Hoover 5012PH User Manual

5012

Motor

Vogue

VOGUE

Bagless Vacuum

Cleaner with

Powerhead

Compact Powerhead for

a Powerful Clean

Washable HEPA Filtration

Bagless, Cyclonic Technology

High Eﬃciency Soft Start Motor

High Eﬃciency

One Touch Empty

7 8

5012PH Heritage

Congratulations on your purchase of your new HOOVER vacuum cleaner. There are many useful features built into your cleaner and we recommend that you carefully read this instruction book so that you may take best advantage of them.

Features:

1. Handle

2. Hose

3. Air Outlet

4. Handle Release Button

5. Telescopic Tube

6. Powerhead

7. Handle

Accessories: (not shown)

Combination Floor Brush Crevice Tool

Upholstery Tool

3.4.

Dusting Brush

Speciﬁcations:

Max. Watts: 1100W + 100W = 1200W Motor: High eciency soft start Dust Capacity: 1.8L Noise Level: <72dBa Telescopic Tube: Aluminium

8. Dust Canister Release Button

9. Dust Canister

10. Automatic Cord Retract Button

11. Power Cable and Plug

12. Upright Park (Combination

oor head only)

13. On/O Button

Power Cable Length: 5m Hose Length: 1.9m Net Weight: 6.77kg Operating Radius: 8m Filtration: HEPA

e u

Fea

Before you begin

The cleaner must be operated in accordance with these instructions and used only for domestic household cleaning to remove DRY dirt and dust from household carpets, ﬂooring and fabrics. This cleaner is not ﬁt to be used as an industrial cleaner, and is not designed for the collection of vitreous building material including particle board, construction products and similar products such as wood/ﬁbres, cement, ﬁllers, ﬁbre glass etc or excessive or frequent sand. The infrequent pick-up of these materials in these circumstances may be harmful to your cleaner and may void the manufacturer’s warranty.

Please read these instructions thoroughly

This will ensure you obtain full beneﬁt from your new cleaner. Keep this Instruction Manual in a handy place for future reference.

Important

Always switch the cleaner oﬀ and remove the plug from the electricity supply before cleaning your appliance, when not in use, or attempting any maintenance task. The cleaner must only be connected to an AC supply at the voltage shown on the rating plate. This cleaner should only be used for its intended purpose as described in these instructions. Never operate the vacuum cleaner without lters.

Before you begin

Precautionary measures:

If the opening that sucks in the air, the suction pipe or the telescopic wand are blocked, you should switch o the vacuum cleaner at once. First clear the blocked substance before you attempt to start the vacuum cleaner again.

1. Do not operate the vacuum cleaner too close to heaters and like radiators, cigarette butts etc.

2. Before you insert the plug into the wall contact, make sure your hand is dry.

3. Before you start using the vacuum cleaner, please remove large or sharp objects from the ﬂoor in order to prevent that the paper ﬁlter is damaged.

4. When you want to pull the plug from the wall contact, please do this at the plug itself and not by means of the electrical cable.

This vacuum cleaner is equipped with a plug and a cable, which rewinds automatically. If anything gets damaged, both the plug and the cable must be repaired by a qualied technician.

Warning

To reduce the risk of ﬁre, electric shock, or injury:

1. Do not leave the appliance connected to the mains power supply when not in use. Disconnect from any power supply before performing any maintenance duties.

2. To reduce the risk of electric shock, do not use outdoors or on wet surfaces.

3. This appliance must not be used as a toy. Do not allow children to use the appliance unattended.

4. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure they do not play with the appliance.

5. Use only as described in this instruction manual. Do not use for any other purpose except those outlined in this instruction manual.

6. If the power cable or plug appears damaged, do not use. If the vacuum cleaner is not working correctly, has been dropped, damaged, left outdoors, or dropped into water, return to a Hoover service agent or contact Hoover Customer Care: 1300 360 845 / sales@hooverﬂoorcare.com.au / www.hooverﬂoorcare.com.au.

7. Do not pull or carry the appliance by the power cable, use the power cable as a handle, or pull the power cable around sharp edges or corners. Avoid running the appliance over the power cable.

8 Keep the appliance away from heated surfaces.

9. Unplug the appliance by lightly grasping and pulling the plug from the wall. Do not unplug the machine by pulling on the power cable.

10. Do not handle the appliance and/or power cable with wet hands.

11. Always ensure that all openings and entry points on the appliance are clear from objects or any blockages before commencing use. Removal of dust, lint, hair and dirt from all openings and entry points will help improve airﬂow on the appliance.

12. Keep hair, loose clothing, ﬁngers and all body parts away from openings and entry points on the appliance.

13. Ensure the appliance is switched oﬀ before unplugging.

14. Use extra care when cleaning on stairs.

15. Do not use the appliance to pick up ﬂammable items or combustible liquids (i.e. petrol, hot ashes, cigarettes, matches or anything burning) or use in areas where such substances and items may be present.

16. Hold the plug when rewinding onto cord reel. To prevent accidental injury do not allow the plug to whip when rewinding.

17. Ensure the appliance is disconnected from the mains power supply before connecting the hose to the unit.

18. Do not use the appliance without dust bag and/or ﬁlter in place.

19. If the power cable is damaged, return to a Hoover service agent or contact Hoover Customer Care in order to avoid a hazard.

20. Do not extend the power cable beyond the red mark.
