Honeywell AHE 4 User Manual

AHE

AHE SERIES 4

Direct Vent Wall-Mounted Boilers

User’s

Information

Manual

If the information in this manual is not followed exactly, a fire or explosion may result, causing property damage, personal injury or loss of life.

Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any phone in your

building.

• Immediately call your gas supplier from a neighbor’s phone. Follow

the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the fire department.

Installation and service must be performed by a qualified installer, service technician or the gas supplier.

Part number 550-141-893/0800

AHE Series 4 Direct Vent Wall-Mounted Boilers — User’s Information Manual

Please read this page first

Hazard definitions

The following defined terms are used throughout this manual to bring attention to the presence of hazards of various risk levels or to important information concerning the life of the product.

Indicates presence of hazards that will cause severe personal injury, death or substantial property damage.

Indicates presence of hazards that can cause severe personal injury, death or substantial property damage.

Indicates presence of hazards that will or can cause minor personal injury or property damage.

Indicates special instructions on installation, operation or maintenance that are important but not related to personal injury or property damage.

Contents

Hazard definitions ................................................................................................... 2

Stop!! — Read before proceeding — Important safety information ..................... 3

Boiler maintenance ................................................................................................. 4

User maintenance procedures ............................................................................ 5-8

Operating instructions — Robertshaw 7200 .......................................................... 9

Operating instructions — Honeywell VR8205 and White-Rodgers 36E.............. 10

Common problems and solutions ........................................................................ 11

Warranty ................................................................................................................ 12

Part number 550-141-893/0800

AHE Series 4 Direct Vent Wall-Mounted Boilers — User’s Information Manual

Stop!! — Read before proceeding

Failure to adhere to the following guidelines can result in severe personal injury, death or substantial property damage.

When servicing boiler

• To avoid electric shock, disconnect electrical supply before performing maintenance.

• To avoid severe burns, allow boiler to cool before performing maintenance.

Boiler operation

• Do not block flow of combustion or ventilation air to boiler.

• Should overheating occur or gas supply fail to shut off, do not turn off or disconnect electrical supply to circulator. Instead, shut off the gas supply at a location external to the appliance.

• Do not use this boiler if any part has been under water. Immediately call a qualified service technician to inspect the boiler and to replace any part of the control system and any gas control that has been under water.

Boiler water

• Do not use petroleum-based cleaning or sealing compounds in boiler system. Water seal deterioration will occur, causing leakage between sections. This can result in substantial property damage.

• Do not use "homemade cures" or "boiler patent medicines". Serious damage to boiler, personnel and/or property may result.

• Continual fresh makeup water will reduce boiler life. Mineral buildup in sections reduces heat transfer, overheats cast iron, and causes section failure. Addition of oxygen and other gases can cause internal corrosion. Leaks in boiler or piping must be repaired at once to prevent makeup water.

• Do not add cold water to hot boiler. Thermal shock can cause sections to crack.

Glycol — potential fire hazard

All glycol is flammable when exposed to high temperatures. If glycol is allowed to accumulate in or around the boiler or any other potential ignition source, a fire can develop. In order to prevent potential severe personal injury, death or substantial property damage from fire and/or structural damage:

• Never store glycol of any kind near the boiler or any potential ignition source.

• Monitor and inspect the system and boiler regularly for leakage. Repair any leaks immediately to prevent possible accumulation of glycol.

• Never use automotive antifreeze or ethylene glycol in the system. Using these glycols can lead to hazardous leakage of glycol in the boiler system.

Part number 550-141-893/0800

AHE Series 4 Direct Vent Wall-Mounted Boilers — User’s Information Manual

Boiler maintenance

Boiler service and maintenance

The User’s Information Manual provides information to the boiler owner/user for routine operation and maintenance and emergency shutdown. Detailed information on boiler installation, operation, start-up, service and parts is included in the Boiler Manual. The Boiler Manual is intended only for use by a qualified installer/

service technician.

Maintenance schedule

Maintain the boiler using the maintenance schedule below. Have the boiler started up and serviced at least annually by a qualified service technician to ensure boiler/system reliability.

Service technician

(covered in Boiler Manual — for use only by a

qualified service technician)

Inspect:

• Reported problems

• Boiler area

• Air openings

• Flue gas vent system (and air piping)

• Main burner flames

• Water piping

• Boiler heating surfaces

• Burners and base

Service:

• Cleaning boiler heating surfaces

• Blower motor

• Oiled-bearing circulators

START

Start-up:

• Perform start-up per manual

Check/test:

NNNUAL

• Gas piping

• Cold fill and operating pressures

• Air vents and air elimination

• Blower motor assembly

• Circulator with mixing valve

• Limit controls and cutoffs

• Expansion tank

• Boiler relief valve

Owner maintenance

(see following pages for instructions)

• Check boiler area

Daily

Monthly

Periodically

Every 6 months • Operate relief valve

End of season • Shut down procedure

• Check air openings

• Check boiler pressure/ temperature gauge

• Check boiler piping

• Check venting system

• Check boiler relief valve

• Check automatic air vents

• Main burner flames

• Test low water cutoff

• Clean vent termination and air intake screens

Review:

• Review with owner

Part number 550-141-893/0800
