Honda Civic Coupe With Navigation Technical Reference Guide
T E C H N O L O G Y
R E F E R E N C E
G U I D E
o w n e r s . h o n d a . c o m
201 4 Ho nda Ci vic C ou pe w it h Navi ga ti on
31TS8C10 Te ch nolo gy R efer en ce Gui de
00X31-TS 8-C100 ©2013 America n Honda Mo tor Co. , Inc. — A ll Righ ts Reserved Printed in U.S .A.
2014 Civic Coupe
with Navigation
TEC HNO LOG Y R EFER ENC E G UID E
INSTRUMENT PANEL p.4
This Technology Reference Guide is designed to help you
get acquainted with your 2014 Honda Civic Coupe with
Navigation and provide basic instructions on some of its
technology and convenience features.
This guide is not intended to be a substitute for the
Owner’s Manual. For more detailed information on vehicle
controls and operation, please refer to the respective
sections in the Owner’s Manual or Navigation Manual.
Civic EX-L shown throughout guide
Smart Entry with Push Button Start.....................................................................2
Instrument Panel Indicators ...................................................................................4
Intelligent Multi-Information Display (i-MID).....................................................6
Eco Assist
Tire Pre ssure Monitoring System (TPMS)...........................................................9
Auto Door Locks ...................................................................................................10
One-Touch Turn Signal...........................................................................................11
Auto Headlights with Wiper Integration...........................................................11
Multi-View Rear Camera ......................................................................................12
LaneWatch™...........................................................................................................13
Display Audio with Navigation.............................................................................14
Voice Recognition...................................................................................................16
Navigation.................................................................................................................20
TM
*..............................................................................................................8
DISPLAY AUDIO WITH
NAVIGATION p. 14
i-MID p.6
ECO
BLUETOOTH
HANDSFREELINK®p.23
®
p.23
ASSISTTMp.8
Bluetooth®HandsFreeLink®(HFL)........................................................................23
SMS Text Messaging and E-Mail............................................................................27
Siri Eyes Free Mode ...............................................................................................28
HondaLink Assist ....................................................................................................29
Basic Audio Operation ..........................................................................................30
®
or USB Flash Drive .....................................................................................31
iPod
Bluetooth
Pandora
HDMI Video .............................................................................................................34
Settings for Your Vehicle ........................................................................................35
Honda Owners .......................................................................................................36
Safety Reminder......................................................................................................36
Fuel Information......................................................................................................37
®
Audio......................................................................................................32
®
...................................................................................................................33
*if equipped
SMART E NT RY WITH P US H BUTTON ST AR T
Operate certain functions of your vehicle by simply having the remote transmitter
within operating range.
Unlocking the Doors
Locking the Doors
Grab either one of the front door handles
when the vehicle is off. Wait until the doors
unlock, then pull the handle to open.
Press the door lock button on either front
door handle when the vehicle is off.
Engine Start/Stop Button
Accessory or On Mode
Press ENGINE START/STOP once without pressing the brake pedal for Accessory
mode. Press it again for On mode.
Starting the Engine
Press and hold the brake pedal*, then press ENGINE START/STOP.
*For manual transmission, press and hold the clutch.
Turning the Vehicle Off
Shift to Park*, then press ENGINE START/STOP.
*For manual transmission, apply the parking brake.
Note: If you press ENGINE START/STOP and the shift lever is not in Park, the vehicle goes
into Accessory mode.
Opening the Trunk
Press the trunk release button under the
trunk handle. The vehicle can be on or off.
2 3
PASSENGER
AIRBAG
OFF
INSTRUMENT PANEL INDICATORS
Briefly appear with each engine start. Red and amber indicators are most critical.
Blue and green indicators are used for general information. See your Owner’s
Manual for more information.
Si only
i-VTEC indicator
REV indicators
Malfunction Indicators
If an indicator remains on, there may be a problem; see your dealer
Charging system
Low brake fluid, Brake system
Low oil pressure
Supplemental Restraint System
(SRS)
Transmission (blinking)
D
Smart Entry System
Anti-Lock Brake System (ABS)
Electric Power Steering (EPS)
Malfunction indicator lamp
(check engine light)
Vehicle Stability Assist®(VSA)
Tire Pressure Monitoring System
(TPMS) (blinks and stays on)
Low temperature
Door/Trunk open:
Close door(s) / trunk
Low fuel:
Refill
Low tire pressure:
Add air
On/Off Indicators
PASSENGER AIRBAG OFF
(next to i-MID)
VSA OFF
CRUISE MAIN on
Si only
High temperature:
Drive slowly or pull over
Message indicator:
See i-MID
Immobilizer (blinks):
Use other vehicle key
and see dealer
Exterior lights on
Turn signals/hazards on
Fog lights on
Condition Indicators
Action is needed by driver
Parking brake on:
Release
4 5
Seat belt reminder:
Fasten seat belt(s)
CRUISE CONTROL on
ECON* on
High beams on
*if equipped
INTELLI GE NT MULTI- IN FORMATION DI SPLAY (i- MI D)
Consists of several displays that provide you with useful information.
Accessing the i-MID
Press the Display/Info button to
change main displays.
Main Displays
Main display Power
monitor
(Si only)
Sub-displays
Press the SEL/RESET button
to change sub-displays.
Steering Wheel Controls
Use these buttons to operate the i-MID and the Vehicle Menu.
Outside
temperature
Odometer
Trip A
Trip B
Clock
Clock
(or wallpaper)
Audio display
(or Phone
display during
call)
A warning or indicator message
may appear as necessary. Press
the INFO button to clear it.
*Press and hold the Display/Info button to enter the trip computer menu. Press Display/Info to scroll
through range, elapsed time, and average speed.
Trip
computer*
Turn-by-turn
directions
(next route
maneuver)
(+) Button:
Press to scroll
upward in the
Vehicle Menu.
) Button:
(
t
Press to go back to
the previous Vehicle
Menu screen.
(-) Button:
Press to scroll
downward in the
Vehicle Menu.
Display/Information
Button:
Change i-MID displays.
SOURCE Button:
Press to enter a
selection.
(
) Button:
u
Press to go to the next
Vehicle Menu screen.
MENU Button:
Press to go to Vehicle
Menu for customization
and other settings.
6 7
ECO ASS IS T
mph
mph
mph
TM
TIRE PR ES SURE MONITO RI NG SYSTEM ( TPMS)
When turned on, performance of the vehicle’s engine, transmission, cruise control, and
air conditioning system are adjusted to maximize fuel efficiency. Available on EX-L.
Turning ECON Mode On/Off
1. Press ECON.
2. The ECON mode indicator
comes on.
3. Check the i-MID for the
system status.
4. Press ECON again to turn the
system off.
Monitors the vehicle’s tire pressures.
How It Works
When the tire pressure drops
significantly below recommended
levels, the low tire pressure
indicator comes on.
If a message also appears on
the i-MID, there may be a
problem with the system.
See your dealer.
What to Do
1. Visually inspect the tires for damage.
2. Use a tire air pressure gauge to
check which tire(s) have low
pressure.
3. Inflate the tire(s), if necessary, to the
recommended pressures listed on
the label on the driver’s doorjamb.
4. Start TPMS calibration.
What to Do
Ambient Meter
Any time you inflate, change, or rotate one or more of your tires, you need to
Indicates real-time fuel efficiency using color-coded bars.
High fuel efficiency Moderate fuel efficiency Low fuel efficiency
This feature can be turned off in the Customize Settings Menu. See your Owner’s
Manual for more information.
8 9
recalibrate the system. Use the buttons on the steering wheel to operate the
Vehicle Menu (see page 7).
1. Press MENU.
2. Select Customize Settings.
3. Select TPMS Calibration.
4. Select Initialize.
5. Select Yes.
Calibration begins and will finish automatically.
The process takes about 30 minutes of driving
30-60 mph.
6. Press MENU to exit.
