Civic Sedan
2010
Technology Reference Guide
Indicators/Info
Display/TPMS
Instrument Panel Indicators
Indicators briefly appear with each engine start. Red and amber indicators are most critical. Blue and
green indicators are used for general information.
Malfunction Indicators: If an indicator remains on, there may be a problem; see your dealer.
Charging system
Low brake fluid
Low oil pressure
SRS (supplemental restraint system)
EPS (electronic power steering)*
2010 Civic Sedan
ABS (anti-lock brake system)
DRL (daytime running lights)
Malfunction lamp (check engine light)
TPMS (tire pressure monitoring system)
VSA (vehicle stability assist)
PASSENGER
AIRBAG
OFF
2010 Civic Sedan
Condition Indicators: Action needed by driver.
Rev Limit Indicator*:
Shift to correct gear
Door/Trunk open: Close
door(s) / trunk
PASSENGER AIRBAG
(above Hazard
OFF
Warning button)
SIDE AIRBAG OFF
VSA solid: off
Blinks: activated
Seat belt reminder:
Fasten seat belt(s)
Low fuel: Refill
Low tire pressure:
Add air
Maintenance minder:
Make appointment
On/Off Indicators
CRUISE CONTROL on
CRUISE MAIN on
Immobilizer
Flashes: improperly coded key;
use correct key
Turn signals/hazards on
Fog lights (Si) on* High beams on
Headlights on
* Si models only
Information Display
Consists of several displays that provide you with useful information.
Information DisplaysAccessing the Information Display
Once you start the engine, the information display
shows your last active selection from the previous
drive cycle.
Odometer,
Trip meter A
Outside
temperature*,
Trip meter A
To toggle between the different displays, press
and release the select/reset button repeatedly.
2010 Civic Sedan
Outside
temperature*,
Trip meter B
Oil life
* if equipped
2010 Civic Sedan
Tire Pressure Monitoring System (TPMS)
Monitors the vehicle’s tire pressures.
How It Works What to Do
Each tire valve stem contains a TPMS
sensor.
When the tire pressure drops
significantly below recommended levels,
the low tire pressure indicator comes on.
Indicators/Info
Display/TPMS
Visually inspect the tires and use a tire air pressure
gauge to check which tire(s) have low pressure.
P
E
S
C
N
T
I
and
Inflate the tire(s) to the recommended pressures
listed on the label on the driver’s doorjamb.
Auto Door Locks
Auto Door Locking/Unlocking
Default Lock Setting
Default Unlock Setting
The doors are preset to
lock when your vehicle
reaches about 9 mph.
Only the driver’s door
is preset to unlock
when you shift into
Park (P).
Modifying the Auto Door Unlock Setting
Follow these steps to program all doors to unlock when you shift to Park:
1. Close the driver’s
door. Shift into
Park.
2. Turn the ignition
to the ON (II)
position.
3. Press and hold the unlock side of
the master lock switch for about 10
seconds. In that time, you will hear
three clicks.
2010 Civic Sedan
4. Within 5 seconds, turn
the ignition to the LOCK
(0) position.
2010 Civic Sedan
Programmable Auto Door Lock/Unlock Settings
Below are the different programmable options you can choose. See Auto Door Locking/Unlocking in
your owner's manual for instructions on programming these settings.
Auto Unlock
(all doors)
Auto Unlock
(only driver’s
door)
Turn off
Auto Unlock
AUTO DOOR UNLOCK
When you turn
the ignition OFF
When you turn
the ignition OFF
Operate manually
Auto Door Locks
When you shift
into Park
When you shift
into Park
Auto Lock
Turn off
Auto Lock
AUTO DOOR LOCK
When you
reach 9 mph
Operate manually
When you shift
out of Park
Voice Command/
HFL/Navigation
Voice Command
Using the Voice Command System
To reduce driver distraction, use voice commands for hands-free calling, navigation, and audio functions.
A full list of these commands is in the navigation system manual.
HFL Talk button: Give HFL commands
or answer incoming calls.
NAVI Talk button:
Give navigation and
audio commands.
NAVI Back button:
Cancel a command or
return to the previous
screen.
HFL Back button: End a call, go back to
the previous command, or cancel an
operation.
Voice Command Tips:
Press and release the HFL or NAVI Talk button, wait for a
•
beep, then give a command.
• For a list of available HFL commands, press and release the
HFL Talk button and say “Hands-free help.”
• For a list of available navigation commands, press and
release the NAVI Talk button and say “Voice command help.”
• Speak in a clear, natural voice.
• Reduce all background noise.
• Adjust the dashboard and side
vents away from the microphone in
the ceiling.
• Close the windows.
2010 Civic Sedan
Bluetooth® HandsFreeLink
Pairing Your Phone
Press and release the HFL Talk button before you give a command.
®
(if equipped)
2010 Civic Sedan
Enable “Discovery” or “Search” mode
1
on your Bluetooth-compatible phone.
Has a phone been paired to the system
before?
Say “Phone
2
setup.”
Say “Pair.”
3
YES
YESNO
NO
The system gives you
information about
pairing a phone for
the first time.
HFL gives you a four-digit pairing code.
4
HFL searches for your phone, and you must
search for a Bluetooth device on your
phone as well. When HFL finds your phone,
your phone prompts you to connect to HFL.
Was connection successful?
Enter the code from step 4 on your
5
phone when your phone prompts you.
Was pairing successful?
NO
Repeat steps 2-5.
HFL asks you to name the phone. For
6
example, say “Mary’s phone.”
Your phone is now paired to HFL. The
system exits out of the HFL menu.
For more information or troubleshooting,
call HFL consumer support at
(888) 528-7876, visit handsfreelink.honda.com,
or see your owner’s manual for details.
YES
Making a Call
1. Press the HFL Talk button, and say “Call” or
“Dial” and the desired phone number.
Receiving a Call
1. A notification is heard, and the following
screen appears on the navigation display.
2. Press the HFL Talk button, and say “Call” or
“Dial” to continue.
3. The call is connected and heard through the
vehicle’s speakers.
2010 Civic Sedan
2. Press the HFL Talk button to accept the
call.
3. Press the HFL Back button to end or
decline the call.
2010 Civic Sedan
Navigation (if equipped)
Entering a Destination Using Voice Commands
Press and release the NAVI Talk button before you give a command.
Say “Display menu.”
1
Say “Address.”
2
Say “City” (or “Change state” if
3
necessary).
Say the name of the city you want, or
4
say “Current city” to select the city
currently shown.
A list of city names appears. Say
5
the number listed next to the city you
want to select.
Say the street name. Do not include
6
the direction (N, S, E, W) or type
(St., Ave., Blvd., etc.).
A list of street names appears. Say
7
the number listed next to the street
you want to select.
Say the entire street address number.
8
For example, “1-2-5-0.”
The system calculates the route
9
and displays the “Calculate route to”
screen. Say “OK” to set the route.
Note: Entering destinations can also be done manually
from the Menu screen.
Entering a Destination Using the “Find Nearest” Command
Try these simple steps to find a nearby point of interest, such as a gas station, movie theater, restaurant, etc.
Press and release the NAVI Talk button before you give a command.
1. Say “Find nearest ATM.”
3. Say the number you want to select.
2. A list of the nearest ATMs are
displayed by shortest distance to
destination.
4. The system calculates the route and
displays the “Calculate route to” screen.
Say “OK” to set the route.
2010 Civic Sedan
2010 Civic Sedan
Commonly Used Voice Commands
Here are some examples of commonly used voice commands. Try some of these to familiarize yourself with
the voice command system.
Press and release the NAVI Talk button before you give a command.
Look for Restaurants in Your Location
Say a command like “Display restaurants” to see
restaurant icons appear on the map.
Make Audio Selections
Say a command like “Radio 97.1 FM” or “CD play
track 5” to select that station or song.
Adjust the System Volume
Say "display setup" then "volume up" to increase the
volume of the system voice response.
Get Estimated Distance to Destination
After a destination is entered, say “How far to
destination?” to hear the remaining distance.
Commonly Used Voice Commands (continued)
Press and release the NAVI Talk button before you give a command.
General Commands
(Accepted on most screens
to change displays)
Navigation Commands
(Accepted on Map screen
after a destination is entered)
• Display map
• Display menu
• Setup
Find Place Commands
(Accepted on Map screen)
• Find nearest:
- ATM
- gas station
- Mexican
restaurant
- post office
• Information
• Display audio screen
• What time is it?
- bank
- Honda dealer
- airport
- hospital
2010 Civic Sedan
• How long/far to the destination?
• Display destination
• Display entire route
Display Commands
(Accepted on Map screen)
• Display (or hide):
- ATM
- gas station
- restaurant
- post office
• Display north up/
heading up
• Zoom in/out
• Go home
• Display current
location
2010 Civic Sedan
Commonly Used Voice Commands (continued)
Press and release the NAVI Talk button before you give a command.
Audio Commands
(Accepted on most screens)
Help Commands
(Accepted on most screens)
Radio Commands
• Radio on
• Radio # FM/AM
• Radio preset
1/2/3/4/5/6
• Radio seek up
• Radio seek down
XM Commands
• XM channel #
• XM channel up
• XM channel down
• XM preset
1/2/3/4/5/6
CD Commands
• CD play
• CD play track/disc #
• CD skip forward/back
• CD track random
• CD track repeat
PC Card Commands
• Card play
• Card play track #
• Card skip forward
• Card skip back
Auxiliary Commands
• Auxiliary (AUX) play
Voice Command/
HFL/Navigation
• Help (list of available commands for current
screen)
• Voice command help (list of all available
navigation, audio, and climate control
commands)
Setup Commands
(Accepted on the Setup screen)
• Brightness up/down
• Volume up/down/
min/max/off
• Guidance prompts
min/max/normal
Audio
Components
Playing an iPod®or USB Flash Memory Device (if equipped)
Some of the same controls used to operate your in-dash CD player are used to operate an iPod or USB
flash memory device.
Connecting and Beginning Play
1. Open the center console, and pull out the
USB adapter cable.
3. Push AUX or touch the AUX icon to play.
EX EX with Navigation
USB Connector
USB Adapter Cable
2. Connect your USB connector to your flash
drive or iPod dock connector.
iPod is a registered trademark of Apple Computer, Inc.,
registered in the U.S. and other countries. iPod not included.
2010 Civic Sedan
2010 Civic Sedan
PC Card Instructions (models with navigation)
Connecting and Beginning Play
1. Press OPEN.
3. Insert the PC card into the slot and press
CLOSE.
PC card
slot
CLOSE
Button
2. If necessary, insert your PC card into a PC
card adapter.
4. Press AUDIO to show the audio display. Use
|
the
and |buttons to skip through
tracks on the card.
Audio
Components
About This Technology Reference Guide
This Technology Reference Guide has been prepared to help you
get quickly acquainted with your new Honda, and to provide
reference instructions on driving controls and convenience items.
However, this guide is not intended as a substitute for the
Owner’s Manual. For complete information on operating the
vehicle safely, please refer to the Owner’s Manual.
As with the Owner’s Manual, this guide covers all models of the
Honda Civic 4-Door. Therefore, you may find descriptions of
equipment and features that are not on your particular model.
Safety Reminder
Your vehicle is equipped with airbags. Airbags do not replace
your seat belts; they add to the protection offered by seat belts.
Airbags can help protect you in some types of collisions, but they
do not provide protection in all collisions.
Always make sure you and your passengers wear seat belts, and
that young children are properly secured in a child seat or
booster in the rear seat. Never place an infant seat in the front
passenger’s seat as the force of a deploying airbag can seriously
injure an infant.
Fuel Recommendation
• Use only unleaded gasoline of 87
octane or higher (except Si).
• Use only unleaded gasoline of 91
octane or higher for Si.
• Some gasoline in North Amer ica
contains MMT, a manganese-based
fuel additive. Prolonged and consistent
use of gasoline containing MMT can
deteriorate your vehicle’s performance,
fuel economy, and the emissions
control system. Always use MMT-free
gasoline if alternatives exist. Failures
caused by use of gasoline containing
MMT may not be covered under
warranty.
• For further impor tant information on
fuel and lubricants for your car and
information on gasoline that does
not contain MMT, contact your
dealer or visit Owner Link at
www.hondacars.com.
31SNAQ40
00X31-SNA-Q400
2010 Honda Civic 4-Door Technology Reference Guide
©2009 American Honda Co., Inc.
-
All Rights Reserved
Printed in U.S.A.
Loading...
