2
TABLE OF CONTENTS
SAFETY INSTRUCTIONS
FOLDING & MOVING
LEVELING, POWER & EMERGENCY STOP
KNOW YOUR TREADMILL
OMEGA II
GET TING STARTED
PROGRAMMING/DISPLAY
KNOW YOUR TREADMILL
PARAGON II HRC, QUANTUM II HRC & QUANTUM II
GET TING STARTED
DISPL AY
PROGRAM PROFILES
USING YOUR RACE PROGRAM
USING YOUR HRC PROGR AM
USING YOUR ADVENTURE PROGRAM
TROUBLESHOOTING
COMMON QUESTIONS
MAINTENANCE PROCEDURES
EXERCISE GUIDELINES
DEVELOPING A FITNESS PROGRAM
& IMPORTANCE OF WARM UP/ COOL DOWN
FITNESS GOALS
WEEKLY LOG SHEETS
MONTHLY LOG SHEETS
LIMITED HOME USE WARRANTY
3
6
7
8
9
11
13
14
17
19
24
25
27
28
30
32
33
34
35
36
37
38
!
C AUTION
Read all precautions and instructions in this manual before using this equipment.
Save this manual for future reference.
TREADMILL SERIES
3
SAVE THESE INSTRUCTIONS
Read all instructions before using this Treadmill. When using an electrical product, basic
precautions should always be followed, including the following: Read all instructions
before using this HORIZON FITNESS T readmill
WARNING ! Connect this exercise product to a properly grounded outlet only. S e e
grounding instructions.
GROUNDING INSTRUCTIONS
This product must be grounded. If a treadmill should malfunction or breakdown,
grounding provides a path of least resistance for electrical current to reduce the risk of
electrical shock. This product is equipped with a cord having an equipment-grounding
conductor and a grounding plug. The plug must be plugged into an appropriate outlet
that is properly installed and grounded in accordance with local codes and ordinances.
DANGER ! Improper connection of the equipment-grounding conductor can result
in a risk of electric shock. Check with a qualified electrician or serviceman if you are in
doubt as to whether the product is properly grounded. Do not modify the plug provided
with the product. If it will not fit the outlet, have a proper outlet installed by a qualified
electrician.
This product is for use on a nominal 220-volt circuit, and has a grounding plug that looks
like the plug illustrated below. A temporary adapter such as the one illustrated below may
be used to connect this plug to a 2-pole receptacle as shown, if a properly grounded outlet is not available. The temporary adapter should be used only until a properly grounded
outlet can be installed by a qualified electrician. The green colored rigid ear, lug, or the like
extending from the adapter must be connected to a permanent ground such as a properly grounded outlet box cover. Whenever the adapter is used, it must be held in place by a
metal screw.
3-POLE
GROUNDED
OUTLET
GROUNDED TREADMILL
POWER CORD
METAL
GROUNDING
SCREW
2-POLE
OUTLET IN
GROUNDED BOX
ADAPTER
IMPORTANT SAFETY INSTRUCTIONS
38
FRAME •LIFETIME
Horizon Fitness warrants the frame against defects in workmanship and materials for the
lifetime of the original owner.
ELECTRONICS & PARTS
Horizon Fitness warrants the electronic components and all original parts for aperiod from
the date of original purchase, so long as the device remains in the possession of the original owner.
LABOR
Horizon Fitness shall cover the labor cost for the repair of the device for a period from the
date of the original purchase, so long as the device remains in the possession of the original owner.
EXCLUSIONS AND LIMITATIONS
This warranty applies only to the original owner and is not transferable. The warranty is
expressly limited to the repair or replacement of a defective frame, electronic componet, or
defective part and is the sole remedy of the warranty.
The warranty does not cover normal wear and tear, improper assembly or maintenance, or
installation of parts or accessories not originally intended or compatible with the elliptical
trainer as sold. The warranty does not apply to damage or failure due to accident, abuse,
corrosion, discoloration of paint or plastic, or neglect. Horizon Fitness shall not be responsible for incidental or consequential damages. All returns must be pre-authorized by
Horizon Fitness. Horizon Fitness' obligation under this warranty is limited to replacing or
repairing, at Horizon Fitness' option, the product at one of its authorized service centers.
An Horizon Fitness authorized service center must receive all products for which a warranty claim is made. These products must be received with all freight and other transportation
charges prepaid, accompanied by sufficient proof of purchase. Parts and electronic components reconditioned to As New Condition by Horizon Fitness or its vendors may sometimes be supplied as warranty replacement parts and constitute fulfillment of warranty
terms. This warranty gives you specific legal rights, and your rights may vary from state to
state.
LIMITED HOME USE WARRANTY
Please consult your local dealer for more warranty details.
TREADMILL SERIES
TREADMILL SERIES
4
WARNING ! To reduce the risk of burns, fire, electrical shock or injur y to persons:
• Never use the treadmill before securing the safety tether clip to your clothing.
• If you experience chest pains, nausea, dizziness, or shortness of breath, stop
exercising immediately and consult your physician before continuing.
• Do not wear clothes that might catch on any part of the treadmill.
• Keep power cord away from heated surfaces.
• K eep children off of treadmill at all times.
• Do not use treadmill outdoors.
• Unplug treadmill before moving it.
• Do not remove the treadmill motor covers or roller covers. Service should be
performed only by an authorized Horizon Fitness service provider.
• Treadmill should be plugged into a dedicated
20amp circuit.
• At no time should more than one person be on treadmill while in operation.
CHILDREN
• Keep children off your Treadmill at all times.
• When the Treadmill is in use, young children and pets should be kept at least
10 feet away.
CLEANING
• Clean with soap and slightly damp cloth only; never use solvents.
OTHER SAFETY TIPS FOR YOUR HORIZON FITNESS TREADMILL
CAUTION !
If you experience chest pains, nausea, dizziness or shortness of breath, stop
exercising immediately and consult your physician before continuing.
• Do not wear clothing that might catch on any part of the Treadmill.
• Read this Owner’s Guide before operating this Treadmill.
37
MONTHLY LOG SHEET
OPERATION
To reduce the risk of damaging important components on your treadmill, it is strongly recommended that your treadmill is plugged into a dedicated
20amp outlet, without the
use of an additional extension cord.
It is essential that your treadmill is used only indoors, in a climate controlled room. If your
treadmill has been exposed to colder temperatures or high moisture climates, it is strongly
recommended that the treadmil is warmed up to room temperature before first time use.
Failure to do so may cause premature electronic failure.
MONTH
MONTHLY GOAL:
WEEK#
DISTANCE
CALORIES
TIME
MONTHL Y TOTALS
MONTH
MONTHLY GOAL:
WEEK#
DISTANCE
CALORIES
TIME
MONTHL Y TOTALS
TREADMILL SERIES
TREADMILL SERIES
DAY
SUN
MON
TUES
WED
THUR
FRI
SAT
5
CONGRATULATIONS ! on choosing a Horizon Fitness Treadmill.
You’ve taken an important step in developing and sustaining an exercise program! Your
Horizon Fitness Treadmill is a tremendously effective tool for achieving your personal fit ness goals. Regular use of your Horizon Fitness Treadmill can improve the quality of your
life in so many ways.
Here are just a few of the health benefits of aerobic exercise:
• W eight Loss
• A Healthier Heart
• Improved Muscle Tone
• Increased Daily Energy Levels
• Reduced Stress
• Help In Countering Anxiety and Depression
• An Improved Self Image
The key to reaping these benefits is to develop the exercise habit. Your new Horizon Fitness
Treadmill will help you eliminate the obstacles that prevent you from getting in your exercise time. Inclement weather and darkness won't interfere with your workout when you use
your Horizon Fitness Treadmill in the comfort of your home. This manual provides you with
basic information for using and enjoying your new machine. A more complete knowledge
of your new Horizon Fitness Treadmill will assist you in realizing your goal of a healthy
lifestyle.
IMPORTANT: PLEASE READ BEFORE USE !
36
WEEKLY LOG SHEET
CAUTION ! There are several areas during the assembly process of a Horizon
Fitness treadmill that special attention must be paid. It is very important to follow the
assembly instructions correctly and to make sure all parts are firmly tightened. If the assembly instructions are not followed correctly, the treadmill could have frame parts that are not
tightened and will seem loose and may cause irritating noises. There should be no side-toside play in the console masts or any forward and back play in the console assembly or handlebars. If there is any play in these areas, the treadmill has not been properly assembled.
To prevent damage to the treadmill, the assembly instructions must be reviewed and corrective actions should be taken.
ASSEMBLY
CAUTION:
BEFORE BEGINNING ANY EXERCISE PROGRAM, ALWAYS CONSULT
YOUR PHYSICIAN. IF YOU EXPERIENCE CHEST PAINS, NAUSEA, DIZZINESS OR
SHORTNESS OF BREATH, STOP EXERCISING AND CONSULT YOUR PHYSICIAN
BEFORE CONTINUING.
WEEK#
WEEKLY GOAL:
WEEK TOTALS
D A TE DISTANCE CALORIES TIME COMMENTS
TREADMILL SERIES
TREADMILL SERIES
DAY
SUN
MON
TUES
WED
THUR
FRI
SAT
WEEK#
WEEKLY GOAL:
WEEK TOTALS
D A TE DISTANCE CALORIES TIME COMMENTS
6
35
An important step in developing a long term fitness program is to determine your goals. Is
your primary goal for exercising on your Horizon Fitness Treadmill to lose weight? Improve
muscle? Burn Stress? Prepare for the spring racing schedule? Knowing what your goals are
will help you develop a more successful exercise program. Below are some common exercise goals:
If possible try to define your personal goals in precise, measurable terms, and then put your
goals in writing. The more specific you can be, the easier it will be to track your progress.
If your goals are long term, divide them up into monthly and weekly segments. Longer
term goals can lose some of the immediate motivation benefits. Short term goals are
easier to achieve. Your Horizon Fitness T readmill console provides you with several readouts
that can be used to record your progress. You can track Distance, Calories or Time. Time is
the most important and useful of test functions.
KEEPING AN EXERCISE DAIRY
Photocopy the weekly and monthly log sheets on the following pages to make your personal exercise log book. As time goes by you’ll be able to look back with pride at the work
you’ve done. As your fitness improves, you can look back and see how far you’ve come.
• W eight Loss
• Improve Body Shape and Tone
• Increased Energy Level
• Improved Sports Performance
• Improved Cardiovascular Endurance
• W eight Maintenance
• Strengthen Leg Muscles
• Improved Sleep Patterns
• Stress Reduction
ACHIEVING YOUR FITNESS GOALS
MOVING
Your Horizon Fitness treadmill has a pair of transport wheels built into the base frame. To
move, make sure the treadmill is folded and securely latched. Then firmly grasp the handlebars, tilt the treadmill back and roll.
CAUTION ! Our Treadmills are heavy, use care and
additional help if necessary when moving. Do not attempt to move or transport treadmill
unless it is in upright, folded position with the lock latch secured. Failure to follow these
instructions could result in injury.
FOOT LOCK-LATCH
FOLDING
Firmly grasp the back end of the treadmill. Carefully lift the end of the treadmill deck to the
upright position until the foot lock latch engages and securely locks the deck into position.
Make sure the deck is securely latched before letting go. To unfold, firmly grasp the back
end of the treadmill. Gently press down on the foot lock latch with your foot until the lock
latch disengages. Carefully lower the deck to the ground.
NOTE: on some models the foot
lock latch might be on the right hand side. NOTE: when folding the Horizon Fitness
Treadmill
the console assembly will tilt away from you, but will return when fully folded
in the upright position. Please allow two additional feet from wall when folding.
TREADMILL SERIES
TREADMILL SERIES
34
STRETCH FIRST
Before using your Horizon Fitness product, it is best to take a few minutes doing a few gentle stretching exercises. Stretching prior to exercise will improve flexibility and reduce
chances of exercise related injury. Ease into each of these stretches with a slow gentle
motion. Do not stretch to the point of pain. Make sure not to bounce while doing these
stretches.
WALL PUSH
Stand near a wall with the toes of one foot about 18" from the wall, and the other foot
about 12" behind the other foot. Lean forward, pushing against the wall with your
palms. Keep your heels flat and hold this position for a count of 15 seconds. Make sure
that you do not bounce while stretching. Alternate positions of your feet and repeat for
a total of 8 repetitions.
STANDING QUADRICEPS STRETCH
Using a wall to provide balance, grasp your left ankle with your left hand and hold your
foot against the back of your thigh for a count of 15 seconds. Repeat with your right
ankle and hand, and continue alternating for a total of 8 repetitions.
SEATED TOE TOUCH
Sit on the floor with your legs together and straight out in front of you. Do not lock your
knees. Extend your fingers towards your toes and hold for a count of 15 seconds. Make
sure that you do not bounce while stretching. Sit upright again. Repeat for a total of 8
repetitions.
WARM UP
The first 2 to 5 minutes of a workout should be devoted to warming up. The warm-up
will limber your muscles and prepare them for more strenuous exercise. Make sure that
you warm-up on your Horizon Fitness product at a slow pace.
COOL DOWN
Never stop exercising suddenly! A cool-down period allows your heart to readjust to the
decreased demand. Make sure that your cool down period consists of a very slow pace
to allow your heart rate to lower. After the cool-down, repeat the stretching exercises list ed above to loosen and relax your muscles.
DEVELOPING A FITNESS PROGRAM
THE IMPORTANCE OF WARM UP AND COOL DOWN
7
LEVELING
The treadmill should be level for optimum use. Once you have placed the treadmill where
you intend to use it, raise or lower the adjustable levelers located on the treadmill base
frame. Once you have leveled the treadmill, lock the levelers in place by tightening the nuts
against the frame. To assure the treadmill is level, a carpenter's level is recommended.
TURN POWER ON
Make sure that your treadmill is properly connected to a power outlet. The on/off switch is
located next to the power cord. Flip this switch to the 'on' position, so that the switch is lit.
You will hear a beep and the console will light up.
SAFETY KEY
Your treadmill will not start unless the safety key is placed on the safety key holder. Attach
the clip end securely to your clothing. This safety key is designed to cut the power to the
treadmill if you should fall.
NEVER USE THE TREADMILL WITHOUT SECURING THE
SAFETY KEY CLIP TO YOUR CLOTHING. PULL ON THE SAFETY KEY CLIP FIRST TO
MAKE SURE IT WILL NOT COME OFF YOUR CLOTHING.
DO NOT STAND ON THE BELT
While you are preparing to use the treadmill, do not stand on the belt. Place your feet on
the side rails before starting the treadmill. Start walking on the belt only after the belt has
begun to move. Never start the treadmill at a fast running speed and attempt to jump on!
TREADMILL SERIES
TREADMILL SERIES
8
33
Always consult your physician before beginning an exercise program.
HOW OFTEN?
The American Heart Association recommends that you exercise at least 3 to 4 days per week
to maintain cardiovascular fitness. If you have other goals such as weight or fat loss, you
will achieve your goal faster with more frequent exercise. Whether it’s 3 days or 6 days,
remember that your ultimate goal should be to make exercise a lifetime habit. Many people are successful staying with a fitness program if they set aside a specific time of day to
exercise. It doesn’t matter whether it’s in the morning before your shower, during lunch
hour or while watching the evening news. What’s more important is that it’s a time that
allows you to keep a schedule, and a time when you won’t be interrupted. If you are to be
successful with your fitness program, you have to make it a priority in your life. So decide
on a time, pull out your day planner and pencil in your exercise times for the next month!
HOW LONG?
For aerobic exercise benefits, it’s recommended that you exercise from between
24 and 32 minutes per session. But start slowly and gradually increase your exercise times.
If you’ve been sedentary during the past year, it may be a good idea to keep your exercise
times to as little as five minutes initially. Your body will need time to adjust to the new
activity. If your goal is weight loss, a longer exercise session at lower intensities has been
found to be most effective. A workout time of 48 minutes or more is recommended for
best weight loss results.
HOW HARD?
How hard you workout is also determined by your goals. If you use your Horizon Fitness
Treadmill to prepare for a 5K run, you will probably work out at a higher intensity than if
your goal is general fitness. Regardless of your long term goals, always begin an exercise
program at low intensity. Aerobic exercise does not have to be painful to be beneficial!
There are two ways to measure your exercise intensity. The first is by monitoring your heart
rate, and the second is by evaluating your perceived exertion level (this is simpler than it
sounds!).
PERCEIVED EXERTION LEVEL
The second and simpler way to gauge your exercise intensity is to evaluate your perceived
exertion level. While exercising if you are too winded to maintain a conversation without
gasping, you are working out too hard. A good rule of thumb is to work to the point of
exhilaration, not exhaustion. If you cannot catch your breath, it’s time to slow down.
Always be aware of other warning signs of overexertion.
EXERCISE GUIDELINES KNOW YOUR TREADMILL
CONSOLE
W ATER BOT TLE
HOLDER
MOTOR COVER
SIDE RALL
ROLLER
END CAP
RUNNING BELT
TRANSPORT WHEELL
LEVELER
OMEGA II
OMEGA II
TREADMILL SERIES
9
32
MAINTENANCE PROCEDURES
Cleanliness of your Horizon Fitness treadmill and its operating environment will keep maintenance problems and service calls to a minimum. For this reason, Horizon Fitness recommends that the following preventive maintenance schedule be followed.
AFTER EACH USE (DAILY)
Turn off the treadmill with the on/off switch, and unplug the power cord from the wall outlet.
WARNING!
To remove power from the treadmill, the power cord must be disconnected from the wall
outlet.
• Wipe down the running belt, deck, motor cover, and console casing with a damp cloth.
Never use solvents, as they can cause damage to the treadmill.
• Inspect the power cord. If the power cord is damaged, contact Horizon Fitness.
• Make sure the power cord is not underneath the treadmill or in any other area where it
can become pinched or cut.
• Check the tension and alignment of the running belt. Make sure that the treadmill belt
will not damage any other components on the treadmill by being misaligned.
EVERY WEEK
Clean underneath the treadmill, following these steps:
• Turn off the treadmill with the on/off switch, then unplug the power cord at the wall out
let.
• Fold the treadmill into the upright position, making sure that the lock latch is secure.
• Move the treadmill to a remote location.
• Wipe or vacuum any dust particles or other objects that may have accumulated unde
neath the treadmill.
• Return the treadmill to its previous position.
EVERY MONTH
• Inspect all assembly bolts of the machine for proper tightness.
EVERY YEAR
• It may be necessary to rewax your treadmill running deck and belt once a year to main
tain optimal performance of your treadmill. Please contact your local dealer with ques
tions about applying wax to your treadmill.
W arning! Only use paraffin wax provided by Horizon Fitness!
• Lubricate the air shocks with teflon based spray.
QUICK START UP
Simply press the Start button to begin exercising.
Metric
British
OMEGA II
TREADMILL SERIES
10
31
TENSIONING THE BELT
If you can feel a slipping sensation when running on the treadmill, the running belt must
be tightened. In most cases, the belt has stretched from use, causing the belt to slip. This
is a normal and common adjustment. To eliminate this slipping,
tension both the rear roller bolts
with the appropriate size allen
wrench, turning it 1/4 TURN to
the right as shown. Try the tread mill again to check for slipping.
Repeat if necessary, but NEVER
TURN the roller bolts more than
1/4 turn at a time. the belt ten sion is set properly when the running belt is 1/4 of an inch from
the deck.
CENTERING THE BELT
If the running belt is too far to the right side, use the supplied Allen wrench to turn the
right tension bolt clockwise 1/4 turn at a time until the belt remains centered during use.
If the running belt is too far to the left side, turn the left tension bolt clockwise 1/4 turn at
a time until the belt remains centered during use.
IF THE BELT IS TOO FAR TO
THE LEFT SIDE:
• Turn the left roller bolt 1/4 turn
clockwise (tighten).
IF THE BELT IS TOO FAR TO
THE RIGHT SIDE:
• Turn the right roller bolt 1/4
turn clockwise (tighten).
PAUSE
Press the Stop button to pause your workout.
RESET
Press and hold the Stop button to reset the treadmill.
Metric
British
OMEGA II
TREADMILL SERIES
11
CHOOSING THE TIME
Press SELECT and use the +or - buttons to set Time. Once the desired Time is selected,
press the ST A R T button. Select your desired speed using the + or - (speed) buttons.
FINISHING A WORKOUT
When your workout is finished, the treadmill
console will beep twice and ‘ E N D ’ will be
displayed in the Time window. Your workout
information will stay displayed on the console for 15 seconds before it will reset.
PROGRAMMING
DISPLAY
SELECT
Used to view alternate information such
as Speed, Pulse, Laps, Elevation, and
Calories during your workout.
NOTE: The
console will automatically default back to
show Time/Distance.
TIME
Shown as Minutes:Seconds. View the time
remaining or the time elapsed in your workout.
30
ARE THE SOUNDS MY TREADMILL MAKES NORMAL?
All treadmills make a certain type of thumping noise due to the belt riding over the
rollers, especially new treadmills. This noise will diminish over time, although may not
totally go away. Over time, the belt will stretch, causing the belt to ride smoother over
the rollers.
WHY IS THE TREADMILL I HAD DELIVERED LOUDER THAN THE ONE AT
THE STORE?
All fitness products seem quieter in a large store showroom because there is generally
more background noise than in your home. Also, there will be less reverberation on a
carpeted concrete floor than on a wood overlay floor. Sometimes a heavy rubber mat
will help reduce reverberation through the floor. If a fitness product is placed close to a
wall, there will be more reflected noise.
WHEN SHOULD I BE WORRIED ABOUT A NOISE?
As long as the sounds your treadmill makes are no louder that a normal conversational
tone of voice, it is considered normal noise. If your treadmill is louder than this, Please
contact your local dealer for further assistance.
WHAT KIND OF ROUTINE MAINTENANCE IS REQUIRED?
W e use sealed bearings throughout our treadmill so lubrication is not needed. The most
important maintenance step is to simply wipe your perspiration off the treadmill after each
use.
HOW DO I CLEAN MY HORIZON FITNESS TREADMILL?
Clean with soap and water cleaners only. Never use solvents on plastic parts.
COMMON PRODUCT QUESTIONS
MAINTENANCE
OMEGA II
TREADMILL SERIES
SPEED
Indicates how fast your walking or running surface is moving.
ELEVATION
Indicates the incline of your walking or running
surface.
DISTANCE
Indicates the miles traveled during your workout.
PULSE/LAPS
Indicates the number of times you have traveled
around the lap profile window. One lap equals
1
⁄
4
of a mile. NOTE: Pulse will be displayed if the
heart rate handlebars are being used. The pulse
reading is measured in beats per minute.
CALORIES
Indicates the total number of calories burned during
your workout.
DISPLAY
29
• Constant movement and vibration due to constantly holding
the heart rate handlebars while exercising. If you are receiving
erratic heart rate readouts, try to only hold the grips long
enough to monitor your heart rate.
• When you are breathing heavily during a workout.
• When your hands are constricted by wearing a ring.
• When your hands are dry or cold. Try to moisten your palms
by rubbing them together to warm.
• Anyone with heavy arrhythmia.
• Anyone with arteriosclerosis or peripheral circulation disorder.
• Anyone whose skin on the measuring palm is especially thick.
PROBLEM:There is no heart rate reading.
SOLUTION: If you are using the chest strap, there may be a poor connection between
the electrodes and the skin. Remoisten the electrodes with water.
SOLUTION: The chest strap may not be positioned properly. Reposition the chest strap.
It may be necessary to experiment with the fit and position of the chest strap.
SOLUTION:V erify that the distance between the chest strap and the console is not
beyond the recommended range of 36 inches.
SOLUTION:The battery in the chest strap may be dead. Take the chest strap to a jewelry
store or return to Horizon Fitness for a battery replacement.
PROBLEM: Erratic or inconsistent readout.
SOLUTION: This is often caused by dry electrodes or a loose chest strap. Moisture on
the rubber electrodes is required for proper operation. Try a more generous coating of
water on the electrodes and tightening the chest strap.
If the above troubleshooting section does not remedy the
problem, discontinue use and turn the power off.
12
Please consult your local dealer for further assistance.
OMEGA II
TREADMILL SERIES
13
CONSOLE
GRIP PULSE HANDLE-
BARS
RUNNING BELT
TRANSPORT WHEEL
SIDE RAIL
LEVELER
MOTOR COVER
WATER BOTTLE
HOLDER
UPRIGHT
SUPPORT
TOUCH PAD
ROLLER
END CAP
KNOW YOUR TREADMILL
28
Horizon Fitness treadmills are designed to be reliable and easy to use. However, if you expe rience a problem, please reference the troubleshooting guide listed below.
PROBLEM: The console does not light up.
SOLUTION: V erify that the power cord is plugged in properly to the outlet, and that the
treadmill switch is turned on.
PROBLEM: The treadmill circuit breaker trips during a workout.
SOLUTION: Ver i f y t h at t h e t r ea d m il l is p l ug g e d i n to a d ed i ca t e d 2 0 am p c ir c ui t . NOTE:
no extension cord.
PROBLEM: The treadmill shuts off when elevating
SOLUTION: Verify that there is enough slack in the power cord to reach to the wall out -
let during elevation.
PROBLEM: The running belt does not stay centered during a workout.
SOLUTION: Verify that the treadmill is on a level surface. Verify that the belt is properly
tightened (refer to Centering The Belt.)
PROBLEM: The treadmill makes a clicking noise towards the front of the machine while
walking or running on it.
SOLUTION: For optimum use, the treadmill needs to be level. Refer to the section on
leveling your treadmill.
Check your exercise environment for sources of interference such as fluorescent lights,
computers, or appliances containing large motors. These items may cause erratic heart
rate readouts.
You may experience an erratic readout under the following conditions:
• Gripping the heart rate handlebars too tight. Try to maintain
moderate pressure while holding onto the heart rate handlebars.
TROUBLESHOOTING YOUR TREADMILL
HEART RATE TROUBLESHOOTING
PARAGON II HRC, QUANTUM II HRC, QUANTUM II
PARAGON II HRC, QUANTUM II HRC & QUANTUM II
TREADMILL SERIES
14
QUICK START UP
Simply press the Start button to begin exercising.
GETTING STARTED
27
USING YOUR ADVENTURE PROGRAM
Your Adventure Program is designed to allow you to create your own programming, with the
ability to save your program settings for future workouts. To use your Adventure Program, fol low these instructions:
1. Once the Adventure Program has been selected, press ‘Select’.
2. Choose your desired time using the + or - speed or incline keys and press ‘Select’.
3. Choose your desired speed using the + or - speed or incline keys and press ‘Select’.
You will need to select a speed for all 15 segments, pressing ‘Select’ after each segment.
4. Once all 15 speed segments have been chosen, you will need to select your desired
incline level for each segment as well. Choose your desired incline level using the + or speed or incline keys and press ‘Select’. Once you have chosen your desired incline level
for all 15 segments, press ‘Start’ to begin your program. At this time, your program has
been successfully saved into memory, and can be used for future workouts.
5. To reset your program information and delete it from memory, press and hold the
‘Select’ button for 5 seconds once you have selected the Adventure Program in the start
menu.
6. While using your saved program in the Adventure Program, you are able to adjust the
speed or incline, but any changes will not be saved.
PAUSE
Press the Stop button to pause your workout.
RESET
Press and hold the Stop button to reset the treadmill.
Metric
British
Metric
British
TREADMILL SERIES
PARAGON II HRC, QUANTUM II HRC & QUANTUM II
15
QUICK SPEED KEYS
When in a program, the user is able to press any of the desired quick speed k eys to get to a spe cific speed more quickly.
NOTE: When in a speed-based program, if the user presses any
of the quick speed keys, all of the remaining speed segments in the program will be
modified as well. For example, when in P2, the first segment default speed is 2.5 mph. If
the user presses the 4 mph quick speed key, all of the remaining segments will increase
by 1.5 mph as well.
CHANGING THE SPEED AND ELEVATION
When in a program, the user is able to change the difficulty of the program by pressing
the plus (+) or minus (-) buttons to the desired level.
NOTE: The user is only able to
increase or decrease the elevation or speed during the program. When in a program, if the
user increases or decreases the difficulty of speed or elevation, all of the remaining program
speeds or elevation segments will be modified as well. For example, when in P2, the first
segment default speed is 2.5 mph. If this speed is increased by 1 mph, all of the remaining segments will be increased by 1mph as well.
26
TARGET ZONE
Your Target Zone is a percentage of your maximum heart rate. Target Zone will vary for each
individual, depending on age, current level of conditioning, and personal fitness goals. The
American Heart Association recommends working-out at a Target Heart Rate Zone of
between 60% and 75% of your maximum heart rate. See the chart below for convenient
reference.
EXAMPLE: for a 42-year old user: find A G E along the bottom of the chart (round to 40),
follow A G E column up to the TARGET ZONE BAR. RESULTS: 60% of maximum Hear Rate =
108 Beats Per Minute, 75% of maximum Heart Rate = 135 Beat Per Minute.
HEART RATE HANDLEBARS
Place the palm of your hands directly on the grip pulse handlebars. Both hands must grip
the bars for your heart rate to register. When griping the pulse handlebars, do not grip
tightly. Holding the grips tightly may elevate your blood pressure. K eep a loose, cupping
hold. It is recommended that you hold the grip pulse handlebars only long enough to see
your heart rate readout on the console. You may experience an erratic readout if consis tently holding the grip pulse handlebars.
TELEMETRIC CHEST TRANSMITTER
Prior to wearing the chest transmitter on your chest, moisten the two rubber electrodes
with water. Center the chest strap just below the breast or pectoral muscles, directly over
your sternum, with the Horizon Fitness logo facing out.
NOTE: The chest strap must be
tight and properly placed to receive an accurate and consistent readout. If the chest strap
is too loose, or positioned improperly, you may receive an erratic or inconsistent heart rate
readout.
WARNING! The heart rate function is not a medical device. V arious factors may
affect the accuracy of your heart rate reading. The heart rate reading is intended only as an
exercise aid.
Target Zone Chart
TREADMILL SERIES
PARAGON II HRC, QUANTUM II HRC & QUANTUM II
16
CHOOSING A PROGRAM
Choose a Program by pressing the +or speed buttons. Once the desired programs is
selected, press the SELECT button. You are
also able to press the numbered quick speed
key which correlates with the numbered program to choose your desired program. For
example press the number 1 quickspeed key
for program number 1.
CHOOSING THE TIME
Choose Time by pressing the +or -speed
buttons or use the default time. Once the
desired time is selected, press the ST A R T
button.
FINISHING A WORKOUT
When your workout is finished, the treadmill console will beep and ‘ E N D ’ will be
flashing in the Time window. Your workout information will stay displayed on the
console for 30 seconds before it will reset.
CHOOSING THE LEVEL
Choose the program difficulty level, level 1-10, by pressing the + or - speed buttons.
Available only on certain programs. You may also choose your program level by pressing
the numbered quick speed key that correlates with the program level number. F or example,
to choose a program level of 5, simply press quick speed key number 5. Once the program
level has been chosen, press the ‘select’ button. Once in a program, the user may change
the difficulty level by pressing the + or - speed keys or by pressing the quick speed keys.
NOTE: If one segment is changed, the entire program will in turn be changed. For example,
when in a program, if the user increases the speed 1 mph, all of the remaining segments
will also be increased by 1 mph.
25
(PARAGON II HRC & QUANTUM II HRC)
Once the HRC program is selected, press 'Select'. Using the chart on page 26, determine
your target heart rate. Your target heart rate should be set at a number that you will be
able to exercise at throughout the majority of your workout. To adjust your target heart
rate, press the plus (+) or minus (-) Speed buttons.
Once you have chosen your target heart rate, press 'Select'. Press the plus (+) or minus (-)
speed buttons to adjust your time. Once you choose your time, press the 'Start' button and
begin your workout.
After the 5 minute warm up period, the elevation level will increase gradually to get the
user to the entered target heart rate zone. Once the user is at the target heart rate zone,
plus or minus 5 beats, the elevation level will remain at the current resistance level.
If the user is more than 25 beats per minute above the target heart rate zone, the console
will shut down for safety reasons.
The last five minutes of the program will begin the cool down period. At this time, the program will gradually decrease the resistance level to give the user a smooth cool down.
NOTE: The chest strap is required to use the HRC program.
CHEST STRAP TRANSMITTER PLACEMENT AND MOISTENING THE
ELECTRODES
APPLY MOISTURE HERE
BACKSIDE OF CHEST TRANSMITTER
LOGO
USING YOUR HRC PROGRAM
PARAGON II HRC & QUANTUM II HRC
PARAGON II HRC, QUANTUM II HRC & QUANTUM II
17
24
DISPLAY
SELECT
Used to view your Calories and Laps during
your workout.
CALORIES
Total Calories burned during your workout.
DISTANCE
Miles traveled during your workout.
TIME
Shown as Minutes:Seconds. View the time
remaining or the time elapsed in your workout.
PULSE
Shown as Beats Per Minute. Used to
monitor your heart rate during your
workout (displayed when contact is
made with both grips or the chest strap
is used).
USING YOUR RACE PROGRAM
Your Race Program is design to add motivation to a workout by allowing you to
compete against a selected pacer. To use your Race Program, follow these instruc tions:
1. Once the Race Program is selected, Press 'Select'.
2. Choose the desired Pace (speed) using the + or - speed or incline keys and press 'Select'.
The selected pace is
the pace you will be racing against. You will choose your own speed
after the program started.
3. To choose your desired distance press the + or - speed or incline keys and press 'select'.
NOTE: your program time will be set according to your speed and distance.
4. Once the desired Pace (Speed) and distance has been chosen, press the 'Start' key.
5. Upon pressing 'Start', the program will be broken up into 10 segments (which will not
be displayed on console as 8 LED lights). The first segment will be dedicated to a warm up,
which will be half of the selected pace (Speed) and will be set at 2.5 minutes. Segments
2-9 will consist of the Race Program, with segment 10 being dedicated to a cool down
period, which again will be half of the selected Pace (Speed) segment will not be displayed.
If the user beats the pacer to the finish line, the speed window will flash, and the program
will end.
6. You can adjust the your own speed at any time during the program by pressing the +
or - speed keys or by using the quick speed keys.
TREADMILL SERIES
PARAGON II HRC, QUANTUM II HRC & QUANTUM II
18
23
ELEVATION
Shown in the top left-hand window.
Indicates the incline of your walking or running surface.
SPEED
Shown in the top right-hand display win d o w. Indicates how fast your walking or running surface is moving.
PROGRAM PROFILE
Represents the Program profile that you have
chosen.
(Paragon II HRC, Quantum II HRC)
LAP PROFILE
One lap around the profile
window equals 1/4 of a mile. (Manual
program only)
DISPLAY
LAP PROFILE
( Quantum II )
One lap around the profile window equals
1/4 of a mile. (Manual program only)
ROCK CLIMB:Elevation and Speed changes ; time defaults to 30 minutes
TREADMILL SERIES
PARAGON II HRC, QUANTUM II HRC & QUANTUM II
19
22
MANUAL
Customized workout, with no default time
( ALL MODELS )
PROGRAM PROFILES
CROSS COUNTRY
Speed changes; time defaults to 30 minutes
( PARAGON II HRC, QUANTUM II HRC &
QUANTUM II )
HILL RUN
Speed changes; time defaults to 30 minutes
( PARAGON II HRC, QUANTUM II HRC &
QUANTUM II )
AFTER BURNER
Elevation changes; time defaults to 30 minutes
( PARAGON II HRC, QUANTUM II HRC &
QUANTUM II )
HILL CLIMB
Elevation and speed changes; time defaults to
30 minutes
( PARAGON II HRC )
AFTER BURNER : Elevation changes ; time defaults to 30 minutes
HILL CLIMB:Elevation and speed changes ; time defaults to 30 minutes
PARAGON II HRC, QUANTUM II HRC & QUANTUM II
PARAGON II HRC, QUANTUM II HRC & QUANTUM II
20
21
CROSS COUNTRY: Speed changes ; time defaults to 30 minutes
ROCK CLIMB
Elevation and speed changes; time defaults to 30 minutes
( PARAGON II HRC & QUANTUM II )
PROGRAM PROFILES
RACE
Speed changes; time defaults to 30 minutes
( PARAGON II HRC & QUANTUM II HRC)
ADVENTURE 2 (USER PROGRAM)
Customized workout, time defaults to
30 minutes
( PARAGON II HRC & QUANTUM II HRC )
ADVENTURE 1 (USER PROGRAM)
Customized workout, time defaults to
30 minutes
( PARAGON II HRC, QUANTUM II HRC &
QUANTUM II)
HRC
Elevation changes to keep you in your target
heart rate; time defaults to 30 minutes
( PARAGON II HRC & QUANTUM II HRC)
HILL RUN: Speed changes ; time defaults to 30 minutes
PARAGON II HRC, QUANTUM II HRC & QUANTUM II
PARAGON II HRC, QUANTUM II HRC & QUANTUM II
Loading...
