DZ-HS501E/DZ-HS500E
DZ-HS501E(UK)/DZ-HS500E(UK)
English
DZ-HS500EDZ-HS501E
Instruction manual
To obtain the best performance and ensure years of
trouble-free use, please read this entire instruction
manual.
DVDCAM PC Software Support Centre
URL http://dvdcam-pc.support.hitachi.ca/
Support Centre phone numbers for software provided:
PIXELA PC Software Support Centre
UK, Germany, France and Spain: +800-1532-4865 (Toll-free)
Other countries: +44-1489-564-764
Languages available: English, French, German, Spanish
URL: http://www.pixela.co.jp/oem/hitachi/e/index.html
1
English
Important Information
For Your Safety
The power switch turns the DVD video camera/recorder on and off, leaving the date/time feature unaffected. If the
camera/recorder is to be left unattended for a long period of time, turn it off.
WARNING : TO PREVENT FIRE OR SHOCK HAZARD, DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE.
WARNING : TO PREVENT FIRE OR SHOCK HAZARD, USE THE
RECOMMENDED ACCESSORIES ONLY.
The DVD video camera/recorder and AC
adapter/charger have the following caution
marks.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT OPEN.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
Precautions
WARNING: Many television programmes and
films are copyrighted. In certain circumstances,
copy-right law may apply to private in-home
videotaping of copyrighted materials.
The liquid crystal display (LCD) panel is
made by highly precise technology. More than
99.99% of its picture elements (pixels) are
effective, but some (less than 0.01%) may
appear as coloured bright dots. This does not
indicate a fault as the LCD panel stretches the
limits of current technology.
Identifications of caution marks
This symbol warns the user that
uninsulated voltage within the unit
may have sufficient magnitude to cause
electric shock. Therefore, it is dangerous
to make any kind of contact with any
inside part of this unit.
This symbol alerts the user that
important literature concerning the
operation and maintenance of this unit
has been included. Therefore, it should
be read carefully to avoid any
problems.
WARNING: To prevent risk of injury or damage
to your DVD video camera/recorder and the AC
adapter/charger, use only the DZ-BP07PW/DZBP14SW/DZ-BP7SW battery and DZ-ACS3 (E)
AC adapter/charger.
CLASS 1
LASER PRODUCT
CAUTION
This product contains a laser diode of higher
class than 1. To ensure continued safety, do
not remove any covers or attempt to gain
access to the inside of the product. Refer all
servicing to qualified personnel.
2
Information for users applicable in European Union countries
This symbol on the product or on its packaging means that your electrical and electronic
equipment should be disposed at the end of life separately from your household wastes.
There are separate collection systems for recycling in EU.
For more information, please contact the local authority or the dealer where you
purchased the product.
Information für Nutzer in den Ländern der Europäischen Union
Das auf dem Produkt oder auf der Verpackung angebrachte Symbol bedeutet, dass Ihre
elektrischen und elektronischen Geräte nicht mit dem Haushaltsmüll entsorgt werden
sollen. Es existieren separate Recycling-Sammelsysteme in der EU.
Für mehr Informationen wenden Sie sich bitte an Ihre örtlichen Behörden oder an den
Fachhändler, bei dem Sie das Produkt erworben haben.
Information utilisateurs, applicable dans les pays de l’Union Européenne
Ce symbole figurant sur le produit ou son emballage signifie que votre équipement
électrique et électronique doit être mis au rebut séparément de vos déchets ménagers
lorsqu’il a atteint la fin de sa durée de vie.
Il existe des systèmes de collecte séparée pour le recyclage dans l’UE.
Pour plus d’informations, veuillez prendre contact avec les autorités locales ou le
revendeur auquel vous avez acheté ce produit.
Informatie voor gebruikers in landen van de Europese Unie
Dit symbool op het product of op zijn verpakking betekent dat uw elektrische of
elektronische apparatuur na het verstrijken van de levensduur gescheiden van het
huisvuil moet worden weggegooid.
Er zijn afzonderlijke ophaalsystemen voor recyclage in de E.U.
Voor meer informatie neemt u contact op met de plaatselijke overheid of de dealer waar u
het product hebt gekocht.
English
Information till användare inom Europeiska unionen
Märkningen av produkter och förpackningar med denna symbol betyder att elektrisk och
elektronisk utrustning måste tas om hand separat från hushållssopor när utrustningen har
förbrukats. EU har särskilda återvinningsanläggningar för denna typ av utrustning.
Kontakta de lokala myndigheterna eller återförsäljaren där produkten har köpts för mer
information.
Informazioni per gli utenti negli Stati dell’Unione Europea
Questo simbolo sul prodotto o sull’imballaggio indica che l’apparato elettrico o elettronico
alla fine del suo periodo di vita dovrebbe essere smaltito separatamente dai rifiuti
domestici.
Nell’UE esistono altri sistemi di raccolta differenziata.
Per ulteriori informazioni, contattare le autorità locali o il rivenditore presso il quale è stato
acquistato il prodotto.
Información para usuarios aplicable en los países de la Unión Europea
Este símbolo en el producto o en su embalaje significa que debería deshacerse de su
equipo eléctrico o electrónico, al final de su vida útil, de forma separada del resto de los
residuos domésticos. Para estos productos hay sistemas de recogida selectiva para
reciclarlos en la Unión Europea.
Para más información, rogamos contacte con la autoridad local o el distribuidor donde
adquirió el producto.
3
English
Important for United Kingdom
(for DZ-HS501E (UK) / DZ-HS500E (UK))
The mains lead on this equipment is supplied with a moulded plug incorporating a fuse, the value
of which is indicated on the pin face of the plug.
Should the fuse need to be replaced, an ASTA or BSI approved BS 1362 fuse must be used of the
same rating. If the fuse cover is detachable never use the plug with the cover omitted. If a
replacement fuse cover is required, ensure it is of the same colour as that visible on the pin face of
the plug. Fuse covers are available from your dealer.
DO NOT cut off the mains plug from this equipment. If the plug fitted is not suitable for the power
points in your home or the cable is too short to reach a power point, then obtain an appropriate
safety approved extension lead or consult your dealer.
If there is no alternative to cutting off the mains plug, ensure that you dispose of it immediately,
having first removed the fuse, to avoid a possible shock hazard by inadvertent connection to the
mains supply.
IMPORTANT
The wires in the mains lead are coloured in accordance with the following code:
Blue= Neutral, Brown= Live
As these colours may not correspond with the coloured markings identifying the terminals in your
plug, proceed as follows:
The wire coloured BLUE must be connected to the terminal marked with the letter N or coloured
BLUE or BLACK.
The wire coloured BROWN must be connected to the terminal marked with the letter L or coloured
BROWN or RED. On no account connect either of these wires to the terminal marked E or by the
earth symbol or coloured green or green and yellow.
4
IMPORTANT SAFETY INSTRUCTIONS
In addition to the careful attention devoted to quality standards in the manufacture of your video product, safety is a
major factor in the design of every instrument. But, safety is your responsibility too.
This page lists important information that will help to assure your enjoyment and proper use of DVD video camera/
recorder and accessory equipment.
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8 Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9 Protect the mains lead from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
10 Only use attachments/accessories specified by the
manufacturer.
English
11 Use only with the cart, stand,
tripod, bracket, or table specified
by the manufacturer, or sold with
the apparatus. When a cart is
used, use caution when moving
the cart/apparatus combination to
avoid injury from tip-over.
12 Unplug this apparatus during lightning storms or
when unused for long periods of time.
13 Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as mains lead or plug is
damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.
14 The apparatus shall not be exposed to dripping or
splashing and that no objects filled with liquids,
such as vases, shall be placed on the apparatus.
15 The equipment (AC Adapter/Charger) shall be
used near the socket-outlet and shall be easily
accessible.
5
English
Cautions on HDD
Save the data recorded on HDD:
• To back up the data recorded on HDD, save it on a DVD. It is also recommended that you use this
DVD video camera/recorder to dub the data. You can also use a PC to save the data on a DVD.
• It is recommended that you periodically save your recordings.
Do not subject the DVD video camera/recorder to any vibrations or impact:
• This could result in the HDD not being recognised or recording, playback or dubbing to become
impossible.
• Do not subject this DVD video camera/recorder to any vibrations or impact especially during
recording, playback or dubbing, or while the ACCESS/PC indicator is lit or blinking.
• If vibrations to this DVD video camera/recorder are repeated, or the drop status of DVD video
camera/recorder is detected (see page 68), recording, playback or dubbing will stop to protect the
HDD in this DVD video camera/recorder.
Carefully check the temperature of this DVD video camera/recorder:
• If the temperature of this DVD video camera/recorder is too high or too low, normal recording or
playback may not be possible.
• If the power switch is set to “HDD” with the temperature of this DVD video camera/recorder too
high or too low, message “The temperature of HDD is outside the operating temperature range.
Turn off power.” may appear to protect the HDD. Even if this happens, setting the power switch to
“DVD” may allow you to use the DVD video camera/recorder with a DVD, so it is recommended
that you carry a spare DVD even if you intend to record on the HDD.
This DVD video camera/recorder cannot be used at high altitude:
• Note that the DVD video camera/recorder cannot be used in a place where the atmospheric
pressure is low, such as 3,000 meters or more above sea-level.
Do not place this DVD video camera/recorder near a magnet or magnetic field:
• If you so, recording, playback or dubbing may not be possible.
Please note in advance that Hitachi will not accept any liability or make compensation for loss
of data, or direct or indirect damage when recording or playback is not performed normally
due to a fault in this DVD video camera/recorder. This also applies to repairs on this DVD
video camera/recorder (including repair of components other than HDD).
Cautions When Using
• Hitachi cannot compensate for any damages caused when recording is not made normally or
recorded contents cannot be played back because of a defect in the DVD video camera/recorder,
disc or card. Also, Hitachi cannot be responsible for your recorded video and audio.
• If you or a third party make a mistake when handling this DVD video camera/recorder, disc,
card, etc., the recorded contents may be lost. We cannot be responsible for compensation for
damage due to loss of recorded contents.
Handle the liquid crystal display (LCD) with care:
• The LCD is a very delicate display device: Do not press its surface with force, hit it or prick it with
a sharp object.
• If you push the LCD surface, unevenness in display may occur. If unevenness does not disappear
soon, turn the DVD video camera/recorder off, wait for a few moments, and then turn it on again.
• Do not place the DVD video camera/recorder with the open LCD screen down.
• Close the LCD monitor when not using the DVD video camera/recorder.
6
Liquid crystal display (LCD) and viewfinder:
• The LCD screen and viewfinder are the products of highly precise technology. Among the total
number of pixels (approx. 120,000 pixels for LCD monitor and equivalent to approx. 200,000 pixels
for viewfinder), 0.01% or less pixels may be missing (black dots) or may remain lit as coloured dots
(red, blue, green). This shows the limitations of the current technology, and does not indicate a
fault that will interfere with recording.
• The LCD screen and viewfinder will be slightly dimmer than usual when the DVD video camera/
recorder is at low temperature, as in cold areas, or immediately after power is turned on. Normal
brightness will be restored when the temperature inside the DVD video camera/recorder rises.
Hold the DVD video camera/recorder correctly:
• Do not hold the viewfinder or LCD monitor when lifting the DVD video camera/recorder: The
viewfinder or LCD monitor could detach and the DVD video camera/recorder may fall.
Do not subject the DVD video camera/recorder to impact:
• This DVD video camera/recorder is a precision machine. Take great care that you do not strike it
against a hard object or let it fall.
• When using a tripod, firmly secure the DVD video camera/recorder on it. Do not use the DVD
video camera/recorder with a tripod in a place where it is subject to severe vibrations or impact.
No sand or dust!
• Fine sand or dust entering the DVD video camera/recorder or AC adapter/charger could cause
malfunctions or defects.
No water or oil!
• Water or oil entering the DVD video camera/recorder or AC adapter/charger could cause electric
shock, malfunctions or defects.
Heat on surface of product:
• The surfaces of the DVD video camera/recorder, AC adapter/charger and battery will be slightly
warm, but this does not indicate a fault.
Screen on connected TV:
• Never leave the Disc Navigation screen, still image or camera image displayed on your TV to
which the DVD video camera/recorder is connected: Doing so could result in displayed image
retention or phosphor degradation of TV screen.
Be careful of ambient temperature:
• If the temperature of this DVD video camera/recorder is too high or too low, normal recording/
playback may not be possible.
• Take care that the temperature of this DVD video camera/recorder, when connected to PC does
not rise excessively (reference for usage: approx. 30 minutes at about 30ºC).
• Do not leave the DVD video camera/recorder on beach sand or in a closed vehicle where the
temperature is very high for a long time: This could cause malfunctions.
Do not point directly at the sun:
• If direct sunlight strikes the lens or viewfinder, the DVD video camera/recorder could malfunction
or a fire could occur.
• Do not leave the DVD video camera/recorder with the LCD screen exposed to direct sunlight: This
could cause malfunctions.
Do not use the DVD video camera/recorder near TV or radio:
• This could cause noise to appear on the TV screen or in radio broadcasts.
Do not use the DVD video camera/recorder near strong radio waves or magnetism:
• If the DVD video camera/recorder is used near strong radio waves or magnetism, such as a radio
wave tower or electric appliances, recording or playback may stop, or noise could enter the video
and audio that are being recorded. During playback of normally recorded video and audio, noise
may also be present in picture and sound.
At worst the DVD video camera/recorder could malfunction.
Do not expose the DVD video camera/recorder to soot or steam:
• Thick soot or steam could damage the DVD video camera/recorder case or cause malfunctions.
English
7
Do not use the DVD video camera/recorder near corrosive gas:
English
• If the DVD video camera/recorder is used in a place where there is dense exhaust gas generated
by petrol or diesel engine, corrosive gas such as hydrogen sulfide, or sulfur such as in a hot spring
area, the external or internal terminals could corrode, which would disable normal operation, or
the battery connecting terminals could corrode, so power will not turn on.
Do not use the DVD video camera/recorder near ultrasonic humidifier:
• With some water in humidifier, calcium and other chemicals dissolved in water could scatter in the
air, and white particles could adhere to the optical head of the DVD video camera/recorder, which
could cause it to operate abnormally.
Do not expose the DVD video camera/recorder to insecticide:
• Insecticide entering the DVD video camera/recorder could dirty the lens in laser pickup block for
DVD, and in such a case the DVD video camera/recorder might not operate normally. Turn the
DVD video camera/recorder off and cover it with vinyl sheet, etc. before using insecticide.
Do not use a generally available 8 cm CD lens cleaner:
• Cleaning the DVD lens is not necessary when using this DVD video camera/recorder in the usual
way.
• Using 8 cm CD lens cleaner could cause this DVD video camera/recorder to be faulty.
• If you have to clean the lens, use a Hitachi Maxell cleaner that is exclusively for 8 cm DVD discs.
Be careful of moisture condensation:
• When you move the DVD video camera/recorder between places where the difference in
temperatures is great – such as entering a lodge from a ski slope or going out of a cooled room or
vehicle – condensation (vapour in air warmed or cooled to water droplets) could occur on the lens
and/or inside the DVD video camera/recorder. If condensation occurs, do not open the cover of
disc or card insertion block if possible. If condensation occurs on the lens, wipe it off with a soft,
dry cloth. Even if the external surface of DVD video camera/recorder has dried, condensation may
remain inside: Turn the DVD video camera/recorder off and leave it in a dry place for at least 1 – 2
hours before using it again.
Do not use the DVD video camera/recorder for a long uninterrupted period of time:
• This DVD video camera/recorder cannot be used for a long time continuously as a surveillance
camera/monitor. If you use it for a long continuous period of time, the temperature of DVD video
camera/recorder could exceed the limit and the recording/playback operation may slow down or
other faults could occur. If this happens, turn it off and wait for a while before using it again.
8
Do not turn the DVD video camera/recorder off while the ACCESS/PC indicator or
CARD ACCESS indicator is lit or blinking:
• The ACCESS/PC or CARD ACCESS indicator is lit or
blinking to show that data is being written to disc or card,
or being read from it. At this time, do not do any of the
following, so as not to damage the data:
− Remove battery
− Disconnect AC adapter/charger
− Plug or unplug PC connection cable
− Remove disc or card
− Subject DVD video camera/recorder to severe
vibrations or impact
− Violently open or close the LCD monitor
The ACCESS/PC indicator will light for a while after
recording is finished. While it is lit, do not subject the DVD
video camera/recorder to any vibration or impact, and do
not disconnect the battery or AC adapter/charger.
If, when using HDD/DVD, you turn the DVD video
camera/recorder off while the ACCESS/PC indicator is lit
or blinking, turn it on again: When using a DVD, turn it on
with the DVD loaded. The HDD/DVD will be restored (see page 140).
ACCESS/PC indicator
CARD ACCESS indicator
Do not wipe the DVD video camera/recorder case with benzene or thinner:
• The coating of case could peel off or the case surface could deteriorate.
• When using a chemical cleaning cloth, follow the instructions.
Also read the instructions attached with optional accessories:
• For optional accessories, observe the cautions and follow instruction manuals attached.
The battery provided has not been charged at time of purchase:
• Charge it before using the DVD video camera/recorder (see page 30).
• The battery will discharge as time passes. (The battery is produced so that it discharges on its own
in order to protect its characteristics.)
Disc cannot be inserted or removed unless a charged battery or AC adapter/
charger is connected to the DVD video camera/recorder.
Be sure to set the power switch to “OFF” when turning the DVD video camera/
recorder off:
• Disconnecting the battery or AC adapter/charger while the DVD video camera/recorder is being
powered could cause a fault.
English
9
English
Cautions When Storing
Do not leave the DVD video camera/recorder in a place where the temperature is
very high for a long period of time:
• The temperature inside a closed vehicle or trunk can become very high in a hot season. If you leave
the DVD video camera/recorder in such a place, it could malfunction or the case could be
damaged. Also, do not expose the DVD video camera/recorder to direct sunlight or place it near a
heater.
Do not store the DVD video camera/recorder in a place where the humidity is high
or in a dusty place:
• Dust entering the DVD video camera/recorder could cause malfunctions. If the humidity is high,
the lens could be mouldy, and the DVD video camera/recorder could become inoperable. It is
recommended that you put the DVD video camera/recorder with desiccant in a box when storing
it in a closet, etc.
Do not store the DVD video camera/recorder in a place subject to strong
magnetism or intense vibrations:
• This could cause malfunctions.
Detach the battery from the DVD video camera/recorder and store it in a cool place:
• Leaving the battery attached or storing it at high temperature could shorten its life.
Suggestions and Restrictions
Make a trial recording:
• Always make a trial recording before doing actual recording to make sure that recording is normal.
The data that have not been stored normally because of a defect in the DVD video camera/
recorder cannot be restored.
It is recommended that you use the HDD from which recorded contents can be deleted for trial
recording.
Do not use the DVD video camera/recorder for professional applications:
• This DVD video camera/recorder is designed and produced for home-use recording and playback.
Copyright:
• Data recorded on the HDD/disc/card in this DVD video camera/recorder using other digital/
analog media or devices are protected by the copyright act and cannot be used without permission
of the owner of copyright, except for personal enjoyment. Be aware that recording is restricted for
some demonstrations, performances and exhibitions, even for personal enjoyment.
10
CLEANING
Be sure to set the power switch to “OFF” before cleaning this DVD video camera/recorder.
●Cleaning LCD screen and camera
lens
Use dry, soft cloth to wipe dirt off. When
cleaning the LCD screen, be careful not to use
force, scratch it, or subject it to impact: Doing
such could cause a defect in the screen, result in
display unevenness, or damage the LCD
monitor.
●If dust adheres to the viewfinder
lens, remove it using a cotton
swab, etc.
Do not rub the lens with force: Doing so could
scratch the lens.
●Cleaning DVD Video Camera/
Recorder Case
Do not wipe the DVD video camera/recorder
case hard with any foreign object, such as grit,
adhering to it, and do not use rough fabrics to
clean the case: Doing so could scratch it.
Use soft cloth, etc. to gently wipe dirt off the case.
●Do not use benzene or thinner to
clean DVD video camera/recorder
case
The coating of case could peel off or the case
could deteriorate. Wipe off dirt on the case with
a soft cloth which has been completely wrung
out. When using chemical cleaning cloth, follow
instructions for use.
HANDLING DISCS
●Using discs
Discs are very delicate recording media.
Carefully read the following cautions and
observe them:
• Always use a brand new disc when recording
important material.
• Be sure not to touch the recording surface of
disc, or dirty or scratch it.
• If there is dust, scratch, dirt on disc or if it is
warped, the following phenomena may occur:
− Block noise in playback
− Momentary stop of
playback image
− Sound interrupted during
playback, or abnormal
sound
− Blue thumbnail
display* (Fig. 1)
− Disc cannot correctly
be recognised
− Disc cannot be
initialised
− Delay between video
and audio
Even if disc is normal, the above phenomena
may occasionally occur. While the ACCESS/
PC indicator is lit, do not subject disc to
vibrations or impact, and avoid using DVD
video camera/recorder at extremely high or
low temperatures, or in environment where
condensation is likely to occur.
PLAY
*
Block noise
SELECT
Fig. 1
001/ 006All Programs
• When recording images,
the DVD video camera/
recorder may avoid the
portions of disc where
recording is not possible,
due to dust, scratches,
etc. [It will pause 9 at
PLAY
SELECT
(Recording one scene
may produce multiple
thumbnails.)
such a portion and
automatically restart
recording (:).]
This will cause recording to be interrupted for
several seconds to several minutes, and
multiple thumbnails will be created by one
recording session as shown above. In this case,
the recordable time on disc will decrease.
• Be careful when removing the disc since the
metal of removal slot of DVD video camera/
recorder, and disc itself, may be hot.
●Storing discs
• When storing disc, replace it in the plastic case
in which it was purchased.
• Be careful that no condensation occurs on disc.
• Do not place disc in following places:
− Direct sunlight for a long time
− Where humidity is high or in dusty place
− Where there is heat from a heater, etc.
English
001/ 002All Programs
11
DISC CLEANING
English
Use the disc cleaning cloth provided to lightly
wipe off any dirt adhering to the disc as shown
in the figure. Do not wipe the disc with force:
Doing so could cause scratches.
Never use solvent (thinner, water, antistat or
detergent) for cleaning.
Lightly wash the dirty cleaning cloth with
detergent: The dirt removal capacity of the cloth
will improve (rinse the cloth well with water so
that no detergent remains).
Use the disc cleaning
cloth to clean from inner
to outer edges in axial
direction.
NOTE WHEN TRANSFERRING OR DISCARDING DISCS AND SD MEMORY CARDS
•
The “Format” function on this DVD video camera/recorder will only change the file control information:
It will not completely delete the data in the built-in hard disk; your personal data could leak out. To
prevent the data from leaking out, execute complete deletion of HDD (see p. 110).
•
“Formatting” or “deletion” using the functions of DVD video camera/recorder or PC will change only
the file control information: It will not completely delete the data on disc or memory card.
• When transferring or discarding a disc or memory card, it is recommended that you physically
destroy it or use deletion exclusive software (generally available) to completely delete the data on
it. It is user’s responsibility to control the data on disc and memory card.
•
Hitachi will not accept any responsibility for leaking of personal data.
Read This First
To guide you, we have included following five chapters.
• The section on “Setups” explains how to set
up the DVD video camera/recorder, battery,
and set the date/time.
• The section on “Basic Techniques” explains the
basic operation of this DVD video camera/
recorder – recording of movies, still images
and playback of recorded images.
•
The section on “Disc Navigation” explains
editing with Disc Navigation: Refer to this
section when dubbing from HDD to disc,
finalising a DVD-RW/DVD-R/+RW and
initialising a DVD-RAM/DVD-RW/+RW.
• The section on “Connecting to PC” explains
the contents of provided CD-ROM and how to
install the software included.
• “Subsidiary Information” includes an
introduction to products sold separately, and
troubleshooting.
We want this manual to be as helpful as
possible, so it includes two easy ways to find the
information you need:
• A quick index for the information you use
most often.
•
A detailed table of contents directing you to
specific information quickly (see pages 15 – 17).
Get to know your DVD video camera/recorder by
using this manual, and get to know Hitachi. We
appreciate your business.
Quick Index
Available Discs................................................. 27
Recording Movie.............................................. 44
Playing Back .................................................... 72
Functions Available with Disc Navigation.........79
Dubbing on DVD.............................................. 83
Connecting to a TV ........................................116
Connecting to PC........................................... 120
With this DVD video camera/recorder you can view the picture being recorded or the playback
picture whether on the LCD monitor or in the viewfinder. Opening or closing the LCD monitor
switches the picture to appear on the LCD monitor or in the viewfinder.
It is possible to switch the language in the on-screen display of this DVD video camera/recorder
(see page 37).
12
About This Manual
HDD
●Displays in this manual
Understand that the displays are different from those you will actually see in the viewfinder or on
the LCD screen.
●Notation of cancel button
Press the STOP/EXIT button to stop your operation midway, or return the menu screen to the
preceding one. The expression “press the button” will be used in this text.
HDD
● , , , , , and marks beside headings
Some functions of this DVD video camera/recorder are unavailable with HDD/disc/card used. Refer
to the marks at right above each function to identify whether the HDD/disc/card is compatible with
the function. Refer to these marks and identify the functions and operation to match the HDD/disc/
card you use.
●Illustrations in this manual
Although the external appearances of DZ-HS501E / HS500E are different, the method of operating
these models is identical.
The illustrations of DZ-HS501E are used for the explanation in this text.
This instruction manual shows four DVD video camera/recorder models - DZ-HS501E, DZ-
●
HS500E, DZ-HS501E (UK) and DZ-HS500E(UK).
The DZ-HS501E and DZ-HS501E (UK) functions and specifications are referred to as “DZHS501E”.
The DZ-HS500E and DZ-HS500E (UK) functions and specifications are referred to as “DZHS500E”.
No model names are mentioned for functions and specifications common to all models; if there are
any differences between models, the model names are specified.
®
Microsoft
registered trademarks of Microsoft Corporation.
Windows Vista™ is a trademark of Microsoft Corporation.
Intel
Intel
Macintosh is a trademark of Apple, Inc.
IBM
Manufactured under licence from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
Other company names and product names listed are trademarks or brand names belonging to each
individual company.
SD logo is a trademark.
, Windows®, Windows® Me, Windows® 2000 Professional, and Windows® XP are
®
, Pentium® Processor, and Celeron® Processor are registered trademarks of Intel Corporation.
®
Core is a trademark of Intel Corporation.
®
and PC/AT® are registered trademarks of International Business Machines Corporation.
English
13
English
Introduction
●
Recording is possible on both HDD and DVD: In FINE mode, recording for
up to 11 hours is possible on HDD; up to 30 minutes on DVD (p. 44, 157)
●
Dubbing to an 8 cm DVD can be performed on this DVD video camera/recorder
using only one button: Simple dubbing without a DVD recorder or PC
●You can capture photos from videos (p. 74)
You can record an image displayed during playback of video as a photo on a card.
●You can start recording immediately after stopping playback (p. 44, 73)
Unlike tape devices, you do not need to search for the recording start position or locate the
beginning of blank portion.
You can stop playback and immediately start recording: New recording will not overwrite any
previously recorded data.
●You can immediately play back desired recorded scenes (p. 72)
You do not need to rewind, unlike recorders using tape.
You can select any scene you want and immediately play it back (using Disc Navigation function).
●Use Disc Navigation to create your original movie (p. 101)
You can delete unnecessary scenes, move any scenes, etc., and create your original movie work (Play List).
To edit the scenes recorded on the HDD, use the dubbing function to easily create a DVD from the
edited original movie. If you edit the scenes recorded on a disc, you can play back the edited original
movie and easily dub it on another DVD recorder or VCR.
●Create original DVDs on PC (p. 120)
You can create an original DVD, using the provided software CD-ROM.
The created DVD disc can be played back on DVD player/recorder, DVD-ROM drive, etc.
(p. 83)
14
Table of Contents
Important Information .........................................2
For Your Safety ..................................................2
Precautions ........................................................2
IMPORTANT SAFETY INSTRUCTIONS ...........5
Cautions on HDD ...............................................6
Cautions When Using ........................................6
Cautions When Storing ....................................10
Suggestions and Restrictions...........................10
CLEANING .......................................................... 11
HANDLING DISCS .............................................. 11
DISC CLEANING................................................. 12
NOTE WHEN TRANSFERRING OR DISCARDING
DISCS AND SD MEMORY CARDS ................. 12
Read This First.................................................12
About This Manual ...........................................13
Introduction ......................................................14
Table of Contents.............................................15
Checking Provided Accessories.......................18
Names of Parts ................................................19
Demonstration Function ...................................23
Setting Up the DVD Video Camera/
Recorder........................................................23
HOLDING DVD VIDEO CAMERA/
RECORDER ..................................................... 23
ATTACHING SHOULDER STRAP ...................... 23
ATTACHING LENS CAP ..................................... 24
INSERTING BATTERY INTO REMOTE
CONTROL ........................................................ 24
REMOVING BATTERY FROM REMOTE
CONTROL ........................................................ 25
HDD/DVD/Cards ..............................................26
HDD, DISCS........................................................ 27
INFORMATION ON DVD-R................................. 27
NOTES ON FINALISATION ................................ 27
EXAMPLES OF DISCS THAT CANNOT BE
USED ON THIS DVD VIDEO CAMERA/
RECORDER ..................................................... 28
AVAILABLE CARDS............................................ 28
CAUTIONS FOR DISC AND CARD.........................28
Preparations for Power Supply ........................29
USING DVD VIDEO CAMERA/RECORDER
WITH AC ADAPTER/CHARGER...................... 29
Setting Up the Battery ......................................30
CHARGING BATTERY........................................ 30
ATTACHING BATTERY TO DVD VIDEO
CAMERA/RECORDER ..................................... 31
REMOVING BATTERY........................................ 31
BATTERY REMAINING LEVEL INDICATOR ...... 33
EFFICIENT USE OF BATTERY .......................... 33
Turning DVD Video Camera/Recorder
On and Off .....................................................34
Setups
Viewing Images ............................................... 35
VIEWING IMAGE ON LCD MONITOR
SCREEN ...........................................................35
VIEWING SUBJECT THROUGH
VIEWFINDER ................................................... 35
Setting Date and Time..................................... 36
CHANGING DISPLAY FORMAT OF
DATE AND TIME .............................................. 36
Initial Settings .................................................. 37
SWITCHING OPERATING SOUND
ON OR OFF (BEEP)......................................... 37
TURNING DVD VIDEO CAMERA/RECORDER
OFF AUTOMATICALLY (POWER SAVE) ........ 37
CHANGING DISPLAY LANGUAGE
(LANGUAGE)....................................................37
RESETTING MENU SETTINGS TO DEFAULTS
(RESET)............................................................38
TURNING RECORD LED ON OR OFF
(RECORD LED) ................................................ 38
CHANGING SETTING OF
DEMONSTRATION ..........................................38
LCD/EVF Setup............................................... 39
ADJUSTING BRIGHTNESS OF LCD SCREEN
(LCD BRIGHTNESS) AND VIEWFINDER
(EVF BRIGHTNESS) ........................................ 39
ADJUSTING COLOUR DENSITY
(COLOUR LEVEL) ............................................ 40
ALWAYS DISPLAYING IMAGE IN
VIEWFINDER ................................................... 40
Inserting and Removing Disc .......................... 41
Inserting and Removing Card.......................... 43
Basic Techniques
Recording Movie ............................................. 44
Recording Stills ............................................... 45
Swift Restart of Recording
(SLEEP/RESTART button) ........................... 46
On-Screen Information .................................... 47
INFORMATION DISPLAY DURING
RECORDING ....................................................47
Checking Flow of Menu................................... 52
Zooming .......................................................... 54
MACRO RECORDING ........................................ 54
RECORDING SUBJECTS FOR STRONGER
WIDE-ANGLE OR TELEPHOTO EFFECT .......55
Manually Focusing Subject ............................. 56
FOCUSING DURING RECORDING.................... 56
Adjusting Brightness of Image to be recorded
(Exposure) .................................................... 58
Compensating for Backlight ............................ 58
Using Full Auto Function ................................. 59
Setting Up Camera Functions ......................... 60
English
15
English
SELECTING SHOOTING MODE TO MATCH THE
SUBJECT
(SWITCHING PROGRAMME AE MODE) ........ 60
RECORDING DARK SUBJECTS USING LCD
MONITOR LIGHT ............................................. 61
ADJUSTING COLOUR (WHITE BALANCE) ....... 61
USING THE ELECTRONIC IMAGE
STABILISER (EIS) ............................................ 63
RECORDING SUBJECT USING LARGE
MAGNIFICATION (DIGITAL ZOOM) ................ 63
REDUCING WIND NOISE DURING
RECORDING (MIC.FILTER) ............................ 63
Setting Up Record Functions........................... 64
SWITCHING MOVIE QUALITY
(VIDEO MODE) ................................................ 64
SETTING TO WIDE TV SCREEN MODE
(16:9 MODE)..................................................... 65
SWITCHING QUALITY OF STILL IMAGE
(QUALITY) ........................................................ 67
SELF-TIMER ....................................................... 67
SETTING ON-SCREEN DISPLAY OUTPUT
ON OR OFF (OSD OUTPUT) ........................... 68
DROP DETECTION (HDD PROTECTION)......... 68
Using External Microphone.............................. 69
Disc Navigation
Using Disc Navigation...................................... 70
STARTING OR TERMINATING DISC
NAVIGATION.................................................... 70
PLAYING BACK FROM DISC NAVIGATION
SCREEN........................................................... 72
ADJUSTING VOLUME DURING PLAYBACK..... 72
PLAYING BACK LATEST RECORDED
SCENE ............................................................. 73
DELETING LAST RECORDED SCENE .............. 73
CAPTURING PHOTO.......................................... 74
SEARCH PLAYBACK OF MOVIE ....................... 74
FRAME ADVANCE/FRAME BACK/SLOW
PLAYBACK OF MOVIE .................................... 74
SKIP PLAYBACK OF MOVIE..............................75
PLAYING BACK STILLS ..................................... 75
JUMPING TO SPECIFIED POINT (GO TO) ....... 76
INFORMATION DISPLAY DURING
PLAYBACK....................................................... 77
SELECTING MULTIPLE SCENES...................... 78
SELECTING CONSECUTIVE SCENES
TOGETHER...................................................... 78
FUNCTIONS AVAILABLE WITH DISC
NAVIGATION.................................................... 79
UNDERSTANDING FLOW OF DISC
NAVIGATION MENU ........................................ 80
Dubbing on DVD.............................................. 83
FIRST-TIME (“NEW”) DUBBING ......................... 84
DUBBING SCENES RECORDED ON SAME DAY
COLLECTIVELY (“DATE” DUBBING) .............. 85
DUBBING ALL SCENES RECORDED ON HDD
(DUBBING “ALL”) ............................................. 86
SELECTING SCENES RECORDED ON HDD AND
DUBBING THEM
(SCENE “SELECT” DUBBING) ........................ 87
TURNING OFF DUBBED MARK FROM
THUMBNAIL (MARK OFF) ............................... 87
Scene............................................................... 88
DELETING SCENES (EDIT – DELETE) ............. 88
DIVIDING MOVIES (EDIT – DIVIDE) .................. 89
COMBINING MULTIPLE SCENES
(EDIT – COMBINE) .......................................... 90
ARRANGING ORDER OF SCENES
(EDIT – MOVE)................................................. 90
DIRECTING SCENES EFFECTIVELY
(EFFECT – FADE) ............................................ 91
PLAYING BACK BY SKIPPING SCENES
(EFFECT – SKIP) ............................................. 92
CHANGING IMAGES FOR THUMBNAILS
(EFFECT – THUMBNAIL) ................................. 93
COPYING STILLS ON DVD-RAM TO CARD
(COPY) ............................................................. 94
LOCKING SCENES ON CARD (LOCK) .............. 95
SELECTING SCENES USING MENU SCREEN
(SELECT) ......................................................... 96
DISPLAYING INFORMATION USING MENU
SCREEN (DETAIL) ........................................... 97
Programme ......................................................98
WHAT IS “PROGRAMME”? ................................ 98
SWITCHING TO THUMBNAIL DISPLAY OF
SPECIFIC DATE (SELECT) ............................. 98
PLAYING BACK PROGRAMME (PLAY) .............99
CHANGING TITLE OF PROGRAMME
(TITLE).............................................................. 99
Play List .........................................................101
WHAT IS “PLAY LIST”? ..................................... 101
CREATING NEW PLAY LIST (CREATE).......... 101
SWITCHING TO DISPLAY OF EACH PLAY
LIST (SELECT) ............................................... 102
PLAYING BACK A PLAY LIST (PLAY)..............102
ADDING SCENES TO PLAY LIST
(EDITING PLAY LIST) .................................... 103
DELETING SCENES FROM PLAY LIST
(EDITING PLAY LIST) .................................... 104
ADDING SCENES USING SUBMENU FOR
EDITING (EDITING PLAY LIST) .................... 104
DELETING SCENES USING SUBMENU FOR
EDITING (EDITING PLAY LIST) .................... 105
SELECTING SCENES USING SUBMENU FOR
EDITING (EDITING PLAY LIST) .................... 105
ARRANGING ORDER OF SCENES
(MOVE) ...........................................................106
CHANGING TITLE OF PLAY LIST (TITLE)....... 107
DELETING PLAY LIST (DELETE).....................107
Go To............................................................. 108
MOVING TO BEGINNING (END) OF
HDD/DVD/CARD ............................................108
HDD/DVD/Card Management........................ 108
INITIALISING HDD/DVD/CARD ........................108
PROTECTION ................................................... 109
VERIFYING REMAINING FREE SPACE ON
DISC OR CARD (CAPACITY) ........................ 109
UPDATING CONTROL INFORMATION OF
HDD/DVD-RAM/DVD-RW (VR-MODE)
(UPDATE CONTROL INFO.).......................... 110
16
TOC
DELETING DATA ON HDD
(FULL FORMAT) ............................................ 110
FINALISING DVD-RW/DVD-R/+RW
(FINALIZE DVD) ............................................. 111
ADDITIONALLY RECORDING ON FINALISED
DVD-RW (VF-MODE)/+RW
(UNFINALIZE DVD) ........................................ 112
Others ............................................................113
DISPLAYING DUBBED/UNDUBBED SCENES IN
LIST (CATEGORY)......................................... 113
DISPLAYING MOVIES OR STILLS
INDEPENDENTLY (CATEGORY) .................. 113
PLAYING BACK SCENES REPEATEDLY
(REPEAT PLAY) ............................................. 114
PLAYING BACK WIDE-MODE IMAGES ON
4:3 DISPLAY TV (TV TYPE)........................... 114
SLIDE SHOW (CONTINUOUS PLAYBACK OF
STILLS)........................................................... 115
Viewing on TV Screen....................................116
CONNECTING TO A TV.................................... 116
VIEWING ON TV SCREEN ............................... 117
Playback on DVD Recorder/Player ................118
PLAYING BACK DVD-RAM/DVD-RW
(VR-MODE) .................................................... 118
PLAYING BACK DVD-RW (VF-MODE)/
DVD-R/+RW ................................................... 118
Recording (Dubbing) Images On Other
Video Devices..............................................119
Connecting to PC
Software Provided..........................................120
Requirements of available PC........................121
Installing Software..........................................122
Connecting to PC via PC Connection
Cable ...........................................................125
USING DISC IN DVD DRIVE BUILT
INTO PC ......................................................... 127
BEFORE TERMINATING PC CONNECTION
(UNPLUGGING PC CONNECTION CABLE)/
CHANGING OVER POWER SWITCH ........... 128
Using ImageMixer 3 for Windows ..................129
VIEWING IMAGES RECORDED ON
HDD/DISC USING PC .................................... 129
CREATING DVD-VIDEO USING IMAGES
RECORDED ON HDD/DISC .......................... 130
Using ImageMixer 3 Mac Edition for
DVDCAM .....................................................133
VIEWING IMAGES RECORDED ON HDD/DISC
USING MACINTOSH ...................................... 133
IMPORTING IMAGES RECORDED ON HDD/
DISC INTO MACINTOSH ............................... 134
CREATING DVD-VIDEO USING IMAGES
RECORDED ON HDD/DISC .......................... 135
Uninstalling Software .....................................137
Contact The Following ...................................137
Cautions when connecting DVD video
camera/recorder to PC ................................138
Introduction to Optional Accessories............. 139
Subsidiary Information
CAMERA ACCESSORIES ................................ 139
POWER SUPPLY .............................................. 139
Trouble Messages......................................... 140
Troubleshooting............................................. 147
System Reset................................................ 154
Major Specifications ...................................... 155
STORAGE CAPACITY OF
HDD/DVD/CARD ...........................................157
RECORDABLE STILLS (PHOTOS)
ON CARD ....................................................... 158
Index.............................................................. 159
Be sure to read the following before
opening the package of CD-ROM............... 161
English
17
English
Checking Provided Accessories
Make sure that you have all the following accessories in package:
Battery (model DZ-BP07PW):
Portable power supply for this DVD video
camera/recorder. Charge it before use.
Mains lead:
Connect between household AC outlet and AC adapter/charger.
for DZ-HS501E and
DZ-HS500E
Lithium battery (model CR2032):
For DZ-HS501E only.
To power the remote control.
WARNING: Keep
this battery away
from children. If
swallowed, consult
a physician
immediately for
emergency
treatment.
Lens cap and lens cap string:
Attach the lens cap when not recording, to
protect the lens.
AC adapter/charger
(model DZ-ACS3 (E)):
Used to power the DVD video camera/
recorder from AC outlet, or charge battery.
for DZ-HS501E (UK) and
DZ-HS500E(UK)
AV/S output cable:
Used when viewing the picture played back
on the DVD video camera/recorder on TV
screen, or output video to another video
device.
Software CD-ROM:
Use this CD-ROM when connecting the
DVD video camera/recorder to PC.
DC power cord:
When powering the DVD video camera/
recorder from household AC outlet, use
this cord to connect the DVD video
camera/recorder and AC adapter/charger.
Infrared remote control
(model DZ-RM4W):
For DZ-HS501E only.
Use to control the DVD video camera/
recorder from a distance.
Shoulder strap:
Attach to the DVD video camera/recorder
to hang it from shoulder.
PC connection cable:
Use this cable when connecting the DVD
video camera/recorder to PC.
Disc cleaning cloth:
Always use this to clean discs.
18
Names of Parts
6
5
English
1294
7
(Inside the cover)
1 Hand strap attachment bracket (p. 23)
2 Stereo microphone
Take care that the microphone is not blocked
by a hand, etc., during recording.
3Recording indicator (p. 38, 44, 67)
The red indicator will light during recording.
4 Infrared receiver
(for DZ-HS501E only) (p. 25)
When the remote control is used to operate
the DVD video camera/recorder, this
receiver will receive the infrared signal.
5Optical 15× zoom lens
(for DZ-HS501E only)
Optical 30× zoom lens
(for DZ-HS500E only)
(p. 54)
3
8
10
6 Zoom lever (p. 54, 56, 72)
To adjust the zoom or volume.
7PC connection terminal (TO PC) (p. 125)
8 AV output jack (p. 116, 119)
9 External microphone jack (for DZ-HS501E
only) (p. 69)
10 Wide-screen colour liquid crystal display
(inside) (p. 35)
Although the external appearances of DZHS501E and DZ-HS500E are different, the
method of operating these models is identical.
DZ-HS501E illustrations are used in this
manual.
19
English
12 13 141815
1611
17
19 20 22 23
11 Viewfinder (p. 35)
12 Dioptre control (p. 35)
To adjust the focus of image appearing in the
viewfinder. (Pull out the viewfinder.)
13 SLEEP/RESTART button (p. 46)
To switch the sleep/restart status between
ON and OFF.
14 ACCESS/PC indicator (p. 9, 44)
Will blink or light when the HDD/DVD is
accessed (write or read), or the DVD video
camera/recorder is connected to a PC.
15 PHO
TO/SELECT button (p. 45, 78, 96)
16 DISC EJECT button (p. 41)
Press down and release this button to open
the cover of DVD insertion block.
17 DVD insertion block (p. 41)
21
18 BATTERY EJECT button (p. 31)
Press this button when removing the battery.
19 Battery attachment platform (p. 31)
20 Record button (REC) (p. 44)
21 LOCK switch (p. 44)
It is recommended that you set the LOCK
switch to (to the upper position) to prevent
the power switch in the “HDD” position
from accidentally moving to “DVD”.
22 Power switch (p. 34)
23 Hand strap (p. 23)
20
2725 26 28 29 3024
English
31 3733 34 35 3632 38 39
24 FULL AUTO button (p. 59)
To switch the DVD video camera /recorder
to full automatic.
25 FOCUS button (p. 56)
To switch between manual focus and autofocus.
26 MENU button (p. 36, 52, 89)
Press this button to display the menu for
setting camera functions and Disc
Navigation.
27 DISC NAVIGATION button (p. 70)
28 DUBBING button (p. 84)
29 STOP/EXIT button (p. 13, 52, 73)
To end playback or cancel setting of menu.
30 EXPOSURE button (p. 58)
Press this button to adjust the exposure.
31 Speaker (p. 72)
32 RESET button (p. 154)
To reset all settings to defaults (status when
the DVD video camera/recorder was
shipped from the factory).
33 DISPLAY (Screen display) button
(p. 47, 71, 77)
Press this button to display the details of
image being played back or camera setting
status, or switch the display off.
34 CARD ACCESS indicator (p. 9, 45)
35 QUICK MENU button (p. 52)
To display only the functions that you
frequently use (simple menus).
36 FINALIZE button (p. 111)
Press this button to finalise the recorded
DVD-RW/DVD-R/+RW.
37 Card insertion block (p. 43)
38 BLC (backlight compensation) button (p. 58)
Press this button when subject is being
lighted from rear.
39 2 / 1 / 0 / / / buttons
(p. 36, 52, 56, 58, 73, 74, 75)
Use these buttons to select a scene or menu item,
and then press the centre (
scene, or designate an option from the menu.
These buttons are also used to adjust the
exposure or focus.
40 Tripod threaded hole
Used to attach the DVD video camera/
recorder to a tripod.
) to play back the
40
21
English
41
42
43
44
45
46
47
41 PHOTO button (p. 45)
42 REC button (p. 44)
43 MENU button (p. 36, 52, 89)
REC
MENU
SELECT
DELETE
DISC
NAVIGATION
DISPLAY
48
DIGITAL
ZOOM
ZOOM
49
50
51
52
53
54
55
56
49 ZOOM T button (p. 54)
50 DIGITAL ZOOM button (p. 54)
51 ZOOM W button (p. 54)
44 SELECT button (p. 78, 96)
45 Reverse search button (p. 74)
46 DELETE button (p. 88)
47 DISC NAVIGATION button (p. 70)
48 DISPLAY button (p. 47, 71, 77)
52 Reverse skip button (p. 75)
53 Forward search button (p. 74)
54 Play/pause button (p. 73)
55 Stop button (p. 13, 52, 73)
56 Forward skip button (p. 75)
* The buttons on remote control will function the same as those on DVD video camera/recorder.
22
Setups
This section explains preparations for recording – setting up the DVD video camera/recorder
and battery.
Demonstration Function
This DVD video camera/recorder is equipped with a demonstration function.
The default at purchase time is “Auto”, which will automatically start the demonstration approx. ten
minutes after the DVD video camera/recorder, connected to the AC adapter/charger, is turned on and
left unoperated.
Refer to “CHANGING SETTING OF DEMONSTRATION” on page 38 if you
wish to view the demonstration immediately or change the setting to “Off”.
Setting Up the DVD Video Camera/Recorder
HOLDING DVD VIDEO CAMERA/RECORDER
Insert your right hand from the bottom of DVD video camera/recorder up to the base of your thumb.
Put your hand in a position where you can easily operate the REC button and the Zoom lever.
Adjust the length of hand strap so that the DVD video camera/recorder is stable when you press the
REC button with your thumb.
English
ATTACHING SHOULDER STRAP
Be sure to pass through the 2 slots.
Pass the shoulder strap through
the shoulder strap attachments.
23
ATTACHING LENS CAP
English
1 Attach the shorter end of lens cap string to
the lens cap.
2 Attach the longer end of lens cap string to the
hand strap of DVD video camera/recorder.
3 Push the both sides of cap inward and attach
it over the lens.
Note:
• Always keep the lens cap on when not using the DVD
video camera/recorder, to protect the lens.
• When recording, attach the lens cap to the hand strap
by hooking the tab inside the cap onto strap for
comfortable shooting.
Shorter end
Longer end
Push and fit
INSERTING BATTERY INTO REMOTE CONTROL
Insert the provided lithium battery into remote control.
1 While inserting a fine rod into the hole
marked PUSH, pull the battery holder out
forward.
2 Insert the lithium battery with the positive $
terminal facing down.
3 Slide the cover to close it.
Note:
The life of lithium battery is approximately one year. If
the battery is discharged, no operation is possible with
remote control: Replace the battery.
Battery holder
24
REMOVING BATTERY FROM REMOTE CONTROL
1 While pushing the battery holder, slide the
battery out.
Warn ing :
• KEEP THE BATTERY AWAY FROM CHILDREN AND
PETS.
• IF SWALLOWED, CONSULT A PHYSICIAN
IMMEDIATELY FOR EMERGENCY TREATMENT.
• BATTERY MAY EXPLODE IF NOT HANDLED
PROPERLY. DO NOT RECHARGE, DISASSEMBLE
OR DISPOSE OF IN FIRE.
●Using remote Control
Point the remote control to the infrared receiver on the DVD video camera/recorder. The remote
controllable distance is up to 5 m.
Note:
• When using the remote control, make sure that the
infrared receiver on DVD video camera/recorder is not
exposed to direct sunlight or any intense light. If the
infrared receiver is subject to light stronger than the
infrared light from remote control, the DVD video
camera/recorder cannot be operated by remote
control.
• If there is an obstacle between the remote control and
infrared receiver on DVD video camera/recorder,
remote control may not be possible.
:
Note
• Replace the battery with a Hitachi Maxell, Sony,
Panasonic, Sanyo, Toshiba CR2032, or Duracell
DL2032. Use of another battery may present a risk of
fire or explosion.
• Dispose of battery safely in accordance with local
laws. Do not dispose of in fire.
• Do not short circuit the battery.
• Do not hold the battery with the metallic tweezers.
• Keep the battery in a dark, cool, dry place.
• The remote control (DZ-RM4W) and lithium battery
(CR2032) are supplied only with the DZ-HS501E.
• The DVD video camera/recorder uses the “VCR2”
remote control code of Hitachi VCRs. If you use a
Hitachi VCR, etc. with remote control code set to
“VCR2”, a VCR placed near the DVD video camera/
recorder will also be operated by the remote control:
To prevent this, change the remote control code of the
VCR.
English
25
English
HDD/DVD/Cards
The following table lists the storage media (discs and cards) that can be used on this DVD video
camera/recorder and the functions which are available with them:
Media
Function
HDD
DVDRAM
DVD-RW
mode)
To record video (p. 44) ●●●●●●—
To record photo (p.45) ——————●
To dub on DVD (p. 83) ● ——————
To delete image just
recorded (p. 73)
To select image and delete it
(p. 88)
●●●—— ●●
●●●——— ●
To edit image (p. 89 – 90) ●●●————
To play on other DVD players
and DVD recorders (p. 111)
To use new disc or new card
without formatting
To initialise and reuse
(p. 108)
To additionally record on
finalised disc (p. 112)
To edit copied video on PC
(p. 120)
To playback video on PC
(p. 120)
*
1: Playable on devices that conform to either 8 cm DVD-RAM, 8 cm DVD-RW (VR mode) or 8cm +RW.
*
2: Must be finalised. Cannot be played on some DVD players or DVD recorders.
*
3: Some DVD devices conform to SD memory card.
*
4: When media that are sold “formatted” are used. If the initialisation format differs, the media can be initialised on
this DVD video camera/recorder and then used.
*
5: To additionally record, the finalised disc must be unfinalised.
*
6: The provided software is used.
*
7: Finalise the disc when editing/playing back on PC.
— ∴
— ●
●●●●— ●●
——●●*5— ●
*6
●
*6
●
*1
*4
*6
●
*6
●
DVD-RW
(VR
(VF
DVD- R +RW
mode)
*1*2
∴
*2
●
*2
●
*1*2
∴
——● — ●
*5
*6*7
●
*6*7
●
*6*7
●
*6*7
●
●: Functions available; —: Not available
*6*7
●
*6*7
●
*6*7
●
*6*7
●
memory
SD
card
—
*4
—
—
—
*3
26
HDD, DISCS
HDD, and usable discs and marks (logos) Function
Allows extensive recording (approx. 11 hours in FINE
HDD
DVD-RAM Ver. 2.1 (8 cm)
mode).
Allows you to delete unnecessary scenes or edit
scenes.
Allows you to delete unnecessary scenes or edit
scenes.
English
DVD -RW
[Ver1.1 (8 cm) 2x speed (2x/1x)]
DVD -R
[for General Ver. 2.0 (8 cm)]
+RW Ver. 1.2 (8 cm)
*
1: Playback on all DVD players is not guaranteed. The disc must be finalised before being played back on a DVD
player.
*
2: Playback on all DVD players is not guaranteed.
Note:
• This DVD video camera/recorder can use only the 8-cm bare discs not packed in a square car tridge, square
caddy case or round DVD holder. The discs in a square cartridge, square caddy case or round DVD holder can be
used if they are removed from the package, but take great care not to dirty or scratch the bare disc.
•It is recommended that you use Hitachi Maxell HG type single-sided discs, since their compatibility with
this DVD video camera/recorder has been confirmed.
When using an HG type double-sided disc, take great care with handling it. Using a disc other than these discs
may not allow the DVD video camera/recorder to deliver optimum performance.
Allows you to choose the VR mode for deleting
unnecessary scenes or editing scenes, or the VF
mode in which deletion or editing is not possible, but
high compatibility with DVD players is provided *1.
Provides high compatibility with DVD players *1. No
deletion or editing is possible.
Provides high compatibility with DVD players but does
not need to be finalised *2. Scenes can be deleted
immediately after being recorded.
INFORMATION ON DVD-R
For optimum recording on DVD-R, this DVD video camera/recorder writes control data to the disc
in order to automatically make adjustments when it is inserted and ejected accompanying recording.
If the disc has no area to be written for adjustment, recording may not be possible. To prevent this,
do not insert or eject a DVD-R accompanying recording more than 100 times.
This DVD video camera/recorder cannot record a DVD-R in the VR mode.
NOTES ON FINALISATION
• Do not insert a DVD-RW/DVD-R recorded or dubbed on this DVD video camera/recorder but
not finalised, into a recordable device, such as a DVD recorder: The recorded data may be
damaged.
• Use only DZ-HS501E/HS500E to record/dub or finalise a DVD-RW (VF-mode)/DVD-R/+RW
recorded or dubbed on this DVD video camera/recorder but not finalised: Using any other device
could damage the data recorded on the disc.
• DVD-RW/DVD-R/+RW edited and finalised on PC or those finalised on another DVD recorder
may not be playable on this DVD video camera/recorder, depending on the editing software used
or recorded status of DVD-RW/DVD-R/+RW.
•
If you insert a DVD-R recorded on a DVD video camera/recorder other than DZ-HS501E/HS500E and not
finalised, the Disc Navigation screen will automatically start, and no recording can be done on the disc nor
can it be finalised.
•
Do not insert a DVD-RW/DVD-R that was recorded by a DVD recorder manufactured by a company other
than Hitachi, and which has not been finalised, in this DVD video camera/recorder: Doing so will make the
disc unusable.
27
EXAMPLES OF DISCS THAT CANNOT BE USED ON THIS DVD VIDEO
English
CAMERA/RECORDER
• CD
• CD-R
• CD-RW
• CD-ROM
• DVD-ROM
• DVD-Video
• DVD-R (4.7 GB) for Authoring Ver. 2.0
• DVD-R DL (Dual Layer)
• DVD-RW DL (Dual Layer)
• +R DL (Double Layer)
• +RW DL (Double Layer)
• +R
• Discs other than those with diameter of 8 cm
AVAILABLE CARDS
SD memory cards can be used on this DVD video
camera/recorder (incompatible with 2 GB).
When using an exclusive adapter, a miniSD
memory card and micro SD memory card can be
used in the same way as an SD memory card.
No SDHC card or multimedia card can be used.
●Handling card
• Do not use cards other than
the designated ones.
• Be sure to perform trial
recording before recording
vital images.
• Do not touch the card
terminal or allow it to touch
metal.
• Do not paste anything other
than exclusive label on label pasting portion.
• Do not subject card to impact, bend or drop it.
• Do not disassemble card or modify it.
• Do not expose card to water.
• Do not use or store card in the following
places:
− Where the temperature is high, such as in
vehicle at high temperatures, under burning
sun or near a heater
− Where humidity is high, or in dusty place
• When the erasure prevention switch is locked,
no recording, deletion or editing will be
possible on the card: Only playback will be
possible.
Terminal
CAUTIONS FOR DISC AND CARD
• It is recommended that you create a backup
file for valuable data on hard disk of PC.
• Do not do the following, or the data on disc or
card may be damaged or lost:
− Do not remove the disc or card or turn DVD
video camera/recorder off during reading or
writing of data
− Do not use DVD video camera/recorder in a
place subject to static electricity or electrical
noise
− Do not have printing done at a print lab or
DPE service
− Do not leave a DVD unused in the DVD
video camera/recorder for a long time
Note:
•
This DVD video camera/recorder can play back image
data recorded on other digital cameras conforming to
the DCF (Design rule for Camera File system) standard.
The range of image data playable on this DVD video
camera/recorder is that with pixels from 80 horizontal ×
60 vertical to 4000 horizontal × 3000 vertical.
• DCF is an integrated image file format of digital
cameras: Image files can be used on all digital
devices conforming to DCF.
• Image data edited on PC and certain types of image
data may not be visible on this DVD video camera/
recorder.
• The image data recorded on another device may not
be playable on this DVD video camera/recorder.
Erasure prevention
switch
28
Locked status
Preparations for Power Supply
USING DVD VIDEO CAMERA/RECORDER WITH AC ADAPTER/CHARGER
It is recommended that you use the AC adapter/charger to power the DVD video camera/recorder
from household AC outlet when you perform settings on it, play back or edit images, or use it
indoors.
Note:
Be sure to use the specified AC adapter/charger (DZ-ACS3 (E)) to power the DVD video camera/recorder. Using
other AC adapter/chargers could cause electric shock or result in fire.
Mains lead
To AC outlet
* The shape of plug
AC adapter/charger
DC power cord
varies depending
on the model.
1 Connect the mains lead to AC adapter/
charger.
2 Plug the mains lead into AC outlet.
3 Plug one end of DC power cord into the DC
output jack on AC adapter/charger.
English
4 Attach the other end of DC power cord to the
battery attachment platform on DVD video
camera/recorder.
Use the same procedure as that for battery
when attaching and detaching the DC power
cord: See page 31.
29
English
Setting Up the Battery
The DZ-BP07PW battery provided has not been charged at purchase time: Charge it before using
the DVD video camera/recorder.
Note:
• Be sure to use the DZ-BP07PW, DZ-BP14SW (optional) or DZ-BP7SW (optional) battery for the DVD video
camera/recorder: Using other batteries could cause the DVD video camera/recorder to malfunction, or result in
fire.
• Be sure to use the DZ-ACS3 (E) AC adapter/charger to charge the battery: Using other chargers could cause
electric shock or fire.
• Charge the battery at temperatures of 10 – 30ºC.
• If the CHARGE indicator does not light when the AC adapter/charger is plugged into AC outlet, unplug it from the
AC outlet, wait a few moments, and then plug it into the AC outlet again. If the CHARGE indicator still does not
light, the AC adapter/charger may be faulty. Unplug it from the AC outlet and consult your dealer.
• The AC adapter/charger can be used around the world. An AC plug adapter is required in some foreign countries.
If you need one, purchase it from your local electronics distributor.
CHARGING BATTERY
Use the provided AC adapter/charger to charge the battery.
1 Connect the mains lead to AC adapter/
charger.
2 Plug the mains lead into AC outlet.
CHARGE indicator
DC output jack
3 Attach the battery to AC adapter/charger.
Note:
When charging a battery, unplug the DC power cord
from the DC output jack on AC adapter/charger.
Battery
Mains lead
AC adapter/charger
To AC outlet
* The shape of plug
varies depending
on the model.
30
●Battery charged status
You can find out the charged status of battery by checking the CHARGE indicator on AC adapter/
charger:
Charge status CHARGE indicator
During charge Lit
Charge complete Goes out
Note:
See “Troubleshooting” on page 147 when the CHARGE indicator blinks.
●Reference for time required to charge battery (at approx. 25ºC):
DZ-BP07PW (provided)/DZ-BP7SW (optional): Approx. 90 minutes
DZ-BP14SW (optional): Approx. 165 minutes
The charge time will vary depending on the remaining power level of battery.
ATTACHING BATTERY TO DVD VIDEO CAMERA/RECORDER
English
1 Fit the battery to the battery attachment
platform on this DVD video camera/recorder
and slide it downward until a click is heard.
Te r mi n a l
side must be
down.
Note:
• Make sure that the battery is in the correct orientation.
• Make sure that the battery is securely attached:
Incomplete attachment could cause the battery to fall,
resulting in damage.
REMOVING BATTERY
After using the DVD video camera/recorder, remove the battery from it.
1 While holding down the BATTERY EJECT
button, slide the battery upward to remove it.
Note:
• For safety, be sure to turn the DVD video camera/
recorder off before attaching or removing the battery.
• Be careful not to drop the removed battery.
• If the battery remains attached, minute level current
will flow even if the DVD video camera/recorder is off,
and the battery will discharge.
• Set the power switch to OFF before removing the
battery.
31
●Continuously recordable time with fully charged battery (with no zoom
English
operation, etc.)
See the following table as a reference for how long the DVD video camera/recorder can
continuously be used with a fully charged battery:
With DZ-BP07PW (provided)/DZ-BP7SW (optional)
Video mode
XTRA
FINE
STD
When using viewfinder approx. 80 min approx. 70 min approx. 100 min approx. 85 min
When using LCD monitor approx. 70 min approx. 65 min approx. 90 min approx. 75 min
When using viewfinder approx. 80 min approx. 70 min approx. 100 min approx. 85 min
When using LCD monitor approx. 70 min approx. 65 min approx. 90 min approx. 75 min
When using viewfinder approx. 80 min approx. 80 min approx. 100 min approx. 100 min
When using LCD monitor approx. 70 min approx. 70 min approx. 90 min approx. 85 min
With DZ-BP14SW (optional)
Video mode
XTRA
FINE
STD
• The time is only for reference: It will vary depending on recording contents.
When using viewfinder
When using LCD monitor
When using viewfinder
When using LCD monitor
When using viewfinder
When using LCD monitor
The reference for how long the DVD video camera/recorder can actually be used
will be approx. 1/2 to 1/3 of the above time:
The continuously recordable time of DVD video camera/recorder in the above table shows the time
available when the DVD video camera/recorder is in the recording mode without using any other
function after recording is started. In actual recording, the battery will discharge 2 – 3 times faster
than this reference, since the REC button and zoom are being operated, and playback is performed.
Assume that the actually recordable time with a fully charged battery is between 1/2 and 1/3 of the
above time, and prepare enough batteries to allow for the time you are planning to record on the
DVD video camera/recorder.
The continuously recordable time may be less depending on the conditions when the DVD video
camera/recorder is used (if recording and recording pause are repeated at short intervals, etc.).
Note that the battery discharges faster in cold places.
DZ-HS501E DZ-HS500E
HDD DVD HDD DVD
DZ-HS501E DZ-HS500E
HDD DVD HDD DVD
approx. 165 min approx. 145 min approx. 200 min approx. 170 min
approx. 145 min approx. 130 min approx. 180 min approx. 150 min
approx. 165 min approx. 145 min approx. 200 min approx. 170 min
approx. 145 min approx. 130 min approx. 180 min approx. 150 min
approx. 165 min approx. 170 min approx. 200 min approx. 210 min
approx. 145 min approx. 145 min approx. 180 min approx. 170 min
Note:
• See “Troubleshooting” on page 147 when charging is not possible.
• The charge time will vary depending on the battery remaining level.
• During and after charging, and when the DVD video camera/recorder is being used, the battery will be warm, but
this does not indicate a fault.
• A battery cannot be charged while the DC power cord is connected to the DC output jack of AC adapter/charger:
Unplug the DC power cord when charging a battery.
• Charge the battery at ambient temperature 10ºC to 30ºC: Charging at temperatures other than this range could
damage the battery.
32
BATTERY REMAINING LEVEL INDICATOR
When the battery is used to power the DVD video camera/recorder, the battery remaining level
appears in the viewfinder or on the LCD screen as follows:
Fully charged Nearly empty
White portion shows remaining level (Blinks)
EFFICIENT USE OF BATTERY
• The battery will slightly discharge even if it is
detached from the DVD video camera/
recorder.
• If the battery is left attached to DVD video
camera/recorder, it will consume a slight
amount of power. Therefore, it is
recommended that you charge the battery
shortly before using the DVD video camera/
recorder, usually on the day before you plan to
use it.
When not using the DVD video camera/
recorder for an extended period:
It is recommended that you fully charge the
battery once a year, attach it to DVD video
camera/recorder and use it up; then remove the
battery and store it in a cool place again.
Battery life:
The battery life varies greatly depending on the
ambient environment and how often the DVD
video camera/recorder is used. If the usable
time of DVD video camera/recorder with a fully
charged battery is noticeably short, the battery is
probably dead: Purchase a new one.
Power save and discharge of battery:
It is recommended that you turn the DVD video
camera/recorder off in status other than
recording, since even during recording pause
battery power is consumed at the same level as
during recording.
If, when you specify Power Save On, the
recording pause status continues for
approximately 5 minutes, the DVD video
camera/recorder will automatically turn off.
To set or release power save, see “TURNING
DVD VIDEO CAMERA/RECORDER OFF
AUTOMATICALLY (POWER SAVE)” on
page 37.
English
33
English
Turning DVD Video Camera/Recorder On and
Off
While holding down the grey button at the right
of power switch, set the switch according to
each recording function:
Set to “OFF”:
The DVD video camera/
recorder will turn off
Set to “SD”:
To record photos on an SD
memory card and play
them back
Set to “HDD”:
To record or dub movie on
HDD and play it back
Set to “DVD”:
To record movie on DVDRAM/DVD-RW/DVD-R/
+RW and play it back
P
Note:
• Once you turn the DVD video camera/recorder on to
let it recognise the disc, you can immediately record
or play back by turning the DVD video camera/
recorder on again. However, if a long time has
elapsed after the disc was inserted, it will take some
time for the DVD video camera/recorder to start
because it must recognise the disc again (see
“Troubleshooting” on page 147).
• It will take some time for the DVD video camera/
recorder to display the Disc Navigation screen after
power is turned on.
• When the DVD video camera/recorder is turned on,
the self-diagnosis function will work and a message
may appear. In this case, refer to “Trouble Messages”
on page 140 and take corrective action.
• When turning the DVD video camera/recorder off or
changing over the power switch between “HDD” and
“DVD”, you will not need to hold down the grey button:
Simply move the power switch.
34
Power switch
Viewing Images
VIEWING IMAGE ON LCD MONITOR
SCREEN
If you open the LCD monitor, you can monitor
subject image on the LCD screen.
1 Open the LCD monitor.
The LCD monitor has a portion where you
can hook your finger. Hook the finger there to
open the monitor.
●Range where the LCD monitor can
be moved
The LCD monitor can be opened up to
approximately 90º.
If the LCD monitor is open 90º, it can be tilted
with the screen down as much as 90º, and can
also be tilted with screen up and turned up to
180° so the screen faces in the same direction as
the lens.
If the LCD monitor is turned 180º so the screen
faces in the same direction as the lens during
recording, subject image will also appear in the
viewfinder as a mirror image (left/right
reversed).
Tilt the LCD monitor to adjust its vertical angle
so that you can see the screen easily.
Note:
• If no image appears on LCD monitor screen, refer to
“Troubleshooting” on page 147.
• If LCD monitor lights white, refer to page 61.
• Be sure to open the LCD monitor approximately 90º
before changing its vertical angle.
• Do not record for a prolonged time with the LCD
monitor turned approximately 180º in close contact
with the DVD video camera/recorder body: Doing this
could cause the DVD video camera/recorder and LCD
monitor to become hot.
VIEWING SUBJECT THROUGH
VIEWFINDER
1 Pull out the viewfinder.
2 Turn the dioptre control knob to adjust the
focus to suit your eyesight.
Note:
• If no image appears in viewfinder, refer to
“Troubleshooting” on page 147.
• If the LCD monitor is opened approximately 90º, the
viewfinder will be off: Turn the open LCD monitor 180º
so that it faces the same direction as the lens; the
image will appear in the viewfinder.
• Focusing will not be correct unless the viewfinder is
pulled out.
• See “LCD/EVF Setup” (on page 40) if you wish to
display images in the viewfinder regardless of
whether you open or close the LCD monitor.
Dioptre control
Pull out the viewfinder
until a click is heard.
Viewfinder
English
180º
90º
Hook your finger
(Bottom)
35
HDD
HDD
English
Setting Date and Time
Set the current date and time so that the date and time you make a recording can be recorded
correctly.
The following procedure can also be used to correct the date and time you have already set.
Use 2 / 1 / 0 / / buttons
to select, and then press to
designate.
1 Press the MENU button, use the 2/1/
0// buttons to choose “Date Set” on the
“Date Setup” menu screen.
2 Press the / button.
The figure for the day
will be selected.
[The digit that is
highlighted first depends on the date display
format (set up in Date Mode): The digit on the
left end of the date display will be first
highlighted.]
Note:
After setting the figure for the day, press the /
button to select the digit to be set. If you press the
button after selecting the figure for the day, the
screen for verifying the set date will appear instead
of screen for setting month, year or time.
3 Press the 0 or /
button to select the digit
you want to set in
sequence.
Da te Set u p
Da t e Se t 1 / 1 /2007
Dat e Mode
ENTER RETURN
Da te Set u p
1/ 3/2007
Da t e Se t
Dat e Mode
ENTER RETURN
0: 00
0:00
Press the 2 or 1 button to select the
number for current date/time, and then
repeat step 3 to set the current date and time.
Note:
To stop date/time setting midway, press the
button.
4 After setting the current
date and time, press the
button.
The screen for verifying
Da te Set
1/ 3/ 2007 8 :00
Da te set up?
YES NO
ENTER
the set date will appear.
5 If the displayed date and time are correct,
press the 0 button to choose “YES”, and
then press the button.
The date and time will be set, and the DVD
video camera/recorder will enter the
recording pause status.
Choosing “NO” will restore the menu screen.
CHANGING DISPLAY FORMAT OF DATE AND TIME
You can select one of three date display formats: day/month/year, month/day/year or year/
month/day. Choose “Date Mode” on the “Date Setup” menu screen in procedure 1, and then set to
the desired date display mode.
Note:
This DVD video camera/recorder incorporates a rechargeable battery to store the date and time in memory. If this
built-in battery is exhausted, the date and time will be reset. To prevent this, every 6 months, connect the AC
adapter/charger to DVD video camera/recorder and connect them to AC outlet, or attach a charged battery to the
DVD video camera/recorder, and leave it for at least 24 hours with the DVD video camera/recorder turned off: The
built-in battery will recharge.
36
HDD
HDD
Initial Settings
Press the MENU button, and then use 2/1/0/// buttons to display the “Initial Setup”
menu screen. See page 52 for detailed operation procedure. Press the MENU button again to exit
setting.
SWITCHING OPERATING SOUND ON OR OFF (BEEP)
Select “On” or “Off”, and
then press the button.
On: Beep will be heard
when the power
switch is changed
In i t ia l Setup
Beep
Power Save
Record LED
Language
Demo Mo de
Reset
ENTER RETURN
On
Of f
over, the REC button is pressed when
HDD/disc is used, the SLEEP/RESTART or
EJECT button is pressed, etc.
Off: No beep is heard.
TURNING DVD VIDEO CAMERA/RECORDER OFF AUTOMATICALLY
(POWER SAVE)
Select “On” or “Off”, and
then press the button.
On: To engage power
save. If the DVD
video camera/
recorder is left in the recording pause status
without being operated for 5 minutes, it
will automatically turn off to prevent the
battery from discharging needlessly.
Off: To cancel power save.
In i t ia l Setup
Beep
Power Save
Record LED
Language
Demo Mo de
Reset
ENTER RETURN
On
Of f
Note:
The “Beep” setting will be stored in memory even when
the DVD video camera/recorder is turned off.
Note:
• To turn the DVD video camera/recorder on again from
automatic off activated by the power save function,
set the power switch to “OFF”, and then set it to
“HDD”, “DVD” or “SD”.
• The Power Save setting will not appear in the onscreen information display.
• If the sleep/restart standby status continues for 30
minutes, the DVD video camera/recorder will
automatically turn off regardless of the Power Save
setting.
English
CHANGING DISPLAY LANGUAGE (LANGUAGE)
You can change the language used to display the menu and information.
The following shows that English is changed to French.
1 Press or / button
with the screen shown
on the right displayed:
The “Language” screen
will appear.
2 Choose “Français”, and
then press button.
The display will change
to French.
In i t ia l Setup
Beep
Power Save
Record LED
Language
Demo Mo de
Reset
ENTER RETURN
Language
Eng l i s h
Español
Italiano
ENTER RETURN
Fr ançais
Deutsch
On
Off
On
Eng l i s h
Auto
Note:
The language setting will be stored in memory even
when the DVD video camera/recorder is turned off.
37
RESETTING MENU SETTINGS TO DEFAULTS (RESET)
English
You can restore menu settings to defaults (initial settings at the factory (p. 154)). (Note, however, that
the date/time will not be reset.)
1 Choose “Reset” on the
“Initial Setup” menu
screen, and then press
the button.
In i t ia l Setup
Beep
Power Save
Record LED
Language
Demo Mo de
Reset
ENTER RETURN
On
Off
On
English
Auto
2 If you are sure that you
wish to reset, use the
0 button to choose
“YES”, and then press
the button.
Reset
Reset?
YES NO
ENTER
The screen for verifying reset will appear.
The setting items have now been reset to
defaults.
Note:
To cancel resetting midway, choose “NO” on the screen
for verification in step 2 or press the button.
TURNING RECORD LED ON OR OFF (RECORD LED)
You can switch off the recording indicator on the front of DVD video camera/recorder even during
recording.
Select “On” or “Off”, and
then press the button.
On: The recording
indicator will light
red to show that the
In i t ia l Setup
Beep
Power Save
Record LED
Language
Demo Mo de
Reset
ENTER RETURN
On
On
Of f
DVD video camera/recorder is recording.
Off: The recording indicator will not light even
during recording.
Note:
• The Record LED setting will not appear in the on-
screen information display.
• The Record LED setting will be stored in memory
even when the DVD video camera/recorder is turned
off.
• Specify “Record LED: Off” when recording a subject
behind a glass or water tank that reflects light: The
reflected light of the recording indicator will not be
recorded.
• Even if “Record LED: Off” is specified, the recording
indicator will light while the self-timer is counting
down.
CHANGING SETTING OF DEMONSTRATION
Choose the desired option
using the screen on the
right, and then press the
button.
Ini ti al Setup
Beep
Power Save
Record LED
Language
Demo Mode
Reset
ENTER RETURN
Auto: To start demonstration if the DVD
video camera/recorder connected to
AC adapter/charger is inactive for
approx. 10 minutes or more after it is
turned on.
Off: To set demonstration to off.
Start: To start demonstration immediately.
Auto
Off
Start
Note:
• If “Auto” is specified, the demonstration will not start if
a battery is connected.
• Pressing the (STOP/EXIT) or DISC NAVIGATION
button will exit demonstration.
• If “Auto” is specified, the demonstration will not start
when the power switch on this DVD video camera/
recorder is set to “DVD” and a DVD is loaded, or when
the power switch is set to “SD” and a card is loaded.
• The demonstration function will not work when the
DVD video camera/recorder is connected to PC.
• While the demonstration is being given, the recording
indicator will blink.
38
HDD
HDD
LCD/EVF Setup
ADJUSTING BRIGHTNESS OF LCD SCREEN (LCD BRIGHTNESS) AND
VIEWFINDER (EVF BRIGHTNESS)
1 Press the MENU button, use the 2/1/
0/// buttons to choose “LCD/EVF
Adjust” on the “LCD/EVF Setup” menu
screen, and then choose “LCD Brightness”or
“EVF Brightness”.
The brightness adjustment bar will appear on
the screen.
2 Use the 0// buttons
for adjustment.
Press 0 :
The screen becomes
dimmer.
Press / :
The screen becomes
brighter.
LCD/ EVF Ad j u s t
LCD Br i gh tness
EVF B r ig ht ness
Co lo u r Le ve l
adjustment bar
ENTERADJUST
Brightness
3 Press the button to end the setting.
Note:
• To stop the setting midway, press the MENU button.
• The brightness setting will be stored in memory even
after the DVD video camera/recorder is turned off.
English
39
ADJUSTING COLOUR DENSITY (COLOUR LEVEL)
English
You can adjust the colour density of the LCD monitor screen and viewfinder.
1 Press the MENU
button, use the 2/
1/0///
buttons to choose
“LCD/EVF Adjust” on
LCD/EVF Se t up
LCD/EVF Adj us t
EVF D i s p l a y
ENTER RETURN
the “LCD/EVF Setup” menu screen, and then
choose “Colour Level”.
Aut o
3 Press the button to end the setting.
Note:
• To stop the setting midway, press the MENU button.
• The colour setting will be stored in memory even after
the DVD video camera/recorder is turned off.
• Even if the brightness or density of LCD monitor
screen or viewfinder is changed, the brightness or
density of the recorded image itself will not change.
The colour density adjustment bar will
appear on the screen.
2 Use the 0// buttons
for adjustment.
Press 0 :
For lighter colour.
Press / :
For denser colour.
LCD/ EVF Ad j u s t
LCD Br i gh tness
EVF B r ig ht ness
Co lo ur L eve l
Colour density
adjustment bar
ENTERADJUST
ALWAYS DISPLAYING IMAGE IN VIEWFINDER
1 Press the MENU
button, use the 2/
1/0///
buttons to choose “EVF
Display” on the “LCD/
EVF Setup” menu screen.
LCD/EVF Se t up
LCD/EVF Adj us t
EVF D i s p l a y
ENTER RETURN
2 Choose “On” and press the button.
Aut o
O
n
Auto: If the LCD monitor is open, no image
On: Images will always appear in the
Note:
The setting on EVF Display will be stored in memory
even after the DVD video camera/recorder is turned off.
will appear in the viewfinder.
viewfinder regardless of whether the
LCD monitor is open/closed.
40
Inserting and Removing Disc
Set the power switch to “DVD” or “OFF” .
1
When the power switch is set to “HDD” or
“SD”, the cover of disc insertion block will
not open. When “Please insert DVD.” appears
during dubbing, however, the cover of disc
insertion block will open even when the
power switch is set to “HDD” (see p. 83).
2 Press down the DISC EJECT button once and
release it.
A few moments after the ACCESS/PC
indicator blinks, the cover of disc insertion
block will open.
When removing the disc:
While pushing down the centre portion of
turntable, pick up the disc, holding its edge,
to remove it.
Tu r nt a b le
3 Gently open the cover by hand fully until it
stops.
• Note that the recording surface of disc must face
the inside of DVD video camera/recorder. When
using a single-sided disc, the recording surface is
the side without label.
• Never touch the disc recording surface or pickup
lens. Touching the pickup lens could cause a fault.
4 When inserting a disc:
Push the disc against the turntable at the
centre to lock it until a click is heard.
• Use the disc cleaning cloth provided to wipe off
any dirt adhering to the disc recording surface.
• Do not use a dirtied or scratched disc.
5 Push the section marked “PUSH CLOSE” on
the cover of disc insertion block, to close the
cover.
Then the DVD video camera/recorder will
automatically recognise the disc: While the
ACCESS/PC indicator is lit, do not cut off the
power supply, and do not subject the DVD
video camera/recorder to any vibrations or
impact.
English
Pickup lens
Push the shaded
portion.
41
Note:
English
•
If the cover of disc insertion block is open, the ACCESS/PC indicator will blink when an image is displayed on the LCD
monitor screen: In this case, the DVD video camera/recorder will not turn off even if the power switch is set to “OFF”.
If the cover remains open after a while, the DVD video camera/recorder will automatically turn off.
• Disc cannot be inserted or removed unless a charged battery or AC adapter/charger is connected to the DVD
video camera/recorder.
• If there is some delay before recording starts, refer to “Troubleshooting” on page 147.
• Do not close the cover if a disc is not properly loaded on the turntable.
• If a single-sided disc is inserted into DVD video camera/recorder with the printed label facing the inside, an error
message will appear. Remove the disc and reinsert it with its recording side facing the inside. See “Trouble
Messages” on page 140.
• Do not remove the battery or disconnect the AC adapter/charger during removal of the disc or until power is
completely turned off: If you do, the disc cover will not open. If this happens, reattach the battery or AC adapter/
charger, push down the DISC EJECT button once, and then release it.
• Do not insert anything other than the 8 cm DVD-RAM/DVD-RW/DVD-R/+RW into the disc insertion block: Doing
so could cause malfunctions.
• When inserting or removing the disc, BE SURE NOT to look into the lens in laser pickup: Doing so could damage
your eyesight.
• Close the cover of disc insertion block gently: Using force could cause a fault.
• When using double-sided disc
Recording is possible on both sides of double-sided disc. However, when recording or playback on one side is
finished, recording or playback will not move automatically to the other side. Remove the disc once from the DVD
video camera/recorder, turn over the disc and insert it again for continued use.
The recording surfaces of double-sided disc are likely to become dirtied or scratched: Always make sure that
there is no dirt or scratch on the recording surface facing the pickup lens, and then use the disc taking great care
that it is not dirtied or scratched. Use the provided disc cleaning cloth to wipe off any dirt on disc (see page 12).
●When using brand-new DVD-RW/+RW
When a disc is first loaded in the DVD video camera/recorder, the “Format DVD” screen will
appear.
When recording on this DVD video
camera/recorder:
Choose “Yes” on the “Format DVD” screen, and
then press the button.
When using DVD-RW, choose the recording
format (VR or VF mode), and then press the
button.
The disc will be formatted.
For
m
Format DVD
DVD is not formatted.
Format the DVD now?
YES NO
ENTER
at DVD
DVD Format.
Selec t record for
VR Mode VFMode
ENTER
m
at.
(When using DVD-RW)
42
When recording data from PC:
While the “Format DVD” screen is displayed,
choose “No” and then press the button, or
press the button.
However, if data from PC has not yet been
recorded, the disc can be made usable on this
DVD video camera/recorder. When inserting
the disc into this DVD video camera/recorder,
the same message will appear: If you wish to use
it on this DVD video camera/recorder, choose
“YES”.
Inserting and Removing Card
Open the LCD monitor.
1
2 Turn the DVD video camera/recorder off.
3 Open the cover of card insertion block.
4 Inserting Card:
Insert card with its terminal inward until it
locks.
Removing Card:
Push the centre of card edge.
The card will come out so that it can be held
by fingers.
English
5 Close the cover of card insertion block.
Note:
• Always close the cover of card insertion block: Placing
the DVD video camera/recorder on a desk, etc. with
cover open could damage the cover.
43
Basic Techniques
HDD
English
This section explains about recording of movies and still images, and also basic settings on
DVD video camera/recorder.
HDD
Recording Movie
Before You Begin
Pressing REC
once will start
recording;
pressing it once
again will
temporarily stop
recording.
Remove the lens cap, and then point the DVD
1
video camera/recorder at subject.
• When setting the power switch to “DVD”, insert a recordable DVD-RAM/DVDRW/DVD-R/+RW into this DVD video camera/recorder.
ACCESS/PC
indicator
2 Turn the DVD camera/recorder on.
Set the power switch to “HDD” or “DVD” to
turn the DVD video camera/recorder on.
After the ACCESS/PC indicator goes out,
perform the subsequent operation:
3 Check the subject on the screen (viewfinder
or LCD).
When using the viewfinder, close the LCD
monitor before pulling out the viewfinder.
4 Press the REC button.
The “9” mark in the viewfinder or on the
LCD screen will change to the “:” mark,
and recording will start.
During recording, the recording indicator on
the front of DVD video camera/recorder will
light.
Pressing REC again during recording will set
the DVD video camera/recorder to the
recording pause status.
Note:
• See “Troubleshooting” on page 147 when recording
movie is not possible.
• See “Troubleshooting” on page 147 if it takes some
time before recording is possible.
• See “Troubleshooting” on page 147 if the DVD video
camera/recorder does not operate.
• See page 47 for on-screen information display.
• It is recommended that you set the LOCK switch to
(the upper position) to prevent the power switch in the
“HDD” position from accidentally moving to “DVD”
position.
• When using a DVD-RW (VF-mode)/DVD-R, videos of
different qualities (VIDEO Modes) or 16:9 On and Off
cannot be recorded or dubbed on the same disc (see
page 83).
• While the ACCESS/PC indicator is lit or blinking, do
not turn the DVD video camera/recorder off, and take
care not to subject it to any vibration: Doing so could
cause an error in the recorded data, which could
make it unplayable (see page 9).
• The minimum recordable time of movie is
approximately 3 seconds.
• Hitachi cannot be responsible for video and audio that
cannot be recorded or edited because of any defect.
• Each time the DVD video camera/recorder enters the
recording pause status, the counter display will be
reset to “00:00:00”.
• After recording for 9 hours when using HDD, the DVD
video camera/recorder will automatically stop
recording: After approx. one minute, it will
automatically restart recording. (no scene will be
recorded during this recording pause.) As a result,
multiple thumbnails will appear for the scene recorded
continuously for more than 9 hours, even with onetime recording of that scene. Mark “:” will
continue to appear on the screen while the DVD video
camera/recorder is automatically pausing when it has
continued recording for more than 9 hours.
5 When recording is finished, turn the DVD
video camera/recorder off.
44
Recording Stills
Note:
Recording of still images is possible on card.
PHOTO/SELECT
button
CARD ACCESS indicator
1 Remove the lens cap, and then point the DVD
video camera/recorder at subject.
2 Turn the DVD camera/recorder on.
Set the power switch to “SD”.
After the CARD ACCESS indicator goes out,
perform the subsequent operation:
3 Check the subject on the screen (viewfinder
or LCD).
English
5 Press the PHOTO/SELECT button all the way
(full pressing).
The screen will be black, and then the
recorded still will be displayed. When the
“9” mark appears, you can proceed with
the next recording; while “CARD ACCESS” is
being displayed, you cannot proceed with the
next recording.
Note:
• If you wish to record without locating a subject at the
centre of screen, first locate the subject at the centre
of screen, press the PHOTO/SELECT button halfway
down, determine the composition to be recorded, and
then press the PHOTO/SELECT button all the way
down.
• If you press the PHOTO/SELECT button all the way
down at one stroke without pressing it half way,
recording will be possible, but the focus may be
incorrect.
• See “Size And Quality Of Photos” on page 158 for
details of photos on card.
• See “Troubleshooting” on page 147 if recording
photos is not possible.
• If focusing is difficult with auto focus, choose manual
focus, and manually correct the focus before
recording (see page 56).
• Shake of the DVD video camera/recorder may cause
blur in recorded image.
• When holding the DVD video camera/recorder for
recording, grasp it securely with both hands.
• When recording with higher zoom magnification, it is
recommended that you secure the DVD video
camera/recorder on a tripod.
• There may be a difference between the image you
see on the LCD screen or viewfinder and the
recorded image.
When using the viewfinder, pull it out and
close the LCD monitor.
4 Press the PHOTO/SELECT button half way
(half pressing).
The DVD video camera/recorder will
automatically focus on the subject at the
centre of screen, and the “9” indicator on
screen will light in purple (the focus will not
change when manual focus is chosen).
45
HDD
HDD
English
Swift Restart of Recording (SLEEP/RESTART
button)
If you press the SLEEP/RESTART button while in the recording pause status instead of turning the
DVD video camera/recorder off, the status that recording is possible will be restored in approx.
1.5 seconds.
Setting to the sleep/restart standby
status:
Press the SLEEP/RESTART button in the
recording pause status.
The SLEEP/RESTART button will light, and the
DVD video camera/recorder will enter the
sleep/restart standby status.
In the following cases, pressing the SLEEP/
RESTART button will not set the DVD video
camera/recorder to the sleep/restart standby
status:
• No disc is loaded although the power switch is set to
“DVD”.
• No card is loaded although the power switch is set to
“SD”.
• An unusable disc or card is loaded.
• The HDD or a loaded DVD or card has no remaining
free space.
• The Disc Navigation screen is being displayed.
• During playback.
Restoring from sleep/restart standby
status
Press the SLEEP/RESTART button that is lit:
The DVD video camera/recorder will return to
the recording pause status.
Pressing the REC or PHOTO/SELECT button
will also restore the DVD video camera/
recorder to recording pause from the sleep/
restart standby status.
The following operation will release the sleep/
restart standby status:
• Press down the DISC EJECT button.
• Change over the power switch (“HDD”↔“DVD”).
:
Note
• If you press the REC or PHOTO/SELECT button while
in the sleep/restart standby status, the sleep/restart
status will be released, but recording of a video or
photo will not start. To record, press the REC or
PHOTO/SELECT button again.
• After the DVD video camera/recorder is restored from
the sleep/restart standby status, the zoom position
will return to 1x*
exposure and rear lighting will also reset to the initial
values.
• The DVD video camera/recorder in sleep/restart
standby status consumes approx. half the power it
does during ordinary recording, but the recordable
duration in that status will be longer than standing by
in the recording pause status.
• If the sleep/restart standby status continues more
than 30 minutes, the DVD video camera/recorder will
turn off regardless of the Power Save setting (leaving
the DVD video camera/recorder in recording pause
status for 5 minutes will also turn it off: Default).
• Setting the power switch to OFF in the sleep/restart
standby status will turn the DVD video camera/
recorder off.
*1 3x on DZ-HS500E.
1
. The settings on manual focus,
SLEEP/RESTART button
46
HDD
HDD
On-Screen Information
Various types of information will appear in the viewfinder or on the LCD screen during recording.
INFORMATION DISPLAY DURING RECORDING
See the next page for details.
2. 16:9 mode
8 3. Programme AE
@ 4. Backlight compensation
A 5. EIS
= 6. White balance
1. Recording mode
10. Zoom
11. Exposure correction
12.Manual Focus
13. HDD,DVD/Card type
14. Movie recording quality
FINE
15. HDD
Protection
j
FULL AUTO
HDD ACCESS
Warning message
00:00:00
10
REM
REM
1/ 3/2007
REC
30MIN
Scene
14
8:00
C 7. Microphone filter
8. Self-timer
9. Recording status
Movie recording time
Remaining space
16.
on HDD/DVD/Card
17.
Remaining number
of recordable scenes
18. Remaining
battery level
FULL AUTO indicator
(p. 59)
Current date/time
English
The above screen is an example for
explanation:
It is different from the actual display.
47
1. Recording mode (p. 44, 45)
English
: Movie (HDD/DVD)
: Still (Card)
2. 16:9 mode (only in movie recording mode)
(p. 65)
No display : 16:9 mode OFF
: 16:9 mode ON
3. Programme AE (only in movie recording
mode) (p. 60)
No display : Auto
:Sports
5
:Portrait
6
: Spotlight
7
: Sand & Snow
8
: Low Light
9
4. Backlight compensation (p. 58)
No display : Backlight compensation OFF
: Backlight compensation ON
@
5. Electronic image stabiliser (EIS)*1 (p. 63)
No display : EIS OFF
:EIS ON
A
6. White balance (p. 61)
No display : Auto
:Set
;
: Outdoor
<
:Indoor
=
7. Microphone filter (only in movie recording
mode) (p. 63)
No display : Microphone filter OFF
: Microphone filter ON
C
8. Self-timer (only in still recording mode) (p. 67)
No display : Self-timer OFF
: Self-timer ON
D
9. Recording status
:
9
No display
(countdown is from 10 seconds)
: During recording
: During recording pause (lights in
green)
When focus locks during photo
recording (lights in purple)
*2
10.Zoom (p. 54)
)
(Digital Zoom: Off)
*
(Digital Zoom: 60×*3)
+
(Digital Zoom: 800×*4only in movie
recording mode)
11.Exposure correction (p. 58)
No display : Auto
:Manual
12.Manual focus (p. 56)
No display : Autofocus
:Manual focus
48
13. HDD, DVD/Card type
:HDD
: HDD (write-protected)
!
/
: DVD-RAM
: DVD-RAM (write-protected)
: DVD-RW (VR-mode/VF-mode)
: Protected DVD-RW (VR-mode)
: DVD-RW (VR-mode) finalised on
this video camera/recorder
: DVD-RW (VR-mode) finalised on a
device other than this DVD video
camera/recorder
"
: Finalised DVD-RW (VF-mode) disc
:DVD-R
: DVD-R already finalised on this
DVD video camera/recorder
%*
: DVD-R finalised on a device other
than this DVD video camera/
recorder (including a DVD-R
recorded on a Hitachi DVD video
camera/recorder marketed before
DZ-HS501E/HS500E, but not
finalised)
:+RW
:Finalised +RW
&
'
No display
: SD memory card
: Locked SD memory card
*5
14.
Movie recording quality (
recording mode
) (p. 64)
only in movie
XTRA : Best quality
FINE : High quality
STD : Standard quality
Still recording quality (only in still recording
mode) (p. 67)
FINE : High quality
NORM : Standard quality
ECO : Number of recordable stills is
prioritised
15. HDD Protection (p. 68)
No display : HDD Protection On
: HDD Protection Off
16. Remaining space on disc/card
REM XX
MIN
: Remaining recordable minutes
*7
during movie recording
*6
REM XX*8: Number of remaining recordable
still images during still recording
17. Remaining number of recordable scenes
(when using HDD)
REM XX
Scene
: Will appear when the remaining
number of recordable scenes (999
scenes max.*9) is 50 or less. If the
number is down to 10 or less, the
display will be in purple.
18. Remaining battery level (p. 33)
(full charge)
J
K
L
(low remaining charge)
M
English
*6
*1 Not displayed when recording photo on DZ-HS501E.
*2 When no disc or card is in the DVD video camera/recorder or disc has not yet been initialised, a write-protected
disc or locked card, or a disc or card with no remaining space, has been inserted. Or if the HDD is protected or
has no remaining free space.
*3 “120x” will appear on DZ-HS500E.
*4 “1500x” will appear on DZ-HS500E.
*5 No display if no disc or card is loaded, or if a disc or card unusable on this DVD video camera/recorder is
loaded.
*6 No remaining time or number will be displayed with a protected HDD/disc or locked card, or finalised DVD-RW
(VF-mode)/DVD-R/+RW.
*7 In XTRA mode, possible recording time may be longer than the displayed time.
*8 The displayed number of recordable stills is for reference: This number may not decrease, depending on the
recording conditions.
*9 Combining scenes will not increase the remaining number of recordable scenes.
49
●Switching the information display mode
English
You can switch the display mode of on-screen information:
Press the DISPLAY button.
The full and minimum display modes will alternate.
• Full display mode: All types of information will
appear.
• Minimum display mode: The recording mode (see
1 on page 47) and recording status (see 9 on
page 47) will appear. If the DVD video camera/
recorder has warning information, a warning message will appear.
Note:
The DVD video camera/recorder does not record the date and time as a part of image. However, this information
during recording will be recorded with image as data which can be checked on Disc Navigation screen during
playback (see “INFORMATION DISPLAY DURING RECORDING” on page 47).
●Display when recording an image of yourself
When recording with the LCD screen facing the same direction as the
lens, the operating status will appear: The battery remaining level will
appear only when the remaining level is very low, and the display will
blink.
Operating status/warning message
Battery remaining level
No warning/message (see page 47) will appear when recording with the LCD screen facing the same
direction as the lens.
Instead, the following screen display symbols will blink to inform you of the operation status of
DVD video camera/recorder.
When the LCD monitor is turned 180º from the position with the LCD screen facing the same
direction as the lens, the warning/message can be checked.
50
●Interpreting symbols on LCD screen when recording with the screen
facing the same direction as the lens
Screen
display
symbol
• Status in which recording is not possible on HDD.
• An attempt to record a photo on HDD was made.
%
)
/
7
8
Note:
• If the LCD screen is set facing the same direction as the lens, the LCD screen will display a mirror image (left and
right reversed).
• If the LCD screen is set facing the same direction as the lens, you can also view subject image in the viewfinder.
• Although you can switch to the manual focus, exposure and on-screen display modes even during recording with
LCD screen facing the same direction as lens, they will not appear on the screen.
• When the LCD monitor is opened and turned 180º with the Programme AE set to Low Light, the monitor screen
will light white (see page 61).
• An attempt to record a still is being made with a DVD-RAM/DVD-RW/DVD-R/+RW used.
• An unusable disc is loaded.
• An attempt to record movie on a card was made.
• An unusable card is loaded.
• HDD/disc is write-protected.
• A locked card is loaded.
• During recording (lights in red).
• The remaining capacity on HDD/disc is approaching the limit 0 (blinks in red).
• During recording pause (lights in green).
• During focus lock (lights in purple).
• The remaining capacity on HDD/disc/card is approaching the limit 0 (blinks in red).
• There is no remaining capacity on HDD/disc/card (blinks in green).
Description
English
51
English
Checking Flow of Menu
The following two on-screen menu modes are available with this DVD video camera/recorder:
• Full Menu: To display all menu items for experts
• Quick Menu: To display only the fundamental menu items for first timers
●Operating Menu
The Full Menu will appear if you press the MENU button.
You can use the 2/1/0// buttons on DVD video camera/recorder to select various setting
options in Full Menu and designate them.
Press the MENU button
The cursor to be
chosen will move to
the right
Press / or
Camer a Funct i ons Set up
A
Prog ram AE
A
W
hi te Bal.
EIS
Dig .Zoom
MIC.Fi lter
ENTER RETURN
Aut o
Aut o
On
60x
Off
Press 0 or
Camer a Funct i ons Set up
ENTER RETURN
Prog ram AE
W
hi te Bal.
EIS
Dig .Zoom
MIC.Fi lter
A
A
Aut o
Aut o
On
60x
Off
Press 2Press 1
The cursor to
be chosen will
move down
Record Funct i ons Setup
V I DEO Mod e F I NE
16:9 On
OSD Ou t pu t On
HDD Protection On
ENTER RETURN
Press the button directly to choose an option from menu.
To return to the screen one before, press the button.
Pressing the MENU button again will cause the Menu display to
disappear.
Note:
• Pressing the QUICK MENU button will display the Quick Menu screen: The operation will be the same as when
the MENU button is pressed.
• Pressing the MENU button during recording will not display the menu.
• The menu screen will disappear when it is left for approx. one minute without any operation.
52
●Flow of Full Menu
■ The shaded menu item can also be set using the Quick Menu.
Refer to page indicated for details of each function.
Camera Functions Setup
Camer a Funct i ons Set up
A
Aut o
Prog ram AE
A
W
hi te Bal.
Aut o
On
EIS
Dig .Zoom
60x
Off
MIC.Fi lter
ENTER RETURN
Date Setup
Dat e Set up
Da t e Se t
Da t e Mode D/ M/ Y
ENTER RETURN
English
Programme AE (p. 60)
White balance (p. 61)
*1
(p. 63)
EIS
Digital zoom (p. 54)
*2
Microphone filter
(p. 63)
*1: Not displayed when DZ-HS501E is in “SD” status.
*2: Not displayed in “SD” status.
Record Functions Setup
Record Funct i ons Setup
V I DEO Mod e F INE
16:9 On
OSD Ou t pu t On
HDD Protection On
ENTER RETURN
Movie quality*3 (p. 64)
*4
16:9
(p. 65)
Self-timer*5 (p. 67)
On-screen information display output (p. 68)
HDD protection
*3: The quality mode is displayed in “SD” status (p. 67).
*4: Not displayed in “SD” status.
*5: Displayed in “SD” status.
*6: Displayed only in “HDD” status.
*6
(p. 68)
Date setting (p. 36)
Display format (p. 36)
LCD/EVF Setup
LCD/EVF Se t up
LCD/EVF Ad j us t
EVF D i sp l a y Au t o
ENTER RETURN
Adjust (p. 39)
EVF Display (p. 40)
Initial Setup
Initial Setup
Beep On
w
er Save Off
Po
Record LED On
Language Engl ish
Demo Mode Aut o
Reset
ENTER RETURN
Beep (p. 37)
Power save (p. 37)
Recording LED (p. 38)
Language selection (p. 37)
Demo mode (p. 38)
Reset (p. 38)
53
English
HDD
Zooming
HDD
If you continue to hold the zoom lever on the
“T” control side with Dig. Zoom specified, the
digital zoom will be activated midway (when
1 Press the MENU button, choose “Dig. Zoom”
on the “Camera Functions Setup” menu
screen, and then press the button.
optical 15-power is exceeded on DZ-HS501E or
optical 30-power is exceeded on DZ-HS500E).
You can zoom up to 800-power on DZ-HS501E;
2 Choose the desired magnification, and then
press the button.
up to 1500-power on DZ-HS500E.
W: recording wide area
(wide-angle)
3 Press the MENU button to end the setting.
Moving the zoom lever will display the
digital zoom bar.
Note:
• The digital zoom setting will be stored in memory
even if the DVD video camera/recorder is turned off.
• You can also use the DIGITAL ZOOM button on
remote control to switch the digital zoom setting:
T: recording enlarged
image (telephoto)
Pressing the button during movie recording will switch
the setting between “Off”, “60×”*
Pressing the button during photo recording will switch
between “Off” and “60×”*
• If you set zoom to “800×”*
digital zoom will be up to “60×”*
• When a subject is zoomed, it may be momentarily out
of focus.
• When digital zoom is engaged, the image quality will
be rougher.
*1 “120x” on DZ-HS500E.
*2 “1500x” on DZ-HS500E.
1
, and “800×”*2:
1
.
2
when recording photo, the
1
.
MACRO RECORDING
Use the macro function when recording a small object from close-up position: You can shoot the
subject as close as approximately 2 cm from the lens surface, magnifying the image to fill the screen.
1 Aim the DVD video camera/recorder at the
subject, and press the zoom lever to “W”
control side.
54
Note:
• Zoom can be used, but the subject may not be
focused, depending on the distance to the subject. In
this case, move the zoom to “W” control side to focus.
• The amount of light tends to be insufficient during
macro recording: If the subject image is too dark, use
additional lighting.
RECORDING SUBJECTS FOR STRONGER WIDE-ANGLE OR TELEPHOTO
EFFECT
Use the tele-conversion lens or wide-conversion lens with the following filter diameter and thread
pitch to record subjects for stronger telephoto or wide-angle effect:
Filter diameter: 30.5 mm for DZ-HS501E; 34 mm for DZ-HS500E
Thread pitch: 0.5 mm
When attaching the optional DZ-TL1 tele-conversion lens or DZ-WL1 wide-conversion lens, use the
optional step-up ring: DZ-SR3037 for DZ-HS501E, DZ-SR3437 for DZ-HS500E (see page 139).
1 Attach the step-up ring over the lens.
2 Remove the cap of conversion lens, and screw the lens into the thread of step-up ring.
Conversion lens
Step-up ring
(Attach)
• Tele-conversion lens: For stronger telephoto effect
• Wide-conversion lens: For stronger wide-angle effect
Note:
• With DZ-TL1 tele-conversion lens, the focusing range
at “T” (telephoto) control side is between approx. 5 m
and infinite.
• When a conversion lens is attached, note that the four
corners of screen will be slightly dim if you zoom in on
a subject on the W control side (wide-angle side).
• When replacing the lens, take care not to drop the
DVD video camera/recorder.
• If a generally available filter is attached, do not attach
the removed lens hood.
• Some generally available conversion lenses may not
be usable on this DVD video camera/recorder,
depending on the lens maker.
English
55
HDD
HDD
English
Manually Focusing Subject
The DVD video camera/recorder usually focuses on a subject automatically (autofocus). You can also
manually focus a subject depending on the recording conditions.
FOCUSING DURING RECORDING
Normally, the DVD video camera/recorder automatically focuses the subject (autofocus), but you
can also manually focus a subject, depending on the recording conditions (manual focus).
Focusing range
You can switch the display mode of on-screen information:
• On T (tele) side: approximately 1 m from lens surface to infinity
• On W (wide) side: approximately 2 cm from lens surface to infinity
1 Press the FOCUS button during recording.
Manual Focus icon will appear on the screen.
00:00:00
REM
Manual Focus icon
FINE
3 0 MIN
8:00
1/ 3/2007
2 Press the zoom lever to “T” control side to
zoom in on subject.
3 Use the 0// buttons to adjust the focus,
while viewing the image in the viewfinder or
on the LCD screen.
Adjust with
0// buttons
Note:
• Pressing FOCUS will alternate between manual focus
and auto focus. With auto focus, no indication will
appear on the screen.
• Be sure to zoom in on your subject before manually
focusing on it. If you bring the subject into focus at the
“W” control side, focus will be faulty when you turn the
zoom lever to the “T” control side to zoom in on the
subject.
• Manual focus is released when the DVD video
camera/recorder is turned off. When you turn the DVD
video camera/recorder on next time, auto focus will be
restored.
56
Manually focus the following objects, which may not be automatically focused (see page 56):
Objects not in
the centre of
screen
Objects with
little variation
in brightness,
such as white
wall
Objects that
are far and
near at the
same time
English
Objects
moving rapidly
Object behind
glass with
water
droplets, dirt
on it
neon sign,
spotlight, etc.
which glares
or emits
strong light
Night view
Dark objectsObjects lit by
57
HDD
HDD
HDD
English
Adjusting Brightness of Image to be recorded
(Exposure)
The DVD video camera/recorder usually adjusts the exposure automatically. You can also manually
adjust the exposure depending on the recording conditions.
1 Press the EXPOSURE button during
recording.
The exposure adjustment bar will appear on
the screen.
Exposure adjustment bar
FINE
2 Use the 0// buttons to adjust the
exposure, while viewing the image in the
viewfinder or on the LCD screen.
00:00:00
REM
3 0 MIN
8:00
1/ 3/2007
HDD
Note:
• Pressing EXPOSURE will alternate between manual
adjustment and auto exposure. With auto exposure,
no indication will appear on the screen.
• The exposure setting will return to Auto when the
DVD video camera/recorder is turned off.
Adjust with 0// buttons
Compensating for Backlight
When subject is lighted from rear, this function will compensate for lighting so that the subject is not
too dark.
1 Press the BLC button during recording.
00:00:00
REM
Backlight correction icon
FINE
The backlight correction icon will appear.
Note:
• Pressing the BLC button will alternate between
backlight setting between on and off.
• The backlight setting will automatically return to “off ”
when the DVD video camera/recorder is turned off.
58
3 0 MIN
8:00
1/ 3/2007
HDD
HDD
Using Full Auto Function
Pressing the FULL AUTO button will fully automate the camera functions.
1 Press the FULL AUTO button.
“FULL AUTO” will be displayed on the screen
of DVD video camera/recorder for several
seconds.
The following settings will reset to defaults:
Function
Focus Auto 56
Backlight
compensation
Exposure Auto 58
Programme AE Auto 60
White balance Auto 61
EIS On 63
MIC.Filter Off 63
When setting
full auto
Off 58
Reference
page
English
59
HDD
HDD
English
Setting Up Camera Functions
Before You Begin
• See page 52 for how to set.
SELECTING SHOOTING MODE TO MATCH THE SUBJECT
(SWITCHING PROGRAMME AE MODE)
This DVD video camera/recorder automatically detects the status of subject and surrounding
situation and records the optimum image: If you choose the shooting mode to match the recording
conditions, clearer images will be recorded.
1 Press the MENU button, use the 2/1/
0// buttons to choose “Program AE” on
the “Camera Functions Setup” menu screen,
and then press the button.
The options will appear on the right of
“Program AE”.
2 Use the 2/1/0// buttons to choose
the desired option, and then press the
button: The selected option will be set.
3 Press the MENU button to end the setting.
The menu screen will disappear.
Note:
• You can check the selected AE mode by the on-
screen information display. However, nothing will
appear in the Auto mode.
• The shooting mode set as above will be stored in
memory even if the DVD video camera/recorder is
turned off.
• When recording in a dark area, an after-image will
appear when filming a moving subject or if camera
shake occurs (it is therefore recommended that you
use a tripod in such cases).
• If the Sports mode is used under a fluorescent light,
the image may flicker: In this case, use the Auto mode
for recording.
Auto : The camera/recorder automatically
judges the subject and surrounding environment
for optimum recording.
Sports : Reduces blurring when recording
rapidly moving subjects such as in golf or tennis.
Portrait : Makes a subject, such as a person
or a creature, stand out from a blurred
background.
Spotlight : Prevents overexposure of subject
portrait face, etc. when strong light strikes the
subject, as in a wedding or on stage.
Sand & Snow : Prevents underexposure of
subject portrait face, etc. in a place where
reflection of light is intense, such as at the
seaside in midsummer or on a ski slope.
Low Light : Allows user to record in a dark
place even with decreased lighting.
Turn the LCD monitor 180º during recording:
The LCD monitor light can then be used for
recording.
60
RECORDING DARK SUBJECTS USING LCD MONITOR LIGHT
When Programme AE is set to Low Light, you can use the light from LCD monitor to record a subject.
1 Press the MENU button, use the 2/1/
0// buttons to choose “Program AE” on
the “Camera Functions Setup” menu screen,
and then press the button.
2 Use the 2/1/0// buttons to choose
“Low Light”, and then press the button.
Note:
• Use the viewfinder to check the image to be recorded.
• The LCD monitor light allows you to record a subject
up to 1 m even in a dark place.
• An after-image will appear when filming a moving
subject or if camera shake occurs (it is recommended
that you use a tripod).
• If a subject cannot be focused properly, manually
adjust the focus (see page 56).
3 Press the MENU button to end the setting.
4 Open the LCD
monitor, turn it 180º
so that it faces the
same direction as
the lens: The LCD
monitor will light
white.
ADJUSTING COLOUR (WHITE BALANCE)
This DVD video camera/recorder automatically adjusts the colour of subject. Change the white
balance setting depending on the recording conditions.
Mode Setting content On-screen display
Auto White balance always automatically adjusted None
Set You can manually adjust white balance to match the light
source or situation (p. 62)
Outdoor To record in fine weather
Indoor To record under incandescent light, halogen light or bulb-
colour type fluorescent light
;
<
=
English
61
1 Press the MENU button, use the 2/1/
English
0// buttons to choose “White Bal.” on the
“Camera Functions Setup” menu screen, and
then press the button.
2 Choose the desired option, and then press the
button.
3 Press the MENU button to end the setting.
●Setting white balance manually
Note:
• The white balance mode can be confirmed using the
on-screen information.
• The white balance setting will be stored in memory
even when the DVD video camera/recorder is turned
off.
• Do not block the infrared sensor with hand, etc.
Infrared sensor block
• If a tele or wide-conversion lens is used, the auto
white balance may not operate depending on the
recording conditions. If this happens, set to the mode
to match the recording conditions, or manually set the
white balance.
• Be sure to remove the lens cap before turning the
DVD video camera/recorder on: If the DVD video
camera/recorder is turned on with the lens capped,
the white balance will not work normally.
1 Point the DVD
video camera/
recorder at a white
object so that it fills
the screen. Use an
object that is not
transparent.
If focus is not
correct when the
white object fills the screen, manually focus
the object, referring to “Manually Focusing
Subject” (see page 56).
Thick paper
2 Press the MENU button, use the 2/1/
0// buttons to choose “White Bal.”, “Set”
on the “Camera Functions Setup” menu
screen, and then press the button.
3 Hold button pressed until the “;”
indicator changes from blinking to a steady
light. When the “;” indicator lights, the
white balance setting will be complete.
4 Press the button to end the setting.
62
Note:
• The white balance set using the “Set” option will be
stored in memory until it is re-set.
• Do not use a coloured object when setting the white
balance: The appropriate tint cannot be set.
• The setting on white balance “Set” may not be
possible in a dark place. Also, the white balance
cannot be set when the zoom bar is in the digital
zoom range (p. 54). In such status, the “;” indicator
will remain blinking. Set the white balance in a bright
place with “Dig. Zoom: Off” specified.
• If the recording conditions have changed, re-set the
white balance for appropriate colours.
• The setting will be stored in memory even when the
DVD video camera/recorder is turned off: The “;”
indicator will blink when the DVD video camera/
recorder is turned on next time. Re-set the white
balance as needed.
USING THE ELECTRONIC IMAGE STABILISER (EIS)
When you use zoom (see page 54) to record a magnified subject image, it will correct fuzziness in the
recorded image.
1 Press the MENU button, use the 2/1/
0// buttons to choose “EIS” on the
“Camera Functions Setup” menu screen, and
then press the button.
2 Choose the “On” or “Off”, and then press the
button.
3 Press the MENU button to end the setting.
Note:
• You can check EIS On or Off by the on-screen
information display.
• The EIS setting will be stored in memory even when
the DVD video camera/recorder is turned off.
• After recording with EIS set to “Off ”, it is
recommended that you return the setting to “On” and
then turn the DVD video camera/recorder off, unless
you normally record with “Off” setting.
• It is recommended that you specify “EIS: Off” when
using the DVD video camera/recorder on a desk or
tripod.
• When “EIS: On” is specified, there will be a slight
difference between the actual movement and the
movement on screen.
• Gross camera shake may not be entirely corrected
even if “EIS: On” is specified: Firmly hold the DVD
video camera/recorder with both hands.
• EIS may not operate correctly when the tele or wideconversion lens is used.
• EIS cannot be used when using card on DZ-HS501E.
RECORDING SUBJECT USING LARGE MAGNIFICATION (DIGITAL ZOOM)
See page 54 for setting on digital zoom.
REDUCING WIND NOISE DURING RECORDING (MIC.FILTER)
When recording sound from the microphone built into this DVD video camera/recorder, you can
reduce wind noise in recording.
If “MIC.Filter: On” is specified, the low-frequency components in the sound picked up by
microphone will be cut off during recording: This makes it easier to hear the target voice or sound
during playback.
English
1 Press the MENU button, use the 2/1/
0// buttons to choose “MIC.Filter” on the
“Camera Functions Setup” menu screen, and
then press the button.
2 Choose the desired option, and then press the
button.
3 Press the MENU button to end the setting.
Note:
• You can also use the on-screen display to confirm that
the MIC.Filter has been set.
• The MIC.Filter setting will be stored in memory even
when the DVD video camera/recorder is turned off.
• The MIC.Filter function will work only during movie
recording.
• The microphone filter function works only with the
built-in microphone: It will not function when using an
external microphone (p. 69).
63
English
HDD
Setting Up Record Functions
HDD
SWITCHING MOVIE QUALITY (VIDEO MODE)
Choose the movie quality from “XTRA”, “FINE”, “STD”.
It is recommended that you record critical subjects in the “XTRA” or “FINE” mode.
1 Press the MENU button, use the 2/1/
0/// buttons to choose “VIDEO
Mode” on the “Record Functions Setup”
menu screen, and then press the button.
2 Choose the desired quality mode, and then
press the button.
3 Press the MENU button to end the setting.
Block-like noise may appear in recorded image, or the outline of subject image is distorted under the
recording conditions listed below. Pan the DVD video camera/recorder as slowly as possible (Block
noise is likely to appear in the “STD” mode):
• If there is a complicated pattern in background (as in following figure on left);
• If the DVD video camera/recorder is moved excessively or quickly;
• If subject is moving rapidly even when the DVD video camera/recorder is not moving.
Note:
• The movie quality setting will be stored in memory
even when the DVD video camera/recorder is turned
off.
• The “VIDEO Mode” setting will not change even if the
DVD is replaced.
• When using a DVD-RW (VF-mode)/DVD-R, the
“VIDEO Mode” setting will not change even if the disc
is replaced.
• When using DVD-RW (VF-mode)/DVD-R, you cannot
switch the setting on movie quality or wide-screen
mode while recording on the disc: The DVD video
camera/recorder will be automatically set to the movie
quality or wide-screen mode first used with the disc
for recording.
• When using a DVD-RW (VF-mode)/DVD-R/+RW:
You cannot specify the combination of “VIDEO Mode:
STD” and “16:9 On”(p. 83). If you specify “16:9 On”
and try to switch the VIDEO Mode to STD from XTRA
or FINE, the screen will automatically switch to the
4:3-aspect ratio display.
• The movie quality setting is effective only during
movie recording: The setting will not be displayed
during recording of stills.
(Image when block-like noise occurs) (Image without block-like noise)
64
HDD
HDD
SETTING TO WIDE TV SCREEN MODE (16:9 MODE)
When viewing recorded images later on a wide-screen TV (aspect ratio 16:9), specify wide-screen
(16:9) mode “On”: You can also record images with the aspect ratio changed (the aspect ratio with
“Off” is 4:3).
The following figures compare the images displayed on LCD monitor and in viewfinder when the
wide-screen mode is “on” and “off”.
English
“16:9 On” specified
(aspect ratio 16:9)
1 Press the MENU button, use the 2/1/
0// buttons to choose “16:9” on the
“Record Functions Setup” menu screen, and
then press the button.
When viewing playback on an ordinary TV screen later, specify “16:9 Off”: Recording with “16:9 On”
specified will be played back on an ordinary TV with longer vertical direction of image.
An image recorded with “16:9 On” specified will appear as follows:
Display on LCD monitor screen Display in viewfinder
“16:9 Off” specified
(aspect ratio 4:3)
2 Choose “On”, and then press the button.
3 Press the MENU button to end the setting.
65
Images recorded with “16:9 Off” specified will appear as follows:
English
Display on LCD monitor screen Display in viewfinder
Note:
• The 16:9 setting will be kept even after the DVD video camera/recorder is turned off.
• When using a DVD-RW (VF-mode)/DVD-R/+RW:
You cannot specify the combination of “VIDEO Mode: STD” and “16:9 On”(p. 83). If you specify “16:9 On” and try
to switch the VIDEO Mode to “STD” from “XTRA” or “FINE”, the screen will automatically switch to the 4:3-aspect
ratio display.
• When using DVD-RW (VF-mode)/DVD-R, switching between wide mode (16:9) and normal mode (4:3) will not be
possible while using the same disc.
• Images recorded with “16:9 On” (aspect ratio 16:9) specified will be played back with the setting used during
recording regardless of the 16:9 setting then being used.
• The 16:9 setting is not compatible with ID-1/ID-2*.
• If you connect this DVD vide camera/recorder to the S1 or S2 terminal of TV, the TV will automatically switch to
the wide-screen mode: See TV instruction manual for details.
• When using a video selector, the TV may not automatically be switched to 16:9 mode.
• If you connect the DVD video camera/recorder with a disc recorded in wide mode to a TV with 4:3 display only
and play it back, vertically long images will appear. To display 4:3 images, set “TV type” (p. 114) to 4:3 and view
the images.
• If you play back a +RW recorded in wide mode on a DVD recorder/player, etc., vertically long images will appear
even on a wide-screen TV. In this case, change the setting on the DVD recorder/player, or set “TV type” (p. 114) to
4:3 and view the images.
* This system records the aspect ratio (16:9, 4:3) information in void space between video signals.
66
SWITCHING QUALITY OF STILL IMAGE (QUALITY)
You can switch the still recording quality.
It is recommended that you use “FINE” when recording vital images (p. 158 “Size And Quality
Of Photos”).
English
1 Press the MENU button, use the 2/1/
0/// buttons to choose “Quality” on
the “Record Functions Setup” menu screen,
and then press the button.
3 Press the MENU button to end the setting.
Note:
• The still quality setting will be stored in memory even
when the DVD video camera/recorder is turned off.
2 Choose the option you want, and then press
the button.
SELF-TIMER
You can record photos using the self-timer function, as with ordinary cameras.
The self-timer function is valid only when recording photos (stills).
1 Press the MENU button, use the 2/1/
0/// buttons to choose “Self Timer”
on the “Record Functions Setup” menu
screen, and then press the button.
2 Select “On”, and then press the button.
The self-timer will be set.
3 Press the MENU button to end the setting.
4 Press the PHOTO/SELECT button.
The recording indicator at the front of DVD
video camera/recorder will blink.
The self-timer indicator will start to count
down, and recording will commence
approximately 10 seconds later.
Note:
• You can also check that self-timer has been set by
reviewing the on-screen information.
• To release the self-timer mode, choose “Off” on the
menu screen or turn DVD video camera/recorder off.
• To suspend self-timer, press the PHOTO/SELECT
button again before recording starts, or press the
button.
67
HDD
HDD
HDD
English
SETTING ON-SCREEN DISPLAY OUTPUT ON OR OFF (OSD OUTPUT)
If you connect this DVD video camera/recorder to a TV to view images on TV screen, you can
switch off the on-screen information (displayed in the viewfinder or on the LCD screen) from the TV
screen.
1 Press the MENU button, use the 2/1/
0/// buttons to choose “OSD
Output” on the “Record Functions Setup”
menu screen, and then press the button.
2 Choose “On” or “Off”, and press the
button.
3 Press the MENU button to end the setting.
“On” setting “Off” setting
00:00:00
REM
3 0 MIN
8:00
FINE
1/ 3/2007
TV screen TV screen
Note:
• The “OSD Output” setting will be stored in memory
even when the DVD video camera/recorder is turned
off.
• Even if “Off” is chosen, the on-screen information will
appear during playback. See page 77 for playback onscreen information display.
• Even after the on-screen information is removed from
the TV screen, it will still appear in the viewfinder or
on the LCD screen.
HDD
DROP DETECTION (HDD PROTECTION)
The default setting is “On”. Specify “HDD Protection: Off” if you plan to use the HDD built in this
DVD video camera/recorder in a weightless condition, such as skydiving, to prevent stop in
recording or playback: Specifying “On” in such status will activate the drop detection function and
stop recording or playback to protect the HDD built in this DVD video camera/recorder.
1 Press the MENU button, use the 2/1/
0/// buttons to choose ”HDD
Protection” on the ”Record Functions Setup”
menu screen, and then press the button.
00:00:00
REM
2 Choose ”On” or ”Off”, and then press the
button.
When “Off” is specified, the icon will appear.
Note:
• The “HDD Protection” setting will return to “On” when
the DVD video camera/recorder is turned off.
FINE
(When “HDD Protection: Off” is specified)
3 0 MIN
8:00
1/ 3/2007
An icon will
appear.
68
HDD
HDD
Using External Microphone
Connect external microphone (generally available) to the external microphone jack of this DVD
video camera/recorder. Clearer sound can be recorded. Turn on the switch on external microphone
and start recording. For details on external microphone, see “Major Specifications” on page 155.
To external
microphone jack
Note:
• Depending on the shape of its plug, an external microphone cannot be plugged in, while the cable is left plugged
in the AV/S output terminal. Unplug the AV/S output cable to use the external microphone.
• This DVD video camera/recorder cannot use a plug-in power type microphone. (Power is not supplied from this
DVD video camera/recorder.)
• Connecting an external microphone will switch off the built-in microphone.
• The DZ-HS500E cannot use any external microphone.
English
69
Disc Navigation
HDD
English
HDD
Using Disc Navigation
STARTING OR TERMINATING DISC NAVIGATION
Disc Navigation is a tool for editing scenes recorded on this DVD video camera/recorder.
Here is an explanation on “scene” and “programme”, so that you will be able to make most use of
Disc Navigation function.
The screens in this instruction manual are basically those that will appear when the HDD is used:
Some items will not appear when a DVD-RAM/DVD-RW/DVD-R/+RW or card is used, but the
operation is the same.
• Turn the DVD video camera/recorder on (p. 34).
Before You Begin
• When using HDD: Set the power switch to “HDD”.
• When using DVD: Set the power switch to “DVD”.
• When using DVD card: Set the power switch to “SD”.
1 Set the power switch properly.
2 Press the DISC NAVIGATION button.
The Disc Navigation screen (shown on
page 71) will appear.
3 Press the DISC NAVIGATION button again.
Disc Navigation will be terminated and the
DVD video camera/recorder will enter the
recording pause status.
You can also press the button to end Disc
Navigation.
70
Disc Navigation screen
Thumbnail
001/014All Prog rams
Cursor
Dubbed mark
Still image icon
Operation guide
*1 Scene:
Video (movie).......... “One scene” refers to images recorded from one press of REC button until recording is
*2
*3
PLAY
SELECT
stopped by pressing the REC button again.
Selected scene*1 number/
Number of all scenes
Current page position
*4
Bar graph
Icon of HDD, DVD/card type
Photo (still) .............. “One scene” refers to a single photo recording by pressing the PHOTO/SELECT button.
*2 Icon displayed on a photo recorded on a DVD-RAM using Hitachi DVD video camera/recorder that can record
photos on a DVD-RAM.
DZ-HS501E/HS500E cannot record any photos on a DVD-RAM.
*3 The operation guide will vary depending on the operation status of DVD video camera/recorder.
*4 Appears when 13 scenes or more have been recorded.
*5 When using a disc, the icon that corresponds to the type of disc being used will appear. “ ” will appear for
card.
Icons to be displayed on thumbnail:
......................Dubbed mark (p. 84)
2 ....................... Fade-in (p. 91)
3 ....................... Fade-out (p. 91)
Note:
• Each time the DISPLAY button is pressed, the recording date/time of the scene on which the cursor is placed,
recording data of scene (VIDEO Mode, 16:9, recording length), and operation guide will appear in sequence
(when HDD is used).
( ...................... Photo (p. 45)
.................. Skip (p. 92)
& ...................... Lock (p. 95)
English
*5
002/014All Prog rams
FINE 16:9 0min. 39sec.
002/014All Prog rams
PLAY
SELECT
002/014All Prog rams
1/ 3/2007 10:00:00
Displayed only when HDD
is used
• Each time Disc Navigation is started with a DVD-RW (VF-mode)/DVD-R inserted, message “Creating Thumbnail
...” will appear. After the message appears, the Disc Navigation screen will appear.
• In the following cases, the Disc Navigation screen will appear or a message will be displayed:
- HDD or disc is write-protected.
- Finalised DVD-RW (VF-mode)/DVD-R/+RW
- DVD-RW (VF-mode)/DVD-R recorded on a Hitachi DVD video camera/recorder model marketed before DZ-
HS501E/HS500E, and not finalised
- Locked card
• Do not leave the Disc Navigation screen displayed on TV to which the DVD video camera/recorder is connected:
Doing so could damage the TV screen, possibly by burning.
71
PLAYING BACK FROM DISC NAVIGATION SCREEN
English
1 Press the DISC NAVIGATION button.
2 Use the 2/1/0// buttons to select
the desired scene.
The selected scene will be framed: This is
called a “cursor”.
Note:
• Pressing the 0 or / button will move the cursor
to the preceding or following scene.
Pressing the 2 or 1 button will move the
cursor up or down, or move to the preceding or
following page.
• If there is a large number of recorded scenes, it
may take time more than usual until playback of
scenes starts.
3 Press the button.
Playback will start from the selected scene.
ADJUSTING VOLUME DURING PLAYBACK
If the LCD monitor is open during playback of movie, playback sound will be heard from the
speaker. Adjust the sound volume using the zoom lever. Tilt it to the “T” side to increase the volume,
“W” side to reduce the volume.
VOLUME
Vol um e
●When playback ends
The DVD video camera/
recorder will enter the
playback pause status at
the last image of last scene.
Pressing the or DISC
NAVIGATION button will
restore the Disc
Navigation screen.
When the playback pause status continues for as
long as 5 minutes, the Disc Navigation screen
will automatically be restored.
Playback pause
●Playing back photos
A photo on DVD-RAM will be displayed for
approx. 3 seconds. When playing back photos
on card, playback will stop after each photo
playback.
Note:
• Press the button to temporarily stop playback.
Pressing the button again will start from that
point.
• If you press the button after playback of the last
scene on disc finishes, playback will start again from
the beginning.
• Pressing the button will always restore the Disc
Navigation screen.
• When playing back photos on card, “Playback” will
appear. In the case of a photo with a large number of
pixels, it will take some time for the photo to appear.
72
• Insert a disc or card recorded on this DVD video camera/recorder to play
HDD
HDD
Before You Begin
back scenes on it. (p. 44, 45).
• Turn the DVD video camera/recorder on (p. 34).
HDD
PLAYING BACK LATEST RECORDED SCENE
Playing Back
1 Press the button in the recording pause
status.
The DVD video camera/recorder will enter
the playback mode, and the scene you have
recorded last will be played back.
When playback is finished, the DVD video
camera/recorder will enter the pause status
at the last image on disc.
If the playback pause status continues for as
long as 5 minutes, the DVD video camera/
recorder will automatically return to the
recording pause status.
Note:
• To temporarily stop playback, press the button.
Press the button again to restart playback.
• Even if you stop playback midway and immediately
start recording again, the new image will be recorded
after the last scene on HDD, disc or card (the
previous images will not be overwritten).
• Image data edited on PC, etc., or the recorded image
may not appear on this DVD video camera/recorder;
also, the recorded sound may not play back,
depending on the type of image data.
• Image data recorded on another DVD video camera/
recorder or DVD recorder may not be played on this
DVD video camera/recorder.
• Depending on the amount of data to be played back,
it may take some time for the playback image to
appear.
• Do not operate the power switch or remove the card
while the ACCESS/PC or CARD ACCESS indicator is
lit or blinking: Doing so may damage the card or the
data on card.
• If the temperature of this DVD video camera/recorder
is too high, normal playback may not be possible:
Turn the DVD video camera/recorder off once, wait
until the ambient temperature becomes lower, and
then operate it again.
English
2 Press the button.
Playback will stop, and recording pause
status will be restored.
DELETING LAST RECORDED SCENE
1 Press the MENU button during playback.
2 Choose “Edit”, “Delete Scene”, and then
press the button.
The screen for verifying deletion will appear.
HDD
3 Choose “YES”, and then press the
button.
The last recorded scene will be deleted, and
the recording pause status will be restored.
Note:
•
If you press the MENU button during playback using the
Disc Navigation menu, “Delete Scene” will not appear.
73
HDD
HDD
HDD
HDD
English
CAPTURING PHOTO
You can record an image displayed during playback of video as a photo on a card.
1 Press the MENU button at a scene you wish
to capture during playback.
2 Choose “Edit”, “PHOTO Capture”, and then
press the button.
The screen for verifying capture will appear.
3 Choose “YES”, and then press the
button.
The captured scene will be recorded on a
card.
Note:
• You can also press PHOTO/SELECT button for the
scene you wish to capture in step 1: The screen for
verifying capture will appear. Choose “YES”, and then
press the button. The scene will be recorded on
a card.
• A captured photo is played back on the DVD video
camera/recorder as follows:
When captured from a video recorded with 16:9 (wide
mode) On specified:
Number of pixels (JPEG
standard): 640 x 360
When captured from a
video recorded with 16:9
(wide mode) Off specified:
Number of pixels (JPEG
standard): 640 x 480
HDD
SEARCH PLAYBACK OF MOVIE
During playback, press the 0 or / button and
hold it: Search playback will start.
Hold down / :
Scenes will be visually scanned forward.
Hold down 0 :
Scenes will be visually scanned backward.
Release the 0 or / button when you find the
desired image:
Normal playback will start from that point.
Note:
• If the temperature inside the DVD video camera/
recorder rises, normal skip or search playback may
not be possible: Turn the DVD video camera/recorder
off, wait for a few moments, and then turn it on again.
HDD
FRAME ADVANCE/FRAME BACK/SLOW PLAYBACK OF MOVIE
During playback pause, press the 0 or /
button: Frame advance, frame back or slow
playback will start.
Press / once:
Picture will advance one frame.
Press 0 once:
Picture will go back one frame.
Hold down / :
Forward slow playback.
Hold down 0 :
Reverse slow playback.
After frame advance, frame back or slow
playback, the DVD video camera/recorder will
enter the playback pause status.
Note:
• In slow playback, a rapidly moving subject image may
be distorted.
• The intervals for playing back frames in frame
advance/frame back/slow playback are as follows:
Frame advance and forward slow: Approx. 0.03
seconds
Frame back and reverse slow: Approx. 0.5 seconds
• No sound will be heard during search playback or
slow playback.
74
SKIP PLAYBACK OF MOVIE
HDD
During playback, press the 2 or 1 button to
locate the start of desired scene.
Press 1 once:
To skip to the first image of the scene
following the one being played back, and start
playback.
Press 2 once:
To return to the first image of the scene being
played back, and start playback.
Hold down 1 :
To continuously locate the beginnings of
scenes, starting from the scene following the
scene being played back. When the desired
image appears, release the button: Playback
will start from that point.
Hold down 2 :
To continuously locate the beginnings of
scenes backward, starting from the scene
preceding the scene currently being played
back. When the desired image appears, release
the button: Playback will start from that point.
HDD
Portion being played back
Press 2
Scene 1 Scene 2 Scene 3
Portion being played back
Press 2
Scene 1 Scene 2 Scene 3
Pressing the 2 button at a portion several seconds
from the start of scene being played back will return
to the start of the scene preceding that being played
back.
Note:
• If you perform skip playback during playback pause,
the DVD video camera/recorder will enter the
playback pause status at the beginning of the located
scene.
• Pressing the 1 button in the last scene on HDD or
disc will set the DVD video camera/recorder to the
playback pause status at the last image.
• If the temperature inside the DVD video camera/
recorder rises, normal skip or search playback may
not be possible: Turn the DVD video camera/recorder
off, wait for a few moments, and then turn it on again.
twice
once
Press 2
once
Press 1
once
Press 1
once
Press 1
twice
Press 1
twice
English
PLAYING BACK STILLS
Press the 2 or 1 button during playback to
quickly play back stills in sequence.
Press 1 once:
To display stills one by one forward.
Press 2 once:
To display stills one by one backward.
[When using DVD-RAM]
(This DVD video camera/recorder cannot record
any photo on a DVD-RAM.)
Releasing the 2 or 1 button will start
continuous playback.
[When using card]
When the 2 or 1 button is released, the
photo at that point will be displayed, and then
the DVD video camera/recorder will enter the
playback pause status.
Use the slide show function for continuous
display (p. 115).
75
English
HDD
HDD
JUMPING TO SPECIFIED POINT (GO TO)
1 Press the MENU button
during playback.
2 Choose the option
(point you want to go
Go To
Top
End
Speci fy
ENTER RETURN
to), and then press the button.
●Specifying the point to view
1 Choose “Specify” in step 2 above, and then
press the button.
The screen for specifying the point to go to
will appear.
Position of currently
played back image
Go to
TOP ENDCURRENT
Cursor
0:00:00 00:24:2400: 03 :26
TOP END ENTER CANCEL
Total recording time of
all selected scenes
00: 03 :26
GO TO
Cursor position
2 Use the 2/1/0// buttons to select
the desired time of chosen point.
Press 2 : To select the start.
Press 1 : To select the end.
Press 0 or / :
• Press once:
To move the cursor in 1-minute units for
HDD (10-second units for DVD, 1-still
units for card)
• Hold down:
To move the cursor in 10-minute units for
HDD (1-minute units for DVD, 10-still
units for card)
To p:
To go to the start, and enter playback pause.
End:
To go to the end of last scene, and enter
playback pause.
Specify:
To go to a specified point and enter playback
pause. See the following for details.
3 Press the button to enter the selection.
The DVD video camera/recorder will go to
the specified point and enter the playback
pause status.
Pressing the button again will start
playback.
Note:
• To cancel the “Go To” procedure midway, press the
button before going to the specified point.
• If multiple scenes are selected using the Disc
Navigation function or PHOTO/SELECT button,
choosing “Top” will jump to the beginning of selected
scenes (p. 108).
• When multiple scenes are selected, the total time of
selected scenes will appear in the “total recording
time” display.
• With card, the number of stills will appear at the
“TOP”, “CURRENT”, “END” and “GO TO” indicators.
• The cursor may not move at same-pitch intervals.
76
Go to
TOP ENDCURRENT
0: 00: 00 00: 24: 2400 :03 :26
00: 00: 00
GO TO
TOP END ENTER CANCEL
(When the start of scene is selected)
HDD
HDD
INFORMATION DISPLAY DURING PLAYBACK
Various types of information on recording will be superimposed on playback image you are viewing.
9:27
1/ 3/2007
No display Playback information
●Switching the information display
mode
Press the DISPLAY button: You can switch the
display mode of on-screen information.
When using HDD/DVD:
Recording mode
Scene No. Repeat play
Programme No. or Play List No.
Programme or Play List
When using card:
Scene No. File name
003
Recording mode
Lock
00606
*1
100—0003
*4
00:00:16
HDD, Disc type
Playback operation
Playback
operation
Counter
*3
Slide Show
*4
*5
*2
*4
*5
display
*1
Programme or Play List.
*2
Number of programme or play list being
played back (not displayed when all
programmes are being played back).
*3
Refer to “HDD, DVD/Card type” on page 49.
*4
Will appear when each function is specified
“On”.
*5
:Standard playback
. : Playback pause
/ : Forward search playback
0 : Reverse search playback
1 :Forward skip playback
2 : Reverse skip playback
3 : Forward frame advance
4 : Reverse frame back
:Forward slow playback
:Reverse slow playback
See pages 73-75 for how to operate.
The “6” mark will appear on the first image
on disc.
The “5” mark will appear on the last image
on disc.
• Recording date/time display: Shows the date/
time when recording was started. Even when
playback starts, the date/time display will not
advance.
• No display: No information will appear.
However, when the mode of playback
operation is switched, the symbol will appear
for approx. 3 seconds.
Note:
See page 98 and after for “Programme”, page 101 and
after for “Play List”.
Recording date/time
English
77
SELECTING MULTIPLE SCENES
English
1 Press the DISC NAVIGATION button.
2 Use the 2/1/0// buttons to select
the desired scene.
3 Press the PHOTO/SELECT button once:
The selected scene will be framed in red and
yellow.
Repeat steps 2 and 3 to randomly select
multiple scenes.
SELECTING CONSECUTIVE SCENES TOGETHER
1 Press the DISC NAVIGATION button.
2 Use the 2/1/0/
/ buttons to point the
cursor at the first scene
in the range of scenes
you want to select.
PLAY PHOTO SELECT
Ye l l o w fr a me
3 Hold down the
PHOTO/SELECT
button for at least one
second:
The selected scene will
be doubly framed in
yellow and blue.
ENTER CANCEL
Double frames in
yellow and blue
4 Use the 2/1/0/
/ buttons to select the
last scene in the range
you want, and then
press the button:
The thumbnails of
scenes in the specified
range will be framed in
red, and then selected.
PLAY DESELECT ALL
Red frame
When scenes up to
this point are selected
005/ 014All Programs
005/ 014All Programs
010/0 14All Programs
Note:
• You can know the status of scenes from the colours of
cursor and bargraph:
Cursor Bar graph Status of scenes
Yellow Light blue
Blue Light blue
Red Yellow
• Pressing the button after selecting scenes will
play back only the selected scenes from the
beginning of each.
• To cancel a selected scene, select the scene to be
cancelled, and then press the PHOTO/SELECT
button.
To cancel all selected scenes, press the button.
• You can also select scenes in reverse from the last
scene in the range.
• To release multiple selection, press the or PHOTO/
SELECT button before pressing the button in
step 4.
• Up to 999 scenes can be selected.
Current cursor position
Range of scenes being
selected
Scenes already selected
78
FUNCTIONS AVAILABLE WITH DISC NAVIGATION
HDD
The Disc Navigation mode will allow a variety of further operations.
Functions Available with Disc Navigation
Available
function
Editing of scenes
Setting special
effects to scenes
Copy from disc to
card
Scene lock
Scene
information
display
Changing title
Creation of play
list
Initialisation
Protection
Remaining
display
(Capacity)
Disc finalisation
Unfinalising disc
Repeat play
Slide show
*1Only deletion is possible.
2
Additional recording can be made on a finalised DVD-RW (VR-mode).
*
●●●
1
*
●●●
●
●
●●●●●●●
●●●
●●●
●●●● ●●
●●●
●●●●●●●
2
*
●
●●●
●●
●●●●●●
●
You can delete unnecessary scenes,
combine scenes, or divide one scene.
You can attach fade and skip to a
scene, and change existing thumbnails.
You can copy photos recorded on DVDRAM disc to card.
You can lock any scene so that it will not
be deleted by mistake: Essential scenes
are thereby protected, and recording
another still is possible.
You can display information on one
scene or multiple scenes, such as
image quality, recording time, etc.
You can change the title of play list or
programme.
You can create an original movie by
changing the combination of scenes.
You can delete all data recorded on
HDD/DVD/Card.
You can protect the HDD/DVD-RAM/
DVD-RW (VR-mode) to prevent deletion
or editing by mistake.
The remaining recordable movie time or
number of recordable stills is displayed.
You can use this DVD video camera/
recorder to finalise any DVD-RW/DVDR/+RW recorded on it so that the disc
can be viewed on DVD recorder/player,
etc.
You can unfinalise a DVD-RW (VFmode)/+RW that was finalised on this
DVD video camera/recorder so that
additional videos can be recorded on
the disc.
You can repeatedly play back
programmes and scenes.
You can play back stills continuously. 115
Contents
Referenc
English
e page
88 – 90
91 – 93
94
95
97
99, 107
101
108
109
109
111
112
114
Note
:
Note
Setting special effects to scenes (fade, skip, thumbnail) are unique to this DVD video camera/recorder. When a disc
with any effects set on this DVD video camera/recorder is directly played back on a DVD recorder/player or read into
PC, the set effect results will not be reflected in the playback or reading. To reflect the set effect results, connect
both devices using the AV/S output cable and then perform recording (Dubbing, p. 119).
79
UNDERSTANDING FLOW OF DISC NAVIGATION MENU
English
Press the MENU button on the Disc Navigation screen: The menu screens for Disc Navigation and
menu screens for HDD/DVD/Card will appear.
Shaded items will also appear in Quick Menu display mode (see page 52).
Refer to pages indicated for details of settings.
●When using HDD
Scene Edit (p. 88) Divide (p. 89)
Effect (p. 91) Delete (p. 88)
Dubbing
(p. 83) Combine (p. 90)
Select (p. 96) Move*
Detail (p. 97)
1
Fade (p. 91)
Skip (p. 92)
Thumbnail (p. 93)
Execute (p. 84)
Mark Off (p. 87)
Start → Current (p. 96)
Current → End (p. 96)
All (p. 96)
(p. 90, 106) *1Will appear when a
play list is displayed.
Play list Select (p. 102) Go To Top (p. 108)
Program Select (p. 98) Full Format (p. 110)
Others Category (p. 113) All (p. 113)
Play (p. 102) End (p. 108)
Create (p. 101)
Edit (p. 103 – 106) HDD Setting
Title (p. 107) Protect HDD (p. 109)
Delete (p. 107) Capacity (p. 109)
Play (p. 99)
Title (p. 99)
Repeat Play (p. 114) Dubbed (p. 113)
TV type (p. 114) Un Dubbed (p. 113)
On (p. 114)
Off (p. 114)
16:9 (p. 114)
4:3 (p. 114)
Format HDD (p. 108)
Update Control Info. (p. 110)
80
●When using DVD-RAM/DVD-RW (VR-mode)
Scene Edit (p. 88) Divide (p. 89)
Effect (p. 91) Delete (p. 88)
Copy*2(p. 94) Combine (p. 90)
Select (p. 96) Move*
Detail (p. 97)
2
DVD-RAM only
*
3
Fade (p. 91)
Skip (p. 92)
Thumbnail (p. 93)
Start → Current (p. 96)
Current → End (p. 96)
All (p. 96)
(p. 90, 106) *3Will appear when a
English
play list is displayed.
Play list Select (p. 102) Go To Top (p. 108)
Program Select (p. 98) Update Control Info. (p. 110)
Others Category*
Play (p. 102) End (p. 108)
Create (p. 101)
Edit (p. 103 – 106) DVD Setting
Title (p. 107)
Delete (p. 107) Protect DVD (p. 109)
Play (p. 99)
Title (p. 99)
5
Repeat Play (p. 114) VIDEO (p. 113)
TV type (p. 114) PHOTO (p. 113)
5
DVD-RAM only
*
(p. 113) All (p. 113)
On (p. 114)
Off (p. 114)
16:9 (p. 114)
4:3 (p. 114)
Finalize DVD*
Format DVD (p. 108)
Capacity (p. 109)
4
*
DVD-RW (VR-mode) only
4
(p. 111)
81
●When using DVD-RW (VF-mode)/DVD-R/+RW
English
Scene Select (p. 96) Start → Current (p. 96)
Detail (p. 97) Current → End (p. 96)
All (p. 96)
Program Select (p. 98) DVD Setting
Go To Top (p. 108) *
Others
Play (p. 99)
End (p. 108)
Repeat Play (p. 114) On (p. 114)
Off (p. 114)
TV type (p. 114) 16:9 (p. 114)
4:3 (p. 114)
●When using card
Scene Delete (p. 88)
Go To Top (p. 108) Slide Show
Card
Lock (p. 95)
Select (p. 96) Start → Current (p. 96)
Detail (p. 97) Current → End (p. 96)
All (p. 96)
End (p. 108)
Format Card (p. 108)
Capacity (p. 109)
Finalize DVD (p. 111)
Unfinalize DVD*6(p. 112)
Format DVD*6(p. 108)
Capacity (p. 109)
6
DVD-RW (VF-mode)/+RW only
Start (p. 115)
82
Dubbing on DVD
This DVD video camera/recorder allows you to choose the desired method when dubbing images
recorded on HDD to a DVD:
“New”: To dub scenes recorded on HDD to a DVD, without dubbed marks appearing, beginning with
“Date”: To dub scenes recorded on HDD on the same date to a DVD, beginning with the first scene.
“All”: To dub all scenes recorded on HDD to a DVD, beginning with the first scene.
“Select”: To select your favourite scenes from all those recorded on HDD, for dubbing.
●List of dubbing possible/impossible
the first scene without dubbed mark.
• Set the power switch to “HDD”.
• Prepare a recordable disc.
• The recording time for a scene that can be dubbed on one disc is
• Be sure to use the AC adapter/charger to power the DVD video camera/
Before You Begin
• If power is turned off and dubbing is interrupted midway, proper dubbing
• The time shown on dubbing is for reference: Dubbing will be performed
approx. 30 minutes ( in FINE mode). If the HDD contains a scene
exceeding the length that is recordable on one disc, it cannot be
dubbed: Divide the scene (see p. 89), and then perform dubbing.
recorder during dubbing: Dubbing is not possible with a battery
connected.
will not be possible.
at normal speed in XTRA mode; approx. 2 times the normal in FINE
mode; approx. 4 times the normal in STD mode.
If the number of scenes on HDD is too large, or the temperature of this
DVD video camera/recorder is too high, the required recording time may
be longer than the display time on screen.
English
Disc to be
dubbed
DVD -RAM
DVD -RW
(VR-mode)
DVD -RW
(VF-mode)
DVD-R
+RW
* You cannot specify the combination of “VIDEO Mode: STD” and “16:9 On”.
VIDEO Modes
(XTRA/FINE/STD) mixed
●●●
●●●
———
———
●* ●*—
Videos on HDD
Wide/normal modes
(16:9/4:3) mixed
●: Dubbing possible; —: Dubbing impossible
VIDEO Mode “STD” and
wide mode (16:9)
●Note when dubbing:
• If message “Scene No.xxx is too large. Please divide this Scene before dubbing.” appears during dubbing, the
dubbing will stop. Divide the specified scene (see page 89), and then dub the divided scenes.
• The maximum number of scenes and programmes that can be dubbed will vary depending on the DVD used
(see page 157).
• With this DVD video camera/recorder, the scenes on HDD will be dubbed to a DVD in the order of display on
HDD Disc Navigation screen. To dub the scenes in a different order, create a play list on which scenes are
registered in the desired order of dubbing (see page 101), and then execute dubbing.
83
• If you want to dub only the scenes with dubbed marks , “Category” in HDD setting should be designated
English
(see page 113).
• Marks will appear for the thumbnails of the scenes which have been once
dubbed. If the marks make the thumbnails difficult to see, you can turn off the
marks (see page 87).
• If a finalised disc or a heavily scratched or dirty disc is inserted into this DVD video
camera/recorder, a message will appear and dubbing will not be possible: Use
another disc.
• A DVD-RW/DVD-R dubbed on this DVD video camera/recorder will not be finalised: To play it back on a DVD
recorder, be sure to finalise it on this DVD video camera/recorder.
• The details of editing scenes on HDD (fade, skip, change of thumbnail, etc.) will not be reflected in the scenes
if they are dubbed on a DVD-RW (VF-mode)/DVD-R/+RW.
• If you combine scenes with different recording dates on a play list, and dub the combined scene to a DVDRAM/DVD-RW (VR-mode), the scenes will be dubbed separately for each date. However, if a combined scene
is subsequently divided, the scenes may not be dubbed separately for each date.
• If you dub scenes combined using the Disc Navigation function to a DVD-RW (VF-mode)/DVD-R/+RW, the two
scenes immediately before the combination (sometimes more than two scenes) will be dubbed.
• If you divide a scene using the Disc Navigation function, and then dub both the divided scenes to a DVD-RW
(VF-mode)/DVD-R/+RW, the scene before the division will be dubbed.
• Please note in advance that Hitachi will not accept any responsibility for compensation or loss of data,
or direct or indirect damage when dubbing is not performed normally due to a fault in this DVD video
camera/recorder.
PLAY
FIRST-TIME (“NEW”) DUBBING
This option allows you to dub scenes without dubbed marks, among those recorded on HDD, to a
DVD beginning with the first scene without dubbed mark.
If those scenes cannot be included on one DVD, the capacity of scenes will be calculated and the
scenes will be dubbed up to capacity. When the DVD is replaced following the instruction on
replacement of DVD during dubbing, dubbing will start from the scene following: Repeat this
operation until dubbing of all scenes on HDD without dubbed marks is finished.
1 Press the DUBBING button.
The Dubbing Menu will appear.
You can also display the Dubbing Menu from
the Disc Navigation screen: Press the DISC
NAVIGATION button, press the MENU
button, choose “Scene”, “Dubbing”,
“Execute”, and then press the button.
002/014All Programs
SELECT
2 From the Dubbing
Menu screen, choose
“New” and press the
button.
If no DVD is loaded in
Dubbing Menu
New All
Dubbing the scene which
isn't dubbed in HDD.
EXIT
ENTER
this DVD video camera/recorder, a message
will appear: Press the DISC EJECT button,
and then load a DVD.
3 The screen for verification will appear:
Choose “YES” and press the button.
Dubbing (New)
Dubbing scenes to DVD?
YES NO
ENTER CHECK SCENE
84
SelectDate
Pressing the 2 button at this time will allow
you to check the scenes to be dubbed to a
DVD that is loaded in the DVD video
camera/recorder: The scenes to be dubbed
will be encircled by a red cursor. To return to
the verification screen, press the (STOP/
EXIT) button.
To stop dubbing, choose ŽNOž on the
verification screen, or press the (STOP/
EXIT) button.
Press 2
Press
Dubbing (New)
RETURN
4 Replace the DVD.
If one disc cannot contain all scenes, the
screen for verifying DVD replacement will
appear. To continue dubbing, press the DISC
EJECT button, and then replace the DVD:
Dubbing will restart from the scene
following.
To stop dubbing, press the (STOP/EXIT)
button.
5 After dubbing is finished, check the “Delete
Scene” screen.
Choosing “YES” will delete the dubbed
scenes from the HDD.
To retain the dubbed scenes on the HDD,
choose “NO”.
6 Press DISC EJECT button to remove the DVD.
Close the cover of DVD insertion block.
If you do not want to remove the DVD, press
the (STOP/EXIT) button to end dubbing.
DUBBING SCENES RECORDED ON SAME DAY COLLECTIVELY (“DATE”
DUBBING)
This option allows you to collectively dub scenes recorded on HDD on one day, to a DVD.
If those scenes cannot be included on one DVD, the capacity of scenes will be calculated and the
scenes will be dubbed up to capacity. When the DVD is replaced following the instruction on
replacement of DVD during dubbing, dubbing will start from the scene following: Repeat this
operation until dubbing of all scenes recorded on HDD on one day is finished.
English
1 Press the DUBBING button.
The Dubbing Menu will appear.
You can also display the Dubbing Menu from
the Disc Navigation screen: Press the DISC
NAVIGATION button, press the MENU
button, choose “Scene”, “Dubbing”,
“Execute”, and then press the button.
2 From the Dubbing Menu screen, choose
“Date” and press the button.
If no DVD is loaded in this DVD video
camera/recorder, a message will appear:
Press the DISC EJECT button, and then load a
DVD.
3 From the “Select
Date” screen, select
the date on which
scenes are to be
dubbed, and then
press the button.
If you have changed the title of programme
(see page 99), the title will appear on the
“Select Date” screen in place of the date.
Select Date
01 1/ 3/ 2007
02 5/ 3/ 2007
03 10/ 3/2007
04 15/ 3/2007
ENTER
4 The screen for verification will appear:
Choose “YES” and press the button.
Pressing the 2 button at this time will allow
you to check the scenes to be dubbed to a
DVD that is loaded in the DVD video
camera/recorder: The scenes to be dubbed
will be encircled by a red cursor. To return to
the verification screen, press the (STOP/
EXIT) button.
5 Replace the DVD.
If one disc cannot contain all scenes, the
screen for verifying DVD replacement will
appear. To continue dubbing, press the DISC
EJECT button, and then replace the DVD:
Dubbing will restart from the scene
following.
To stop dubbing, press the (STOP/EXIT)
button.
6 After dubbing is finished, check the “Delete
Scene” screen.
Choosing “YES” will delete the dubbed
scenes from the HDD.
To retain the dubbed scenes on the HDD,
choose “NO”.
7 Press DISC EJECT button to remove the DVD.
Close the cover of DVD insertion block.
If you do not want to remove the DVD, press
the (STOP/EXIT) button to end dubbing.
85
DUBBING ALL SCENES RECORDED ON HDD (DUBBING “ALL”)
English
You can dub all scenes recorded on the HDD to a DVD from the beginning in sequence.
If the scenes cannot be included on one DVD, count the capacity size of scenes, and dub the scenes
that can be stored on the DVD. Replace the disc during dubbing, following the screen for replacing
DVD: Dubbing will restart from the following scene. This operation will be repeated until all scenes
on the HDD are dubbed.
1 Press the DUBBING button.
The Dubbing Menu will appear.
You can also display the Dubbing Menu from
the Disc Navigation screen: Press the DISC
NAVIGATION button, press the MENU
button, choose “Scene”, “Dubbing”,
“Execute”, and then press the
2
From the Dubbing Menu screen, choose “All”
and press the
If no DVD is loaded in this DVD video
camera/recorder, a message will appear:
Press the DISC EJECT button, and then load a
DVD.
3
The screen for verification will appear: Choose
“YES” and press the
Pressing the 2 button at this time will allow
you to check the scenes to be dubbed to a
DVD that is loaded in the DVD video
camera/recorder. The scenes to be dubbed
will be encircled by a red cursor. To return to
the verification screen, press the
EXIT) button.
button.
button.
button.
(STOP/
4 Replace the DVD.
If one DVD cannot contain all scenes, the
screen for verifying disc replacement will
appear. To continue dubbing, press the DISC
EJECT button, and then replace the DVD.
Dubbing will restart from the scene
following. To stop dubbing, press
EXIT).
(STOP/
5 After dubbing is finished, check the “Delete
Scene” screen.
Choosing “YES” will delete the dubbed
scenes from the HDD.
To retain the dubbed scenes on the HDD,
choose “NO”.
6 Press the DISC EJECT button to remove the
DVD.
Close the cover of DVD insertion block.
If you do not want to remove the DVD, press
the
(STOP/EXIT) button to end dubbing.
86
SELECTING SCENES RECORDED ON HDD AND DUBBING THEM (SCENE
“SELECT” DUBBING)
You can select desired scenes recorded on HDD and dub only those scenes on DVDs.
English
1 Press the DUBBING button.
The Dubbing Menu will appear.
You can also display the Dubbing Menu from
the Disc Navigation screen: Press the DISC
NAVIGATION button, press the MENU
button, choose “Scene”, “Dubbing”,
“Execute”, and then press the
button.
2 From the Dubbing Menu screen, choose
“Select” and press the
If no DVD is loaded in this DVD video
camera/recorder, a message will appear:
Press the DISC EJECT button, and then load a
DVD.
button.
3 Place the cursor on a scene to be dubbed, and
then press the
button: The cursor of the selected scene will
change to red (see p. 78), and the scene with
red cursor will be dubbed to a DVD.
If you wish to dub
other scenes, place the
cursor on a scene in the
same way, and press
the
or PHOTO/
SELECT button to
select it.
To cancel a selected scene, press the
PHOTO/SELECT button again. To cancel all
selected scenes, press
If the total capacity size of the selected scenes
exceeds the remaining free space on DVD, the
or PHOTO/SELECT
DVD remaining bar
Dubbing (Select)
DUB
ENTER SELECT
or
(STOP/EXIT).
remaining bar at the top right of screen will
be red, and a message will appear. Select the
scenes again.
If you select a scene whose size exceeds one
DVD, a message that prompts you to divide it
will appear: After dividing the scene, execute
dubbing again.
4 Press the DUBBING button.
The screen for verifying dubbing will appear.
Instead of pressing the DUBBING button, you
can press the MENU button, choose “Edit”,
and then “Enter”: The same screen will
appear.
Choosing “YES” will start dubbing.
To cancel dubbing, choose “NO” or press
(STOP/EXIT).
5 When dubbing is finished, check the “Delete
Scene” screen.
Choosing “YES” will delete the dubbed
scenes from the HDD.
To retain the dubbed scenes on the HDD,
choose “NO”.
6 Press the DISC EJECT button to remove the
DVD.
Close the cover of DVD insertion block.
If you do not want to remove the DVD, press
the
(STOP/EXIT) button to end dubbing.
TURNING OFF DUBBED MARK FROM THUMBNAIL (MARK OFF)
If the dubbed mark makes the thumbnail difficult to see, you can turn off the mark.
1 Press the DISC NAVIGATION button, and
then press the MENU
2 Choose “Scene”,
“Dubbing”, “Mark
Off”, and then press the
button.
The “Cancel Dubbed
Mark” screen will appear.
Scene
Dubbing
ENTER RETURN
Execute
Ma rk O f f
3 Place the cursor on a scene for which you
want to turn the dubbed mark off, and then
press the PHOTO/SELECT button.
You can also select multiple scenes.
4 If there is no change in the scene for which
you want to turn the mark off, press the
button.
5 Press the (STOP/EXIT) button to end the
mark-off procedure.
Note:
• You can use “New” dubbing to dub scenes with the
dubbed mark turned off.
• Pressing the MENU button in step 3 will display the
submenu screen (see “Editing using submenu” on
page 89).
87
English
HDD
Scene
HDD
DELETING SCENES (EDIT – DELETE)
You may want to delete unwanted scenes.
Scenes on DVD-RW (VF-mode)/DVD-R cannot be deleted, and menu item “Delete” will not appear
with DVD-RW (VF-mode)/DVD-R.
When using +RW, no scene can be deleted from the Disc Navigation menu, but the scenes recorded
last on it can be deleted (see page 73).
1 Press the DISC NAVIGATION button.
2 Place the cursor on the scene to be deleted.
3 Press the MENU button.
4 Choose “Scene”, “Edit”, “Delete”, and then
press the button.
When using card, choose “Scene”, “Delete”,
and then press the button.
5 The “Delete Scene” screen will appear: If you
are sure you want to delete the selected scene,
press the button.
If you want to change the scene to be deleted,
you can change it on this screen.
6 The screen for verifying deletion will appear:
Choose “YES”, and then press the
button.
Choose “NO” to cancel deletion.
After Yes or No setting, the “Delete Scene”
screen will be restored.
Repeat steps 5 and 6 to delete other scenes.
7 Press the button to quit.
Note:
• If you point the cursor at the scene to be deleted on
DISC NAVIGATION screen, and then press the
DELETE button on remote control, the screen in step
5 will appear.
• To delete an unwanted part of a scene on DVD-RAM/
DVD-RW (VR-mode), divide the scene first, and then
delete the unnecessary part (see page 89).
• If you delete all data on HDD/DVD/card, initialising the
HDD/DVD/card will be recommended (see page 108).
• If the time of deleted scenes (stills) is quite short, the
remaining free space of HDD/DVD/card may not
increase in the HDD/DVD/card or card remaining
indicator.
• The locked scenes on card cannot be deleted (see
page 95).
88
●Editing using submenu
HDD
Press the MENU button before pressing the button in step 5 (see page 88): The submenu will
appear.
Edit Delete*1....................To delete selected scenes
Select Start → Current.......To select scenes from the start to the one that the cursor is on
Go To Top............................ To move the cursor to the first scene
Pressing the button will restore the screen in step 5.
1
*
The menu item to be displayed will vary depending on the setting.
Note:
Although the submenu screen will appear for each setting, some menu items may not appear, depending on the
setting.
Exit............................To restore the Disc Navigation screen
Current → End........To select scenes from the scene the cursor is on to the end
All .............................To select all scenes
End............................ To move the cursor to the last scene
at the moment
HDD
DIVIDING MOVIES (EDIT – DIVIDE)
You can divide a scene into two parts.
To delete unnecessary portion of scene, first divide the scene, and then delete the unnecessary
portion.
English
1 Press the DISC NAVIGATION button.
2 Place the cursor on the scene to be divided.
3 Press the MENU button.
4 Choose, “Scene”, “Edit”, “Divide” and then
press the button.
5 The “Divide Scene” screen will appear: If you
are sure you want to divide the selected
scene, press the button: The selected
scene will be played back.
If you want to change the scene to be divided,
you can change it on this screen.
6 When you reach the
point where you want
to divide the scene,
press the PHOTO/
SELECT button.
7 The screen for verifying
division will appear:
Choose “YES”, and then
press the button.
Sel ect Division Point
The status bar of
scene being played
back can be switched
off or on by pressing
the DISPLAY button
002 00:00:18
ENTER CANCEL
Choose “NO” to cancel division.
After division, the “Divide Scene” screen will
be restored.
Repeat steps 5 – 7 to divide another scene.
8 Press the button to quit.
Note:
• If you press the MENU button before pressing the
button in step 5, the submenu will appear.
• Search and frame advance are useful when
designating division points.
• Combining scenes that were divided will restore the
original scene (see page 90).
• If a special effect has been added to the original
scene, the “IN” effect will be added to the first half of
scene, and the “OUT” effect, to the latter half.
• The division point may drift before or after the
designated point by approximately 0.5 seconds.
• Since a scene with a skip set cannot be played back,
no division point can be specified: Release the skip
for the scene before dividing it.
• If the division point is at a still, a message will appear,
but no division will be made.
• If the division point is at the start or end of a scene, a
message will appear, but no division will be made.
• A movie scene whose recording time is 0.5 seconds
or less cannot be divided.
• If free space available on HDD/DVD is insufficient,
division will not be possible: Delete unnecessary
scenes.
• If you divide a scene with dubbed mark , the
dubbed marks will appear on both divided scenes.
89
HDD
HDD
HDD
English
COMBINING MULTIPLE SCENES (EDIT – COMBINE)
If you have recorded numerous short scenes, combining them will be facilitated by the use of Disc
Navigation.
Be sure to select consecutive multiple scenes. When using the HDD or a DVD-RAM, combining
scenes is possible only when “Category: All” is specified (p. 113). Stills cannot be combined.
1 Press the DISC NAVIGATION button.
2 Press the MENU button, choose “Scene”,
“Edit”, “Combine”, and then press
button.
3 The “Combine Scenes” screen will appear:
Point the cursor at the first scene to be
combined, and then press the button.
The cursor will change to double frames of
blue and yellow.
4 Use the 2/1/0// buttons to
determine the range of scenes to be
combined, point the cursor at the last scene,
and then press the button.
The cursor will change to a red frame. The
last scene will be double frames of red and
yellow.
5 If you do not wish to change the scenes to be
combined, press the button.
To change the scenes, press the (STOP/
EXIT) button to return the cursor to yellow,
and then select the scenes to be combined
again.
6 The screen for verifying combination will
appear: Choose “YES”, and then press the
button.
The two images appearing on the verification
screen are those of the first and last scenes to
be combined.
Choose “NO” to cancel combination.
After Yes or No setting, the “Combine
Scenes” screen will be restored.
The thumbnail of the first scene will appear in
the combined scene.
Repeat steps 3 and 6 to combine other scenes.
7 Press the button to quit.
Note:
• You can also select multiple scenes after step 1:
Press the MENU button to continue the procedure of
combination.
• If you press the MENU button before pressing the
button in step 3, the submenu will appear (see
page 89).
• With fade effect, the “IN” effect of the first scene in the
selected range and the “OUT” effect on the last scene
will be attached to a combined scene.
• Scenes in different programmes (different recording
dates) cannot be combined: Create a play list first,
and then combine such scenes on the play list. (see
page 101)
• When using the HDD, scenes with different VIDEO
Modes or 16:9 mode cannot be combined.
• If you combine scenes with dubbed marks , the
dubbed marks will appear on the combined scene.
• If you combine scenes with and without dubbed mark
, the dubbed mark will not appear on the combined
scene.
HDD
ARRANGING ORDER OF SCENES (EDIT – MOVE)
You can arrange scenes within a play list by moving them to desired positions (p. 106). Create a play
list first, and then arrange the scenes [“CREATING NEW PLAY LIST (CREATE)”, p. 101].
90
DIRECTING SCENES EFFECTIVELY (EFFECT – FADE)
HDD
You can add fading to the beginning and/or end of scene.
There are three types of special effects:
Fade Out Fade Out Fade Out
White:
Fades in from white screen
Fades out to white screen
Wipe:
Fades in from black screen
to vertical direction of screen
Fades out from vertical
direction of screen to black
screen
B/W:
Fades in from Black and
White screen to colour
screen
Fades out from colour screen
to Black and White screen
HDD
English
Fade InFade InFade In
1 Press the DISC NAVIGATION button.
2 Place the cursor on the scene to which fade is
to be added.
3 Press the MENU button.
4 Choose, “Scene”, “Effect”, “Fade” and then
press the button.
5 The “Fade” screen will appear: If you are sure
you want to add the fade effect to the scene,
press the button.
If you want to change the scene to which fade
is added, you can change it on this screen.
6 Select the special effects for “IN” and/or
“OUT”, choose “Enter”, and then press the
button.
You can use the 2/1 buttons to move the
cursor to “IN”, “OUT”, “Enter” or “Cancel”.
Use the 0// buttons to choose the effect
to be added, and then press the button
to set the effect.
To cancel setting, choose “Cancel”.
If you choose “Enter” and press the
button, the “Fade” screen will be restored
after a message appears.
Repeat steps 5 and 6 to add fade to other
scenes.
7 Press the button to quit.
The “2” and/or “3” icon(s) will appear in
the scenes for which fade in and/or fade out
have been set.
“In” effect
PLAY
“Out” effect
Note:
• If a disc on which fade has been set on scene with
this DVD video camera/recorder is played on a DVD
recorder/player, or the scene is captured into a PC,
the set fade will not be reflected (see Note on
page 79).
• When dubbing on a DVD-RW (VF-mode)/DVD-R/
+RW, the setting on fade will not be reflected (see
page 83).
91
HDD
HDD
o
English
PLAYING BACK BY SKIPPING SCENES (EFFECT – SKIP)
You can specify “Skip” for scenes you do not want to play back: The selected scenes will be skipped.
1 Press the DISC NAVIGATION button.
2 Place the cursor on the scene to which skip is
to be set.
Multiple scenes can be selected for skipping
(p. 78).
3 Press the MENU button.
4 Choose “Scene”, “Effect”, “Skip”, and then
press the button.
5 The “Set Skip” screen will appear: If you are
sure you want to skip the selected scene,
press the button.
If you want to change the scene to be
skipped, you can change it on this screen.
After skip setting, the “Set Skip” screen will
be restored.
Repeat step 5 to set skipping of other scenes.
6 Press the button to quit.
A skip icon “ ” will appear in the
thumbnail of any scene for which skipping
has been set.
Skip icon
●Releasing Skip
Perform the same procedure as setting skip: The
skip icon will disappear and skipping of the
scene will be released.
Note:
• If you press the MENU button before pressing the
button in step 5, the submenu screen will appear
(p. 89).
• If a disc on which skip has been set on scene with
this DVD video camera/recorder is played on a DVD
recorder/player, or the scene is captured into a PC,
the set skip will not be reflected (see Note on
page 79).
• When dubbing on a DVD-RW (VF-mode)/DVD-R/
+RW, the setting on skip will not be reflected (see
page 83).
All Pr
92
HDD
HDD
CHANGING IMAGES FOR THUMBNAILS (EFFECT – THUMBNAIL)
Normally, the first image of the recorded scene is displayed as a thumbnail: You can choose another
image of the scene for thumbnail. If you set a vivid image to thumbnail, you can know what you
recorded from a glance at the Disc Navigation screen.
English
1 Press the DISC NAVIGATION button.
2 Place the cursor on the scene whose
thumbnail you wish to change.
3 Press the MENU button.
4 Choose “Scene”, “Effect”, “Thumbnail”, and
then press the button.
5 The “Change Thumbnail” screen will appear:
If you are sure you want to change the
thumbnail of the selected scene, press the
button: The selected scene will be played
back.
If you want to change the scene whose
thumbnail is to be changed, you can change it
on this screen.
6 When the image you want to use as the
thumbnail of the scene appears, press the
PHOTO/SELECT button.
7 The screen for verifying switching of
thumbnail will appear: Choose “YES”, and
then press the button.
Choose “NO” to cancel switching of
thumbnail.
After Yes or No setting, the “Change
Thumbnail” screen will be restored.
Repeat steps 5 – 7 to change the other scenes.
Note:
• If you press the MENU button before pressing the
button in step 6, the submenu screen will appear
(p. 89).
• A thumbnail of still cannot be changed.
• Since the scene to which skipping is set cannot be
played back, you will not be able to change its
thumbnail: Release the skip setting of the scene to
change the thumbnail.
• If a disc on which thumbnail has been set with this
DVD video camera/recorder is played on a DVD
recorder/player, or the scene is captured into a PC,
the set thumbnail will not be reflected (see Note on
page 79).
• When dubbing on a DVD-RW (VF-mode)/DVD-R/
+RW, the setting on changing thumbnail will not be
reflected (see page 83).
8 Press the button to quit.
93
English
COPYING STILLS ON DVD-RAM TO CARD (COPY)
• Set a DVD-RAM (recorded on a Hitachi DVD video camera/recorder that
Before You Begin
can record photos on a DVD-RAM) that includes the photos you wish to
copy, and a card with recordable space, in this DVD video camera/
recorder.
1 Set the power switch to “DVD“.
2 Press the DISC NAVIGATION button.
3 Place the cursor on the scene to be copied.
4 Press the MENU button.
5 Choose “Copy” on the “Scene” menu screen,
and then press the button.
6 The “Copy to card” screen will appear: If you
are sure you want to copy the selected still,
press the button.
If you want to change the still to be copied,
you can change it on this screen.
7 The screen for verifying copy will appear:
Choose “YES”, and then press the
button.
Choose “NO” to cancel copy.
After Yes or No setting, the “Copy to card”
screen will be restored.
Repeat steps 6 and 7 to copy other stills to
card.
8 Press the button to quit.
Note:
• No movie can be copied.
• If you press the MENU button before pressing the
button in step 6, the submenu screen will appear
(p. 89).
• See “Category” (p. 113) to check the stills recorded
on DVD-RAM.
• You can also select multiple scenes (p. 78).
• Even if all scenes, including movies, are selected to
be copied, only stills will be copied.
• Data on card cannot be copied to DVD.
94
LOCKING SCENES ON CARD (LOCK)
You can lock each photo recorded on card so that it will not be deleted or edited by mistake.
English
1 Set the power switch to “SD”.
2 Press the DISC NAVIGATION button.
3 Place the cursor on the scene to be locked.
You can also select multiple scenes (p. 78).
4 Press the MENU button.
5 Choose “Lock” on the “Scene” menu screen,
and then press the button.
6 The “Lock Set” screen will appear: If you are
sure you want to lock the selected scene,
press the button.
7/19
Lock icon
If you want to change the scene to be locked,
you can change it on this screen.
After setting, the “Lock Set” screen will be
restored.
Repeat step 6 to lock another scene.
7 Press the button to quit.
The lock icon “&” will appear on any scene
for which lock has been set.
●To unlock the scene:
Select the locked scene, and then use the
procedure shown on the left to unlock the scene:
The lock icon will disappear and locking will be
released.
Note:
• If you press the MENU button before pressing the
button in step 6, the submenu screen will appear
(p. 89).
• When initialising the card, the locked scenes will also
be deleted.
95
HDD
HDD
English
SELECTING SCENES USING MENU SCREEN (SELECT)
You can use this “Select” function to select consecutive scenes at one time.
This function is useful when there are numerous scenes.
1 Press the DISC NAVIGATION button.
2 Point the cursor at the first or last scene to be
selected: When selecting all scenes, simply
proceed with step 3.
3 Press the MENU button.
●Deselecting selected scenes
Deselecting scenes one by one:
While you are displaying the “All Programs”
screen on which scenes have been selected, place
the cursor on the scene to be deleted, and then
press the PHOTO/SELECT button.
Note:
Up to 999 scenes can be selected.
4 Choose “Select” on the “Scene” menu screen.
5 Choose “Start →
Current”, “Current →
End” or “All” and then
press the button.
Deselecting all the selected scenes at once:
While you are displaying the “All Programs”
screen on which scenes have been selected, press
the button.
Scene
Ed it
Ef fec t
Copy
Select
Detai l
ENTER RETURN
Start– Cur rent
Curr ent– End
All
96
HDD
HDD
DISPLAYING INFORMATION USING MENU SCREEN (DETAIL)
You can display various information for a scene: the recording mode, recording date/time and
length, special effects and movie quality mode.
English
1 Press the DISC NAVIGATION button.
2 Place the cursor on the scene whose
information you wish to know.
3 Press the MENU button.
4 Choose “Scene”, “Detail”, and then press the
button.
The detailed information on the scene will
appear.
(When using HDD/DVD)
Detail
Scene No. 007
VIDEO(FINE) 1min13sec
Dat e: 1/ 3 /2007 8: 00: 00
Ski p:
O
*1
*2
*1 Not displayed with DVD-RW (VF-mode)/DVD-R/
+RW.
*2 When using the HDD, any scene whose
thumbnail has the dubbed mark will appear.
*3 Not displayed with DVD-RAM/DVD-RW/DVD-R
(finalised)/+RW recorded on another device .
*4 Will not appear if the loaded card does not
comply with DCF.
*5 Number of pixels on still in horizontal direction:
This may not appear with a JPEG file that does
not conform to this DVD video camera/recorder.
ff
Fade IN:None OUT:None
Dubbed
PREV NEXT RETURN
(When using card)
Detail
Scene No. 7
100–0007 (640 )
Dat e: 1/ 3 /2007 8 : 00: 00
Lock :
O
ff
PREV NEXT RETURN
*3
*4
*5
Note:
• If multiple scenes have been selected, the total
recording time of the selected scenes (total number in
case of stills) will appear.
(When using HDD/DVD)
De tai l
V I DEO : 1
m
in43sec ( 2scenes)
m
in 0sec ( 0scenes)
(XTRA) : 0
m
in43sec ( 2scenes)
(F INE): 1
m
in 0sec ( 0scenes)
(STD) : 0
(---) : 1
m
PHOTO : 0
RETURN
in 0sec ( 0scenes)
*1
*2
*3
*1 Number of scenes whose quality mode is
unknown:
This will appear when the disc has a scene
recorded on a device other than this DVD video
camera/recorder, only if the disc has a scene
whose mode is unknown.
*2 This will appear with a DVD-RAM, including
photos recorded on a Hitachi DVD video camera/
recorder that has this capability.
*3 Not displayed with a DVD-RAM/DVD-RW/DVD-R
(finalised) /+RW that was recorded on another
device.
(When using card)
De tai l
Scene No. 6
10/ 3/ 2007 12: 50:00
Scene No. 7
15/ 3/ 2007 8:0 0:00
Scenes: 2
RETURN
Note:
• DCF (Design rule for Camera File system) is a
unified image file format for video cameras: Image
files can be commonly used for all digital devices
that conform to DCF. This DVD video camera/
recorder complies with DCF.
• Pressing the / button will display information on
the following scene; pressing the 0 button will
display information on the preceding scene.
5 Press the button to quit.
97
English
HDD
Programme
WHAT IS “PROGRAMME”?
Programme refers to an assembly of scenes recorded on the same date regardless of whether they are
movie or still.
Scene No. 1 Scene No. 2 Scene No. 3 Scene No. 4 Scene No. 5 Scene No. 6
9:00
Movie
Movie
10:20
Still
Programme No. 1
Recorded on March 10
SWITCHING TO THUMBNAIL DISPLAY OF SPECIFIC DATE (SELECT)
Since the scenes recorded on this DVD video camera/recorder are collected as “programmes” for
each recording date, selecting a programme will allow you to display only the scenes on a specific
date.
11:45
Still
HDD
13:30
Movie
17:20 20:00
Still
1 Press the DISC NAVIGATION button.
2 Press the MENU button.
3 Use the 2/1/0/// buttons to
choose “Select” on the “Program” menu
screen, and then press the button.
4 Select the programme
to be displayed, and
then press the
button.
The Disc Navigation
screen of the selected
programme will
appear.
Select Progra
All Programs
01 1 / 3/ 2007
02 5/ 3 /2007
03 10/ 3 /2007
ENTER RETURN
10/ 3
PLAY PHOTO SELECT
/2007
m
001/00803
Note:
• Pressing the button on the “Select Program” screen
will restore the Disc Navigation screen.
• If a disc recorded on another device is loaded in this
DVD video camera/recorder, the programme may not
be a collection of recordings on the same date.
• If you change the video quality or switch the wide
mode with a +RW, multiple programmes will be
produced even if they are recorded on the same date.
98
PLAYING BACK PROGRAMME (PLAY)
HDD
HDD
You can play back only the selected programme.
HDD
English
1 Press the DISC NAVIGATION button.
4 Select the programme to be played back, and
then press the button.
2 Press the MENU button.
3 Use the 2/1/0/// buttons to
choose “Play” on the “Program” menu
screen, and then press the button.
CHANGING TITLE OF PROGRAMME (TITLE)
The recording date/time has initially been attached to any programme.
You can change the recording date/time to any desired title.
1 Press the DISC NAVIGATION button.
2 Press the MENU button.
Playback will start from the first scene of the
selected programme.
Note:
If “Repeat Play: On” is specified, the selected
programme will be repeatedly played back (PLAYING
BACK SCENES REPEATEDLY (REPEAT PLAY),
p. 114).
6 After entering the title,
choose “Enter” and
then press the
button.
3 Choose “Title” on the “Program” menu
screen, and then press the button.
4 Select the programme
whose title you want to
change, and then press
the button.
Progra
m Title
01 1 / 3/ 2007
02 5/ 3 / 2007
03 10/ 3 /2007
ENTER RETURN
The screen for setting a title will appear.
5 Use the 2/1/0/
/ buttons to select a
letter, and then press
the button: The
selected letter will be
entered.
Title input bar
10/ 3 /2007TITLE
1 234567890SPACE
ABCDEFGHI JKLM
NOPQRST UVWXYZ
АИ М ТЩБЙ Н УЪГСХ
ВК О ФЫДЛ П ЦЬЗ
1 Cancel
INPUT DELETE SELECT
Ent er
7 The screen for verifying
the change in title will
appear: Choose “YES”,
and then press the
button.
Choose “NO” to cancel changing of the title.
After Yes or No setting, the Disc Navigation
screen of the selected programme will appear.
HDD
TITLE
1234567890SPACE
abcdefghi jk lm
nopqrs tuvwxyz
аи мтщб йн уъгсх
вк офыдл пцьзЯ
2 En ter Cancel
ENTER DELETE SELECT
TITLE at a Par k
Finish title setting?
ENTER
at a Park
YES NO
Repeat this procedure,
inputting letters one by
one to create a title.
Up to 20 characters can
be input.
Input mode
Palette for selecting
characters
99
Note:
English
• If you wish to delete the letter for title, press the
button once: The input letter will be deleted. Holding
down the button will delete all letters in the TITLE
column.
• You can also use the DELETE button on remote
control to delete any input letters.
• Pressing the PHOTO/SELECT button on the title
setting screen (in step 5) will change the cursor
position from the title input bar to character select
palette, input mode number, and then to “Cancel”. You
can also use the 2/1/ 0 // buttons to move
the cursor up/down and to the left/right and change its
position.
• To cancel the setting of title, choose “NO” on the
screen for verifying the entered title: The screen for
verifying cancellation of title setting will appear. To
cancel title setting, choose “YES”.
• If you press the button on the screen for verifying
change in title, the title setting screen will be restored.
• Double byte characters set on other devices may be
displayed blank on this DVD video camera/recorder.
• Titles set on this DVD video camera/recorder may not
be visible on other devices.
●Characters available for entering
title
You can choose the title input mode: “capital
letter”, “small letter” or “symbol”.
To change the input mode in step 5, press the
DISPLAY button, or use the PHOTO/SELECT
button to place the cursor on the input mode,
and then press the button.
TITLE
30/ 3/ 2007
1234567890SPACE
ABCDEFGHI JKLM
NOPQRST UVWXYZ
АИ М ТЩБЙ Н УЪГСХ
ВК О ФЫДЛ П ЦЬЗ
Ent er
1 Cancel
CHANGE DELETE SELECT
Input mode
TITLE
30/ 3/ 2007
1234567890SPACE
abcdefg hi jklm
nopqrs tuvwxyz
аи мтщб йн уъгсх
вк офыдл пцьзЯ
Ent er
2 Cancel
CHANGE DELETE SELECT
TITLE
1234567890SPACE
3 Cancel
CHANGE DELETE SELECT
30/ 3/ 2007
Ent er
100
Loading...
