Honeywell V5011F, V5011G Catalog Page

Download

Flanged Globe Valves

3-1/2 WITH STEM DOWN

DIMENSIONS

1/2 3/4 1 1-1/4 1-1/2 2 2-1/2 3

2 1-3/4 1-7/8 2 2-7/8 3-1/8 2-3/4 3-1/8

51 45 48 51 73 80 70 80

1-3/4 1-3/4 1-3/4 1-5/8 1-5/8 2 2-3/8 2-5/8

45 45 45 42 42 51 61 67

3-3/8 3-3/8 4-1/4 4-7/8 5-5/8 5-5/8 7-1/2 8-7/8

86 86 108 124 143 143 191 226

AB C

V5011F,G THREADED DIRECT BODY

inin

mmmm

BODY STYLE

PIPE SIZE

(in.)

M2804A

V5011F,G

V5011F,G Two-Way Threaded Globe Valves

Used for two-position or modulating control of steam and water and glycol solutions (to 50 percent concentration) in heating or cooling systems.

• Sizes range from 2-1/2 to 3 inches

• Direct acting

• High pressure steam models with stainless steel trim

• Spring-loaded, self-adjusting packing

• Stainless steel stem prevents corrosion

• Valve designs provide equal percentage characteristics of flow for close control of water, and linear characteristic of flow for close control of steam or chilled water

• Valves utilize direct mounting, electric or pneumatic linear valve actuators; Q5001 linkage with Modutrol Motor; or Q5020/Q5022A linkages with Direct Coupled Actuators to operate the valve

Dimensions in inches (millimeters)

Valve Type: Globe Valve Body Pattern: Two-way, Straight-through Connection Type: Female NPT Controlled Medium: Chilled or hot water with up to 50% Glycol;

not for use with steam or fuels

Leakage Rating: 0.5% of Cv Maximum Differential for Quiet Water Service: 20 psid (138 kPa) Fluid Temperature Range: 40 F to 337 F (4 C to 169 C) Stem Travel: 3/4 in. (20 mm) Bonnet Size: 1 3/8 in. (35 mm) Valve Action: Stem down to close ANSI/ASME Rating: 150 Actuation: Must be purchased separately Approvals CRN Number: 0C0861.9087YTN

Commercial

V5011F

V5011G

Valve Size Flow Capacity Flow

Product Number

V5011F1105/U 2 1/2 in. DN65 63 Cv 54 kvs Equal

V5011F1113/U 3 in. DN80 100 Cv 85 kvs Equal

Characteristic

Percentage

V5011G1111/U 2 1/2 in. DN65 63 Cv 54 kvs Linear 240 psi water at 150 F;

V5011G1129/U 3 in. DN80 100 Cv 85 kvs Linear 240 psi water at 150 F;

Maximum Safe Operating Pressure

217 psi at 250 F water; 250 psi at 100 F water

100 psi at 337 F steam

70-6910 549

Materials

Body Cartridge Packing Plug/Ball/Disc Seat Stem

Red

Brass Teflon and

Brass

Red

— Teflon

Brass

Nitrile

Cone

Brass plug with Teflon® disc

Stainless Steel plug with carbon-loaded Teflon® disc

Brass Stainless

Steel

Stainles

Stainless

s Steel

Steel

Used With(inch) DN (Cv) (Kv) (psi) (kPa)

1496 psi at 121 C water; 1724 kPa at 38 C water

240 psi at 66 C; 690 kPa at 69C steam

Q5001/Modutrol IV Motor; MP953; ML6420,21A,25; ML7420/ML7421A/ ML7425; ML6984/ML7984; Q5020/DCA

Q5020/DCA; ML6984/ML7984; ML7420/ML7421A/ML7425; ML6420,21A,25; Q5001/Modutrol IV Motor; MP953

ML6984/ML7984; Q5020/DCA; Q5001/ Modutrol IV Motor; MP953; ML6420,21A,25; ML7420/ML7421A/ ML7425

ML7420/ML7421A/ML7425; ML6420,21A,25; Q5001/Modutrol IV Motor; MP953; Q5020/DCA; ML6984/ ML7984

Components

Flanged Globe Valves

1,2

M17378A

in. (mm)Bin. (mm)

1/2 3/4

1 1-1/4 1-1/2

3-1/4 (83)

4-1/16 (103) 4-3/16 (106)

4-3/4 (120) 5-1/4 (134)

1-9/16 (40)

1-13/16 (47)

VALVE

SIZE (IN)

in. (mm)

V5011N1XXX

V5011N2XXX

3-1/2 (89)

5-1/4 (133)

VALVE

Y2 WITH STEM EXTENSION FOR MP953C,E (8 IN. ONLY)

STEM FULLY DOWN

STEM FULLY UP

5-15/16 (151)4-3/16 (107)

V5011N3XXX

V5011N Two-way Globe Valves

Used for two-position or modulating control of steam and water and glycol solutions (to 50 percent concentration) in heating or cooling systems.

• Sizes range from 1/2 to 2 inches

• Direct and reverse acting

• High pressure steam models with stainless steel trim

• Spring-loaded, self-adjusting packing

• Stainless steel stem prevents corrosion

• Valve designs provide equal percentage characteristics of flow for close control of water, and linear characteristic of flow for close control of steam or chilled water

• Valves utilize direct mounting, electric or pneumatic linear valve actuators; Q5001 linkage with Modutrol Motor; or Q5020/Q5022A linkages with direct coupled rotary actuators to operate the valve

• Not suitable for combustible gases

Dimensions in inches (millimeters)

Valve Size Flow Capacity

Product Number

V5011N1008/U 1/2 in. DN15 0.73 Cv 0.63 kvs Equal

V5011N1016/U 1/2 in. DN15 1.2 Cv 1.0 kvs Equal

V5011N1024/U 1/2 in. DN15 1.85 Cv 1.6 kvs Equal

V5011N1032/U 1/2 in. DN15 2.9 Cv 2.5 kvs Equal

V5011N1040/U 1/2 in. DN15 4.7 Cv 4.0 kvs Equal

550 customer.honeywell.com 70-6910

Flow Characteristic

Percentage

Valve Type: Globe Valve Body Pattern: Tw o- w ay Connection Type: Female NPT Controlled Medium: Chilled or hot water with up to 50% Glycol;

not for use with steam or fuels

Leakage Rating: Seat: 0.05% of Cv Maximum Differential for Quiet Water Service: 20 psid (138 kPa) Maximum Differential Pressure Ratings (Close-off): 240 psi (1655

kPa)

Ambient Temperature Range: 36 F to 248 F water (2 C to 120 C water) Stem Travel: 3/4 in. (20 mm) Bonnet Size: 1 3/8 in. (35 mm) ANSI/ASME Rating: 150 Actuation: Must be purchased separately Materials (Body): Red Brass (Stem): Stainless Steel (Seat): Stainless Steel (Cartridge): See table (Plug/Ball/Disc): See table (Packing): Te fl o n

Approvals CRN Number: 0C0861.9087YTN/0C0861.99

Maximum Safe Operating Pressure

217 psi at 248 F

1500 kPa at 120 C

Valve Action

Stem down to close

(Cartridge)

(Plug/ Ball/ Disc) Used With(inch) DN (Cv) (Kv) (psi) (kPa)

Brass Brass

ML6984/ML7984; Q5020/DCA; Q5001/ Modutrol IV Motor; MP953; ML6420,21A,25; ML7420/ML7421A/ ML7425

Q5020/DCA; ML6984/ML7984; Q5001/ Modutrol IV Motor; MP953; ML7420/ ML7421A/ML7425; ML6420,21A,25

ML6984/ML7984; Q5020/DCA; Q5001/ Modutrol IV Motor; MP953; ML6420,21A,25; ML7420/ML7421A/ ML7425

Q5020/DCA; ML6984/ML7984; Q5001/ Modutrol IV Motor; MP953; ML7420/ ML7421A/ML7425; ML6420,21A,25

ML6984/ML7984; Q5020/DCA; Q5001/ Modutrol IV Motor; MP953; ML6420,21A,25; ML7420/ML7421A/ ML7425

Maximum Safe

Valve Size Flow Capacity

Product Number

V5011N1057/U 3/4 in. DN20 7.3 Cv 6.3 kvs Equal

V5011N1065/U 1 in. DN25 11.7 Cv 10 kvs Equal

Flow Characteristic

Percentage

V5011N1073/U 1 1/4 in. DN32 18.7 Cv 16 kvs Equal

Percentage

V5011N1081/U 1 1/2 in. DN40 29 Cv 25 kvs Equal

Percentage

V5011N1099/U 2 in. DN50 46.8 Cv 40 kvs Equal

Percentage

V5011N2006/U 1/2 in. DN15 0.73 Cv 0.63 kvs Linear 100 psi/

Operating Pressure

217 psi at 248 F

337 F steam

V5011N2014/U 1/2 in. DN15 1.2 Cv 1.0 kvs Linear 100 psi/

337 F steam

V5011N2022/U 1/2 in. DN15 1.85 Cv 1.6 kvs Linear 100 psi/

337 F steam

V5011N2030/U 1/2 in. DN15 2.9 Cv 2.5 kvs Linear 100 psi/

337 F steam

V5011N2048/U 1/2 in. DN15 4.7 Cv 4.0 kvs Linear 100 psi/

337 F steam

V5011N2055/U 3/4 in. DN20 7.3 Cv 6.3 kvs Linear 100 psi/

337 F steam

V5011N2063/U 1 in. DN25 11.7 Cv 10 kvs Linear 100 psi/

337 F steam

V5011N2071/U 1 1/4 in. DN32 18.7 Cv 16 kvs Linear 100 psi/

337 F steam

V5011N2089/U 1 1/2 in. DN40 29 Cv 25 kvs Linear 100 psi/

337 F steam

V5011N2097/U 2 in. DN50 46.8 Cv 40 kvs Linear 100 psi/

337 F steam

V5011N3004/U 1/2 in. DN15 2.9 Cv 2.5 kvs Equal

Percentage

V5011N3012/U 1/2 in. DN15 4.7 Cv 4.0 kvs Equal

Percentage

V5011N3020/U 3/4 in. DN20 7.3 Cv 6.3 kvs Equal

V5011N3038/U 1 in. DN25 11.7 Cv 10 kvs Equal

V5011N3046/U 1 1/4 in. DN32 18.7 Cv 16 kvs Equal

Percentage

217 psi at 248 F

1500 kPa at 120 C

690 kPa/ 169C steam

1500 kPa at 120 C

Valve Action

Stem down to close

Stem up to close

Flanged Globe Valves

(Cartridge)

Brass Brass

Stainless Steel
