Honeywell Dolphin CT60 Quick Start Manual

Dolphin™ CT60

powered by Android 7

Quick Start Guide

CT60-A7-EN-QS Rev A

11/17

Out of the Box

Make sure that your shipping box contains these items:

• Dolphin CT60 mobile computer (Model CT60L0N)

• Rechargeable 3.6 VDC Li-ion battery

• Product documentation

If you ordered accessories for your mobile computer, verify that
they are also included with the order. Be sure to keep the original
packaging in case you need to return the mobile computer for
service.

Note: CT60L0N models do not include a WWAN radio.

Memory Card Specifications

Honeywell recommends the use of Single Level Cell (SLC)
industrial grade microSD™ or microSDHC™ memory cards with
Dolphin mobile computers for maximum performance and
durability. Contact a Honeywell sales representative for
additional information on qualified memory card options.

2

Mobile Computer Features

Scan Buttons

Microphone

Power
Button

Battery Status /
Notification LED

Good Read LED

Speaker

Touch Panel

Volume Buttons

Navigation Panel

3

Note: Hand strap not shown.

Camera Lens

Battery

Camera Button

Battery Latch

Imager
(LED / Laser Aperture)

microSD Card

Door

Laser Safety

Label Location

I/O Connector

4

Install a microSD Card

1

3

2

4

Note: Format the microSD card before initial use.

Note: Always power off the computer and remove the battery before

attempting to install or remove a card.

5
