Honeywell H3D S, H3D2S2X, H3D2SR2X, H3D3S2X, H3D3SR2X Brochure & Specs

equIP® SERIES S 1080p / 3 MP / 5 MP MFZ LENS TRUE
DAY/NIGHT H.264 INDOOR MINIDOME IP CAMERA

H3D Series S

Honeywell’s H.264 indoor H3D Series S cameras offer high definition resolution at full frame
rate, progressive scan technology and edge enhancement for outstanding picture clarity.
ONVIF (Profile S) compliance ensures hassle-free, flexible system integration.

Choose the Resolution That’s Right for Your Application

• 1080p, 3 megapixel and 5 megapixel models

• Quad stream compression (H.264-1+H.264-2+H.264-3+H.264-4/MJPEG)

• Configurable resolution and frame rate for each selected H.264 stream

Maximize Bandwidth without Losing Image Quality

• Highly efficient H.264 video compression

• 3DNR (Digital Noise Reduction) and proprietary SPQ (Smart Picture Quality) provide
significant storage savings without sacrificing image quality in low light

• CMOS progressive scan imager ensures accurate colour rendition through a wide variety
of lighting conditions

P-Iris Control Improves Contrast and Clarity

• The P-Iris setting keeps both close and distant objects in the scene in focus
simultaneously, even in changing lighting conditions

Smart IR Ensures Correct Illumination (IR Models Only)

• The IR LED brightness adjusts automatically to provide even illumination of moving subjects

Onboard Video Storage

• Up to 32 GB microSDHC (Class 10) support. Card not included

Privacy Masking

• Conceal up to 5 areas of a scene from viewing and recording

Time is Money—Installation and Upgrading Made Easy

• Camera and lens integrated in a compact, single-piece unit

• Built-in PoE (Power over Ethernet) eliminates separate power supply and associated
wiring. 12 V DC or 24 V AC inputs where PoE power is unavailable

• Remote configuration, auto focus and motorized zoom adjustments, and firmware
updating through Honeywell Viewer web client or from an NVR/DVR. Password-protected
access to the camera’s video and network setup

• Export/import of configuration facilitates quick rollout of multiple cameras

Market Opportunities

The H3D Series S cameras are perfect for applications that require excellent picture
quality at minimal bandwidth. The cameras can be retrofitted on many existing DVR/NVR
installations without requiring additional storage.

Features

(IR model shown)

• Up to 25 fps (30 fps for NTSC)
progressive scan

• True day/night, 3–9 mm (F1.2)
MFZ lens with removable IR cut
filter. H3D5 lens is 5-9 mm (F1.5)
when set to 5 MP resolution

• IR models feature 24 LEDs,
providing up to 50 ft (15 m) of
illumination depending on scene
reflectance

• Camera tamper detection and
video motion detection

• Supports both dynamic and static
IP addresses and APIPA auto-IP
addressing

• Up to 8× digital zoom

• Date and time stamp embedded
in video stream

• Configurable user privileges for
simple viewing or administrator
control and setup of functions

• Input (×1) and output (×1)
alarm contacts

• Bidirectional audio communication

FEATURES

H3D Series S

Immediately Detect and Respond to Events

The camera can be configured to automatically detect and respond to events such as motion in the scene, alarm inputs, a
network failure and/or tampering. Automated responses include:

• Sending a notification through email, FTP and/or HTTP

• Uploading still images at the time of the event through email and/or FTP

• Recording a video clip of the event to a configured microSDHC memory card or Network Attached Storage device

• Enabling a visual or auditory notification (for example, a flashing light, bell or siren)
