Honda XL600, XL650V Service Manual

Download

Specifications and Main Features

Considered Models -
Honda XL600V Transalp year production range 1987 to 1999 with an engine capacity of 583cc
Honda XL650V Transalp year production range 2000 to 2002 with an engine capacity of 647cc
Honda XRV750 Africa Twin year production range 1990 to 2002 with an engine capacity of 742cc
Motor:
Configuration: V-twin cylinder at 52 degrees
Clutch type: Soaked multi-disc assembly
Transmission system: 5 gearbox speeds
Compression ratios: XL600V: 9,5:1, XL650V: 10,0:1, XRV750: 9,8:1
Performance Specification:
Power Output for Maximum Operations:
XL600V: 46.5bhp at 7542rpms
XL650V: 54bhp at 7500rpms
XRV750: 61bhp at 7500rpms
Torque Output for Maximum Operations:
XL600V: 36.1lb and ft torque at 5798rpm
XL650V: 39lb and ft torque at 5500rpm
XRV750: 45lb and ft torque at 6000rpm
Recorded Speed Limit:
XL600V: Highest limit of 110 mph
XL650V: Highest limit of 112 mph
XRV750: Highest limit of 112 mph
Estimate Consumption of Fuel:
XL600V: An estimate record of 42mpg
XL650V: An estimate record of 36mpg
XRV750: An estimate record of 40mpg
Measures:
Length Features:
XL600V: 2185 millimeters
XL650V: 2210 millimeters
XRV750: 2265 millimeters
Width Features:
XL600V: 905 millimeters
XL650V: 905 mm
XRV750: 905mm
Height Features:
XL600V: 1280 millimeter
XL650V: 1300 millimeter
XRV750: 1430mm
Wheelbase Dimensions:
XL600V: Length of 1450 mm
XL650V: 1460 mm
XRV750: 1440 mm
Seat Height:
XL600V: 850 mm -
XL650V: 850 mm -
XRV750: 880 mm
Ground Clearance:
XL600V: 225 mm -
XL650V: 225 mm -
XRV750: 210 mm
Fuel Capacity:
XL600V: 18 liters -
XL650V: 20 liters -
XRV750: 22 liters
Brake System:
Front:
XL600V: Single disc with twin-piston sliding caliper -
XL650V: Twin discs with twin-piston sliding calipers -
XRV750: Twin discs with twin-piston sliding calipers.
Rear:
XL600V: Drum brake -
XL650V: Single disc with single-piston sliding caliper -
XRV750 Disc: One unit fitted with single-piston sliding caliper

Frequently Asked Questions

Q: What is the engine capacity of the Honda XL600V Transalp Seen Motor Bike?

A: The engine capacity of the Honda XL600V Transalp is 583.

Q: How many gears does the Honda Transalp have?

A: The Honda Transalp is fitted with a 5 speed gearbox.

Q: What is the compression ratio of the Honda XRV750 Africa Twin

A: Compression ratio of Honda XRV750 Africa Twin is 9.8:1.

Q: What is the top speed on XL650V?

A: The top speed on XL650V is 112’ 1 mph.

Q: How much fuel can be stored within the fuel tank of the Honda XL650V?

A: The Honda XL650V has a fuel capacity of 20 liters.

Q: What type of brake system is utilized in the Honda XRV750?

A: In the Honda XRV750, the front brake system employs twin discs with twin-piston sliding calipers while the rear has a single disc with a single-piston sliding caliper.
