Performer
3000
PERFORMER
Compact Bagged
Vacuum Cleaner
Traditional Bagged System
4 Stage Filtration
Compact Stylish Design
11449_HV_Performer_3000_Manual_V7.indd 1 16/08/11 4:48 PM
3000 Performer
Features
Congratulations on the purchase of your new HOOVER vacuum cleaner. There are many
useful features built into your cleaner and we recommend that you carefully read this
5
4
6
3
2
7
9
8
1
instruction manual so that you may take best advantage of them.
Features:
1. Hose Inlet
2. Cable Rewind Button
3. Speed Control
4. On/Off Button
5. Hose
6. Handle
7. Telescopic Tube
8. Floor Head
9. Carry Handle
Specifications:
Watts: 1400W
Dust Capacity: 2L
Noise Level: <86dBa
Telescopic Chrome Tube: 560mm
Power Cable Length: 4m
Weight: 4.8kg
11449_HV_Performer_3000_Manual_V7.indd 2-3 16/08/11 4:48 PM
Before you Begin
Before you begin
Before you begin
The cleaner must be operated in accordance with these instructions and used only for domestic household
cleaning to remove DRY dirt and dust from household carpets, flooring and fabrics. This cleaner is not fit to
be used as an industrial cleaner, and is not designed for the collection of vitreous building material including
particle board, construction products and similar products such as wood/fibres, cement, fillers, fibre glass
etc or excessive or frequent sand. The infrequent pick-up of these materials in these circumstances may be
harmful to your cleaner and may void the manufacturer’s warranty.
Please read these instructions thoroughly
This will ensure you obtain full benefit from your new cleaner. Keep this Instruction Manual in a handy place
for future reference.
Important
Always switch the cleaner off and remove the plug from the electricity supply before cleaning your unit,
when not in use, or attempting any maintenance task. The cleaner must only be connected to an AC supply
at the voltage shown on the rating plate. This cleaner should only be used for its intended purpose as
described in these instructions. Never operate the vacuum cleaner without filters.
Precautionary measures:
1. Do not operate the vacuum cleaner too close to heaters, radiators, and other
hot surfaces.
2. Before inserting the plug into the wall, make sure your hand is dry.
3. Before turning on the vacuum cleaner, remove any large or sharp objects from
the floor or cleaning surface in order to prevent damage to the filter.
4. When you want to pull the plug from the wall, do not use the power cable,
gently pull the plug from the power socket.
If the air inlet, floor head or telescopic tube are blocked, you should switch off
5.
the cleaner straight away and remove from mains power. First clear the blocked
substance before attempting to start the vacuum cleaner again.
11449_HV_Performer_3000_Manual_V7.indd 4-5 16/08/11 4:48 PM
Warning
Instructions for Use
Always remove the plug from the power socket before fitting or removing accessories!
the appliance has finished charging.
any power supply before performing any maintenance duties.
2. To reduce the risk of electric shock, do not use outdoors or on wet surfaces
3. This appliance mus t not be used as a toy. Do not allow children to use the ap pliance unattended.
no esU .4
in this instruction manual.
5. If the power cable or plug appears damaged, do not use. If the cleaner is not working correctly, has been
dropped, damaged, left outdoors, or dropped into water, return to a Hoover service agent or contact Hoover
around sharp edges or corners. Avoid running the appliance over the power cable.
7. Keep the appliance away from heated surfaces.
8. Unplug the charger by lightly grasping and pulling the plug from the wall. Do not unplug the charger by pulling
on the power cable.
9. Do not handle the appliance and/or power cable with wet hands.
10. Always ensure that all openings and entry points on the appliance are clear from objects or any blockages
before commencing use. Removal of dust, lint, hair and dirt from all openings and entry points will help improve
13. Use extr a care when cleaning on stairs .
matches or anything burning) or use in areas where such substances and items may be present.
16.
If the power cable is damaged, return to a Hoover service agent or contact Hoover Customer Care in order to
avoid a hazard.
17.
18.
combustible liquids (i.e. gasoline, hot ashes, cigarettes,
appliance.
morf tcennocsiD .esu ni ton nehw ylppus rewop sniam eht ot detcennoc regrahc eht evael ton oD .1
deniltuo esoht tpecxe esoprup rehto yna rof esu ton oD .launam noitcurtsni siht ni debircsed sa yl
been
for
a
b
elbac rewop eht llup ro ,eldnah a sa elbac rewop eht esu ,elbac rewop eht yb ecnailppa eht yrrac ro llup ton oD .6
d
c
Connection for hand vac and body
a. Body of stick vac
b. Hand vac
c. Air inlet
d. Hand vac release button
Instructions for Use
Instructions for use
Floor Head
Extension Tube
Maintenance
Always remove the plug from the power socket before fitting or removing accessories!
Connecting the vacuum cleaner
1. Assembling or removing the hose.
Assembly
a. Insert the flexible hose into the hose inlet on the front of
the vacuum cleaner.
b. Press until it clicks into position.
Removal
a. Remove the plug from the power socket when releasing
the hose from the air intake duct. Do this by gently pulling
on the hose while the release buttons are depressed.
2. Fitting the telescopic tube, accessories and floor head.
a. Remove the plug from the power supply when releasing
the hose from the hose inlet. Do this by gently pulling on
the flexible hose while the release buttons are depressed.
b. To fit the floor head to the telescopic tube, gently insert the
telescopic tube into the top of the floor head as shown.
The adjustable floor head is ideal for cleaning on carpets
and hard floors.
Changing the dust bag
• Alwaysoperatethecleanerwithdustbaginstalled.
• Ifyouforgettoattachthedustbagorattachitinthewrongmanner,thedustcover
may not close completely.
1. After removing the hose, open the front cover
by gently lifting the release button.
2. Rotate the support of the dust bag to the
correct position.
3. Remove the dust bag.
4. Replace with a new dust bag.
5. Close the cover by pressing down on the cover
until it is securely locked in place.
Carpet Hard Floors
11449_HV_Performer_3000_Manual_V7.indd 8-9 16/08/11 4:48 PM
Maintenance
Cleaning the filter
Ensure the cleaner is not connected to the mains power when performing any maintenance duties.
•Theltershouldbecleanedatleasttwiceayearorwhendirtisvisibleonthelter.
•Alwaysoperatethecleanerwithlterinstalledtopreventmotordamageandmaximizeperformance.
•Donotuseawashingmachinetorinsethelter.
•Donotusehairdriertodryit.
Customer Care
Please contact Hoover Customer Care: 1300 360 845 to find your local spare parts provider.
Changing the filter
1. After removing the hose, open the front cover by gently
lifting the release button.
2.
Rotate the support of the dust bag to the correct position.
3. Remove the dust bag.
4. Pull the filter supporter outward.
5. Gently remove the filter.
4. Rinse the filter in lukewarm water and dry the filter
completely before reinstalling.
1. After removing the hose, open the front cover
by gently lifting the release button.
2. Rotate the support of the dust bag to the correct position.
3. Remove the dust bag.
4. Pull the filter supporter outward.
5. Gently remove the filter.
6. Replace with a new filter, ensure it is securely inserted.
7. Replace the dust bag and close the cover by pressing on
the lid until it is securely locked in place.
Part Part Number
Filter set 32200734
Hose 31220422
Dust bag (pack of 5) 32420359
11449_HV_Performer_3000_Manual_V7.indd 10-11 16/08/11 4:48 PM
Conditions of warranty
Your Hoover cleaner, in the case of domestic use, has a one
year parts and labour warranty against product defects
and failures when the product is used in accordance with
the terms and conditions of this warranty statement.
This warranty commences from the original date of
purchase and is not transferable; please retain your original
proof of purchase for any warranty claims. This warranty is
valid only in the country where the cleaner is purchased.
The cleaner must be operated in accordance with these
instructions and used only for domestic household
cleaning to remove DRY dirt and dust from household
carpets, flooring and fabrics. This cleaner is not fit to be
used as an industrial cleaner, and is not designed for the
collection of vitreous building material including particle
board, construction products and similar products such
as wood/fibres, cement, fillers, fibre glass etc or excessive
or frequent sand. The infrequent pick-up of these
materials in these circumstances may be harmful to your
cleaner and may void the manufacturer’s warranty.
Accessories and consumables including dust bags and
filters, unless defective in manufacture, are not subject to
this warranty. In order to prolong the life of accessories and
consumables, regular care and maintenance is recommended.
When properly used and cared for, your cleaner
will render excellent service; refer to the instruction
manual for further details, as misuse or failure to
follow the instructions makes this warranty void.
In the event of service or advice being needed, please
contact Hoover Floorcare Asia Pacific Pty Ltd, Level 1,
Building 2 Brandon Park Business Park, 530 Springvale Road,
Glen Waverley Victoria 3150, or on 1300 360 845, MondayFriday 9am-5pm EST. The decision to repair or replace the
cleaner is at the sole discretion of Hoover Floorcare. If Hoover Floorcare
decide to repair or replace the cleaner, it will do so at its own cost.
Hoover Floorcare is unable to accept responsibility under this
warranty for any repair work not carried out by an authorised
Hoover Service Agent or from the use of non-genuine parts.
If any part is no longer available or manufactured, Hoover
Floorcare will replace it with a genuine functional replacement
part. This warranty does not apply to the cost of replacing any
parts of the product due to normal wear and tear, alterations,
improper installation, physical abuse, misuse or accidental
damage. Any transportation costs involved in the repair of
defective parts shall be borne by the claimant.
If proof of purchase cannot be provided at the time of
a warranty claim or service, any work carried out on
the cleaner is chargeable.
The repair or replacement of the cleaner under
this warranty does not extend the original period
of warranty.
The benefits conferred by this warranty are
in addition to all other rights and remedies in
respect of the product as outlined under the
Competition and Consumer Act and other State
and Territory laws.
“Our goods come with guarantees that cannot
be excluded in the Australian Consumer Law.
You are entitled to a replacement or refund
for a major failure and for compensation for
any other reasonably foreseeable loss or
damage. You are also entitled to have the
goods repaired or replaced if the goods fail
to be of acceptable quality and the failure
does not amount to a major failure.”
Australia 1300 360 845
To find out more about our range,
visit: www.hooverfloorcare.com.au
email: sales@hooverfloorcare.com.au
Call Hoover Floorcare
with any product queries
11449_HV_Performer_3000_Manual_V7.indd 12 16/08/11 4:48 PM
