RECOMMENDED RETAIL PRICE
g
W/O TAX * EXW DUISBURG / PARIS
CSP 3314 CHAIN SAW UT 74121-D
starter - i
Position Article-no Description Qty Price w/o tax
1 BM_984881001 STARTER HOUSING ASSEMBLY 1 € 15,35
2 BM_UP04092 SPRING & CONTAINER 1 € 7,84
3 BM_PS03117 STARTER PULLEY 1 € 1,65
4 BM_UP04237 SCREW, THREAD FORM, PLASTITE (10-14 X 5/8 IN.) 1 € 1,03
5 BM_UP04089 WASHER RETAINING 1 € 2,47
6 BM_PS06114 GRIP STARTER 1 € 1,18
7 BM_UP03911 STARTER ROPE (46 IN.) 1 € 3,96
8 BM_UP04192 BAFFLE, FAN HOUSING 1 € 4,50
9 BM_UP05850A ROTOR & STARTER PAWL 1 € 16,56
10 BM_984882001 IGNITION KIT (33 CC) 1 € 29,15
11 BM_UP04086 SCREW, THREAD FORM (8-32 X 5/8 IN.) 2 € 4,14
12 BM_UP04825 SPARK PLUG 1 € 5,69
13 BM_UP04222 IGNITION SWITCH HARNESS 1 € 3,00
14 BM_UP04215 GROMMET, WIRE HARNESS (SPLIT) 1 € 0,46
15 BM_UP04241 WASHER, FLAT 1 € 1,21
16 BM_UP04081 JAM NUT 1 € 0,52
17 BM_UP04236 SCREW, TRUSS HD. PLASTITE (10-14 X 7/8 IN.) 2 € 1,03
18 BM_UP04237 SCREW, TRUSS HD. PLASTITE (10-14 X 5/8 IN.) 2 € 1,03
nition
engine internal - oil pump
Position Article-no Description Qty Price w/o tax
1 BM_04932 PISTON PIN 1 € 5,00
2 BM_A08666A CYLINDER MACH/PLATED 1 € 30,95
3 BM_A04935 33CC PISTON (MACH) 1 € 33,72
4 BM_UP04177 PISTON RING 1 € 1,82
5 BM_UP04051 RETAINING RING 2 € 0,44
6 BM_UP04083 SCREW TORX PLUS CAP-SOCKET HD 4 € 5,33
7 BM_PS04989 SCREW, (8/32 X 5/8 IN. PAN HD TORX) 2 € 0,14
8 BM_PA00979 33 CC CRANKSHAFT ASSEMBLY 1 € 72,79
9 BM_UP04174 NEEDLE BEARING 1 € 2,90
10 BM_UP04047 SHAFT SEAL 2 € 4,03
11 BM_08838 BALL BEARING 2 € 2,58
12 BM_UP04046 BEARING CASE 2 € 2,25
13 BM_UP04087 FLAT WASHER 4 € 2,25
14 BM_UP04825 SPARK PLUG 1 € 5,69
15 BM_UP04172 CRANKCASE (33CC) CS 1 € 19,44
16 BM_PA01396 OIL PUMP ASSEMBLY 1 € 9,11
17 BM_UP04185 GROMMET, OIL OUTLET 1 € 1,87
18 BM_UP04188 LEFT HAND WORM 1 € 1,82
19 BM_PA01037 OIL INTAKE TUBE W/FILTER 1 € 1,20
carburetor - muffler - air filter
Position Article-no Description Qty Price w/o tax
1 BM_A07402 MUFFLER 1 € 13,99
2 BM_UP04183 MUFFLER GASKET 1 € 0,67
3 BM_PS04525 SCREW–SQUARE HD. 3 € 1,70
4 BM_UP04059 NUT–LOCKING HEX (10–32) 3 € 0,43
5 BM_UP04203 SCREEN, SPARK 1 € 3,68
6 BM_UP04204 DEFLECTOR, MUFFLER 1 € 5,06
7 BM_UP04244 SCREW (8-32 X .312) 1 € 0,75
15.02.2005 1 / 3 RYOBI SERVICE DEPT.
Position Article-no Description Qty Price w/o tax
8 BM_984891001 CARBURETOR 1 € 37,00
9 BM_UP04094 CARBURETOR GASKET 1 € 2,25
10 BM_07589 FLANGE NUT (10-24) 2 € 0,66
11 BM_UP04218 THROTTLE CABLE 1 € 5,16
12 BM_UP04184 GASKET, HEAT DAM 1 € 0,71
13 BM_UP04173 HEAT DAM 1 € 9,74
14 BM_UP04191 SEAL, HEAT DAM 1 € 1,03
15 BM_UP04084 SCREW, TRUSS HD. (10-24 X 7/8 IN.) 2 € 0,21
16 BM_UP04189 SCREW, CARBURETOR 2 € 0,43
17 BM_07454 FUEL LINE (TANK TO CARB. 8-1/2 IN.) 1 TBO
18 BM_07454 FUEL LINE (CARB. TO PURGE BULB. 8 IN.) 1 TBO
19 BM_UP04171
20 BM_UP04533 AIR FILTER COVER 1 € 5,91
21 BM_PS05070 PRE FILTER (IN ENGINE HOUSING) 1 € 0,15
22 BM_UP04235 SCREW, SLOTTED PAN HD. (8-16 X 5/8 IN.) 2 € 0,66
23 BM_PS06280 ROD, CHOKE 1 € 1,00
24 BM_UP04178 AIR FILTER PLATE 1 € 4,31
25 BM_UP04227 SPRING CLIP (CHOKE ROD) 1 € 0,66
26 BM_UP04825 SPARK PLUG 1 € 5,69
27 BM_PA01396 OIL PUMP ASSEMBLY 1 € 9,11
28 BM_PA01037 OIL INTAKE W/FILTER 1 € 1,20
29 BM_UP03897 SCREW, THD. FORMING (10 -14 X .5) 1 € 0,07
30 BM_UP03867 WASHER, RETAINING 1 € 2,25
CARBURETOR GROMMET
1 € 3,03
engine housing - fuel tank - oil tank
Position Article-no Description Qty Price w/o tax
1 BM_06875 CYLINDER COVER 1 € 14,43
2 BM_UP04219 SCREW-SLOTTED PAN HEAD 3 € 0,43
3 BM_PS03503 CONTROL PANEL 1 € 0,40
4 BM_PS06280 CHOKE ROD 1 € 1,00
5 BM_UP04218 THROTTLE CABLE 1 € 5,16
6 BM_UP04197 ROCKER SWITCH 1 € 2,29
7 BM_UP04215 SPLIT GROMMET 2 € 0,46
8 BM_UP04033 PRIMER BULB 1 € 3,60
9 BM_07454 RUBBER TUBING (5-1/2 IN.) 1 TBO
10 BM_985029 CHASSIS ASSEMBLY 1 € 61,00
11 N/A FILTER ELEMENT (BRONZE) 2
12 N/A DUCK BILL VALVE 2
13 N/A OIL OUTLET GROMMET 1
14 BM_PA01037 OIL INTAKE TUBE, W/FILTER 1 € 1,20
15 BM_07454 RUBBER TUBING 8-1/2 IN.) 1 TBO
16 BM_PS03380 FUEL FILTER 1 € 0,70
17 N/A FUEL CAP, W/RETAINER 1
18 N/A OIL CAP, W/RETAINER 1
X N/A GUIDE BAR BOLT (NOT SHOWN) 2
19 N/A OIL FILTER 1
20 BM_UP04221 SPEED NUT (U-TYPE) 3 € 0,66
21 BM_UP04083 SCREW, (10-24 X 2 IN.) 4 € 5,33
22 BM_UP04087 WASHER 4 € 2,25
23 BM_PS05070 PRE FILTER 1 € 0,15
24 BM_UP04215 SPLIT GROMMET 1 € 0,46
25 BM_UP04052 GROMMET 1 € 2,47
clutch - chain brake - drive case cover
Position Article-no Description Qty Price w/o tax
1 BM_PS04726 HAND GUARD 1 € 6,10
2 BM_07580 HAND GUARD ACTUATING PIN 1 € 0,93
3 BM_UP04056 RETAINING RING 1 € 0,51
15.02.2005 2 / 3 RYOBI SERVICE DEPT.
Position Article-no Description Qty Price w/o tax
4 BM_UP04056 HANDGUARD SPRING 1 € 0,51
5 BM_UP04202 PIVOT, L.H. 1 € 2,06
6 BM_UP04201 PIVOT, R.H. 1 € 2,06
7 BM_UP04240 SCREW (8-32 X 5/8 IN.) 1 € 0,66
8 N/A GUIDE BAR BOLT [ ENGINE HOUSING ... CHASSIS ASSEMBLY ... ] 2
9 BM_UP04206 GUIDE BAR PLATE 1 € 1,18
10 BM_UP04085 GUIDE BAR PLATE 1 € 1,18
11 BM_UP04082 SCREW (6-19 X 1/2 IN.) 1 € 2,25
12 BM_985030001 BRAKE BAND 1 € 1,95
13 BM_UP04181 ROLL PIN 1 € 1,87
14 BM_985021001 CHAIN BRAKE COVER 1 € 0,40
15 BM_UP08000A ADJUSTING PIN 1 € 3,85
16 BM_UP04239 SCREW (8-19 X .320) 3 € 0,50
17 BM_984897001 CHAIN BRAKE LINK 1 € 9,15
18 BM_UP04090 ROLL PIN 1 € 2,44
19 BM_UP04182 THRUST WASHER 1 € 1,69
20 BM_984898001 CLUTCH & HARDWARE 1 € 17,60
21 BM_984350001 DRUM SPROCKET (.375 PITCH) 1 € 7,45
22 BM_PS04669 NEEDLE BEARING 1 € 5,05
23 BM_UP04228 RETAINING RING 1 € 0,16
24 BM_UP04179 CUPPED WASHER 1 € 1,03
25 BM_PA01106 DRIVE CASE COVER ASSEMBLY 1 € 3,50
26 BM_PS02928 CHAIN CATCHER 1 € 0,41
27 BM_UP03897 SCREW (10-24 X 1/2 IN.) 1 € 0,07
28 BM_UP04058 HEX NUT 2 € 2,47
29 BM_985240001 COMPRESSION SPRING 1 € 0,80
handles
Position Article-no Description Qty Price w/o tax
1 BM_06870 REAR HANDLE 1 € 4,20
2 BM_UP04234 SCREW (12-14 X 1-1/2 IN.) 2 € 0,84
3 BM_984354002 THROTTLE TRIGGER 1 € 1,00
4 BM_PS06283 THROTTLE LOCK OUT 1 € 0,95
5 BM_06871 HANDLE COVER 1 € 1,56
6 BM_UP03900 SCREW (10-14 X 3/4 IN.) 2 € 2,25
7 BM_PS06281 THROTTLE PIN LOCK 1 € 0,25
8 BM_UP04238 SCREW (10-14 X 1- 3/8 IN.) 1 € 1,13
9 BM_08898 SPRING 1 € 0,75
10 BM_UP04050 E-RING 1 € 0,25
11 BM_PS03985 FRONT HANDLE 1 € 3,25
12 BM_07384 ISOLATOR PLATE 1 € 0,35
13 BM_UP04237 SCREW (10-14 X 5/8 IN.) 3 € 1,03
14 BM_UP04233 SCREW (10-24 X 5/8 IN.) 1 € 0,66
15 BM_UP04200 LIMITER, ISOLATOR 1 € 1,87
16 BM_UP03897 SCREW (10-14 X 1/2 IN.) 3 € 0,07
17 BM_UP04218 THROTTLE CABLE 1 € 5,16
18 BM_PS05217 EXTENSION SPRING 2 € 4,72
19 BM_PS05199 UPPER ISOLATION SPRING 1 € 0,30
CSP 3314 < ACCESSORIES >
Position Article-no Description Qty Price w/o tax
BM_09207 UNIVERSAL WRENCH COMBINATION 1 € 7,35
BM_UP06563 SCABBARD [ 4206103 ] 1 € 8,00
AB_080006 GUIDE BAR 14" (35CM) 1 € 38,50
AB_080011 CHAIN 14" (35CM / 3/8") 1 € 20,50
PRICES ARE SUBJECT TO CHANGE WITHOUT NOTICE
RQ* ... ON REQUEST NLA* ... NO LONGER AVAILABLE TBO* ... TO BE OBSOLETE
15.02.2005 3 / 3 RYOBI SERVICE DEPT.
