GPS Engine Board
M-9329
SPECIFICATION
No.1-1, Innovation Rd.1, HsinChu City 300, Science-based Industrial Park, Taiwan
(300) 新竹市科學園區創新一路 1-1 號
TEL: 03-6687000 FAX: 03-6687111
Website: www.holux.com
All Right Reserved
GPS Engine Board M-9329
Version Update History
Version
0.1 2010/07/09 Draft release
Date Revised Reason
- i -
Table of Content
1. Introduction.............................................................................................1
1.1 General introductions .......................................................................1
1.2 Key Features......................................................................................1
1.3 Applications....................................................................................... 1
2 Technical Description.............................................................................2
2.1 Block Diagram ...................................................................................2
2.2 Pin Definition .....................................................................................2
2.3 Specification ......................................................................................4
3 Mechanical Dimension ...........................................................................6
3.1 Mechanical Dimension...................................................................... 6
4 Package ...................................................................................................7
4.1 Packing .............................................................................................. 7
4.2 Reference Product Photo.................................................................8
5. User Interface..........................................................................................9
5.1 NMEA Protocol..................................................................................9
5.2 NMEA Protocol format......................................................................9
5.3 MTK NMEA Packet Format............................................................. 10
6. Reference Design ................................................................................. 11
6.1 Reference circuit............................................................................. 11
6.2 Reference PCB pattern................................................................... 12
6.3 Recommendation reflow profile.....................................................13
- ii -
GPS Engine Board M-9329
1. Introduction
1.1 General introductions
M-9329 is an ultra miniature 13.1 * 15.9 * 2.2 mm GPS engine board
designed by low power consumption MTK GPS solution. It provides
superior sensitivity up to -165dBm and fast Time-To-First-Fix in navigation
application. The stable performance of M-9329 is your best choice to be
embedded in your portable device design, like PDA、PND、mobile phone、
Digital Camera for GPS service.
1.2 Key Features
‧ small form factor:13.1* 15.9 * 2.2 mm
‧ RoHS/WEEE compliant
‧ High sensitivity -165dBm(Tracking , Accroding to MTK chip spec)
‧ Up to 66 parallel searching,22 tracking channels
‧ Fast Position Fix
‧ Low power consumption
‧ RTCM-in ready.
‧ Built-in WAAS/EGNOS/MSAS Demodulator.
‧ Support NMEA0183 V 3.01 data protocol.
‧ Real time navigation for location based services.
‧ For Car Navigation, Marine Navigation, Fleet Management, AVL and
Location-Based Services, Auto Pilot, Personal Navigation or touring
devices, Tracking devices/systems and Mapping devices application
1.3 Applications
‧ Automotive and Marine Navigation
‧ Automotive Navigator Tracking
‧ Emergency Locator
‧ Geographic Surveying
‧ Personal Positioning
‧ Sporting and Recreation
‧ Embedded applications: Smart phone, UMPC, PND, MP4
- 1 -
GPS Engine Board M-9329
19 11
P12 P13 P14 P15 P16 P17 P18
P36 P35 P34 P33 P32 P31 P30
P18 P17 P16 P15 P14
P13 P12
P30 P31 P32 P33 P34 P35 P36
2 Technical Description
2.1 Block Diagram
2.2 Pin Definition
P1
P2
P3
P4
P5
P6
P7
P8
P9
P10
P11
Top view Button view
P29
P28
P27
P26
P25
P24
P23
P22
P21
P20
P19
P29
P28
P27
P26
P25
P24
P23
P22
P21
P20
P19
30
M-93_VA1_100813
P1
P2
P3
P4
P5
P6
P7
P8
P9
P10
P11
Pin Pin Name Type
1
2
GPS_RF_IN
GND
Function description
I GPS signal input(DC:2.8V output)
G Ground
- 2 -
GPS Engine Board M-9329
when this pin is low
3
4
5
V_BAT_3V3
6
7
8
9
10
11
VCC_IN_3V3
12
13
RESET
14
15
16
17
GPIO3
GND
GND
GND
NC
GND
GND
GND
GND
GND
GND
GND
G Ground
G Ground
I RTC and backup SRAM , DC Input:2.8~4.2V.
NC: provide the power by module internal VCC.
G Ground
NC NC
G Ground
G Ground
G Ground
I 3.3 ~ 4.2 VDC Power Input
G Ground
I System Reset ,Active Low
G Ground
G Ground
I General purpose I/O
G Ground
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
GPIO1
GND
1PPS
GND
GND
GND
GND
GPIO2
GND
WAKE_UP
GND
GND
TX0
RX0
RX1
GND
I/O General purpose I/O
G Ground
O 1 PPS output pulse width 100 ms, edge tolerance is +/- 50ns.
G Ground
G Ground
G Ground
G Ground
I/O General purpose I/O
G Ground
I NC,Option,the module will go to standby mode
G Ground
G Ground
O Serial Data Output
I Serial Data Input
I Serial Data Input
G Ground
34
35
36
TX1
GND
GND
O Serial Data Output
G Ground
G Ground
- 3 -
GPS Engine Board M-9329
2.3 Specification
General
GPS technology
Frequency
C/A Code
Channels
Sensitivity
Receiver Accuracy
Position
Velocity
Time
Datum
Datum
Time to First Fix
Hot start
Warm start
(Follow MTK chip specification)
MTK GPS chipset MT3329
L1,1575.42MHZ
1.023MHZ chip rate
66 parallel searching,22 tracking channels
- 165 dBm (Tracking)
(Follow MTK chip specification)
Without aid:3.0 M 2D-RMS
DGPS(WAAS, EGNOS, MSAS, RTCM):2.5 M
Without aid:0.1 M/sec
0.1µs. Sync GPS time
WGS84(Default) total 219 datum’s
(Follow MTK chip specification)
< 1 sec.
< 33 sec.
Cold start
Reacquisition
Protocol
GPS Output Data
Update Rata
Protocol Support
1PPS
Limitations
Acceleration Limit
Altitude Limit
Velocity Limit
Jerk Limit
Power
< 35 sec.
＜1sec.
NMEA0183(V3.01)GGA,GLL,GSA,GSV,RMC,VTG
Support Baud rate 4800/9600/…./115200 bps
(default 4800), Data bit:8 , Stop bit:1, No parity.
1Hz(default)
NMEA-0183
Enable(1Hz pulse 10% duty cycle)
(Follow MTK chip specification)
＜4G
＜18000 meters
＜515 M/sec
20 M/sec3
Operation Current
Operation Current
Acquisition:≒42 mA@3.3V
Tracking:≒＜36 mA@3.3V
- 4 -
GPS Engine Board M-9329
VCC_IN_3V3: 3.3~4.2V
DC Input Range
V_BAT_3V3:
2.0~4.2V
Processing Core
Processor Type
Processor Speeds
Interface
Temperature
Operating Temperature
Storage Temperature
Operating Humidity
Physical
Dimension
Weight
ARM7EJ-S
48 MHz
CMOS 2.8 V Level
-30 to +80 .
-40 to +85 .
5% to 95%, Non condensing
13.1 * 15.9 * 2.2 mm.
<1g.
- 5 -
GPS Engine Board M-9329
3 Mechanical Dimension
3.1 Mechanical Dimension
TOP VIEW
- 6 -
GPS Engine Board M-9329
4 Package
4.1 Packing
Tray dimension: 325*220*9 mm, Standard Content Qty: 100 pcs.
Carton dimension: 340*235*120 mm, Standard Content Qty: 2,000 pcs.
- 7 -
GPS Engine Board M-9329
4.2 Reference Product Photo
The photo is for reference, the real content will depend on the real
configuration.
Top side:
Bottom side: (The PCB version depend)
- 8 -
GPS Engine Board M-9329
5. User Interface
M-9329 provides 2-wire digital UART port for communication of GPS position
data using NMEA protocol or MTK extension protocol. UART port is capable of
4800 to 115200 baud rate.
5.1 NMEA Protocol
M-9329 is default to support standard NMEA-0183 protocol. In addition, a
series of MTK extensions (PMTK messages) have been developed that can
be used to provide extended capabilities common to many applications.
5.2 NMEA Protocol format
M-9329 is capable of supporting following NMEA formats:
NMEA RECORD Description
GGA GPS fix data
GLL Geographic
GSA GNSS DOP and active satellite
GSV GNSS Satellites in view
RMC Recommended minimum specific GNSS data
VTG Course Over Ground and Ground Speed
ZDA Time & Data
- 9 -
GPS Engine Board M-9329
identifier used to tell
5.3 MTK NMEA Packet Format
Preamble TalkerID PktType Datafield * CHK1 CHK2 CR LF
Maximum packet length is restricted to 255 bytes
Field Length Type D
Preamble 1 byte Character “$”
TalkerID 4 byte Character string “PMTK”
“000”to “999”, an
PktType 3 byte Character string
DataField Variable
* 1 byte Character
CHK1
2 byte Character string
CHK2
CR, LF 2 byte Binary data
the decoder how to
decode the packet
“, ”must be inserted
ahead each data
filed to help the
decoder process
the Data Field
The star symbol is
used to mark the
end of Data Field
checksum of the
data between
Preamble “, ”and “*”
used to identify the
end of a packet
- 10 -
GPS Engine Board M-9329
6.
Reference Design
6.1 Reference circuit
Fig 1 is M-9329 uses patch Antenna connects to RS-232 transceiver solutions
intended for portable or hand-held applications.
Fig.A-1
- 11 -
GPS Engine Board M-9329
6.2 Reference PCB pattern
- 12 -
GPS Engine Board M-9329
6.3 Recommendation reflow profile
1. We strongly recommend that this module should be designed to mount on
top side of motherboard with main chip together which process the final
reflow.
2. The maximum frequency of this module to pass reflow process should be
no more than twice, including repair operation, otherwise it may cause
side effect to the performance.
3. Below is the recommend reflow profile referred to Main MTK chipSet.
- 13 -
