Holux UB-93 SPECIFICATION

GPS Engine Board

UB-93
SPECIFICATION

1F, No. 30, R&D Rd. II, HsinChu City 300, Science-based Industrial Park, Taiwan

(300) 新竹市科學園區研發二路 30 號 1 樓

TEL: [phone] FAX: [phone]

Website: www.holux.com

Version : 0.4

All Right Reserved

UB-93

GPS Module series THE PRO NAME IN GPS

Version Change History

Version Date Revised Reason

0.1 2009/04/02 Draft release

HOLUX Technology , Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw

2

UB-93

GPS Module series THE PRO NAME IN GPS

Index

1. Introduction.............................................................................................4

1.1 General introductions..............................................................................4

1.2 Key Features.............................................................................................4

1.3 Applications..............................................................................................4

2 Technical Description.............................................................................5

2.1 Block Diagram..........................................................................................5

2.2 Configuration ..................................................... 錯誤! 尚未定義書籤。

2.3 Pin Definition............................................................................................5

2.4 Specification..............................................................................................7

3. Mechanical Dimension ..............................................................................8

3.1 Mechanical Dimension.............................................................................8

4. Package ......................................................................................................9

4.1 Packing.......................................................................................................9

4.2 Reference Product Photo........................................................................10

5. User Interface........................................................................................10

5.1 NMEA Protocol.......................................................................................10

5.2 NMEA Protocol format .........................................................................10

5.3 MTK NMEA Packet Format..................................................................11

6. Reference design..................................................................................12

6.1 Reference circuit .....................................................................................12

6.2 Reference PCB pattern...........................................................................12

6.3 Recommendation reflow profile ...........................................................13

HOLUX Technology , Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw

3

UB-93

GPS Module series THE PRO NAME IN GPS

1. Introduction

1.1 General introductions
UB-93 is an ultra miniature 17 * 22.4 * 3 mm GPS engine board designed by low

power consumption MTK GPS solution. It provides superior sensitivity up to

-159dBm and fast Time-To-First-Fix in navigation application. The stable
performance of UB-93 is your best choice to be embedded in your portable device
design, like PDA、PND、mobile phone、Digital Camera for GPS service.

1.2 Key Features
‧ small form factor:17* 22.4 * 3 mm
‧ RoHS/WEEE compliant
‧ High sensitivity -159dBm
‧ Searching up to 32 Channel of satellites
‧ Fast Position Fix
‧ Low power consumption
‧ RTCM-in ready.
‧ Built-in WAAS/EGNOS/MSAS Demodulator .
‧ Support NMEA0183 V 3.01 data protocol.
‧ Real time navigation for location based services.
‧ For Car Navigation, Marine Navigation, Fleet Management, AVL and

Location-Based Services, Auto Pilot, Personal Navigation or touring devices,
Tracking devices/systems and Mapping devices application

1.3 Applications

‧ Automotive and Marine Navigation
‧ Automotive Navigator Tracking
‧ Emergency Locator
‧ Geographic Surveying
‧ Personal Positioning
‧ Sporting and Recreation
‧ Embedded applications:
‧ Smart phone, UMPC, PND, MP4

HOLUX Technology , Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw

4

UB-93

GPS Module series THE PRO NAME IN GPS

2 Technical Description

2.1 Block Diagram

2.2 Pin Definition

HOLUX Technology , Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw

5

UB-93

GPS Module series THE PRO NAME IN GPS

Pin Pin Name Type Function description

1
2
3
4
5
6
7
8

9
10
11
12
13
14
15
16

TX1
RX1
TX0
RX0

VCC_IN_3V3

GND

RESET

V_BA T_3V3

GND
GND
GND

GPS_RF_IN

NC

NC
NC

NC

O Serial Data Output

I Serial Data Input

O Serial Data Output

I Serial Data Input

NC NC

I 3.3 ~ 5 VDC Power Input

G Ground
NC NC
NC NC

I System Reset,Active Low
I RTC and backup SRAM ,Power Input: 3.3~ 5 VDC

NC NC

G Ground

G Ground

G Ground

I GPS signal input(DC:2.85V output)

17
18
19
20
21
22
23
24
25
26
27
28

GND

VCC_RF

V_ANT

NC
NC
NC
NC
NC
NC
NC
NC

1PPS

G Ground
O Output Voltage RF section

I Antenna Biavoltage

NC NC
NC NC
NC NC
NC NC
NC NC
NC NC
NC NC
NC NC

O 1 PPS output

HOLUX Technology , Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw

6

UB-93

GPS Module series THE PRO NAME IN GPS

2.3 Specification

General

GPS technology MTK GPS chipset MT3318

Frequency L1,1575.42MHZ

C/A Code 1.023MHZ chip rate

Channels 32 channels all in view searching

Sensitivity Better than -159dBm

Receiver Accuracy

Position

Velocity Without aid:0.1 M/sec

Time

Datum

Datum WGS84(Default) total 219 datum’s

Time to First Fix

Hot start 1 sec. average

Warm start 33 sec. average

(Follow MTK chip specification)
Without aid:3.0 M 2D-RMS
DGPS(WAAS, EGNOS, MSAS, RTCM):2.5 M

0.1μs. Sync GPS time

(Follow MTK chip specification)

Cold start 36 sec. average

Reacquisition

Protocol

＜1sec.

NMEA0183(V3.01)- GGA,GLL,GSA,GSV,RMC,VTG

GPS Output Data

Support Baud rate 4800/9600/…./115200 bps (default 4800),
Data bit:8 , Stop bit:1, No parity.

Update Rata

1Hz(default)

Protocol Support NMEA-0183

1PPS
Limitations

Acceleration Limit
Altitude Limit
Velocity Limit

Enable(1Hz pulse 10% duty cycle)
(Follow MTK chip specification)

＜4G
＜18000 meters
＜515 M/sec

Jerk Limit 20 M/sec

Power

Operation Current

Acquisition:≒60 mA@3.3V

3

Operation Current

HOLUX Technology , Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw

Tracking:≒＜45mA@3.3V

7

UB-93

GPS Module series THE PRO NAME IN GPS

VCC_IN: 3.3~5.0V

DC Input Range

V_RTC:3.3~5.0V

Processing Core

Processor Type ARM7EJ-S
Processor Speeds

Interface
Temperature

Operating Temperature

Storage Temperature

Operating Humidity

Physical

Dimension

Weight

48 MHz
CMOS 2.85 V Level

-40 to +85 .

-40 to +125 .

5% to 95%, Non condensing

17 * 22.4 * 3 mm.
<1g.

3. Mechanical Dimension

3.1 Mechanical Dimension

(Unit : mm)

HOLUX Technology , Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw

8

UB-93

GPS Module series THE PRO NAME IN GPS

4. Package

4.1 Packing

HOLUX Technology , Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw

9

UB-93

GPS Module series THE PRO NAME IN GPS

4.2 Reference Product Photo

The photo is for reference, the real content will depend on the real configuration.
Top side :

Bottom side : (The PCB version depend)

5. User Interface

UB-93 provides 2-wire digital UART port for communication of GPS position data

using NMEA protocol or MTK extension protocol. UART port is capable of 4800 to
115200 baud rate.

5.1 NMEA Protocol

UB-93 is default to support standard NMEA-0183 protocol. In addition, a series of

MTK extensions (PMTK messages) have been developed that can be used to provide
extended capabilities common to many applications.

NMEA Protocol format

UB-93 is capable of supporting following NMEA formats:

NMEA RECORD Description

GGA GPS fix data

HOLUX Technology , Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw

10

UB-93

GPS Module series THE PRO NAME IN GPS

GLL Geographic

GSA GNSS DOP and active satellite

GSV GNSS Satellites in view

RMC Recommended minimum specific GNSS data

VTG Course Over Ground and Ground Speed

ZDA Time & Data

5.3 MTK NMEA Packet Format
Preamble TalkerID PktType Datafield * CHK1 CHK2 CR LF

Maximum packet length is restricted to 255 bytes

Field Length Type D

Preamble 1 byte Character

TalkerID 4 byte Character string

PktType 3 byte Character string

DataField Variable

* 1 byte Character

CHK1

2 byte Character string

CHK2

“$＂

“PMTK＂

“000＂to “999＂, an identifier

used to tell the decoder how to
decode the packet

“, ＂must be inserted ahead
each data filed to help the decoder
process the Data Field

The star symbol is used to mark

the end of Data Field

checksum of the data between
Preamble “, ＂and “*＂

CR, LF 2 byte Binary data

used to identify the end of a
packet

HOLUX Technology , Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw

11

UB-93

GPS Module series THE PRO NAME IN GPS

6. Reference design

6.1 Reference circuit

Fig 1 is UB-93 uses patch Antenna connects to RS-232 transceiver solutions

intended for portable or hand-held applications.
Fig 1

6.2 Reference PCB pattern

HOLUX Technology , Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw

12

UB-93

GPS Module series THE PRO NAME IN GPS

6.3 Recommendation reflow profile

1. We strongly recommend that this module should be designed to mount on top

side of motherboard with main chip together which process the final reflow.

2. The maximum frequency of this module to pass reflow process should be no

HOLUX Technology , Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw

13

UB-93

GPS Module series THE PRO NAME IN GPS

more than twice, including repair operation, otherwise it may cause side
effect to the performance.

3. Below is the recommend reflow profile referred to Main MTK chipSet.
