Bed Extender User’s Information
© 2005 American Honda Motor Co., Inc. - All Rights Reserved. 1
RIDGELINE
Introduction
Thank you for purchasing this Honda accessory.
Please read this user’s information carefully before using the bed extender, and keep this information
in the glove box for future reference .
This product is designed to be used exclusively on a Honda Ridgeline. Honda is not responsible if the product
is used for anything other than its intended purpose.
This user’s information should be considered a permanent part of the vehicle. It should remain with the vehicle
at all times and stay with the vehicle when sold.
SYMBOLS
If instructions are preceded by the following symbols, they will give helpful advice or information.
ADVICE
• Gives advice to prevent damage to the
product.
• Gives advice to handle emergency situation.
2 © 2005 American Honda Motor Co., Inc. - All Rights Reserved.
Gives helpful information or instructions to be
followed in using the product.
INFORMATION
Bed Extender Arrangement
Installation with the Tailgate Opened Flat Installation in the Forward Position
NOTICE
LABEL
NOTICE LABEL
4N23032K
Installation with the Tailgate Closed
4N23011K
To avoid damage to the tailgate or the bed
ADVICE
extender:
• Rotate the bed extender forward.
Close the tailgate.
NOTICE
LABEL
• Do not exceed 300 lbs (136 kg) on tailgate.
• Be sure extender is properly installed before
driving.
• Do not secure cargo to the tailgate or the
extender.
INFORMATION
Install the bed extender so that the notice label
4N25501K
© 2005 American Honda Motor Co., Inc. - All Rights Reserved. 3
4N23022K
comes to the right side of the vehicle.
Installation
Installing the Bed Extender Vertically:
• Open the tailgate. Inser t the r ight and left
projections from the bed extender into the right
and left latches.
PROJECTION
LEFT LA TCH
BED EXTENDER
PROJECTION
RIGHT LA TCH
TAILGATE
4N23040K
• Rotate the bed extender backward. Snap the
straps attached to the bed extender to the
snaps.
SNAP
SNAP
SNAP
BED
EXTENDER
SNAP
4N23900K
4 © 2005 American Honda Motor Co., Inc. - All Rights Reserved.
Installation
Installing the Bed Extender
Horizontally:
• Insert the right and left
projections from the bed
extender into the right and left
latches. Push down the bed
extender until the engaged
parts lock.
LEFT
LATCH
PROJECTION
BED
EXTENDER
PROJECTION
RIGHT
LATCH
4N23050K
• Snap the straps attached to the
bed extender to the snap.
SNAP
SNAP
SNAP
BED
EXTENDER
SNAP
4N23061K
Installing the Bed Extender
in the Forward Position
• Wind each strap onto a bar of
the bed extender and secure
the straps as shown.
• Insert the right and left
projections from the bed
extender into the right and left
latches on the front brackets.
Push down the bed extender
until the engaged parts lock.
PROJECTION
BED
EXTENDER
STRAP
CLIP
PROJECTION
LEFT
LATCH
RIGHT
LATCH
4N23091K
© 2005 American Honda Motor Co., Inc. - All Rights Reserved. 5
Removal
Removing the Bed Extender Vertically:
• Unsnap the straps and rotate the bed extender
upward.
STRAP
BED EXTENDER
STRAP
4N23101K
• Pull the bed extender up to remove. Close the
tailgate.
BED EXTENDER
4N23111K
6 © 2005 American Honda Motor Co., Inc. - All Rights Reserved.
Removal
4N23152K
Removing the Bed Extender Horizontally:
• Unsnap the straps. Unlock the right and left
latches by pulling the lever toward you and
remove the bed extender by pulling it up straight.
• Close the tailgate.
LEFT/RIGHT
LEVER
Pull the lever
toward you to
unlock.
STRAP
BED
EXTENDER
STRAP
TAILGATE
LATCH
4N23121K
Removing the Bed Extender from the Forward
Position
• Unlock the right and left latches by pulling the
lever toward you then remove the bed extender
by pulling it up straight.
LEFT/RIGHT
LATCH
LEVER
Pull the lever
toward you to
unlock.
BED
EXTENDER
© 2005 American Honda Motor Co., Inc. - All Rights Reserved. 7
8 © 2005 American Honda Motor Co., Inc. - All Rights Reserved.© 2005 American Honda Motor Co., Inc - All Rights Reserved. Printed in Japan08L26-SJC-1000-81
