LIST NO. J887
CORDLESS DRIVER DRILL
Model DS 10DFL2
1
6
7
8
9
10
11
12
13
21
22
23
24
25
26
27
28
2014 · 7 · 10
(E1)
2
4
14
15
16
3
5
17
18
19
20
503
505
504
501
502
29
30
31
39
37
34
35
38
36
33
32
40
41
Page 2
PART
S
ITEM
CODE NO.
NO.
1 337426 LEFT-HAND HEXALOBULAR M5 1
DESCRIPTION REMARKS
* 2 337390 DRILL CHUCK 10TLRM-N (W/O CHUCK WRENCH) 1
* 2 337389 DRILL CHUCK 10TLRM-N (W/O CHUCK WRENCH) 1 FOR USA,CAN
3 337407 GEAR BOX ASS'Y 1 INCLUD.4-28
4 337423 CLUTCH DIAL 1
5 337422 NUT 1
6 337421 SPRING 1
7 337420 THRUST PLATE 1
8 337408 FRONT CASE 1
9 320773 CLICK SPRING 1
10 337411 WASHER (B) 1
11 337409 LOCK RING 1
12 319744 ROLLER 4
13 306936 STEEL BALL D5 6
14 337412 RING GEAR 1
15 337410 CARRIER 1
16 337415 PLANET GEAR (C) SET (4 PCS.) 4
17 320762 PLATE (B) 1
18 337413 REAR CASE 1
19 337425 SCREW SET D2.6 X 12 (4 PCS.) 4
20 337424 SHIFT ARM (A) 1
21 337416 SLIDE RING GEAR 1
22 337414 PINION (C) 1
23 320781 PLANET GEAR (B) SET (4 PCS.) 4
24 337417 PINION (B) 1
25 337418 PLANET GEAR (A) SET (3 PCS.) 3
26 328726 FIRST RING GEAR 1
27 320768 PLATE (A) 1
28 337419 MOTOR SPACER 1
29 337406 MOTOR DC 12V 1
* 30 INTERNAL WIRE (RED) 1 FOR USA,CAN
* 31 INTERNAL WIRE (BLACK) 1 FOR USA,CAN
* 32 337357 TRUSS HD. SCREW M4 (BLACK) 1 FOR USA,CAN
* 33 337362 HOOK (A) ASS'Y 1 INCLUD.32 FOR USA,CAN
34 337403 HOUSING (A).(B) SET 1
35 337405 SHIFT KNOB 1
* 36 334866 INTERNAL WIRE FERRITE SET 1 FOR GBR
37 329548 PUSHING BUTTON (A) 1
38 337359 SWITCH TERMINAL SET 1
39 NAME PLATE 1
40 313687
TAPPING SCREW (W/FLANGE) D3 X 16 (BLACK) 8
* 41 331067 BATTERY BCL 1015 (EUROPE,AUS,NZL) 2 INCLUD.504
* 41 BATTERY BCL 1015S (USA,CAN) 2 INCLUD.504 SUPPLIED WITH ITEM NO.603
NO.
USED
DS 10DFL2
- 2 - 7 - 14 *ALTERNATIVE PARTS
Page 3
STANDARD ACCESSORIES
ITEM
NO.
CODE NO.
DESCRIPTION REMARKS
501 CHARGER (MODEL UC 10SL2) 1
502 336642 CASE 1
503 983006 + DRIVER BIT NO.2 65L 1
504 331086 BATTERY COVER 1
* 505 BIT SET 1 FOR USA,CAN
NO.
USED
OPTIONAL ACCESSORIES
ITEM
NO.
CODE NO.
DESCRIPTION REMARKS
* 601 337362 HOOK (A) ASS'Y 1 INCLUD.602 FOR GBR
* 602 337357 TRUSS HD. SCREW M4 (BLACK) 1 FOR GBR
* 603 331065 BATTERY BCL 1015 (USA,CAN) 1 INCLUD.504
* 604 337384 BATTERY BCL 1030 (EUROPE) 1 INCLUD.504 FOR GBR
NO.
USED
DS 10DFL2
7 - 14 Printed in Japan - 3 -
*ALTERNATIVE PARTS
(140710N)
