Honda Accord 2016 Owners Manual

California Proposition 65 Warning

WARNING: This product contains or emits

chemicals known to the state of California to cause cancer and birth defects or other reproductive harm.

NOTICE

To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as law enforcement, that have the special equipment, can read the information if they have access to the vehicle or the EDR.

Event Data Recorders

This vehicle is equipped with an event data recorder (EDR).

The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed. The EDR is designed to record data related

to vehicle dynamics and safety systems for a short period of time, typically 30 seconds or less. The EDR in this vehicle is designed to record such data as:

• How various systems in your vehicle were operating;

• Whether or not the driver and passenger safety belts were

buckled/fastened;

• How far (if at all) the driver was depressing the accelerator and/or brake pedal; and,

• How fast the vehicle was traveling.

These data can help provide a better understanding of the circumstances in which crashes and injuries occur. NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situation occurs; no data are recorded by the EDR under normal driving conditions and no personal data (e.g., name, gender, age, and crash location) are recorded. However, other parties, such as law enforcement, could combine the EDR data with the type of personally identifying data routinely acquired during a crash investigation.

31T2A630 2016 Accord 4-Door Owner's Manual

The data belongs to the vehicle owner and may not be accessed by anyone else except as legally required or with the permission of the vehicle owner.

Service Diagnostic Recorders

This vehicle is equipped with service-related devices that record information about powertrain performance. The data can be used to verify emissions law requirements and/or help technicians diagnose and solve service problems. It may also be combined with data from other sources for research purposes, but it remains confidential.

California Perchlorate Contamination Prevention Act

The airbags, seat belt tensioners, and CR type batteries in this vehicle may contain perchlorate materials - special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate/

As you read this manual, you will find information that is preceded by a symbol. This information is intended to help you avoid damage to your vehicle, other property, or the environment.

A Few Words About Safety

3DANGER

3WARNING

3CAUTION

You will find this important safety information in a variety of forms, including:

Your safety, and the safety of others, is very important. And operating this vehicle safely is an important responsibility.

To help you make informed decisions about safety, we have provided operating procedures and other information on labels and in this manual. This information alerts you to potential hazards that could hurt you or others.

Of course, it is not practical or possible to warn you about all the hazards associated with operating or maintaining your vehicle. You must use your own good judgment.

● Safety Labels - on the vehicle.

● Safety Messages - preceded by a safety alert symbol

one of three signal words: DANGER, WARNING, or CAUTION. These signal words mean:

You WILL be KILLED or SERIOUSLY HURT if you don't follow instructions.

You CAN be KILLED or SERIOUSLY HURT if you don't follow instructions.

You CAN be HURT if you don't follow instructions.

● Safety Headings - such as Important Safety Precautions.

● Safety Section - such as Safe Driving.

● Instructions - how to use this vehicle correctly and safely.

This entire book is filled with important safety information - please read it carefully.

3 and

This owner’s manual should be considered a permanent part of the vehicle and should remain with the vehicle when it is sold.

This owner’s manual covers all models of your vehicle. You may find descriptions of equipment and features that are not on your particular model.

Images throughout this owner’s manual (including the front cover) represent features and equipment that are available on some, but not all, models. Your particular model may not have some of these features.

This owner’s manual is for vehicles sold in the United States and Canada.

The information and specifications included in this publication were in effect at the time of approval for printing. Honda Motor Co., Ltd. reserves the right, however, to discontinue or change specifications or design at any time without notice and without incurring any obligation.

2 Safe Driving P. 27

For Safe Driving P. 28 Seat Belts P. 32 Airbags P. 39

2 Instrument Panel P. 67

Indicators P. 68 Gauges and Displays P. 95

2 Controls P. 113

Clock P. 114 Locking and Unlocking the Doors P. 116 Opening and Closing the Moonroof Adjusting the Seats P. 160

P. 138

2 Features P. 185

Audio System P. 186 Audio System Basic Operation P. 192, 215 Customized Features P. 298, 316 HomeLink® Universal Transceiver

P. 340

2 Driving P. 411

Before Driving P. 412 Towing a Trailer P. 417 Refueling P. 497 Fuel Economy P. 499

2 Maintenance P. 501

Before Performing Maintenance P. 502 Maintenance MinderTM P. 505 Checking and Maintaining Wiper Blades P. 537 Climate Control System Maintenance P. 551

2 Handling the Unexpected P. 557

Tools P. 558 If a Tire Goes Flat P. 559 Overheating P. 572 Indicator, Coming On/Blinking P. 574

2 Information P. 583

Specifications P. 584 Identification Numbers P. 588 Emissions Testing P. 591 Warranty Coverages P. 593

Contents

Child Safety P. 52 Exhaust Gas Hazard P. 64 Safety Labels P. 65

Opening and Closing the Trunk P. 128 Security System P. 132 Opening and Closing the Windows P. 135 Operating the Switches Around the Steering Wheel P. 139 Adjusting the Mirrors P. 158 Interior Lights/Interior Convenience Items P. 168 Climate Control System P. 180

Audio Error Messages P. 286 General Information on the Audio System P. 291 Bluetooth® HandsFreeLink® P. 343, 374 Compass

When Driving P. 421 Braking P. 479 Parking Your Vehicle P. 491 Accessories and Modifications P. 500

Maintenance Under the Hood P. 513 Replacing Light Bulbs P. 529 Checking and Maintaining Tires P. 539 Battery P. 548 Remote Transmitter Care P. 549 Cleaning P. 552

Engine Does Not Start P. 565 Jump Starting P. 568 Shift Lever Does Not Move P. 571 Fuses P. 578 Emergency Towing P. 582

P. 409

Quick Reference Guide

Safe Driving

Instrument Panel

Controls

Features

Driving

Maintenance

Handling the Unexpected

Information

P. 4

P. 27

P. 67

P. 113

P. 185

P. 411

P. 501

P. 557

P. 583

Devices that Emit Radio Waves P. 589 Reporting Safety Defects P. 590 Authorized Manuals P. 595 Customer Service Information P. 596

Index

P. 600

Quick Reference Guide

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

❙ System Indicators (P 68) ❙ Gauges (P 95) ❙ Information Display

(P 96)

❙ Audio System (P 192, 215)

❙ ENGINE START/STOP Button

(P 140)

❙ Front Seat Heater Switches

(P 178)

❙ Ignition Switch

(P 139)

❙ ECON Button (P 441)

❙ Multi-Information Display

(P 99)

❙ (Vehicle Stability Assist (VSA®) System OFF) Button (P 472)

❙ Tire Pressure Monitoring System (TPMS) Button

(P 476)

❙ Audio/Information Screen

(P 193, 216)

❙ Navigation System

() See Navigation System Manual

❙ Audio/Information Touch Screen

(P 218)

❙ Auxiliary Input Jack

(P 188)

❙ Rear Window Defogger (P 154) ❙ Heated Mirror Button

(P 154)

❙ Hazard Warning Button ❙ Center Pocket (P 171)

❙ Climate Control System (P 180)

❙ Collision Mitigation Braking System

(CMBSTM) OFF Button* (P 486)

❙ Road Departure Mitigation (RDM) Button

(P 461)

❙ Parking Sensor System Button

(P 493)

Visual Index

Quick Reference Guide

❙ (+ / (- / / Buttons (P 190)

❙ SOURCE Button (P 190)

❙ Bluetooth® HandsFreeLink® System

Voice Control Buttons

(P 343, 374)

❙ Navigation System Voice Control Buttons

(P 235), () See Navigation System Manual

❙ Steering Wheel Adjustments (P 157)

❙ SEL/RESET Button

(P 100)

❙ (Information) Buttons

(P 99)

❙ Paddle Shifter (Shift up)

(P 434)

❙ Brightness Control (P 153)

❙ (Select/Reset) Knob (P 96)

❙ (Display) Button (P 193, 216)

❙ Paddle Shifter (Shift down)

(P 434)

❙ LaneWatch

TM*

(P 473)

❙ Fog Lights

(P 146)

❙ Headlights/Turn Signals (P 144)

❙ Adaptive Cruise Control (ACC) Buttons

(P 448)

❙ MENU Button

(P 190)

❙ Cruise Control Buttons (P 442)

❙ Lane Keeping Assist System (LKAS) Button

(P 466)

❙ Horn (Press an area around .)

❙ Distance Button

(P 455)

❙ Wipers/Washers (P 151)

* Not available on all models

Visual Index

Quick Reference Guide

❙ Door Mirror Controls (P 159)

❙ Passenger's Front Airbag

(P 42)

❙ Parking Brake (P 479)

❙ Glove Box (P 170)

❙ Rearview Mirror (P 158)

❙ Hood Release Handle (P 515)

❙ Power Door Lock Master Switch (P 126)

❙ Power Window Switches (P 135)

❙ Interior Fuse Box (P 580) ❙ Driver's Front Airbag (P 42)

❙ Trunk Main Switch

(P 130)

❙ Fuel Fill Door Release Handle (P 498)

❙ Trunk Release (P 128)

❙ Shift Lever

Continuously Variable Transmission (CVT)

(P 430, 432)

Automatic Transmission

(P 436)

Manual Transmission (P 438)

❙ Wireless Charger

(P 174)

❙ Accessory Power Socket

(P 173)

❙ USB Port (P 187)

Quick Reference Guide

❙ Seat Belt to Secure a Child Seat (P 61)

❙ Sun Visors ❙ Vanity Mirrors

❙ Map Lights (P 169)

❙ Front Seat (P 160)

❙ Seat Belts (P 32)

❙ LATCH to Secure a Child Seat (P 57)

❙ Side Curtain Airbags (P 48)

❙ Grab Handle

❙ Ceiling Light (P 168)

❙ Coat Hook (P 176)

❙ Seat Belt (Installing a Child Seat) (P 59)

❙ Rear Seat (P 166)

❙ Accessory Power

Socket

(P 173)

❙ Side Airbags (P 46)

❙ Sunglasses Holder

(P 177)

❙ Moonroof Switch

(P 138)

❙ USB Port

(P 187)

* Not available on all models

Visual Index

Quick Reference Guide

❙ Maintenance Under the Hood (P 513) ❙ Windshield Wipers (P 151, 537)

❙ Tires (P 539, 559)

❙ Door Lock/Unlock Control (P 119)

❙ Power Door Mirrors (P 159)

❙ Headlights (P 144, 529)

❙ How to Refuel (P 498) ❙ High-Mount Brake Light (P 536)

❙ Emergency Trunk Release Lever (P 131)

❙ Opening/Closing the Trunk (P 128)

❙ Parking Lights (P 144, 531, 533)

❙ Front Turn Signal/Side Marker Lights

(P 144, 531, 532, 533)

❙ Fog Lights

(P 146, 531)

❙ Multi-View Rear Camera (P 496)

❙ Trunk Release Button

(P 129)

❙ Brake Lights (P 534)

❙ Back-Up Lights (P 535) ❙ Taillights (P 535)

❙ Rear Side Marker/Taillights (P 534)

❙ Rear Turn Signal Lights (P 534)

Quick Reference Guide

Ambient Meter

● Changes color to reflect your driving style. Green: Fuel efficient driving Light green: Moderate acceleration/ deceleration White: Aggressive acceleration/ deceleration

● The ambient meter color changes in accordance with your brake or accelerator pedal operation.

ECON Button (P 441)

Helps maximize fuel economy.

ECON Mode Indicator (P 78)

Comes on when the ECON button is pressed.

Models with multi-information display

The message is displayed for a few seconds when the ECON button is pressed.

Ambient Meter

* Not available on all models

Eco Assist System (P 441)

Quick Reference Guide

Safe Driving (P 27)

Airbags (P 39)

● Your vehicle is fitted with airbags to help protect you and your passengers during a moderate-to-severe collision.

Child Safety (P 52)

● All children 12 and younger should be seated in the rear seat.

● Smaller children should be properly restrained in a forward-facing child seat.

● Infants must be properly restrained in a rear-facing child seat.

Exhaust Gas Hazard (P 64)

● Your vehicle emits dangerous exhaust gases that contain carbon monoxide. Do not run the engine in confined spaces where carbon monoxide gas can accumulate.

Before Driving Checklist (P 31)

● Before driving, check that the front seats, head restraints, steering wheel, and mirrors have been properly adjusted.

Seat Belts (P 32)

● Fasten your seat belt and sit upright well back in the seat.

● Check that your passengers are wearing their seat belts correctly.

Fasten your lap belt as low as possible.

Quick Reference Guide

Instrument Panel (P 67)

Canada

U.S.

Low Fuel Indicator

Anti-lock Brake System (ABS) Indicator

Parking Brake and Brake System Indicator (Red)

Canada

U.S.

Washer Level Indicator

System Indicators

Malfunction Indicator Lamp

Low Oil Pressure Indicator

Charging System Indicator

Vehicle Stability Assist (VSA®) System Indicator

VSA® OFF Indicator

Low Tire Pressure/ TPMS Indicator

Electric Power Steering (EPS) System Indicator

Lights Indicators

Lights On Indicator High Beam Indicator

Fog Light Indicator

Immobilizer System Indicator

Seat Belt Reminder Indicator

System Indicators

CRUISE CONTROL

Indicator

Adaptive Cruise Control (

ACC

) Indicator (Amber)

CRUISE MAIN Indicator

Tachometer

Speedometer

Fuel Gauge

Security System Alarm Indicator

Shift Lever Position Indicator

Gauges (P 95)/Information Display* (P 96)/ Multi-Information Display

(P 99)/System Indicators (P 68)

Turn Signal and Hazard Warning Indicators

System Indicators

Temperature Gauge

M (7-speed manual shift mode) Indicator/ Shift Indicator

Maintenance Minder Indicator

Smart Entry System Indicator

Starter System Indicator

System Message Indicator

ECON mode Indicator

Road Departure Mitigation (RDM) Indicator

Collision Mitigation Braking System

(CMBSTM) Indicator

Light Control Indicator

Door and Trunk Open Indicator

Brake System Indicator (Amber)

Supplemental Restraint System Indicator

Canada

U.S.

Models with information display

Auto High-Beam Indicator (Green)

/ Auto High-Beam Indicator (Amber)

Lane Keeping Assist System (

LKAS

) Indicator (Amber)

Lane Keeping Assist System (

LKAS

) Indicator (White)

Parking Sensor System Indicator

Adaptive Cruise Control (

ACC

) Indicator (White)

* Not available on all models

Quick Reference Guide

Controls (P 113)

Models with two displays

Models with one display

Clock (P 114)

The audio system receives signals from GPS satellites, updating the clock automatically.

a Select , then select Settings. b Select Clock/Info, then Clock

Adjustment.

c Adjust the hours and minutes by

selecting / .

d Select OK to set the time.

a Enter the Clock Adjustment screen.

2 Adjusting the Clock (P 114)

b Rotate to change hour, then press

c Rotate to change minute, then

press .

ENGINE START/STOP

Button

Press the button to change the vehicle’s power mode.

(P 140)

Quick Reference Guide

Turn Signal Control Lever

Right

Left

Light Control Switches

Low Beam

High Beam

Flashing

Wiper/Washer Control Lever

Adjustment Ring

(-: Low Sensitivity

(- : Lower speed, fewer sweeps

(+: High Sensitivity

(+ : Higher speed, more sweeps

MIST OFF AUTO

: Wiper speed varies automatically

INT

: Low speed with intermittent

LO: Low speed wipe HI: High speed wipe

Pull toward you to spray washer fluid.

* Not available on all models

Turn Signals (P 144)

Wipers and Washers

(P 151)

Steering Wheel (P 157)

● To adjust, pull the adjustment lever towards you, adjust to the desired position, then lock the lever back in place.

Lights (P 144)

Unlocking the Front Doors from the Inside

(P 124)

● Pull either front door inner handle to unlock and open it at the same time.

*1:Vehicle with auto wiper *2:Vehicle without auto wiper

● Unlocking and opening the driver’s door from the inner handle unlocks all the other doors.

Quick Reference Guide

Trunk (P 128)

Trunk Release

Selector Switch

Adjustment Switch

Power Window Lock Button

Window Switch

Indicator

● To unlock and open the trunk:

• Pull the trunk release.

• Press the trunk release button on the remote

transmitter or the smart entry remote.

• Press the trunk release button trunk lid.

on the

Power Door Mirrors

(P 159)

● With the ignition switch in ON the selector switch to L or R.

● Push the appropriate edge of the adjustment switch to adjust the mirror.

, move

Power Windows (P 135)

● With the ignition switch in ON and close the power windows.

● If the power window lock button is in the off position, each passenger's window can be opened and closed with its own switch.

● If the power window lock button is in the on position (indicator on), each passenger's window switch is disabled.

, open

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Quick Reference Guide

Models with navigation system

Driver’s Side Temperature Control Buttons

(Windshield Defroster) Button

SYNC (Synchronized) Button

Air flows from floor and windshield defroster vents.

Air flows from floor vents.

Air flows from floor and dashboard vents, and back of the center console

Air flows from dashboard vents and back of the center console

AUTO Button

(On/Off) Button

(Recirculation) Button

MODE Control Button

/ (Fan Control) Buttons

A/C (Air Conditioning) Button

Passenger’s Side Temperature Control Buttons

* Not available on all models

Climate Control System (P 180)

● Press the AUTO button to activate the climate control system.

● Press the button to turn the system on or off.

● Press the button to defrost the windshield.

The climate control system is voice operable. (P 235)

Quick Reference Guide

Features (P 185)

(+ / (- / / Button

SOURCE Button

Models with one display

Models with two displays

Audio Remote Controls

(P 190)

(+ / (- Button

●

Press to adjust the volume up/down.

● SOURCE Button

FMAMCDUSBiPod Bluetooth® AudioPandora®

FMAMSiriusXM® Pandora® Apps

Bluetooth® AudioAudio

CDUSBiPod

AUX

● / Button Radio:Press to change the preset station.

Press and hold to select the next or previous strong station.

CD/USB device:

Press to skip to the beginning of the next song or return to the beginning of the current song. Press and hold to change a folder.

Quick Reference Guide

Audio System (P 192, 215)

(P 192)

Models with one display

Audio/Information Screen

BACK Button

FM/AM Button

(Skip/Seek) Button

Selector Knob

Button

VOL/ (Volume/Power) Knob

CD Button

AUX Button

CD Slot

(CD Eject) Button

Preset Buttons (1-6)

SETTINGS Button

(Skip/Seek) Button

PHONE Button

MENU Button

DISP Button

* Not available on all models

Quick Reference Guide

(Power) Button

(HOME) Icon

VOL (Volume) Icons

(MENU) Icon

(BACK) Icon

Audio/Information Touch Screen

Audio/Information Screen

App List

(P215)

For navigation system operation () See the Navigation System Manual

Models with two displays

MAP

Quick Reference Guide

M Indicator

Shift Indicator

Manual Transmission* (P 438) Continuously Variable Transmission

(CVT)

(P 430, 432)

● Shift to

(P and depress the brake pedal when starting the engine.

● Shifting

Park

Turn off or start the engine. Transmission is locked.

Neutral

Transmission is not locked.

Drive (S)

● Better acceleration.

● Increased engine

braking.

● Going up or down hills.

● On models with paddle

shifter, 7-speed manual shift mode can be used.

Models without paddle shifter

Models with paddle shifter

Depress the brake pedal and press the release button to move out of

(P.

Press the release button to move the shift lever.

Move the shift lever without pressing the release button.

Reverse

Used when reversing.

Drive

● Normal driving.

● On models with paddle

shifter, 7-speed mode can be used temporarily.

Low

● Further increased engine braking.

● Going up or down hills.

Shift Down

Paddle Shifter

Shift Up (+ Paddle Shifter

7-Speed Manual Shift Mode

(P 434)

● Allows you to manually shift the transmission up or down without removing your hands from the steering wheel.

When the shift lever is in (S

● Pulling a paddle shifter changes the mode from continuously variable transmission (CVT) to 7-speed manual shift mode.

● The M indicator and the selected speed number are displayed in the shift indicator.

When the shift lever is in (D

● Pulling a paddle shifter temporarily changes the mode from continuously variable transmission (CVT) to 7-speed manual shift mode. The selected speed number is displayed in the shift indicator.

Shift Lever

Release Button

* Not available on all models

Driving (P 411)

Quick Reference Guide

Automatic Transmission* (P 436)

● Shift to

(P and depress the brake pedal when starting the engine.

● Shifting

Park

Turn off or start the engine. Transmission is locked.

Neutral

Transmission is not locked.

Drive (S)

● Automatically changing gears between 1st and 5th (5th gear is used only in at high speed).

● Used when towing a trailer in hilly terrain.

● Used to increase engine braking.

Depress the brake pedal and press the release button to move out of

(P.

Press the release button to move the shift lever.

Move the shift lever without pressing the release button.

Reverse

Used when reversing.

Drive

Normal driving.

Shift Lever

Release Button

VSA® OFF Button (P 472)

● The vehicle stability assist (VSA®) system helps stabilize the vehicle during cornering, and helps maintain traction while accelerating on loose or slippery road surfaces.

● VSA® comes on automatically every time you start the engine.

● To turn VSA® on or off, press and hold the button until you hear a beep.

Cruise Control (P 442)

● Cruise control allows you to maintain a set speed without keeping your foot on the accelerator pedal.

● To use cruise control, press the CRUISE

button, then press the –/SET

MAIN

button once you have achieved the desired speed (above 25 mph or 40 km/h).

Quick Reference Guide

Collision Mitigation

a Push the fuel fill door

release handle.

b Turn the fuel fill cap

slowly to remove the cap.

c Place the cap in the

holder on the fuel fill door.

d After refueling, screw

the cap back on until it clicks at least once.

* Not available on all models

Braking System

(CMBS

(P 483)

● When a possible collision is likely unavoidable, the CMBS reduce the vehicle speed and the severity of the collision.

● To turn the CMBS hold the button until you hear a beep.

) OFF Button*

Tire Pressure Monitoring System (TPMS)

● Detects a change in tire conditions and overall dimensions due to decrease in tire pressures.

● The TPMS is turned on automatically every time you start the engine.

● A calibration procedure must be performed when certain conditions arise.

can help you to

on or off, press and

(P 475)

Refueling (P 497)

Fuel recommendation: Unleaded gasoline with a pump octane number 87 or

higher required

Fuel tank capacity: 17.2 US gal (65 L)

Quick Reference Guide

Maintenance (P 501)

Under the Hood (P 513)

● Check engine oil, engine coolant, and windshield washer fluid. Add when necessary.

● Check brake fluid and clutch

fluid.

● Check the battery condition monthly.

a Pull the hood release handle under the corner of the

dashboard.

b Locate the hood latch lever, pull the lever up, and lift up

the hood.

c When finished, close the hood and make sure it is firmly

locked in place.

Lights (P 529)

● Inspect all lights regularly.

Wiper Blades (P 537)

● Replace blades if they leave streaks across the windshield.

Tires (P 539)

● Inspect tires and wheels regularly.

● Check tire pressures regularly.

● Install snow tires for winter

driving.

Quick Reference Guide

Handling the Unexpected (P 557)

* Not available on all models

Flat Tire (P 559)

● Park in a safe location and replace the flat tire with the compact spare tire in the trunk.

Indicators Come On

(P 574)

● Identify the indicator and consult the owner's manual.

Engine Won’t Start

(P 565)

● If the battery is dead, jump start using a booster battery.

Blown Fuse (P 578)

● Check for a blown fuse if an electrical device does not operate.

Overheating (P 572)

● Park in a safe location. If you do not see steam under the hood, open the hood, and let the engine cool down.

Emergency Towing

(P 582)

● Call a professional towing service if you need to tow your vehicle.

Quick Reference Guide

What to Do If

Models without smart entry system

Models with smart entry system

Models without smart entry system

Models with smart entry system

Models without smart entry system

Models with smart entry system

The ignition switch does not turn from Why?

(0 to (q.

●

The steering wheel may be locked.

●

Try to turn the steering wheel left and right while turning the ignition key.

The power mode does not change from VEHICLE OFF (LOCK) to ACCESSORY. Why?

The ignition switch does not turn from I cannot remove the key. Why?

The power mode does not change from ACCESSORY to VEHICLE OFF (LOCK). Why?

*1:Except U.S. automatic transmission/CVT models

(q to (0 and

●

Move the steering wheel left and right while pressing the ENGINE START/STOP button at the same time.

The shift lever should be moved to (P.

Quick Reference Guide

* Not available on all models

Why does the brake pedal pulsate slightly when applying the brakes?

This can occur when the ABS activates, and does not indicate a problem. Apply firm, steady pressure on the brake pedal. Never pump the brake pedal.

The rear door cannot be opened from inside the vehicle. Why?

Why do the doors lock after I unlocked the doors using a remote transmitter?

Why does the beeper sound when I open the driver's door?

Why does the beeper sound when I start driving?

Check if the childproof lock is in the lock position. If so, open the rear door with the outside door handle. To cancel this function, push the lever to the unlock position.

If you do not open the doors within 30 seconds, the doors are relocked automatically for security.

The beeper sounds when:

●

The key is left in the ignition switch*.

●

The power mode* is in ACCESSORY.

●

The exterior lights are left on.

The beeper sounds when:

●

Driver and/or front passenger are not wearing their seat belts.

●

The parking brake lever is not fully released.

Quick Reference Guide

Why do I hear a screeching sound when I apply the brake pedal?

The brake pads may need to be replaced. Have your vehicle inspected by a dealer.

Safe Driving

You can find many safety recommendations throughout this chapter, and throughout this manual.

For Safe Driving

Important Safety Precautions ............. 28

Your Vehicle’s Safety Features............ 30

Safety CheckList................................. 31

Seat Belts

About Your Seat Belts........................ 32

Fastening a Seat Belt.......................... 35

Seat Belt Inspection............................ 38

Airbags

Airbag System Components............... 39

Types of Airbags ................................ 42

Front Airbags (SRS) ............................ 42

Side Airbags ...................................... 46

Side Curtain Airbags .......................... 48

Airbag System Indicators.................... 49

Airbag Care ....................................... 51

Child Safety

Protecting Child Passengers ............... 52

Safety of Infants and Small Children.......54

Safety of Larger Children ................... 62

Exhaust Gas Hazard

Carbon Monoxide Gas....................... 64

Safety Labels

Label Locations .................................. 65

Safe Driving

For Safe Driving

1Important Safety Precautions

Some states, provinces and territories prohibit the use of cell phones other than hands-free devices by the driver while driving.

The following pages explain your vehicle's safety features and how to use them properly. The safety precautions below are ones that we consider to be among the most important.

Important Safety Precautions

■ Always wear your seat belt

A seat belt is your best protection in all types of collisions. Airbags are designed to supplement seat belts, not replace them. So even though your vehicle is equipped with airbags, make sure you and your passengers always wear your seat belts, and wear them properly.

■ Restrain all children

Children ages 12 and under should ride properly restrained in a back seat, not the front seat. Infants and small children should be restrained in a child seat. Larger children should use a booster seat and a lap/shoulder seat belt until they can use the belt properly without a booster seat.

■ Be aware of airbag hazards

While airbags can save lives, they can cause serious or fatal injuries to occupants who sit too close to them, or are not properly restrained. Infants, young children, and short adults are at the greatest risk. Be sure to follow all instructions and warnings in this manual.

■ Don't drink and drive

Alcohol and driving don't mix. Even one drink can reduce your ability to respond to changing conditions, and your reaction time gets worse with every additional drink. So don't drink and drive, and don't let your friends drink and drive, either.

Safe Driving

■ Pay appropriate attention to the task of driving safely

Engaging in cell phone conversation or other activities that keep you from paying close attention to the road, other vehicles, and pedestrians could lead to a crash. Remember, situations can change quickly, and only you can decide when it is safe to divert some attention away from driving.

■ Control your speed

Excessive speed is a major factor in crash injuries and deaths. Generally, the higher the speed, the greater the risk, but serious injuries can also occur at lower speeds. Never drive faster than is safe for current conditions, regardless of the maximum speed posted.

■ Keep your vehicle in safe condition

Having a tire blowout or a mechanical failure can be extremely hazardous. To reduce the possibility of such problems, check your tire pressures and condition frequently, and perform all regularly scheduled maintenance.

uuFor Safe DrivinguImportant Safety Precautions

uuFor Safe Driving uYour Vehicle’s Safety Features

Safe Driving

1Your Vehicle’s Safety Features

Your vehicle is equipped with many features that work together to help protect you and your passengers during a crash.

Some features do not require any action on your part. These include a strong steel framework that forms a safety cage around the passenger compartment, front and rear crush zones, a collapsible steering column, and tensioners that tighten the front seat belts in a sufficient crash.

However, you and your passengers cannot take full advantage of these features unless you remain seated in the correct position and always wear your seat belts. In fact, some safety features can contribute to injuries if they are not used properly.

Safety Cage Crush Zones Seats and Seat-Backs Head Restraints Collapsible Steering Column Seat Belts Front Airbags

Side Curtain Airbags Door Locks

Side Airbags

Seat Belt Tensioners

Your Vehicle’s Safety Features

The following checklist will help you take an active role in protecting yourself and your passengers.

Safe Driving

Safety CheckList

1Safety CheckList

If the door and trunk open indicator is on, a door and/or the trunk is not completely closed. Close all doors and the trunk tightly until the indicator goes off.

2 Door and Trunk Open Indicator P. 74

Models with information display

Models with multi-information display

For the safety of you and your passengers, make a habit of checking these items each time before you drive.

• After everyone has entered the vehicle, be sure all doors are closed and locked. Locking the doors helps prevent an occupant from being ejected and an outsider from unexpectedly opening a door.

2 Locking/Unlocking the Doors from the Inside P. 124

• Adjust your seat to a position suitable for driving. Be sure the front seats are adjusted as far to the rear as possible while allowing the driver to control the vehicle. Sitting too close to a front airbag can result in serious or fatal injury in a crash.

2 Adjusting the Seats P. 160

• Adjust head restraints to the proper position. Head restraints are most effective when the center of the head restraint aligns with the center of your head. Taller persons should adjust their head restraint to the highest position.

2 Adjusting the Front and Rear Outer Head Restraint Positions P. 163

• Always wear your seat belt, and make sure you wear it properly. Confirm that any passengers are properly belted as well.

2 Fastening a Seat Belt P. 35

• Protect children by using seat belts or child seats according to a child's age, height and weight.

2 Child Safety P. 52

uuFor Safe DrivinguSafety CheckList

Safe Driving

Seat Belts

1About Your Seat Belts

Seat belts cannot completely protect you in every crash. But in most cases, seat belts can reduce your risk of serious injury.

Most states and all Canadian provinces and territories require you to wear seat belts.

The emergency locking retractor may lock if you lean forward too quickly. Slower movements will allow the belt to extend fully without locking.

WARNING

Not wearing a seat belt properly increases the chance of serious injury or death in a crash, even though your vehicle has airbags.

Be sure you and your passengers always wear seat belts and wear them properly.

About Your Seat Belts

Seat belts are the single most effective safety device because they keep you connected to the vehicle so that you can take advantage of many built-in safety features. They also help keep you from being thrown against the inside of the vehicle, against other passengers, or out of the vehicle. When worn properly, seat belts also keep your body properly positioned in a crash so that you can take full advantage of the additional protection provided by the airbags.

In addition, seat belts help protect you in almost every type of crash, including:

- frontal impacts

- side impacts

- rear impacts

- rollovers

■ Lap/shoulder seat belts

All five seating positions are equipped with lap/shoulder seat belts with emergency locking retractors. In normal driving the retractor lets you move freely while keeping some tension on the belt. During a collision or sudden stop the retractor locks to restrain your body.

The rear seat belts also have a lockable retractor for use with child seats.

2 Installing a Child Seat with a Lap/Shoulder Seat Belt P. 59

Safe Driving

■ Proper use of seat belts

1About Your Seat Belts

If a rear seat passenger moves around and extends the seat belt, the lockable retractor may activate. If this happens, release the retractor by unfastening the seat belt and allow the belt to retract completely. Then refasten the belt.

1Seat Belt Reminder

The indicator will also come on if a front passenger does not fasten their seat belt within six seconds after the ignition switch is turned to ON

. When no one is sitting in the front passenger’s seat, the indicator will not come on and the beeper will not sound. The indicator also may not come on and the beeper may not sound when the occupant is not heavy enough to trigger the weight sensor. Such occupants (e.g., infants and smaller children) should be moved to the rear seat as a deploying front airbag likely will injure or kill them.

2 Protecting Child Passengers P. 52

* Not available on all models

Follow these guidelines for proper use:

• All occupants should sit upright, well back in the seat, and remain in that position for the duration of the trip. Slouching and leaning reduce the effectiveness of the belt and can increase the chance of serious injury in a crash.

• Never place the shoulder part of a lap/shoulder seat belt under your arm or behind your back. This could cause very serious injuries in a crash.

• Two people should never use the same seat belt. If they do, they could be very seriously injured in a crash.

• Do not put any accessories on the seat belts. Devices intended to improve comfort or reposition the shoulder part of a seat belt can reduce the protective capability and increase the chance of serious injury in a crash.

Seat Belt Reminder

■

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Your vehicle monitors front seat belt use. If the ignition switch is turned to ON

before the driver’s seat belt is fastened, the beeper will sound and the indicator will blink. If the driver does not fasten the belt before the beeper stops, the indicator will remain on.

The beeper will also periodically sound and the indicator will blink while driving until the driver's and front passenger’s seat belts are fastened.

Continued

uuSeat BeltsuAbout Your Seat Belts

Safe Driving

1Automatic Seat Belt Tensioners

The seat belt tensioners can only operate once. If a tensioner is activated, the SRS indicator will come on. Have a dealer replace the tensioner and thoroughly inspect the seat belt system as it may not offer protection in a subsequent crash.

During a moderate-to-severe side impact, the tensioner on that side of the vehicle also activates.

Automatic Seat Belt Tensioners

■

The front seats are equipped with automatic seat belt tensioners to enhance safety.

The tensioners automatically tighten the front seat belts during a moderate-tosevere frontal collision, sometimes even if the collision is not severe enough to inflate the front airbags.

Safe Driving

Fastening a Seat Belt

1Fastening a Seat Belt

No one should sit in a seat with an inoperative seat belt or one that does not appear to be working correctly. Using a seat belt that is not working properly may not protect the occupant in a crash. Have a dealer check the belt as soon as possible.

Never insert any foreign objects into the buckle or retractor mechanism.

Pull out slowly.

Correct Seated Posture.

Latch Plate

Buckle

After adjusting a front seat to the proper position, and while sitting upright and well back in the seat:

uuSeat BeltsuFastening a Seat Belt

2 Adjusting the Seats P. 160

1. Pull the seat belt out slowly.

2. Insert the latch plate into the buckle, then

tug on the belt to make sure the buckle is secure.

u Make sure that the belt is not twisted or

caught on anything.

Continued

uuSeat BeltsuFastening a Seat Belt

Safe Driving

1Fastening a Seat Belt

To release the belt, push the red PRESS button then guide the belt by hand until it has retracted completely. When exiting the vehicle, be sure the belt is out of the way and will not get caught by closing the door.

WARNING

Improperly positioning the seat belts can cause serious injury or death in a crash.

Make sure all seat belts are properly positioned before driving.

Lap belt as low as possible

1Adjusting the Shoulder Anchor

The shoulder anchor height can be adjusted to four levels. If the belt contacts your neck, lower the height one level at a time.

After an adjustment, make sure that the shoulder anchor position is secure.

Push

Adjusting the Shoulder Anchor

■

The front seats have adjustable shoulder anchors to accommodate taller and shorter

occupants.

3. Position the lap part of the belt as low as possible across your hips, then pull up on the shoulder part of the belt so the lap part fits snugly. This lets your strong pelvic bones take the force of a crash and reduces the chance of internal injuries.

4. If necessary, pull up on the belt again to remove any slack, then check that the belt rests across the center of your chest and over your shoulder. This spreads the forces of a crash over the strongest bones in your upper body.

1. Move the anchor up and down while holding the release button.

2. Position the anchor so that the belt rests across the center of your chest and over your shoulder.

Safe Driving

Advice for Pregnant Women

1Advice for Pregnant Women

Each time you have a checkup, ask your doctor if it is okay for you to drive.

To reduce the risk of injuries to both you and your unborn child that can be caused by an inflating front airbag:

• When driving, sit upright and adjust the seat as far

back as possible while allowing full control of the vehicle.

• When sitting in the front passenger's seat, adjust

the seat as far back as possible.

Wear the shoulder belt across the chest avoiding the abdomen.

Wear the lap part of the belt as low as possible across the hips.

■

If you are pregnant, the best way to protect yourself and your unborn child when driving or riding in a vehicle is to always wear a seat belt and keep the lap part of the belt as low as possible across the hips.

uuSeat BeltsuFastening a Seat Belt

uuSeat BeltsuSeat Belt Inspection

Safe Driving

1Seat Belt Inspection

WARNING

Not checking or maintaining seat belts can result in serious injury or death if the seat belts do not work properly when needed.

Check your seat belts regularly and have any problem corrected as soon as possible.

Seat Belt Inspection

Regularly check the condition of your seat belts as follows:

• Pull each belt out fully, and look for frays, cuts, burns, and wear.

• Check that the latches work smoothly and the belts retract easily.

u If a belt does not retract easily, cleaning the belt may correct the problem. Only

use a mild soap and warm water. Do not use bleach or cleaning solvents. Make sure the belt is completely dry before allowing it to retract.

Any belt that is not in good condition or working properly will not provide proper protection and should be replaced as soon as possible. A belt that has been worn during a crash may not provide the same level of protection in a subsequent crash. Have your seat belts inspected by a dealer after any collision.

Safe Driving

Airbags

Airbag System Components

8 810

Continued

uuAirbagsu Airbag System Components

Safe Driving

The front, front side, and side curtain airbags are deployed according to the direction and severity of impact. Both side curtain airbags are deployed in a rollover. The airbag system includes:

a Two SRS (Supplemental Restraint System)

front airbags. The driver’s airbag is stored in the center of the steering wheel; the front passenger’s airbag is stored in the dashboard. Both are marked SRS AIRBAG.

b Two side airbags, one for the driver and

one for a front passenger. The airbags are stored in the outer edges of the seatbacks. Both are marked SIDE AIRBAG.

c Two side curtain airbags, one for each

side of the vehicle. The airbags are stored in the ceiling, above the side windows. The front and rear pillars are marked SIDE CURTAIN AIRBAG.

d An electronic control unit that continually

monitors and can record information about the sensors, the airbag activators, the seat belt tensioners, and driver and front passenger seat belt use when the ignition switch is in ON

e Automatic front seat belt tensioners. The

driver’s and front passenger’s seat belts incorporate sensors that detect whether or not they are fastened.

f A driver’s seat position sensor. If the seat

is too far forward, the airbag will inflate with less force.

g Weight sensors in the front passenger’s

seat. The front passenger’s airbag will be turned off if the weight on the seat is 65 lbs (29 kg) or less (the weight of an infant or small child).

h Impact sensors that can detect a

moderate-to-severe front or side impact.

i An indicator on the dashboard that alerts

you that the front passenger’s front airbag has been turned off.

j An indicator on the instrument panel that

alerts you to a possible problem with your airbag system or seat belt tensioners.

k Safing Sensor

l A rollover sensor that can detect if your

vehicle is about to roll over and signal the control unit to deploy both side curtain airbag.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Safe Driving

■

1Important Facts About Your Airbags

Do not attempt to deactivate your airbags. Together, airbags and seat belts provide the best protection.

When driving, keep hands and arms out of the deployment path of the front airbag by holding each side of the steering wheel. Do not cross an arm over the airbag cover.

Airbags can pose serious hazards. To do their job, airbags must inflate with tremendous force. So, while airbags help save lives, they can cause burns, bruises, and other minor injuries, sometimes even fatal ones if occupants are not wearing their seat belts properly and sitting correctly.

What you should do: Always wear your seat belt properly, and sit upright and as far back from the steering wheel as possible while allowing full control of the vehicle. A front passenger should move their seat as far back from the dashboard as possible.

Remember, however, that no safety system can prevent all injuries or deaths that can occur in a severe crash, even when seat belts are properly worn and the airbags deploy.

Do not place hard or sharp objects between yourself and a front airbag. Carrying hard or sharp objects on your lap, or driving with a pipe or other sharp object in your mouth, can result in injuries if your front airbag inflates.

uuAirbags uAirbag System Components

Important Facts About Your Airbags

Do not attach or place objects on the front airbag covers. Objects on the

covers marked SRS AIRBAG could interfere with the proper operation of the airbags or be propelled inside the vehicle and hurt someone if the airbags inflate.

uuAirbagsu Types of Airbags

Safe Driving

1Types of Airbags

The airbags can inflate whenever the ignition switch is in ON

After an airbag inflates in a crash, you may see a small amount of smoke. This is from the combustion process of the inflator material and is not harmful. People with respiratory problems may experience some temporary discomfort. If this occurs, get out of the vehicle as soon as it is safe to do so.

1Front Airbags (SRS)

Dual-Stage, Multiple-Threshold Front Airbags (SRS)

Your vehicle is equipped with dual-stage, multiplethreshold front airbags (SRS). During a frontal crash severe enough to cause one or both front airbags to deploy, the airbags can inflate at different rates, depending on the severity of the crash, whether or not the seat belts are latched, and/ or other factors. Frontal airbags are designed to supplement the seat belts to help reduce the likelihood of head and chest injuries in frontal crashes.

Types of Airbags

Your vehicle is equipped with three types of airbags:

• Front airbags: Airbags in front of the driver's and front passenger's seats.

• Side airbags: Airbags in the driver's and front passenger's seat-backs.

• Side curtain airbags: Airbags above the side windows.

Each is discussed in the following pages.

Front Airbags (SRS)

The front SRS airbags inflate in a moderate-to-severe frontal collision to help protect the head and chest of the driver and/or front passenger.

SRS (Supplemental Restraint System) indicates that the airbags are designed to supplement seat belts, not replace them. Seat belts are the occupant's primary restraint system.

Housing Locations

■

The front airbags are housed in the center of the steering wheel for the driver, and in the dashboard for the front passenger. Both airbags are marked SRS AIRBAG.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Safe Driving

■

1How the Front Airbags Work

Although the driver's and front passenger's airbags normally inflate within a split second of each other, it is possible for only one airbag to deploy. This can happen if the severity of a collision is at the margin, or threshold, that determines whether or not the airbags will deploy. In such cases, the seat belt will provide sufficient protection, and the supplemental protection offered by the airbag would be minimal.

Front airbags are designed to inflate during moderate-to-severe frontal collisions. When the vehicle decelerates suddenly, the sensors send information to the control unit which signals one or both front airbags to inflate.

A frontal collision can be either head-on or angled between two vehicles, or when a vehicle crashes into a stationary object, such as a concrete wall.

■

uuAirbags u Front Airbags (SRS)

Operation

How the Front Airbags Work

While your seat belt restrains your torso, the front airbag provides supplemental protection for your head and chest.

The total time for inflation and deflation is so fast that most occupants are not aware that the airbags deployed until they see them lying in front of them.

The front airbags deflate immediately so that they won't interfere with the driver's visibility or the ability to steer or operate other controls.

Continued

uuAirbagsu Front Airbags (SRS)

Safe Driving

■ When front airbags should not deploy

Minor frontal crashes: Front airbags were designed to supplement seat belts and help save lives, not to prevent minor scrapes, or even broken bones that might occur during a less than moderate-to-severe frontal crash. Side impacts: Front airbags can provide protection when a sudden deceleration causes a driver or front passenger to move towards the front of the vehicle. Side airbags and side curtain airbags have been specifically designed to help reduce the severity of injuries that can occur during a moderate-to-severe side impact which can cause the driver or passenger to move towards the side of the vehicle. Rear impacts: Head restraints and seat belts are your best protection during a rear impact. Front airbags cannot provide any significant protection and are not designed to deploy in such collisions. Rollovers: Seat belts and, in vehicles equipped with a rollover sensor, side airbags and side curtain airbags offer the best protection in a rollover. Because front airbags could provide little if any protection, they are not designed to deploy during a rollover.

■ When front airbags deploy with little or no visible damage

Because the airbag system senses sudden deceleration, a strong impact to the vehicle framework or suspension might cause one or more of the airbags to deploy. Examples include running into a curb, the edge of a hole, or other low fixed object that causes a sudden deceleration in the vehicle chassis. Since the impact is underneath the vehicle, damage may not be readily apparent.

■ When front airbags may not deploy, even though exterior damage

appears severe

Since crushable body parts absorb crash energy during an impact, the amount of visible damage does not always indicate proper airbag operation. In fact, some collisions can result in severe damage but no airbag deployment because the airbags would not have been needed or would not have provided protection even if they had deployed.

Safe Driving

Advanced Airbags

1Advanced Airbags

If there is a problem with the driver's seat position sensor, the SRS indicator will come on and the airbag will inflate with full (normal) force, regardless of the driver's seating position.

For both advanced front airbags to work properly:

• Do not spill any liquid on or under the seats.

• Do not put any object under the passenger’s seat.

• Make sure any objects are positioned properly on

the floor. Improperly positioned objects can interfere with the advanced airbag sensors.

• All occupants should sit upright and wear their seat

belts properly.

• Do not place any cover over the passenger side

dashboard.

Driver’s Seat Position Sensor

Passenger’s Seat Weight Sensors

■

Your front airbags have advanced features to help reduce the likelihood of airbag related injuries to smaller occupants.

uuAirbags u Front Airbags (SRS)

The driver's advanced front airbag system includes a seat position sensor.

If the seat is too far forward, the airbag inflates with less force, regardless of the severity of the impact.

The passenger's advanced front airbag system has weight sensors.

Although we recommend against carrying an infant or small child in front, if the sensors detect the weight of a child (up to about 65 lbs or 29 kg), the system will automatically turn off the passenger's front airbag.

uuAirbagsu Side Airbags

Safe Driving

1Side Airbags

Make sure you and your front seat passenger always sit upright. Leaning into the path of a side airbag can prevent the airbag from deploying properly and increases your risk of serious injury.

Do not attach accessories on or near the side airbags. They can interfere with the proper operation of the airbags, or hurt someone if an airbag inflates.

Do not cover or replace the front seat-back covers without consulting a dealer. Improperly replacing or covering front seat-back covers can prevent your side airbags from properly deploying during a side impact.

Housing Location

When inflated

Side Airbag

Side Airbags

The side airbags help protect the torso and pelvis of the driver or a front passenger during a moderate-to-severe side impact.

Housing Locations

■

Operation

■

The side airbags are housed in the outside edge of the driver’s and passenger’s seatbacks.

Both are marked SIDE AIRBAG.

When the sensors detect a moderate-tosevere side impact, the control unit signals the side airbag on the impact side to immediately inflate.

Safe Driving

■ When a side airbag deploys with little or no visible damage

Because the airbag systems senses sudden acceleration, a strong impact to the side of the vehicle's framework can cause a side airbag to deploy. In such cases, there may be little or no damage, but the side impact sensors detected a severe enough impact to deploy the airbag.

■ When a side airbag may not deploy, even though visible damage appears

It is possible for a side airbag to not deploy during an impact that results in apparently severe damage. This can occur when the point of impact was towards the far front or rear of the vehicle, or when the vehicle's crushable body parts absorbed most of the crash energy. In either case, the side airbag would not have been needed nor provided protection even if it had deployed.

uuAirbags u Side Airbags

severe

uuAirbagsu Side Curtain Airbags

Safe Driving

1Side Curtain Airbags

If the SRS control unit senses that your vehicle is about to rollover, it immediately deploys both side curtain airbags and activates both front seat belt tensioners.

If the impact is on the passenger’s side, the passenger’s side curtain airbag deploys even if there is no passenger in the passenger seat.

To get the best protection from the side curtain airbags, occupants should wear their seat belts properly and sit upright and well back in their seats.

Do not attach any objects to the side windows or roof pillars as they can interfere with the proper operation of the side curtain airbags.

Side Curtain Airbag Storage

Deployed Side Curtain Airbag

Side Curtain Airbags

The side curtain airbags help protect the heads of the driver and passengers in outer seating positions during a moderate-to-severe side impact. The side curtain airbags equipped in this vehicle are also designed to help reduce the likelihood of partial and complete ejection of vehicle occupants through side windows in crashes, particularly rollover crashes.

Housing Locations

■

Operation

■

The side curtain airbags are located in the ceiling above the side windows on both sides of the vehicle.

The side curtain airbag is designed to deploy in a rollover or a moderate-to-severe side impact.

Safe Driving

■ When side curtain airbags deploy in a frontal collision

1Supplemental Restraint System (SRS) Indicator

WARNING

Ignoring the SRS indicator can result in serious injury or death if the airbag systems or tensioners do not work properly.

Have your vehicle checked by a dealer as soon as possible if the SRS indicator alerts you to a possible problem.

* Not available on all models

One or both side curtain airbags may inflate in a moderate-to-severe angled frontal collision.

Airbag System Indicators

If a problem occurs in the airbag system, the SRS indicator will come on and a message appears on the multi-information display*.

Supplemental Restraint System (SRS) Indicator

■

If the indicator comes on at any other time, or does not come on at all, have the system checked by a dealer as soon as possible. If you don’t, your airbags and seat belt tensioners may not work properly when they are needed.

■ When the ignition switch is turned to

ON (w

The indicator comes on for a few seconds, then goes off. This tells you the system is working properly.

uuAirbagsu Airbag System Indicators

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Continued

uuAirbagsu Airbag System Indicators

Safe Driving

1Passenger Airbag Off Indicator

If the indicator comes on with no front passenger and no objects on the passenger’s seat, or with an adult riding there, something may be interfering with the weight sensors, such as:

• An object hanging on the seat or in the seat-back

pocket.

• A child seat or other object pressing against the

rear of the seat-back.

• A rear passenger pushing or pulling on the back of

the front passenger’s seat.

• The front seat or seat-back is forced back against

an object on the seat or floor behind it.

• An object placed under the front passenger’s seat.

If none of these conditions exist, have your vehicle checked by a dealer as soon as possible.

The passenger airbag off indicator may come on and goes off repeatedly if the total weight on the seat is near the airbag cutoff threshold.

U.S. Canada

Passenger Airbag Off Indicator

■

Infants and small children should always ride properly restrained in a back seat.

2 Child Safety P. 52

Objects placed on the seat can also cause the indicator to come on.

If the front passenger seat is empty, the passenger’s front airbag will not deploy and the indicator will not come on.

■ When the passenger airbag off

indicator comes on

The indicator comes on to alert you that the passenger’s front airbag has been turned off. This occurs when the front passenger’s weight sensors detect 65 lbs (29 kg) or less, the weight of an infant or small child, on the seat.

Safe Driving

Airbag Care

1Airbag Care

We recommend against the use of salvaged airbag system components, including the airbag, tensioners, sensors, and control unit.

You do not need to, and should not, perform any maintenance on or replace any airbag system components yourself. However, you should have your vehicle inspected by a dealer in the following situations:

■ When the airbags have deployed

If an airbag has inflated, the control unit and other related parts must be replaced. Similarly, once an automatic seat belt tensioner has been activated, it must be replaced.

■ When the vehicle has been in a moderate-to-severe collision

Even if the airbags did not inflate, have your dealer inspect the following: the driver’s seat position sensor, weight sensors in the passenger’s seat, front seat belt tensioners, and each seat belt that was worn during the crash.

■ Do not remove or modify a front seat without consulting a dealer

This would likely disable the driver's seat position sensor or the weight sensors in the passenger's seat. If it is necessary to remove or modify a front seat to accommodate a person with disabilities, contact a Honda dealer, or for U.S. vehicles, American Honda Automobile Customer Service at 800-999-1009 and for Canadian vehicles, Honda Canada Customer Relations at 888-9-HONDA-9.

uuAirbags u Airbag Care

Safe Driving

Child Safety

1Protecting Child Passengers

The National Highway Traffic Safety Administration and Transport Canada recommend that all children ages 12 and under be properly restrained in a rear seat. Some states or provinces/territories have laws restricting where children may ride.

WARNING

Children who are unrestrained or improperly restrained can be seriously injured or killed in a crash.

Any child too small for a seat belt should be properly restrained in a child seat. A larger child should be properly restrained with a seat belt, using a booster seat if necessary.

Protecting Child Passengers

Each year, many children are injured or killed in vehicle crashes because they are either unrestrained or not properly restrained. In fact, vehicle accidents are the number one cause of death of children ages 12 and under.

To reduce the number of child deaths and injuries, every state, Canadian province and territory requires that infants and children be properly restrained when they ride in a vehicle.

Children should sit properly restrained in a rear seat. This is because:

• An inflating front or side airbag can injure or kill a child sitting in the front seat.

• A child in the front seat is more likely to interfere with the driver's ability to safely control the vehicle.

• Statistics show that children of all sizes and ages are safer when they are properly restrained in a rear seat.

Safe Driving

• Any child who is too small to wear a seat belt correctly must be restrained in an

1Protecting Child Passengers

To deactivate a lockable retractor, release the buckle and allow the seat belt to wind up all the way.

To remind you of the passenger's front airbag hazards and child safety, your vehicle has warning labels on the dashboard (U.S. models) and on the front visors. Please read and follow the instructions on these labels.

2 Safety Labels P. 65

WARNING

Allowing a child to play with a seat belt or wrap one around their neck can result in serious injury or death.

Instruct children not to play with any seat belt and make sure any unused seat belt a child can reach is buckled, fully retracted, and locked.

• Never hold a child on your lap because it is impossible to protect them in the

• Never put a seat belt over yourself and a child. During a crash, the belt would

uuChild SafetyuProtecting Child Passengers

approved child seat that is properly secured to the vehicle using either the lap belt portion of the lap/shoulder belt or the lower anchors of the LATCH system.

event of a collision.

likely press deep into the child and cause serious or fatal injuries.

• Never let two children use the same seat belt. Both children could be very seriously injured in a crash.

• Do not allow children to operate the doors, windows or seat adjustments.

• Do not leave children in the vehicle unattended, especially in hot weather when

the inside of the vehicle can get hot enough to kill them. They could also activate vehicle controls causing it to move unexpectedly.

uuChild Safety u Safety of Infants and Small Children

Safe Driving

1Protecting Infants

Rear-facing child seats should never be installed in a forward facing position.

Always refer to the child seat manufacturer’s instructions before installation.

WARNING

Placing a rear-facing child seat in the front seat can result in serious injury or death during a crash.

Always place a rear-facing child seat in the rear seat, not the front.

Safety of Infants and Small Children

Protecting Infants

■

An infant must be properly restrained in a rear-facing, reclining child seat until the infant reaches the seat maker's weight or height limit for the seat, and the infant is at least one year old.

■ Positioning a rear-facing child seat

Child seats must be placed and secured in a rear seating position.

When properly installed, a rear-facing child seat may prevent the driver or a front passenger from moving their seat all the way back, or from locking their seat-back in the desired position.

It can also interfere with proper operation of the passenger's advanced front airbag system.

2 Airbags P. 39

If this occurs, we recommend that you install the child seat directly behind the front passenger's seat, move the seat as far forward as needed, and leave it unoccupied. Or, you may wish to get a smaller rear-facing child seat.

Safe Driving

Protecting Smaller Children

1Protecting Smaller Children

Educate yourself about the laws and regulations regarding child seat use where you are driving, and follow the child seat manufacturer's instructions.

Many experts recommend use of a rear-facing seat for a child up to two years old if the child’s height and weight are appropriate for a rear-facing seat.

WARNING

Placing a forward-facing child seat in the front seat can result in serious injury or death if the front airbag inflates.

If you must place a forward-facing child seat in front, move the vehicle seat as far back as possible, and properly restrain the child.

■

If a child is at least one year old and within the weight range indicated by the child seat manufacturer, the child should be properly restrained in a firmly secured forward-facing child seat.

Placing a forward-facing child seat in the front seat can be hazardous, even with advanced front airbags that automatically turn the passenger's front airbag off. A rear seat is the safest place for a child.

uuChild SafetyuSafety of Infants and Small Children

■ Forward-facing child seat placement

We strongly recommend placing a forwardfacing child seat in a rear seating position.

Continued

uuChild Safety u Safety of Infants and Small Children

Safe Driving

1Selecting a Child Seat

Installation of a LATCH-compatible child seat is simple.

LATCH-compatible child seats have been developed to simplify the installation process and reduce the likelihood of injuries caused by incorrect installation.

Selecting a Child Seat

■

Most child seats are LATCH-compatible (Lower Anchors and Tethers for CHildren). Some have a rigid-type connector, while others have a flexible-type connector. Both are equally easy to use. Some existing and previously owned child seats can only be installed using the seat belt. Whichever type you choose, follow the child seat manufacturer's use and care instructions as well as the instructions in this manual. Proper installation is key to maximizing your child's safety.

In seating positions and vehicles not equipped with LATCH, a LATCH compatible child seat can be installed using the seat belt and a top tether for added security. This is because all child seats are required to be designed so that they can be secured with a lap belt or the lap part of a lap/shoulder belt. In addition, the child seat manufacturer may advise that a seat belt be used to attach a LATCH-compatible seat once a child reaches a specified weight. Please read the child seat owner’s manual for proper installation instructions.

■ Important consideration when selecting a child seat

Make sure the child seat meets the following three requirements:

• The child seat is the correct type and size for the child.

• The child seat is the correct type for the seating position.

• The child seat is compliant with Federal Motor Vehicle Safety Standard 213 or

Canadian Motor Vehicle Safety Standard 213.

Safe Driving

■

Marks

Rigid Type

Lower Anchors

Flexible Type

A LATCH-compatible child seat can be installed in either of the two outer rear seats. A child seat is attached to the lower anchors with either the rigid or flexible type of connectors.

uuChild SafetyuSafety of Infants and Small Children

Installing a LATCH-Compatible Child Seat

1. Locate the lower anchors under the marks.

2. Place the child seat on the vehicle seat then

attach the child seat to the lower anchors according to the instructions that came with the child seat.

u When installing the child seat, make sure

that the lower anchors are not obstructed by the seat belt or any other object.

Continued

uuChild Safety u Safety of Infants and Small Children

Safe Driving

1Installing a LATCH-Compatible Child Seat

For your child's safety, when using a child seat installed using the LATCH system, make sure that the seat is properly secured to the vehicle. A child seat that is not properly secured will not adequately protect a child in a crash and may cause injury to the child or other vehicle occupants.

Anchor

Tether Strap Hook

3. Open the tether anchor cover behind the head restraint.

4. Raise the head restraint to its highest position, then route the tether strap between the head restraint legs, and secure the tether strap hook onto the anchor.

5. Tighten the tether strap as instructed by the child seat manufacturer.

6. Make sure the child seat is firmly secured by rocking it forward and back and side to side; little movement should be felt.

7. Make sure any unused seat belt that a child can reach is buckled, the lockable retractor is activated, and the belt is fully retracted and locked.

Safe Driving

Installing a Child Seat with a Lap/Shoulder Seat Belt

1Installing a Child Seat with a Lap/Shoulder Seat Belt

A child seat that is not properly secured will not adequately protect a child in a crash and may cause injury to the child or other vehicle occupants.

■

uuChild SafetyuSafety of Infants and Small Children

1. Place the child seat on the vehicle seat.

2. Route the seat belt through the child seat

according to the seat manufacturer’s instructions, and insert the latch plate into the buckle.

u Insert the latch plate fully until it clicks.

3. Slowly pull the shoulder part of the belt all the way out until it stops. This activates the lockable retractor.

4. Let the seat belt completely wind up into the retractor, then try to pull it out to make sure the retractor is locked.

u If you are able to pull the shoulder belt

out, the lockable retractor is not activated. Pull the seat belt all the way out, and repeat steps 2 – 4.

5. Grab the shoulder part of the seat belt near the buckle, and pull up to remove any slack from the lap part of the belt.

u When doing this, place your weight on

the child seat and push it into the vehicle seat.

Continued

uuChild Safety u Safety of Infants and Small Children

Safe Driving

1Installing a Child Seat with a Lap/Shoulder Seat Belt

To deactivate a lockable retractor, release the buckle and allow the seat belt to wind up all the way.

6. Make sure the child seat is firmly secured by rocking it forward and back and side to side; little movement should be felt.

7. Make sure any unused seat belt that a child can reach is buckled, the lockable retractor is activated, and the belt is fully retracted and locked.

Safe Driving

Adding Security with a Tether

1Adding Security with a Tether

Since a tether can provide additional security to the lap/shoulder seat belt installation, we recommend using a tether whenever one is available.

Tether Anchorage Points

Cover

Anchor

Outer Position

Tether Strap Hook

Anchor

Center Position

Tether Strap Hook

Anchor

■

uuChild SafetyuSafety of Infants and Small Children

A tether anchorage point is provided behind each rear seating position. A child seat that is installed with a seat belt and comes with a tether can use the tether for additional security.

1. Locate the appropriate tether anchorage point and lift the cover.

2. Raise the head restraint to its highest position, then route the tether strap through the head restraint legs. Make sure the strap is not twisted.

3. Secure the tether strap hook onto the anchor.

4. Tighten the tether strap as instructed by the child seat manufacturer.

uuChild Safety u Safety of Larger Children

Safe Driving

1Safety of Larger Children

WARNING

Allowing a child age 12 or under to sit in front can result in injury or death if the passenger's front airbag inflates.

If a larger child must ride in front, move the vehicle seat as far to the rear as possible, have the child sit up properly and wear the seat belt properly, using a booster seat if needed.

Safety of Larger Children

Protecting Larger Children

■

The following pages give instructions on how to check proper seat belt fit, what kind of booster seat to use if one is needed, and important precautions for a child who must sit in front.

Checking Seat Belt Fit

■

When a child is too big for a child seat, secure the child in a rear seat using the lap/ shoulder seat belt. Have the child sit upright and all the way back, then answer the following questions.

If you answer yes to all these questions, the child is ready to wear the lap/shoulder seat belt correctly. If you answer no to any question, the child needs to ride on a booster seat until the seat belt fits properly without a booster seat.

■ Checklist

• Do the child's knees bend comfortably over the edge of the seat?

• Does the shoulder belt cross between the child's neck and arm?

• Is the lap part of the seat belt as low as possible, touching the child's thighs?

• Will the child be able to stay seated like this for the whole trip?

Safe Driving

Booster Seats

1Booster Seats

When installing a booster seat, make sure to read the instructions that came with it, and install the seat accordingly. There are high- and low-type booster seats. Choose a booster seat that allows the child to wear the seat belt correctly.

Some U.S. states and Canadian provinces and territories require children to use a booster seat until they reach a given age or weight (e.g. 6 years or 60 lbs). Be sure to check current laws in the state or province, or territory where you intend to drive.

■

Protecting Larger Children-Final Checks

■

Your vehicle has a rear seat where children can be properly restrained. If you ever have to carry a group of children, and a child must ride in front:

• Make sure you read and fully understand the instructions and safety information in this manual.

• Move the front passenger seat as far back as possible.

• Have the child sit upright and well back in the seat.

• Check that the seat belt is properly positioned so that the child is secure in the

seat.

■ Monitoring child passengers

We strongly recommend that you keep an eye on child passengers. Even older, more mature children sometimes need to be reminded to fasten their seat belts and sit up properly.

uuChild SafetyuSafety of Larger Children

If a lap/shoulder seat belt cannot be used properly, position the child in a booster seat in a rear seating position. For the child's safety, check that the child meets the booster seat manufacturer's recommendations.

Safe Driving

Exhaust Gas Hazard

1Carbon Monoxide Gas

An enclosed area such as a garage can quickly fill up with carbon monoxide gas. Do not run the engine with the garage door closed. Even when the garage door is open, drive out of the garage immediately after starting the engine.

WARNING

Carbon monoxide gas is toxic. Breathing it can cause unconsciousness and even kill you.

Avoid any enclosed areas or activities that expose you to carbon monoxide.

Carbon Monoxide Gas

The engine exhaust from this vehicle contains carbon monoxide, a colorless, odorless, and highly toxic gas. As long as you properly maintain your vehicle, carbon monoxide gas will not get into the interior.

■ Have the exhaust system inspected for leaks whenever

• The exhaust system is making an unusual noise.

• The exhaust system may have been damaged.

• The vehicle is raised for an oil change.

When you operate a vehicle with the trunk open, airflow can pull exhaust gas into the interior and create a hazardous condition. If you must drive with the trunk open, open all the windows and set the climate control system as shown below.

1. Select the fresh air mode.

2. Select the mode.

3. Set the fan speed to high.

4. Set the temperature control to a comfortable setting.

Adjust the climate control system in the same manner if you sit in your parked vehicle with the engine running.

Safe Driving

Safety Labels

Sun Visor

U.S. models

Canadian models

Radiator Cap

U.S. models only

Dashboard

Label Locations

These labels are in the locations shown. They warn you of potential hazards that can cause serious injury or death. Read these labels carefully.

If a label comes off or becomes hard to read (except for the U.S. dashboard label which may be removed by the owner), contact a dealer for a replacement.

Instrument Panel

* Not available on all models

This chapter describes the buttons, indicators, and gauges that are used while driving.

Indicators ............................................ 68

Information Display Warning and

Information Messages

Multi-Information Display Warning and

Information Messages

Gauges and Displays

Gauges.............................................. 95

Information Display Multi-Information Display

.................... 85

.................... 87

.......................... 96

................. 99

Instrument Panel

Indicators

U.S.

Canada

(Red)

U.S.

Canada

(Amber)

* Not available on all models

Indicator Name On/Blinking Explanation Message

Parking Brake and Brake System Indicator (Red)

●

Comes on for a few seconds when you turn the ignition switch to ON

, then goes off if the parking

brake has been released.

●

Comes on when the parking brake is applied, and goes off when it is released.

●

Comes on when the brake fluid level is low.

●

Comes on if there is a problem

●

Comes on while driving - Make sure the parking brake is released. Check the brake fluid level.

2 What to do when the indicator

●

comes on while driving P. 576

Comes on along with the ABS indicator - Have your vehicle checked by

a dealer.

2 If the Brake System Indicator (Red)

Comes On P. 576

with the brake system.

●

The beeper sounds and the indicator comes on if you drive with the parking brake not fully released.

Brake System Indicator (Amber)

●

Comes on for a few seconds when you turn the ignition switch to ON

, then goes off.

●

Comes on if there is a problem with a system related to braking other than the conventional brake

●

Stays on constantly - Have your vehicle checked by a dealer.

system.

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

uuIndicatorsu

Instrument Panel

* Not available on all models

Indicator Name On/Blinking Explanation Message

Low Oil Pressure Indicator

●

Comes on when you turn the ignition switch to ON (w*1, and goes off when the engine starts.

●

Comes on when the engine oil

●

Comes on while driving - Immediately stop in a safe place.

2 If the Low Oil Pressure Indicator

Comes On P. 574

pressure is low.

Malfunction Indicator Lamp

Charging System Indicator

●

Comes on when you turn the ignition switch to ON

, and goes off either when the engine starts or after several seconds if the engine did not start. If “readiness codes” have not been set, it blinks five times before it goes off.

●

Comes on if there is a problem with the emissions control system.

●

Blinks when a misfire in the engine’s cylinders is detected.

●

Comes on when you turn the ignition switch to ON

, and goes off when the engine starts.

●

Comes on when the battery is not charging.

●

Readiness codes are part of the on board diagnostics for the emissions control systems.

2 Testing of Readiness Codes P. 591

●

Comes on while driving - Have your vehicle checked by a dealer.

●

Blinks while driving - Stop in a safe place where there are no flammable objects. Stop the engine for 10 minutes or more, and wait for it to cool down. Then, take the vehicle to a dealer.

2 If the Malfunction Indicator Lamp

Comes On or Blinks P. 575

●

Comes on while driving - Turn off the climate control system and rear defogger in order to reduce electricity consumption.

2 If the Charging System Indicator

Comes On P. 574

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Continued

uuIndicatorsu

Instrument Panel

Models with information display

Models with multiinformation display

Models with information display

Models with multiinformation display

* Not available on all models

Indicator Name On/Blinking Explanation Message

●

Indicates the current shift lever position.

Shift Lever Position Indicator

●

Comes on when 7-speed manual

2 Shifting P. 430, 432, 436

shift mode is applied.

M (7-speed manual shift mode) Indicator/ Shift Indicator

2 7-Speed Manual Shift Mode P. 434

—

uuIndicatorsu

Instrument Panel

Models with information display

Models with multiinformation display

* Not available on all models

Indicator Name On/Blinking Explanation Message

●

Blinks if the transmission system has a problem.

●

Blinks while driving - Avoid sudden starts and acceleration and have your vehicle checked by a dealer immediately.

Transmission Indicator

Seat Belt Reminder Indicator

●

Comes on and the beeper sounds if you are not wearing a seat belt when you turn the ignition switch to ON

●

If the front passenger is not wearing a seat belt, the indicator comes on a few seconds later.

●

Blinks while driving if either you or the front passenger has not fastened

●

The beeper stops and the indicator goes off when you and the front passenger fasten their seat belts.

●

Stays on after you or the front passenger has fastened the seat belt - A detection error may have

occurred in the sensor. Have your vehicle checked by a dealer.

2 Seat Belt Reminder P. 33

a seat belt. The beeper sounds and the indicator blinks at regular intervals.

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Continued

uuIndicatorsu

Instrument Panel

* Not available on all models

Indicator Name On/Blinking Explanation Message

Low Fuel Indicator

Anti-lock Brake System (ABS) Indicator

Supplemental Restraint System Indicator

●

Comes on when the fuel reserve is running low (approximately 2.6 U.S. gal./9.7 Liter left).

●

Blinks if there is a problem with the fuel gauge.

●

Comes on for a few seconds when you turn the ignition switch to ON

, then goes off.

●

If it comes on at any other time, there is a problem with the ABS.

●

Comes on for a few seconds when you turn the ignition switch to ON

, then goes off.

●

Comes on if a problem with any of the following is detected:

- Supplemental restraint system

●

Comes on - Refuel your vehicle as soon as possible.

●

Blinks - Have your vehicle checked by a dealer.

●

Stays on constantly - Have your vehicle checked by a dealer. With this indicator on, your vehicle still has normal braking ability but no anti-lock function.

2 Anti-lock Brake System (ABS)

P. 481

●

Stays on constantly or does not come on at all - Have your vehicle

checked by a dealer.

- Side airbag system

- Side curtain airbag system

- Seat belt tensioner

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

uuIndicatorsu

Instrument Panel

* Not available on all models

Indicator Name On/Blinking Explanation Message

Vehicle Stability Assist (VSA®) System Indicator

●

Comes on for a few seconds when you turn the ignition switch to ON

, then goes off.

●

Blinks when VSA® is active.

●

Comes on if there is a problem with the VSA® system or hill start assist

●

Stays on constantly - Have your vehicle checked by a dealer.

2 Vehicle Stability Assist (VSA®), aka

Electronic Stability Control (ESC), System P. 471

system.

●

Comes on for a few seconds when Vehicle Stability Assist (VSA®) OFF Indicator

you turn the ignition switch to ON

, then goes off.

●

Comes on when you deactivate

2 VSA® OFF Button P. 472

—

VSA®.

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Continued

uuIndicatorsu

Instrument Panel

Models with information display

Models with multiinformation display

* Not available on all models

Indicator Name On/Blinking Explanation Message

●

Comes on for a few seconds if you turn the ignition switch to ON (w*1,

●

Goes off when all doors and the trunk are closed.

then goes off.

●

Comes on if any door or the trunk is

Door and Trunk Open Indicator

Parking Sensor System Indicator

Electric Power Steering (EPS) System Indicator

not completely closed.

●

The beeper sounds and the indicator comes on if any door or the trunk is opened while driving.

●

Comes on for a few seconds when you turn the ignition switch to ON

, then goes off.

●

Comes on if there is a problem with the parking sensor system.

●

Comes on when you turn the ignition switch to ON

off when the engine starts.

●

Comes on if there is a problem with the EPS system.

, and goes

●

Check if the area around the sensor(s) is covered with mud, ice, snow, etc. If the indicator stays on even after you clean the area, have the system checked by a dealer.

●

Stays on constantly or does not come on at all - Have your vehicle

checked by a dealer.

2 If the Electric Power Steering (EPS)

System Indicator Comes On P. 576

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

—

uuIndicatorsu

Instrument Panel

* Not available on all models

Indicator Name On/Blinking Explanation Message

Low Tire Pressure/ TPMS Indicator

●

Comes on for a few seconds when you turn the ignition switch to ON (w*1, then goes off.

●

May come on briefly if the ignition switch is turned to ON (w*1 and the vehicle is not moved within 45 seconds, to indicate the calibration process is not yet complete.

●

Comes on and stays on when:

- One or more tires’ pressures are determined to be significantly low.

- The system has not been calibrated.

●

Blinks for about one minute, and then stays on if there is a problem with the TPMS, or when a compact spare tire is temporarily installed.

●

Comes on while driving - Stop in a safe place, check tire pressures, and inflate the tire(s) if necessary.

●

Stays on after the tires are inflated to the recommended pressures - The

system needs to be calibrated.

2 TPMS Calibration P. 475

●

Blinks and remains on - Have your vehicle checked by a dealer. If the vehicle is fitted with a compact spare, get your regular tire repaired or replaced and put back on your vehicle as soon as you can.

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Continued

uuIndicatorsu

Instrument Panel

* Not available on all models

Indicator Name On/Blinking Explanation Message

System Message Indicator

●

Comes on for a few seconds when you turn the ignition switch to ON (w*1, then goes off.

●

Comes on along with a beep when a problem is detected. A system message on the multi-information display appears at

the same time.

●

While the indicator is on, press the

(information) button to see the

message again.

●

Refer to the Indicators information in this chapter when a system message appears on the multi-information display. Take the appropriate action for the message.

●

The multi-information display does not return to the normal screen unless the

warning is canceled, or the button is pressed.

Turn Signal and Hazard Warning Indicators

High Beam Indicator

Lights On Indicator

●

Blinks when you operate the turn signal lever.

●

Blink along with all turn signals when you press the hazard warning button.

●

Comes on when the high beam headlights are on.

●

Comes on whenever the light switch is on, or in AUTO when the exterior lights are on.

●

Does not blink or blinks rapidly - A turn signal light bulb has blown. Change the bulb immediately.

2 Replacing Light Bulbs P. 531, 533,

534

— —

●

If you remove the key from the ignition switch*1 while the exterior lights are on, a chime sounds when the driver's door is opened.

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

—

uuIndicatorsu

Instrument Panel

Indicator

* Not available on all models

Indicator Name On/Blinking Explanation Message

●

Fog Light Indicator

Immobilizer System Indicator

Comes on when the fog lights are on.

●

Comes on briefly when you turn the ignition switch to ON (w*1, then goes off.

●

Comes on if the immobilizer system cannot recognize the key information.

— —

●

Blinks - You cannot start the engine. Turn the ignition switch to LOCK (0*1, pull the key out, and then insert the key

and turn it to ON

●

Repeatedly blinks - The system may

again.

be malfunctioning. Have your vehicle

—

checked by a dealer.

●

Do not attempt to alter this system or add other devices to it. Electrical problems can occur.

●

Security System Alarm Indicator

Blinks when the security system alarm has been set.

2 Security System Alarm P. 132

—

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Continued

uuIndicatorsu

Instrument Panel

* Not available on all models

Indicator Name On/Blinking Explanation Message

●

Comes on for a few seconds when you turn the ignition switch to ON

, then goes off.

●

Comes on when you press the ECON button.

●

Comes on when you press the CRUISE button.

●

Comes on if you have set a speed for cruise control.

●

Comes on when the washer fluid gets low.

●

Comes on when the scheduled

maintenance is due soon.

2 ECON Button P. 441

2 Cruise Control P. 442

●

Refill the washer fluid.

2 Refilling Window Washer Fluid

P. 528

2 Maintenance MinderTM P. 505

ECON Mode Indicator

CRUISE MAIN Indicator

CRUISE CONTROL

Indicator

Washer Level Indicator

Maintenance Minder Indicator

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

—

uuIndicatorsu

Instrument Panel

U.S.

Canada

* Not available on all models

Indicator Name On/Blinking Explanation Message

Smart Entry System Indicator

Starter System Indicator

Light Control Indicator

●

Comes on for a few seconds when you change the power mode to ON.

●

Comes on as soon as a problem is detected in the smart entry system or push button starting system.

●

Comes on for a few seconds when you turn the ignition switch to ON

, then goes off.

●

Comes on if the starter system has a problem.

●

Comes on if there is a problem with the automatic lighting control system or low beam headlights

●

Stays on constantly or does not come on at all - Have your vehicle checked by a

dealer.

●

As a temporary measure, press and hold the ENGINE START/STOP button for up to 15 seconds while pressing the brake pedal and manually start the engine. Have your vehicle checked by a dealer.

●

Comes on while driving - Turn the lights on manually and have your vehicle checked

by a dealer.

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

—

Continued

uuIndicatorsu

Instrument Panel

* Not available on all models

Indicator Name On/Blinking Explanation Message

●

Comes on when all the operating conditions of the auto high-beam are met.

●

Comes on if there is a problem with the auto high-beam.

2 Auto High-Beam (High Beam Support

System)

●

Manually operate the headlight switch.

●

If you are driving with the high-beam

P. 147

Auto High-Beam Indicator

(Green)

headlights when this happens, the

Auto High-Beam Indicator (Amber)

●

Comes on when the area around the camera on the windshield is blocked by dirt, mud, etc.

headlights are changed to low beams.

●

Stop your vehicle in a safe place, and wipe it off with a soft cloth.

●

If the indicator does not go off after cleaning the lens, have your vehicle checked by a dealer.

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

—

uuIndicatorsu

Instrument Panel

* Not available on all models

Indicator Name On/Blinking Explanation Message

●

Comes on for a few seconds when you turn the ignition switch to ON

, then goes off.

●

Comes on if there is a problem with

●

Stays on constantly - Have your vehicle checked by a dealer.

the RDM system.

●

Comes on when the RDM system shuts itself off.

●

Stays on - The temperature inside the camera is too high. Use the climate control system to cool

Road Departure Mitigation (RDM) Indicator

down the camera. The system activates when the temperature inside the camera cools down.

2 Front Sensor Camera* P. 445

●

Stays on - The area around the camera is blocked by dirt, mud, etc. Stop your vehicle in a safe place, and wipe it off with a soft cloth.

●

Have your vehicle checked by a dealer if the indicator and message come back on after you cleaned the area around the camera.

2 Front Sensor Camera* P. 445

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Continued

uuIndicatorsu

Instrument Panel

* Not available on all models

Indicator Name On/Blinking Explanation Message

Adaptive Cruise Control (ACC) Indicator (Amber)

●

Comes on for a few seconds when you turn the ignition switch to ON

, then goes off.

●

Comes on if there is a problem with ACC.

●

Comes on if anything covers the radar sensor cover and prevents the sensor from detecting a vehicle in front.

●

May come on when driving in bad weather (rain, snow, fog, etc.)

●

ACC has been automatically

●

Comes on while driving - Have your vehicle checked by a dealer.

●

When the radar sensor gets dirty, stop your vehicle in a safe place, and wipe off dirt using a soft cloth.

●

Have your vehicle checked by a dear if the indicator does not go off even after you clean the sensor cover.

canceled.

●

Adaptive Cruise Control (ACC) Indicator

(White)

Comes on when you press the MAIN button.

●

Comes on if the temperature inside the camera is too high.

●

ACC has been automatically canceled.

2 Adaptive Cruise Control (ACC)* P. 447

●

Use the climate control system to cool down the camera.

●

Goes off - The camera has been cooled down. Pressing the MAIN button can resume the system.

2 Front Sensor Camera* P. 445 2 Adaptive Cruise Control (ACC)

P. 447

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

—

uuIndicatorsu

Instrument Panel

* Not available on all models

Indicator Name On/Blinking Explanation Message

Lane Keeping Assist System (LKAS) Indicator (Amber)

Lane Keeping Assist System (LKAS) Indicator

(White)

●

Comes on for a few seconds when you turn the ignition switch to ON

, then goes off.

●

Comes on if there is a problem with the LKAS.

●

Comes on when you press the MAIN button.

●

Stays on constantly - Have your vehicle checked by a dealer.

2 Lane Keeping Assist System (LKAS)*

P. 464

—

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Continued

uuIndicatorsu

Instrument Panel

* Not available on all models

Indicator Name On/Blinking Explanation Message

Collision Mitigation Braking System (CMBSTM) Indicator

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

●

Comes on for a few seconds when you turn the ignition switch to ON

, then goes off.

●

Comes on when you deactivate the CMBS

. A multi-information

display message appears for five

●

Stays on constantly without the CMBSTM off - Have your vehicle checked by

a dealer.

2 Collision Mitigation Braking SystemTM

(CMBS

)* P. 483

seconds.

●

Comes on if there is a problem with the CMBSTM.

●

Comes on when the CMBSTM system shuts itself off.

●

Stays on - The area around the camera is blocked by dirt, mud, etc. Stop your vehicle in a safe place, and wipe it off with a soft cloth.

2 Front Sensor Camera* P. 445

●

When the radar sensor gets dirty, stop your vehicle in a safe place, and wipe off dirt using a soft cloth.

●

Have your vehicle checked by a dealer if the message does not disappear even after you clean the sensor cover.

2 Collision Mitigation Braking SystemTM

●

Stays on - The temperature inside the

(CMBS

)* P. 483

camera is too high. Use the climate control system to cool down the camera. The system activates when the temperature inside the camera cools down.

2 Front Sensor Camera* P. 445

uuIndicatorsuInformation Display Warning and Information Messages

Instrument Panel

* Not available on all models

Information Display Warning and Information Messages

The following messages appear only on the information display.

Message Condition Explanation

●

Appears when the fuel fill cap is loose or is not installed.

●

Appears when there is a problem with the sensor on the battery.

2 Check/Tighten Fuel Cap Message P. 575

●

Stays on constantly - Have your vehicle checked by a dealer.

Continued

uuIndicatorsuInformation Display Warning and Information Messages

Instrument Panel

Models with smart entry system

Automatic transmission/CVT models

U.S. manual transmission models

Canadian models

Message Condition Explanation

●

Appears if you push the ENGINE START/STOP button to turn the engine off without the shift lever in (P .

●

Appears when the power mode is in ACCESSORY.

●

Push the ENGINE START/STOP button twice after moving the shift lever to (P .

—

●

Appears when the steering wheel is locked.

●

Appears when you close the door with the power mode in ON without the smart entry remote inside the vehicle.

●

Appears when the smart entry remote’s battery becomes weak.

●

Move the steering wheel left and right while pressing the ENGINE START/STOP button at the same time.

●

Disappears when you bring the smart entry remote back inside the vehicle and close the door.

●

Replace the battery as soon as possible.

2 Replacing the Button Battery P. 549

uuIndicatorsuMulti-Information Display Warning and Information Messages

Instrument Panel

* Not available on all models

Multi-Information Display Warning and Information Messages

The following messages appear only on the multi-information display. Press the (information) button to see the message again with the system message indicator on.

Message Condition Explanation

●

Appears when the fuel fill cap is loose or is not installed.

2 Check/Tighten Fuel Cap Message P. 575

●

Appears when the scheduled maintenance is due soon.

u Consequently, Maintenance Due Now and

2 Maintenance Minder Messages on the Multi-

Information Display P. 510

Maintenance Past Due follow.

●

Appears when the engine coolant temperature gets abnormally high.

2 Overheating P. 572

●

Appears if there is a problem with the automatic lighting control system.

●

Appears while driving - Manually turn the lights on, and have your vehicle checked by a dealer.

●

Appears if there is a problem with the low beam headlights.

●

Appears while driving - The low beam headlights may not be on. When conditions allow you to drive safely, have your vehicle checked by a dealer as soon as possible.

Continued

uuIndicatorsuMulti-Information Display Warning and Information Messages

Instrument Panel

Models with auto high-beam

Models with parking sensor system

Canadian models

Message Condition Explanation

●

Appears if there is a problem with the auto highbeam.

●

Manually operate the headlight switch.

●

If you are driving with the high-beam headlights when this happens, the headlights are changed to low beams.

●

Appears when the area around the camera on the windshield is blocked by dirt, mud, etc.

●

Appears if there is a problem with the parking sensor system. The beeper sounds.

●

Appears when the washer fluid is low.

●

Stop your vehicle in a safe place, and wipe it off with a soft cloth.

●

If the message does not disappear after cleaning the lens, have your vehicle checked by a dealer.

●

Check if the area around the sensor(s) is covered with mud, ice, snow, etc. If the indicator(s) stays on even after you clean the area, have the system checked by a dealer.

●

Refill the washer fluid.

2 Refilling Window Washer Fluid P. 528

Instrument Panel

Models without smart entry system

uuIndicatorsuMulti-Information Display Warning and Information Messages

Message Condition Explanation

●

Appears when the ignition key is turned to ACCESSORY (q from ON (w. (The driver’s door is closed.)

—

●

Appears when you open the driver’s door while the ignition key is in ACCESSORY (q .

●

Appears when you open the driver’s door while the ignition key is in LOCK (0.

●

Turn the ignition switch to LOCK (0 , then remove the key.

●

Remove the key from the ignition switch.

Continued

uuIndicatorsuMulti-Information Display Warning and Information Messages

Instrument Panel

Models with smart entry system

U.S. manual transmission models

Canadian models

Message Condition Explanation

●

Appears after you unlock and open the driver’s door.

2 Starting the Engine P. 423

●

Appears when the steering wheel is locked.

●

Appears if you push the ENGINE START/STOP button to turn the engine off without the shift lever

(P.

●

Appears when the power mode is in ACCESSORY.

●

Move the steering wheel left and right while pressing the ENGINE START/STOP button.

●

Move the shift lever to (P . The power mode changes to VEHICLE OFF.

—

Instrument Panel

Models with smart entry system

uuIndicatorsuMulti-Information Display Warning and Information Messages

Message Condition Explanation

●

Appears after the driver’s door is opened when the power mode is in ACCESSORY.

●

Press the ENGINE START/STOP button twice with your foot off the brake pedal to change the power mode to VEHICLE OFF (LOCK).

●

Appears when you close the door with the power mode in ON without the smart entry remote inside the vehicle.

●

Appears when the smart entry remote battery becomes weak.

●

Appears if the smart entry remote battery is too weak to start the engine or the key is not within operating range to start the engine. A beeper sounds six times.

●

Appears three seconds after the To Start Engine: Brake + Push message appears.

●

Appears three seconds after you bring the smart entry remote in front of the ENGINE START/STOP button when To Start, Hold Remote Near Start Button appears. To Start Engine: Brake + Push appears sequentially.

●

Disappears when you bring the smart entry remote back inside the vehicle and close the door.

2 Smart Entry Remote Reminder P. 142

●

Replace the battery as soon as possible.

2 Replacing the Button Battery P. 549

●

Bring the smart entry remote in front of the ENGINE START/STOP button to be touched with.

2 If the Smart Entry Remote Battery is Weak P. 566

2 Changing the Power Mode P. 140

Continued

uuIndicatorsuMulti-Information Display Warning and Information Messages

Instrument Panel

* Not available on all models

Message Condition Explanation

●

Appears while you are customizing the settings and the shift lever is moved out of (P.

●

Appears when there is a problem with the sensor on the battery.

●

Appears when the battery is not charging.

●

Appears when the starter system has a problem.

2 Customized Features P. 103

●

Have your vehicle checked by a dealer.

2 Checking the Battery P. 548

●

Appears along with the battery charging system indicator - Turn off the climate control system and rear

defogger to reduce electricity consumption.

2 If the Charging System Indicator Comes On P. 574

●

As a temporary measure, press and hold the ENGINE START/STOP button for up to 15 seconds while

pressing the brake pedal and manually start the engine. Have your vehicle checked by a dealer.

●

Appears for about three seconds when ACC has been automatically canceled.

●

Flashes when the system senses a likely collision with a vehicle in front of you.

●

You can resume the set speed after the condition that caused ACC to cancel improves. Press the RES/+ button.

2 Adaptive Cruise Control (ACC)* P. 447

●

Take appropriate action to prevent a collision (apply the brakes, change lanes, etc.).

2 Adaptive Cruise Control (ACC)* P. 447 2 Collision Mitigation Braking System

P. 483

(CMBSTM)*

Instrument Panel

Lane Keeping Assist System (LKAS)

Road Departure Mitigation (RDM) System

When you selected Warning Only

When you selected Normal or Wide

* Not available on all models

uuIndicatorsuMulti-Information Display Warning and Information Messages

Message Condition Explanation

●

Appears when the area around the camera is blocked by dirt, mud, etc. Stop your vehicle in a safe place, and wipe it off with a soft cloth.

●

May appear when driving in bad weather (rain,

●

Have your vehicle checked by a dealer if the message appears again after you cleaned the area around the camera.

snow, fog, etc.).

●

Appears if the temperature inside the camera is too high.

●

ACC/LKAS has been automatically canceled.

●

Appears when the vehicle is driving out of a detected line. The steering wheel vibrates rapidly.

●

Appears when the vehicle is driving out of a detected line.

- The steering wheel vibrates rapidly when the vehicle is drifting out of a detected line.

- The steering wheel vibrates rapidly when the

●

Use the climate control system to cool down the camera.

●

Goes off - The camera has been cooled down. Pressing the MAIN/LKAS button can resume the system.

2 Front Sensor Camera* P. 445 2 Adaptive Cruise Control (ACC) 2 Lane Keeping Assist System (LKAS)

●

Keep the vehicle within the lane you are driving.

●

The color of either line changes from white to amber as the vehicle gets closer to that side of the lane line.

2 Lane Keeping Assist System (LKAS)* P. 464

●

Keep the vehicle within the lane you are driving.

●

The color of either line changes from white to amber as the vehicle gets closer to that side of the lane line.

2 Road Departure Mitigation (RDM) System* P. 460

●

You can change the setting for the road departure mitigation system. Normal, Wide, and Warning Only can be selected.

2 Customized Features P. 103, 298, 316

vehicle is drifting out of a detected line. The system also steers the vehicle to help you remain within your driving lane.

P. 447

P. 464

Continued

uuIndicatorsuMulti-Information Display Warning and Information Messages

Instrument Panel

Models with remote engine starter

* Not available on all models

Message Condition Explanation

●

Blinks when you fail to steer the vehicle. The beeper sounds simultaneously.

●

Appears when the LKAS is in operation, or the LKAS button is pressed, but there is a problem with a system related to the LKAS. The LKAS cancels automatically. The beeper sounds simultaneously.

Message Condition Explanation

●

Appears when you unlock and open the driver’s door while the engine is running by smart entry remote.

●

Operate the steering wheel to resume the LKAS.

●

If any other system indicators come on, such as the VSA®, ABS and brake system, take appropriate action.

2 Indicators P. 68

2 Remote Engine Start* P. 425

Instrument Panel

1Fuel Gauge

NOTICE

You should refuel when the reading approaches . Running out of fuel can cause the engine to misfire, damaging the catalytic converter.

The actual amount of remaining fuel may differ from the fuel gauge reading.

1Temperature Gauge

NOTICE

Driving with the temperature gauge pointer in the upper zone can cause serious engine damage. Pull safely to the side of the road and allow engine temperature to return to normal.

2 Overheating P. 572

Gauges and Displays

Gauges

Gauges include the speedometer, tachometer, fuel gauge, and related indicators. They are displayed when the ignition switch is in ON (w*1.

Speedometer

■

Displays your driving speed in mph (U.S.) or km/h (Canada).

Tachometer

■

Shows the number of engine revolutions per minute.

Fuel Gauge

■

Displays the amount of fuel left in the fuel tank.

Temperature Gauge

■

Displays the temperature of the engine coolant.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

uuGauges and DisplaysuInformation Display

Instrument Panel

1Switching the Display

Each time you press the knob, the information display changes as follows:

Some of the items on the information display also appear on the audio/information screen. They also change along with the information display changes while the fuel consumption is shown.

Instant Fuel Economy, Odometer, Trip Meter A, Outside Temperature

Instant Fuel Economy, Range, Trip Meter A, Outside Temperature

Engine Oil Life

Instant Fuel Economy, Average Fuel Economy A, Trip Meter A, Outside Temperature

Instant Fuel Economy, Average Fuel Economy B, Trip Meter B, Outside Temperature

Select/Reset Knob

* Not available on all models

Information Display

The information display shows the odometer, trip meter, engine oil life and maintenance service item codes, and other gauges.

Switching the Display

■

Press the (Select/Reset) knob to change the display.

Instrument Panel

1Trip Meter

Switch between trip meter A and trip meter B by pressing the knob.

1Average Fuel Economy

You can change when to reset the average fuel economy.

2 Customized Features P. 298, 316

Odometer

■

Shows the total number of miles (U.S.) or kilometers (Canada) that your vehicle has accumulated.

Trip Meter

■

Shows the total number of miles (U.S.) or kilometers (Canada) driven since the last reset. Meters A and B can be used to measure two separate trips.

■ Resetting a trip meter

To reset a trip meter, display it, then press and hold the knob. The trip meter is reset to 0.0.

Average Fuel Economy

■

Shows the estimated average fuel economy of each trip meter in mpg (U.S.) or l/100 km (Canada). The display is updated at set intervals. When a trip meter is reset, the average fuel economy is also reset.

Instant Fuel Economy

■

Shows the instant fuel economy as a bar graph in mpg (U.S.) or l/100 km (Canada).

uuGauges and DisplaysuInformation Display

Engine Oil Life

■

Shows the remaining oil life and Maintenance Minder

2 Maintenance MinderTM P. 505

Continued

uuGauges and DisplaysuInformation Display

Instrument Panel

1Outside Temperature

The temperature sensor is in the front bumper. Road heat and exhaust from another vehicle can affect the temperature reading when your vehicle speed is less than 19 mph (30 km/h).

It may take several minutes for the display to be updated after the temperature reading has stabilized.

Outside Temperature

■

Shows the outside temperature in Fahrenheit (U.S.) or Celsius (Canada).

■ Adjusting the outside temperature indicator

Adjust the temperature reading up to ± 5°F or ± 3°C if the temperature reading seems incorrect.

1. Turn the ignition switch to ON

2. Press and hold the (Select/Reset) knob for 10 seconds or more while the

outside temperature is shown on the information display.

u The information display goes into temperature adjustment mode. The display

starts showing from -5°F to +5°F (U.S.) or -3°C to +3°C (Canada).

3. Release the knob when the right adjustment amount is shown.

u The adjustment is complete.

Range

■

Shows the estimated distance you can travel on the remaining fuel. This distance is estimated from the fuel economy of your previous trips.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

uuGauges and DisplaysuMulti-Information Display

Instrument Panel

Average Fuel Economy/ Instant Fuel Economy

Range Elapsed Time Average Speed

Blank Screen Vehicle Settings Engine Oil Life

Button

* Not available on all models

Multi-Information Display

The multi-information display shows the odometer, trip meter, outside temperature indicator, and other gauges. It also displays important messages such as warnings and other helpful information.

Switching the Display

■

■ Main displays

Press the (information) button to change the display.

Continued

Honda Accord 2016 Owners Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

A Few Words About Safety

Contents

Quick Reference Guide

Visual Index

Eco Assist System (P 441)

Safe Driving (P 27)

Instrument Panel (P 67)

Controls (P 113)

Features (P 185)

Driving (P 411)

Maintenance (P 501)

Handling the Unexpected (P 557)

What to Do If

Safe Driving

Instrument Panel
