-HD) ................................................................................................................ 20

H. Evaporator Assembly ...................................................................................................... 21

FH2-SSB(-HD) ................................................................................................................ 21

J. Condenser Assembly ....................................................................................................... 23

FH2-SSB(-HD) ................................................................................................................ 23

K. Control Box Assembly ..................................................................................................... 26

FH2-SSB ......................................................................................................................... 26

FH2-SSB-HD ................................................................................................................... 28

KK. Common Control Box .................................................................................................... 30

FH2-SSB(-HD) ................................................................................................................ 30

L. Body-Prefinal ................................................................................................................... 32

FH2-SSB(-HD) ................................................................................................................ 32

M. Door-Right ...................................................................................................................... 34

FH2-SSB ......................................................................................................................... 34

N. Door-Left ......................................................................................................................... 36

FH2-SSB ......................................................................................................................... 36

P. Mullion-Vertical ................................................................................................................. 38

FH2-SSB ......................................................................................................................... 38

Q. Door-Half (UR) ................................................................................................................ 40

FH2-SSB-HD ................................................................................................................... 40

R. Door-Half (LR) ................................................................................................................. 41

FH2-SSB-HD ................................................................................................................... 41

S. Door-Half (UL) ................................................................................................................. 42

FH2-SSB-HD ................................................................................................................... 42

T. Door-Half (LL) .................................................................................................................. 43

FH2-SSB-HD ................................................................................................................... 43

U. Mullion-Cross .................................................................................................................. 44

FH2-SSB-HD ................................................................................................................... 44

V. Literature & Packaging ..................................................................................................... 46

FH2-SSB(-HD) ................................................................................................................ 46

2

Auxiliary Codes

FH2-SSB H-0 October 1998

J-0 December 1998
J-1 September 1999
J-2 October 1999

L-5 March 2001
M-5 February 2002
M-6 March 2002
M-7 September 2002
N-5 December 2002
N-6 January 2003
P-5 March 2004
P-6 August 2004
Q-5 December 2004

FH2-SSB-HD J-1 October 1999

L-5 April 2001
M-6 March 2002
M-7 August 2002
N-6 January 2003
P-5 December 2003
P-6 August 2004
Q-5 December 2004

Auxiliary Code Breakdown

K-5
Designates the year. "K" indicates the year 2000. Years progress or regress in alphabetical order.
"J" is 1999, "L" is 2001, "M" is 2002, and so on. The letters "I" and "O" were skipped.
Designates significant part changes within the same year for this model. Base is 5 (0 for auxiliary
codes prior to L) and this number advances for each change.

Example: P-6
"P" indicates 2004.
"6" indicates the first significant part change for 2004.

Note About Ordering Parts

Most assemblies cannot be ordered as complete units; parts in the assemblies generally must be ordered
separately.

3

Material Abbreviations

ALUMINUM
AL = Aluminum

COPPER
CU = Copper

PLASTIC

ABS = Acrylonitrile -butadiene - styrene
AC = Polyacetal
EVA = Ethylene vinyl acetate
PA = Polyamide = Nylon
PC = Polycarbonate
PE = Polyethylene
PES = Polyester
PETP = Polyethylene terephthalate = Tetlon
PP = Polypropylene
PS = Polystyrene
PTFE = Polytetrafluoroethylene = Teflon
PUR = Polyurethane
PVC = Polyvinyl chloride

RUBBER

VN = Vinyl Nitrile
EPDM = EP rubber
NBR = Nitrile butadiene rubber
NR = Natural rubber
NP = Neoprene
SI.R = Silicone rubber
SY.R = Synthetic rubber
EPH = Epichlorohydrin

STEEL

GS = Galvanized steel
SS = Stainless steel
PS = Plated steel
PAS = Primed steel

4

A. Reach-In

FH2-SSB(-HD)

H-0, J-0, J-1, J-2

F

4

4a 4b

B1 B2

B

5

1

3

C1

C

1a 1b

B3

5a 5b

2a 2b

2

2c

D

5

A. Reach-In

FH2-SSB(-HD)

L-5, M-5, M-6, M-7, N-5, N-6, P-5, P-6, Q-5

F

4

4a 4b

E1

E

E2 E3

C

C1

B1 B2

B

9a

9

10

8a

8

7

6

1

1a

1b

B3

5b

5

11a

11

2

2a 2b

2c

D

6

Title: A. Reach-In Model: FH2-SSB(-HD)

Index

No. Description

Material or
Model Number Part Number

H-0

to

J-2

L-5

M-5

to

N-5

B Refrigeration System Freezer 1A0255A01 1 1 1 1

B1 Bolt Assembly 8×45 437889-01 6 6 6 6

Truss Head Screw 5×10, SS 7C32-0510 2 2 2 2

B2

B3 Washer 8 7W22-0800 2 2 2 2

C Control Panel Assembly - 2A1219A02 1 1 1 1

C1 T2 Screw 4×8, SS 7P32-0408 7 7 7 7

D Body-Final

FH2-SSB

FH2-SSB-HD

2A1215A02 1 -

2A1215A06

1 1 1

1A0370A01 1 -

1A0370A04 1 1 1

E Panel-Front Hinged Assembly - 2A2011A02 1 1 1

E1 Clevis Pin - 8907-0102 2 2 2

Cotter Pin - 8907-0103 2 2 2

E2

E3 Flat Washer 4A0655-03 2 2 2

F Label Location

FH2-SSB

FH2-SSB-HD

3A0603G01 1 1 1 1

3A0603G04 1 1 1 1

Required Number

N-6

to

Q-5

1 Gusset-Side Top GS 3A1006-01 1 -

Gusset-Frame 4A2845-01 1 1 1

1a T2 Screw 4×8, SS 7P32-0408 2 4 4 4

1b Truss Head Screw 5×10, SS 7C32-0510 2 -

2 Panel-Side, Top

Insert-Threaded M5 4A0407-01 10 4 4 4

2a

Taper Collar SS 4H0171-01 4 4 4 4

2b

Screw Countersunk 5×20,SS 7C42-0520 4 4 4 4

2c

SS 2A0615-02 2 -

2A1800-01

2 2 2

3 Panel - Front SS 1A0040-01 1 -

See "E" above

4 Cover-UL, Top GS 2A1118-01 1 -

2A1118-03

1 1 1

4a Truss Head Screw 5×10, SS 7C32-0510 3 -

4b T2 Screw 4×8, SS 7P32-0408 2 5 5 5

5 Cover-UL, Rear GS 2A1117-01 1 1 1 1

5a Truss Head Screw 5×10, SS 7C32-0510 2 -

5b T2 Screw 4×8, SS 7P32-0408 3 5 5 5

6 Power Cordset - 4A1543-01

Shown on

assy K

1 1 1

7 Bushing SB-625-8 420470-01 1

8 Wire Clamp - 4A0809-03 1 1 1

8a T2 Screw 4×8,SS 7P32-0408 1 1 1

9 Spacer-Hinge 4A2473-01 2 2 2

9a Countersunk Screw 5×20, SS 7C42-0520 2 2 2

10 Bracket-Hinge 4A2306-01 2 2 2

11 Frame-Side Top GS 2A1803-01 2 2 2

11a Truss Head Screw 5×10,SS 7C32-0510 8 8 8

7

B. Refrigeration System

FH2-SSB(-HD)

H-0, J-0, J-1, J-2, L-5, M-5, M-6, M-7, N-5, N-6, P-5, P-6, Q-5

1

1a 1b

K

K1

H

H1

8

G

G1

19

1c 1d

18

17

1e

23

22a

22

5

2e

2c

2f

2a 2b

2

2d

7

16a

16

4

13a

13

15a

15

14

12

21

21a

J1

J

6

20

9

11

8

3

10

Title: B. Refrigeration System Model: FH2-SSB(-HD)

Required Number

J-0

H-0

to

J-2

Index

No. Description

G Evap Fan Shroud Assembly - 3A0263G01 1 1 1 1 -

G1 Truss Head Screw 4x16, SS 7C32-0416 4 4 4 4 4

H Evaporator Assembly - 2A1015A01 1 1 1 1 1

H1 T2 Screw 4×8, SS 7P32-0408 2 2 2 2 2

J Condenser Assembly - 3A1138A01 1 1 -

J1 T2 Screw 4×8, SS 7P32-0408 4 4 4 4 4

K Control Box Assembly - 2A1206A01 1 1 1 1 1

K1 Truss Head Screw 4×16,SS 7C32-0416 4 4 4 4 4

1 Cover-Evap Case - 2A0245G01 1 1 1 1 1

1a Hex Head Bolt 1/4-20×3.25” 7C11I1432 4 -

1b Washer Flat 4A0521-02 4 -

1c Draw Latch 97-50-224-11 4A1710-01 4 4 4 4

1d Truss Head Screw 4×16,SS 7C32-0416 4 4 4 4

1e T2 Screw 4×8, SS 7P32-0408 8 8 8 8

2 Compressor RS80C1E-

Grommet EPDM 434403-01 4 4 4 4 4

2a

Spacer Tecumseh

2b

Hex Bolt 8×45 7B01-0845 4 4 4 4 4

2c

Washer-Flat 8 7W21-0800 4 4 4 4 4

2d

Split Lock Washer 8 7L21-0800 4 4 4 4 4

2e

Protector 071-0518-06 4A1877-05 1 1 1 1 1

2f

3 Switch-Pressure 4A2516-02 Shown on

4 Drier Sporlan CW-

5 Thermistor-Cabinet Taiko 4A1429 4A1429-02 1 1 -

6 Filter-Condenser - 3A0277-01 1 1 -

7 Thermostat-Clean Filter - 4A0965-01 1 1 1 1 1

8 Seal-Evap Tubing Neoprene/

9 Fitting-Drain Overflow PP 4A0664-01 1 1 -

10 Washer-Drain Overflow Rubber 4A0665-01 1 1 -

Rubber Gasket 413854-03 1 1 1

11 Nut-Drain Fitting Heyco 8463 4A0666-01 1 1 -

Gasket - Cond. Coil - 4A0455-01 1 1 1 1 1

12

13 Divider Air UL GS 3A1297-02 1 1 1 -

13a T2 Screw 4×8, SS 7P32-0408 4 4 4 4 4

Material or
Model Number Part Number

3A0263G02

3A0585A01 1 1 1

4A1346-01 1 1 1 1 1

CAA-219

434404-01 4 4 4 4 4

70459

assembly J

4A0924-01 1 1 1 1 1

052-S

- 4A1429-01 1 1 1

3A0277-02

3A0972-01 2 2 2 2 2

EPDM

- 4A2182-01 1 1 1

3A1297-01

M-5

to

L-5

P-5

1 1 1

1 1 1

1 1

P-6
Q-5

1

9

Title: B. Refrigeration System Model: FH2-SSB(-HD)

Required Number

J-0

H-0

to

J-2 L-5

Index

No. Description

14 Pan - Evap. Drain - 2A0200-01 1 1 -

15 Strap - Condensate Coil - 3A0413-01 1 1 -

15a Truss Head Screw 5×10, SS 7C32-0510 1 1 1 1 1

16 Drier Bracket - 4A0806-01 1 1 1 1 1

16a T2 Screw 4×8, SS 7P32-0408 2 2 2 2 2

17 Expansion Valve - 4A0922-01 1 1 1 1 1

18 Exp. Valve Cover (A) - 3A0372-01 1 1 1 1 1

19 Exp. Valve Cover (B) - 3A0372-02 1 1 1 1 1

Coil - Condensate - 2A1856-01 1 1 1

20

Heater - Drain - 4A2975-01 1

21

Nylon Tie CV-200 8911-0200 2

21a

22 Thermistor Bracket (A) ABS 433964-01 1 1 1 1 1

Truss Head Screw 4×16, SS 7C32-0416 2 2 2 2 2

22a

Thermistor Bracket (B) ABS 433920-01 1 1 1 1 1

23

Material or
Model Number Part Number

2A0200-02

3A0413-03 1 1 1

M-5

to

P-5

1 1 1

P-6
Q-5

10

C. Control Panel Assembly

FH2-SSB(-HD)

H-0, J-0, J-1, J-2, L-5, M-5, M-6, M-7, N-5, N-6, P-5, P-6, Q-5

5a

5

7

4a44b

6a

6

2a

2

3

Title: C. Control Panel Assembly Model: FH2-SSB(-HD)

H-0

L-5

Index

No. Description

1 Panel-Control (Painted)

Panel-Control SS 1A0835-01 1

2 Board-Display 2A0883-01 1 1 1

2a

Ribbon Cable 4A1106-02 1 1 1

3 Label-Display PC 4A1558-02 1 1 -

4 Mount-Display Board PC 3A0823-01 1 1 1

4a Palnut 4A1398-01 6 6 6

4b Nylon Screw 4A1397-01 4 4 4

5 Control Panel Cover GS 3A0559-01 1 1 1

5a T2 Screw 4×8, SS 7P32-0408 2 2 2

6 Board Cover GS 3A1046-01 1 1 1

6a T2 Screw 4×8, SS 7P32-0408 2 2 2

7 Locking Hole Plug 4A0586-03 4 4 4

Material or
Model Number Part Number

3A1047G01 1 -

1A0626G01

3A2850-02

to

J-2

to

N-6

1 -

1

7

Required Number

P-5

to

Q-5

1

11

D. Body-Final

FH2-SSB

H-0, J-0, J-1, J-2

L

P

N

M

11

10

6

6

3

2

7a

7

1

4

8a

8

12

4

1

8

5

12

8a

4

5

10

4

9

7a

7

D. Body-Final

FH2-SSB

L-5, M-5, M-6, M-7, N-5, N-6, P-5, P-6, Q-5

P

L

N

M

11

6

6

3

2

14a

14

1

4

13a

13

13

4

1

10

12

10

9

7a

8a

8

7

Title: D. Body-Final Model: FH2-SSB

H-0

Index

No. Description

L Body Prefinal

M Door Right

N Door Left 1A0318A02 1 -

P Mullion Vertical 2A1289A01 1 -

Material or
Model Number Part Number

2A1207A01 1 -

2A1207A06

1A0318A01 1 -

1A0318A03 1

1A0318A04 1

2A1289A05

to

J-2

Required Number

L-5

to

Q-5

1

1

1 Hinge Stop Pin

2 Hinge Tension Screw 4A0446-01 2 2

3 Hinge Bushing Cover 4A0445-01 2 2

4 Hinge Lock Washer 4A0553-01 4 2

5 Hinge Pivot Pin (Btm) 4A0443-01 2 -

6 Hinge Pivot Pin (Top)

7 Bracket Door Hinge (UL,LR) Use latest for

Bracket Door Hinge (LR) 3A1626-01 1

7a Countersunk Screw 5×20, SS 7C42-0520 6 3

8 Bracket Door Hinge (LL,UR) Use latest for

Bracket Door Hinge (LL) 3A1627-01 1

8a Countersunk Screw 5×20, SS 7C42-0520 6 3

9 Hinge Stop Plate (Right) 4A0441-01 1 1

10 Screw Stop Plate 4A0483-01 2 2

11 Cover Corner 3A0221-01 8 -

Hinge Stop Plate (Left) 4A0441-02 1 1

12

13 Bracket Door Hinge (UR) 3A1580-01 1

13a Countersunk Screw 5×20, SS 7C42-0520 3

14 Bracket Door Hinge (UL) 3A1581-01 1

14a Countersunk Screw 5×20, SS 7C42-0520 3

all aux. codes

all aux. codes

4A0444-01 2 -

4A2180-01

4A0442-01 2 -

4A2179-01

3A0209-01 2 -

3A0215-01 2 -

3A1751-01 8

2

2

14

D. Body-Final

FH2-SSB-HD

J-1

S

L

U

Q

3

2

11

T

R

10

6

6

4

1

4

7a

7

8a

8

1

12

8a

8

4

5

10

9

7

7a

4

5

10

12

8

8a

13

4

14

10

9

7

7a

13

4

14

15

D. Body-Final

FH2-SSB-HD

L-5, M-6, M-7, N-6, P-5, P-6, Q-5

S

Q

L

U

16

T

16a

R

3

2

11

10

12

6

6

4

1

4

15a

15

1

10

12

8

8a

10

15

15a

9

13

7

7a

4

14

10

9

16

16a

13

4

14

16

Title: D. Body-Final Model: FH2-SSB-HD

Index

No. Description

L Body Prefinal

Q Door Half (UR)

R Door Half (LR)

S Door Half (UL)

T Door Half (LL)

U Mullion-Cross

Material or
Model Number Part Number

M-6

J-1 L-5

2A1347A01 1 -

2A1347A04

1A0326A01 1 1 -

1A0326A03

1A0324A01 1 1 -

1A0324A03

1A0324A02 1 1 -

1A0326A04

1A0326A02 1 1 -

1A0326A04

2A1350A01 1 -

2A1350A04

Q-5

1 1

1

1

1

1

1 1

Required Number

to

1 Hinge Stop Pin

2 Hinge Tension Screw 4A0446-01 4 4 4

3 Hinge Bushing Cover 4A0445-01 4 4 4

4 Hinge Lock Washer 4A0553-01 6 4 4

5 Hinge Pivot Pin (Btm) 4A0443-01 2 -

6 Hinge Pivot Pin (Top)

7 Bracket Door Hinge (UL,LR) 3A0209-01 3 -

Bracket Door Hinge (LR) 3A1626-01 1 1

7a Countersunk Screw 5×20, SS 7C42-0520 9 3 3

8 Bracket Door Hinge (LL,UR) 3A0215-01 3 -

Bracket Door Hinge (LL) 3A1627-01 1 1

8a Countersunk Screw 5×20, SS 7C42-0520 9 3 3

9 Hinge Stop Plate (R) 4A0441-01 2 2 2

10 Screw Stop Plate 4A0483-01 4 4 4

11 Cover Corner

Hinge Stop Plate (L) 4A0441-02 2 2 2

12

13 Stop Pin 4A1734-01 2 2 2

14 Pivot Pin 4A1735-01 2 2 2

15 Bracket Door Hinge (UR) 3A1580-01 2 2

15a Countersunk Screw 5×20, SS 7C42-0520 6 6

16 Bracket Door Hinge (UL) 3A1581-01 2 2

16a Countersunk Screw 5×20, SS 7C42-0520 6 6

4A0444-01 2 -

4A2180-01

4A0442-01 2 -

4A2179-01

3A0221-01 16 -

3A1751-01 16 16

2 2

2 2

17

E. Panel-Front Hinged Assembly

FH2-SSB(-HD)

L-5, M-5, M-6, M-7, N-5, N-6, P-5, P-6, Q-5

1

2

3a

3

Title: E. Panel-Front Hinged Assembly Model: FH2-SSB(-HD)

Index

No. Description

1 Hinge – Front Panel (L) GS 4A2153-01 1

2 Hinge – Front Panel (R) GS 4A2154-01 1

3 Channel – Hinge GS 4A2170-01 2

3a Truss Head Screw 5×8, SS 7C32-0508 4

4 Panel – Front SS 1A0624-02 1

Material or
Model Number Part Number

4

Required Number

L-5

to

Q-5

18

F. Label Location

FH2-SSB(-HD)

H-0, J-0, J-1, J-2, L-5, M-5, M-6, M-7, N-5, N-6, P-5, P-6, Q-5

1

9

5

2

3

VIEW A

7

Title: F. Label-Location Model: FH2-SSB(-HD)

Index

No. Description

1 Label-Penguin-HA(L) - 4A0526-02 1 1

2 Emblem-Hoshizaki - 4A0560-01 1 1

3 Label – Door Heater Switch PVC FILM 4A1039-01 1 1

4 Caution Label PVC FILM 4A1931-01 1 1

5 Wiring Diagram PVC FILM 2A2343-01 1 1

6 Label – R404A - 4A0960-01 1 1

7 Label – Power - 4A0522-01 1 1

8 Label – Display Info - 3A1413-01 1 1

9 Cover-Nameplate - 4A3727-01 1

8

Material or
Model Number Part Number

H-0

to

P-6 Q-5

4

6

Required Number

19

G. Evaporator Fan Shroud Assembly

FH2-SSB(-HD)

H-0, J-0, J-1, J-2, L-5, M-5, M-6, M-7, N-5, N-6, P-5, P-6, Q-5

2

8

1a

1

4

3a33b

9

7

6a

6

5

4a

Title: G. Evaporator Fan Shroud Assembly Model: FH2-SSB(-HD)

H-0

L-5

Index

No. Description

1 Blade-Fan Pusher

1a Hex Nut 4A1345-01 1 1 1

2 Motor-Evap Fan

3 Orifice - Evap Fan SS 4A0412-01 1 1 1

3a T2 Screw 4×8, SS 7P32-0408 3 3 3

3b Lock Washer - 4A0459-01 3 3

4 Shroud - Evap SS 1A0100-01 1 1 -

4a Truss Head Screw 4×16, SS 7C32-0416 4 4 4

5 Bracket - Heater Supply - 3A3243-01 1

6 Heater - Glass Tube - 3A2335-02 1

6a T2 Screw 4×8, SS 7P32-0408 2

7 Wire Tie (Twist) - 4A1223-01 4

8 Bushing - 428394-02 2

9 Nylon Tie CV-100 8911-0100 4

Material or
Model Number Part Number

Air Drive
AD9CCW30UBA

Morri
PSC4BE9BEA1

3A0438-01 1 1 1

4A0413-01 1 1 1

1A0100-02

to

J-2

to

P-5

Required Number

P-6

Q-5

1

20

H. Evaporator Assembly

FH2-SSB(-HD)

H-0, J-0, J-1, J-2, L-5, M-5, M-6, M-7, N-5, N-6, P-5, P-6, Q-5

9

8

5 5a

6

2 2a

4

7a

7

1

3

3a

These additional parts added to FH2-SSB(-HD) Evaporator Assembly at aux. code M-6

11

10

12

21

13

Title: H. Evaporator Assembly Model: FH2-SSB(-HD)

H-0

M-6

to

M-5

to

P-5

Index

No. Description

1 Evaporator - 2A0636-01 1 1 1

2 Bracket-Evap Shroud(R) SS 4A0545-01 1 1 -

2a T2 Screw

3 Bracket-Evap Shroud(L) SS 4A0548-01 1 1 -

3a T2 Screw 4×8, SS 7P32-0408 2 2 -

4 Heater – Defrost - 3A0591-01 1 1 1

5 Thermostat – Defrost - 4A0954-02 1 1 1

5a T2 Screw 4×8, SS 7P32-0408 2 2 2

6 Bushing - 420470-01 1 1 1

7 Thermistor – Defrost - 4A1428-01 1 1 1

7a Thermistor – Clip - 320418-01 1 1 1

8 “Y” Joint - 4A1687-03 1 1 1

9 “Y” Joint - 4A1687-02 1 1 1

10 Clip – Support Evap (A) - 4A2826-01 1 1

11 Clip – Support Evap (B) - 4A2827-01 1 1

Clip – Support Evap (C) - 4A2828-01 2 2

12

13 Shield – Heat - 3A1853G01 1 1

Material or
Model Number Part Number

4×8, SS 7P32-0408 2 2 -

Required Number

P-6

Q-5

Installation Instructions for Parts 10, 11, 12, & 13

1. The original heat shield must be removed. This can be done by lifting the evaporator up and

sliding the heat shield out.

2. The new heat shield (part #13) is then installed in the rotocast drain pan.

3. The clips are then slid onto the end plate on the evaporator. Support clips (part #12) are

installed onto the hairpin end of the evaporator as shown in the illustration.

4. The other support clips (parts #10 and #11) are installed on the return bend end (same side
as inlet andoutlet tubes) as shown in the illustration.

NOTE: All clips are shown in the illustration in the correct orientation for installation. The

parts are slid onto the evaporator bracket using the tab on the support clip.

22

J. Condenser Assembly

FH2-SSB(-HD)

H-0, J-0, J-1, J-2

5

4

11a

11

2a

2

12a

12

13a

13

14a

14

6a

6

7

3

3a

10

8a

8

23

9

1

J. Condenser Assembly

FH2-SSB(-HD)

L-5, M-5, M-6, M-7, N-5, N-6, P-5, P-6, Q-5

5

4

3

3a

8a

8

2a

2

1

6a

6b

24

14

14a

9

Title: J. Condenser Assembly Model: FH2-SSB(-HD)

Required Number

L-5

Index

No. Description

Material or
Model Number Part Number

H-0 J-0 J-1 J-2

to

P-5

1 Condenser 973803 2A0638-01 1 1 1 1 1 1

2 Shroud Condenser GS 2A0639-02 1 -

2A1491-01

2a T2 Screw 4×12, SS 7P32-0412

1 1 1 1 1

8 8 8 8 8 8

3 Fan Motor SP-B16EM1 4A0815-01 1 -

U90B1 FASCO 440911-01 1 1 1 1 -

GE
5KCP84DFK148S

4A3158-01 1

3a Self Locking Nut 4×8 7N21I0832 4 4 4 4 4

4 Fan Blade (Puller) Air Drive

AD9CW38UBA

Air Drive

3A0608-01 1 -

4A1865-01 1 1 1 1 1

AD10CCW32

5 Hex Nut 1/4”-20 Zinc 4A1345-01 1 1 1 1 -

6 Bracket-Condenser Fan GS 3A0457-01 1 -

3A1298-01

2A1668-01

1 1 -

1 1 1

6a Hex Bolt 6×25 4 -

Truss Head Screw 5×12, SS 7C32-0512 4 4 4 4 4

7 Well Nut D1420 4A0422-01 2 -

8 Retainer-Filter GS 4A0929-01 1 1 1 1 -

4A2138-01

1 1

8a T2 Screw 4x8, SS 7P32-0408 2 2 2 2 2 2

9 Base - Condenser - 2A1217-01 1 1 1 1 1 1

10 Switch-Pressure 20PS025WT

3A0335-03 1 1 -

450K320K

D94V
20PSO24W

3A0335-02 1 1 Shown on

assembly B

T500K330K

11 Bracket-Press Switch GS 4A0552-01 1 1 1 1 -

11a T2 Screw 4×8 7P31-0408 1 1 1 1 -

Bracket-Press Switch (B) GS 4A1565-01 1 1 1 1 -

12

12a T2 Screw

4×8 7P31-0408 2 2 2 2 -

13 Thermostat- Defrost Backup Ranco 4A1344-01 1 1 1 1 -

13a T2 Screw 4×8 7P31-0408 2 2 2 2 -

14 Capacitor-Fan

5MFD, 250VAC

443192-02 1 1 1 1 1 1

14a T2 Screw 4×8, SS 7P32-0408 1 1 1 1 1 1

P-6
Q-5

25

K. Control Box Assembly

FH2-SSB

H-0, J-0, J-1, J-2, L-5, M-5, M-6, M-7, N-5, N-6, P-5, P-6, Q-5

3

7a

7

3a

1

2

KK

5

8a

8

9

6a

6

4

26

Title: K. Control Box Assembly Model: FH2-SSB

J-0

Index

No. Description

KK Common Control Box - 2A1147A01 1 1 1 1

1 Capacitor-Run 25MFD,

2 Capacitor-Start 88-106MFD,

3 Starter

3a T2 Screw 4×8, SS 7P32-0408 1 1 1 1

4 Power Cordset - 4A1543-01 1 1 Shown on

5 Grounding Screw M5 433304-02 1 1 1 1

6 Wire Clamp - 4A0809-02 1 1 -

6a T2 Screw 4×8, SS 7P32-0408 1 2 -

7 Strap GS 434580-14 1 1 1 1

7a T2 Screw 4×8, SS 7P32-0408 1 1 1 1

8 Mount Bracket

8a T2 Screw 4×8, SS 7P32-0408 2 2 2 2

9 Bushing 420470-01 1 1 -

Material or
Model Number Part Number

439943-02 1 1 1 -

370VAC

330VAC

3ARR3CT3S5

3ARR3KC24S5

GS 4A0809-03 1 1 -

3A2005-06

3A0076-07 1 1 1 1

434172-01 1 -

4A1107-13 1 1 1

4A1876-01 1 1

H-0

to

J-2 L-5

assembly A

Required Number

M-5

to

Q-5

1

27

K. Control Box Assembly

FH2-SSB-HD

J-1, L-5, M-6, M-7, N-6, P-5, P-6, Q-5

3a

3

7a

7

1

2

KK

5

8a

8

9

6a

6

4

28

Title: K. Control Box Assembly Model: FH2-SSB-HD

M-6

Index

No. Description

KK Common Control Box - 2A1147A01 1 1 1

1 Capacitor-Run 25MFD,

2 Capacitor-Start 88-106MFD,

3 Starter

3a T2 Screw 4x8, SS 7P32-0408 1 1 1

4 Power Cordset - 4A1543-01 1 1 Shown on

5 Grounding Screw M5 433304-02 1 1 1

6 Wire Clamp - 4A0809-02 1 1 -

6a T2 Screw 4x8, SS 7P32-0408 1 1 -

7 Strap GS 434580-14 1 1 1

7a T2 Screw 4x8, SS 7P32-0408 1 1 1

8 Mount Bracket GS 4A1876-01 1 1 1

8a T2 Screw 4x8, SS 7P32-0408 2 2 2

9 Bushing 420470-01 1 1 -

Material or
Model Number Part Number

439943-02 1 1 -

370VAC

330VAC

3ARR3CT3S5

3ARR3KC24S5

3A2005-06

3A0076-07 1 1 1

434172-01 1 -

4A1107-13 1 1

J-1 L-5

to

Q-5

1

assembly A

Required Number

29

KK. Common Control Box

FH2-SSB(-HD)

H-0, J-0, J-1, J-2, L-5, M-5, M-6, M-7, N-5, N-6, P-5, P-6, Q-5

4a

4

7

18 19

20

16

21

24

17

22

24a

23

8

13

26

10a

10

11

9

5a

5

1

3

12

2

25a

25

6

15

14

30

Title: KK. Common Control Box Model: FH2-SSB(-HD)

H-0

L-5

M-7

to

to

Index

No. Description

1 Board – Control Use latest for

2 Board Support NYLON 4A0336-03 6 6 6 6

3 Base – Control Box GS 2A1146-01 1 1 1 1

4 Cover – Control Box GS 2A1031-01 1 1 1 1

4a T2 Screw 4x8, SS 7P32-0408 2 2 2 2

5 Switch – Bracket GS 2A1032-01 1 -

5a T2 Screw 4x8, SS 7P32-0408 2 2 2 2

6 Bushing SB-1093-15 420470-03 1 1 1 1

7 Bushing SB-625-8 420470-01 1 1 1 1

8 Switch – Toggle 7802K21 4A0424-01 1 1 1 1

9 Switch – Rocker 1801 1102 4A0418-01 1 1 1 1

10 Terminal Block ESB1-6-8 4A1540-01 1 1 -

10a Tapping Screw 3x8 431415-01 1 1 1 1

11 Board Connector 5198-10 434003-05 1 1 1 1

Board Connector 5198-07 434003-07 1 1 1 1

12

13 Board Connector 5198-03 434003-11 1 1 1 1

14 Plug Housing (9 Pin) 3191-09P 412832-02 1 1 1 1

15 Receptacle Housing (9 Pin) 3191-09R1 412831-02 1 1 1 1

16 Plug Housing (6 Pin) 3191-06P 412832-03 1 1 1 1

17 Receptacle Housing (6 Pin) 3191-06R1 412831-03 1 1 1 1

18 Plug Housing 03-12-2036 4A0425-01 1 1 1 1

19 Receptacle Housing 03-12-1035 4A0426-01 1 1 1 1

Receptacle Housing (4 Pin) 3191-04R1 412831-05 1 1 1 1

20

Plug Housing (4 Pin) 3191-04P 412832-05 1 1 1 1

21

22 Receptacle Housing (2 Pin) 3191-02R1 412831-07 1 1 1 1

23 Plug Housing (2 Pin) 3191-02P 412832-07

Transformer 26D285H 3A0172-01 1 -

24

Tapping Screw 3x8 431415-01 2 2 2 2

24a

Compressor Relay HE1aN-

25

25a Tapping Screw 3x8 431415-01 2 2 2 2

Board Connector 5198-03 434003-09 1 1 1

26

Material or
Model Number Part Number

2A0882-01 1 -

all aux. codes

ESB2-323-424 4A2619-01

F4-10 3A1759-01 1 1 1

AC120V

2A1854-01

2A2862-21

2A1032-02

4A1307-01 1 1 1 1

J-2

1 1 1 1

to

M-6

P-5

1 1 -

1 1 1

1 1

Required Number

P-6
Q-5

1

31

L. Body-Prefinal

FH2-SSB(-HD)

H-0, J-0, J-1, J-2, L-5, M-5, M-6, M-7, N-5, N-6, P-5, P-6, Q-5

5

1

4a

4

5

6

3a

3

2a

2

32

Title: L. Body-Prefinal Model: FH2-SSB(-HD)

Index

No. Description

1 Cabinet Prefoam

2 Distributor-Air (Bottom) SS 1A0143-01 1 1 1 -

2a T2 Screw

3 Pilaster SS 3A0145-01 6 6 6 6

3a Truss Head Screw 5x10,SS 7C32-0510 18 18 18 18

4 Distributor-Air Top Assembly ABS 1A0152-02 1 1 1 -

4a T2 Screw 4x8, SS 7P32-0408 7 7 7 -

5 Switch Door FH2-SSB

6 Vinyl Hose L=1700 7716-0913 1 -

Material or
Model Number Part Number

FH2-SSB

FH2-SSB-HD

4x10, SS 7P32-0410 2 2 2 2

Nylon

FH2-SSB-HD

Nylon

2A0706G01 1 1 1 -

2A0706G06

2A1346G01 1 1 -

2A1346G04

1A0512-01

1A0985-01 1

4A0487-01 2 -

3A1386-01 2 -

3A1826-01

3A1386-01 4 4 -

3A1826-01

7730I3812

H-0

J-0
J-1 J-2

2 2

1 1 1

Required Number

L-5

to

P-6 Q-5

1

1

1 -

4

33

M. Door-Right

FH2-SSB

H-0, J-0, J-1, J-2, L-5, M-5, M-6, M-7, N-5, N-6, P-5, P-6, Q-5

6

11

12

1

8

4

5

3

10

2

9

34

7a

7

Title: M. Door-Right Model: FH2-SSB

J-0

L-5

to

J-2

to

M-7

Index

No. Description

1 Door-Prefoam (R) - 1A0317G01 1 1 1 -

2 Lock-Tumbler M4-5813-001 4A0462-01 1 1 1 1

3 Lock-Stop Washer M5-8060-103 4A0458-01 1 1 1 1

4 Cam-Door Lock P.S 4A0228-01 1 1 1 1

5 Lock-Screw SS 4A0461-01 1 1 1 1

6 Gasket-Door Jarrow #P-

7 Stop-Door SS 4A0351-01 1 1 -

7a Screw-Countersunk 5X20, SS 7C42-0520 2 -

Truss Head Screw 5X25, SS 7C32-0525 2 -

8 Lock-Washer SS 4A0459-01 1 1 1 1

9 Lock-Key M5-0680-111 4A0460-01 1 1 1 1

10 Washer-Door Lock SS 4A0670-01 1 1 1 1

11 Hinge-Spring 4A3312-01 1 1 1 1

Hinge-Spring Cart 4A0438-01 1 1 1 1

12

Material or
Model Number Part Number

1A0317G03 1

3A0273-01 1 1 1 1
2209
244A Gray

H-0

Required Number

N-5

to

Q-5

35

N. Door-Left

FH2-SSB

H-0, J-0, J-1, J-2, L-5, M-5, M-6, M-7, N-5, N-6, P-5, P-6, Q-5

11 12

1

6

4

5

2

9

10

8

3

7a

7

36

Title: N. Door-Left Model: FH2-SSB

J-0

L-5

to

J-2

to

M-7

Index

No. Description

1 Door-Prefoam (L) - 1A0317G02 1 1 1 -

2 Lock-Tumbler M4-5813-001 4A0462-01 1 1 1 1

3 Lock-Stop Washer M5-8060-103 4A0458-01 1 1 1 1

4 Cam-Door Lock P.S 4A0228-01 1 1 1 1

5 Lock-Screw SS 4A0461-01 1 1 1 1

6 Gasket-Door Jarrow #P-

7 Stop-Door SS 4A0351-01 1 1 -

7a Screw-Countersunk 5X20, SS 7C42-0520 2 -

Truss Head Screw 5X25, SS 7C32-0525 2 -

8 Lock-Washer SS 4A0459-01 1 1 1 1

9 Lock-Key M5-0680-111 4A0460-01 1 1 1 1

10 Washer-Door Lock SS 4A0670-01 1 1 1 1

11 Hinge-Spring 4A3312-02 1 1 1 1

Hinge-Spring Cart 4A0438-02 1 1 1 1

12

Material or
Model Number Part Number

1A0317G04 1

3A0273-01 1 1 1 1
2209
244A Gray

H-0

Required Number

N-6

to

Q-5

37

P. Mullion-Vertical

FH2-SSB

H-0, J-0, J-1, J-2, L-5, M-5, M-6, N-5, N-6, P-5, P-6, Q-5

1

2a

2

4a

4

M-7 and later

7

8

3a

3

M-6 and earlier

The santoprene light socket was changed to
a porcelain lampholder at M-7. This change
is non-interchangeable. If the light socket is
not operating on a unit with a santoprene
light socket, Hoshizaki recommends
replacement with HS-3554.

HS2

HS2a

5

6a

6

6a

6

Note:

Parts 5, 6 and 6a are not included in
HS-3554; they are shown for reference only.

38

HS1

5

HS1a

Title: P. Mullion-Vertical Model: FH2-SSB

Required Number

Index

No. Description

Material or
Model Number Part Number

H-0

J-0

to

L-5

M-5
M-6

M-7

N-5

N-6

to

P-6 Q-5

1 Mullion-Prefoam - 2A1288G01 1 1 -

2A1288G05

1 1 1 1

2 Pilaster-Mullion SS 2A0205-01 2 2 2 -

2A0205-02

2 2 -

2A3246-01

Truss Head Screw 4×20 SS 7C32-0420 6 6 6 6 -

2a

5×10, SS 7C32-0510 6 6

3 Plate-Strike (Front) SS 4A0355-01 1 1 1 1 1 1

3a Truss Head Screw 4×8, SS 7C32-0408 1 1 1 1 1 1

4 Plate-Strike (Base) SS 4A0354-01 1 1 1 1 1 1

4a T2 Screw 4×8, SS 7P32-0408 2 2 2 2 2 2

5 Bulb-Light GE, 40A15 4A0437-01 1 1 1 -

- 4A2420-01 1 1 1

6 Shield-Light 2778-1010-

4A0465-01 1 1 1 1 1 1
3000

6a Truss Head Screw 5×10, SS 7C32-0510 2 -

Cheese Head Screw 5×12, SS 7C52-0512 2 2 2 2 2

7 Insert – Threaded Wide - 4A0839-01

8 Lampholder - 4A2862-01 1 1 1

Non­interchangeable
part change. If
light socket is not
operating for these
codes, Hoshizaki
recommends
replacement with
HS-3554 (below).

2 2 2

2

HS-3554-Lampholder Conversion Kit

Index

No. Description

Material or
Model Number Part Number

HS1 Plate-Lampholder Mount SS 4A2880-01 1

HS1a Cheese Head Screw SS 7C52-0512 2

Lampholder 4A2862-01 1

HS2

HS2a

Terminal-Flag DNFR18-

8101-18FJ 2

250FIBK

39

Required Number

M-6 and earlier

Q. Door-Half (UR)

FH2-SSB-HD

J-1, L-5, M-6, M-7, N-6, P-5, P-6, Q-5

6

11

12

1

5

8

4

3

10

7a

7

2

9

Title: Q. Door-Half (UR) Model: FH2-SSB-HD

L-5

Index

No. Description

1 Door-Prefoam (UR) - 1A0325G01 1 1 -

2 Lock-Tumbler M4-5813-001 4A0462-01 1 1 1

3 Lock-Stop Washer M5-8060-103 4A0458-01 1 1 1

4 Cam-Door Lock P.S 4A0228-01 1 1 1

5 Lock-Screw SS 4A0461-01 1 1 1

6 Gasket-Door(Half) Jarrow #P-

7 Stop-Door SS 4A0351-01 1 -

7a Truss Head Screw 5×25, SS 7C32-0525 2 -

8 Lock-Washer SS 4A0459-01 1 1 1

9 Lock-Key M5-0680-111 4A0460-01 1 1 1

10 Washer-Door Lock SS 4A0670-01 1 1 1

11 Hinge-Spring 4A3312-01 1 1 1

Hinge-Spring Cart 4A0438-01 1 1 1

12

Material or
Model Number Part Number

1A0325G03

3A0273-02 1 1 1
2209
244A Gray

J-1

to

M-7

Required Number

N-6

to

Q-5

1

40

R. Door-Half (LR)

FH2-SSB-HD

J-1, L-5, M-6, M-7, N-6, P-5, P-6, Q-5

6

4

3

10

11

12

5

8

2

9

Title: R. Door-Half (LR) Model: FH2-SSB-HD

L-5

Index

No. Description

1 Door-Prefoam (LR) - 1A0323G01 1 1 -

2 Lock-Tumbler M4-5813-001 4A0462-01 1 1 1

3 Lock-Stop Washer M5-8060-103 4A0458-01 1 1 1

4 Cam-Door Lock P.S 4A0228-01 1 1 1

5 Lock-Screw SS 4A0461-01 1 1 1

6 Gasket-Door (Half) Jarrow #P-

7 Stop-Door SS 4A0351-01 1 -

7a Truss Head Screw 5×25, SS 7C32-0525 2 -

8 Lock-Washer SS 4A0459-01 1 1 1

9 Lock-Key M5-0680-111 4A0460-01 1 1 1

10 Washer-Door Lock SS 4A0670-01 1 1 1

11 Hinge-Spring 4A3312-01 1 1 1

Hinge-Spring Cart 4A0438-01 1 1 1

12

Material or
Model Number Part Number

1A0323G03

3A0273-02 1 1 1
2209
244A Gray

J-1

to

M-7

Required Number

N-6

to

Q-5

1

1

7a

7

41

S. Door-Half (UL)

FH2-SSB-HD

J-1, L-5, M-6, M-7, N-6, P-5, P-6, Q-5

11

12

6

1

7a

7

2

9

Title: S. Door-Half (UL) Model: FH2-SSB-HD

L-5

Index

No. Description

1 Door-Prefoam (UL) - 1A0323G02 1 1 -

2 Lock-Tumbler M4-5813-001 4A0462-01 1 1 1

3 Lock-Stop Washer M5-8060-103 4A0458-01 1 1 1

4 Cam-Door Lock P.S 4A0228-01 1 1 1

5 Lock-Screw SS 4A0461-01 1 1 1

6 Gasket-Door(Half) Jarrow #P-

7 Stop-Door SS 4A0351-01 1 -

7a Truss Head Screw 5×25, SS 7C32-0525 2 -

8 Lock-Washer SS 4A0459-01 1 1 1

9 Lock-Key M5-0680-111 4A0460-01 1 1 1

10 Washer-Door Lock SS 4A0670-01 1 1 1

11 Hinge-Spring 4A3312-02 1 1 1

Hinge-Spring Cart 4A0438-02 1 1 1

12

Material or
Model Number Part Number

1A0323G04

3A0273-02 1 1 1
2209
244A Gray

J-1

to

M-7

8

5

4

3

10

Required Number

N-6

to

Q-5

1

42

T. Door-Half (LL)

FH2-SSB-HD

J-1, L-5, M-6, M-7, N-6, P-5, P-6, Q-5

7

11

4

5

6

12

10

3

8

2

9

1

7a

Title: T. Door-Half (LL) Model: FH2-SSB-HD

Index

Description Material or

No.

1 Door-Prefoam (LL) - 1A0325G02 1 1 -

2 Lock-Tumbler M4-5813-001 4A0462-01 1 1 1

3 Lock-Stop Washer M5-8060-103 4A0458-01 1 1 1

4 Cam-Door Lock P.S 4A0228-01 1 1 1

5 Lock-Screw SS 4A0461-01 1 1 1

6 Gasket-Door(Half) Jarrow #P-

7 Stop-Door SS 4A0351-01 1 -

7a Truss Head Screw 5×25, SS 7C32-0525 2 -

8 Lock-Washer SS 4A0459-01 1 1 1

9 Lock-Key M5-0680-111 4A0460-01 1 1 1

10 Washer-Door Lock SS 4A0670-01 1 1 1

11 Hinge-Spring 4A3312-02 1 1 1

Hinge-Spring Cart 4A0438-02 1 1 1

12

Model Number

2209
244A Gray

Part Number Required Number

L-5

to

J-1

M-7

1A0325G04

3A0273-02 1 1 1

N-6

to

Q-5

1

43

U. Mullion-Cross

FH2-SSB-HD

J-1, L-5, M-6, M-7, N-6, P-5, P-6, Q-5

1

2a

2

M-7 and later

4a

4

7

8

3a

3

3

M-6 and earlier

The santoprene light socket was changed to
a porcelain lampholder at M-7. This change
is non-interchangeable. If the light socket is
not operating on a unit with a santoprene
light socket, Hoshizaki recommends
replacement with HS-3554.

3a

5

6a

6

4a

4

6a

6

HS2

HS2a

Note:

Parts 5, 6 and 6a are not included in
HS-3554; they are shown for reference only.

44

HS1

5

HS1a

Title: U. Mullion-Cross Model: FH2-SSB-HD

Required Number

M-7

Index

No. Description

Material or
Model Number Part Number

J-1 L-5 M-6

to

P-6 Q-5

1 Mullion-Prefoam - 2A1351G01 1 -

2A1351G04

1 1 1 1

2 Pilaster-Mullion SS 2A0205-02 2 2 2 2 -

2A3246-01

Truss Head Screw 4×20, SS 7C32-0420 6 6 6 6 6

2a

3 Plate-Strike(Front) SS 4A0355-01 2 2 2 2 2

3a Truss Head Screw 4×8, SS 7C32-0408 2 2 2 2 2

4 Plate-Strike (Base) SS 4A0354-01 2 2 2 2 2

4a T2 Screw 4×8, SS 7P32-0408 4 4 4 4 4

5 Bulb-Light GE, 40A15 4A0437-01 1 1 -

- 4A2420-01 1 1 1

6 Shield-Light 2778-1010-

4A0465-01 1 1 1 1 1

3000

6a Truss Head Screw 5×10, SS 7C32-0510 2 -

Cheese Head Screw 5×12, SS 7C52-0512 2 2 2 2

7 Insert – Threaded Wide - 4A0839-01

8 Lampholder - 4A2862-01 1 1

Non­interchangeable
part change. If
light socket is not
operating for these
codes, Hoshizaki
recommends
replacement with HS­3554 (below).

2 2

2

HS-3554-Lampholder Conversion Kit

Index

No. Description

Material or
Model Number Part Number

HS1 Plate-Lampholder Mount SS 4A2880-01 1

HS1a Cheese Head Screw SS 7C52-0512 2

Lampholder 4A2862-01 1

HS2

HS2a

Terminal-Flag DNFR18-

8101-18FJ 2
250FIBK

Required Number

M-6 and earlier

45

V. Literature & Packaging

FH2-SSB(-HD)

H-0, J-0, J-1, J-2, L-5, M-5, M-6, M-7, N-5, N-6, P-5, P-6, Q-5

Title: V. Literature & Packaging Model: FH2-SSB(-HD)

H-0

Index

No. Description

1 Instruction Manual Paper 91A34010L 1

Material or
Model Number Part Number

to

Q-5

Required Number

Packaging (Available Only For Models
Currently In Production)

1 Filler – Door 4A2977-01 2

2 Pad – Corner 3A2598-01 4

3 Post – Corner 3A2603-01 4

4 Support – Corner 3A2596-01 4

5 Stop – Door 4A1873-01 2

6 Flat Washer 7W21I5800 4

7 Hex Head Bolt 7B01 I5825 4

8 Pallet 3A1815-01 1

9 Stop – Door (Center)

FH2-SSB-HD Only

10 Protector – Front 3A2595-01 1

FH2-SSB

FH2-SSB-HD

1A0766A11 1

1A0766A12

4A1874-01 2

1

46
