USER MANUAL
IMPORTANT SAFETY REMINDERS
This appliance should only be used for domestic cleaning, as
described in this user guide. Please ensure that this guide is
fully understood before operating the appliance.
cigarette ends or other similar items.
Do not spray with or pick up flammable liquids, cleaning fluids,
aerosols or their vapours.
Do not run over the power cord when using your appliance or
remove the plug by pulling on the power cord.
Do not leave the appliance plugged in. Always switch off and
remove the plug from the socket after use, or before cleaning
the appliance or any maintenance task.
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
If the power cord is damaged stop using the appliance
immediately. To avoid a safety hazard, an authorised Hoover
service engineer must replace the power cord.
Keep hands, feet, loose clothing and hair away from rotating
brushes.
Use only attachments, consumables or spares recommended
or supplied by Hoover.
When using cleaning tools ensure that the appliance is kept in
the upright (parked) position. This will avoid possible damage
to the carpet or floor covering. When cleaning stairs, do not
position the appliance above you.
Static electricity: some carpets can cause a small build up
of static electricity. Any static discharge is not hazardous to
health.
Do not use your appliance out of doors or on any wet surface
or for wet pick up.
Do not continue to use your appliance if it appears faulty.
Hoover service: To ensure the continued safe and efficient
operation of this appliance we recommend that any servicing
or repairs are only carried out by an authorised Hoover service
engineer.
Do not stand on or wrap the cord around arms or legs when
using your appliance.
Do not use the appliance to clean animals or people.
When using the cleaning tools, ensure to always steady the
appliance with your other hand. This will ensure that the
appliance does not fall while in use.
WARNING: A thermal cut out switches off the appliance to prevent overheating
if it is used when full or there is a blockage or dirty filters. If this should
happen then switch off, unplug and correct the fault. It will take approximately
45 minutes for the cut out to automatically reset.
The Environment
The symbol on this appliance indicates that this appliance may not
be treated as household waste. Instead it must be handed over to the
applicable collection point for the recycling of electrical and electronic
equipment. Disposal must be carried out in accordance with local
environmental regulations for waste disposal. For more detailed
information about treatment, recovery and recycling of this appliance, please
contact your local city office, your household and waste disposal service or
the shop where you purchased the appliance.
This appliance complies with the European Directives 2006/95/EC,
2004/108/EC and 2011/65/EU.
Do not pick up hard or sharp objects, matches, hot ashes,
HOOVER Limited, Pentrebach, Merthyr Tydfil, Mid Glamorgan, CF48 4TU, UK
- 1-
GETTING TO KNOW YOUR CLEANER
Effortless cleaning
with your new
Hoover
HANDLE
PET HAIR & ALLERGEN
REMOVER HOLDER*
PET HAIR & ALLERGEN
REMOVER*
This vacuum cleaner is supplied with an Energy
Label as required by European Regulation (EU)
665/2013. The label shows a red prohibition
circle on the right covering the hard floor symbol.
This indicates that the vacuum cleaner is not
suitable for use on hard floors.
HOSE
BIN HANDLE
CREVICE TOOL/
DUSTING BRUSH
REAR WHEEL
BIN LID
HOSE HOOK
BIN RELEASE
BUTTON
CORD HOOK
BIN
BIN BASE
ON/ OFF BUTTON
CORD HOOK
HOSE
CONNECTOR
(*Certain models only)
- 2 -
PREPARING TO USE YOUR CLEANER POWER SWITCh SETTING
Switching on and off
1. Using a cross head screw driver, remove the
screw from rear of the cleaner main body.
2. Insert the handle into the main body of the cleaner.
1
2
1. Plug cord into an electrical outlet.
Press the on /off switch to operate
2.
cleaner.
3
3. Insert the screw through the handle and into the main
body, tighten securely.
4. Place the crevice tool /dusting brush into the
tool holder.
CLEANER RELEASE
4
Unlock the cleaner by placing on the
foot on the hood and leaning the handle
backward. For cleaning under low
furniture simply lower handle to floor.
- 3 -
CLEANING TOOLS REMOvAL AND EMPTYING OF ThE
DUST CONTAINER
IMPORTANT: When using cleaning tools, the cleaner must be kept
in the upright position, particularly when cleaning stairs.
!
To Detach the cleaning
hose rotate the hose end
anti-clockwise and pull
upwards.
All accessories can fit on the end of the tube.
Attach crevice tool to the hose end connector.
To use the dusting brush function simply
press the button and slide to the end of
crevice tool .
Fit the Per Hair & Allergen Remover*
To remove the dust container
from the cleaner, press the
bin release button.
Hold the container over a
bin and push the easy open
button placed at the rear of
the dust container.
The dust container door will
open and you can empty with
no contact with dust.
CLEANING ThE STAIRS
IT IS DANGEROUS TO PLACE THE CLEANER ABOVE
YOU WHEN CLEANING STAIRS.
ALWAYS work with the cleaner below you. Ensure it
is positioned up against the bottom step.
(*Certain models only)
- 4 -
IMPORTANT: Do not fill above the MAX level
mark shown on the bin.
!
MAINTAINING ThE DUST CONTAINER AND FILTERS
( PERIODIC MAINTENANCE IS REQUIRED TO MAINTAIN OPTIMUM PERFORMANCE)
Cleaning the Separator
Remove the dust container as described
on the previous page.
Hold the dust container lid and with the
other hand rotate the container in a anti-
clockwise direction to release.
Hold the container lid and rotate the
separator in an anti-clockwise direction
to release.
Remove the pre motor filter from inside
the separator and tap to remove any
excess dirt from the filter, it is also
recommended to clean the separator.
Once dirt is removed the filter can be
rinsed under the tap.
The pre-motor filter should be washed
<40
after every five bin empties. Wash under
hand warm water. Remove excess water
and leave to dry for 24 hours.
When completely dry, refit the filter.
Cleaning the Exhaust Filter
Underneath the dust container you can
find the exhaust filter.
Turn the dust container lid anticlockwise to unlock and lift to take
out.
Turn the separator anti-clockwise
to remove from the dust container
lid.
Tap separator over a bin to
remove any dirt/debris.
Using a soft brush clean any dirt/
debris out of the separator.
Refit the container top.
Please pay attention to alignment
tab.
Lift to remove the exhaust filter.
Remove any dirt/debris by rinsing under
water(Max 40°C)
Leave to dry for 24 hours or until fully dry
before replacing back into the cleaner.
IMPORTANT: Do not operate your cleaner
without either the dust container or filters
in the right place.
Twist the top part of the container
whilst holding the lower part to
lock together.
- 5 -
ChANGING ThE bELT OR bRUSh
If your cleaner is not picking up efficiently, the
belt or brush (or both) may need replacing, but
first make sure you have:
• Emptied the dust container
• Cleaned the filters
• Checked for blockages
Remove foot plate
Turn the machine over.
Locate the four screws as
shown opposite.
Remove the screws
completely.
IM P O R TA NT: Switch cleaner off
and remove plug from electricity
supply before checking the
brushes or removing hood.
Replace belt
Remove the old belt then
locate the new belt around
the motor spindle and the
brush. Locate the right
hand of the brush into the
cleaner housing .
Hold the brush assembly
and stretch the belt until
brush mountings slot down
into the cleaner housing.
Rotate the brush to
ensure free movement of
the belt.
CLEARING A bLOCKAGE
IM P O R TA NT: Switch the cleaner off and
remove the plug from electricity supply
!
before dismantling cleaning.
This cleaner is unlikely to become
blocked, except by overfilling of dust
container or accidentally picking
up large solid objects. Cleaning a
blockage is simple.
If cleaning tools were
in use, check cleaning
tool. Next check hose
handgrip.
Turn the cleaner ON
and stretch the hose to
its full length.
Replace opposite
Refit sole plate opposite
secure with screws.
- 6 -
Check that the brushes
are free of debris and
can rotate.
Check for a blockage
in the hose socket.
User checklist
If your cleaner is not working properly run through the following checklist.
1 .Is there a working electricity supply to the cleaner? Check with another
electrical product.
2. Is the dust container full or choked with fine dust? To empty the dust container
sec the instructions on page 5/6.
IMPORTANT INFORMATION
Hoover Service
Should you require service at any time, please contact your local Hoover Service
Ofce.
Hoover spares and Consumables
3. Is the hose blocked? To clear a blockage, see the instructions on page 6.
4. Is there a blockage in the cleaner base? To clear a blockage, see the
instructions on page 6.
5. Are the filters blocked? To clear the fitters, see the instructions on page 5.
6. Are the brushes rotating correctly? To check the brushes, see the instructions
on page 6.
7. Has the cleaner overheated? If so, it will take about 45 minutes to reset itself.
If there is any doubt call the Hoover Service Office for advice. They may be able
to assist you over the telephone. A service charge will be made if the cleaner is
examined and found to be in
Working order, has not been assembled in accordance with these instructions or
has been used incorrectly.
WARNING!
A thermal cut out switches off the cleaner to prevent overheating if it is used when
full or there is a blockage or dirty filters. If this should happen switch off, unplug and
correct the fault.
It will take about 45 minutes for the cut out to automatically reset.
Always replace parts with genuine Hoover spares. These are available from your local
Hoover dealer or direct from Hoover. When ordering parts always quote your model
number.
USE ONLY HOOVER SPARES
SPARE PARTS & CONSUMABLES CODE
FILTERS KIT U76 - 35601699
HOSE D156 - 35601698
AGITATOR Y36 - 35601697
BELT V37 - 35601700
PET HAIR & ALLERGEN REMOVER J44 - 35601064
Quality
Hoover’s factories have been independently assessed for quality. Our products
are made using a quality system which meets the requirements of ISO 9001
GUARANTEE STATEMENT
IMPORTANT: Do not run cleaner over the supply cord as this could damage the
supply cord insulation.
The guarantee conditions for this appliance are as defined by our representative
in the country in which it is sold. Details regarding these conditions can be
obtained from the dealer from whom the appliance was purchased. The bill of
sale or receipt must be produced when making any claim under the terms of this
guarantee.
Subject to change without notice.
- 7 -
Hoover Limited
Pentrebach
Merthyr Tydl
Mid Glamorgan
CF48 4TU
HOOVER CUSTOMER HELPINE
03444 995599
© 2015 48017172
Loading...
