USER'S MANUAL Vol.1 Basic
Please read this user's manual thoroughly to ensure correct usage through understanding.
BEDIENUNGSANLEITUNG Teil 1 Grundlagen
Bitte lessen Sie diese Benutzerhandbuch zugunsten der korrekten Bedienung aufmerksam.
MANUEL D'UTILISATION Vol.1 Fondements
Nous vous recommandons de lire attentivement ce manuel pour bien assimiler le fonctionnement de l'appareil.
MANUALE D'ISTRUZIONI Vol.1 Informazioni di base
Vi preghiamo voler leggere attentamente il manuale d'istruzioni in modo tale da poter comprendere quanto riportato
ai fini di un corretto utilizzo del proiettore.
MANUAL DE USUARIO Vol.1 Básico
Lea cuidadosamente este manual del usuario para poder utilizar corretamente el producto.
GEBRUIKSAANWIJZING Vol.1 Basis
Lees voor het qebruik alstublieft deze handleiding aandachtig door, om volledig profijt te hebben van de
uitgebreide mogelijkheden.
BRUKERHÅNDBOK Vol.1 Grunnleggende
Vennligst les denne bruksanvisningen grundig for å være garantert driftssikker bruk.
NSTRUÇÕES DO PROPRIETÁRIO Vol.1 Básico
Para assegurar o uso correto do equipamento, por favor leia atentamente este manual do utilizador.
ENGLISH
DEUTSCH
FRANÇAIS
ITALIANO
ESPAÑOL
NEDERLANDS
NORSK
PORTGÊS
REGULATORY
NOTICES
Liquid Crystal Projector
ED-S3170A/ED-X3270A
00ED-S317-27WBasic/初02.12.17 9:11AM ページ2
RESET
E
N
O
T
S
Y
E
K
POWER
UT
INP
N
TENP
LANP
/O
Y
B
D
N
A
T
S
1
ENGLISH
LCD Projector ED-S3170A/ED-X3270A
USER'S MANUAL
USER'S MANUAL Vol.1 (Basic)
Page
PROJECTOR FEATURES................2
PREPARATIONS ..............................2
PART NAMES...................................4
SETTING UP
THE PROJECTOR ............................6
CONNECTING
YOUR DEVICES................................8
USING THE REMOTE
CONTROL.......................................13
TURNING ON THE POWER ...........14
TURNING OFF THE POWER .........16
ADJUSTING THE VOLUME ...........17
TEMPORARILY MUTING
THE SOUND....................................17
ADJUSTING THE POSITION..........18
USING THE AUTOMATIC
ADJUSTMENT FEATURE ..............19
Page
CORRECTING KEYSTONE
DISTORTIONS ................................20
USING THE MAGNIFY
FEATURE........................................21
FREEZING THE SCREEN ..............21
SIGNAL SEARCHING.....................22
SELECTING THE ASPECT
RATIO..............................................22
TEMPORARILY BLANKING
THE SCREEN..................................22
USING THE MENU
FUNCTIONS....................................23
OPERATING THE PC SCREEN .....24
THE LAMP ......................................25
THE AIR FILTER.............................27
OTHER CARE.................................29
CONTENTS
Thank you for purchasing this projector.
• The information in this manual is subject to change without notice.
• The manufacturer assumes no responsibility for any errors that may appear in this manual
• The reproduction, transmission or use of this document or contents is not permitted without express
written authority.
TRADEMARK ACKNOWLEDGEMENT :
• PS/2, VGA and XGA are registered trademarks of the International Business Machines Corporation.
• Apple, Mac and ADB are registered trademarks of Apple Computer, Inc.
• VESA and SVGA are trademarks of the Video Electronics Standard Association.
• Windows is a registered trademark of Microsoft Corporation.
• All other trademarks are the property of their respective owners.
NOTE
WARNING • Please read the accompanying manual “SAFETY
INSTRUCTIONS” and this “USER'S MANUAL” thoroughly to ensure correct
usage through understanding. After reading, store this instruction manual in a
safe place for future reference.
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ1
2
●
Ultra High Brightness
Crisp, ultra-bright presentations is achieved
by using a UHB (ultra high brightness) lamp
and a highly efficient optical system
●
Partial Magnification Function
Interesting parts of images can be magnified
for closer viewing
●
Keystone Distortion Correction
Quick correction of distorted images electrically
●
Whisper Mode Equipped
Special mode is available for reducing
projector noise to achieve quieter operation
PREPARATIONS
Your projector should come with the items
shown below. Check to make sure that all the
items are included. Contact your dealer if
anything is missing.
Projector
(with Lens Cap)
USER'S MANUALVol.1 Basic
Please read this user's manual thoroughly to ensure correct usage through understanding.
BEDIENUNGSANLEITUNG Teil 1 Grundlagen
Bitte lessen Sie diese Benutzerhandbuch zugunsten der korrekten Bedienung aufmerksam.
MANUEL D'UTILISATION Vol.1 Fondements
Nous vous recommandons de lire attentivement ce manuel pour bien assimiler le fonctionnement de l'appareil.
MANUALE D'ISTRUZIONI Vol.1 Informazioni di base
Vi preghiamo voler leggere attentamente il manuale d'istruzioni in modo tale da poter comprendere quanto riportato
ai fini di un corretto utilizzo del proiettore.
MANUAL DE USUARIO Vol.1 Básico
Lea cuidadosamente este manual del usuario para poder utilizar corretamente el producto.
GEBRUIKSAANWIJZING Vol.1 Basis
Lees voor het qebruik alstublieft deze handleiding aandachtig door, om volledig profijt te hebben van de
uitgebreide mogelijkheden.
BRUKERHÅNDBOK Vol.1 Grunnleggende
Vennligst les denne bruksanvisningen grundig for å være garantert driftssikker bruk.
NSTRUÇÕES DO PROPRIETÁRIO Vol.1 Básico
Para assegurar o uso correto do equipamento, por favor leia atentamente este manual do utilizador.
ENGLISHDEUTSCH
FRANÇAIS
ITALIANO
ESPAÑOL
NEDERLANDS
NORSK
PORTGÊS
Liquid Crystal Projector
ED-S3170A/ED-X3270A
User's Manuals
(Vol.1/Vol.2)
Safety Instructions
Power cord
(UK Type)
RGB cable
USB mouse
cable
Remote control
Two AA batteries
(for the remote
control)
Video/Audio cable
PROJECTOR
FEATURES
This liquid crystal projector is used to project
various computer signals as well as NTSC / PAL /
SECAM video signals onto a screen. Little space
is required for installation and large images can
easily be realized.
• Keep the original packing material for future reshipment.
NOTE
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ2
RESET
E
N
O
T
S
Y
E
K
POWER
T
U
INP
N
O
/
TENP
Y
B
D
N
A
T
S
P
N
LA
STANDBY/ON
VIDEO
RGB SEARCH
ASPECT
AUTO BLANK
HOME
PAGE UP VOLUME
MAGNIFY
ON
END
PAGE DOWN
MUTE
OFF
KEYSTONEFREEZE
MENUPOSITION
ENTER
ESC RESET
T
RESE
E
N
O
T
S
R
Y
E
E
K
OW
P
T
U
P
IN
N
O
TENP
/
Y
B
D
N
A
T
S
P
N
LA
3
ENGLISH
1
Connect your devices to the projector
Connect your computer, VCR and/or other
devices you will be using to the projector.
Insert the batteries into the remote
control
2
13
3
4
PART NAMES
THE PROJECTOR
Zoom ring
15
Focus ring
15
Air filter
27
Elevator button
6
Elevator button
6
KEYSTONE button
20
STANDBY/ON button
14
INPUT button
15
RESET button
24
MENU button
23
LAMP indicator
26
TEMP indicator
27
POWER indicator
14
Indicates the corresponding
reference page
AC power inlet
3
S-VIDEO IN port
11
RGB IN 1 and 2 ports
10
AUDIO IN R and L ports
11
VIDEO IN port
11
CONTROL port
10
RGB OUT port
12
USB port
10
AUDIO IN
1/2 port
10
AUDIO OUT port
9
Power switch
14
Lens cap
14
Remote sensor
13
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ4
RESET
E
N
O
T
S
Y
E
K
POWER
TENP
P
N
LA
T
U
INP
N
/O
Y
B
D
N
A
T
S
S
T
A
N
D
B
Y
/O
N
IN
P
U
T
K
E
Y
S
LANP
TENP
T
O
POWER
N
E
R
E
S
E
T
5
ENGLISH
THE REMOTE CONTROL
STANDBY/ON button
14
VIDEO button
15
MENU button
23
RGB button
15
BLANK button
22
SEARCH button
22
VOLUME button
17
MUTE button
17
KEYSTONE button
20
ASPECT button
22
AUTO button
19
MAGNIFY buttons
21
KEYBOARD buttons
24
FREEZE button
21
POSITION button
18
ESC button
23
,,,
Cursor buttons
23
RESET button
24
ENTER button
23
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ5
VIDEO
ASPECT
MAGNIFY
ON
OFF
RGB SEARCH
AUTO BLANK
HOME
PAGE UP VOLUME
END
PAGE DOWN
STANDBY/ON
MUTE
KEYSTONEFREEZE
MENUPOSITION
ENTER
ESC RESET
6
7
ENGLISH
Refer to the illustrations and tables below to determine the screen size and
projection distance.
Adjusting the Screen Size and Projection Distance
Top view
a
c
b
Lens center
The screen
Side view
Top view
a
c
b
Lens center
The screen
Side view
If 4:3 aspect ratio
If 16:9 aspect ratio
9
16
The values shown in the table are calculated for a full size screen
(ED-S3170A: 800x600 pixels/ED-X3270A: 1024x768 pixels).
a:Distance from the projector to the screen (±10%)
b:Distance from the lens center to the bottom of the screen (±10%)
c:Distance from the lens center to the top of the screen (±10%)
Screen Size [inch (m)]
a [inch (m)]
b
[inch (cm)]c [inch (cm)]
Min. Max.
30 (0.8) 35 (0.9) 42 (1.1) 1 (2) 17 (44)
40 (1.0) 47 (1.2) 56 (1.4) 1 (3) 23 (58)
50 (1.3) 59 (1.5) 71 (1.8) 1 (4) 29 (73)
60 (1.5) 71 (1.8) 85 (2.2) 2 (4) 34 (87)
70 (1.8) 83 (2.1)
100 (2.5)
2 (5) 40 (102)
80 (2.0) 95 (2.4)
114 (2.9)
2 (6) 46 (116)
90 (2.3)
107 (2.7) 129 (3.3)
3 (7) 51 (131)
100 (2.5)
119 (3.0) 143 (3.6)
3 (7) 57 (145)
120 (3.0)
143 (3.6) 172 (4.4)
3 (9) 69 (174)
150 (3.8)
180 (4.6) 216 (5.5)
4 (11) 86 (218)
200 (5.0)
240 (6.1) 288 (7.3)
6 (15)
114 (290)
250 (6.3)
300 (7.6) 361 (9.2)
7 (18)
143 (363)
300 (7.5)
360 (9.2)
433 (11.0)
9 (22)
171 (435)
Screen Size [inch (m)]
a [inch (m)]
b
[inch (cm)]c [inch (cm)]
Min. Max.
30 (0.8) 38 (1.0) 46 (1.2) 2 (4) 16 (41)
40 (1.0) 51 (1.3) 61 (1.6) 2 (5) 22 (55)
50 (1.3) 64 (1.6) 77 (2.0) 3 (6) 27 (69)
60 (1.5) 77 (2.0) 93 (2.4) 3 (8) 32 (82)
70 (1.8) 90 (2.3)
109 (2.8)
4 (9) 38 (96)
80 (2.0)
104 (2.6) 125 (3.2)
4 (10) 43 (110)
90 (2.3)
117 (3.0) 140 (3.6)
5 (12) 49 (124)
100 (2.5)
130 (3.3) 156 (4.0)
5 (13) 54 (137)
120 (3.0)
156 (4.0) 188 (4.8)
6 (15) 65 (165)
150 (3.8)
196 (5.0) 235 (6.0)
8 (19) 81 (206)
200 (5.0)
261 (6.6) 314 (8.0)
10 (26)
108 (275)
250 (6.3)
327 (8.3)
393 (10.0)
13 (32)
135 (343)
300 (7.5)
393 (10.0)
472 (12.0)
15 (39)
162 (412)
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ7
4
3
8
Display monitors
12
DVD players
11
VCRs
11
Laptop computers
10
Desktop computers
10
Indicates the
corresponding
reference page
ATTENTION
Precautions to observe when connecting other devices to the projector
• Whenever attempting to connect other devices to the projector, please thoroughly
read the manual of each device to be connected.
• TURN OFF ALL DEVICES prior to connecting them to the projector. Attempting to
connect a live device to the projector may generate extremely loud noises or other
abnormalities that may result in malfunction and/or damage to the device and/or
projector. Refer to the “TECHNICAL” of the USER’S MANUAL (Vol.2) for the pin
assignment of connectors and RS-232C communication data.
• Make sure that you connect devices to the correct port. Incorrect connection may
result in malfunction and/or damage to the device and/or projector.
• A component cable and some other cables have to be used with core set. Use the
accessory cable or a designated-type cable for the connection. For cables that have
a core only at one end, connect the core to the projector.
• Secure the screws on the connectors and tighten.
CONNECTING YOUR DEVICES
Devices You Can Connect to the Projector
(Refer to this section for planning your device
configuration to use for your presentation.)
CAUTION • Incorrect connecting could result in fire or electrical shock. Please
read this manual and the separate “SAFETY INSTRUCTIONS”.
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ8
9
ENGLISH
Ports and Cables
Refer to the table below to find out which projector port and cable to use for connecting a
given device. Use this table for determining which cables to prepare.
About Plug-and-Play Capability
• This projector is compatible with VESA DDC 1/2B. Plug-and-Play can be achieved by
connecting this projector to computers that are VESA DDC (display data channel)
compatible. Please take advantage of this function by connecting the accessory RGB
cable to the RGB IN 1 port (DDC 1/2B compatible). Plug-and-Play may not work
properly if any other type of connection is attempted.
• Plug-and-Play is a system composed of the computer, its operating system and
peripheral equipment (i.e. display devices).
• Please use the standard drivers as this projector is a Plug-and-Play monitor.
• Plug-and-Play may not function properly with some type of computers. Use the RGB
IN 2 port if Plug-and-Play does not function correctly.
NOTE
Function Projector Port Connection Cables
RGB input
RGB IN 1
Accessory RGB cable or optional RGB
cable with D-sub 15-pin shrink jack and
inch thread screws
RGB IN 2
RGB output RGB OUT
USB mouse control USB Accessory USB cable
Audio input from computer
AUDIO IN 1
・Linked to RGB IN 1
Optional audio cable with stereo mini jack
AUDIO IN 2
・Linked to RGB IN 2
PS/2 mouse control
CONTROL
Optional PS/2 mouse cable
ADB mouse control Optional ADB mouse cable
Serial mouse control Optional serial mouse cable
RS-232C communication Optional RS-232C cable
S-video input S-VIDEO IN
Optional S-video cable with mini DIN 4-pin
jack
Video input VIDEO IN Accessory audio/video cable
Audio input from video
equipment
AUDIO IN L
Accessory audio/video cable or optional
audio cable with RCA jack
AUDIO IN R
Audio output AUDIO OUT
Optional audio cable with stereo mini jack
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ9
10
B
A
AUDIO IN
R L / (MONO) VIDEO IN
K
S-VIDEO IN
USB
1 RGB IN 2
RGB OUT CONTROL
A
AUDIO IN 2
AUDIO cable
RGB cable
AUDIO OUT
RGB IN
Analogue
RGB OUT
AUDIO IN
AUDIO OUT
1 2
B
Laptop computer
1 2
AUDIO IN
AUDIO OUT
USB
11
ENGLISH
DVD player
VCR
Connecting to a DVD Player
Connecting to a VCR
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ11
K
AUDIO IN
R L / (MONO) VIDEO IN
A A A
1 2
AUDIO IN
AUDIO OUT
A
S-VIDEO IN
B
USB
AUDIO/VIDEO IN
1 RGB IN 2
RGB OUT CONTROL
B
S-VIDEO IN
AUDIO/VIDEO cable
AUDIO/VIDEO OUT
S-VIDEO OUT
Ifusinganaudio/video
connection
K
AUDIO IN
R L / (MONO) VIDEO IN
A A A
1 2
AUDIO IN
S-VIDEO IN
AUDIO OUT
A
1 RGB IN 2
B
RGB OUT CONTROL
USB
AUDIO/VIDEOIN AUDIO/VIDEOOUT
B
S-VIDEOIN
S-VIDEO cable
If using a S-video
connection
AUDIO/VIDEO cable
S-VIDEO cable
If using a S-video
connection
S-VIDEOOUT
12
RGB cable
A
AUDIO IN
R L / (MONO) VIDEO IN
K
S-VIDEO IN
1 RGB IN 2
RGB OUT CONTROL
A
RGBOUT
RGBIN
USB
AUDIO IN
AUDIO OUT
1 2
CONNECTING YOUR DEVICES (continued)
Connecting to a Display Monitor
Display monitor
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ12
13
ENGLISH
1
Remove the battery
cover
Slide back and remove
the battery cover in the
direction of the arrow.
Insert the batteries
Align and insert the two AA
batteries (that came with the
projector) according to their plus
and minus terminals (as indicated
in the remote control).
Close the battery
cover
Replace the battery cover
in the direction of the arrow
and snap it back into place.
•
The remote control works with both the
projector's front and rear remote sensors.
•
The range of the remote sensor on the front and
back is 3 meters with a 60-degree range (30
degrees to the left and right of the remote sensor).
•
Since the remote control uses infrared light to send
signals to the projector (Class 1 LED), be sure to
use the remote control in an area free from
obstacles that could block the remote control's
output signal to the projector.
2 3
USING THE REMOTE CONTROL
CAUTION
Precautions to observe in regards to the batteries
Always handle the batteries with care and use them only as directed. Improper use may result in
battery cracking or leakage, which could result in fire, injury and/or pollution of the surrounding environment.
• Keep the battery away from children and pets.
•
Be sure to use only the batteries specified for use with the remote control. Do not mix new batteries with used ones.
•
When inserting batteries, verify that the plus and minus terminals are aligned correctly (as indicated in the remote control).
• When you dispose the battery, you should obey the law in the relative area or country.
Precautions to observe when using the remote control
• Do not drop or otherwise expose the remote control to physical impact.
•
Do not get the remote control wet or place it on wet objects. Doing so may result in malfunction.
• Remove the batteries from the remote control and store them in a safe place if you
won't be using the remote control for an extended period.
• Replace the batteries whenever the remote control starts to malfunction.
•
When strong light, such as direct sunlight or light from an extremely close range (such as from an
inverter fluorescent lamp), hits the projector's remote sensor, the remote control may cease to function.
Adjust the direction of the projector to keep light from directly hitting the projector's remote sensor.
ATTENTION
Putting batteries into the remote control unit
Operating the remote control
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ13
approximately
3 meters
30 degrees
s
e
re
g
e
d
0
3
approximately
3 meters
30 degrees
s
e
re
g
e
d
0
3
14
1
Make sure that the power cord is firmly and
correctly connected to the projector and outlet
2
Turn on the projector's power
Set the power switch to [ | ] (ON). The projector will go
to STANDBY mode and the POWER indicator will light to
solid orange.
3
Press the STANDBY/ON button (control
panel or remote control)
• The projector begins warming up and the POWER
indicator blinks green.
• The POWER indicator stops blinking
and lights to solid green once the
projector's power is completely on.
4
Remove the lens cap
The picture is projected.
S
T
A
N
D
B
Y
/
O
N
I
N
P
L
U
A
T
N
P
K
T
E
E
Y
N
S
T
P
O
P
N
O
E
W
E
R
R
E
S
E
T
15
ENGLISH
6
Use the zoom ring to adjust the
screen size
7
Use the focus ring to focus the
5
If selecting RGB input
Press the RGB button
Press this button to toggle between the
devices connected to RGB IN 1 and 2.
As illustrated below, each time you
press the RGB button, the projector
switches between RGB IN 1 and 2.
Select the signal you wish to project.
If selecting video input
Press the VIDEO button
Press this button to toggle between the
devices connected to VIDEO IN and SVIDEO IN. As illustrated below, each
time you press the VIDEO button, the
projector switches between VIDEO IN
and S-VIDEO IN. Select the signal you
wish to project.
Using the remote control
Press the INPUT button
As illustrated below, each time you
press the INPUT button, the projector
switches between its input signal
ports. Select the signal you wish to
project.
Using the projector's control panel
RGB
RGB IN 1 RGB IN 2
VIDEO
VIDEO IN S-VIDEO IN
INPUT
RGB IN 1 RGB IN 2
S-VIDEO IN
VIDEO IN
16
1
Press the STANDBY/ON button (control
panel or remote control)
The message "Power off?" will appear on the screen for approximately 5 seconds.
3
Check that the POWER indicator stops
blinking and lights to solid
orange.
Switch the power switch to
[O] (OFF).
4
Confirm that the POWER indicator has
gone off and then attach the lens cap.
When the projector has completed powering down, the
POWER indicator will go off.
TURNING OFF THE POWER
RGB SEARCH
AUTO BLANK
HOME
PAGE UP VOLUME
END
PAGE DO WN
ENTER
STANDBY/ON
KEYSTONEFREEZE
VIDEO
ASPECT
MAGNIFY
ON
OFF
ESC RESET
MUTE
MENUPOSITION
STANDBY/ON
17
ENGLISH
1
Press the VOLUME button
As illustrated on the right, a dialog will
appear on the screen to aid you in adjusting
the volume.
1
Press the MUTE button
As illustrated on the right, a dialog will appear on the
screen indicating that you have muted the sound. Press
the VOLUME button to close the dialog. (Even if you don't
do anything, the dialog will automatically disappear after
a few seconds.)
Press the MUTE button again to restore the sound.
2
Press the , buttons to adjust
the volume
Press the VOLUME button again to close the dialog and
complete this operation. (Even if you don't do anything, the
dialog will automatically disappear after a few seconds.)
Press this to increase the volume
Press this to decrease the volume
VOLUME
MUTE
ADJUSTING THE VOLUME
TEMPORARILY MUTING THE SOUND
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ17
RGB SEARCH
AUTO BLANK
HOME
PAGE UP VOLUME
END
PAGE DO WN
ENTER
STANDBY/ON
KEYSTONEFREEZE
VIDEO
ASPECT
MAGNIFY
ON
OFF
ESC RESET
MUTE
MENUPOSITION
VOLUME
VOLUME
16
VOLUME
16
RGB SEARCH
AUTO BLANK
HOME
PAGE UP VOLUME
END
PAGE DO WN
ENTER
STANDBY/ON
KEYSTONEFREEZE
VIDEO
ASPECT
MAGNIFY
ON
OFF
ESC RESET
MUTE
MENUPOSITION
MUTE
VOLUME
16
18
1
Press the POSITION button
As illustrated on the right, a dialog will appear on the screen
to aid you in adjusting the position.
2
Use the , , , buttons to adjust
the position
When you want to initialize the position, press the RESET
button during adjustment.
Press the POSITION button again to close the dialog and
complete this operation. (Even if you don't do anything, the
dialog will automatically disappear after a few seconds.)
This function is only available for RGB IN 1/2 input.
ADJUSTING THE POSITION
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ18
VIDEO
ASPECT
MAGNIFY
ON
OFF
RGB SEARCH
AUTO BLANK
HOME
PAGE UP VOLUME
END
PAGE DO WN
STANDBY/ON
MUTE
KEYSTONEFREEZE
MENUPOSITION
POSITION
POSITION
ENTER
ESC RESET
19
ENGLISH
The automatic adjustment operation requires approximately 10 seconds. Also, please
note that it may not function correctly with some input signals.
NOTE
1
USING THE AUTOMATIC ADJUSTMENT FEATURE
Press the AUTO button
Horizontal position (H. POSIT), vertical position (V.
POSIT), clock phase (H. PHASE) and horizontal size (H.
SIZE) are automatically adjusted.
Make sure that the application window is set to its
maximum size prior to attempting to use this feature.
Dark pictures may still be incorrectly adjusted. Use a
bright screen when adjusting.
The signal type best suited for the respective input
signal is selected automatically.
This feature is available only if VIDEO is set to AUTO in
the INPUT menu.
Automatic Adjustment for RGB Input
Automatic Adjustment for Video Input
VIDEO
ASPECT
HOME
END
MUTE
PAGE DOWN
KEYSTONEFREEZE
OFF
ON
MENUPOSITION
ENTER
ESC RESET
PAGE UP VOLUME
MAGNIFY
AUTO BLANK
RGB SEARCH
STANDBY/ON
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ19
AUTO
20
• This function may not be work well with some types of input signals.
• The adjustable range for correcting keystone distortions will vary with the type of
input signal.
NOTE
CORRECTING KEYSTONE DISTORTIONS
1
Press the KEYSTONE button
As illustrated on the right, a dialog will appear
on the screen to aid you in correcting the
distortion.
2
Use the , buttons to select the
direction of distortion to correct ( / )
3
Use the , buttons to correct the
distortion
Press the KEYSTONE button again to close the dialog and
complete this operation. (Even if you don't do anything, the
dialog will automatically disappear after a few seconds.)
VIDEO
ASPECT
HOME
END
MUTE
PAGE DOWN
KEYSTONEFREEZE
OFF
ON
MENUPOSITION
ENTER
ESC RESET
PAGE UP VOLUME
MAGNIFY
AUTO BLANK
RGB SEARCH
STANDBY/ON
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ20
KEYSTONE
KEYSTONE
16
21
ENGLISH
The projector will automatically exit from MAGNIFY mode if either the INPUT SELECT,
AUTO, ASPECT or VIDEO feature is used, or, if there is a change in the input signal's state.
NOTE
•
The projector will automatically exit from FREEZE mode if either the POSITION, VOLUME, MUTE, AUTO,
BLANK ON/OFF or MENU ON/OFF feature is used, or, if there is a change in the input signal's state.
•
If the projector continues projecting the same image for a long time (i.e. you forget to exit FREEZE mode),
the image might possibly remain as an afterimage. Do not leave the projector in FREEZE mode for too long.
NOTE
USING THE MAGNIFY FEATURE
FREEZING THE SCREEN
1
Press the MAGNIFY (ON) button
The projector enters MAGNIFY mode.
2
Press the POSITION button, then use the ,,
, buttons to select the area to enlarge and then
press the POSITION button again to confirm your
selection
3
Press the , buttons to zoom in and
out of the selected area.
Press the MAGNIFY (OFF) button to exit MAGNIFY mode
and restore the screen to normal. (The projector will also
automatically exit MAGNIFY mode if there is a change in the
input signal's state.)
1
Press the FREEZE button
The [II] icon appears and the screen will freeze at
the current image. Press the FREEZE button again
and the [ ] appears as the projector exits FREEZE
mode.
MAGNIFY
HOME
END
MUTE
PAGE DOWN
KEYSTONEFREEZE
OFF
ON
MENUPOSITION
PAGE UP VOLUME
MAGNIFY
▲
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ21
RGB SEARCH
AUTO BLANK
HOME
PAGE UP VOLUME
END
PAGE DOWN
ENTER
STANDBY/ON
KEYSTONEFREEZE
VIDEO
ASPECT
MAGNIFY
ON
OFF
ESC RESET
MUTE
MENUPOSITION
POSITION
MAGNIFY
ON
POSITION
FREEZE
22
SIGNAL SEARCHING
SELECTING THE ASPECT RATIO
TEMPORARILY BLANKING THE SCREEN
1
Press the SEARCH button
When you press the SEARCH button, the projector begins
searching for input signals. If it detects an input signal, the
search will cease and the projector will project the detected
signal. If the projector is unable to find an input signal at any of
its ports, it will return to the state it was in prior to the search.
1
Press the ASPECT button
RGB IN 1, RGB IN 2,
VIDEO IN, S-VIDEO IN,
VIDEO
ASPECT
HOME
END
MUTE
PAGE DOWN
KEYSTONEFREEZE
OFF
ON
PAGE UP VOLUME
MAGNIFY
AUTO BLANK
RGB SEARCH
STANDBY/ON
VIDEO
ASPECT
HOME
END
MUTE
PAGE DOWN
KEYSTONEFREEZE
OFF
ON
MENUPOSITION
ENTER
ESC RESET
PAGE UP VOLUME
MAGNIFY
AUTO BLANK
RGB SEARCH
STANDBY/ON
L
1
VIDEO
ASPECT
HOME
END
MUTE
PAGE DOWN
KEYSTONEFREEZE
OFF
ON
MENUPOSITION
PAGE UP VOLUME
MAGNIFY
AUTO BLANK
RGB SEARCH
STANDBY/ON
Press the BLANK button
The input signal screen is shut off, and a blank screen
appears. You can set the blank screen using the menu
(from the SCREEN menu, select BLANK). Press the BLANK
button again to remove the blank screen, and return to the
input signal screen.
BLANK
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ22
SEARCH
RGB IN 1 RGB IN 2
S-VIDEO IN
ASPECT
4:3 16:9
4:3 16:9 SMAL
VIDEO IN
23
ENGLISH
USING THE MENU FUNCTIONS
1
Press the MENU button
The menu display appears on the screen. The
projector has the following menus: MAIN,
PICTURE-1, PICTURE-2, INPUT, SCREEN, and
OPTION. Select a menu using the / buttons. The
current settings of the items that can be manipulated via the
selected menu appear.
2
Select a menu using the
/
buttons,
then press the or ENTER button.
The display of the selected menu appears.
[ex. Adjusting SHARPNESS]
Use the / buttons to select PICTURE-1, then press
the or ENTER button.
: SELECT
MENU
MAIN
PICTURE-1
PICTURE-2
INPUT
SCREEN
OPTION
COLOR BAL R
COLOR BAL B
SHARPNESS
COLOR
TINT
–1
+1
–1
+1
–1
3
Select an item using the
/
buttons, then press the
or ENTER button.
The operation display of the selected item appears. To adjust a numerical value,
press the or ENTER button again to switch to the single menu (small display
showing only the operation display area).
[ex. Adjusting SHARPNESS]
Use the / buttons to select SHARPNESS, then
press the or ENTER button.
4
Press the
/
buttons to adjust the level.
Press the MENU button to hide the menu and finish your operation. Alternatively,
press the or ESC button to return to the previous display.
[ex. Adjusting SHARPNESS]
Use the / buttons to adjust the SHARPNESS.
COLOR BAL R
COLOR BAL B
SHARPNESS
COLOR
TINT
0
MENU
: SELECT
MAIN
PICTURE-1
PICTURE-2
INPUT
SCREEN
OPTION
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ23
VIDEO
ASPECT
MAGNIFY
ON
OFF
ESC RESET
STANDBY/ON
RGB SEARCH
AUTO BLANK
HOME
PAGE UP VOLUME
END
PAGE DOWN
MUTE
KEYSTONEFREEZE
MENUPOSITION
ENTER
ENTER
MENU
ENTER
24
You can use the remote control as a simplified mouse or keyboard.
OPERATING THE PC SCREEN
CAUTION
Caution: Mistaken use of the mouse/keyboard control could damage your equipment.
•
Only connect to a PC.
•
Before connecting, read the manuals of the device you will connect.
•
Do not unplug the connector cables while the computer is operating.
•
It may not be possible to control notebook PCs, and other computers with built-in pointing devices (e.g.
track balls), using this remote control. In this case, before connecting go into BIOS (system setup) and
select external mouse, and disable the pointing devices. In addition, the mouse may not function if the
computer does not have the needed utility program. See your computer’s hardware manual for details.
•
The USB control can be used with Windows 95 OSR 2.1 or higher. It may not be possible to
use the remote control, depending on the computer’s configurations and mouse drivers.
•
The USB control can only be used for the functions listed above. You cannot do things like press two buttons
at once (for instance, pressing two buttons at the same time to move the mouse pointer diagonally).
•
This function is not available while the lamp is warming up (the POWER indicator flashes green), while adjusting the volume and
display, correcting for trapezoidal distortion, zooming in on the screen, using the BLANK function, or displaying the menu screen.
NOTES
PS/2, ADB, Serial Mouse Control
1. Turn off the projector and PC power, and connect the projector’s
CONTROL terminal to the computer via the mouse cable.
2.
If a USB cable is connected, disconnect it. If a USB cable is connected, the USB control
function is given priority, and mouse control from the CONTROL terminal will not function.
3. Turn on the projector power, then the computer.
The functions in the table below can be controlled. If you have difficulty with control,
restart the computer (either from the software or by pressing the restart button).
USB Mouse/Keyboard Control
1.
Connect the projector’s USB terminal to the computer using a USB cable.
The functions in the table below can be controlled.
Available Functions Remote Control Operation
Move Pointer
Use buttons
Left click with mouse Press ENTER button
Right click with mouse Press RESET button
Available Functions Remote Control Operation
Move Pointer
Use buttons
Left click with mouse Press ENTER button
Right click with mouse Press RESET button
Press keyboard’s HOME key Press HOME button
Press keyboard’s END key Press END button
Press keyboard’s PAGE UP key Press PAGE UP button
Press keyboard’s PAGE DOWN key Press PAGE DOWN button
Press keyboard’s ESC key Press ESC button
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ24
RGB SEARCH
AUTO BLANK
HOME
PAGE UP VOLUME
END
PAGE DOWN
ENTER
STANDBY/ON
MUTE
KEYSTONEFREEZE
MENUPOSITION
VIDEO
ASPECT
MAGNIFY
ON
OFF
ESC RESET
25
ENGLISH
THE LAMP
HIGH VOLTAGE
HIGH TEMPERATURE
HIGH PRESSURE
Before replacing the lamp, check the serial number of the replacement lamp bulb (sold separately:
DT00511 for ED-S3170A/DT00521 for ED-X3270A), then contact your local dealer. Before replacing
the lamp, turn off the power, and unplug the power cord, then wait at least 45 minutes, in order to
ensure that the lamp is properly cooled. Removing the lamp bulb while it is still hot could cause
burns, or cause the lamp bulb to burst.
The LCD projector uses a glass lamp bulb. It is a mercury lamp with high
internal pressure. High-pressure mercury lamps can break with a loud
bang, or burn out, if jolted or scratched, or through wear over time. Each lamp has a
different lifetime, and some may burst or burn out soon after you start using them. In
addition, when the bulb bursts, it is possible for shards of glass to fly into the lamp housing,
and for gas containing mercury to escape from the projector’s vent holes.
•
Handle with care: jolting or scratching could cause the lamp bulb to burst during use.
•
If the replace lamp indicator (see "Related Messages" (Vol.2 ) and "Regarding the
indicator Lamps" (Vol.2 )) comes on, replace the lamp as soon as possible. Using the
lamp for long periods of time, or past the replacement date, could cause it to burst. Do
not use old (used) lamps; this is a cause of breakage.
•
If the lamp breaks soon after the first time it is used, it is possible that there are electrical problems
elsewhere besides the lamp. If this happens, contact your local dealer.
•
If the lamp should break (it will make a loud bang when it does), ventilate the room well, and make
sure not to breathe the gas that comes out of the projector vents, or get it in your eyes or mouth.
•
If the lamp should break (it will make a loud bang when it does), unplug the power cord from
the outlet, and make sure to request a replacement lamp from your local dealer. Note that
shards of glass could damage the projector’s internals, or cause injury during handling, so
please do not try to clean the projector or replace the lamp yourself.
•
Obey local ordinances when disposing of used lamps. In most cases, it is possible to dispose of used
bulbs in the same manner as used glass bottles, but in some cases, bulbs are sorted separately.
• Do not use the projector with the lamp cover removed.
WARNING
7
8
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ25
26
• The LAMP indicator is also red when the lamp unit reaches high temperature.
Before replacing the lamp, switch power OFF, wait approximately 20 minutes, and switch power
ON again. If the LAMP indicator is still red, replace the lamp.
NOTE
THE LAMP (continued)
Replacing the lamp
All projector lamps will wear out eventually. If used for long periods of time, the image could become
darkened, and the color contrast could be impacted as well. We recommend that you replace your lamps
early. If the LAMP indicator turns red, or a message prompts you to replace the lamp when you power up
the projector, the lamp needs to be replaced. (See "Related Messages" (Vol.2 ) and "Regarding the
Indicator Lamps" (Vol.2 ) for details.)
1
Turn off the projector, and unplug the
power cord. Allow the lamp bulb to cool
for at least 45 minutes, and prepare a
new lamp (sold separately: DT00511 for
ED-S3170A/DT00521 for ED-X3270A)
5
Insert the new lamp, and tighten the 1
screw firmly to lock it in place
•
Also steadily push the opposite side of the
screwed side of the
lamp into the unit.
6
Replace the lamp cover, and tighten
the 2 screws firmly to lock it in
place
7
Slowly turn the projector so that
the top is facing up
2
After making sure that the projector has
cooled adequately, slowly flip over the
projector, so that the bottom is facing up
3
Unscrew the 2
screws, and
remove the
lamp cover
4
Unscrew the 1 screw, and slowly pull
out the lamp by the handle
•
Be careful not to touch the inside of the lamp case.
27
ENGLISH
THE AIR FILTER
Caring for the air filter
The air filter should be cleaned about every 100 hours. If the LAMP indicator and
TEMP indicator blink red simultaneously, or a message prompts you to clean the air
filter when you turn on the unit, the filter needs to be cleaned. (See "Related
Messages" (Vol.2 ) and "Regarding the Indicator Lamps" (Vol.2 ) for details.)
1
Turn off the projector, and unplug the power cord
2
Apply a vacuum cleaner to
the top of the air filter cover
to clean the air filter
3
Turn on the projector, and use the menu to reset the filter
timer
• To reset the air filter timer, from the OPTION menu, select FILTER TIME.
7 8
Air Filter Cover
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ27
28
THE AIR FILTER (continued)
Replacing the air filter
If the soiling will not come off the air filter, or it becomes damaged, then it needs to be
replaced. Please contact your local dealer, after confirming the model of your
separately sold replacement air filter. (See "Optional Parts" on Vol.2 .)
1
Turn off the projector, and unplug the power cord. Prepare a
new air filter (one specified for your projector)
2
Remove the air filter cover and air filter
4
Turn on the projector power, and using the menu, reset the
filter timer
• To reset the lamp timer, from the OPTION menu, select FILTER TIME.
3
Insert the new filter, and replace the
filter cover
ATTENTION • Make sure to turn off the power and unplug the power cord before caring for
the unit. Please carefully read "Safety Instructions", in order to care for your projector correctly.
• Do not use with air filter cover removed.
• If the air filter becomes clogged by dust or the like, internal temperature rises and could cause
malfunction. The power is automatically turned off in order to prevent the unit from overheating
internally.
10
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ28
29
ENGLISH
OTHER CARE
Caring for the inside of the projector :
In order to ensure the safe use of your projector, please have it cleaned and inspected by
your local dealer about once every 2 years. Never try to care for the inside of the unit
yourself. Doing so is dangerous.
Caring for the lens :
Lightly wipe the lens with a commercially available lens-cleaning wipe. Do not touch the
lens directly with your hand.
Caring for the cabinet and remote control transmitter :
Wipe lightly with gauze or a soft cloth. If soiling is severe, dip a soft cloth in water or a
neutral cleanser diluted in water, and wipe lightly after wringing well. Then, wipe lightly
with a soft, dry cloth.
ATTENTION • Make sure to turn off the power and unplug the power cord before caring for
the unit. Please carefully read "Safety Instructions" in this manual, in order to care for your projector
correctly.
• Do not use cleaners or chemicals other than those listed above, including benzene and paint
thinner.
• Do not use aerosols or sprays.
• Do not polish or wipe with hard objects.
01ED-S317-27/Vol1/E/初02.12.17 8:57AMページ29
ENGLISH
1
LCD Projector ED-S3170A/ED-X3270A
USER'S MANUAL
USER'S MANUAL Vol.2 (Extended)
Thank you for purchasing this projector.
• The information in this manual is subject to change without notice.
• The manufacturer assumes no responsibility for any errors that may appear in this manual
• The reproduction, transmission or use of this document or contents is not permitted without express
written authority.
TRADEMARK ACKNOWLEDGEMENT :
• PS/2, VGA and XGA are registered trademarks of the International Business Machines Corporation.
• Apple, Mac and ADB are registered trademarks of Apple Computer, Inc.
• VESA and SVGA are trademarks of the Video Electronics Standard Association.
• Windows is a registered trademark of Microsoft Corporation.
• All other trademarks are the property of their respective owners.
NOTE
WARNING • Please read the accompanying manual “SAFETY
INSTRUCTIONS” and this “USER'S MANUAL” thoroughly to ensure correct
usage through understanding. After reading, store this instruction manual in a
safe place for future reference.
Page
MULTIFUNCTIONAL SETTINGS........................................................................2
WHAT TO DO WHEN YOU THINK A MACHINE DEFECT HAS OCCURRED ......7
SPECIFICATIONS .............................................................................................10
WARRANTY AND AFTER-SERVICE................................................................11
.......................................................................................
For "TECHNICAL" see the end of this manual.
CONTENTS
ED-S3170/X3270/Vol.2/ENG02.12.17 10:15 AMページ1
MAIN Menu
Item Description
BRIGHT
Adjust Brightness: Light ⇔ Dark
CONTRAST
Adjust Contrast: Strong ⇔ Weak
ASPECT
Select Aspect Ratio:
At RGB Input:
4:3 ⇔ 16:9
At VIDEO Input, S-VIDEO Input:
4:3 ⇔ 16:9 ⇔ SMALL
• The SMALL picture may not be displayed correctly with certain input signals.
PICT.POSIT.
Select Picture Position (for 16:9/SMALL Picture):
TOP ⇔ CENTER ⇔ BOTTOM
GAMMA
Select Gamma Mode:
NORMAL ⇔ CINEMA ⇔ DYNAMIC
MIRROR
Select Mirror Status:
NORMAL ⇔ H:INVERT ⇔ V:INVERT ⇔ H&V:INVERT
LANGUAGE
Select Menu Language:
ENGLISH ⇔ FRANÇAIS ⇔ DEUTSCH ⇔ ESPAÑOL
⇔ ITALIANO ⇔ NORSK ⇔ NEDERLANDS ⇔
日本語 ⇔ POTUGUÊS ⇔ 中文 ⇔
ENGLISH
PICTURE 1 Menu
PICTURE 2 Menu
With the PICTURE 1 menu, the five items shown in the Table
below can be performed.
Perform each operation in accordance with the instructions in the
Table.
With the PICTURE 2 menu, the five items shown in the Table
below can be performed.
Perform each operation in accordance with the instructions in the
Table.
Item Description
COLOR BAL R
Adjust Red Color Balance: Dark ⇔ Light
COLOR BAL B
Adjust Blue Color Balance: Dark ⇔ Light
SHARPNESS
Adjust Sharpness (for VIDEO/S-VIDEO): Clear ⇔ Soft
COLOR
Adjust COLOR (for VIDEO/S-VIDEO):
Dark ⇔ Light
TINT
Adjust Tint (for VIDEO/S-VIDEO): Green ⇔ Red
PICTURE1 Menu
Item Description
V POSITION
Adjust Vertical Position (for RGB): Up ⇔ Down
H POSITION
Adjust Horizontal Position (for RGB): Left ⇔ Right
H PHASE
Adjust Horizontal Phase (for RGB):
Right ⇔ Left
• Adjust to eliminate flicker.
H SIZE
Adjust Horizontal Size (for RGB): Large ⇔ Small
• If the horizontal size adjustment is excessive, the image may not be displayed
correctly. In such a case, initialize H SIZE with the RESET button.
OVER SCAN
Select Over-scan Ratio (for VIDEO/S-VIDEO):
LARGE ⇔ MIDDLE ⇔ SMALL
• It is recommended to select SMALL to avoid flicker at the lower part of the
picture.
3
PICTURE2 Menu
Example : PICTURE1 Menu
(COLOR BAL R)
Example : PICTURE2 Menu
(V POSITION)
ED-S3170/X3270/Vol.2/ENG02.12.17 10:15 AMページ3
MENU
MAIN
COLOR BAL R
PICTURE-1
COLOR BAL B
PICTURE-2
SHARPNESS
INPUT
COLOR
SCREEN
TINT
OPTION
: SELECT
12
MENU
MAIN
V POSITION
PICTURE-1
H POSITION
PICTURE-2
H PHASE
INPUT
H SIZE
SCREEN
OVER SCAN
OPTION
: SELECT
12
MULTIFUNCTIONAL SETTINGS (continued)
INPUT Menu
With the INPUT menu, the four items shown in the Table below can be
performed. With inputting of RGB IN 1 and RGB IN 2 signals, the
horizontal and vertical frequencies of the signals will be displayed on the
initial screen of the INPUT menu.
Perform each operation in accordance with the instructions in the Table.
4
Item Description
AUTO
Auto Adjust (for RGB): Automatically adjusts H POSITION, V POSITION, H
PHASE, and H SIZE. Use this function with the maximum window size.
Auto Adjust (for VIDEO/S-VIDEO): Automatically selects the proper VIDEO
mode for the current input signal. This function is active only when the AUTO
mode is selected for the item VIDEO. Refer to the description for the item
VIDEO below.
• This function may not be available with a PAL60 signal and certain other
signals.
• The AUTO mode operation requires approximately 10 seconds.
VIDEO
Select Mode of Signal Type (for VIDEO/S-VIDEO):
AUTO ⇔ NTSC ⇔ PAL ⇔ SECAM ⇔
NTSC4.43 ⇔ M-PAL ⇔ N-PAL
Selecting AUTO mode activates and performs the AUTO function for VIDEO/SVIDEO. It automatically selects the proper mode from among those above.
Use this function if the image becomes unstable with VIDEO/S-VIDEO. (e.g.
The image becomes irregular, or lacks color.)
• AUTO mode may not function correctly with a PAL60 signal and certain other
signals.
• The AUTO mode operation requires approximately 10 seconds.
SYNC ON G
On/Off SYNC ON G Mode:
TURN ON ⇔ TURN OFF
Selecting TURN ON turns on the SYNC ON G mode. The SYNC ON G mode
allows reception of SYNC on G.
• In the SYNC ON G mode, the picture may be distorted with certain input
signals. In such a case, remove the signal connector so that no signal is
received and turn SYNC ON G off, and then reconnect the signal.
Example : INPUT Menu
(AUTO)
INPUT Menu
ED-S3170/X3270/Vol.2/ENG02.12.17 10:15 AMページ4
MENU
MAIN
AUTO
PICTURE-1
VIDEO
PICTURE-2
SYNC ON G
INPUT
SCREEN
OPTION
: SELECT
EXECUTE
ENGLISH
SCREEN Menu
With the SCREEN menu, the five items shown in the Table below can be performed.
Please perform each operation in accordance with the instructions in the Table.
5
SCREEN Menu
Item Description
MULTIFUNCTIONAL SETTINGS (continued)
OPTION Menu
With the OPTION menu, the five items shown in the Table below
can be performed.
Please perform each operation in accordance with the instructions
in the Table.
Item Description
VOLUME
Adjust Volume: High ⇔ Low
AUTO OFF
Adjust AUTO OFF Time:
Long (MAX. 99 min.) ⇔ Short (Min. 1 min.) ⇔ (DISABLE: 0 min.)
The system automatically enters the standby mode if no signal is received
within the set time. This function is inactive when DISABLE (0 min.) is selected.
WHISPER
Select WHISPER Mode:
NORMAL ⇔ WHISPER
When WHISPER is selected the WHISPER mode is activated. In the WHISPER
mode, acoustic noise and screen brightness are reduced.
LAMP TIME
Refer to LAMP TIME: When set, this function displays the total time the
projector lamp has been used since new.
Reset LAMP TIME [Use this function only when the lamp has been replaced!]:
Depress the RESET button for at least 3 seconds while lamp time is being
displayed. The reset menu will then appear. After you replace the lamp with a
new lamp, select RESET on the menu with the button.
• Do not reset the lamp time unless you have replaced the lamp. And, always
reset the lamp time when replacing the lamp. The message functions will not
operate properly if the lamp time is not reset correctly.
• Before replacing the lamp, carefully read the descriptions headed "THE
LAMP".
FILTER TIME
Refer to FILTER TIME: This function displays the total time the air-filter has
been used since new.
Reset FILTER TIME [Use this function only when the filter is cleaned or replaced!]:
Depress the RESET button for at least 3 seconds while filter time is being
displayed. The reset menu will then appear. After you replace the filter, select
RESET on the menu with the button.
• Do not reset the filter time unless you have cleaned or replaced the filter. And,
always reset the filter time when cleaning or replacing the filter. The message
functions will not operate properly if the filter time is not reset correctly.
•
Before cleaning or replacing the filter, carefully read the descriptions headed "THE AIR FILTER".
6
Example : OPTION Menu
(VOLUME)
OPTION Menu
ED-S3170/X3270/Vol.2/ENG02.12.17 10:15 AMページ6
MENU
MAIN
VOLUME
PICTURE-1
AUTO OFF
PICTURE-2
WHISPER
INPUT
LAMP TIME
SCREEN
FILTER TIME
OPTION
: SELECT
12
ENGLISH
WHAT TO DO WHEN YOU THINK AMACHINE DEFECT HAS OCCURRED
Related Messages
When the unit's power is ON, messages such as those shown below may be displayed. When
any such message is displayed on the screen, please respond as described below.
7
Note 1: Although this message will be automatically disappeared after around 3 minutes, it will be
reappeared every time the power is turned ON.
Note 2: Lamps have a finite product life. Lamps are characterized by the fact that, after long hours of
usage, a lamp will no longer light up, or the lamp will break or burst, etc. This unit is equipped
with an automatic shut-down function, such that the power will automatically be turned OFF
when lamp usage time has reached 2,000 hours. Please be aware, however, that among lamp
types, there are major differences in product lifetimes; a lamp may thus fail to light even prior
to the functioning of the automatic shut-down function of this unit.
NOTES
Message Description
CHANGE THE LAMP
AFTER REPLACING LAMP,
RESET THE LAMP TIMER.
(Note 1)
Lamp usage time is approaching 2,000 hours. (Note 2)
Preparation of a new lamp, and an early lamp change, is
recommended. After you have changed the lamp, please be
sure to reset the lamp timer.
CHANGE THE LAMP
AFTER REPLACING LAMP,
RESET THE LAMP TIMER.
THE POWER WILL TURN OFF
AFTER
＊＊ hr.
(Note 1)
Lamp usage time is approaching 2,000 hours. A lamp change
within ＊＊ hours is recommended. (Note 2)
When lamp usage reaches 2,000 hours, the power will
automatically be turned OFF. Please change the lamp by
referring to “THE LAMP” in Vol.1 (Basic). After you have
changed the lamp, please be sure to reset the lamp
timer.
CHANGE THE LAMP
AFTER REPLACING LAMP,
RESET THE LAMP TIMER.
THE POWER WILL TURN OFF
AFTER 0 hr.
As lamp use has reached 2,000 hours, the power will soon be
automatically turned OFF. (Note 2)
Please immediately turn the power OFF, and follow the
instructions in the “THE LAMP” section of the separate booklet,
Vol.1 (Basic).
After you have changed the lamp, please be sure to reset the
lamp timer.
CLEAN THE AIR FILTER
AFTER CLEANING AIR FILTER,
RESET THE FILTER TIMER.
A note of precaution when cleaning the air filter.
After cleaning the filter, operate FILTER TIME of the OPTION
Menu, and perform reset of the filter timer.
NO INPUT IS DETECTED
ON ＊＊＊
There is no input signal.
Please confirm the signal input connection, and the status of the
signal source.
SYNC IS OUT OF RANGE
ON ＊＊＊ ＊＊＊＊＊
kHz
＊＊＊＊＊
Hz
The horizontal or vertical wavelength of the inputted signal is
outside of the response parameters of this unit. Please confirm
the specs for this unit or the signal source specs.
CHECK THE AIR FLOW
The internal portion temperature is rising. Please turn the power
OFF, and allow the unit to cool down for approximately 20
minutes. After having confirmed the following items, then please
resent the power to ON.
•
Is there blockage of the air passage aperture?
•
Is the air filter dirty?
•
Does the peripheral temperature exceed 35°C?
fH
fV
ED-S3170/X3270/Vol.2/ENG02.12.17 10:15 AMページ7
Regarding the Indicator Lamps
Lighting and flashing of the POWER indicator, the LAMP indicator, and the
TEMP indicator have the meanings as described in the Table below.
Please respond in accordance with the instructions within the Table.
POWER
indicator
LAMP
indicator
TEMP
indicator
Description
The orange
lamp is lighted
Turned OFF
(Not lighted)
Turned OFF
(Not lighted)
The STANDBY mode is set
Flashing of the green lamp
Turned OFF Turned OFF
The unit is warming up. Please wait.
The green lamp is lighted
Turned OFF Turned OFF
The unit is in an ON state. Ordinary operations may be performed.
Flashing of the orange lamp
Turned OFF Turned OFF
The unit is cooling down. Please wait.
Blinking of the
red lamp
- -
The unit is cooling down. Please wait.
A certain error has been detected. Wait until the POWER indicator lamp has finished
flashing, and then perform the proper response measure using the item descriptions
below as reference.
The red lamp
is lighted, or
blinks
The red lamp
is lighted
Turned
OFF
The lamp does not light.
There is a possibility that the interior portion has become heated. Turn the power OFF and wait
approximately 20 minutes. After the main unit has cooled down, please confirm whether or not
there is blockage of the air passage aperture, whether or not the filter is dirty, and/or whether or
not the peripheral temperature exceeds 35°C, etc. After performing any needed maintenance,
turn the power ON again; if the same display is displayed, then please change the lamp.
The red lamp
is lighted, or
blinks
Blinking of the
red lamp
Turned
OFF
Either there is no lamp and/or lamp cover, or either of these has not been properly fixed
(attached). Turn the power OFF and wait approximately 45 minutes. After the main unit has
sufficiently cooled down, please make confirmation of the attachment state of the lamp and
lamp cover. After performing any needed maintenance, turn the power ON again; if the same
display is displayed, then please contact a sales store or a service company.
The red lamp
is lighted, or
blinks
Turned
OFF
Blinking of the
red lamp
The cooling fan is not operating. Turn the power OFF and wait approximately 20 minutes. After the
main unit has cooled down, please make confirmation that no foreign matter has become caught in
the fan, etc. After performing any needed maintenance, turn the power ON again; if the same display
is displayed, then please contact a sales store or a service company.
The red lamp is
lighted, or
blinks
Turned
OFF
The red lamp is
lighted
There is a possibility that the interior portion has become heated. Turn the power OFF and wait
approximately 20 minutes. After the main unit has cooled down, please confirm whether or not
there is blockage of the air passage aperture, whether or not the filter is dirty, and/or whether or
not the peripheral temperature exceeds 35°C, etc. After performing any needed maintenance,
turn the power ON again; if the same display is displayed, then please contact a sales store or a
service company.
The green lamp
is lighted
Alternative blinking
with the red lamp
There is a possibility that the interior portion has become overcooled. Please use the unit within
the usage temperature parameters (0°C to 35°C). After performing any needed maintenance,
turn the power ON again; if the same display is displayed, then please contact a sales store or a
service company.
The green
lamp is lighted
Simultaneous blinking
with the red lamp
This is a notification that it is time to clean the filter.
After cleaning the filter, operate the FILTER TIME portion of the OPTION Menu, and perform
reset of the FILTER TIME.
When the interior portion has become overheated, for safety purposes, the power source is automatically turned OFF,
and the indicator lamps may also be turned OFF. Press the “
○
” (power OFF) side of the main power switch, and wait
for approximately 20 minutes. Please then use the unit only after having first confirmed that the unit has sufficiently
cooled down.
NOTE
8
ED-S3170/X3270/Vol.2/ENG02.12.17 10:15 AMページ8
ENGLISH
9
WHAT TO DO WHEN YOU THINK A MACHINE DEFECT HAS OCCURRED (continued)
Phenomena That May Easily Be Mistaken for Machine Defects
Before requesting repair, check in accordance with the following chart.
If the situation cannot be corrected, then contact your dealer.
Although bright spots or dark spots may appear on the screen, this is a unique characteristic of liquid crystal displays, and
such do not constitute or imply a machine defect.
NOTE
Phenomenon
Cases not involving a machine defect
Items to be confirmed
Reference
Page(s)
Power does not
come ON
The main power source is not ON.
Turn on the main power.
Vol.1-3, 14
The electrical power cord is not plugged in. Correctly connect the power cord.
The main power source has been
interrupted during operation, such as by
a power outage (blackout), etc.
Be sure to press the “O” (power OFF) side
of the main power switch, and leave this OFF
for approximately 20 minutes. After the unit
has sufficiently cooled down, turn ON the
power source.
Vol.1-14
No sound or
pictures are
outputted
The input changeover settings
are mismatched.
Select the input signal, and
correct the settings.
Vol.1-15
No signal is being inputted.
Correctly connect the connection cord.
Vol.1-10, 11
Pictures are
displayed, but no
sounds are heard
The electrical wiring to this unit
is not correctly connected.
Correctly connect the connection cord.
Vol.1-10, 11
The volume setting has been set at (or
adjusted to) an extremely low level.
Adjust the VOLUME setting to a higher level.
Vol.1-17
The MUTE mode is the current setting.
Press the MUTE button to release
(change) the MUTE mode setting.
Vol.1-17
Sounds are
heard, but no
pictures are
displayed
The electrical wiring to this unit
is not correctly connected.
Correctly connect the connection cord.
Vol.1-10, 11
The brightness setting has been set at
(or adjusted to) an extremely low level.
Adjust the BRIGHT setting to a
brighter level.
Vol.2-2
The lens cap has not been removed.
Remove the lens cap.
Vol.1-14
Colors have a fadedout appearance
Color tone is poor
Color depth setting or color tone setting
Perform picture adjustments by changing the
COLOR BAL R, the COLOR BAL B, and/or the
TINT settings, etc.
Vol.2-3
Pictures appear
dark
The brightness setting and/or contrast
setting has not been properly adjusted.
Perform picture adjustments by changing the
BRIGHT and/or CONTRAST settings, etc.
Vol.2-2
The WHISPER mode is the current
setting.
Change (by releasing) from the
WHISPER mode.
Vol.2-6
Lamp is approaching the end of its
product lifetime.
Exchange the old lamp with a new
lamp.
Vol.1-25, 26
Pictures appear
blurry
Either the FOCUS setting or the H
PHASE is not properly adjusted.
Adjust the FOCUS and H PHASE settings.
Vol.1-15
Vol.2-3
9
ED-S3170/X3270/Vol.2/ENG02.12.17 10:15 AMページ9
Dimension Diagram
Unit : mm
Item Specification
Product name Liquid crystal projector
Liquid
crystal
panel
Panel size 1.8 cm (0.7 type)
Drive system TFT active matrix
Pixels
ED-S3170A：480,000 pixels (800 horizontal x600 vertical)
ED-X3270A：786,432 pixels (1024 horizontal x 768 vertical)
Lens Zoom lens F=1.7 ~ 1.9 f=21.7 ~ 26.1 mm
Lamp 150 W UHB
Speaker 1.0W
Power supply AC100 ~ 120V, 2.7A / AC220 ~ 240V, 1.3A
Power consumption 240W
Temperature range 0 ~ 35°C (Operating)
Size 295 (W) x 87.5 (H) x237 (D) mm
Weight (mass) 2.7 kg
Ports
Optional Parts
Lamp: ED-S3170A=DT00511, ED-X3270A=DT00521
Air Filter: MU01691
* For others, consult your dealer.
RGB Ports
RGB IN(1, 2) ..................2
VIDEO Ports
VIDEO IN ........................1
S-VIDEO IN ....................1
AUDIO Ports
AUDIO IN(1,2) ................2
AUDIO IN(R, L) ..............1
RGB OUT Ports
RGB OUT........................1
AUDIO OUT Ports
AUDIO OUT....................1
CONTROL Ports
CONTROL ......................1
USB ................................1
• This specifications are subject to change without notice.
NOTE
SPECIFICATIONS
10
ED-S3170/X3270/Vol.2/ENG02.12.17 10:15 AMページ10
237
87.5
295
231
77.5
37
50.5
ENGLISH
If a problem occurs with the equipment, first refer to the “WHAT TO DO WHEN YOU
THINK A MACHINE DEFECT HAS OCCURRED” section and run through the suggested
checks. If this does not resolve the problem contact your dealer or service company. They
will tell you what warranty condition is applied.
WARRANTY AND AFTER-SERVICE
11
7
ED-S3170/X3270/Vol.2/ENG02.12.17 10:15 AMページ11
1
TECHNICAL
TECHNICAL
TECHNICAL
SIGNAL CONNECTOR PIN ASSIGNMENT
RGB IN [1]/[2]
RGB OUT
D-sub 15-pin Shrink Mini Din 4-pin
S-VIDEO
Mini Din 4-pin
Pin No
Signal
1
Color:
0.286Vp-p (NTSC, burst signal),
75Ω terminator
0.3Vp-p (PAL/SECAM, burst signal),
75Ω terminator
2
Brightness:
1.0Vp-p, 75Ω terminator
3 Ground
4 Ground
signal Terminal Specification
RGB signal
input
RGB IN（1、2）
Video: Analog 0.7Vp-p, 75Ω terminator (positive)
H/V. sync.: TTL level (positive/negative)
Composite sync.: TTL level
D-sub 15-pin shrink jack
AUDIO IN 1
200mVrms,50kΩ (max.3.Ovp-p)
Stereo mini jack
AUDIO IN 2
Video signal
input
VIDEO IN 1.0Vp-p, 75Ω terminator, RCA jack
S-VIDEO IN
Brightness signal: 1.0Vp-p, 75Ω terminator
Color signal: 0.286Vp-p (NTSC, burst signal),75Ω terminator
0.300Vp-p (PAL/SECAM, burst signal),75Ω terminator
Mini DIN 4-pin jack
AUDIO IN（R、L）
200mVrms, 50 kΩ (max. 3.0Vp-p)
RCA jack
Signal output
RGB OUT
Video: Analog 0.7Vp-p, 75Ω output impedance (positive)
H/V. sync.: TTL level (positive/negative)
Composite sync.: TTL level
D-sub 15-pin shrink jack
AUDIO OUT
200mVrms, out put impedance1kΩ (max.3.Ovp-p)
Stereo mini jack
Pin No Signal Pin No Signal
1 Video input Red 9 -
2 Video input Green 10 Ground
3 Video input Blue 11 -
4 -
12
RGB IN [1]: SDA (DDC)
5 Ground RGB IN [2]: -
6 Ground Red RGB OUT : -
7 Ground Green 13
H. sync./ Composite sync.
8 Ground Blue 14 Vertical sync
15
RGB IN [1]: SCL (DDC)
RGB IN [2]: -
RGB OUT : -
ED-S3170/X3270/TECHNICAl02.12.179:25AMページ1
2
Resolution
H ××V
fH (kHz) fV (Hz) Rating Signal mode
Display mode
ED-S3170A ED-X3270A
720 × 400
37.9 85.0 VESA TEXT Zoom in Zoom in
640 × 480
31.5 59.9 VESA VGA (60Hz) Zoom in Zoom in
640 × 480
35.0 66.7 Mac13"mode Zoom in Zoom in
640 × 480
37.9 72.8 VESA VGA (72Hz) Zoom in Zoom in
640 × 480
37.5 75.0 VESA VGA (75Hz) Zoom in Zoom in
640 × 480
43.3 85.0 VESA VGA (85Hz) Zoom in Zoom in
800 × 600
35.2 56.3 VESA SVGA (56Hz) Zoom in
800 × 600
37.9 60.3 VESA SVGA (60Hz) Zoom in
800 × 600
48.1 72.2 VESA SVGA (72Hz) Zoom in
800 × 600
46.9 75.0 VESA SVGA (75Hz) Zoom in
800 × 600
53.7 85.1 VESA SVGA (85Hz) Zoom in
832 × 624
49.7 74.5 Mac16"mode Zoom out Zoom in
1024 × 768
48.4 60.0 VESA XGA (60Hz) Zoom out
1024 × 768
56.5 70.1 VESA XGA (70Hz) Zoom out
1024 × 768
60.0 75.0 VESA XGA (75Hz) Zoom out
1024 × 768
68.7 85.0 VESA XGA (85Hz) Zoom out
1152 × 864
67.5 75.0 VESA SXGA (75Hz) Zoom out Zoom out
1280 × 960
60.0 60.0 VESA SXGA (60Hz) Zoom out Zoom out
1280 × 1024
64.0 60.0 VESA SXGA (60Hz) Zoom out Zoom out
1280 × 1024
80.0 75.0 VESA SXGA (75Hz) Zoom out Zoom out
1280 × 1024
91.2 85.0 VESA SXGA (85Hz) Zoom out Zoom out
1600 × 1200
75.0 60.0 VESA UXGA (60Hz) Zoom out Zoom out
EXAMPLE OF COMPUTER SIGNAL
• Some computers may have multiple display screen modes. Use of some
of these modes will not be possible with this projector.
• Be sure to check jack type, signal level, timing and resolution before connecting this
projector to a computer.
• Depending on the input signal, full-size display may not be possible in some cases.
Refer to the number of display pixels above.
• This projector will display up to UXGA (1600X1200) resolution signals but the image
will be rescaled to the native resolution of the projector. Best display performance is
achieved when the signal input resolution is the same as the native resolution of the
projector.
• The image may not be displayed correctly when the input sync. signal is “Composite
Sync.” or “Sync. on G”.
NOTE
ED-S3170/X3270/TECHNICAl02.12.179:25AMページ2
3
TECHNICAL
The following signals are used for the initial settings.
The signal timing of some computer models may be different. In such case, refer to
adjust the V.POSIT and H.POSIT of the menu.
DATA
HSYNC
DATA
VSYNC
Display interval c
Back porch b
Sync a
Front porch d
Display interval c
Back porch b
Sync a
Front porch d
Computer /
Signal
Horizontal signal timing (µs)
a b c d
TEXT 2.0 3.0 20.3 1.0
VGA (60Hz) 3.8 1.9 25.4 0.6
Mac 13"mode 2.1 3.2 21.2 2.1
VGA (72Hz) 1.3 3.8 20.3 1.0
VGA (75Hz) 2.0 3.8 20.3 0.5
VGA (85Hz) 1.6 2.2 17.8 1.6
SVGA (56Hz) 2.0 3.6 22.2 0.7
SVGA (60Hz) 3.2 2.2 20.0 1.0
SVGA (72Hz) 2.4 1.3 16.0 1.1
SVGA (75Hz) 1.6 3.2 16.2 0.3
SVGA (85Hz) 1.1 2.7 14.2 0.6
Mac 16"mode 1.1 3.9 14.5 0.6
XGA (60Hz) 2.1 2.5 15.8 0.4
XGA (70Hz) 1.8 1.9 13.7 0.3
XGA (75Hz) 1.2 2.2 13.0 0.2
XGA (85Hz) 1.0 2.2 10.8 0.5
1152×864 (75Hz)
1.2 2.4 10.7 0.6
1280×960 (60Hz)
1.0 2.9 11.9 0.9
1280×1024 (60Hz)
1.0 2.3 11.9 0.4
1280×1024 (75Hz)
1.1 1.8 9.5 0.2
1280×1024 (85Hz)
1.0 1.4 8.1 0.4
1600×1200 (60Hz)
1.2 1.9 9.9 0.4
Computer /
Signal
Vertical signal timimg (lines)
a b c d
TEXT 3 42 400 1
VGA (60Hz) 2 33 480 10
Mac 13"mode 3 39 480 3
VGA (72Hz) 3 28 480 9
VGA (75Hz) 3 16 480 1
VGA (85Hz) 3 25 480 1
SVGA (56Hz) 2 22 600 1
SVGA (60Hz) 4 23 600 1
SVGA (72Hz) 6 23 600 37
SVGA (75Hz) 3 21 600 1
SVGA (85Hz) 3 27 600 1
Mac 16"mode 3 39 624 1
XGA (60Hz) 6 29 768 3
XGA (70Hz) 6 29 768 3
XGA (75Hz) 3 28 768 1
XGA (85Hz) 3 36 768 1
1152×864 (75Hz)
3 32 864 1
1280×960 (60Hz)
3 36 960 1
1280×1024 (60Hz)
3 38 1024 1
1280×1024 (75Hz)
3 37 1024 2
1280×1024 (85Hz)
3 44 1024 1
1600×1200 (60Hz)
3 46 1200 1
INITIAL SET SIGNALS
ED-S3170/X3270/TECHNICAl02.12.179:25AMページ3
4
1
2
3
4
5
678
9
10
11 12
13
14
15
CONNECTION TO THE MOUSE CONTROL
1
2
3
4
1
2
3
4
+
5V
—
DATA
+
DATA
GND
+
5V
—
DATA
+
DATA
GND
1
234
2
1
3
4
USB jack
(B type)
USB jack
(A type)
Projector
USB cable
Computer
ADB Mouse
2
1
4
3
6
5
2
1
4
3
8
7
10
9
12
11
14
13
15
RTS
GND
+5V
ADB
GND
+5V
(
POWER ON
)
DATA
2
1
4
3
Mouse jack
Mini DIN 4-pin
Projector
Computer
CONTROL Terminal
D-sub 15-pin shrink jack
Serial Mouse
2
1
4
3
6
5
2
1
4
3
6
5
8
7
10
9
8
7
9
12
11
14
13
15
RI
CD
RD
TD
DTR
GND
DSR
CTS
RTS
RTS
GND
SEL0
TD
21
4
3
6
5
8
9
7
Mouse jack
D-sub 9-pin
Projector
Computer
1
2
3
4
5
678
9
10
11 12 13
14
15
CONTROL Terminal
D-sub 15-pin shrink jack
USB Mouse
PS/2 Mouse
2
1
4
3
6
5
2
1
4
3
6
5
8
7
10
9
12
11
14
13
15
CLK
DATA
SEL0
RTS
GND
+5V
DATA
GND
+5V
CLK
2
1
4
3
6
5
Mouse jack
Mini DIN 6-pin
Projector
Computer
1
2
3
4
5
678
9
10
11 12 13
14
15
CONTROL Terminal
D-sub 15-pin shrink jack
ED-S3170/X3270/TECHNICAl02.12.179:25AMページ4
5
TECHNICAL
(1)
Turn off the projector and computer power supplies and connect with the RS-232C cable.
(2) Turn on the computer power supply and after the computer has started up, turn on the
projector power supply.
Control jack
D-sub 15-pin shrink jack
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
RD
TD
GND
SELO
RTS
1
2
3
4
5
6
7
8
9
CD
RD
TD
DTR
GND
DSR
RTS
DTS
RI
1
2345
67
8
9
RS-232C jack
D-sub 9-pin
Projector Computer
Communications setting
19200bps, 8N1
1 Protocol
Consist of header (7 bytes) + command data (6 bytes).
2 Header
BE + EF + 03 + 06 + 00 + CRC_low + CRC_high
CRC_low : Lower byte of CRC flag for command data.
CRC_high : Upper byte of CRC flag for command data.
3 Command data
byte_0 byte_1 byte_2 byte_3 byte_4 byte_5
Action Type Setting code
low high low high low high
Command data chart
Action (byte_0 - 1)
Action Classification Content
1 SET Change setting to desired value.
2 GET Read projector internal setup value.
4 INCREMENT Increment setup value by 1.
5 DECREMENT Decrement setup value by 1.
6 EXECUTE Run a command.
RS-232C COMMUNICATION
ED-S3170/X3270/TECHNICAl02.12.179:25AMページ5
6
Requesting projector status (Get command)
(1) Send the request code Header + Command data (‘02H’+‘00H’+ type (2 bytes)
+‘00H’+‘00H’) from the computer to the projector.
(2) The projector returns the response code ‘1DH’+ data (2 bytes) to the computer.
Changing the projector settings (Set command)
(1) Send the setting code Header + Command data (‘01H’+‘00H’+ type (2 bytes) +
setting code (2 bytes)) from the computer to the projector.
(2) The projector changes the setting based on the above setting code.
(3) The projector returns the response code ‘06H’ to the computer.
Using the projector default settings (Reset Command)
(1) The computer sends the default setting code Header + Command data (‘06H’+‘00H’+
type (2 bytes) +‘00H’+‘00H’) to the projector.
(2) The projector changes the specified setting to the default value.
(3) The projector returns the response code ‘06H’ to the computer.
Increasing the projector setting value (Increment command)
(1) The computer sends the increment code Header + Command data (‘04H’+‘00H’+
type (2 bytes) +‘00H’+‘00H’) to the projector.
(2) The projector in creases the setting value on the above setting code.
(3) The projector returns the response code ‘06H’ to the computer.
Decreasing the projector setting value (Decrement command)
(1) The computer sends the decrement code Header + Command data (‘05H’+‘00H’+
type (2 bytes) +‘00H’ + ‘00H’) to the projector.
(2) The projector decreases the setting value on the above setting code.
(3) The projector returns the response code ‘06H’ to the computer.
When a command sent by the projector cannot be understood by the computer
When the command sent by the projector cannot be understood, the error command ‘15H’ is
returned by the computer. Some times, the projector ignores RS-232C commands during
other works. If the error command ‘15H’ is returned, please send the same command again.
When data sent by the projector cannot be practice
When the command sent by the projector cannot be practiced, the the error code ‘1cH’
+‘xxxxH’ is returned.
When the data length is greater than indicated by the data length code, the projector will
ignore the excess data code.
Conversely, when the data length is shorter than indicated by the data length code, an
error code will be returned to the projector.
RS-232C COMMUNICATION (continued)
• Operation cannot be guaranteed when the projector receives an
undefined command or data.
•
Provide an interval of at least 40ms between the response code and any other code.
• The projector outputs test data when the power supply is switched ON, and when the
lamp is lit. Ignore this data.
• Commands are not accepted during warm-up.
NOTE
ED-S3170/X3270/TECHNICAl02.12.179:25AMページ6
7
TECHNICAL
Command data chart
Names Operation type Header
Command data
CRC Action Type Setting code
Blank Color
Set
Blue BE EF 03 06 00 CB D3 01 00 00 30 03 00
White BE EF 03 06 00 6B D0 01 00 00 30 05 00
Black BE EF 03 06 00 9B D0 01 00 00 30 06 00
MyScreen BE EF 03 06 00 FB CA 01 00 00 30 20 00
ORIGNAL BE EF 03 06 00 FB E2 01 00 00 30 40 00
Get BE EF 03 06 00 08 D3 02 00 00 30 00 00
Mirror
Set
Normal BE EF 03 06 00 C7 D2 01 00 01 30 00 00
H Inverse BE EF 03 06 00 57 D3 01 00 01 30 01 00
V lnverse BE EF 03 06 00 A7 D3 01 00 01 30 02 00
H&V Inverse BE EF 03 06 00 37 D2 01 00 01 30 03 00
Get BE EF 03 06 00 F4 D2 02 00 01 30 00 00
Freeze
Set
Normal BE EF 03 06 00 83 D2 01 00 02 30 00 00
Freeze BE EF 03 06 00 13 D3 01 00 02 30 01 00
Get BE EF 03 06 00 B0 D2 02 00 02 30 00 00
Startup
Set
ORIGNAL BE EF 03 06 00 0B D2 01 00 04 30 00 00
OFF BE EF 03 06 00 9B D3 01 00 04 30 01 00
MyScreen BE EF 03 06 00 CB CB 01 00 04 30 20 00
Get BE EF 03 06 00 38 D2 02 00 04 30 00 00
Language
Set
English BE EF 03 06 00 F7 D3 01 00 05 30 00 00
Français BE EF 03 06 00 67 D2 01 00 05 30 01 00
Deutsch BE EF 03 06 00 97 D2 01 00 05 30 02 00
Español BE EF 03 06 00 07 D3 01 00 05 30 03 00
Italiano BE EF 03 06 00 37 D1 01 00 05 30 04 00
Norsk BE EF 03 06 00 A7 D0 01 00 05 30 05 00
Nederlands BE EF 03 06 00 57 D0 01 00 05 30 06 00
Português BE EF 03 06 00 C7 D1 01 00 05 30 07 00
日本語
BE EF 03 06 00 37 D4 01 00 05 30 08 00
中文
BE EF 03 06 00 A7 D5 01 00 05 30 09 00
BE EF 03 06 00 57 D5 01 00 05 30 0A 00
Get BE EF 03 06 00 C4 D3 02 00 05 30 00 00
Magnify
Get BE EF 03 06 00 7C D2 02 00 07 30 00 00
Increment BE EF 03 06 00 1A D2 04 00 07 30 00 00
Decrement BE EF 03 06 00 CB D3 05 00 07 30 00 00
Auto off
Get BE EF 03 06 00 08 86 02 00 10 31 00 00
Increment BE EF 03 06 00 6E 86 04 00 10 31 00 00
Decrement BE EF 03 06 00 BF 87 05 00 10 31 00 00
Brightness
Reset
Execute BE EF 03 06 00 58 D3 06 00 00 70 00 00
Contrast Reset Execute BE EF 03 06 00 A4 D2 06 00 01 70 00 00
V.Position
Reset
Execute BE EF 03 06 00 E0 D2 06 00 02 70 00 00
ED-S3170/X3270/TECHNICAl02.12.179:25AMページ7
8
Command data chart
(continued)
Names Operation type Header
Command data
CRC Action Type Setting code
H.Position Reset Execute BE EF 03 06 00 IC D3 06 00 03 70 00 00
H.Size Reset Execute BE EF 03 06 00 68 D2 06 00 04 70 00 00
Color Balance
R Reset
Execute BE EF 03 06 00 94 D3 06 00 05 70 00 00
Color Balance
B Reset
Execute BE EF 03 06 00 D0 D3 06 00 06 70 00 00
Sharpness Reset Execute BE EF 03 06 00 C4 D0 06 00 09 70 00 00
Color Reset Execute BE EF 03 06 00 80 D0 06 00 0A 70 00 00
Tint Reset Execute BE EF 03 06 00 7C D1 06 00 0B 70 00 00
Keystone_V Reset Execute BE EF 03 06 00 08 D0 06 00 0C 70 00 00
Keystone_H Reset Execute BE EF 03 06 00 98 D8 06 00 20 70 00 00
Auto Adjust Execute BE EF 03 06 00 91 D0 06 00 0A 20 00 00
Lamp Time Reset Execute BE EF 03 06 00 58 DC 06 00 30 70 00 00
Filter Time Reset Execute BE EF 03 06 00 98 C6 06 00 40 70 00 00
Blank on/off
Set
off BE EF 03 06 00 FB D8 01 00 20 30 00 00
on BE EF 03 06 00 6B D9 01 00 20 30 01 00
Get BE EF 03 06 00 C8 D8 02 00 20 30 00 00
Error Status Get
BE EF 03 06 00 D9 D8 02 00 20 60 00 00
(Example of Return)
00 00 01 00 02 00 03 00
(Normal) (Cover-error) (Fan-error) (Lamp-error)
04 00 05 00 06 00 07 00 08 00
(Temp-error) (Air flow-error) (Lamp-Time-over) (Cool-error) (Filter-Error)
Power
Set
OFF
BE EF 03 06 00 2A D3 01 00 00 60 00 00
ON
BE EF 03 06 00 BA D2 01 00 00 60 01 00
Get
BE EF 03 06 00 19 D3 02 00 00 60 00 00
Input Source
Set
RGB1 BE EF 03 06 00 FE D2 01 00 00 20 00 00
RGB2 BE EF 03 06 00 3E D0 01 00 00 20 04 00
Video BE EF 03 06 00 6E D3 01 00 00 20 01 00
SVideo BE EF 03 06 00 9E D3 01 00 00 20 02 00
Get BE EF 03 06 00 CD D2 02 00 00 20 00 00
Volume
Get BE EF 03 06 00 31 D3 02 00 01 20 00 00
Increment BE EF 03 06 00 57 D3 04 00 01 20 00 00
Decrement BE EF 03 06 00 86 D2 05 00 01 20 00 00
Mute
Set
Normal BE EF 03 06 00 46 D3 01 00 02 20 00 00
Mute BE EF 03 06 00 D6 D2 01 00 02 20 01 00
Get BE EF 03 06 00 75 D3 02 00 02 20 00 00
Brightness
Get BE EF 03 06 00 89 D2 02 00 03 20 00 00
Increment BE EF 03 06 00 EF D2 04 00 03 20 00 00
Decrement BE EF 03 06 00 3E D3 05 00 03 20 00 00
ED-S3170/X3270/TECHNICAl02.12.179:25AMページ8
9
TECHNICAL
Names Operation type Header
Command data
CRC Action Type Setting code
Contrast
Get BE EF 03 06 00 FD D3 02 00 04 20 00 00
Increment BE EF 03 06 00 9B D3 04 00 04 20 00 00
Decrement BE EF 03 06 00 4A D2 05 00 04 20 00 00
Color Balance R
Get BE EF 03 06 00 01 D2 02 00 05 20 00 00
Increment BE EF 03 06 00 67 D2 04 00 05 20 00 00
Decrement BE EF 03 06 00 B6 D3 05 00 05 20 00 00
Color Balance B
Get BE EF 03 06 00 45 D2 02 00 06 20 00 00
Increment BE EF 03 06 00 23 D2 04 00 06 20 00 00
Decrement BE EF 03 06 00 F2 D3 05 00 06 20 00 00
Keystone_V
Get BE EF 03 06 00 B9 D3 02 00 07 20 00 00
Increment BE EF 03 06 00 DF D3 04 00 07 20 00 00
Decrement BE EF 03 06 00 0E D2 05 00 07 20 00 00
Keystone_H
Get BE EF 03 06 00 E9 D0 02 00 0B 20 00 00
Increment BE EF 03 06 00 8F D0 04 00 0B 20 00 00
Decrement BE EF 03 06 00 5E D1 05 00 0B 20 00 00
Aspect
Set
4:3 BE EF 03 06 00 9E D0 01 00 08 20 00 00
16:9 BE EF 03 06 00 0E D1 01 00 08 20 01 00
Small BE EF 03 06 00 FE D1 01 00 08 20 02 00
Get BE EF 03 06 00 AD D0 02 00 08 20 00 00
Position at
16 : 9 or Small
Set
Default BE EF 03 06 00 62 D1 01 00 09 20 00 00
Bottom BE EF 03 06 00 F2 D0 01 00 09 20 01 00
Top BE EF 03 06 00 02 D0 01 00 09 20 02 00
Get BE EF 03 06 00 51 D1 02 00 09 20 00 00
V.Position
Get BE EF 03 06 00 0D 83 02 00 00 21 00 00
Increment BE EF 03 06 00 6B 83 04 00 00 21 00 00
Decrement BE EF 03 06 00 BA 82 05 00 00 21 00 00
H.Position
Get BE EF 03 06 00 F1 82 02 00 01 21 00 00
Increment BE EF 03 06 00 97 82 04 00 01 21 00 00
Decrement BE EF 03 06 00 46 83 05 00 01 21 00 00
H.Size
Get BE EF 03 06 00 B5 82 02 00 02 21 00 00
Increment BE EF 03 06 00 D3 82 04 00 02 21 00 00
Decrement BE EF 03 06 00 02 83 05 00 02 21 00 00
H.Phase
Get BE EF 03 06 00 49 83 02 00 03 21 00 00
Increment BE EF 03 06 00 2F 83 04 00 03 21 00 00
Decrement BE EF 03 06 00 FE 82 05 00 03 21 00 00
Sharpness
Get BE EF 03 06 00 F1 72 02 00 01 22 00 00
Increment BE EF 03 06 00 97 72 04 00 01 22 00 00
Decrement BE EF 03 06 00 46 73 05 00 01 22 00 00
Color
Get BE EF 03 06 00 B5 72 02 00 02 22 00 00
Increment BE EF 03 06 00 D3 72 04 00 02 22 00 00
Decrement BE EF 03 06 00 02 73 05 00 02 22 00 00
ED-S3170/X3270/TECHNICAl02.12.179:25AMページ9
10
Command data chart
(continued)
Names Operation type Header
Command data
CRC Action Type Setting code
Tint
Get BE EF 03 06 00 49 73 02 00 03 22 00 00
Increment BE EF 03 06 00 2F 73 04 00 03 22 00 00
Decrement BE EF 03 06 00 FE 72 05 00 03 22 00 00
Video Format
Set
Auto BE EF 03 06 00 9E 75 01 00 00 22 0A 00
NTSC BE EF 03 06 00 FE 71 01 00 00 22 04 00
PAL BE EF 03 06 00 6E 70 01 00 00 22 05 00
SECAM BE EF 03 06 00 6E 75 01 00 00 22 09 00
NTSC 4.43 BE EF 03 06 00 5E 72 01 00 00 22 02 00
M-PAL BE EF 03 06 00 FE 74 01 00 00 22 08 00
N-PAL BE EF 03 06 00 0E 71 01 00 00 22 07 00
Get BE EF 03 06 00 0D 73 02 00 00 22 00 00
Sync on G
Set
off BE EF 03 06 00 CB D0 01 00 08 30 01 00
on BE EF 03 06 00 5B D1 01 00 08 30 00 00
Get BE EF 03 06 00 68 D1 02 00 08 30 00 00
WHISPER
Set
NORMAL BE EF 03 06 00 3B 23 01 00 00 33 00 00
WHISPER BE EF 03 06 00 AB 22 01 00 00 33 01 00
Get BE EF 03 06 00 08 23 02 00 00 33 00 00
GAMMA
Set
NORMAL BE EF 03 06 00 C7 F0 01 00 A1 30 00 00
CINEMA BE EF 03 06 00 57 F1 01 00 A1 30 01 00
DYNAMIC BE EF 03 06 00 A7 F1 01 00 A1 30 02 00
Get BE EF 03 06 00 F4 F0 02 00 A1 30 00 00
Over Scan
Set
Large BE EF 03 06 00 C2 71 01 00 09 22 02 00
Middle BE EF 03 06 00 32 71 01 00 09 22 01 00
Small BE EF 03 06 00 A2 70 01 00 09 22 00 00
Get BE EF 03 06 00 91 70 02 00 09 22 00 00
MyScreen Size
Set
Full BE EF 03 06 00 43 D6 01 00 12 30 00 00
X1 BE EF 03 06 00 D3 D7 01 00 12 30 01 00
Get BE EF 03 06 00 70 D6 02 00 12 30 03 00
MyScreen Lock
Set
off BE EF 03 06 00 3B EF 01 00 C0 30 00 00
on BE EF 03 06 00 AB EE 01 00 C0 30 01 00
Get BE EF 03 06 00 08 EF 02 00 C0 30 00 00
Lamp Time Get BE EF 03 06 00 C2 FF 02 00 90 10 00 00
Filter Time Get BE EF 03 06 00 C2 F0 02 00 A0 10 00 00
ED-S3170/X3270/TECHNICAl02.12.179:25AMページ10
REGULATORY NOTICES
REGULATORY NOTICES
WARNING: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
INSTRUCTIONS TO USERS: This equipment complies with the requirements
of FCC (Federal Communication Commission) equipment provided that the
following conditions are met.
The cables may have to be used with the core set to the projector side. Use
the cables which are included with the projector or specified.
CAUTION: Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
FCC Statement Warning
For the Customers in CANADA
NOTICE: This Class B digital apparatus complies with Canadian ICES-003.
Pour les utilisateurs au Canada
AVIS: Cet appareil numérique de la Classe B est conforme à la norme NMB-003 du
Canada.
Core
1
REGULATORY
NOTICES
REGULATORYNOTICES02.12.179:11AMページ1
