Hard Disk Drive Specification
Deskstar 7K160
3.5 inch hard disk drive
Models:
HDS721616PLAT80 HDS721612PLAT80 HDS721680PLAT80 HDS721616PLA380
HDS721616PLA320
HDS721680PLA380
HDS721680PLA320
Version 2.0 6 July 2009
Hard Disk Drive Specification
Deskstar 7K160
3.5 inch hard disk drive
Models:
HDS721616PLAT80
HDS721612PLAT80 HDS721680PLAT80 HDS721616PLA380
HDS721616PLA320
HDS721612PLA380
HDS721680PLA380 HDS721680PLA320
Version 2.0 6 July 2009
1st Edition (Revision 0.1) (14 June 2006) Revised 2nd Edition (Revision 1.0)(14 July 2006) Revised 3rd Edition (Revision 1.5)(10 January 2007) Revised 4th Edition (Revision 1.6)(19 January 2007) Revised 5th Edition (Revision 1.7)(28 January 2007) Revised 6th Edition (Revision 1.8)(09 March 2007) Final
7th Edition (Revision 1.9)(26 September 2008) Revised
8th Edition (Revision 2.0)(6 July 2009) Revised
The following paragraph does not apply to the United Kingdom or any country where such provisions are inconsistent with local law: HITACHI GLOBAL STORAGE TECHNOLOGIES PROVIDES THIS PUBLI­CATION "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUD­ING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer or express or implied warranties in certain transactions, therefore, this statement may not apply to you.
This publication could include technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these changes will be incorporated in new editions of the publication. Hitachi may make improvements or changes in any products or programs described in this publication at any time.
It is possible that this publication may contain reference to, or information about, Hitachi products (machines and programs), programming, or services that are not announced in your country. Such references or information must not be construed to mean that Hitachi intends to announce such Hitachi products, programming, or services in your coun­try.
Technical information about this product is available by contacting your local Hitachi Global Storage Technologies representative or on the Internet at
http://www.hitachigst.com
Hitachi Global Storage Technologies may have patents or pending patent applications covering subject matter in this document. The furnishing of this document does not give you any license to these patents. ©Copyright Hitachi Glo­bal Storage Technologies
Note to U.S. Government Users - Documentation related subject to restricted rights - Use, duplication or disclosure is subject to restrictions set forth in GSA ADP Schedule Contract with Hitachi Global Storage Technologies Inc.
Table of Contents
1.0. General.........................................................................................................................1
1.1. Introduction........................................................................................................... 1
1.2. References............................................................................................................. 1
1.3. Abbreviations........................................................................................................ 1
1.4. Caution.................................................................................................................. 3
2.0. General features of the drive .....................................................................................5
3.0. Fixed-disk subsystem description..............................................................................9
3.1. Control electronics................................................................................................ 9
3.2. Head disk assembly ............................................................................................. 9
3.3. Actuator ................................................................................................................ 9
4.0. Drive characteristics.................................................................................................11
4.1. Default logical drive parameters......................................................................... 11
4.2. Data sheet............................................................................................................ 12
4.3. World Wide Name Assignment.......................................................................... 12
4.4. Drive organization.............................................................................................. 12
4.4.1 Drive format ..............................................................................................12
4.4.2 Cylinder allocation ....................................................................................13
4.5. Performance characteristics................................................................................ 15
4.5.1 Command overhead ...................................................................................15
4.5.2 Mechanical positioning .............................................................................15
4.5.3 Drive ready time ........................................................................................17
4.5.4 Operating modes ........................................................................................17
5.0. Defect flagging strategy............................................................................................19
6.0. Electrical interface specification..............................................................................21
6.1. Connector location .............................................................................................. 21
6.1.1 4 pin DC power connector .........................................................................22
6.1.2 AT signal connector ..................................................................................22
6.2. Signal definitions (PATA model)....................................................................... 23
6.3. Signal descriptions.............................................................................................. 24
6.4. Interface logic signal levels (pata model)........................................................... 27
6.5. Signal definition (SATA model) ........................................................................ 27
6.5.1 TX+ / TX- ..................................................................................................27
6.5.2 RX+ / RX- .................................................................................................28
6.5.3 Out of band signaling (SATA model) .......................................................28
6.6. Reset timings ...................................................................................................... 29
6.7. PIO timings......................................................................................................... 30
6.7.1 Write DRQ interval time ...........................................................................30
6.7.2 Read DRQ interval time ............................................................................30
6.8. Multi-word DMA timings................................................................................... 31
6.9. Ultra DMA timings............................................................................................. 32
6.9.1 Initiating Read DMA .................................................................................32
6.9.2 Host Pausing Read DMA ..........................................................................33
6.9.3 Host Terminating Read DMA ...................................................................34
6.9.4 Device Terminating Read DMA ...............................................................35
6.9.5 Initiating Write DMA ................................................................................36
6.9.6 Device Pausing Write DMA ......................................................................37
6.9.7 Device Terminating Write DMA ...............................................................38
6.9.8 Host Terminating Write DMA ..................................................................39
6.10. Addressing of registers..................................................................................... 40
6.10.1 Cabling ....................................................................................................40
7.0. Specification ..............................................................................................................43
7.1. Jumper settings ................................................................................................... 43
7.1.1 Jumper pin location ...................................................................................43
7.1.2 Jumper pin identification ...........................................................................43
7.1.3 Jumper pin assignment ..............................................................................44
7.1.4 Jumper positions ........................................................................................45
7.2. Environment ....................................................................................................... 49
7.2.1 Temperature and humidity ........................................................................49
7.2.2 Corrosion test .............................................................................................50
7.3. DC power requirements...................................................................................... 50
7.3.1 Input voltage ..............................................................................................51
7.3.2 Power supply current (typical) ..................................................................52
7.3.3 Power supply generated ripple at drive power connector .........................53
7.4. Reliability ........................................................................................................... 54
7.4.1 Data integrity .............................................................................................54
7.4.2 Cable noise interference ............................................................................54
7.4.3 Start/stop cycles .........................................................................................54
7.4.4 Preventive maintenance .............................................................................54
7.4.5 Data reliability ...........................................................................................54
7.4.6 Required power-off sequence ....................................................................54
7.5. Mechanical specifications................................................................................... 55
7.5.1 Physical dimensions and weight ................................................................55
7.5.2 Mounting hole locations ............................................................................56
7.5.3 Connector locations ...................................................................................57
7.5.4 Drive mounting ..........................................................................................58
7.5.5 Heads unload and actuator lock .................................................................58
7.6. Vibration and shock............................................................................................ 59
7.6.1 Operating vibration ....................................................................................59
7.6.2 Nonoperating vibration ..............................................................................59
7.6.3 Operating shock .........................................................................................60
7.6.4 Nonoperating shock ...................................................................................60
7.6.5 Nonoperating rotational shock ..................................................................60
7.7. Acoustics............................................................................................................. 61
7.8. Identification labels ............................................................................................ 61
7.9. Safety.................................................................................................................. 62
7.9.1 UL and CSA approval ...............................................................................62
7.9.2 German safety mark ..................................................................................62
7.9.3 Flammability ..............................................................................................62
7.9.4 Safe handling .............................................................................................62
7.9.5 Environment ..............................................................................................62
7.9.6 Secondary circuit protection ......................................................................62
7.10. Electromagnetic compatibility.......................................................................... 63
7.10.1 CE Mark ..................................................................................................63
7.10.2 C-TICK mark ...........................................................................................63
7.10.3 BSMI mark ..............................................................................................63
7.10.4 MIC Mark ................................................................................................63
7.11. Packaging.......................................................................................................... 63
7.11.1 Substance restriction requirements ..........................................................63
8.0. General.......................................................................................................................65
8.1. Introduction......................................................................................................... 65
8.2. Terminology ....................................................................................................... 65
8.3. Deviations from standard.................................................................................... 65
9.0. Registers.....................................................................................................................67
9.1. Register set.......................................................................................................... 67
9.2. Alternate Status Register .................................................................................... 68
9.3. Command Register ............................................................................................. 68
9.4. Cylinder High Register....................................................................................... 68
9.5. Cylinder Low Register........................................................................................ 68
9.6. Data Register ...................................................................................................... 69
9.7. Device Control Register .................................................................................... 69
9.8. Drive Address Register....................................................................................... 70
9.9. Device/Head Register......................................................................................... 70
9.10. Error Register.................................................................................................... 71
9.11. Features Register .............................................................................................. 71
9.12. Sector Count Register....................................................................................... 71
9.13. Sector Number Register.................................................................................... 72
9.14. Status Register.................................................................................................. 72
10.0. General operation...................................................................................................75
10.1. Reset response .................................................................................................. 75
10.2. Register initialization ........................................................................................ 76
10.3. Diagnostic and Reset considerations................................................................ 77
10.4. Sector Addressing Mode................................................................................... 78
10.4.1 Logical CHS addressing mode ................................................................78
10.4.2 LBA addressing mode .............................................................................78
10.5. Power management features............................................................................. 79
10.5.1 Power mode .............................................................................................79
10.5.2 Power management commands ...............................................................79
10.5.3 Standby timer ...........................................................................................79
10.5.4 Interface capability for power modes ......................................................80
10.6. S.M.A.R.T. Function ........................................................................................ 81
10.6.1 Attributes .................................................................................................81
10.6.2 Attribute values .......................................................................................81
10.6.3 Attribute thresholds .................................................................................81
10.6.4 Threshold exceeded condition .................................................................81
10.6.5 S.M.A.R.T. commands ............................................................................81
10.6.6 Off-line read scanning .............................................................................81
10.6.7 Error log ...................................................................................................82
10.6.8 Self-test ....................................................................................................82
10.7. Security Mode Feature Set................................................................................ 83
10.7.1 Security mode ..........................................................................................83
10.7.2 Security level ...........................................................................................83
10.7.3 Passwords ................................................................................................84
10.7.4 Operation example ...................................................................................84
10.7.5 Command table ........................................................................................88
10.8. Host Protected Area Feature............................................................................. 90
10.8.1 Example for operation (In LBA Mode) ...................................................90
10.8.2 Security extensions ..................................................................................91
10.9. Seek overlap...................................................................................................... 92
10.10. Write cache function....................................................................................... 93
10.11. Reassign function............................................................................................ 94
10.11.1 Auto Reassign function .........................................................................94
10.12. Power-Up in Standby feature set.................................................................... 95
10.13. Advanced Power Management feature set (APM)......................................... 96
10.14. Automatic Acoustic Management feature set (AAM).................................... 97
10.15. Address Offset Feature................................................................................... 98
10.15.1 Enable/Disable Address Offset Mode ...................................................98
10.15.2 Identify Device Data ..............................................................................99
10.15.3 Exceptions in Address Offset Mode .....................................................99
10.16. 48-bit Address Feature Set............................................................................ 100
10.17. Streaming feature Set.................................................................................... 100
10.17.1 Streaming commands ..........................................................................101
10.17.2 Urgent bit .............................................................................................101
10.17.3 Flush to Disk bit ..................................................................................101
10.17.4 Not Sequential bit ................................................................................101
10.17.5 Read Continuous bit ............................................................................102
10.17.6 Write Continuous bit ...........................................................................102
10.17.7 Handle Streaming Error bit .................................................................102
10.17.8 Streaming Logs ....................................................................................102
10.18. SATA BIST (Built-in Self Test)................................................................... 102
10.19. SATA Interface Power Management............................................................ 102
10.20. Software Setting Preservation....................................................................... 102
10.20.1 COMRESET Preservation Requirements ............................................103
10.21. SATA II Optional Features........................................................................... 104
10.21.1 Asynchronous Signal Recovery ..........................................................104
10.21.2 Device Power Connector Pin 11 Definition ........................................104
10.21.3 Phy Event Counters .............................................................................104
10.21.4 READ LOG EXT Log Page 11h .........................................................106
10.22. SCT Command Transport Feature Set.......................................................... 107
10.22.1 SCT Command Protocol ......................................................................108
10.22.2 SCT Command Set ..............................................................................116
11.0. Command protocol ...............................................................................................127
11.1. PIO Data In commands................................................................................... 127
11.2. PIO Data Out Commands............................................................................... 128
11.3. Non-data commands...................................................................................... 130
11.4. DMA commands............................................................................................. 131
12.0. Command descriptions.........................................................................................133
12.1. Check Power Mode (E5h/98h) ....................................................................... 138
12.2. Configure Stream (51h).................................................................................. 139
12.3. Device Configuration Overlay (B1h) ............................................................. 141
12.3.1 DEVICE CONFIGURATION RESTORE (Subcommand C0h) .........141
12.3.2 DEVICE CONFIGURATION FREEZE LOCK (subcommand C1h) ..141
12.3.3 DEVICE CONFIGURATION IDENTIFY (subcommand C2h) .........142
12.3.4 DEVICE CONFIGURATION SET (subcommand C3h) ......................142
12.4. Download Microcode (92h)............................................................................ 145
12.5. Execute Device Diagnostic (90h)................................................................... 147
12.6. Flush Cache (E7h) .......................................................................................... 148
12.7. Flush Cache Ext (EAh)................................................................................... 149
12.8. Format Track (50h)......................................................................................... 150
12.9. Format Unit (F7h)........................................................................................... 152
12.10. Identify Device (ECh)................................................................................... 153
12.11. Idle (E3h/97h).............................................................................................. 164
12.12. Idle Immediate (E1h/95h)............................................................................. 165
12.13. Initialize Device Parameters (91h) ............................................................... 166
12.14. Read Buffer (E4h)......................................................................................... 167
12.15. Read DMA (C8h/C9h).................................................................................. 168
12.16. Read DMA Ext (25h).................................................................................... 170
12.17. Read Log Ext (2Fh)...................................................................................... 172
12.17.1 General Purpose Log Directory ...........................................................174
12.17.2 Extended Comprehensive SMART Error Log ....................................175
12.17.3 Extended Self-test log sector ...............................................................177
12.17.4 Read Stream Error Log ........................................................................178
12.17.5 Write Stream Error Log .......................................................................180
12.17.6 Streaming Performance Log ................................................................181
12.18. Read Long (22h/23h).................................................................................... 183
12.19. Read Multiple (C4h)..................................................................................... 185
12.20. Read Multiple Ext (29h)............................................................................... 186
12.21. Read Native Max ADDRESS (F8h)............................................................. 188
12.22. Read Native Max Address Ext (27h)............................................................ 189
12.23. Read Sectors (20h/21h)................................................................................. 190
12.24. Read Sector(s) Ext (24h) .............................................................................. 192
12.25. Read Stream DMA (2Ah)............................................................................. 194
12.26. Read Stream PIO (2Bh)................................................................................ 198
12.27. Read Verify Sectors (40h/41h)..................................................................... 201
12.28. Read Verify Sectors Ext (42h)...................................................................... 203
12.29. Recalibrate (1xh) .......................................................................................... 205
12.30. Security Disable Password (F6h).................................................................. 206
12.31. Security Erase Prepare.................................................................................. 207
12.32. Security Erase Unit (F4h)............................................................................. 208
12.33. Security Freeze Lock (F5h).......................................................................... 210
12.34. Security Set Password (F1h)......................................................................... 211
12.35. Security Unlock (F2h) .................................................................................. 213
12.36. Seek (7xh).................................................................................................... 215
12.37. Set Features (EFh) ........................................................................................ 216
12.37.1 Set Transfer mode ................................................................................217
12.37.2 Write Cache .........................................................................................217
12.37.3 Advanced Power Management ............................................................217
12.37.4 Automatic Acoustic Management .......................................................219
12.38. Set Max ADDRESS (F9h)............................................................................ 220
12.38.1 Set Max Set Password (Feature=01h) .................................................222
12.38.2 Set Max Lock (Feature=02h) ..............................................................223
12.38.3 Set Max Unlock (Feature = 03h) .........................................................224
12.38.4 Set Max Freeze Lock (Feature = 04h) .................................................225
12.39. Set Max Address Ext (37h)........................................................................... 226
12.40. Set Multiple (C6h)........................................................................................ 228
12.41. Sleep (E6h/99h)............................................................................................ 229
12.42. S.M.A.R.T. Function Set (B0h).................................................................... 230
12.42.1 S.M.A.R.T. Function Subcommands ..................................................231
12.42.2 Device Attribute Data Structure ..........................................................235
12.42.3 Device Attribute Thresholds data structure .........................................238
12.42.4 S.M.A.R.T. Log Directory ...................................................................240
12.42.5 S.M.A.R.T. summary error log sector .................................................240
12.42.6 Self-test log data structure ..................................................................242
12.42.7 Selective self-test log data structure ....................................................243
12.42.8 Error reporting .....................................................................................244
12.43. Standby (E2h/96h)........................................................................................ 246
12.44. Standby Immediate (E0h/94h)...................................................................... 248
12.45. Write Buffer (E8h)........................................................................................ 249
12.46. Write DMA (CAh/CBh)............................................................................... 250
12.47. Write DMA Ext (35h)................................................................................... 252
12.48. Write DMA FUA Ext (3Dh)......................................................................... 254
12.49. Write Log Ext (3Fh) ..................................................................................... 256
12.50. Write Long (32h/33h)................................................................................... 257
12.51. Write Multiple (C5h).................................................................................... 259
12.52. Write Multiple Ext (39h).............................................................................. 261
12.53. Writer Multiple FUA Ext (CEh)................................................................... 263
12.54. Write Sectors (30h/31h)................................................................................ 265
12.55. Write Sector(s) Ext (34h).............................................................................. 267
12.56. Write Stream DMA (3Ah)............................................................................ 269
12.57. Write Stream PIO (3Bh)............................................................................... 271
13.0. Timings ..................................................................................................................275
List of Tables
Table 1: Formatted capacities.....................................................................................11
Table 2: Mechanical positioning performance ...........................................................12
Table 3: Word Wide Name Assignment.....................................................................12
Table 4: Command overhead......................................................................................15
Table 5: Mechanical positioning performance ...........................................................15
Table 6: Full stroke seek time.....................................................................................16
Table 7: Single track seek time...................................................................................16
Table 8: Latency Time................................................................................................17
Table 9: Drive ready time...........................................................................................17
Table 10: Description of operating modes..................................................................17
Table 11: Mode transition times.................................................................................18
Table 12: PATA Plist physical format........................................................................19
Table 13: Signal definitions........................................................................................23
Table 14: Special signal definitions for Ultra DMA ..................................................24
Table 15: System reset timing chart ...........................................................................29
Table 16: System reset timing ....................................................................................29
Table 17: PIO cycle timings chart ..............................................................................30
Table 18: Multiword DMA cycle timing chart...........................................................31
Table 19: Multiword DMA cycle timings ..................................................................31
Table 20: Ultra DMA cycle timings (Initiating Read)................................................32
Table 21: Ultra DMA cycle timing chart (Host pausing Read)..................................33
Table 22: Ultra DMA cycle timings (Host pausing Read) .........................................33
Table 23: Ultra DMA cycle timing chart (Host pausing Read)..................................34
Table 24: Ultra DMA cycle timings (Host pausing Read) .........................................34
Table 25: Ultra DMA cycle timing chart (Host pausing Read)..................................35
Table 26: Ultra DMA cycle timings (Device Terminating Read)..............................35
Table 27: Ultra DMA cycle timing chart (Initiating Write) .......................................36
Table 28: Ultra DMA cycle timing chart (Device Pausing Write).............................37
Table 29: Ultra DMA cycle timings (Device Pausing Write) ....................................37
Table 30: Ultra DMA cycle timing chart (Device Terminating Write)......................38
Table 31: Ultra DMA cycle timings (Device TerminatingWrite) ..............................38
Table 32: Ultra DMA cycle timing chart (Host Terminating Write)..........................39
Table 33: Ultra DMA cycle timings (Host Terminating Write).................................39
Table 34: I/O address map..........................................................................................40
Table 35: Jumper positions for capacity clip to 32GB ...............................................47
Table 36: Jumper settings for Disabling Auto Spin....................................................47
Table 37: Temperature and humidity .........................................................................49
Table 38: Limits of temperature and humidity...........................................................50
Table 39: Input voltage...............................................................................................51
Table 40: Power supply current of 80GB and 160GB models...................................52
Table 41: Power supply generated ripple at drive power connector ..........................53
Table 42: Random vibration PSD...............................................................................59
Table 43: Random vibration PSD profile break points (operating) ............................59
Table 44: Random Vibration PSD profile breakpoints (nonoperating)......................59
Table 45: Sinusoidal shock wave ...............................................................................60
Table 46: Rotational shock .......................................................................................60
Table 47: Sound power levels.....................................................................................61
Table 48: Register Set .................................................................................................67
Table 49: Alternate Status Register............................................................................68
Table 50: Device Control Register .............................................................................69
Table 51: Drive Address Register...............................................................................70
Table 52: Device Head/Register.................................................................................70
Table 53: Error Register .............................................................................................71
Table 54: Status Register............................................................................................72
Table 55: Reset response table ...................................................................................75
Table 56: Default Register Values..............................................................................76
Table 57: Diagnostic codes.........................................................................................76
Table 58: Reset error register values ..........................................................................77
Table 59: Power conditions ........................................................................................80
Table 60: Initial setting...............................................................................................85
Table 61: Usual operation for POR ............................................................................86
Table 62: Password lost..............................................................................................87
Table 63: Seek overlap ...............................................................................................92
Table 64: Device address map before and after Set Feature ......................................98
Table 65: Phy Event Counter Identifiers ..................................................................105
Table 66: Read Long EXT Log Page 11h data structure definition .........................106
Table 67: Feature Code List .....................................................................................121
Table 68: Command Set ...........................................................................................133
Table 69: Command Set (subcommand) ..................................................................136
Table 70: Check Power Mode command (E5h/98h) ................................................138
Table 71: Configure Stream (51h)............................................................................139
Table 72: Check Power Mode Command (E5h/98h) ...............................................141
Table 73: Device Configuration Overlay Features register values...........................141
Table 74: Device Configuration Overlay Data structure..........................................143
Table 75: DCO error information definition ............................................................144
Table 76: Downlad Microcode Command (92h)......................................................145
Table 77: Execute Device Diagnostic command (90h)............................................147
Table 78: Flush Cache command (E7h) ...................................................................148
Table 79: Flush Cache Ext Command (EAh)...........................................................149
Table 80: Format Track command (50h)..................................................................150
Table 81: Format Unit command (F7h)....................................................................152
Table 82: Identify Device command (ECh)..............................................................153
Table 83: Identify device information .....................................................................154
Table 84: Identify device information......................................................................156
Table 85: Identify device information .....................................................................158
Table 86: Identify device information......................................................................159
Table 87: Identify device information......................................................................160
Table 88: Identify device information......................................................................161
Table 89: Idle command (E3h/97h)..........................................................................164
Table 90: Idle Immediate command (E1h/95h)........................................................165
Table 91: Initialize Device Parameters command (91h) ..........................................166
Table 92: Read Buffer (E4h) ....................................................................................167
Table 93: Read DMA command (C8h/C9h).............................................................168
Table 94: Read DMA Ext Command (25h)..............................................................170
Table 95: Read Log Ext Command (2Fh) ................................................................172
Table 96: Log Address Definition............................................................................173
Table 97: General Purpose Log Directory................................................................174
Table 98: Extended Comprehensive SMART Error Log .........................................175
Table 99: Extended Error log data structure.............................................................175
Table 100: Command data structure.........................................................................176
Table 101: Error data structure.................................................................................176
Table 102: Read Stream Error Log...........................................................................178
Table 103: Stream Error Log entry...........................................................................180
Table 104: Write Stream Error Log..........................................................................181
Table 105: Streaming Performance Parameters log .................................................182
Table 106: Sector Time Array Entry (Linearly Interpolated)...................................182
Table 107: Access Time Array Entry (Linearly Interpolated)..................................182
Table 108: Read Long (22h/23h)..............................................................................183
Table 109: Read Multiple (C4h)...............................................................................185
Table 110: Read DMA Ext Command (25h)............................................................186
Table 111: Read Native Max ADDRESS (F8h).......................................................188
Table 112: Read Native Max Address Ext command (27h).....................................189
Table 113: Read Sectors Command (20h/21h).........................................................190
Table 114: Read Sector(s) Ext command (24h) ......................................................192
Table 115: Read Stream DMA Command (2Ah).....................................................194
Table 116: Read Stream PIO (2Bh)..........................................................................198
Table 117: Read Verify Sectors (40h/41h)...............................................................201
Table 118: Read Verify Sectors Ext command (42h)...............................................203
Table 119: Recalibrate (1xh) ....................................................................................205
Table 120: Security Disable Password (F6h) ...........................................................206
Table 121: Password Information for Security Disable Password command ..........206
Table 122: Security Disable Password (F3h) ...........................................................207
Table 123: Security Erase Unit (F4h).......................................................................208
Table 124: Erase Unit information ...........................................................................208
Table 125: Security Freeze Lock command (F5h) ...................................................210
Table 126: Security Set Password command (F1h)..................................................211
Table 127: Security Set Password Information ........................................................211
Table 128: Security Unlock command (F2h) ...........................................................213
Table 129: Seek command (7xh)..............................................................................215
Table 130: Set Features command (EFh) .................................................................216
Table 131: Set Max ADDRESS command (F9h).....................................................220
Table 132: Set Max Set Password command ...........................................................222
Table 133: Set Max Set Password data contents ......................................................222
Table 134: Set Max Lock command.........................................................................223
Table 135: Set Max Unlock command (F9h) ...........................................................224
Table 136: Set Max Freeze Lock (F9h)....................................................................225
Table 137: Set Max Address Ext command (37h)....................................................226
Table 138: Set Multiple command (C6h).................................................................228
Table 139: Sleep command (E6h/99h) .....................................................................229
Table 140: S.M.A.R.T. Function Set command (B0h).............................................230
Table 141: Device Attribute Data Structure.............................................................235
Table 142: Individual Attribute Data Structure........................................................235
Table 143: Device Attribute Thresholds Data Structure ..........................................239
Table 144: Individual Threshold Data Structure ......................................................239
Table 145: S.M.A.R.T. Log Directory......................................................................240
Table 146: S.M.A.R.T. summary error log sector ..................................................240
Table 147: Error log data structure..........................................................................241
Table 148: Command data structure.........................................................................241
Table 149: Error data structure.................................................................................241
Table 150: Self-test log data structure......................................................................242
Table 151: Selective self-test log data structure.......................................................244
Table 152: S.M.A.R.T. Error Codes.........................................................................244
Table 153: Standby (E2h/96h)..................................................................................246
Table 154: Standby Immediate (E0h/94h)................................................................248
Table 155: Write Buffer (E8h) .................................................................................249
Table 156: Write DMA (CAh/CBh).........................................................................250
Table 157: Write DMA Ext Command (35h)..........................................................252
Table 158: Write Log Ext Command (3Fh) ............................................................256
Table 159: Write Long (32h/33h).............................................................................257
Table 160: Write Multiple (C5h)..............................................................................259
Table 161: WriteMultiple Ext Command (39h) .......................................................261
Table 162: Write Sectors command (30h/31h).........................................................265
Table 163: Write Sectors Ext....................................................................................267
Table 164: Write Stream DMA Command (3Ah)....................................................269
Table 165: Write Stream PIO Command (3Bh) .......................................................271
1.0 General
1.1 Introduction
This document describes the specifications of the Deskstar 7K160, a 3.5-inch hard disk drive with ATA interface and a rotational speed of 7200 RPM.
HDS721616PLAT80 HDS721612PLAT80 HDS721680PLAT80 HDS721616PLA380 HDS721612PLA380 HDS721680PLA380
These specifications are subject to change without notice.
, HDS721616PLA320 160 GB
, HDS721680PLA320 80 GB
160 GB 120 GB 80 GB
120 GB
1.2 References
• Information Technology - AT Attachment with Packet Interface-7.
1.3 Abbreviations
Abbreviation Meaning
AAmpere AC alternating current AT Advanced Technology ATA Advanced Technology Attachment BIOS Basic Input/Output System C Celsius CSA Canadian Standards Association C-UL Canadian-Underwriters Laborato ry Cyl cylinder DC Direct Current DFT Drive Fitness Test DMA Direct Memory Access ECC error correction code EEC European Economic Community EMC electromagnetic compatibility ERP Error Recovery Procedure ESD E lectrostatic Discharge FCC Federal Com munications Commission
Deskstar 7K160 Hard Disk Drive Specification
1
FRU field replacement unit G gravity (a uni t of force)
2
G
/Hz (32 ft/sec)2 per Hertz Gb 1,000,000,000 bits GB 1,000,000,000 bytes GND ground h hexadecimal HDD hard disk drive Hz Hertz I Input ILS integrated lead suspension I/O Input/Output ISO International Standards Organization KB 1,000 bytes Kbpi 1000 bits per inch kgf-cm kilogram (force)-centimeter KHz kilohertz LBA logical block addressing Lw unit of A-weighted sound power mmeter max maximum MB 1,000,000 bytes Mbps 1,000,000 bits per second MHz megahertz MLC Machine Level Control mm millimeter ms millisecond us, ms microsecond OOutput OD Open Drain Programmed Input/Output POH power on hours Pop population P/N p art number p-p peak-to-peak PSD power spectral density RES radiated electromagnetic susceptibility RFI radio frequency interference RH relative humidity RMS root mea n square RPM revolu t ions per minute RST reset R/W read/write sec second
Deskstar 7K160 Hard Disk Drive Specification
2
SELV secondary low voltage S.M.A.R.TSelf-Monitoring, Analysis, and Reporting Technology TPI tracks per inch Trk track TTL transistor-transistor logic UL Underwriters Laboratory Vvolt VDE Verband Deutscher Electrotechniker Wwatt 3-state transistor-transistor tristate logic
1.4 Caution
• Do not apply force to the top cover.
• Do not cover the breathing hole on the top cover.
• Do not touch the interface connector pins or the surface of the printed circuit board
• This drive can be damaged by electrostatic discharge (ESD). Any damages incurred to the drive after its removal from the shipping package and the ESD protective bag are the responsibility of the user.
Deskstar 7K160 Hard Disk Drive Specification
3
Deskstar 7K160 Hard Disk Drive Specification
4
2.0 General features of the drive
• Formatted capacities of 160 GB, 120 GB and 80 GB
• Spindle speeds of 7200 RPM
• Fluid Dynamic Bearing motor
• Enhanced IDE interface
• Sector format of 512 bytes/sector
• Closed-loop actuator servo
• Load/Unload mechanism, non head disk contact start/stop
• Automatic Actuator lock
• Interleave factor 1:1
• Seek time of 8.8 ms in Read Operation. 8.5 ms typical without Command Overhead
• Sector Buffer size of
• Ring buffer implementation
• Write Cache
• Native command queuing support (SATA model)
• Advanced ECC On The Fly (EOF)
• Automatic Error Recovery procedures for read and write commands
• Self Diagnostics on Power on and resident diagnostics
• PIO Data Transfer Mode 4 (16.6 MB/s)
• DMA Data Transfer
• Multiword mode Mode 2 (16.6 MB/s)
• Ultra DMA Mode 6 (133 MB/s)
• Serial ATA Data Transfer 3Gbps / 1.5Gbps
• CHS and LBA mode
• Power saving modes/Low RPM idle mode (APM)
• S.M.A.R.T. (Self Monitoring and Analysis Reporting Technology)
• Support security feature
• Quiet Seek mode (AAM)
2048K and 8192 K (Upper 292 KB is used for firmware)
• 48-bit addressing feature
• Adaptive BPI
• ATA-7 compliant
• UDMA 133 support
• Streaming feature set support
• World Wide Name
Deskstar 7K160 Hard Disk Drive specification
5
Deskstar 7K160 Hard Disk Drive Specification
6
Part 1. Functional specification
Deskstar 7K160 Hard Disk Drive specification
7
Deskstar 7K160 Hard Disk Drive Specification
8
3.0 Fixed-disk subsystem description
3.1 Control electronics
The drive is electronically controlled by a microprocessor, several logic modules, digital/analog modules, and var­ious drivers and receivers. The control electronics performs the following major functions:
• Controls and interprets all interface signals between the host controller and the drive.
• Controls read write accessing of the disk media, including defect management and error recovery.
• Controls starting, stopping, and monitoring of the spindle.
• Conducts a power-up sequence and calibrates the servo.
• Analyzes servo signals to provide closed loop control. These include position error signal and estimated velocity.
• Monitors the actuator position and determines the target track for a seek operation.
• Controls the voice coil motor driver to align the actuator in a desired position.
• Constantly monitors error conditions of the servo and takes corresponding action if an error occurs.
• Monitors various timers such as head settle and servo failure.
• Performs self-checkout (diagnostics).
3.2 Head disk assembly
The head disk assembly (HDA) is assembled in a clean room environment and contains the disks and actuator assembly. Air is constantly circulated and filtered when the drive is operational. Venting of the HDA is accom­plished via a breather filter.
The spindle is driven directly by an in-hub, brushless, sensorless DC drive motor. Dynamic braking is used to quickly stop the spindle.
3.3 Actuator
The read/write heads are mounted in the actuator. The actuator is a swing-arm assembly driven by a voice coil motor . A closed-loop position ing servo controls the movement of the actuator. An embedded servo pattern supplies feedback to the positioning servo to keep the read/write heads centered over the desired track.
The actuator assembly is balanced to allow vertical or horizontal mounting without adjustment. When the drive is powered off, the actuator automatically moves the head to the actuator ramp outside of the disk
where it parks.
Deskstar 7K160 Hard Disk Drive Specification
9
Deskstar 7K160 Hard Disk Drive Specification
10
4.0 Drive characteristics
4.1 Default logical drive parameters
Table 1: Formatted capacities
PATA SATA
HDS721680PLAT80 HDS721680PLA3
x0
HDS721612PLAT80 HDS721612PLA380
HDS721616PLAT80 HDS721616PLA3
Physical Layout
Label capacity (GB) 80 120 160 Bytes per sector 512 512 512 Sectors per track 720-1500 672-1280 720-1500 Number of heads 1 2 2 Number of disks 1 1 1 Data sectors per cylinder 567-1170 1134-2340 1440-3000 Data cylinders per zone 256-9088 1152-6656 256-9088
Logical layout
1
Number of heads 16 16 16 Number of Sectors per track 63 63 63
Number of Cylinders
2
16,383 16,383 16383
Number of sectors 160,836,480 241,256,720 321,672,960 Total logical data bytes 82,348,277,760 123,522,416,640 164,696,555,520
IDEMA Std. Capacity
3
Number of Sectors 156,301,488 312,581,808
x0
Total Logical Data Bytes 80,026,361,856
160,041,885,696
Notes:
1.
Number of cylinders: For drives with capacities greater than 8.45 GB the Identify Device information word 01
limits the number of cylinders to 16, 383 per the ATA specification.
2.
Logical layout: Logical layout is an imaginary drive parameter (that is, the number of heads) which is used to access the drive from the system interface. The logical layout to Physical layout (that is, the actual Head and Sec­tors ) translation is done automatically in the drive. The default setting can be obtained by issuing an IDENTIFY DEVICE command.
3.
Applies to part numbers beginning with 0Y3.
Deskstar 7K160 Hard Disk Drive Specification
11
4.2 Data sheet
Table 2: Mechanical positioning performance
Description 80GB Model 1 20GB Model 160GB Model Data transfer rates (Mbps) 966 824 966 Interface transfer rates (Mb/s) 133 (PATA) / 300 (SATA)
Data buffer size Rotational speed (RPM) 7200 Number of buffer segments (read) up to 128 Number of buffer segments (write) up to 63 Recording density - max (Kbpi) 900 733 900 Track density [TPI] 135 125 135
Areal density - max (Gbits/in Number of data bands 30
1
(KB)
2
)
120 92 120
2048 (80GB & 160GB), 8192
4.3 World Wide Name Assignment
Table 3: Word Wide Name Assignment
Description
Organization Hitachi GST
Manufacturing Site Excelstor Plant China / Hitachi GST China Plant (GSP)
Product Deskstar 7K160
OUI 000CCAh
SHBU Block Assignment 320h for ExcelStor,China
Port/Node ID 11b
80 GB model 120 GB model 160 GB model
324h for Hitachi GST China Plant
326h for Excel­Stor,China
328h for Hitachi
321h for Excel­Stor,China
325h for Hitachi GST China Plant
4.4 Drive organization
4.4.1 Drive format
Upon shipment from manufacturing the drive satisfies the sector continuity in the physical format by means of the defect flagging strategy described in Section 5.0, “Defect flagging strate gy” on page 21 in order to provide the maximum performance to users.
Deskstar 7K160 Hard Disk Drive Specification
12
4.4.2 Cylinder allocation
Physical cylinder is calculated from the starting data track of 0. It is not relevant to logical CHS. Depending on the capacity some of the inner zone cylinders are not allocated.
Zone Start Logical cyl. Stop Logical cyl. #cyl
0 0 4607 4608 1 4608 13695 9088 2 13696 21375 7680 3 21376 29055 7680 4 29056 35071 6016 5 35072 41855 6784 6 41856 45823 3968 7 45824 48895 3072 8 48896 56191 7296 9 56192 63231 7040
10 63232 67967 4736
11 67968 74111 6144 12 74112 80383 6272 13 80384 85247 4864 14 85248 88447 3200 15 88448 94207 5760 16 94208 99711 5504 17 99712 104063 4352 18 104064 108415 4352 19 108416 113151 4736 20 113152 117759 4608 21 117760 118783 1024 22 118784 121599 2816 23 121600 124031 2432 24 124032 126335 2304 25 126336 129023 2688 26 129024 131711 2688 27 131712 131967 256 28 131968 133119 1152 29 133120 134271 1152
Data cylinder
This cylinder contains the user data which can be sent and retrieved via read/write commands and a spare area for reassigned data.
Spare cylinder
Deskstar 7K160 Hard Disk Drive Specification
13
The spare cylinder is used by Hitachi Global Storage Technologies manufacturing and includes data sent from a defect location.
Deskstar 7K160 Hard Disk Drive Specification
14
4.5 Performance characteristics
Drive performance is characterized by the following parameters:
• Command overhead
• Mechanical head positioning
- Seek time
- Latency
• Data transfer speed
• Buffering operation (Look ahead/Write cache)
All the above parameters contribute to drive performance. There are other parameters that contribute to the perfor­mance of the actual system. This specification tries to define the bare drive characteristics, not system throughput, which depends on the system and the application.
4.5.1 Command overhead
Command overhead is defined as the time required from the time the command is written into the command regis­ter by a host to the assertion of DRQ for the first data byte of a READ command when the requested data is not in the buffer excluding Physical seek time and Latency.
The table below gives average command overhead.
Table 4: Command overhead
Command type (Drive is in quiescent state) Time (typical)
(ms)
Read (cache not hit) (from Command Write to Seek Start) Read (cache hit) (from Command Write to DRQ) Write (from Command Write to DRQ) Seek (from Command Write to Seek Start)
0.5 0.5
0.1 0.2
0.015 0.2
0.5 not applicable
Time (typical) for queued command (ms)
4.5.2 Mechanical positioning
4.5.2.1 Average seek time (without command overhead, including settling)
Table 5: Mechanical positioning performance
Command type Typical (ms) Max (ms)
Read 40-80GB 8.5 9.5 Write 40-80GB 9.5 10.5 Read (Quiet Seek mode) 14.0 14.7 Write (Quiet Seek mode) 15.0 15.7
Deskstar 7K160 Hard Disk Drive Specification
15
The terms “Typical” and “Max” are used throughout this document and are defined as follows:
Typical The average of the drive population tested at nominal environmental and voltage conditions. Max Maximum value measured on any one drive over the full range of the environmental and voltage
conditions. The seek time is measured from the start of the actuator’s motion to the start of a reli­able read or write operation. A reliable read or write implies that error correction or recovery is not used to correct arrival problems. The average seek time is measured as the weighted average of all possible seek combinations.
max
Σ (m10 n)(Tnin + Tnout)
n=1
Weighted Average = ––––––––––––––––––––––––––––
(max + 1)(max)
where
max = Maximum seek length n= Seek length (1 to max) Tnin = Inward measured seek time for an n track seek Tnout = Outward measured seek time for an n track seek
4.5.2.2 Full stroke seek time (without command overhead, including settling)
Table 6: Full stroke seek time
Function Typical (ms) Max (ms)
Read Write
15.1 18.1
16.1 19.1 Read (Quiet Seek mode) 32.5 35.5 Write (Quiet Seek mode) 33.5 36.5
Full stroke seek is measured as the average of 1,000 full stroke seeks with a random head switch from both direc­tions (inward and outward).
4.5.2.3 Single track seek time (without command overhead, including settling)
Table 7: Single track seek time
Function Typical (ms) Max (ms)
Read 0.8 1.5
Write 1.3 2.0
Read (Quiet Seek mode) 0.8 1.5
Write (Quiet Seek mode) 1.3 2.0
Single track seek is measured as the average of one (1) single track seek from every track in both directions (inward and outward).
Deskstar 7K160 Hard Disk Drive Specification
16
Loading...
+ 268 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
