Honeywell ATC928G3000 User Manual
WIRELESS BINDING GUIDE
A step-by-step guide for binding wireless heating controls
This WIRELESS BINDING
GUIDE provides simple
step-by-step instructions
for binding wireless
heating controls.
It’s assumed the devices are
appropriately installed and
powered up ready for binding.
For full installation
instructions please refer
to the Installation Guide of
the individual devices.
2
Contents
Binding to a Wi-Fi evohome
Controller (ATC928G3000) ................................ 5
Digital Room Thermostat (DTS92) ................................ 6
Mixing Valve Controller (HM80) ..................................... 7
Radiator Controller (HR92) ................................................ 8
Radiator Controller (HR80) ................................................ 9
Room Temperature Sensor (HCF82) ..........................10
Room Temperature Sensor (HCW82) ....................... 11
Single Zone Thermostat (T87RF) ................................ 12
Underfloor Heating Controller (HCE80/HCC80)
.. 13
Wireless Cylinder Thermostat (CS92) .......................14
Wireless Relay Box (BDR91) Boiler ............................. 15
Wireless Relay Box (BDR91) Sundial Valve ..............16
Wireless Relay Box (BDR91) Zone Valve....................17
Wireless Relay Box (HC60NG) .......................................18
Wireless OpenTherm Bridge (R8810) ....................... 19
Binding to a evohome
Controller (ATC928G2000) ............................. 21
Digital Room Thermostat (DTS92) ............................. 22
Mixing Valve Controller (HM80) .................................. 23
Radiator Controller (HR92) ..............................................24
Radiator Controller (HR80) ............................................. 25
Remote Access Gateway (RFG100)............................ 26
Room Temperature Sensor (HCF82) ..........................27
Room Temperature Sensor (HCW82) ....................... 28
Single Zone Thermostat (T87RF) ................................ 29
Underfloor Heating Controller (HCE80/HCC80)
.. 30
Wireless Cylinder Thermostat (CS92) .......................31
Wireless Relay Box (BDR91) Boiler ............................. 32
Wireless Relay Box (BDR91) Sundial Valve ............. 33
Wireless Relay Box (BDR91) Zone Valve................... 34
Wireless Relay Box (HC60NG) ...................................... 35
Wireless OpenTherm Bridge (R8810) ....................... 36
3
Contents
Binding to a Digital Room
Thermostat (DTS92) ............................................ 37
Wireless Relay Box (BDR91) ........................................... 38
Wireless OpenTherm Bridge (R8810) ....................... 39
Binding to a Single Zone
Thermostat (T87RF) ............................................ 41
Remote Access Gateway (RFG100).............................42
Wireless Relay Box (BDR91) ........................................... 43
Wireless OpenTherm Bridge (R8810) ....................... 44
Binding to a Programmable
Thermostat (CM90 0RF) .................................... 45
Wireless Relay Box (BDR91) ........................................... 46
Wireless Relay Box (HC60NG) ....................................... 47
Wireless OpenTherm Bridge (R8810) ....................... 48
Binding to a Programmable
Thermostat (CM70 0RF ) ..................................... 49
Wireless Relay Box (BDR91) ........................................... 50
Wireless Relay Box (HC60NG) .......................................51
Wireless OpenTherm Bridge (R8810) ....................... 52
Binding to a Programmer or
Timer (ST9000RF) ................................................ 53
Digital Room Thermostat (DTS92) ............................. 54
Wireless Cylinder Thermostat (CS92) ...................... 55
Wireless Relay Box (BDR91) Boiler ............................. 56
Wireless Relay Box (BDR91) Sundial Valve ............. 57
Wireless OpenTherm Bridge (R8810) ....................... 58
4
5
Wi-Fi evohome Controller (ATC928G3000)
Binding to a
Wi-Fi evohome Controller (ATC928G3000)
6
Wireless connectivity Guide
To bind a Digital Room Thermostat (DTS92) to a Wi-Fi evohome Controller
(ATC928G3000) as the room temperature sensor in a zone...
On the evohome Controller
1
Press and hold SETTINGS for 5 seconds
2
Press the green tick
3
Press ZONE CONFIGURATION
4
Press on the required zone
5
Press TEMPERATURE SENSOR
6
Press REMOTE SENSOR
7
Press the green tick
On the Digital Room Thermostat
8
Press and hold for 2 seconds
to put the unit into standby
9
Press and together for 3
seconds – it should display 'INst'
10
Press – it should display 'COnt'
11
Press three times – it should display 'CLr'
12
Press once to clear any previous binding data
13
Press – it should display 'COnt'
14
Press once to send the binding
signal to the evohome Controller
You should receive a SUCCESS message on the
evohome Controller. If not go back and re-bind.
Digital Room
Thermostat (DTS92)
Wi-Fi evohome Controller
(ATC928G3000)
7
Wi-Fi evohome Controller (ATC928G3000)
To bind a Mixing Valve Controller (HM80) to a Wi-Fi evohome
Controller (ATC928G3000) “mixing valve” zone...
On the evohome Controller
1
Press and hold SETTINGS for 5 seconds
2
Press the green tick
3
Press ZONE CONFIGURATION
4
Press on the required zone
5
Press HE ATING TYPE
6
Press MIXING VALVE
7
Press the green tick
On the Mixing Valve Controller
8
Press and hold both buttons on the
Mixing Valve Controller for 4 seconds
until the red light flashes
On the evohome Controller
9
Press the bind button
You should receive a SUCCESS message on the
evohome Controller. If not go back and re-bind.
The Mixing Valve Controller will not provide a
heat demand to the boiler. If you want this zone to
provide a heat demand change the Heating Type
from 'MIXING VALVE' to 'ZONE VALVES' once the
Mixing Valve controller is bound. There's no need
to re-bind any device – The Mixing Valve Controller
will still operate as intended and the evohome
Controller will send the heat demand to the boiler.
Mixing Valve Controller
(HM80)
Wi-Fi evohome Controller
(ATC928G3000)
8
Wireless connectivity Guide
To bind a Radiator Controller (HR92) to a Wi-Fi evohome
Controller (ATC928G3000) “radiator valve” zone...
On the evohome Controller
1
Press and hold SETTINGS for 5 seconds
2
Press the green tick
3
Press ZONE CONFIGURATION
4
Press on the required zone
5
Press RF DEVICE BINDING
6
Press the forward arrow
On the Radiator Controller
7
Press the button once − it
should display UNBOUND
8
Press and hold the button for a further
5 seconds until it displays BIND
9
Press the button once – it
should display BINDING
On the evohome Controller
10
Press the bind button
You should receive a SUCCESS message on
both the evohome Controller and the Radiator
Controller. If not go back and re-bind.
Radiator Controller
(HR92)
Wi-Fi evohome Controller
(ATC928G3000)
9
Wi-Fi evohome Controller (ATC928G3000)
To bind a Radiator Controller (HR80) to a Wi-Fi evohome
Controller (ATC928G3000) “radiator valve” zone...
On the evohome Controller
1
Press and hold SETTINGS for 5 seconds
2
Press the green tick
3
Press ZONE CONFIGURATION
4
Press on the required zone
5
Press RF DEVICE BINDING
6
Press the forward arrow
On the Radiator Controller
7
Press the recessed bind button on the
underside of the Radiator Controller – it should
briefly show a flashing RF icon then SYNC.
8
Press the recessed bind button again – it
should show a flashing RF icon
On the evohome Controller
9
Press the bind button
The evohome Controller will not show a SUCCESS
message. It’s recommended to perform a
quick functional check to validate the bind.
To do this, adjust the setpoint temperature on
the evohome controller for that zone to the
maximum and minimum, checking the radiator
controller responds to the new setpoint.
Radiator Controller
(HR80)
Wi-Fi evohome Controller
(ATC928G3000)
10
Wireless connectivity Guide
To bind a Room Temperature Sensor (HCF82) to a Wi-Fi evohome Controller
(ATC928G3000) as the room temperature sensor in a zone...
On the evohome Controller
1
Press and hold SETTINGS for 5 seconds
2
Press the green tick
3
Press ZONE CONFIGURATION
4
Press on the required zone
5
Press TEMPERATURE SENSOR
6
Press REMOTE SENSOR
7
Press the green tick
On the Room Temperature Sensor
8
Press the bind button on the bottom
right hand corner of the unit once
– the red LED light will flash
You should receive a SUCCESS message on the
evohome Controller. If not go back and re-bind.
Room Temperature
Sensor (HCF82)
Wi-Fi evohome Controller
(ATC928G3000)
11
Wi-Fi evohome Controller (ATC928G3000)
To bind a Room Temperature Sensor (HCW82) to a Wi-Fi evohome Controller
(ATC928G3000) as the room temperature sensor in a zone...
On the evohome Controller
1
Press and hold SETTINGS for 5 seconds
2
Press the green tick
3
Press ZONE CONFIGURATION
4
Press on the required zone
5
Press TEMPERATURE SENSOR
6
Press REMOTE SENSOR
7
Press the green tick
On the Room Temperature Sensor
8
Press the bind button on the bottom
right hand corner of the unit once
– the red LED light will flash
You should receive a SUCCESS message on the
evohome Controller. If not go back and re-bind.
Room Temperature
Sensor (HCW82)
Wi-Fi evohome Controller
(ATC928G3000)
12
Wireless connectivity Guide
To bind a Single Zone Thermostat (T87RF) to a Wi-Fi evohome Controller
(ATC928G3000) as the room temperature sensor in a zone...
On the evohome Controller
1
Press and hold SETTINGS for 5 seconds
2
Press the green tick
3
Press ZONE CONFIGURATION
4
Press on the required zone
5
Press TEMPERATURE SENSOR
6
Press REMOTE SENSOR
7
Press the green tick
On the Single Zone Thermostat
8
Press and hold on the left touch zone (just below
and to the left of the display) for approximately
10 seconds until a flashing ‘Bo’ is displayed
9
Turn the dial clockwise until a
flashing ‘Co’ is displayed
10
Press the left touch zone once to send the
binding signal to the evohome Controller
You should receive a message on the evohome
Controller to say the binding signal was
received. If not go back and re-bind.
Single Zone
Thermostat (T87RF)
Wi-Fi evohome Controller
(ATC928G3000)
13
Wi-Fi evohome Controller (ATC928G3000)
We recommend that you refer to the full
evohome Controller installation guide
when binding the Underfloor Heating
Controller. This product will include a
range of different actuators and sensors
used across the underfloor heating zones,
with a variety of binding procedures.
Underfloor Heating
Controller (HCE80/HCC80)
Wi-Fi evohome Controller
(ATC928G3000)
14
Wireless connectivity Guide
Wireless Cylinder
Thermostat (CS92)
To bind a Wireless Cylinder Thermostat (CS92) to a Wi-Fi evohome
Controller (ATC928G3000) to control a hot water cylinder...
On the evohome Controller
1
Press and hold SETTINGS for 5 seconds
2
Press the green tick
3
Press SYSTEM DEVICES
4
Press STORED HOT WATER
5
Press ENABLED
6
Press HOT WATER SENSOR BINDING
On the Wireless Cylinder Thermostat
7
Press and hold the button for 5
seconds. The green light should come
on and the red light should flash
8
Press the button again
You should receive a SUCCESS message on
the evohome Controller and the LED on the
Wireless Cylinder Thermostat should stop blinking
and turn OFF. If not, go back and re-bind.
Wi-Fi evohome Controller
(ATC928G3000)
15
Wi-Fi evohome Controller (ATC928G3000)
Wireless Relay Box
(BDR91) Boiler
To bind a Wireless Relay Box (BDR91) to a Wi-Fi evohome
Controller (ATC928G3000) to control a boiler...
On the evohome Controller
1
Press and hold SETTINGS for 5 seconds
2
Press the green tick
3
Press SYSTEM DEVICES
4
Press BOILER CONTROL
5
Press WIRELESS RELAY BOX
On the Wireless Relay Box
6
Press and hold the button for 15 seconds
(until the red LED blinks rapidly) to
clear any previous binding data
7
Press and hold the button again for 5
seconds (until the red LED blinks slowly)
On the evohome Controller
8
Press the bind button
You should receive a SUCCESS message
on the evohome Controller and the LED on
the Wireless Relay Box should stop blinking
and turn OFF. If not, go back and re-bind.
Wi-Fi evohome Controller
(ATC928G3000)
16
Wireless connectivity Guide
Wireless Relay Box
(BDR91) Sundial Valve
To bind a Wireless Relay Box (BDR91) to a Wi-Fi evohome Controller
(ATC928G3000) to control a Sundial valve (hot water or heating)...
On the evohome Controller
1
Press and hold SETTINGS for 5 seconds
2
Press the green tick
3
Press SYSTEM DEVICES
4
Press STORED HOT WATER
5
Press ENABLED
6
Press HOT WATER VALVE BINDING
or HEATING VALVE BINDING
On the Wireless Relay Box
7
Press and hold the button for 15 seconds
(until the red LED blinks rapidly) to
clear any previous binding data
8
Press and hold the button again for 5
seconds (until the red LED blinks slowly)
On the evohome Controller
9
Press the bind button
You should receive a SUCCESS message
on the evohome Controller and the LED on
the Wireless Relay Box should stop blinking
and turn OFF. If not, go back and re-bind.
Wi-Fi evohome Controller
(ATC928G3000)
17
Wi-Fi evohome Controller (ATC928G3000)
Wireless Relay Box
(BDR91) Zone Valve
To bind a Wireless Relay Box (BDR91) to a Wi-Fi evohome
Controller (ATC928G3000) Zone Valve zone...
On the evohome Controller
1
Press and hold SETTINGS for 5 seconds
2
Press the green tick
3
Press ZONE CONFIGURATION
4
Press on the required zone
5
Press HE ATING TYPE
6
Press ZONE VALVE
7
Press the green tick
On the Wireless Relay Box
8
Press and hold the button for 15 seconds
(until the red LED blinks rapidly) to
clear any previous binding data
9
Press and hold the button again for 5
seconds (until the red LED blinks slowly)
On the evohome Controller
10
Press the bind button
You should receive a SUCCESS message
on the evohome Controller and the LED on
the Wireless Relay Box should stop blinking
and turn OFF. If not, go back and re-bind.
Wi-Fi evohome Controller
(ATC928G3000)
Loading...
