USER MANUAL
60 COMBI
English
SUMMARY
SAFETY INFORMATION
COMBI REFRIGERATOR HOOVER
Climate Class
TRANSPORTATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
STARTING TO USE
COMBI OPERATION
VERTICAL DISPLAY
TOP FEAUTRED VERTICAL DISPLAY
INTERNAL USER INTERFACE
TECHNICAL FEATURES
HUMIDITY EQUALISER
ANTIBACTERIAL SYSTEM (if present)
WATER DISPENSER
Tips for keeping food perfect in the Fridge
Where to store your foods in the fridge
Storing Frozen Food
ENERGY SAVING
TAKE CARE
Defrosting
Cleaning and Care
CHANGING THE INTERNAL LIGHT
REVERSING THE DOOR SWING
TROUBLE SHOOTING
Thank you for purchasing this product.
Before using your refrigerator, please carefully
read this instruction manual in order to
maximize its performance. Store all
documentation for subsequent use or for other
owners. This product is intended solely for household
use or similar applications such as:
- the kitchen area for personnel in shops, offices and
other working environments
- on farms, by clientele of hotels, motels and other
environments of a residential type
- at bed and breakfasts (B & B)
- for catering services and similar applications not for
retail sale.
This appliance must be used only for purposes of
storage of food, any other use is considered
dangerous and the manufacturer will not be
responsible for any omissions. Also, it is
recommended that you take note of the warranty
conditions. Please, to obtain the best possible
performance and trouble free operation from your
appliance it is very important to carefully read
these instructions. Failure to observe these
instructions may invalidate your right to free
service during the guarantee period.
SAFETY INFORMATION
This guide contains many
important safety
information. Please, we
suggest you keep these
instructions in a safe place
for easy reference and a
good experience with the
appliance.
The refrigerator contains a
refrigerant gas (R600a:
isobutane) and insulating
gas (cyclopentane), with
high compatibility with the
environment, that are,
however, inflammable.
Caution: risk of fire
If the refrigerant circuit
should be damaged:
Avoid opening flames
and sources of ignition.
Thoroughly ventilate the
room in which the appliance
is situated
Percentage running
WARNING!
Care must be taken
19
while
cleaning/carrying the
appliance to avoid
touching the
condenser metal
wires at the back of
the appliance, as you
might injure your
fingers and hands or
damage your
product.
This appliance is not
designed for stacking
with any other
appliance. Do not
attempt to sit or
stand on top of your
appliance as it is not
designed for such
use. You could injure
yourself or damage
the appliance.
Make sure that mains
cable is not caught
under the appliance
during and after
carrying/moving the
appliance, to avoid
the mains cable
becoming cut or
damaged.
When positioning
your appliance take
care not to damage
your flooring, pipes,
wall coverings etc. Do
not move the
appliance by pulling
by the lid or handle.
Do not allow children
to play with the
appliance or tamper
with the controls.
Our company
declines to accept
any liability should
the instructions not
be followed.
Do not install the
appliance in humid,
oily or dusty places,
nor expose it to
direct sunlight and to
water.
Do not install the
appliance near
heaters or
inflammable
materials.
If there is a power
failure do not open
the lid. Frozen food
should not be
affected if the failure
lasts for less than 20
hours. If the failure is
20
longer, then the food
should be checked
and eaten
immediately or
cooked and then
refrozen.
If you find that the lid
of the chest freezer is
difficult to open just
after you have closed
it, don’t worry. This is
due to the pressure
difference which will
equalize and allow
the lid to be opened
normally after a few
minutes.
Do not connect the
appliance to the
electricity supply
until all packing and
transit protectors
have been removed.
Leave to stand for at
least 4 hours before
switching on to allow
compressor oil to
settle if transported
horizontally.
This freezer must only
be used for its
intended purpose
(i.e. storing and
freezing of edible
foodstuff).
Do not store
medicine or research
materials in the Wine
Coolers. When the
material that requires
a strict control of
storage temperatures
is to be stored, it is
possible that it will
deteriorate or an
uncontrolled reaction
may occur that can
cause risks.
Before performing
any operation,
unplug the power
cord from the power
socket.
On delivery, check to
make sure that the
product is not
damaged and that all
the parts and
accessories are in
perfect condition.
If in the refrigeration
system a leak is
noted, do not touch
the wall outlet and
do not use open
flames. Open the
21
window and let air
into the room. Then
call a service center
to ask for repair.
Do not use extension
cords or adapters.
Do not excessively
pull or fold the power
cord or touch the
plug with wet hands.
Do not damage the
plug and/or the
power cord; this
could cause electrical
shocks or fires.
If the supply cord is
damaged, it must be
replaced by the
manufacturer, its
service agent or
similarly qualified
person in order to
avoid a hazard.
Do not place or store
inflammable and
highly volatile
materials such as
ether, petrol, LPG,
propane gas, aerosol
spray cans,
adhesives, pure
alcohol, etc. These
materials may cause
an explosion.
Do not use or store
inflammable sprays,
such as spray paint,
near the Wine
Coolers. It could
cause an explosion or
fire.
Do not place objects
and/or containers
filled with water on
the top of the
appliance.
We do not
recommend the use
of extension leads
and multi-way
adapters.
Do not dispose of the
appliance on a fire.
Take care not to
damage, the cooling
circuit/pipes of the
appliance in
transportation and in
use. In case of
damage do not
expose the appliance
to fire, potential
ignition source and
immediately ventilate
the room where the
appliance is situated.
22
The refrigeration
system positioned
behind and inside the
Wine Coolers
contains refrigerant.
Therefore, avoid
damaging the tubes.
Do not use electrical
appliances inside the
food storage
compartments of the
appliance, unless
they are of the type
recommended by the
manufacturer.
Do not damage the
refrigerant circuit.
Do not use
mechanical devices
or other means to
accelerate the
defrosting process,
other than those
recommended by the
manufacturer.
Do not use electrical
appliances inside the
food storage
compartments,
unless they are of the
type recommended
by the manufacturer.
Do not touch internal
cooling elements,
especially with wet
hands, to avoid
cracks or injuries.
Maintain the
ventilation openings
in the appliance
enclosure or in the
built-in structure,
free of obstruction.
Do not use pointed or
sharp-edged objects
such as knives or
forks to remove the
frost.
Never use hairdryers,
electrical heaters or
other such electrical
appliances for
defrosting.
Do not scrape with a
knife or sharp object
to remove frost or ice
that occurs. With
these, the refrigerant
circuit can be
damaged, the spill
from which can cause
a fire or damage your
eyes.
Do not use mechanical
devices or other
equipment to hasten
23
the defrosting
process.
Absolutely avoid the
use of open flame or
electrical equipment,
such as heaters,
steam cleaners,
candles, oil lamps
and the like in order
to speed up the
defrosting phase.
Never use water
wash the compressor
position, wipe it with
a dry cloth
thoroughly after
cleaning to prevent
rust.
It is recommended to
keep the plug clean,
any excessive dust
residues on the plug
can be the cause fire.
The product is
designed and built
for domestic
household use only.
The guarantee will be
void if the product is
installed or used in
commercial or nonresidential domestic
household premises.
The product must be
correctly installed,
located and operated
in accordance with
the instructions
contained in the User
Instructions Booklet
provided.
The guarantee is
applicable only to
new products and is
not transferable if
the product is resold.
Our company
disclaims any liability
for incidental or
consequential
damages.
The guarantee does
not in any way
diminish your
statutory or legal
rights.
Do not perform
repairs on this Wine
Coolers. All
interventions must
be performed solely
by qualified
personnel.
If you are discarding
an old product with a
lock or latch fitted to
24
Climate Class
Amb. T. (°C)
Amb. T. (°F)
SN
From 10 to 32
From 50 to 90
N
From 16 to 32
From 61 to 90
ST
From 16 to 38
From 61 to 100
T
From 16 to 43
From 61 to 110
the door, ensure that
it is left in a safe
condition to prevent
the entrapment of
children.
This appliance can be
used by children aged
from 8 years and
above and by persons
with reduced
physical, sensory or
mental capabilities or
with a lack of
experience and
knowledge; provided
that they have been
given adequate
supervision or
instruction
concerning how to
use the appliance in a
safe way and
understand the
hazards involved.
Children should not
play with the
appliance. Cleaning
and user
maintenance should
not be made by
children without
supervision.
Locks :If your
Fridge/Freezer is
fitted with a lock, to
prevent children
being entrapped
keep the key out of
reach and not in the
vicinity of the
appliance. If
disposing of an old
Fridge/Freezer break
off any old locks or
latches as a
safeguard.
COMBI REFRIGERATOR HOOVER
Climate Class
The appliance is designed to operate at the limited
range of ambient temperature, depending on
climate zones. Do not use the appliance at the
temperature out of the limit. Climate class of your
appliance is indicated on the label with technical
description inside the fridge compartment.
TRANSPORTATION
INSTRUCTIONS
The appliance should be transported only in a
vertical upright position. The packing as supplied
must be intact during transportation. If during the
course of transport the product has been
transported horizontally, it must only be laid on its
left hand side (when facing the door front) and it
must not be operated for at least 4 hours to allow
the system to settle after the appliance is brought
back to upright position.
1. Failure to comply with the above instructions
could result in damage occurring to the
appliance. The manufacturer will not be held
responsible if these instructions are
disregarded.
2. The appliance must be protected against rain,
25
moisture and other atmospheric influences.
INSTALLATION INSTRUCTIONS
1. If possible avoid placing the appliance near
cookers, radiators or in direct sunlight as this
will cause the compressor to run for long
periods. If installed next to a source of heat or
refrigerator, maintain the following minimum
side clearances:
From Cookers 4" (100 mm)
From Radiators 12" (300 mm)
From Fridges 4" (100 mm)
2. Make sure that sufficient room, with an
average temperature of between 16°C and
32°C, is provided around the appliance to
ensure free air circulation. Ideally, a space of
no less than 9cm on the back and 2cm on the
sides.
3. The appliance should be located on a smooth
surface.
4. It is forbidden to use the refrigerator
outdoors.
5. Protection from moisture. Do not locate the
freezer in moist space to avoid the metal parts
rusty. And do not spray water to the freezer,
otherwise it will weaken the insulation and
causes current leakage.
6. Refer to "Cleaning and Care" section to
prepare your appliance for use.
7. If the freezer is installed in unheated areas,
garages etc., in cold weather condensation
may form on the outer surfaces. This is quite
normal and is not a fault. Remove the
condensation by wiping with a dry cloth.
8. Never place Refrigerator in a wall recessed or
into fitted cabinets or fumiture when it is
working, the grille at the back may become
hot and the sides warm. Do not drape the
Refrigerator with any covering.
STARTING TO USE
Before you starting to use the freezer, please check
that:
1. The interior is dry and air can circulate
freely at the rear.
2. Clean the interior as recommended
under "TAKE CARE" section (electric
parts of the refrigerator can only be
wiped by dry cloth).
3. Do not switch on until 4 hours after
moving the fridge/freezer. The coolant
fluid needs time to settle. If the
appliance is switched off at any time,
wait 30 minutes before switching back
on to allow the coolant fluid to settle.
4. Before connecting the Refrigerator to
the mains supply position. The
thermostat control dias is located inside
the Fridge compartment.
5. Turn the thermostat knob to the “3”
position and turn on the electricity. The
compressor and the light inside the
refrigerator will begin to work.
6. Before storing foods in your refrigerator,
turn the refrigerator on and wait for 24
hours, to make sure it is working
properly and to allow the Fridge/Freezer
to fail to the correct temperature.
7. Open the door 30 minutes later, if the
temperature in the refrigerator
decreased obviously, it shows that the
refrigerator system works well. When
the refrigerator operates for a period of
time, the temperature controller will
automatically set the temperature
within limits it opens.
COMBI OPERATION
Appliance connected to power at the first time:
When the appliance is connected to power at the
first time, the display will be lit for 2 seconds before
going normal and the appliance runs with
intelligence function.
Display Control: When the refrigerator door is closed
and there is no button operation in 3 minutes, the
display light goes off.
When the display light is off, open the refrigerator
door or click any button to light it up.
VERTICAL DISPLAY (Only on some models)
TEMPERATURE SETTING: Click the “Fridge” or
“Freezer” button and when it flickers in the symbol,
temperatures can be set. Each time when the button
is clicked, the temperature changes accordingly.
Temperatures cannot be set under functions of fast
cooling, fast freezing, Smart ECO and vacation. Under
temperature setting, if there is no button operation
in 5 seconds, the button stops flickering and the set
temperature comes into effect.
SMART ECO: Activate the Smart Eco button to set
the temperatures of the fridge in max. energy
efficiency conditions (+4°C for fridge temperature, -
26
18°C for freezer temperature).
To enter Smart Eco: Click “option” until it flickers and
then click “OK” to enter this function.
To deactivate Smart Eco: Click “option” until it goes
to Smart ECO, click “OK” to quit this function and the
light goes off.
FAST COOLING: Activate Fast Cooling mode to start
an additional pulse for a fast freezing of the fridge
compartment. The function is activated and
confirmed by the switching on of the dedicated LED
icon.
To enter Fast Cooling: Click “option” until it flickers
in “Fast Cooling” and then click “OK” to enter this
function.
To deactivate Fast Cooling: Click “option” until it goes
to “fast cooling” and then click “OK” to deactivate
this function.
FAST FREEZING: Activate Fast Freezing to rapidly
freeze big quantities of food keeping intact
nutritional food properties. When the light in Fast
Freezing goes off and the freezer temperature goes
back to the value before fast freezing. When Fast
Freezing time is up (26 hours), it deactivates
automatically. When it goes to Vacation, Fast
Freezing stops.
To enter Fast Freezing: Click “option” until it flickers
in “Fast Freezing” and then click “OK” to enter this
function.
To deactivate Fast Freezing: Click “option” until it
goes to “fast freezing” and then click “OK” to quit
this function.
VACATION: In case of long stops, the Vacation
function can be used. This function deactivates the
fridge compartment, while leaving the freezer on.
Ensure that there is no food inside the fridge
compartment before using this function. The
function is activated and confirmed by the switching
on of the dedicated LED icon. The light in Vacation
goes off and the refrigerator temperature goes back
to the value before Vacation.
Vacation quits under functions of Smart ECO and Fast
Cooling.
To enter Vacation: Click “option” until it flickers in
“Fast Freezing” and then click “OK” to enter this
function.
To deactivate Vacation: Click “option” until it goes to
“Vacation” and then click “OK” to quit this function.
POWER OFF MEMORY: Refrigerator can
automatically keep all the setting in case of power
off. When the unit is plugged in again, the
refrigerator will run with the setting before power
off.
POWER-ON DELAY: To prevent harm to the
refrigerator in case of sudden power cut and power
on, the unit does not start immediately if the power
off time is less than 5 minutes.
FREEZER OVER-TEMPERATURE ALARM (only in case
of power on): When the freezer temperature is
higher than 10°Cat the first time connected to
power, the symbol light of the freezer chamber goes
on and the number representing temperature
flickers.
Press any button or wait for 5 seconds, flickering
stops and it goes back to the temperature that was
set.
REFRIGERATOR DOOR OPENING ALARM: When the
refrigerator is open over 3 minutes, the buzzer will
buzz. Close the door or press any button to stop the
alarm, but for the latter, the alarm will go off again
after 3 minutes.
SENSOR FAULT ALARM: When it shows “E0”, “E1”,
“E2” or other abnormal symbols, it means sensor
faults and the refrigerator needs repair.
TOP FEAUTRED VERTICAL DISPLAY
(Only on some models)
ALWAYS FRESH Button: On models with Always
Fresh Technology press the "Always Fresh" button to
activate the function.
SETTING Button: Press “SETTING” to change the
temperature.
When button is pressed for the first time: You can
change refrigerator temperature with ▲ PLUS
Button and ▼ MINUS Button.
When button is pressed for the second time: You can
change refrigerator temperature with ▲ PLUS
Button and ▼ MINUS Button.
On models with Always Fresh Technology press the
"Setting" button for 3 seconds to lock and unlock the
display.
ON/OFF Button: To turn on Refrigerator Press
ON/OFF button for 3 seconds. To turn off
Refrigerator: Press ON/Off button for 3 seconds.
Stand-by Mode: To save energy is possible to
activate Stanby Mode. The refrigerator will work in
normal state and all leds will turn OFF
To enter Stan-by Mode: Press ON/OFF button for 1
second.
To deactivate Stan-by Mode: Press ON/OFF button
for 1 second. Fridge back to normal operation.
ECO MODE Button: Press Eco Mode button to set
temperatures of the fridge in max. energy efficiency
conditions (+5°C for fridge temperature, -18°C for
freezer temperature). If you want to exit the ECO
mode function, you need to press the Eco Mode
button again and the refrigerator temperature turns
back to normal operation.
HOLIDAY Button: In case of long stops, the Holiday
function can be used. This function deactivates the
fridge compartment, while leaving the freezer on.
Ensure that there is no food inside the fridge
compartment before using this function. The
function is activated and confirmed by the switching
27
on of the dedicated LED icon. If you want to exit the
Holiday function, you will need to press the "Holiday"
button again, the light in Holiday goes off and the
refrigerator temperature goes back to the value
before Holiday.
SUPER COOLING Button: Press Super Cooling button
to start an additional pulse for a fast freezing of the
fridge compartment. The function is activated and
confirmed by the switching on of the dedicated LED
icon.
If you want to exit the Super Cooling function, you
need to press the Super Cooling button again and the
refrigerator temperature turns back to normal
operation.
SUPER FREEZING Button: Press Super Freezing
button to rapidly freeze big quantities of food
keeping intact nutritional food properties. If you
want to exit the Super Freezing function, you need to
press the Super Freezing button again and the
freezer temperature turns back to normal operation.
WI-FI Button: This appliance is equipped with OneFi+
technology that allows you to control it remotely via
App. Press OneFi+ button to activate Wi-Fi function.
Machine Enrollment (on App): Download the Hoover
Wizard App on your device. The Hoover Wizard App
is available for devices running both Android and iOS,
both for tablets and for smartphones. Get all the
details of the One Fi+ functions by browsing the App
in DEMO mode.
Open the App, create the user profile and enroll the
appliance following the instructions on the device
display or the "Quick Guide" attached on the
machine. This operation is necessary just for the first
installation. To finalize the enrollment following the
instruction on the smartphone’s screen.
Refrigerator usage from remote by App: When the
enrollment is completed, there will be Wi-Fi LED
switched on. From now on it will be possible to
manage the product by using the buttons on the
display or using the App: both of them will be aligned
according to the last command given.
LOCK Button: Press Lock button to block display user
interface (Lock icon enlights, “LO” appears on display
and, after 2 seconds, the refrigerator and freezer
temperature shows recovery). If you want to exit
Lock function, press the "Lock" button again for 3
seconds, and the refrigerator will exit the Lock
function.
INTERNAL USER INTERFACE (Only on
some models)
SET Button: Press SET button for setting the
temperature until you reach the level you want
where level 1 is the warmest and level 4 is the
coldest. Under normal operating conditions, we
recommend using an intermediate setting (level
2). Once the setting takes effect, it immediately
enters the corresponding stall for operation control,
and the stall indicator lights up 3s3min and then goes
out. Factory default temperature is set to 2.
Long press "SET" key to exceed 3s and enter the
hardware self-check program. The hardware selfcheck operation is effective within 10min, and the
long button operation after 10min is invalid.
WI-FI Button: This appliance is equipped with OneFi+
technology that allows you to control it remotely via
App. Press Wi-Fi icon for 3 seconds to activate Wi-Fi
function and the icon light changes from white to
blue.
Machine Enrollment (on App): Download the Wizard
App on your device. The Hoover Wizard App is
available for devices running both Android and iOS,
both for tablets and for smartphones. Get all the
details of the OneFi+ functions by browsing the App
in DEMO mode.
Open the App, create the user profile and enroll the
appliance following the instructions on the device
display or the "Quick Guide" attached on the
machine. This operation is necessary just for the first
installation. To finalize the enrollment following the
instruction on the smartphone’s screen.
Refrigerator usage from remote by App: When the
enrollment is completed, there will be Wi-Fi LED
switched on. From now on it will be possible to
manage the product by using the buttons on the
display or using the App: both of them will be aligned
according to the last command given.
FAST COOL Button: when "FAST COOL" button is
pressed, rapid cooling function is activated,
according to the 21°C to refrigeration control gear.
Maximum running time is 3h, after this time
temperature will be set to 1.
If the "SET" button is pressed in the process of speed
cooling, the instant cooling function is immediately
withdrawn and the default is entered into the next
gear.
TECHNICAL FEATURES
HUMIDITY EQUALISER (Only on some
models)
The exclusive Hoover
Humidity Equaliser uses this
humidity naturally
generated by fruits and
vegetables to keep always a
level between 85% and
95%.
ALWAYS FRESH TECHNOLOGY (Only
on some models)
Is the innovative Hoover technology that allows you
to preserve food better and longer, both in the
refrigerator and in the freezer.
Always Fresh promotes the maintenance and
preservation of foods by interacting with their
enzymatic activity through the activation of water
molecules, naturally present in them.
Preservation technology is activated by a suitable
button on the display.
28
DO
DON’T
Defrost food from the
freezer thoroughly in a
fridge or in a microwave
oven following defrosting
and cooking instructions.
Use pointed sharp
edged objects such as
knives, forks to remove
the ice.
Defrost frozen meat
Put hot food in the
Always Fresh must be switched off during the energy
consumption test.
WATER DISPENSER (Only on some
models)
The water dispenser allows you to get chilled water
compartment.
- Lift the water tank out of the fridge compartment.
- Open the water tank cover and then clean the
water tank and cover
in warm soapy water. Rinse thoroughly.
- After cleaning, attach the cover to the water tank
and then replace
the water tank back on the fridge door.
- Clean the dispenser pad outside the fridge door.
Filling the water tank with water
- Open the small cover.
- Fill the water tank with drinkable water up to the
Max line.
- Close the small cover.
Dispensing
To dispense water, push the dispenser pad gently,
using
a glass or container. To stop the flow of water, pull
your glass away from the
dispenser pad.
Tips for keeping food perfect in the
Fridge
Take extra care with meat and fish: cooked meats
should always be stored on a shelf above raw meats
to avoid bacterial transfer. Keep raw meats on a
plate which is large enough to collect juices and
cover it with cling film or foil.
Leave space around food: this allows cold air to
circulate around the Fridge, ensuring all parts of the
Fridge are kept cool.
Wrap up food!: to prevent transfer of flavors and
drying out, food should be separately packed or
covered. Fruit and vegetables need not be wrapped.
Pre-cooked food should be cooled properly: allow
pre-cooked food to cool down before placing in the
Fridge. This will help to stop the internal
temperature of the Fridge from rising.
Shut the door!: to prevent cold air escaping, try to
limit the number of times you open the door. When
retuning from shopping, sort foods to be kept in your
Fridge before opening the door. Only open the door
to put food in or take it out.
Where to store your foods in the fridge
Cool area: this is where to store foods which will
without opening the fridge
compartment door.
Before first use
Before using the water
dispenser for the first time,
remove and clean
the water tank located
inside the fridge
keep longer if they are kept cool. Milk, eggs, yogurt,
fruit juices, hard cheeses eg. Cheddar. Opened jars
and bottles of salad dressings, sauces and jams. Fats,
eg. Butter, margarine, low-fat speads, cooking fats
and lard.
Coldest area (0°C to 5°C): this is where foods which
must be cold to keep them safe should be kept:
·Raw and uncooked foods should always be
wrapped.
·Pre-cooked chilled foods, eg. Ready meals, meat
pies, soft cheeses.
·Pre-cooked meats eg. Ham,
·Prepared salads(including pre-packed mixed green
salads, rice, potato salad etc).
·Desserts, eg. Fromage frais, home-prepared food
and leftovers or cream cakes.
Crisper: this is the most humid part of the Fridge.
Vegetables, fruit, fresh salad items eg. Unwashed
whole lettuce, whole tomatoes, radishes etc can be
stored here.
WE RECOMMEND THAT ALL PRODUCE KEPT IN THE
SALAD BIN IS WRAPPED.
NOTE：Always wrap and store raw meat, poultry
and fish on the lowest shelf at the bottom of the
fridge. This will stop them dripping onto, or touching
other foods. Do not store inflammable gasses or
liquids in the fridge.
Electrical operation after 3h on the freezer, the
temperature in the cabinet above -12°C, the alarm
light is lit, and buzzer sounds.
Storing Frozen Food
Prepackaged commercially frozen food should be
stored in accordance with the frozen food
manufacturer’s instructions for a freezer
compartment.
To ensure that the high quality achieved by the
frozen food manufacturer and the food retailer is
maintained the following should be remembered:
1．Put packets in the freezer as quickly as
possible after purchase.
2．Do not exceed “Use By”, “Best Before” dates
on the packaging.
29
completely before
cooking.
freezer. Let it cool down
first.
Store commercially
frozen food in accordance
with the instructions
given on the packets that
you buy.
Put liquid-filled bottles
or sealed cans
containing carbonated
liquids into the freezer
as they may burst.
Check contents of the
refrigerator at regular
intervals.
Remove items from the
freezer with wet hands.
Clean and defrost your
refrigerator regularly.
Freeze fizzy drinks.
Prepare fresh food for
freezing in small portions
to ensure rapid freezing.
Consume ice-cream and
water ices direct from
freezer. It may cause
“freezer burns” on lips.
Always choose high
quality fresh food and be
sure it is thoroughly clean
before you freeze it.
Store poisonous or
dangerous substances in
the freezer.
Wrap all foods in
aluminum foil or freezer
quality plastic bags and
make sure any air is
excluded.
Wrap frozen food when
you buy it and put it into
the freezer shortly.
Keep food for as short a
time as possible and
adhere to “Best Before”,
“Use By” dates.
For more about storing, download the App and visit
“Tips & Hints”.
ENERGY SAVING
For better energy saving we suggest:
Installing the appliance away from heat
Avoid putting hot food into the
Do not excessively stuff foods so as to
Defrost the appliance in case there is ice
In case of absence of electrical energy, it
Open or keep the doors of the appliance
Avoid adjusting the setting to
Remove dust present on the rear of the
sources and not exposed to direct
sunlight and in a well-ventilated room.
refrigerator to avoid increasing the
internal temperature and therefore
causing continuous functionalizing of
the compressor.
ensure proper air circulation.
to facilitate the transfer of cold.
is advisable to keep the refrigerator
door closed.
open as little as possible.
temperatures too cold.
appliance.
TAKE CARE
Defrosting
This appliance has automatic defrosting system, no
need to defrost by hand.
Cleaning and Care
After defrosting you should clean the Fridge/Freezer
internally with a weak solution of bicarbonate of
soda. Then rinse with warm water using a damp
sponge or cloth and wipe dry. Wash the baskets in
warm soapy water and ensure they are completely
dry before replacing in the Fridge/Freezer.
Condensation will form on the back wall of the
Fridge; however it will normally run down the back
wall and into the drain hole behind the salad bin.
The drain hole will have a “cleaning spike” inserted
into it. This ensures that small pieces off food can
not enter the drain. After you have cleaned the
inside of your Fridge and removed any food residues
from around the whole, use the “cleaning spike” to
make sure that there are no blockages. Use standard
furniture polish to clean the Fridge/Freezer exterior.
Make sure that the doors are closed to prevent
polish getting on the magnetic door seal or inside.
The grille of the condenser at the back of the
Fridge/Freezer and the adjacent components can be
vacuumed using a soft brush attachment.
Do not use harsh cleaners, scouring pads or solvents
to clean any part of the Fridge/Freezer.
CHANGING THE INTERNAL LIGHT
1. Before carrying out the LED replacement
always disconnect the mains supply.
2. Hold and lift up the LED light cover.
3. Remove the old LED by unscrewing it in an
anti-clockwise direction.
4. Replace with a new LED light by screwing it in a
clockwise direction marking sure that it is
secure in the light holder.
5. Refit the light cover and re-connect your
Fridge to the mains supply and switch on.
REVERSING THE DOOR SWING
Dissemble the Refrigerator Door
1. a．Use a tool to remove the screw off the
hinge cover, and then remove the latter. Insert
the communication line to the hole on the
cabinet top.
b． Use a tool to remove the 4 screws off the
upper hinge cover and then remove the latter.
Pry up the door bush and small end cap cover
on the door.
c． Insert the door bush and door
communication line into the hole on the door
and then put on the small end cap cover.
d． Use a tool to remove the 2 screws as
shows in the below figure to remove the hole
cover on the cabinet top and get the cabinet
communication line out of the hole.
Pry up the small end cap cover on the door
and get out the door bush and door
communication line.
30
e． Insert the door bush into the round hole
on the door and then put on the small end cap
cover.
f． Move the refrigerator door upward over
500mm to remove the door.
2. a． Use a tool to remove the 3 screws off
the middle hinge cover and then remove the
middle hinge.
b． move the freezer door upward over
500mm to remove the door.
c． Remove the adjustable front feet under
the lower hinge; use a tool to remove the 4
screws from the lower hinge and then
disassemble the lower hinge. Door disassembly
is finished.
Assemble door, lower hinge
accessories to the corresponding
positions
1. a． Use a tool to get the door bush out as
shown in the below figure and assemble it to
the corresponding position of the other side.
b． Use a tool to remove the screws off the
stopper ass as shown in the below figure and
then assemble them to the other side of the
door.
c． Use a tool to remove the axle and two
stoppers on the lower hinge and then
assemble them to the position as shown in the
below figure.
Assemble the refrigerator door and
freezer door to the opposite side
1. a． Remove the adjustable front foot as
shown below by hand and then assemble the
lower hinge to the other side of the cabinet
and fix the screws by using a tool.
b． Assemble the shorter adjustable front foot
to the lower hinge side and adjust the height
of the foot to make the refrigerator stay in
level.
2. Put on the freezer door and turn the middle
hinge by 180 °C and then assemble it to the
other side of the cabinet; use a tool to screw
up the 3 screws to fix the middle hinge.
3. Put on the refrigerator door and assemble
the upper hinge to the other side of the
cabinet; use a tool to screw up the 4 screws to
fix the upper hinge.
4. After that, connect the door
communication line and the cabinet
communication line and then put on the upper
hinge cover and fix it using a screw.
Assemble the hole cover to the other side of
the cabinet and use a tool to screw up the hole
cover.
Door disassembly is finished here.
Double check that the door is aligned correctly and
all the seals are closed on all sides. If necessary, readjust the levelling feet.
NOTE: If you want to have the door swing reversed,
we recommend that your contact a qualified
technician. You should only try to reverse the door
yourself if you believe that you are qualified to do so.
All parts removed must be saved to do the
reinstallation of the door. You should rest the fridge
freezer on something solid so that it will not slip
during the door change process. Do not lay the fridge
freezer flat as this may damage the coolant system.
Ensure the fridge freezer is unplugged and empty.
We recommend that 2 people handle the fridge
freezer during assembly.
TROUBLE SHOOTING
If the appliance does not operate when switched on,
check.
Power cut: If the internal temperature of the
Fridge/Freezer compartment is -18°C or less when
the power returns, your food is safe. The food in your
Fridge/Freezer will remain frozen for approx 16
hours with the door closed. Do not open the
Fridge/Freezer door more than necessary.
The product is designed and built for domestic
household use only.
The plug is inserted properly in the socket and that
the power supply is on. (To check the power supply
to the socket, plug in another appliance).
The fuse has blown/circuit breaker has tripped/main
distribution switch has been turned off.
The temperature control has been set correctly.
If the refrigerator is exceptionally cold, you may have
accidentally adjusted the thermostat control dial to a
higher position.
If the refrigerator is exceptionally warm, the
compressor may not be working. Turn the
thermostat control dial to the maximum setting and
wait a few minutes. If there is no humming noise, it is
not working. Contact the local store where your
purchase was made.
If condensation appears outside of the Refrigerator,
this may be due to a change in the room
temperature. Wipe off any residue of moisture. If the
problem continues contact the local store where
your purchase was made.
If the provided plug has been replaced make sure the
new plug is properly connected. If the appliance is
still not operating after the above checks, please
contact Customers Service.
SCRAPPING OLD APPLIANCES
This appliance is marked according to the European
directive 2012/19/EU on Waste Electrical and
Electronic Equipment (WEEE).
31
WEEE contains both polluting substances (which can
cause negative consequences for the environment)
and basic components (which can be re-used). It is
important to have WEEE subjected to specific
treatments, in order to remove and dispose properly
all pollutants, and recover and recycle all materials.
Individuals can play an important role in ensuring
that WEEE does not become an environmental issue;
it is essential to follow some basic rules:
WEEE should not be treated as household waste.
WEEE should be handed over to the relevant
collection points managed by the municipality or by
registered companies. In many countries, for large
WEEE, home collection could be present.
In many countries, when you buy a new appliance,
the old one may be returned to the retailer who has
to collect it free of charge on a one-to-one basis, as
long as the equipment is of equivalent type and has
the same functions as the supplied equipment.
Conformity
By placing the mark on this product, we are
confirming compliance to all relevant European
safety, health and environmental requirements
which are applicable in legislation for this product.
32
HOOVER HOOVER GROUP S.R.L.
Via Privata Eden Fumagalli
20861 Brugherio Milan Italy
Loading...
