Hitachi CP-SX1350W User Manual

1

Projector

CP-SX1350

CP-SX1350

User's Manual - Operating Guide

User's Manual - Operating Guide

Thank you for purchasing this projector.

TRADEMARK ACKNOWLEDGMENT :

• VGA and XGA are registered trademarks of International Business Machines Corporation.

• Apple and Mac are registered trademarks of Apple Computer, Inc.

• VESA and SVGA are trademarks of Video Electronics Standard Association.

• Windows is a registered trademark of Microsoft Corporation.

• Internet Explorer is a trademark of Microsoft Corporation.
All other trademarks are the property of their respective owners.

WARNING Before using the product, please read the "User's Manual ­Safety Guide" and related manuals to ensure the proper use of this product.

After reading them, store them in a safe place for future reference.

• The information in this manual is subject to change without notice.

• The manufacturer assumes no responsibility for any errors that may appear in this manual.

• The reproduction, transfer or copy of all or any part of this document is not permitted without
express written consent.

NOTE

MP

A
L

MP
E

T

N

O
/

ANDBY
T
S
O

VIDE
U
N

ME

-VIDEO

S

R
E

M

T

O

N

I
O
Z

FOCUS

T

T

E

N

S

E

E

N

R

OMPO
C

BNG
T
U

P
N
I

T

RCH

RGB

SHIF

SEA

S
N

LE

D

­M1

E

N
O

KEYST

2

Projector Features

Projector Features

Preparation

Preparation

●

Ultra High Brightness

Crisp, ultra-bright presentations is achieved by using a UHB (ultra high brightness) lamp and a highly
efficient optical system.

●

Whisper Mode Equipped

Special mode is available for reducing projector noise to achieve quieter operation.

●

User Memory Function

This projector can memorize 4 settings by MY MEMORY function.

●

Partial Magnification Function

Interesting parts of images can be magnified for closer viewing.

●

Keystone Distortion Correction

Quick correction of distorted images electrically.

●

Optical Lens Shift

The lens of this projector can be shifted vertically. When you want to finely adjust the picture position,
use the LENS SHIFT buttons.

This multimedia projector is used to project various computer signals as well as
NTSC/PAL/SECAM video signals onto a screen. Little space is required for
installation and large images can easily be realized.

Please see the “Contents Of Package” of the “User’s Manual – Quick Guide”.
Your projector should come with the items shown there. Contact immediately
your dealer if anything is missing.

• Keep the original packing materials for future reshipment. For moving the projector, be

sure to use the original packing materials. Use special caution for the lens part.

NOTE

3

Content

Content

Projector Features

……………………………………

2

Preparation

……………………………………………………

2

Part Names

……………………………………………………

4

Projector ……………………………4
Control Buttons ……………………5
Remote control ……………………5

Setting Up

…………………………………………………………

6

Arrangement ………………………6
Adjusting The Projector’s
Elevator ……………………………7
Using The Lens shift Buttons ……7
Connecting Your Devices…………8
Connecting The Power Supply …11

Remote Control

…………………………………………

12

About The Laser Pointer ………12
Loading Batteries ………………12
Operating The
Remote Control …………………13
Using The Remote
ID Feature…………………………13
Using The Mouse/Keyboard
Control Function …………………14

Power ON/OFF

…………………………………………

15

Turning On The Power …………15
Turning Off The Power …………15

Operating

……………………………………………………

16

Selecting An Input Signal ………16
Selecting The Aspect Ratio ……17
Using The Automatic
Adjustment Feature………………17
Adjusting The Picture Position …18
Correcting The Keystone
Distortion …………………………18
Adjusting The Volume …………19
Muting The Sound ………………19
Temporarily Blanking
The Screen ………………………19
Freezing The Screen ……………20
Using The Magnify Feature ……20
Displaying The Child Window …21
Selecting An Audio Input ………21

Multifunctional Settings

……………………

22

Using The Menu Functions ……22
MAIN Menu ………………………23
PICTURE-1 Menu ………………24
PICTURE-2 Menu ………………26
INPUT Menu ……………………27
AUTO Menu ………………………29
SCREEN Menu …………………31
OPTION Menu ……………………33
NETWORK Menu ………………35

Network Setting Up

………………………………

36

Lamp

………………………………………………………………

37

Replacing The Lamp ……………38

Air Filter

…………………………………………………………

39

Caring For The Air Filter…………39

Other Care

……………………………………………………

40

Caring For The Inside Of
The Projector ……………………40
Caring For The Lens ……………40
Caring For The Cabinet And
Remote Control …………………40

Troubleshooting

……………………………………

41

Related Messages ………………41
Regarding The Indicator
Lamps ……………………………43
Phenomena That May Easily Be
Mistaken For Machine Defects …45

Warranty And After-Service

…………

47

Specifications

…………………………………………

47

TECHNICAL

4

Part Names

Part Names

Projector

1 Elevator button
2 Elevator foot
3 Remote sensor
4 Lens cap
5 Lens

The picture is projected from
here.

6 Filter cover

An air filter is inside.

A RGB port
B M1-D port
C BNC port
D AUDIO IN 1 port
E AUDIO IN 2 port
F CONTROL port
G NETWORK port
H AUDIO IN R/L port
I VIDEO IN port
J S-VIDEO port
K COMPONENT port
L RGB OUT port
M AUDIO OUT port

7 REMOTE CONTROL port
8 DC OUT port
9 AC Inlet
0 Power switch

- Control buttons

See the following page.

Projector (Front/Right)

Projector (Rear/Left)

5

4

8

7

L

REMOTE CONTROL

N2

RGB

AUDIO OUT

RGB OUT

/P

R

G/Y

B/C

B

/P

BNC

CR/PR

B

H

V

R-AUDIO IN-L

M

H

D
E

A

B

AUDIO IN1

AUDIO

R/C

C

I

R

Ca/Pa

I

LENS SHIFT

VIDEO

M

O

O

COMPON

VIDEO

F

CONTROL

Y

LAMP

EMP
T

ON
/

NDBY

STA

EO

VID

U

MEN

EO

S-VID

TER

Z

IN

FOCUS

T

NT

SE

E

E

R

PON

COM

BNG

PUT

IN

RGB

SEARCH

E

SHIFT

S

N

E

L

M1-D

KEYSTON

3

6

1

2

-

KEYSTONE

M

1-D

RG

B

SEARCH

INPU

T

BNG

E

N

T

RESET

IN

S-VID

TE

R

E

MP

K

LAMP

G

FOCUS

ZOOM

MENU

3

STANDBY/ON

EO

T

NETWORK

S-VIDEO

J

09

5

Part Names (continued)

Part Names (continued)

Remote Control

Control Buttons

1

e

w q

4

7

8

9

0

­=

2

5

6

t

y

u

3

r

1 STANDBY/ON button

and STANDBY/ON indicator

2 TEMP indicator
3 LAMP indicator
4 LENS SHIFT buttons
5 INPUT dial
6 SEARCH button
7 M1-D indicator
8 RGB indicator
9 BNC indicator
0 COMPONENT indicator

- S-VIDEO indicator
= VIDEO indicator
q ZOOM buttons
w FOCUS buttons
e KEYSTONE button
r MENU button
t RESET button
y ENTER button
u Cursor buttons / / /

Control Panel
on the Projector

Remote Control

i LASER INDICATOR
o VIDEO button
p RGB button
[ BLANK button
] ASPECT button
\ LASER button
a Cursor buttons / / /

( Mouse move pointer)

s ESC button

( Keyboard ESC key)

d ( Mouse right button)
f POSITION button
g AUTO button
h PinP button
j MAGNIFY buttons
k FREEZE button
l VOLUME button
; MUTE button
' ID CHANGE switch

1 STANDBY/ON button

4 LENS SHIFT buttons

6 SEARCH button

q ZOOM buttons
w FOCUS buttons
e KEYSTONE button
r MENU button
t RESET button
y ENTER button

( Mouse left button)

u Cursor buttons

///
( Keyboard
Arrow keys / / / )

(Rear)

MP
A

L

P

M
E

T

ON
/

Y

ANDB

ST
O

E

VID

U

N
E
M

DEO
I

V

S-

R

M

E
T

O

N
I

O

Z

FOCUS

T

T

E

N

S

E

E

R

ON
P

COM

NG

B

T

U

P

IN

CH

B

T

R

G

A

R

HIF

E
S

S

S

N

LE

-D
1

M
E
N
O

T
S

KEY

y

i

STANDBY/ON

1

q

+

LENS SHIFT

4

–––

BLANK

w

PREVIOUS

u

r

s
f
h

j

k

e

ESC MENU

POSITION

MAGNFY

ON

OFF

LASER INDICATOR

VIDEO

++

FOCUS ZOOM

ASPECT

MOUSE

RESET AUTO

PinP

FREEZE MUTE

KEYSTONE

1 2 3

ID CHANGE

RGB

LASER

NEXT

VOLUME

SEARCH

o

p

[
\

]

a
d

t

g
l

;

6

'

6

Setting Up

Setting Up

Arrangement

WARNING • Before installation, make sure that the projector is turned off and the
power code is disconnected.

• Do not set up and move the projector, while it is hot.

• Install the projector in a suitable environment according to instructions of the “User’s
Manual – Safety Guide” and this manual.

• The power outlet should be close to the projector and easily accessible.

Refer to the illustrations and tables below to determine the screen size and projection
distance. The values shown in the table are calculated for a full size screen. (±10%)

Reference for
the 4:3 aspect ratio

A

[inch (m)]B[inch (cm)]

C [inch (m)] D [inch (cm)]

min. max. min. max.
40(1.0) 24(61) 46(1.2) 71(1.8) 12(30) 24(61)
60(1.5) 36(91) 71(1.8) 107(2.7) 18(46) 36(91)
70(1.8) 42(107) 83(2.1) 126(3.2) 21(53) 42(107)
80(2.0) 48(122) 95(2.4) 144(3.7) 24(61) 48(122)

100(2.5) 60(152) 120(3.0) 181(4.6) 30(76) 60(152)
120(3.0) 72(183) 144(3.7) 217(5.5) 36(91) 72(183)
150(3.8) 90(229) 181(4.6) 272(6.9) 45(114) 90(229)
200(5.1) 120(305) 243(6.2) 364(9.2) 60(152) 120(305)
250(6.4) 150(381) 304(7.7)

455(11.6)

75(191) 150(381)

300(7.6) 180(457) 366(9.3)

547(13.9)

90(229) 180(457)

350(8.9) 210(533)

427(10.9) 638(16.2)

105(267) 210(533)

400(10.2) 240(610)

489(12.4) 730(18.5)

120(305) 240(610)

500(12.7) 300(762)

612(15.5) 913(23.2)

150(381) 300(762)

A

[inch (m)]B[inch (cm)]

C [inch (m)] D [inch (cm)]

min. max. min. max.
40(1.0) 20(50) 50(1.3) 77(2.0) 10(25) 23(58)
60(1.5) 29(75) 77(2.0) 117(3.0) 15(37) 34(87)
70(1.8) 34(87) 91(2.3) 137(3.5) 17(44) 40(102)
80(2.0) 39(100) 104(2.6) 157(4.0) 20(50) 46(116)

100(2.5) 49(125) 131(3.3) 197(5.0) 25(62) 57(145)
120(3.0) 59(149) 158(4.0) 237(6.0) 29(75) 69(174)
150(3.8) 74(187) 198(5.0) 297(7.5) 37(93) 86(218)
200(5.1) 98(249) 265(6.7)

396(10.1)

49(125) 114(291)

250(6.4) 123(311) 332(8.4)

496(12.6)

61(156) 143(363)

300(7.6) 147(374)

399(10.1) 596(15.1)

74(187) 172(436)

350(8.9) 172(436)

466(11.8) 696(17.7)

86(218) 200(508)

400(10.2) 196(498)

533(13.5) 795(20.2)

98(249) 229(581)

450(11.4) 221(560)

600(15.2) 895(22.7)

110(280) 257(654)

D

B

C

A

B

Screen

Side view

Reference for
the 16:9 aspect ratio

D

B

C

A

B

Screen

Side view

I

N

T

E

R

I

N

P

U

T

M

1

-D

RG

B

BN

G

S

-

V

I

D

E

O

S

TA

N

DBY

/

ON

T

E

M

P

VIDE

O

C

O

M

P

O

N

E

N

T

L

AMP

K

E

Y

S

T

ON

E

S

E

A

RC

H

R

E

S

E

T

ME

N

U

F

OCUS

LE

N

S

SHIF

T

ZO

O

M

7

Setting Up (continued)

Setting Up (continued)

Adjusting The Projector's Elevator

Using The Lens Shift Buttons

You can use the elevator feet to make adjustments if the surface on which you need to set
the projector is uneven or if you otherwise need to adjust the angle of projection. The
adjustment range of the elevator feet is 0 to 9 degrees.

WARNING • Do not touch about the lens and ventilation openings during use or
immediately after use to prevent a burn.

CAUTION

•

Do not incline the projector rightward or leftward. Also do not incline

it backward or forward exceeding 9 degrees. Exceeding these range could cause

malfunction, and could shorten the lifetime of the consumables.

• To prevent damaging the projector and injuring yourself, always hold the projector
whenever using the elevator buttons to adjust the elevator feet.

Press and hold in the elevator buttons.

Raise or lower the projector to the desired height and
then release the elevator buttons.
When you release the elevator buttons, the elevator
feet will lock into position.

As necessary, you can also finely adjust the height of
the projector by twisting the elevator feet by hand.

Elevator buttons

Elevator feet

The lens of this projector can be shifted
vertically. When you want to finely adjust the
picture position, use the LENS SHIFT buttons
of the projector.

1

2

3

STANDBY/ON

VIDEO

LASER INDICATOR

RGB

BLANK ASPECT LASER

LENS SHIFT

+

–––

++

FOCUS ZOOM

Projector

LENS SHIFT buttons

Remote control

8

Setting Up (continued)

Setting Up (continued)

Connecting Your Devices

WARNING • Whenever attempting to connect other devices to the projector, read
thoroughly the "User's Manual - Safety Guide", this manual and the manual of each

device to be connected. Incorrect connecting could result in fire or electrical shock.

CAUTION

• TURN OFF ALL DEVICES prior to connecting them to the projector.

Attempting to connect a live device to the projector may generate extremely loud
noises or other abnormalities that may result in malfunction and/or damage to the
device and/or projector.

ATTENTION

•

Make sure that you connect devices to the correct port. Incorrect connection
may result in malfunction and/or damage to the device and/or projector. Refer to the section
“Technical” of this manual for the pin assignment of connectors and RS-232C communication data.

•

Some cables have to be used with core set. Use the accessory cable or a designated-type cable
for the connection. For cables that have a core only at one end, connect the core to the projector.

• Secure the screws on the connectors and tighten.

• Whenever attempting to connect a laptop computer to the projector, be sure to

activate the laptop’s RGB external image output (set the laptop to CRT display or to
simultaneous LCD and CRT display). For details on how this is done, please refer to
the instruction manual of the corresponding laptop computer.

• Some computers may have multiple display screen modes. Use of some of

these modes may not be compatible with this projector.

• For some RGB input modes, the optional Mac adapter is necessary.

• When the image resolution is changed on a computer, depending on an input,
automatic adjust function may take some time and may not be completed. In this
case, you may not be able to see a check box to select “Yes/No” for the new
resolution on Windows. Then the resolution will go back to the original. It might be
recommended to use other CRT or TFT monitors to change the resolution.

NOTE

Plug-and-Play Capability

• Plug-and-Play is a system incorporated in the computer, its operating system and

peripheral equipment (i.e. display devices).

•

This projector is compatible with VESA DDC 2B. Plug-and-Play can be achieved by
connecting this projector to computers that are VESA DDC (display data channel) compatible.

• Please take advantage of this function by connecting the accessory RGB cable to the

RGB port (DDC 2B compatible). Plug-and-Play may not work properly if any other
type of connection is attempted.

•

Please use the standard drivers in your computer as this projector is a Plug-and-Play monitor.

• The CP-SX1350's M1-D is compatible with HDCP (High-bandwidth Digital Content

Protection) and therefore capable od displaying video from HDCP compatible DVD
players, et al. However, if the HDCP standards are modified, the CP-SX1350's M1-D
might not be able to display video from HDCP compatible developed in conformance
to such modified HDCP standards.

NOTE

9

Setting Up (continued)

Setting Up (continued)

Please refer to the following (for example) for connecting your devices. See the rear of the projector.
You can see the ports.

R/CR/PR G/Y B/CB/PB H V

Examples of connection with a computer

VIDEOR-AUDIO IN-L

S-VIDEO

BNC

RGB

AUDIO IN1

AUDIO IN2

RGB OUT

AUDIO OUT

REMOTE CONTROL

R/C

R/PR G/Y B/CB/PB HV

Y

CONTROL

NETWORK

CR/PR

Ca/Pa

A

E

F G

REMOTE CONTROL

VIDEOR-AUDIO IN-L

S-VIDEO

BNC

RGB

AUDIO IN1

AUDIO IN2

RGB OUT

AUDIO OUT

G/Y H V

Y

CONTROL

NETWORK

CR/PR

Ca/Pa

R/CR/PR B/CB/PB

B

D

REMOTE CONTROL

VIDEOR-AUDIO IN-L

S-VIDEO

BNC

RGB

AUDIO IN1

AUDIO IN2

RGB OUT

AUDIO OUT

R/C

R/PR G/Y B/CB/PB HV

Y

CONTROL

NETWORK

CR/PR

Ca/Pa

C

D

Computer Projector

RGB out RGB cable RGB

Audio out Stereo Mini cable AUDIO IN 2

RS-232C port RS-232C cable CONTROL

Network port CAT-5 cable NETWORK

■ If using a M1-D input (to mouse control)

■ If using a BNC input

DVI port M1-D

USB port M1-D cable

Audio out Stereo Mini cable AUDIO IN 1

BNC cable

RGB out

R/C

R/PR

G/Y
B/CB/PB
H
V

C

D

B

G

F

E

A

D

Audio out Stereo Mini cable AUDIO IN 1

KE

Y
ST

O
N

E
L
E

N

M

S

1

SHIF

­D

T

RG

B

SEAR

INP

U
T

C

H
B
N

G
C
O

M

P

ON

E
NT

RE
S

ET
I
N

S

T

­V

E
R

ID

F

O
E
O

C
US

Z
O

O

M
V
I
DEO

ME

N

U
S
T
A

N
DBY

/
O

N

T
E
M

P

LA

M

A

U
D

IO

I
N1

A

U

D
IO

I
N

2

RGB

RGB OUT

R/C

R

/

P

R

G/Y

B/C

B

/P

B

H

BNC

P

REMOTE

CONTROL

CON

TROL

NETWO

RK

A
U

D
IO

O

UT

CR/PR

Ca/Pa

Y

V

R

-A
U
D
IO

I
N

­L

V

ID

E
O

S

-V
ID

E
O

10

Setting Up (continued)

Setting Up (continued)

VIDEOR-AUDIO IN-L

S-VIDEO

BNC

RGB

AUDIO IN1

AUDIO IN2

RGB OUT

AUDIO OUT

R/C

R/PR G/Y B/CB/PB HV

Y

CONTROL

NETWORK

CR/PR

Ca/Pa

REMOTE CONTROL

H I

REMOTE CONTROL

VIDEOR-AUDIO IN-L

S-VIDEO

BNC

RGB

AUDIO IN1

AUDIO IN2

RGB OUT

AUDIO OUT

R/C

R/PR G/Y B/CB/PB HV

Y

CONTROL

NETWORK

CR/PR

Ca/Pa

H J

REMOTE CONTROL

VIDEOR-AUDIO IN-L

S-VIDEO

BNC

RGB

AUDIO IN1

AUDIO IN2

RGB OUT

AUDIO OUT

R/C

R/PR G/Y B/CB/PB HV

Y

CONTROL

NETWORK

CR/PR

Ca/Pa

H

K

VCR/DVD Player Projector

■ If using a s-video signal

■ If using a component signal

R-AUDIO IN-L VIDEO
R-AUDIO IN-L VIDEO

COMPONENT

S-video out S-video cable S -VIDEO

J

CR

/PR

CB

/PB

Y

CR

/PR out

CB/PB out

Y out

R-AUDIO IN-L VIDEO

R-AUDIO IN
AUDIO IN-L

Audio out (R)

Audio out (L)

Audio out (R)

Audio out (L)

R-AUDIO IN
AUDIO IN-L

R-AUDIO IN
AUDIO IN-L
VIDEO IN

Audio out (R)

Audio out (L)

Video out

H

H

K

H

REMOTE CONTROL

VIDEOR-AUDIO IN-L

S-VIDEO

BNC

RGB

AUDIO IN1

AUDIO IN2

RGB OUT

AUDIO OUT

R/C

R/PR G/Y B/CB/PB HV

Y

CONTROL

NETWORK

CR/PR

Ca/Pa

HI

K

■ If using a SCART RGB input

R (CR/PR)
B (CB/PB)
G (Y)
R-AUDIO IN
AUDIO IN-L
VIDEO IN

SCART
RGB out

SCART
adapter

K

I

H

I

Examples of connection with a VCR/DVD Player

COMPONENT

R-AUDIO IN-L VIDEO

11

Setting Up (continued)

Setting Up (continued)

REMOTE CONTROL

VIDEOR-AUDIO IN-L

S-VIDEO

BNC

RGB

AUDIO IN1

AUDIO IN2

RGB OUT

AUDIO OUT

R/C

R/PR G/Y B/CB/PB HV

Y

CONTROL

NETWORK

CR/PR

Ca/Pa

L

REMOTE CONTROL

VIDEOR-AUDIO IN-L

S-VIDEO

BNC

RGB

AUDIO IN1

AUDIO IN2

RGB OUT

AUDIO OUT

R/C

R/PR G/Y B/CB/PB HV

Y

CONTROL

NETWORK

CR/PR

Ca/Pa

M

Monitor Projector

RGB in RGB cable RGB OUT

Connecting to a monitor

Speaker Projector

Connecting to a speaker (with amplifier)

Audio in Stereo Mini cable AUDIO OUT

M

L

WARNING •

Use extra caution when connecting the power cord as incorrect or faulty

connections may result in fire and/or electrical shock. Please adhere to the “User’s manual –

Safety Guide” and the following.

•

Only plug the power cord into outlets rated for use with the power cord’s specified voltage range.

•

Only use the power cord that came with the projector. If it is damaged, contact your dealer to
newly get correct one.

•

Never modify the power cord. Never attempt to defeat the ground connection of the three-pronged plug.

•

Make sure that you firmly connect the power cord to the projector and wall outlet.

1

Connect the connector of the power cord to
the AC inlet of the projector.

2

Firmly plug the power cord’s plug into the
outlet.

AC Inlet

Connector Plug

Outlet

Connecting The Power Supply

KEYST

ONE
L
E

N

M

S SHIFT

1

-D

RG

B

SEARCH

I
N

P
U

T

BN

G

COM

P

ONENT

R

E

SE

T

I
N

S-VIDEO

T

E
R

F

OCUS

Z

O
O

V

A
U
D

IO

I
N1

A
U

D
IO

I
N2

R/C

R

/P

R

ID

REMOTE

CONTROL

CONTROL

RGB

A

UDIO

O

RGB

UT

OUT

CR/PR

Ca/Pa

Y

G/Y

B/C

B

/P

B

H

V

R

-A
U

D

IO

I
N

-L
VIDE

O

BNC

M

M
E
O

E

N
U

S

TANDBY

/
O

N

TEM

P

LA

MP

NETWORK

S-V

IDE

O

12

Remote Control

Remote Control

About The Laser Pointer

Loading Batteries

WARNING • The laser pointer of the remote control is used in place of a finger or
rod. Never look directly into the laser beam outlet or point the laser beam at other

people. The laser beam can cause vision problems.

CAUTION

• Use of controls or adjustments or performance of procedures other

than those specified herein may result in hazardous radiation exposure.

STANDBY/ON

VIDEO

LA

S

ER IN

D

ICA

TO

R

ESC MENU

POSITION

RESET AUTO

KEYSTONE

1 2 3

ID CHANGE

SEARCH

ON

OFF

FREEZE MUTE

MAGNFY

PinP

VOLUME

RGB

BLANK

PREVIOUS

NEXT

ASPECT LASER

LENS SHIFT

+

–––

++

FOCUS ZOOM

MOUSE

JQA

MADE IN CHINA

P S

C

レーザー光をのぞき込まないこと。
レーザー光を人に向けないこと。
子供に使わせないこと。
製造者：INTERLINK ELECTRONICS

This remote control has a laser pointer in place of a finger or rod. The laser beam works and the
LASER INDICATOR lights while the LASER button is pressed.

CAUTION • About the battery

• Keep a battery away from children and pets.

• Use only the battery specified: two AA batteries.

• Do not mix new battery with used one.

• Make sure the plus and minus terminals are correctly aligned when loading the
battery (as indicated in the remote control).

• Dispose of batteries in accord with environmental laws.

1

Remove the battery
cover.
Slide back and
remove the battery
cover in the direction
of the arrow.

Insert the batteries.
Align and insert the
two AA batteries
according to their plus
minus terminals (as
indicated in the remote
control).

Close the battery
cover.
Replace the battery
cover in the direction
of the arrow and snap
it back into place.

2

3

AVOID EXPOSURE-LASER

RADIATION IS EMITTED
FROM THIS APERTURE

CAUTION

WAVE LENGTH: 640-660nm
MAX OUTPUT: 1mW
CLASS 2 LASER PRODUCT

Comples with 21 CFR, 1040.10 AND 1040.11
IEO60825-1:1993+A1:1997+A2:2001
LASER-STRAHLING
NICHT IN DEN STRAHL BLICKEN
LASER KLASSE 2
WAVE LENGTH:640-660nm MAX OUTPUT:1mW

レーザー光
ビームをのぞきこまないこと
クラス2レーザー製品 JISC6802（1998）
最大出力：1.0mW 波長：640−660nm

MODEL:H-IRC4

LASER RADIATION

DO NOT STARE INTO BEAM

MANUFACTURER: B
MANUFACTURED

JANUARY,2003
INTERLINK K.K.
1-10-7 HIGASHIKANDA CHIYODA-KU,TOKYO,JAPAN
101-0031

MADE IN CHINA

13

Remote Control (continued)

Remote Control (continued)

Operating The Remote Control

CAUTION • Do not disassemble the remote control.

• Do not place the remote control near the projector’s lens, fan, or vents.

• Do not drop or otherwise expose the remote control to physical impact.

•

Do not get the remote control wet or place it on wet objects on it. Doing so may result in malfunction.

• Remove the batteries from the remote control and store them in a safe place if you
won't be using the remote control for an extended period.

• Replace the batteries whenever the remote control starts to malfunction.

•

When strong light, such as direct sunlight or light from an extremely close range (such as from an
inverter fluorescent lamp), hits the projector's remote sensor, the remote control may cease to function.
Adjust the direction of the projector to keep light from directly hitting the projector's remote sensor.

NOTE

•

The remote control works with the
projector’s remote sensor.

•

Front remote sensor is 3 meters with a 60
degree range (30 degrees to the left and
right of a remote sensor).
Rear remote sensor is 3 meters with a 40
degree range (20 degrees to the left and
right of a remote sensor).

•

Also a remote signal reflected in the screen etc.
may be available. If it is difficult to send a remote signal to the sensor directly, please try.

•

Since the remote control uses infrared light to send signals to the projector (Class1 LED), be sure to use the
remote control in an area free from obstacles that could block the remote control’s output signal to the projector.

memo

You can use the remote control as a wired remote control, by connecting the REMOTE CONTROL

ports of the main unit and remote control via an audio cable (3.5 dia. stereo mini cable with plugs).

Set the ID number to the projector beforehand,
referring to the item “IR REMOTE ID” of the section
“OPTION Menu”.

memo

When the ALL is selected to the item “IR
REMOTE ID” of the OPTION menu, the projector is
controlled by a remote control irrespective of the
position of the ID CHANGE switch.

Slide the knob of the switch into the position of the
ID number of the projector you want to control.

Using The Remote ID Feature

This is the function to properly use when you use two or
three same type projectors at the same time. This function
should be used combining a setup of a projector.

ID CHANGE
switch

I

N

T

E

R

I

N

P

U

T

M

1

-

D

R

G

B

B

N

G

S

-V

I

D

E

O

S

T

A

N

D

B

Y

/

O

N

T

E

M

P

V

I

D

E

O

C

O

M

P

O

N

E

N

T

L

A

M

P

K

E

Y

S

T

O

N

E

S

E

A

R

C

H

R

E

S

E

T

M

E

N

U

F

O

C

U

S

L

E

N

S

S

H

IF

T

Z

O

O

M

INT

ER

I
NPUT

M

1

-

D
R
G
B

B

N
G

S

-V
I

D
E
O

S
T
A
N

D
B

Y
/
O

N

T
E

M
P

V

I
D
E
O

C
O

M
P

O
N
E

N
T

L

A
M

P

K
E

Y
S

T
O

N
E
S
E

A
R

C
H

R
E

S
E

T
M
E

N
U

F
O

C
U
S

L
E
N
S

S

H
I
F

T

Z
O

O
M

V
I
D

E
O

R

­A
U
D

I
O

I
N

­L

S

­V

I
D
E

O
B
N

C

R

G
B

A
U
D

I
O
I
N

1

A
U
D

I
O
I
N

2

R
G

B
O

U
T

A
U
D

IO
O

U
T

R
E

M
O

T
E

C
O
N

T
R

O
L

R

/
C

R

/
P

R

G

/
Y

B
/
C

B

/
P

B

H

V

Y

C

O
N

T
RO

L

N

E

T

W
O
R

K

C

R
/

P
R

C

a
/
P
a

approximately
3 meters

30 degrees

30 degrees

approximately
3 meters

20 degrees

20 degrees

1

2

LASER INDICATOR

STANDBY/ON

VIDEO

+

++

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

BLANK

PREVIOUS

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

ON

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

RGB

LASER

NEXT

VOLUME

SEARCH

14

Remote Control (continued)

Remote Control (continued)

Using The Mouse/Keyboard Control Function

CAUTION • Before connecting, read the manuals of the device you will connect.

Mistaken use of the mouse/keyboard control could damage your equipment.

• Only connect to a PC or an USB Hub connected PC.

• Do not unplug the connector cables while the computer is operating.

Using the USB control feature, you can use the remote control as a simplified mouse or
keyboard of the computer.

Connect the M1-D port of the projector to the computer via the M1-D cable. Then
functions illustrated below will be enabled.

memo

The USB control can be used with
Windows 95 OSR 2.1 or higher. It may not be
possible to use the remote control, depending
on the computer’s configurations and mouse
drivers.

memo

The function can be used only for the

functions illustrated on the right.

memo

The projector would be enumerated as a
mouse and a keyboard of HID (Human
Interface Device) class devices, after
connecting cable.

Mouse move pointer

Keyboard

Arrow keys / / /

Mouse right button

Keyboard ESC key

(Front)

(Rear)

Mouse left button

LASER INDICATOR

STANDBY/ON

VIDEO

+

++

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

BLANK

PREVIOUS

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

ON

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

RGB

LASER

NEXT

VOLUME

SEARCH

STANDBY/ON

VIDEO

LASER INDICATOR

RGB

LENS SHIFT

+

–––

++

FOCUS ZOOM

I

N
T
E
R

I
NP
U

T

M1-D
R
GB

B
N
G

S

-V
I
D

EO

ST

A
N

DB

Y
/
O
N

T

E
M
P

V
IDEO

C

O
M
P

O
N
E
N

T

L
A
MP

K

E
Y
S

T
O
N

E

S

EA
R
C

H

R

E
S
E

T
M
E
N

U

F

O
C

US

LE
N
S

SHI
FT

Z
O

O
M

V
I
D
E

O

R

­A

U
D
I

O
I
N

­L

S-V
ID

E
O

BNC

R
G

B

A
U
D

I
O
I
N1

A
U

D
I
O
I
N2

RGB O

U

T

A
U

D
IO

O
UT

REMOTE

CON

TROL

R/C

R

/P

R

G/Y

B
/

C

B

/

P

B

H

V

Y

CONTROL

N

ETWOR

K

CR/PR

Ca/Pa

I

N
T
E
R

I
NP
U

T

M1

­D

R

GB
B
N

G

S

­V
I
D

EO

S

T
A
N

DB

Y
/
O
N

T

E
M
P

V
I

DEO

C

O
MP

O
N
E
N

T

L
A
M

P

K

EY
ST

O
N

E

SE

A
R
CH

R

E
SE

T
M
E
N

U

F

O
C

U
S

L

E
N
S

S
HI
F

T

Z
O

O
M

V
ID
E

O

R

­A

U
D
I

O
I
N

­L

S­V
ID

E
O

BNC

RGB

A
U
D

I
O
I
N1

A
U

D
I
O
I
N

2

R
GB O

U

T

A
U

D
IO

O
U
T

REMOTE

CONTR

OL

R
/C

R

/P

R

G/Y

B
/

C

B

/P

B

H

V

Y

C
ONTRO

L

NETWO

RK

CR/

PR

Ca/P

a

STANDBY/ON

VIDEO

LASER INDICATOR

RGB

LENS SHIFT

+

–––

++

FOCUS ZOOM

I

N
T
E
R

INP
U

T

M
1

­D

R

GB
B
N

G

S

­V
I
D

E
O

S

T
A
ND

B

Y
/
O
N

T

E
M
P

V
ID

EO

C

O
M
P

O
N
E
N

T

LA
MP

K

E
YS

T
ON

E

SE

A
R
CH

R

E
S
E

T
M
E
N

U

F

O
CU

S

LE

N
S

SHI
FT

ZO

O
M

V
ID
E

O

R

­A

U
D
I

O
I
N

­L

S­V
ID

E
O

BNC

RGB

A
U
D

IO
I
N1

A
U

D
I
O
I
N

2

RGB O

UT

A
U

D
IO

O
U
T

REMOTE

CON

T
R

O
L

R
/C

R

/
P

R

G/Y

B
/

C

B

/P

B

H

V

Y

CONTROL

NETWOR

K

CR/PR

Ca/P

a

15

Tur ning On The Power

WARNING • When the power is ON, a strong light is emitted. Do not look
into the lens or vents of the projector.

• Turn the power on/off in right order. Please power on the projector before

the connected devices. Power off the projector after the connected devices.

NOTE

Power ON/OFF

Power ON/OFF

Remove the lens cap.

2

Set the power switch to [ | ] (ON).
The STANDBY/ON indicator will light to solid orange.

STANDBY/ON button / indicator

LENS SHIFT

buttons

Power switch (ON position)

STANDBY/ON

button

3

Press the STANDBY/ON button.
The projector lamp will light up and the
STANDBY/ON indicator will begin blinking green.
When the power is completely on, the indicator
will stop blinking and light green.

4

Use the LENS SHIFT buttons to shift the
picture upward or downward.

5

Select an input signal according to the
section “Selecting An Input Signal” of the
following page.

Power switch (OFF position)

1

Press the STANDBY/ON button.
The message “Power off?” will appear on
the screen for approximately 5 seconds.

Attached the lens cap.

2

Press the STANDBY/ON button again while
“Power off?” the message is visible.
The projector lamp will go off, and the
STANDBY/ON indicator will begin blanking orange.
Then the STANDBY/ON indicator will stop blinking
and light to solid orange when the lamp cooling is
complete.

3

Switch the power switch to [O] (OFF).
The STANDBY/ON indicator will go off.

STANDBY/ON

button

STANDBY/ON button / indicator

Tur ning Off The Power

STANDBY/ON

VIDEO

LASER INDICATOR

RGB

BLANK ASPECT LASER

LENS SHIFT

+

–––

++

FOCUS ZOOM

1

4

STANDBY/ON

STANDBY/ON

STANDBY/ON

STANDBY/ON

I

N
T
E
R

I
N
P
U

T

M
1

­D

R
G

B
B
N

G

S

­V
I
D

E
O

ST

A
NDB

Y
/
O
N

T

E
M
P

V
I

D
EO

C

O
MP

O
N
E
N

T

LA
M

P

K

EY
S

T
O
N

E

S

E
A
R
C

H

R

E
SE

T
ME
N

U

F

O
C

U
S

L

E
N
S

S
H
IF

T

ZO

O
M

V
ID
E

O

R

­A

U
D
I

O
I
N

­L

S

-V
ID

E
O

BNC

RGB

A
U
D

IO
I
N

1

A
U

D
I
O
I
N2

R
GB O

UT

A
U

D
IO

O
U
T

REMOTE

CON

T
R

OL

R
/C

R

/
P

R

G/Y

B
/

C

B

/P

B

H

V

Y

C
ONTROL

NETWOR

K

C

R
/
PR

Ca
/

Pa

16

Operating

Operating

Selecting An Input Signal

Select an input signal.

Turn the INPUT dial of the projector.
Turning the dial cycles through the input ports as
shown below. Select the signal you wish to project.

T

T

■ Using the INPUT dial

Press the SEARCH button of the projector or the
remote control.
Pressing the button automatically cycles through input
ports and displays the picture of retrieved signal.

memo

If no signal is found or the projector is unstable to
find an input signal at any of its ports, it will turn to the state
it was in prior to the search.

■ Using SEARCH button

Press the RGB button of the remote control.
Pressing the button toggles between the RGB ports
as shown below Select the signal you wish to project.

Press the VIDEO button of the remote control.
Pressing the button toggles between the VIDEO ports
as shown below Select the signal you wish to project.

C

VIDEO button

RGB button

SEARCH button

ZOOM

buttons

FOCUS
buttons

Use the FOCUS buttons to adjust the focus.

Use the ZOOM buttons to adjust the screen size.

■ Using RGB button

■ Using VIDEO button

2

3

1

INPUT dial

SEARCH button

M1-D RGB BNC

VIDEO

S-VIDEO COMPONEN

STANDBY/ON

M1-D RGB BNC

VIDEO

S-VIDEO COMPONEN

LENS SHIFT

M1-D RGB BN

LASER INDICATOR

VIDEO

+

++

FOCUS ZOOM

–––

ASPECT

BLANK

LASER

PREVIOUS

NEXT

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

VOLUME

ON

FREEZE MUTE

OFF

KEYSTONE

SEARCH

1 2 3

ID CHANGE

RGB

S-VIDEO VIDEOCOMPONENT

K
E
Y

S
T
O

N

E
LE
N

M1-D
S
SHI

FT

R
GB

S

I

EAR

NP
U
T

C
H

B

N

G
C
O

MP
ON

E

N
T

R
E
S
E

T

I
N

S

T

-V
E
R

I
D

F
O

E
O

CUS

Z

O
O

M

VIDEO

M

E
N

U

ST

A
N

DB

Y
/
O
N

T

E
M
P

L
A

M
P

A

U
D
I
O

I
N
1

REMOTE

CO

N

CONT

T
ROL

R

OL

N

ET
WORK

A

U
D
I
O

I
N

2

RGB

A
U

D
I
O

O

R

UT

GB O

U
T

CR/PR

Ca/P

a

Y

R/C

R

/
P

R

G/Y

B
/
C

B

/P

B

H

V

R

­A

U
D
I
O

I
N

­L
V
ID

E
O

S­V

I
D
E

O

BNC

17

Operating (continued)

Operating (continued)

The Vertical position, the horizontal position, the clock
phase and horizontal size will be automatically adjusted.
And the aspect ratio will be automatically selected.

memo

Make sure that the application window is set to its maximum
size prior to attempting to use this feature. Dark pictures may still
be incorrectly adjusted. Use a bright screen when adjusting.

The signal type mode best suited for the respective input
signal will be selected automatically.

This function is available only when the AUTO is selected to the
item VIDEO of the INPUT menu. For a component video signal, the
signal type is identified automatically independently of this function.

Selecting The Aspect Ratio

Press the Aspect button to toggle between the modes for
aspect ratio.

ASPECT
button

AUTO
button

4:3

16:9

NORMAL REAL

Using The Automatic Adjustment Feature

Press the AUTO button.

memo

NORMAL keeps the original aspect ratio of the input signal.

memo

For a HDTV signal of 1125i(1080i) or 750p(720p), only 16:9 and REAL can be

selected. REAL cannot be selected when there is no input signal.

memo The automatic adjustment operation requires approximately 10 seconds. Also,

please note that it may not function correctly with some input.

4:3

16:9

SMALL

REAL

■ For an RGB signal

■ For a video signal / no signal

■ For an RGB signal

■ For a video signal or s-video signal

1

1

The vertical position and horizontal position will be automatically adjusted.

■ For a video signal, s-video signal or component video signal

The aspect ratio will be automatically selected.
The clock phase will be automatically adjusted.

■ For a component video signal

LASER INDICATOR

STANDBY/ON

VIDEO

+

++

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

BLANK

PREVIOUS

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

ON

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

LASER

NEXT

VOLUME

SEARCH

RGB

LASER INDICATOR

STANDBY/ON

VIDEO

+

++

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

BLANK

PREVIOUS

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

ON

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

RGB

LASER

NEXT

VOLUME

SEARCH

18

Operating (continued)

Operating (continued)

Adjusting The Picture Position

Press the POSITION button.
As illustrated on the right, a
dialog will appear on the
screen to aid you in adjusting
the position.

POSITION
button

Cursor
buttons

RESET
button

KEYSTONE
button

2

1

Use the cursor buttons / / / to adjust the
position.

memo

When you want to initialize the position, press
the RESET button during adjustment.

3

1

Press the POSITION button again to close the
dialog and complete this operation.

memo

Even if you don't do anything, the dialog will
automatically disappear after a few seconds.

2

Use the cursor buttons / to
select the direction of distortion to
correct ( or ).

4

Press the KEYSTONE button again to close the
dialog and complete this operation.

memo

Even if you don't do anything, the dialog will
automatically disappear after a few seconds.

memo When this adjustment is excessive, certain

degradation may appear on the picture. Also,
please note that it may not function correctly with
some input.

3

Use the cursor buttons / to correct the
distortion.

Correcting The Keystone Distortion

Press the KEYSTONE button.
As illustrated on the right, a dialog
will appear on the screen to aid you
in correcting the keystone
distortion.

memo This function is not available for M1-D signals.

Cursor
buttons

POSITION

KEYSTONE

+

0

+

0

LASER INDICATOR

STANDBY/ON

VIDEO

+

++

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

BLANK

PREVIOUS

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

ON

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

LASER INDICATOR

STANDBY/ON

VIDEO

+

++

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

BLANK

PREVIOUS

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

ON

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

LASER

NEXT

VOLUME

SEARCH

LASER

NEXT

VOLUME

SEARCH

RGB

RGB

19

Operating (continued)

Operating (continued)

Adjusting The Volume

Muting The Sound

Temporarily Blanking The Screen

Press the VOLUME button.
As illustrated on the right, a dialog
will appear on the screen to aid you
in adjusting the volume.

Use the cursor buttons / to
adjust the volume.

Press the VOLUME button again to close the
dialog and complete this operation.

memo

Even if you don't do anything, the dialog will

automatically disappear after a few seconds.

Press the MUTE button.
As illustrated on the right, a dialog
will appear on the screen indicating
that you have muted the sound.

Press the MUTE or VOLUME
button to restore the sound.

memo

Even if you don't do anything,
the dialog will automatically
disappear after a few seconds.

Press the BLANK button.
The input signal screen will shut off, and a BLANK
screen will appear.

memo You can set the BLANK screen using the

menu. Please refer to the item “BLANK” of the
table of the section “SCREEN Menu”.

Press the BLANK button again to remove the
blank screen, and return to the input signal screen.

Cursor
buttons

VOLUME
button

MUTE
button

BLANK
button

1

2

3

1

2

1

2

VOLUME

16

VOLUME

16

LASER INDICATOR

STANDBY/ON

VIDEO

+

++

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

BLANK

PREVIOUS

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

ON

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

LASER INDICATOR

STANDBY/ON

VIDEO

+

++

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

BLANK

PREVIOUS

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

ON

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

LASER

NEXT

VOLUME

SEARCH

LASER

NEXT

VOLUME

SEARCH

RGB

RGB

LASER INDICATOR

STANDBY/ON

VIDEO

+

++

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

BLANK

PREVIOUS

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

ON

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

LASER

NEXT

VOLUME

SEARCH

RGB

20

Operating (continued)

Operating (continued)

Freezing The Screen

Press the FREEZE button.
As illustrated on the right, a
dialog will appear on the
screen, and the screen will
freeze at the current image.

Press the FREEZE button again to restore the
screen to normal.
The icon “||” will change to the icon “ ”. And after
a couple of seconds, the dialog will be closed and
the screen will be restored to normal.

memo

The freezing feature will automatically finish if a remote control’s

button that changes some display state (ex. blanking the screen,
displaying a dialog or a menu, adjusting the picture, changing the input
signal) is pressed, or a button of projector is pressed.

•

If the projector continues projecting the same image for a long time (i.e. you forget to exit FREEZE mode),

the image might possibly remain as an afterimage. Do not leave the projector in FREEZE mode for too long.

NOTE

Using The Magnify Feature

Press the MAGNIFY
button.
As illustrated on the right, a dialog
will appear on the screen to aid
you in magnifying the picture.

Press the POSITION button, then use the cursor
buttons / / / to select the area to zoom.

Press the POSITION button again to finalize the
zoom area.

Use the cursor buttons / to adjust the zoom
level.

Press the MAGNIFY button again to close the
dialog and complete this operation.

memo

The magnify feature will automatically finish if the

automatic adjustment is execute, or the aspect, the signal
type mode of video or the signal input state is changed.

FREEZE
button

POSITION
button

Cursor
buttons

MAGNIFY
buttons

1

2

1

2

3

4

5

FREEZE

LASER INDICATOR

STANDBY/ON

VIDEO

+

++

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

BLANK

PREVIOUS

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

ON

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

LASER

NEXT

VOLUME

SEARCH

RGB

ON

MAGNIFY

LASER INDICATOR

STANDBY/ON

VIDEO

+

++

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

BLANK

PREVIOUS

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

ON

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

LASER

NEXT

VOLUME

SEARCH

RGB

OFF

21

Operating (continued)

Operating (continued)

Displaying The Child Window

Press the PinP button.
The child window with a picture of a video signal
will appear.

Press the PinP button again to change the size of
the child window or close the window.

memo

You can select the video signal to display in the
child window, and the position of the child window.
Please refer to the items “P.INP. INPUT” and “P.INP.
POSIT.” of the table of the section “INPUT Menu”.

Selecting An Audio Input

When the child window is on the
screen, press the VOLUME button.
As illustrated on the right, a dialog
will appear on the screen.

Press the VOLUME button again to close the
dialog and complete this operation.

memo

Even if you don’t do anything, the dialog will
automatically disappear after a few seconds.

memo

You also can adjust the volume using the cursor
buttons

/

. Please refer to the section “Adjusting

The Volume”.

Use the cursor buttons / to
select an audio input.

PinP button

Cursor
buttons

VOLUME
button

memo

This feature is available only when the child window is on the screen.

memo

This feature called "PinP (Picture in Picture)" is available only when a RGB signal is selected

to main screen. And this feature does not work when UXGA (1600 x 1200) or higher signal is input.

1

2

1

2

3

Small child window Large child window

No child window

LASER INDICATOR

STANDBY/ON

VIDEO

+

++

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

BLANK

PREVIOUS

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

ON

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

RGB

LASER

NEXT

VOLUME

SEARCH

RGB (Audio input for the main screen)

Video (Audio input for the child window)

VOLUME

RGB Video

16

LASER INDICATOR

STANDBY/ON

VIDEO

+

++

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

BLANK

PREVIOUS

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

ON

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

LASER

NEXT

VOLUME

SEARCH

RGB

22

Multifunctional Settings

Multifunctional Settings

Using The Menu Functions

This projector has the following menus: MAIN, PICTURE-1, PICTURE-2, INPUT, AUTO,
SCREEN, OPTION and NETWORK. Each of these menus is operated using the same
methods. The basic operations of these menus are as follows.

Press the MENU button.
The menu will appear on
the screen.

Use the cursor buttons

/ to select a menu,
then press the (or the
ENTER) button to
progress.
The display of the
selected menu will
appear.

Use the cursor buttons

/ to select an item,
then press the (or the
ENTER) button to
progress.
The operation display of
the selected item will
appear.

Use the cursor buttons / to operate the item.

memo

When you want to reset the adjustment,
press the RESET button during the operation. Note
that the items whose functions are performed
simultaneously with operating (ex. LANGUAGE,
WHISPER, H PHASE etc.) are not reset.

memo

When you want to return to the previous
display, press the or ESC button.

Press the MENU button again to close the menu
display and complete this operation.

memo

Even if you don’t do anything, the menu will
automatically disappear after a few seconds.

3) Select the “SPEAKER”
using the button, then
press the button.

4) Use the cursor button
to select the “TURN OFF”.

5) Press the MENU button.

2) Select the “OPTION”
using the button, then
press the button.

ex. Turning off the built-in speaker

1) Press the MENU button.

MENU
button

Cursor
buttons

ESC button

RESET
button

ENTER
button

: SELECT

MENU
MAIN
PICTURE-1
PICTURE-2
INPUT
AUTO
SCREEN
OPTION
NETWORK

VOLUME
SPEAKER
IR REMOTE
IR REMOTE ID
LAMP TIME
FILTER TIME
SERVICE
RESET

16
TURN ON

ALL
1234 h
4321 h

: SELECT

MENU
MAIN
PICTURE-1
PICTURE-2
INPUT
AUTO
SCREEN
OPTION
NETWORK

VOLUME
SPEAKER
IR REMOTE
IR REMOTE ID
LAMP TIME
FILTER TIME
SERVICE
RESET

16
TURN ON

ALL
1234 h
4321 h

1

2

3

4

5

LASER INDICATOR

STANDBY/ON

VIDEO

+

++

LENS SHIFT

FOCUS ZOOM

–––

ASPECT

BLANK

PREVIOUS

MOUSE

ESC MENU

POSITION

RESET AUTO

MAGNFY

PinP

ON

FREEZE MUTE

OFF

KEYSTONE

1 2 3

ID CHANGE

RGB

LASER

NEXT

VOLUME

SEARCH

MENU
MAIN
PICTURE-1
PICTURE-2
INPUT
AUTO
SCREEN
OPTION
NETWORK

: SELECT

MENU
MAIN

VOLUME

PICTURE-1

SPEAKER

PICTURE-2

IR REMOTE

INPUT

IR REMOTE ID

AUTO

LAMP TIME

SCREEN

FILTER TIME

OPTION

SERVICE

NETWORK

RESET

: SELECT

BRIGHT
CONTRAST
ASPECT
WHISPER
MIRROR
LANGUAGE
[Language]
RESET

OPTION
SPEAKER
TURN ON
TURN OFF

16
TURN ON

ALL
1234 h
4321 h

+0
+0
4:3
NORMAL
NORMAL
ENGLISH

OPTION
SPEAKER
TURN ON
TURN OFF

Item Description

BRIGHT

Adjust the brightness using the / buttons. : Light  Dark

CONTRAST

Adjust the contrast using the / buttons. : Strong  Weak

ASPECT

Select an aspect ratio using the / buttons. :

■ For an RGB signal
NORMAL  4:3  16:9  REAL

The NORMAL keeps the original aspect ratio of the input signal.

■ For a video signal / no signal
4:3  16:9  SMALL  REAL

memo For a HDTV signal of 1125i(1080i) or 750p(720p), only the 16:9 and

REAL can be selected. REAL cannot be selected when there is no input signal.

WHISPER

Select the NORMAL or the WHISPER using the / buttons. :

NORMAL  WHISPER

When the WHISPER is selected, acoustic noise and screen brightness are
reduced.

MIRROR

Select a mirror status using the / buttons. :

NORMAL  H:INVERT  V:INVERT  H&V:INVERT

ex.

LANGUAGE

Select a menu language using the / buttons. :

RESET

Select the EXECUTE using the button to reset the MAIN menu items. :

EXECUTE  CANCEL

The items of the MAIN menu are collectively returned to the initial setting. Note
that the items “WHISPER” and “LANGUAGE” are not reset.

23

Multifunctional Settings (continued)

Multifunctional Settings (continued)

MAIN Menu

With the MAIN menu, the items shown in the table below can be
performed. Perform each operation in accordance with the
instructions in the table below.

: SELECT

MENU
MAIN
PICTURE-1
PICTURE-2
INPUT
AUTO
SCREEN
OPTION
NETWORK

BRIGHT
CONTRAST
ASPECT
WHISPER
MIRROR
LANGUAGE
[Language]
RESET

+0
+0
4:3
NORMAL
NORMAL
ENGLISH

ENGLISH ó FRANÇAIS ó DEUTSCH ó ESPAÑOL ó ITALIANOó NORSK

NEDERLANDS ó PORTUGUÊS ó 日本語 ó    ó

ó SVENSKA ó ó SUOMI ó POLSKI ó TÜRKÇE

24

PICTURE-1 Menu

With the PICTURE-1 menu, the items shown in the table below can
be performed. Perform each operation in accordance with the
instructions in the table below.

: SELECT

MENU
MAIN
PICTURE-1
PICTURE-2
INPUT
AUTO
SCREEN
OPTION
NETWORK

GAMMA
COLOR BAL R
COLOR BAL G
COLOR BAL B
SHARPNESS
COLOR
TINT
MY MEMORY

NORMAL
+0
+0
+0
+0
+0
+0
LOAD1

Multifunctional Settings (continued)

Multifunctional Settings (continued)

Item Description

GAMMA

Select a gamma mode using the / buttons. :

NORMAL  CINEMA  DYNAMIC  CUSTOM

Selecting the CUSTOM and then pressing the (or the ENTER) button calls
the CUSTOM menu.

CUSTOM Menu

Select an item using the / buttons, and press the

(or the ENTER) button to perform each function.

GAMMA  COLOR TEMP  R  G  B

memo The R, G and B can be selected only when the

USER is selected under the COLOR TEMP.

GAMMA

Adjust the gamma data using the / buttons. :

Up  Down

COLOR TEMP

Select a color temperature using the / buttons. :

HIGH  MIDDLE  LOW  USER

R

Adjust the red color level for the USER mode of the COLOR
TEMP using the / buttons. : Strong  Weak

G

Adjust the green color level for the USER mode of the COLOR
TEMP using the / buttons. : Strong  Weak

B

Adjust the blue color level for the USER mode of the COLOR
TEMP using the / buttons. : Strong  Weak

COLOR BAL R

Adjust the red color balance using the / buttons. :

Strong  Weak

COLOR BAL G

Adjust the green color balance using the / buttons. :

Strong  Weak

COLOR BAL B

Adjust the blue color balance using the / buttons. :

Strong  Weak

SHARPNESS

Adjust the sharpness using the / buttons. :

Clear  Soft

COLOR

Adjust the whole color using the / buttons. :

Strong  Weak

memo This item can be selected only at a video signal.

TINT

Adjust the tint using the / buttons. :

Green  Red

memo This item can be selected only at a video signal.

(This table is continued to the following page.)

GAMMA

NORMAL
CINEMA
DYNAMIC
CUSTOM

: SELECT

GAMMA
COLOR TEMP
R
G
B

2.2
HIGH
100
100
100

25

Multifunctional Settings (continued)

Multifunctional Settings (continued)

Item Description

MY MEMORY

Select a command to load or save using the / buttons, and then press
the (or the ENTER) button to perform the function.:

This projector has 4 numbered memories for adjustment data.
Performing the SAVE1, SAVE2, SAVE3 or SAVE4 puts the current adjustment
data on the memory whose number corresponds with the command’s number.
The current adjustment data of the items BRIGHT and CONTRAST in the MAIN
menu and the items in the PICTURE-1 menu is stored.
Performing the LOAD1, LOAD2, LOAD3 or LOAD4 loads the data on the
memory whose number corresponds with the command’s number, and adjusts
the picture automatically depending on the data.

RESET

Select the EXECUTE using the button to reset the PICTURE-1 menu items. :

EXECUTE  CANCEL

The items of the PICTURE-1 menu are collectively returned to the initial setting.
Note that the items “MY MEMORY” and “GAMMA” of the CUSTOM menu under
the item “GAMMA” are not reset.

PICTURE-1 Menu (continued)

LOAD1  LOAD2  LOAD3  LOAD4

SAVE1  SAVE2  SAVE3  SAVE4

26

Multifunctional Settings (continued)

Multifunctional Settings (continued)

PICTURE-2 Menu

With the PICTURE-2 menu, the items shown in the table below can
be performed. Perform each operation in accordance with the
instructions in the table below.

memo This menu cannot be selected at a M1-D signal.

: SELECT

MENU
MAIN
PICTURE-1
PICTURE-2
INPUT
AUTO
SCREEN
OPTION
NETWORK

V POSITION
H POSITION
H PHASE
H SIZE
OVER SCAN
RESET

20
142
31
1344
5

Item Description

V POSITION

Adjust the vertical position using the / buttons. :

Up  Down

memo This item cannot be selected for a M1-D signal.

H POSITION

Adjust the horizontal position using the / buttons. :

Left  Right

memo This item cannot be selected for a M1-D signal.

H PHASE

Adjust the horizontal phase to eliminate flicker using the / buttons. :

Right  Left

memo This item can be selected only at a RGB signal or a component video

signal other than a COMPONENT port input of 525i(480i)/625i(576i)/SCART
RGB.

H SIZE

Adjust the horizontal size using the / buttons. :

Large  Small

memo This item can be selected only at a RGB signal.
memo When this adjustment is excessive, the picture may not be displayed

correctly. In such a case, please reset the adjustment pressing the RESET
button during this operation.

OVER SCAN

Adjust the over-scan ratio using the / buttons. :

Small  Large

memo This item can be selected only at a video signal.
memo When this adjustment is too large, certain degradation may appear at

the frame area of the picture. In such a case, please adjust small.

RESET

Select the EXECUTE using the button to reset the PICTURE-2 menu items. :

EXECUTE  CANCEL
The items of the PICTURE-2 menu are collectively returned to the initial setting.
Note that the item “H PHASE” is not reset.

27

Multifunctional Settings (continued)

Multifunctional Settings (continued)

INPUT Menu

With the INPUT menu, the items shown in the table below can be
performed. Perform each operation in accordance with the
instructions in the table below.

: SELECT

MENU
MAIN
PICTURE-1
PICTURE-2
INPUT
AUTO
SCREEN
OPTION
NETWORK

COLOR SPACE
COMPONENT
VIDEO
3D-YCS
VIDEO NR
P. INP. INPUT
P. INP. POSIT.
POWERUP INPUT

AUTO
COMPONENT
AUTO
TURN OFF
LOW
VIDEO

RGB

Item Description

COLOR SPACE

Select a color space mode using the / buttons. :

AUTO  RGB  SMPTE240  REC709  REC601

Selecting the AUTO automatically selects the optimum mode.

memo This item can be selected only at a RGB signal or a component video

signal other than a COMPONENT port input of 525i(480i)/625i(576i)/SCART
RGB.

memo The AUTO operation may not work well at some signals. In such a case,

select a suitable mode except the AUTO.

COMPONENT

Select a function of COMPONENT port using the / buttons. :

COMPONENT  SCART RGB
When the SCART RGB is selected, the COMPONENT port function as a port for
a SCART RGB signal input. Please refer to the section “Connecting Your
Devices”.

VIDEO

Select a signal type mode using the / buttons. :

AUTO  NTSC  PAL  SECAM  NTSC4.43  M-PAL  N-PAL
Selecting the AUTO automatically selects the optimum mode.

memo This item is performs only at a video signal from the VIDEO port or the S-

VIDEO port. For a component video signal, the signal type is identified
automatically independently of this function.

memo The AUTO operation may not work well at some signals. If the picture

becomes unstable (ex. a irregular picture, a color lack), please select the mode
depending on the input signal.

3D-YCS

Select the TURN ON or the TURN OFF using the / buttons. :

TURN ON  TURN OFF
When the TURN ON is selected, the 3D-YCS mode works for a completely still
image, or images with few motions.

memo This item performs only at a video signal of NTSC3.58.
memo When this function performs, the setting of the item “VIDEO NR” of this

INPUT menu is not effective.

VIDEO NR

Select a noise reduction level using the / buttons. :

HIGH  MIDDLE  LOW
The noise on screen is reduced according to the selected level.

memo This item performs only at a video signal from the VIDEO port or the S-

VIDEO port. At a video signal of NTSC3.58, this function performs only when
the TURN OFF is selected to the item “3D-YSC” of this INPUT menu.

memo When this adjustment is excessive, certain degradation may appear on

the picture.

(This table is continued to the following page.)

28

Multifunctional Settings (continued)

Multifunctional Settings (continued)

INPUT Menu (continued)

Item Description

P.IN P. INPUT

Select a signal input port for the child window using the / buttons. :

VIDEO  S-VIDEO

memo About the child window, please refer to the section “Displaying the Child

Window”.

P.IN P. POSIT.

Select the display position of the child window using the / buttons. :



memo About the child window, please refer to the section “Displaying the Child

Window”.

POWERUP

INPUT

Select a signal input port to display just when the projector is turned on, using
the / buttons. :

LAST INPUT  M1-D  RGB  BNC  COMPONENT  S-VIDEO  VIDEO

Selecting the LAST INPUT selects the port that was used at the last time.

INFORMATION

Pressing the (or the ENTER) button displays the INPUT INFORMATION
menu.
The INPUT INFORMATION menu shows the information about the current
signal input as illustrated below.

memo The “FRAME LOCK” message means the frame lock function is working.

This function automatically works when a RGB signal with vertical frequency of
50 to 60 is input, and it displays a moving picture more smoothly.

memo The “SCART RGB” message means the COMPONENT port is working

as a SCART RGB port. Please refer to the item “COMPONENT” in this table.

RESET

Select the EXECUTE using the button to reset the INPUT menu items. :

EXECUTE  CANCEL

The items of the INPUT menu are collectively returned to the initial setting. Note
that the item “INFORMATION” is not reset.

INPUT-INFORMATION

COMPONENT

576i @50

SCART RGB

INPUT-INFORMATION

RGB

1024x768 @60.0

FRAME LOCK

INPUT-INFORMATION

S-VIDEO

SECAM

AUTO

29

Multifunctional Settings (continued)

Multifunctional Settings (continued)

AUTO Menu

With the AUTO menu, the items shown in the table below can be
performed. Perform each operation in accordance with the
instructions in the table below.

Item Description

ADJUST

Pressing the (or the ENTER) button performs the automatic adjustment.

■ For an RGB signal

The vertical position (V POSITION), the horizontal position (H POSITION), the

clock phase (H PHASE) and the horizontal size (H SIZE) will be automatically

adjusted. And the aspect ratio (ASPECT) will be automatically selected.

Make sure that the application window is set to its maximum size prior to

attempting to use this feature. Dark pictures may still be incorrectly adjusted.

Use a bright screen when adjusting.

■ For a video signal or s-video signal

The signal type mode best suited for the respective input signal will be

selected automatically.

This function is available only when the AUTO is selected to the item

“VIDEO” of the INPUT menu. For a component video signal, the signal type is

identified automatically independently of this function.

■ For a video signal, s-video signal or component video signal

The vertical position and horizontal position will be automatically adjusted.

■ For a component video signal

The aspect ratio will be automatically selected.

The clock phase will be automatically adjusted.

memo This operation requires approximately 10 seconds, and the message

“AUTO IN PROGRESS” is displayed during the operation.

memo This operation may not work well at some signals. If the picture

becomes unstable (ex. a irregular picture, a color lack), please select the
suitable mode to the item “VIDEO” of the INPUT menu.

POWER OFF

Set the time using the / buttons. :

Long (max. 99 minutes)  Short (min. 0 minute = DISABLE)

ex.
When the time is set to 1 to 99, the projector lamp will go off and the
STANDBY/ON indicator begins blinking when the passed time with a proper
signal (without no-signal and an unsuitable signal) reaches at the set time.
Please refer to the section “Turning Off The Power”.

: SELECT

MENU
MAIN
PICTURE-1
PICTURE-2
INPUT
AUTO
SCREEN
OPTION
NETWORK

ADJUST
POWER OFF
SEARCH
RESET

0 min
TURN ON

(This table is continued to the following page.)

AUTO

POWER OFF

ENABLE

1min

POWER OFF

DISABLE

AUTO

0min

30

Multifunctional Settings (continued)

Multifunctional Settings (continued)

Item Description

SEARCH

Select the TURN ON or the TURN OFF using the / buttons. :

TURN ON  TURN OFF
When the TURN ON is selected, detecting no signal cycles through input ports
and displays the picture of retrieved signal.

memo When the TURN ON is selected, pressing the RGB button selects the

M1-D ports, and pressing the VIDEO button selects the COMPONENT port.

memo If no signal is found or the projector is unstable to find an input signal at

any of its ports, it will return to the state it was in prior to the search.

RESET

Select the EXECUTE using the button to reset the AUTO menu items. :

EXECUTE  CANCEL
The items of the AUTO menu are collectively returned to the initial setting. Note
that the item “ADJUST” is not reset.

AUTO Menu (continued)

M1-D RGB

VIDEO S-VIDEO

BNC

COMPONENT

31

Multifunctional Settings (continued)

Multifunctional Settings (continued)

SCREEN Menu

With the SCREEN menu, the items shown in the table below can be
performed. Perform each operation in accordance with the
instructions in the table below.

: SELECT

MENU
MAIN
PICTURE-1
PICTURE-2
INPUT
AUTO
SCREEN
OPTION
NETWORK

BLANK
START UP
MyScreen
MyScreen LOCK
MENU POSITION
MESSAGE
RESET

BLACK
ORIGINAL

TURN OFF

TURN ON

Item Description

BLANK

Select a type of the BLANK screen using the / buttons. :

MyScreen  ORIGINAL  BLUE  WHITE  BLACK

The BLANK screen is the screen, which is displayed by pressing the BLANK button.
The MyScreen is the screen you can register a desired screen, and the
ORIGINAL is the existing standard screen. The BLUE, the WHITE and the
BLACK are the non-pattered (plain) screens in each color.

memo To avoid remaining as an afterimage, the MyScreen and the ORIGINAL

screens will change to the BLACK screen after several minutes.

memo For the MyScreen, please refer to the item “MyScreen” in this table.

START UP

Select a type of the START UP screen using the / buttons. :

MyScreen  ORIGINAL  TURN OFF

The START UP screen is the screen, which is displayed by detecting no signal
or an unsuitable signal.
The MyScreen is the screen you can register a desired screen, and the
ORIGINAL is the existing standard screen. When the TURN OFF is selected,
the BLACK is used.

memo To avoid remaining as an afterimage, the MyScreen and the ORIGINAL

screens will change to the BLANK after several minutes. If also the BLANK
screen is the MyScreen or the ORIGINAL, it will change to the BLACK screen.

memo About the MyScreen, please refer to the item “MyScreen” in this table.

About the BLUE, BLACK and BLANK screens, please refer to the item “BLANK”
in this table.

MyScreen

Pressing the (or the ENTER) button starts the MyScreen registration. Please
see the flow chart on the following page.

MyScreen LOCK

Select the TURN ON or the TURN OFF using the / buttons.:

TURN ON  TURN OFF

The TURN ON disables the operation of the item “MyScreen” of this SCREEN
menu.

MENU POSITION

Adjust the menu position using the / / / buttons. :

Up



Left  +  Right



Down

memo To finish this operation, press the ESC button but not the button.

(This table is continued to the following page.)

32

Multifunctional Settings (continued)

Multifunctional Settings (continued)

Item Description

MESSAGE

Select the TURN ON or the TURN OFF using the / buttons. :

TURN ON  TURN OFF
When the TURN ON is selected, the following message function works.

The message of the “AUTO IN PROGRESS” for the auto adjustment.

The message of the “NO INPUT IS DETECTED”

The message of the “SYNC IS OUT OF RANGE”

The message of the “Searching …”

The message of the “Detecting …”

The indication of the input signal by input change.

The indication of the aspect ratio by changing the aspect ratio.

The indication of “FOCUS” by adjusting the focus.

The indication of “FREEZE” and “||” while freezing the screen by pressing the

FREEZE button.

memo When the TURN OFF is selected, please remember if the picture is

freezing. Do not mistake freezing for a malfunction.

RESET

Select the EXECUTE using the button to reset the SCREEN menu items. :

EXECUTE  CANCEL
The items of the SCREEN menu are collectively returned to the initial setting.

SCREEN Menu (continued)

How to register your picture as the MyScreen

MyScreen is pointed on the SCREEN menu.

The MyScreen

menu appears.

Do you capture the picture from

the current screen?

Registering.

It takes about 1 minute to register.

Just when the picture registration is completed

the registered screen and

the message of the right is displayed for a few seconds.

If the picture registration failed,

the message of the right is displayed for a few seconds.

The picture freeze and the frame for capturing appears.

Move the frame to the position of the picture

which you want to use, using / / / buttons,

and press the ENTER button to register.

NO: Press the ESC/RESET button

YES: Press the ENTER button

If the ESC/RESET
button is pressed ...

Press the button

:NO

ESC ENT

:YES

MyScreen

Do you start capturing this picture?

:RETURN

ESC

ENT

:NEXT

MyScreen
Move the capture area

as you want.

My Screen

45%

MyScreen registration is finished.

A capturing error has occurred.

Please try again.

Item Description

VOLUME

Adjust the volume using the / buttons. :

High  Low

SPEAKER

Select the TURN ON or the TURN OFF using the / buttons. :

TURN ON  TURN OFF

When the TURN ON is selected, the built-in speaker works.

IR REMOTE

Select a remote sensor using the / button (1), then switch
it using the ENTER button (2). :

(1) 1 : FRONT  2 : TOP  3 : REAR (2)  (Off) (On)

memo A sensor cannot be turned off when the other two are off.

Always at least one sensor is on.

IR REMOTE ID

Select a number as an ID number for remote control using the / buttons. :

ALL  1  2  3

The projector is controlled by the remote control whose ID CHANGE switch is
set into the position of the same number as this number. When the ALL is
selected, the projector is controlled by a remote control irrespective of the
position of the ID CHANGE switch.

memo Please refer to the section “Using The Remote ID Feature”.

LAMP TIME

Pressing the button or RESET button displays the LAMP TIME menu.
Select the RESET using button to reset the timer. :

RESET  CANCEL

Selecting the RESET resets the count of the lamp timer to 0.

memo Perform this function only when you have replaced the lamp. The lamp

timer counts the used time of the current lamp, to display the messages about
the lamp. Incorrect performing causes incorrect operation of the messages.

memo About replacing the lamp, please refer to the section” Lamp”.

FILTER TIME

Pressing the button or RESET button displays the FILTER TIME menu.
Select the RESET using button to reset the timer. :

RESET  CANCEL

Selecting the RESET resets the count of the filter timer to 0.

memo Perform this function only when you have cleaned or replaced the air

filter. The filter timer counts the used time of the air filter after cleaning or
replacement, to display the messages about the air filter. Incorrect performing
causes incorrect operation of the messages.

memo About caring for the air filter, please refer to the section “Air Filter”.

33

Multifunctional Settings (continued)

Multifunctional Settings (continued)

OPTION Menu

With the OPTION menu, the items shown in the table below can be
performed. Perform each operation in accordance with the
instructions in the table below.

: SELECT

MENU
MAIN
PICTURE-1
PICTURE-2
INPUT
AUTO
SCREEN
OPTION
NETWORK

VOLUME
SPEAKER
IR REMOTE
IR REMOTE ID
LAMP TIME
FILTER TIME
SERVICE
RESET

16
TURN ON
1: 2: 3:
ALL
1234 h
4321 h

(This table is continued to the following page.)

OPTION
IR REMOTE
1 : FRONT
2 : TOP
3 : REAR
ENT

34

Multifunctional Settings (continued)

Multifunctional Settings (continued)

OPTION Menu (continued)

Item Description

SERVICE

Pressing the (or the ENTER) button calls the SERVICE menu.

SERVICE Menu

Select an item using the / buttons, and press the (or the
ENTER) button to per form each function. :

FANSPEED  AUTO ADJUST  LENS TYPE  LENS LOCK  GHOST  FILTER MESSAGE

FANSPEED

Select the fan speed level using the / buttons. : HIGH  NORMAL
T

he HIGH ups rotation speeds of fans, though. Please use this

function in using a projector at highlands etc.

memo

Note that the projector is noisier when the HIGH is selected.

AUTO

ADJUST

Select the ENABLE or the DISABLE using the / buttons. :

ENABLE  DISABLE
When the ENABLE is selected, detecting a signal change to a RGB
signal performs the automatic adjustment of the vertical position (V
POSITION), the horizontal position (H POSITION), the clock phase
(H PHASE) and the horizontal size (H SIZE).
Depending on conditions, such as input image, signal cable to the unit,
environment around the unit, etc., the automatic adjustment may not
work correctly. In such a case, please choose DISABLE to disable the
automatic adjustment, and adjust manually.

LENS TYPE

Select the lens type currently used using the / buttons. :

AUTO  1  2  3  4  5
Please select depending on the following.
AUTO: automatically selects optimum mode.

1: for a standard lens (Type NL-500 etc.)

2: for a fixed short throw lens (Type FL-501 etc.)

3: for a short throw lens (Type SL-502 etc.)

4: for a long throw lens (Type LL-503 etc.)

5: for a super long throw lens (Type LL-504 etc.)

memo

This setting has an influence on the keystone distortion etc.

memo About the optional lens, ask your dealer.

LENS LOCK

Select the TURN ON or the TURN OFF using the / buttons. :

TURN ON  TURN OFF
Selecting the TURN ON locks the adjustment of the lens shift, the zoom and the focus.

GHOST

1. Choose a color element of ghost using the bottons / .

2. Adjust the chosen element using buttons / to disappear ghost.

FILTER

MESSAGE

Use the / button to set the timer for the interval to show the message for cleaning up the air filter.

100h200h300hTURN OFF50h
After selecting "50h", "100h", "200h" or "300h", the message “REMINDER …” will
appear after the timer reaches the interval time set by this operation. Please
refer to the "FILTER TIME" item and the table "Related message" .
When "TURN OFF" is chosen, the air filter cleaning message will not appear. Selecting "TURN
OFF" displays the message to call an attention to disabling the air filter cleaning message.

•

Please check and clean the air filter periodically, even if there is no message. If
the air filter becomes blocked by dust or others, the internal temperature will rise,
which could cause malfunction, or reduce the lifetime of the projector.

•

It is recommended to choose "100h" in general. Please be careful with the operating environment
of the projector and the condition of air filter, especially when "200h", "300h" or "TURN OFF" is chosen.

RESET

Select the EXECUTE using the button to reset the OPTION menu items. :

EXECUTE  CANCEL

The items of the OPTION menu are collectively returned to the initial setting.

Note that

the items “VOLUME”, “LAMP TIME”, “FILTER TIME” and “SERVICE” are not reset.

33

42

SERVICE
FANSPEED
AUTO ADJUST
LENS TYPE
LENS LOCK
GHOST
FILTER MESSAGE

: SELECT

NORMAL
ENABLE
AUTO
TURN OFF

100

35

Multifunctional Settings (continued)

Multifunctional Settings (continued)

NETWORK Menu

This projector provides the NETWORK function. If you use this
function, please set up the projector according to the Network
environment in which you use it.

memo If DHCP function on your Network is activated, the following

operation is not normally required, because DHCP function on this projector
is active as initial settings. Please see the section “Network Setting Up”.

: SELECT

MENU
MAIN
PICTURE-1
PICTURE-2
INPUT
AUTO
SCREEN
OPTION
NETWORK

SETUP
DHCP
INFORMATION
RESET

TURN OFF

Item Description

SETUP

Press the (or the ENTER) button, then the IP
ADDRESS menu as right comes up.

memo This menu will be shown only when the DHCP

is disabled at the NETWORK menu.
The IP Address is identification number of the projector on the Network.

1. Set the IP Address using the / buttons.

memo The same IP Address with other units cannot be used.

Press the (or the ENTER) button at the IP
ADDRESS menu, then the SUBNET MASK menu
comes up. The SUBNET MASK is an address of the
Network.

2. Set the address of the Network to be used.
Press the (or the ENTER) button at the SUBNET
MASK menu, then the DEFAULT GATEWAY menu
comes up. The DEFAULT GATEWAY is the main
device to access outside of the Network.

3. Set the address of the device as gateway to an outer Network.

DHCP

Select the TURN ON or the TURN OFF using the /
buttons. :

TURN ON  TURN OFF

If your Network doesn’t support the DHCP function, select the TURN OFF.

INFORMATION

Pressing the (or the ENTER) button displays the
INFORMATION menu.
The menu shows the information about the current
Network setting as illustrated right.

RESET

Select the EXECUTE using the button to reset the NETWORK menu items. :

EXECUTE  CANCEL

All items on the NETWORK menu are returned to the initial setting.

NETWORK - SETUP

IP ADDRESS

192 . 168 . 1 . 24

ESC ENT

:RETURN

NETWORK - SETUP

255 . 255 . 255 . 1

ESC ENT

:RETURN

NETWORK - SETUP
DEFAULT GATEWAY

255 . 255 . 255 . 0

ESC ENT

:RETURN

NETWORK-INFORMATION
IP ADDRESS 192. 168. 1. 24
SUBNETMASK 255. 255. 255. 0
DEFAULT GATEWAY 255. 255. 255. 0
MAC ADRRESS 00. E0. 47. 03. 0C. D8

SUBNET MASK

:NEXT

:NEXT

:NEXT

NETWORK

DHCP

TURN ON

TURN OFF

36

Network Setting Up

Network Setting Up

This projector provides the NETWORK function. When you start to use this function,
please consult your dealer for further information.

To start, connect the NETWORK port to a gateway device via a CAT-5 cable, then set up
the projector according to the Network environment in which you use it.

When your Network enables the DHCP function

You can set automatically, if you set the DHCP function to "TURN ON" using the NETWORK
menu. Please refer to the section "NETWORK Menu".

When your Network doesn’t support the DHCP function
or When you use a fixed address even if your Network can support the
DHCP function

Please set the IP Address, the Subnet Mask, the Default Gateway and the DHCP using
the NETWORK menu. At first, set the DHCP function to “TURN OFF”.

You can set them using a Web Browser (Internet Explorer 4.0 or higher) on the computer
connected to the Network.

Input the same IP address as set to the projector onto the Web Browser on the computer
connected to LAN.

ex. Case of IP Address = 192.168.1.11

1) Input “http://192.168.1.11”.

2) Click “ENTER”.

3) Input the required data according to the screen.

4) Make sure of the input data, then click "Write".

memo These setting will be active after reboot. These

setting will be stored, and used when DHCP is OFF.

5) Click “Return to top page”.

6) Click “REBOOT” to complete this operation.

35

37

Lamp

Lamp

The projector uses a high-pressure mercury glass lamp. The lamp can break with a
loud bang, or burn out, if jolted or scratched, handled while hot, or worn over time.

Note that each lamp has a different lifetime, and some may burst or burn out soon after
you start using them. In addition, when the bulb bursts, it is possible for shards of
glass to fly into the lamp housing, and for gas containing mercury to escape from the
projector’s vent holes.

About disposal of a lamp • This product contains a mercury lamp; do not put in
trash. Dispose of in accord with environmental laws.
For lamp recycling, go to www.lamprecycle.org. (in the US)
For product disposal, contact your local government agency or www.eiae.org (in the
US) or www.epsc.ca (in Canada).
For more information, call your dealer.

• If the lamp should break (it will make a loud bang when it does), unplug
the power cord from the outlet, and make sure to request a replacement
lamp from your local dealer. Note that shards of glass could damage the
projector’s internals, or cause injury during handling, so please do not try
to clean the projector or replace the lamp yourself.

• If the lamp should break (it will make a loud bang when it does), ventilate
the room well, and make sure not to breathe the gas that comes out of
the projector vents, or get it in your eyes or mouth.

• Before replacing the lamp, make sure the power switch is off and the
power cable is not plugged in, then wait at least 45 minutes for the lamp
to cool sufficiently. Handling the lamp while hot can cause burns, as well
as damaging the lamp.

• Do not open the lamp cover while the projector is suspended from
above. This is dangerous, since if the lamp’s bulb has broken, the
shards will fall out when the cover is opened. In addition, working in high
places is dangerous, so ask your local dealer to have the lamp replaced
even if the bulb is not broken.

• Do not use the projector with the lamp cover removed. At the lamp
replacing, make sure that the screws are screwed in firmly. Loose
screws could result in damage or injury.

• Use only the lamp of the specified type DT00601

.

• If the lamp breaks soon after the first time it is used, it is possible that
there are electrical problems elsewhere besides the lamp. If this
happens, contact your local dealer or a service representative.

• Handle with care: jolting or scratching could cause the lamp bulb to
burst during use.

• If the indicators or a message prompts you to replace the lamp (see the
section “Related Messages” and “Regarding the indicator Lamps”),
replace the lamp as soon as possible. Using the lamp for long periods of
time, or past the replacement date, could cause it to burst. Do not use
old (used) lamps; this is a cause of breakage.

WARNING

HIGH VOLTAGE HIGH TEMPERATURE HIGH PRESSURE

Disconnect the

plug from the

power outlet

38

Lamp (continued)

Lamp (continued)

After making sure that the projector has cooled
adequately, slide the knob of a lamp cover lock as
shown in the Figure. Then, one side of the lamp
cover is raised. Pull up the lamp cover and remove
it, as shown in the Figure.

If the indicators or a message prompts you to replace the lamp, replace the lamp as soon
as possible.

Turn off the projector, and unplug the power cord. Allow the lamp bulb to cool for at
least 45 minutes.

2

1

Contact your dealer to prepare a new lamp. Tell the dealer your lamp type number.
If the projector is mounted on the ceiling, or if the lamp has broken, also ask the
dealer to replace the lamp.

3

4

Unscrew the 3 screws, and slowly pull out the lamp
by the handle. Be careful not to touch the inside of
the lamp case.

5

Insert the new lamp, and tighten the 3 screws firmly
to lock it in place.

6

Interlocking the 2 tabs of the lamp cover to the
projector, put the lamp cover on the projector. Then
push the point of the lamp cover to fix it, as shown in
the Figure. Make sure that the lamp cover does’t
come up.

7

Turn on the projector, and reset the lamp timer.
(1) While the projector running, press the MENU button to open the menu.
(2) Choose the “OPTION” on the menu using the

/

button, then press the

button or ENTER button.

(3) Choose the “LAMP TIME” using the

/

button, then press the button or

RESET button.

(4) Choose the “RESET” using the button.

memo When the lamp has been replaced after the message of "THE POWER WILL

TURN OFF AFTER 0hr." is displayed, complete this operation within 10 minutes of
switching power on.

memo Incorrectly resetting of the lamp timer (resetting without replacement, or

neglect of resetting after replacement) will result in incorrect message functions.

Lamp cover

Lamp cover
knob

Tabs

In the case of replacement by yourself,

Screws

CO LAMP

PC

Replacing The Lamp

T
EMP

L

STAN
A
MP

D
BY/ON

VIDEO

S-VIDEO

COMPONENT

MENU

IN
TE

R

LENS SHIFT

BNG

RGB

RESET

INPUT

M1-D

FOCUS

ZOOM

SEARCH

KEYSTONE

PC

CO LAMP

TEMP

LAMP

STANDBY/ON

VIDEO

S-VIDEO

COMPONENT

MENU

IN
T

ER

LENS SH

BNG

IFT

RGB

RESET

INPUT

M1-D

FOCUS

ZOOM

SEARCH

KEYSTONE

PC

CO LAMP

TEMP

LAMP

STANDBY/ON

VIDEO

S-VIDEO

COMPONENT

MENU

IN
TE

R

LENS SHIFT

BNG

RGB

RESET

INPUT

M1-D

FOCUS

ZOOM

SEARCH

KEYSTONE

PC

CO LAMP

39

Caring For The Air Filter

Air Filter

Air Filter

WARNING • Please carefully read the “User’s Manual - Safety Guide.

• Before caring, make sure the power switch is off and the power cable is not

plugged in, then wait at least 45 minutes for the lamp to cool sufficiently.

• Use only the air filter of the specified type NJ08081

.

• Do not use the projector with the air filter and filter cover removed. The use without
the air filter could result in damage.

CAUTION

• If the air filter becomes clogged by dust or the like, internal

temperature rises and could cause malfunction. The power is automatically turned

off in order to prevent the projector from overheating internally.

Cleaning the air filter every 100 hours using the FILTER MESSAGE function is
recommended. If the indicators or a message prompts you to clean the air filter, clean the
air filter as soon as possible. Please check and clean the air filter periodically, even if
there is no message. If the soiling will not come off the air filter, or it becomes damaged,
then it needs to be replaced. Please replace the air filter as soon as possible.

memo When you replace the lamp, please replace also the air filter.

Turn off the projector, and unplug the power cord. Allow the lamp bulb to cool for at
least 45 minutes.

Apply a vacuum cleaner to the top of the filter cover and
the air filter to clean.
If the soiling will not come off the air filter, or it becomes
damaged, it needs to be replaced.
If the air filter needs to be replaced, contact your dealer
to prepare a new air filter. Tell the dealer your air filter
type.

Turn on the projector power, and reset the filter timer.
(1) While the projector running, press the MENU button to

open the menu.

(2) Choose the “OPTION” on the menu using the

/

button, then press the button or ENTER button.

(3) Choose the “FILTER TIME” using the

/

button, then

press the

button or

RESET button.

(4) Choose the “RESET” using the button.

memo Incorrectly resetting of the filter timer (resetting

without replacement, or neglect of resetting after replacement) will result in
incorrect message functions.

5

3

2

1

After making sure that the projector has cooled adequately, remove the filter cover
and air filter.

4

Insert the cleaned air filter or a new air filter, and replace
the filter cover.

Hold the release

buttons of the filter

cover while pulling

down it.

Hold the release button

of the air filter while

pulling out it.

34

LAMP

MP
E

T

ON
/

TANDBY
S

VIDEO

U

N
E
M

S-VIDEO

R

E

M

T

O

N
I

ZO

FOCUS

T

T
N

SE

E
E
R

COMPON

BNG

T

U
P
N

I

RCH

A

RGB
E
S

SHIFT

S
N

LE

M1-D

E

N
O
ST

Y

KE

LAMP

MP
E
T

ON
/

STANDBY

VIDEO

U

N
ME

S-VIDEO

R

E

M

T

O

N
I

ZO

FOCUS

T

T
N

SE

E
E
R

COMPON

G

BN

T

U
P
N
I

RGB

EARCH

SHIFT

S

S

N
LE

M1-D
E
N

O

YST
E
K

40

Other Care

Other Care

WARNING • Please carefully read the “User’s Manual - Safety Guide”.

• Before caring, make sure the power switch is off and the power cable is not

plugged in.

• Be cautious of high temperature. Do not touch about the lens and ventilation
openings during use or immediately after use prevent a burn.

• Never try to care for the inside of the unit yourself. Doing so is dangerous.

CAUTION

• Incorrect care could have adverse influence such as discoloration,

peeling paint, etc.

• Do not use cleaner or chemicals other than those listed below, including benzene and
paint thinner.

• Do not use aerosols or sprays.

• Do not polish or wipe with hard objects.

Caring For The Inside Of The Projector

In order to ensure the safe use of your projector, please have it cleaned and inspected by
your local dealer about once every year.

Turn off the projector, and unplug the power cord.

Lightly wipe the lens with a commercially available lens-cleaning wipe. Do not touch
the lens directly with your hand.

2

Caring For The Lens

1

Turn off the projector, and unplug the power cord.

Wipe lightly with gauze or a soft cloth.

memo If soiling is severe, dip soft cloth in water or a neutral cleaner dilute in water,

and wipe lightly after wringing well. Then, wipe lightly with a soft, dry cloth.

Caring For The Cabinet And Remote Control

1

2

41

TTroubleshooting

roubleshooting

Related Messages

When the unit's power is on, messages such as those shown below may be displayed.
When any such message is displayed on the screen, please respond as described below.
If the same message is displayed after the treatment, or if a message other than the
following appears, please contact your dealer or service company.

memo Although these messages will be automatically disappeared around several

minutes, it will be reappeared every time the power is turned on.

• A lamp has a finite product life. Lamps are characterized by the fact that,
after long hours of usage, a lamp will no longer light up, or the lamp will break or burst,
etc. This projector is equipped with an automatic shut-down function, such that the
power will automatically be turned off when lamp usage time has reached 2000 hours.
Please be aware, however, that among lamp types, there are major differences in
product lifetimes; a lamp may thus fail to light even prior to the functioning of the
automatic shut-down function of this projector.

NOTE

(This table is continued to the following page.)

Message Description

CHANGE THE LAMP

AFTER REPLACING LAMP,

RESET THE LAMP TIMER.

The time the lamp timer has counted is approaching
2000 hours.

Preparation of a new lamp, and an early lamp change is
recommended. After you have change the lamp, please be sure
to reset the lamp timer.

CHANGE THE LAMP

AFTER REPLACING LAMP,

RESET THE LAMP TIMER.

THE POWER WILL TURN OFF

AFTER ** hr.

The time the lamp timer has counted is approaching
2000 hours, so a lamp change within ** hours is
recommended.

When lamp usage reaches 2000 hours, the power will
automatically be turned off.
Please change the lamp by referring to the section “Lamp”.
After you have changed the lamp, please be sure to reset the
lamp timer.

CHANGE THE LAMP

AFTER REPLACING LAMP,

RESET THE LAMP TIMER.

THE POWER WILL TURN OFF

AFTER 0 hr.

As the time the lamp timer has counted has reached
2000 hours, the power will soon be automatically
turned off.

Please immediately turn the power off, and change the lamp by
referring to the section “Lamp”. After changing the lamp, please
be sure to reset the lamp timer.

42

Related Messages

(continued)

TTroubleshooting (continued)

roubleshooting (continued)

Message Description

REMINDER

***

HRS PASSED AFTER THE LAST

FILTER CHECK.

FILTER MAINTENANCE IS

ESSENTIAL TO REMOVE WARNING

MESSAGE, RESET FILTER TIMER.

SEE MANUAL FURTHER INFO.

The time the filter timer has counted has reached the
interval time set by the "FILER MESSAGE" of
"SERVICE" item in the OPTION menu.

Please clear or change the air filter by referring to the section
“Air Filter”. After caring for the air filter, please be sure to reset
the filter timer.

PLEASE CHECK THAT THE

FILTER HAS BEEN CLEANED.

FAILURE TO CLEAN MAY

RESULT IN DAMAGE TO THE

PROJECTOR.

SEE MANUAL FURTHER INFO.

The internal portion temperature is rising.

Please turn the power OFF, and allow the unit to cool down at
least 20 minutes. After the projector has sufficiently cooled
down, please make confirmation of the following items, and
then turn the power on again.

• Is there blockage of the air passage aperture?

• Is the air filter dirty?

• Does the peripheral temperature exceed 35°C?

There is no input signal.

Please confirm the signal input connection, and the status of the
signal source.

The horizontal or vertical wavelength of the inputted
signal is outside of the response parameters of this
unit.

Please confirm the specs for this unit or the signal source
specs.

NO INPUT IS DETECTED

ON ***

SYNC IS OUT OF RANGE

ON *** fH *****kHz fV *****Hz

43

TTroubleshooting (continued)

roubleshooting (continued)

Regarding The Indicator Lamps

Lighting and flashing of the STANDBY/ON indicator, the LAMP indicator, and the TEMP
indicator have the meanings as described in the table below. Please respond in
accordance with the instructions within the table. If the same indication is displayed after
the treatment, or if an indication other than the following is displayed, please contact your
dealer or service company.

•

When the interior portion has become overheated, for safety purposes, the
power source is automatically turned off, and the indicator lamps may also be turned off.
In such a case, press the “○” (OFF) side of the main power switch, and wait at least 45
minutes. After the projector has sufficiently cooled down, please make confirmation of
the attachment state of the lamp and lamp cover, and then turn the power on again.

NOTE

STANDBY/ON

indicator

LAMP

indicator

TEMP

indicator

Description

Lighting

in Orange

Turned

off

Turned

off

The projector is in a standby state.

Please refer to the section “Power On/Off”.

Blinking

in Green

Turned

off

Turned

off

The projector is warming up.

Please wait.

Lighting

in Green

Turned

off

Turned

off

The projector is in an on state.

Ordinary operations may be performed.

Blinking

in Orange

Turned

off

Turned

off

The projector is cooling down.

Please wait.

Blinking

in Red

(discre-

tionary)

(discre-

tionary)

The projector is cooling down. A certain error has
been detected.

Please wait until the STANDBY/ON indicator finishes blink,
and then perform the proper response measure using the
item descriptions below as reference.

Lighting

in Red

Lighting

in Red

Turned

off

The lamp does not light, and there is a possibility
that interior portion has become heated.

Please turn the power off, and allow the unit to cool down at
least 20 minutes. After the projector has sufficiently cooled
down, please make confirmation of the following items, and
then turn the power on again.

• Is there blockage of the air passage aperture?

• Is the air filter dirty?

• Does the peripheral temperature exceed 35°C?
If the same indication is displayed after the treatment,
please change the lamp by referring to the section “Lamp”.

(This table is continued to the following page.)

44

TTroubleshooting (continued)

roubleshooting (continued)

Regarding The Indicator Lamps

(continued)

STANDBY/ON

indicator

LAMP

indicator

TEMP

indicator

Description

Lighting

in Red

Blinking

in Red

Turned

off

Either there is no lamp and/or lamp cover, or
either of these has not been properly fixed.

Please turn the power off, and allow the unit to cool down at
least 45 minutes. After the projector has sufficiently cooled
down, please make confirmation of the attachment state of
the lamp and lamp cover, and then turn the power on again.
If the same indication is displayed after the treatment,
please contact your dealer or service company.

Lighting

in Red

Turned

off

Blinking

in Red

The cooling fan is not operating.

Please turn the power off, and allow the unit to cool down at
least 20 minutes. After the projector has sufficiently cooled
down, please make confirmation that no foreign matter has
become caught in the fan, etc., and then turn the power on
again.
If the same indication is displayed after the treatment,
please contact your dealer or service company.

Lighting

in Red

Turned

off

Lighting

in Red

There is a possibility that the interior portion has
become heated.

Please turn the power off, and allow the unit to cool down at
least 20 minutes. After the projector has sufficiently cooled
down, please make confirmation of the following items, and
then turn the power on again.

• Is there blockage of the air passage aperture?

• Is the air filter dirty?

• Does the peripheral temperature exceed 35°C?
If the same indication is displayed after the treatment,
please change the lamp by referring to the section “Lamp”.

Lighting

in Green

Alternative

Blinking in Red

There is a possibility that the interior portion has
become overcooled.

Please use the unit within the usage temperature
parameters (0°C to 35°C). After the treatment, resent the
power to ON.

Lighting

in Green

Simultaneous

Blinking in Red

It is time to clean the air filter, or there is no air
filter.

Please immediately turn the power OFF, and clean or
change the air filter by referring to the section “Air Filter”.
After cleaning or changed the lamp, please be sure to reset
the filter timer. After the treatment, resent the power to ON.

45

TTroubleshooting (continued)

roubleshooting (continued)

Phenomena That May Easily Be Mistaken For Machine Defects

WARNING • Never use the projector if abnormal operations such as smoke,

strange odor, excessive sound, damaged casing or elements or cables,
penetration of liquids or foreign matter, etc. should occur. In such cases, immediately
turn off the power switch and then disconnect the power plug from the power outlet
After making sure that the smoke or odor has stopped, contact your dealer or service
company.

Before requesting repair, please check in accordance with the following chart. If the
situation cannot be corrected, please contact your dealer or service company.

• Although bright spots or dark spots may appear on the screen, this is a

unique characteristic of liquid crystal displays, and such do not constitute or imply a

machine defect.

NOTE

Phenomenon Cases not involving a machine defect

Reference

pages

Power does not
come on.

The electrical power cord is not plugged in.

Correctly connect the power cord.

11

The power switch is not set to the on position.

Set the power switch to [ | ] (On).

15

The main power source has been interrupted during operation
such as by a power outage (blackout), etc.

Please turn the power off, and allow the unit to cool down at least 20
minutes. After the projector has sufficiently cooled down, please turn
the power on again.

15

Either there is no lamp and/or lamp cover, or either of these has
not been properly fixed.

Please turn the power off, and allow the unit to cool down at least 45
minutes. After the projector has sufficiently cooled down, please
make confirmation of the attachment state of the lamp and lamp
cover, and then turn the power on again.

37, 38

Neither sounds
nor pictures are
outputted.

The signal cables are not correctly connected.

Correctly connect the connection cables.

8, 9

Signal source does not correctly work.

Correctly set up the signal source device by referring to the manual
of the source device.

-

The input changeover settings are mismatched.

Select the input signal, and correct the settings.

16

(This table is continued to the following page.)

46

TTroubleshooting (continued)

roubleshooting (continued)

Phenomena That May Easily Be Mistaken For Machine Defects

(continued)

Phenomenon Cases not involving a machine defect

Reference

pages

Pictures are
displayed,
but no sounds
are heard.

The signal cables are not correctly connected.

Correctly connect the connection cables.

8, 9

The volume is adjusted to an extremely low level.

Adjust the VOLUME to a higher level.

19, 33

The sound is muted.

Press the MUTE button to restore the sound.

19

The audio input is not correctly selected when the child window
is displayed.

Correctly select the audio input.

22

Sounds are
heard,
but no pictures
are displayed.

The lens cap is attached.

Remove the lens cap.

4, 15

The signal cables are not correctly connected.

Correctly connect the connection cables.

8, 9

The brightness is adjusted to an extremely low level.

Adjust the BRIGHT to a higher level using the menu function.

23

The screen is blanked.

Press the BLANK button to return to the input signal screen.

19

Video screen
display freezes.

The FREEZE function is working.

Press the FREEZE button to restore the screen to normal.

20

Colors have a
faded- out
appearance, or
Color tone is poor.

Color settings are not correctly adjusted.

Perform picture adjustments by changing the COLOR BAL R,
COLOR BAL G, COLOR BAL B, COLOR and/or TINT settings, using
the menu functions.

24

Pictures appear
dark.

The brightness and/or contrast are adjusted to an extremely low
level.

Adjust the BRIGHT and/or CONTRAST settings to a higher level
using the menu function.

23

The WHISPER function is working.

Select the NORMAL to the item WHISPER in the MAIN menu.

23

The lamp is approaching the end of its product lifetime.

Replace the lamp.

37, 38

Pictures appear
blurry.

Either the focus and/or horizontal phase settings are not
properly.

Adjust the focus using the focus buttons, and/or H PHASE using the
menu function.

16

The lens is dirty or misty.

Clean the lens by referring to the section “Caring For The Lens”.

38

Input signal
changes with no
operation.

The INPUT dial is set between the click points.

Turn the INPUT dial and set it at a click point.

16

47

If a problem occurs with the equipment, first refer to the “Troubleshooting” and run
through the suggested checks. If this does not resolve the problem, please contact your
dealer or service company. They will tell you what warranty condition is applied.

WWarranty And After-Service

arranty And After-Service

Specifications

Specifications

• This specifications are subject to change without notice.

NOTE

Item Specification

Product name Liquid crystal projector

Liquid
crystal
panel

Panel size 2.5 cm (0.99 type)
Drive system TFT active matrix

Pixels 1,470,000 pixels (1400 horizontal x 1050 vertical)
Lens Zoom lens F=1.7 ~ 2.4 f=30.5 ~ 45.8 mm
Lamp 310W UHB
Speaker 1.0W + 1.0W (Stereo)

Power supply

AC100 ~ 120V, 5.2A

AC220 ~ 240V, 2.2A
Power consumption 470W
Temperature range 0 ~ 35°C (Operating)

Size

420 (W) x 150 (H) x 310 (D) mm (Not including protruding parts)

• Please refer to the figure of the section “TECHNICAL” of the
end of this manual.

Weight (mass) 7.7 kg

Ports

Optional
Parts

Lamp DT00601
Air filter NJ08081
Others • Please consult your dealer.

RGB input ports

RGB
M1-D
BNC (R, G, B, H, V)

Video input ports

VIDEO IN
S-VIDEO
COMPONENT
(CR/PR, CB/PB, Y)

Audio input ports

AUDIO IN 1
AUDIO IN 2
AUDIO IN R/L

RGB output port

RGB OUT

Audio output port

AUDIO OUT

Control port

CONTROL

Other ports

NETWORK
REMOTE CONTROL
DC OUT

1

Projector

CP-SX1350

CP-SX1350

User's Manual - Operating Guide

User's Manual - Operating Guide

TECHNICAL

Dimensions

Dimensions

210

420

85.5 (at the bottom of lens position) to 92.99 (at the top of lens position)

160

150

320

73

[unit: mm]

M

O
O

Z

FOCUS

T

MP

A
L

MP
E

T

N

O
/

ANDBY
T

S
O

VIDE
U
N

ME

-VIDEO

S

R
E
T
N

I

T

E

N

S

E

E

N

R

OMPO

C

BNG
T
U
P
N

I

T

RCH

RGB

SHIF

SEA

S
N

LE

D

­M1

E
N

O

KEYST

2

•

Be sure to check jack type, signal level, timing and resolution before

connecting this projector to a computer.

• Some computers may hove multiple display screen modes. Use of some of these

modes will not be possible with this projector.

• Depending on the input signal, full-size display may not be possible in some cases.

Refer to the number of display pixels above.

• Although the projector can display signals with resolution up to UXGA (1600 x 1200),

the signal will be converted to the projector’s panel resolution before being
displayed. The best display performance will be achieved if the resolutions of the
input signal and projector panel are identical.

• Automatically adjustment may not function correctly with some input signals.

• The image may not be displayed correctly when the input sync. signal is a composite

sync. or a sync. on G.

NOTE

Example Of Computer Signal

Example Of Computer Signal

Resolution

H ××V

fH (kHz) fV (Hz) Rating Signal mode Display mode

720 × 400

37.9 85.0 VESA TEXT Zoom in

640 × 480

31.5 59.9 VESA VGA (60Hz) Zoom in

630 × 480

35.0 66.7 Mac13"mode Zoom in

640 × 480

37.9 72.8 VESA VGA (72Hz) Zoom in

640 × 480

37.5 75.0 VESA VGA (75Hz) Zoom in

640 × 480

43.3 85.0 VESA VGA (85Hz) Zoom in

800 × 600

35.2 56.3 VESA SVGA (56Hz) Zoom in

800 × 600

37.9 60.3 VESA SVGA (60Hz) Zoom in

800 × 600

48.1 72.2 VESA SVGA (72Hz) Zoom in

800 × 600

46.9 75.0 VESA SVGA (75Hz) Zoom in

800 × 600

53.7 85.1 VESA SVGA (85Hz) Zoom in

832 × 624

49.7 74.5 Mac16"mode Zoom in

1024 × 768

48.4 60.0 VESA XGA (60Hz) Zoom in

1024 × 768

56.5 70.1 VESA XGA (70Hz) Zoom in

1024 × 768

60.0 75.0 VESA XGA (75Hz) Zoom in

1024 × 768

68.7 85.0 VESA XGA (85Hz) Zoom in

1152 × 864

67.5 75.0 VESA SXGA (75Hz)

1280 × 960

60.0 60.0 VESA SXGA (60Hz)

1280 × 1025

64.0 60.0 VESA SXGA (60Hz)

1280 × 1024

80.0 75.0 VESA SXGA (75Hz)

1400 × 1050

65.2 60.0 VESA SXGA+(60Hz)

1600 × 1200

75.0 60.0 VESA UXGA (60Hz) Zoom out

3

Initial Set Signals

Initial Set Signals

The following signals are used for the initial settings. The signal timing of some computer
models may be different. In such case, adjust the items V POSITION and H POSITION in
the PICTURE-2 menu.

DATA

H. Sync.

V. Sync.

DATA

Display interval c

Back porch b

Sync. a

Front porch d

Display interval c

Back porch b

Sync. a

Front porch d

Computer /

Signal

Horizontal signal timing (µs)

a b c d

TEXT 2.0 3.0 20.3 1.0

VGA (60Hz) 3.8 1.9 25.4 0.6

Mac 13"mode 2.1 3.2 21.2 2.1

VGA (72Hz) 1.3 3.8 20.3 1.0
VGA (75Hz) 2.0 3.8 20.3 0.5

VGA (75Hz) 1.6 2.2 17.8 1.6
SVGA (56Hz) 2.0 3.6 22.2 0.7
SVGA (60Hz) 3.2 2.2 20.0 1.0
SVGA (72Hz) 2.4 1.3 16.0 1.1
SVGA (75Hz) 1.6 3.2 16.2 0.3
SVGA (85Hz) 1.1 2.7 14.2 0.6

Mac 16"mode 1.1 3.9 14.5 0.6

XGA (60Hz) 2.1 2.5 15.8 0.4

XGA (70Hz) 1.8 1.9 13.7 0.3

XGA (75Hz) 1.2 2.2 13.0 0.2

XGA (85Hz) 1.0 2.2 10.8 0.5

1152×864 (75Hz)

1.2 2.4 10.7 0.6

1280×960 (60Hz)

1.0 2.9 11.9 0.9

1280×1024 (60Hz)

1.0 2.3 11.9 0.4

1280×1024 (75Hz)

1.1 1.8 9.5 0.2

1400×1050 (60Hz)

1.2 2.0 11.4 0.7

1600×1200 (60Hz)

1.2 1.9 9.9 0.4

Computer /

Signal

Vertical signal timimg (lines)

a b c d

TEXT 3 42 400 1

VGA (60Hz) 2 33 480 10

Mac 13"mode 3 39 480 3

VGA (72Hz) 3 28 480 9
VGA (75Hz) 3 16 480 1

VGA (75Hz) 3 25 480 1
SVGA (56Hz) 2 22 600 1
SVGA (60Hz) 4 23 600 1
SVGA (72Hz) 6 23 600 37
SVGA (75Hz) 3 21 600 1
SVGA (85Hz) 3 27 600 1

Mac 16"mode 3 39 624 1

XGA (60Hz) 6 29 768 3

XGA (70Hz) 6 29 768 3

XGA (75Hz) 3 28 768 1

XGA (85Hz) 3 36 768 1

1152×864 (75Hz)

3 32 864 1

1280×960 (60Hz)

3 36 960 1

1280×1024 (60Hz)

3 38 1024 1

1280×1024 (75Hz)

3 37 1024 2

1400×1050 (60Hz)

3 32 1050 2

1600×1200 (60Hz)

3 46 1200 1

4

• Video signal: RGB separate, Analog, 0.7 Vp-p, 75 Ω
terminator (positive)

• H./V. sync. Signal: TTL level (positive/negative)

• Composite sync. Signal: TTL level

D-Sub 15 pin shrink jack

Connection T

Connection T

o The Ports

o The Ports

Pin Signal Pin Signal Pin Signal

1

Video input Red

6

Ground Red

-

-

2

Video input Green

7

Ground Green

=

SDA (DDC)

3

Video input Blue

8

Ground Blue

q

H./Composite sync.

4

-

9

-

w

V. sync.

5

Ground

0

Ground

e

SCL (DDC)

A RGB

• Type: T.M.D.S.

•

Amplitude differential: DC 150-1200 mV / AC 1.56 Vp-p

• Amplitude: TTL level (positive/negative)

M1-D jack

Pin Signal Pin Signal Pin Signal

1

T.M.D.S. Data2 +

-

T.M.D.S. Data1 +

o

T.M.D.S. Data0 +

2

T.M.D.S. Data2 -

=

T.M/D.S. Data1 -

p

T.M.D.S. Data0 -

3

T.M.D.S. Data2 Return

q

T.M.D.S. Data1 Return

[

T.M.D.S. Data0 Return

4

T.M.D.S. Clock Return

w

T.M.D.S. Clock +

]

USB +5V DC Input

5

-

e

T.M.D.S. Clock -

\

DDC & USB Return

6

V. Sync.

r

USB Date +

a

DDC Date (SDA)

7

-

t

USB Date -

s

DDC Clock (SCL)

8

Hot Plug Detect

(+5V DC Output)

y

-

d

DDC +5V DC Input

9

-

u

-

f

-

0

-

i

-

g

-

B M1-D

C BNC (R,G,B,H,V)

• BNC jack x5

• Video: Analog 0.7 Vp-p, 75 Ω terminator

• H/V. sync. : TTL level (positive/negative)

• Composite sync. : TTL level

D AUDIO IN 1, E AUDIO IN 2, H AUDIO IN R, L, M AUDIO OUT

• 3.5 dia. Stereo mini jack

• 200 mVrms, 57k Ω terminator

VIDEOR-AUDIO IN-L

S-VIDEO

BNC

RGB

AUDIO IN1

AUDIO IN2

RGB OUT

AUDIO OUT

R/C

R/PR G/Y B/CB/PB HV

Y

CONTROL NETWORK

CR/PR

Ca/Pa

REMOTE CONTROL

D

C

H

A

M

E

B

54321

ewq=-

67890

]\asdfg [po

iuytrewq=-

8709 654321

5

Connection T

Connection T

o The Ports (continued)

o The Ports (continued)

• Video signal: RGB separate, Analog, 0.7 Vp-p, 75 Ω
terminator (positive)

• H./V. sync. Signal: TTL level (positive/negative)

• Composite sync. Signal: TTL level

D-Sub 15 pin shrink jack

Pin Signal Pin Signal Pin Signal

1

Video output Red

6

Ground Red

-

-

2

Video output Green

7

Ground Green

=

-

3

Video output Blue

8

Ground Blue

q

H./Composite sync.

4

-

9

-

w

V. sync.

5

Ground

0

Ground

e

-

L RGB OUT

Mini Din 4 pin jack

I VIDEO IN

• RCA jack

• System: NTSC, PAL, SECAM, PAL-M, PAL-N, NTSC4.43, PAL60

• 1.0 ± 0.1 Vp-p at 75 Ω terminator

K COMPONENT (CR/PR, CB/PB, Y)

• RCA jack x3

• System: 525i (480i), 525p (480p), 625i (576i), 720p, 1080i/1035i

• Y signal: 1.0 ± 0.1 Vp-p at 75 Ω terminated with composite sync.

• C

B

/PB signal: 0.7 ± 0.1 Vp-p at 75 Ω terminated

• C

R

/PR signal: 0.7 ± 0.1 Vp-p at 75 Ω terminated

VIDEOR-AUDIO IN-L

S-VIDEO

BNC

RGB

AUDIO IN1

AUDIO IN2

RGB OUT

AUDIO OUT

R/C

R/PR G/Y B/CB/PB HV

Y

CONTROL NETWORK

CR/PR

Ca/Pa

REMOTE CONTROL

I

J

K

L N

O

N REMOTE CONTROL

• 3.5 dia. Stereo mini jack

• To be connected with the remote control that came with the projector.

O DC OUT

J S-VIDEO

Pin Signal

1

Color signal: 0.286 Vp-p (NTSC, burst), 75 Ω terminator
Color signal: 0.300 Vp-p (PAL/SECAM, burst), 75 Ω terminator

2

Brightness signal: 1.0 Vp-p, 75 Ω terminator

3

Ground

4

Ground

12

3

4

54321

67890

ewq=-

6

Connection T

Connection T

o The Ports (continued)

o The Ports (continued)

VIDEOR-AUDIO IN-L

S-VIDEO

BNC

RGB

AUDIO IN1

AUDIO IN2

RGB OUT

AUDIO OUT

R/C

R/PR G/Y B/CB/PB HV

Y

CONTROL NETWORK

CR/PR

Ca/Pa

REMOTE CONTROL

G

F

D-Sub 9 pin

plug

CONTROL port

F CONTROL

G NETWORK

• RJ-45 (10BASE-T) jack

Computer side

D-Sub 9 pin

jack

1
2
3
4
5
6
7
8
9

RD

-

TD

-

-

GND

-

CTS

RTS

1
2
3
4
5
6
7
8
9

CD
RD
TD
DTR
GND
DSR
RTS
DTS
RI



D-Sub 9 pin

jack

D-Sub 9 pin

plug

RS-232C port



memo About the details of RS-232C communication, please refer to the

following page.

1 2 3 4 5

6 7 8 9

5 4 3 2 1

9 8 7 6

5 4 3 2 1

9 8 7 6

1 2 3 4 5

6 7 8 9

7

RS-232C Communication

RS-232C Communication

Connecting The Cable

Turn off the projector and the computer power supplies.

Connect the CONTROL port of the projector with a RS-232C port of the computer by
a RS-232C cable. Use the cable that fulfills the specification shown in the previous
page.

Turn on the computer power supply and after the computer has started up, turn on
the projector power supply.

1

2

3

19200bps, 8N1

1. Protocol

Consist of header (7 bytes) + command data (6 bytes).

2. Header

BE + EF + 03 + 06 + 00 + CRC_low + CRC_high
CRC_low : Lower byte of CRC flag for command data
CRC_high : Upper byte of CRC flag for command data

3. Command data

Command Data Chart

Communications Setting

byte_0 byte_1 byte_2 byte_3 byte_4 byte_5

Action Type Setting code

low high low high low high

Action (byte_0 - 1)

Action Classification Content

1 SET Change setting to desired value.
2 GET Read projector internal setup value.
4 INCREMENT Increment setup value by 1.
5 DECREMENT Decrement setup value by 1.
6 EXECUTE Run a command.

8

RS-232C Communication (continued)

RS-232C Communication (continued)

Requesting projector status (Get command)

(1) Send the request code Header + Command data (‘02H’+‘00H’+ type (2

bytes)+‘00H’+‘00H’) from the computer to the projector.

(2) The projector returns the response code ‘1DH’+ data (2 bytes) to the computer.

Changing the projector settings (Set command)

(1) Send the setting code Header + Command data (‘01H’+‘00H’+ type (2 bytes) +

setting code (2 bytes)) from the computer to the projector.
(2) The projector changes the setting based on the above setting code.
(3) The projector returns the response code ‘06H’ to the computer.

Using the projector default settings (Reset Command)

(1) The computer sends the default setting code Header + Command data (‘06H’+‘00H’+

type (2 bytes) +‘00H’+‘00H’) to the projector.
(2) The projector changes the specified setting to the default value.
(3) The projector returns the response code ‘06H’ to the computer.

Increasing the projector setting value (Increment command)

(1) The computer sends the increment code Header + Command data (‘04H’+‘00H’+

type (2 bytes) +‘00H’+‘00H’) to the projector.
(2) The projector in creases the setting value on the above setting code.
(3) The projector returns the response code ‘06H’ to the computer.

Decreasing the projector setting value (Decrement command)

(1) The computer sends the decrement code Header + Command data (‘05H’+‘00H’+

type (2 bytes) +‘00H’ + ‘00H’) to the projector.
(2) The projector decreases the setting value on the above setting code.
(3) The projector returns the response code ‘06H’ to the computer.

When the projector cannot understand the received command

When the projector cannot understand the received command, the error code ‘15H’ is
sent back to the computer.
Sometimes the projector cannot properly receive the command. In such a case, the
command is not executed and the error code ‘15H’ is sent back to the computer. If this
error code is returned, send the same command again.

When the projector cannot execute the received command.

When the projector cannot execute the received command, the error code ‘1cH’ +
‘xxxxH’ is sent back to the computer. When the data length is greater than indicated by
the data length code, the projector ignore the excess data code.
Conversely when the data length is shorter than indicated by the data length code, an
error code will be returned to the computer.

• Operation cannot be guaranteed when the projector receives an

undefined command or data.

• Provide an interval of at least 40ms between the response code and any other code.

• The projector outputs test data when the power supply is switched ON, and when the

lamp is lit. Ignore this data.

• Commands are not accepted during warm-up.

NOTE

9

RS-232C Communication (continued)

RS-232C Communication (continued)

Command Data Chart

Names Operation type Header

Command data

CRC Action Type Setting code

Keystone V

Get BE EF 03 06 00 B9 D3 02 00 07 20 00 00

Increment BE EF 03 06 00 DF D3 04 00 07 20 00 00

Decrement BE EF 03 06 00 0E D2 05 00 07 20 00 00

Keystone V Reset

Execute

BE EF 03 06 00 08 D0 06 00 0C 70 00 00

Keystone H

Get BE EF 03 06 00 E9 D0 02 00 0B 20 00 00

Increment BE EF 03 06 00 8F D0 04 00 0B 20 00 00

Decrement BE EF 03 06 00 5E D1 05 00 0B 20 00 00

Keystone H Reset

Execute

BE EF 03 06 00 98 D8 06 00 20 70 00 00

Brightness

Get BE EF 03 06 00 89 D2 02 00 03 20 00 00

Increment BE EF 03 06 00 EF D2 04 00 03 20 00 00

Decrement BE EF 03 06 00 3E D3 05 00 03 20 00 00

Brightness Reset Execute BE EF 03 06 00 58 D3 06 00 00 70 00 00

Contrast

Get BE EF 03 06 00 FD D3 02 00 04 20 00 00

Increment BE EF 03 06 00 9B D3 04 00 04 20 00 00

Decrement BE EF 03 06 00 4A D2 05 00 04 20 00 00

Contrast Reset Execute

BE EF 03 06 00 A4 D2 06 00 01 70 00 00

Aspect

Set

4:3

BE EF 03 06 00 9E D0 01 00 08 20 00 00

16:9

BE EF 03 06 00 0E D1 01 00 08 20 01 00

SMALL

BE EF 03 06 00 FE D1 01 00 08 20 02 00

NORMAL

BE EF 03 06 00 5E DD 01 00 08 20 10 00

REAL

BE EF 03 06 00 5E D7 01 00 08 20 08 00

Get

BE EF 03 06 00 AD D0 02 00 08 20 00 00

Whisper

Set

NORMAL

BE EF 03 06 00 3B 23 01 00 00 33 00 00

WHISPER

BE EF 03 06 00 AB 22 01 00 00 33 01 00

Get

BE EF 03 06 00 08 23 02 00 00 33 00 00

Mirror

Set

Normal

BE EF 03 06 00 C7 D2 01 00 01 30 00 00

H Inverse

BE EF 03 06 00 57 D3 01 00 01 30 01 00

V lnverse

BE EF 03 06 00 A7 D3 01 00 01 30 02 00

H&V Inverse

BE EF 03 06 00 37 D2 01 00 01 30 03 00

Get

BE EF 03 06 00 F4 D2 02 00 01 30 00 00

(This table is continued to the following page.)

10

RS-232C Communication (continued)

RS-232C Communication (continued)

Command Data Chart

(continued)

Names Operation type Header

Command data

CRC Action Type Setting code

Language

Set

ENGLISH BE EF 03 06 00 F7 D3 01 00 05 30 00 00

FRANÇAIS

BE EF 03 06 00 67 D2 01 00 05 30 01 00

DEUTSCH BE EF 03 06 00 97 D2 01 00 05 30 02 00

ESPAÑOL BE EF 03 06 00 07 D3 01 00 05 30 03 00
ITALIANO BE EF 03 06 00 37 D1 01 00 05 30 04 00

NORSK BE EF 03 06 00 A7 D0 01 00 05 30 05 00

NEDERLANDS

BE EF 03 06 00 57 D0 01 00 05 30 06 00

PORTUGUÊS

BE EF 03 06 00 C7 D1 01 00 05 30 07 00

日本語

BE EF 03 06 00 37 D4 01 00 05 30 08 00
BE EF 03 06 00 A7 D5 01 00 05 30 09 00
BE EF 03 06 00 37 DE 01 00 05 30 10 00
BE EF 03 06 00 57 D5 01 00 05 30 0A 00

SVENSKA BE EF 03 06 00 C7 D4 01 00 05 30 0B 00

BE EF 03 06 00 F7 D6 01 00 05 30 0C 00

SUOMI BE EF 03 06 00 67 D7 01 00 05 30 0D 00

POLSKI BE EF 03 06 00 97 D7 01 00 05 30 0E 00
TÜRKÇE BE EF 03 06 00 07 D6 01 00 05 30 0F 00
Get BE EF 03 06 00 C4 D3 02 00 05 30 00 00

Gamma

Set

NORMAL BE EF 03 06 00 C7 F0 01 00 A1 30 00 00

CINEMA BE EF 03 06 00 57 F1 01 00 A1 30 01 00

DYNAMIC BE EF 03 06 00 A7 F1 01 00 A1 30 02 00

CUSTOM BE EF 03 06 00 07 FD 01 00 A1 30 10 00

Get BE EF 03 06 00 F4 F0 02 00 A1 30 00 00

Custom Gamma

Get BE EF 03 06 00 08 F1 02 00 A0 30 00 00

Increment BE EF 03 06 00 6E F1 04 00 A0 30 00 00

Decrement BE EF 03 06 00 BF F0 05 00 A0 30 00 00

Custom

Color Temp

Set

USER BE EF 03 06 00 3B F8 01 00 B0 30 10 00

HIGH BE EF 03 06 00 0B F5 01 00 B0 30 03 00

MIDDLE BE EF 03 06 00 9B F4 01 00 B0 30 02 00

LOW BE EF 03 06 00 6B F4 01 00 B0 30 01 00

Get BE EF 03 06 00 C8 F5 02 00 B0 30 00 00

Custom User R

Set

50 BE EF 03 06 00 57 F7 01 00 B1 30 05 00
60 BE EF 03 06 00 C7 F6 01 00 B1 30 04 00
70 BE EF 03 06 00 F7 F4 01 00 B1 30 03 00

80 BE EF 03 06 00 67 F5 01 00 B1 30 02 00
90 BE EF 03 06 00 97 F5 01 00 B1 30 01 00

100 BE EF 03 06 00 07 F4 01 00 B1 30 00 00

Get BE EF 03 06 00 34 F4 02 00 B1 30 00 00

Custom User G

Set

50 BE EF 03 06 00 13 F7 01 00 B2 30 05 00
60 BE EF 03 06 00 83 F6 01 00 B2 30 04 00
70 BE EF 03 06 00 B3 F4 01 00 B2 30 03 00
80 BE EF 03 06 00 23 F5 01 00 B2 30 02 00
90 BE EF 03 06 00 D3 F5 01 00 B2 30 01 00

100 BE EF 03 06 00 43 F4 01 00 B2 30 00 00

Get BE EF 03 06 00 70 F4 02 00 B2 30 00 00

(This table is continued to the following page.)

11

RS-232C Communication (continued)

RS-232C Communication (continued)

Command Data Chart

(continued)

Names Operation type Header

Command data

CRC Action Type Setting code

Custom User B

Set

50 BE EF 03 06 00 EF F6 01 00 B3 30 05 00
60 BE EF 03 06 00 7F F7 01 00 B3 30 04 00
70 BE EF 03 06 00 4F F5 01 00 B3 30 03 00
80 BE EF 03 06 00 DF F4 01 00 B3 30 02 00
90 BE EF 03 06 00 2F F4 01 00 B3 30 01 00

100 BE EF 03 06 00 BF F5 01 00 B3 30 00 00

Get BE EF 03 06 00 8C F5 02 00 B3 30 00 00

Color Balance R

Get

BE EF 03 06 00 01 D2 02 00 05 20 00 00

Increment

BE EF 03 06 00 67 D2 04 00 05 20 00 00

Decrement

BE EF 03 06 00 B6 D3 05 00 05 20 00 00

Color Balance R

Reset

Execute

BE EF 03 06 00 94 D3 06 00 05 70 00 00

Color Balance G

Get

BE EF 03 06 00 B5 D7 02 00 12 20 00 00

Increment

BE EF 03 06 00 D3 D7 04 00 12 20 00 00

Decrement

BE EF 03 06 00 02 D6 05 00 12 20 00 00

Color Balance G

Reset

Execute

BE EF 03 06 00 04 DB 06 00 29 70 00 00

Color Balance B

Get BE EF 03 06 00 45 D2 02 00 06 20 00 00

Increment BE EF 03 06 00 23 D2 04 00 06 20 00 00

Decrement BE EF 03 06 00 F2 D3 05 00 06 20 00 00

Color Balance B

Reset

Execute BE EF 03 06 00 D0 D3 06 00 06 70 00 00

Sharpness

Get BE EF 03 06 00 F1 72 02 00 01 22 00 00

Increment BE EF 03 06 00 97 72 04 00 01 22 00 00

Decrement BE EF 03 06 00 46 73 05 00 01 22 00 00

Sharpness Reset Execute BE EF 03 06 00 C4 D0 06 00 09 70 00 00

Color

Get BE EF 03 06 00 B5 72 02 00 02 22 00 00

Increment BE EF 03 06 00 D3 72 04 00 02 22 00 00

Decrement BE EF 03 06 00 02 73 05 00 02 22 00 00

Color Reset Execute BE EF 03 06 00 80 D0 06 00 0A 70 00 00

Tint

Get BE EF 03 06 00 49 73 02 00 03 22 00 00

Increment BE EF 03 06 00 2F 73 04 00 03 22 00 00

Decrement BE EF 03 06 00 FE 72 05 00 03 22 00 00

Tint Reset

Execute BE EF 03 06 00 7C D1 06 00 0B 70 00 00

My Memory Load

Set

1 BE EF 03 06 00 0E D7 01 00 14 20 00 00
2 BE EF 03 06 00 9E D6 01 00 14 20 01 00
3 BE EF 03 06 00 6E D6 01 00 14 20 02 00
4 BE EF 03 06 00 FE D7 01 00 14 20 03 00

My Memory Save

Set

1 BE EF 03 06 00 F2 D6 01 00 15 20 00 00
2 BE EF 03 06 00 62 D7 01 00 15 20 01 00
3 BE EF 03 06 00 92 D7 01 00 15 20 02 00
4 BE EF 03 06 00 02 D6 01 00 15 20 03 00

(This table is continued to the following page.)

12

Command Data Chart

(continued)

Names Operation type Header

Command data

CRC Action Type Setting code

V Position

Get BE EF 03 06 00 0D 83 02 00 00 21 00 00

Increment BE EF 03 06 00 6B 83 04 00 00 21 00 00

Decrement BE EF 03 06 00 BA 82 05 00 00 21 00 00

V Position Reset Execute BE EF 03 06 00 E0 D2 06 00 02 70 00 00

H Position

Get BE EF 03 06 00 F1 82 02 00 01 21 00 00

Increment BE EF 03 06 00 97 82 04 00 01 21 00 00

Decrement BE EF 03 06 00 46 83 05 00 01 21 00 00

H Position Reset Execute BE EF 03 06 00 1C D3 06 00 03 70 00 00

H Phase

Get BE EF 03 06 00 49 83 02 00 03 21 00 00

Increment BE EF 03 06 00 2F 83 04 00 03 21 00 00

Decrement BE EF 03 06 00 FE 82 05 00 03 21 00 00

H Size

Get BE EF 03 06 00 B5 82 02 00 02 21 00 00

Increment BE EF 03 06 00 D3 82 04 00 02 21 00 00

Decrement BE EF 03 06 00 02 83 05 00 02 21 00 00

H Size Reset Execute BE EF 03 06 00 68 D2 06 00 04 70 00 00

Over Scan

Get BE EF 03 06 00 91 70 02 00 09 22 00 00

Increment BE EF 03 06 00 F7 70 04 00 09 22 00 00

Decrement BE EF 03 06 00 26 71 05 00 09 22 00 00

Over Scan Reset Execute BE EF 03 06 00 EC D9 06 00 27 70 00 00

Color Space

Set

AUTO BE EF 03 06 00 0E 72 01 00 04 22 00 00

RGB BE EF 03 06 00 9E 73 01 00 04 22 01 00

SMPTE240 BE EF 03 06 00 6E 73 01 00 04 22 02 00

REC709 BE EF 03 06 00 FE 72 01 00 04 22 03 00
REC601 BE EF 03 06 00 CE 70 01 00 04 22 04 00

Get BE EF 03 06 00 3D 72 02 00 04 22 00 00

Component

Set

COMPONENT BE EF 03 06 00 4A D7 01 00 17 20 00 00

SCART RGB BE EF 03 06 00 DA D6 01 00 17 20 01 00

Get BE EF 03 06 00 79 D7 02 00 17 20 00 00

Video Format

Set

AUTO BE EF 03 06 00 9E 75 01 00 00 22 0A 00
NTSC BE EF 03 06 00 FE 71 01 00 00 22 04 00

PAL BE EF 03 06 00 6E 70 01 00 00 22 05 00

SECAM BE EF 03 06 00 6E 75 01 00 00 22 09 00

NTSC 4.43 BE EF 03 06 00 5E 72 01 00 00 22 02 00

M-PAL BE EF 03 06 00 FE 74 01 00 00 22 08 00
N-PAL BE EF 03 06 00 0E 71 01 00 00 22 07 00

Get BE EF 03 06 00 0D 73 02 00 00 22 00 00

3D-YCS

Set

TURN OFF BE EF 03 06 00 E6 70 01 00 0A 22 00 00

TURN ON BE EF 03 06 00 76 71 01 00 0A 22 01 00

Get BE EF 03 06 00 D5 70 02 00 0A 22 00 00

RS-232C Communication (continued)

RS-232C Communication (continued)

(This table is continued to the following page.)

13

RS-232C Communication (continued)

RS-232C Communication (continued)

Command Data Chart

(continued)

Names Operation type Header

Command data

CRC Action Type Setting code

Video NR

Set

LOW BE EF 03 06 00 26 72 01 00 06 22 01 00

MIDDLE BE EF 03 06 00 D6 72 01 00 06 22 02 00

HIGH BE EF 03 06 00 46 73 01 00 06 22 03 00

Get BE EF 03 06 00 85 73 02 00 06 22 00 00

Auto Adjust Execute BE EF 03 06 00 91 D0 06 00 0A 20 00 00

Auto off

Get BE EF 03 06 00 08 86 02 00 10 31 00 00

Increment BE EF 03 06 00 6E 86 04 00 10 31 00 00

Decrement BE EF 03 06 00 BF 87 05 00 10 31 00 00

Auto Search

Set

TURN OFF BE EF 03 06 00 B6 D6 01 00 16 20 00 00

TURN ON BE EF 03 06 00 26 D7 01 00 16 20 01 00

Get BE EF 03 06 00 85 D6 02 00 16 20 00 00

Blank Color

Set

My Screen BE EF 03 06 00 FB CA 01 00 00 30 20 00

Original BE EF 03 06 00 FB E2 01 00 00 30 40 00

Blue BE EF 03 06 00 CB D3 01 00 00 30 03 00

White BE EF 03 06 00 6B D0 01 00 00 30 05 00

Black BE EF 03 06 00 9B D0 01 00 00 30 06 00

Get BE EF 03 06 00 08 D3 02 00 00 30 00 00

Blank on/off

Set

TURN OFF BE EF 03 06 00 FB D8 01 00 20 30 00 00

TURN ON BE EF 03 06 00 6B D9 01 00 20 30 01 00

Get BE EF 03 06 00 C8 D8 02 00 20 30 00 00

Startup

Set

My Screen BE EF 03 06 00 CB CB 01 00 04 30 20 00

Original BE EF 03 06 00 0B D2 01 00 04 30 00 00

TURN OFF BE EF 03 06 00 9B D3 01 00 04 30 01 00

Get BE EF 03 06 00 38 D2 02 00 04 30 00 00

Menu Position V

Get BE EF 03 06 00 40 D7 02 00 16 30 00 00

Increment BE EF 03 06 00 26 D7 04 00 16 30 00 00

Decrement BE EF 03 06 00 F7 D6 05 00 16 30 00 00

Menu Position V

Reset

Execute BE EF 03 06 00 A8 C7 06 00 44 70 00 00

Menu Position H

Get BE EF 03 06 00 04 D7 02 00 15 30 00 00

Increment BE EF 03 06 00 62 D7 04 00 15 30 00 00

Decrement BE EF 03 06 00 B3 D6 05 00 15 30 00 00

Menu Position H

Reset

Execute BE EF 03 06 00 DC C6 06 00 43 70 00 00

Message

Set

TURN OFF BE EF 03 06 00 8F D6 01 00 17 30 00 00

TURN ON BE EF 03 06 00 1F D7 01 00 17 30 01 00

Get BE EF 03 06 00 BC D6 02 00 17 30 00 00

(This table is continued to the following page.)

14

RS-232C Communication (continued)

RS-232C Communication (continued)

Command Data Chart

(continued)

Names Operation type Header

Command data

CRC Action Type Setting code

Volume

Get BE EF 03 06 00 31 D3 02 00 01 20 00 00

Increment BE EF 03 06 00 57 D3 04 00 01 20 00 00

Decrement BE EF 03 06 00 86 D2 05 00 01 20 00 00

Mute

Set

TURN OFF BE EF 03 06 00 46 D3 01 00 02 20 00 00

TURN ON BE EF 03 06 00 D6 D2 01 00 02 20 01 00

Get BE EF 03 06 00 75 D3 02 00 02 20 00 00

Lamp Time Get BE EF 03 06 00 C2 FF 02 00 90 10 00 00

Lamp Time Reset Execute BE EF 03 06 00 58 DC 06 00 30 70 00 00

Filter Time Get BE EF 03 06 00 C2 F0 02 00 A0 10 00 00

Filter Time Reset Execute BE EF 03 06 00 98 C6 06 00 40 70 00 00

Magnify

Get BE EF 03 06 00 7C D2 02 00 07 30 00 00

Increment BE EF 03 06 00 1A D2 04 00 07 30 00 00

Decrement BE EF 03 06 00 CB D3 05 00 07 30 00 00

Freeze

Set

Normal BE EF 03 06 00 83 D2 01 00 02 30 00 00

Freeze BE EF 03 06 00 13 D3 01 00 02 30 01 00

Get BE EF 03 06 00 B0 D2 02 00 02 30 00 00

Power

Set

TURN OFF BE EF 03 06 00 2A D3 01 00 00 60 00 00

TURN ON BE EF 03 06 00 BA D2 01 00 00 60 01 00

Get

BE EF 03 06 00 19 D3 02 00 00 60 00 00

(Example Return)

00 00 01 00 02 00
(Off) (On) (Cool down)

Input Source

Set

M1-D BE EF 03 06 00 0E D2 01 00 00 20 03 00

RGB BE EF 03 06 00 FE D2 01 00 00 20 00 00

BNC BE EF 03 06 00 3E D0 01 00 00 20 04 00

Video BE EF 03 06 00 6E D3 01 00 00 20 01 00

S-Video BE EF 03 06 00 9E D3 01 00 00 20 02 00

Component BE EF 03 06 00 AE D1 01 00 00 20 05 00

Get BE EF 03 06 00 CD D2 02 00 00 20 00 00

Error Status Get

BE EF 03 06 00 D9 D8 02 00 20 60 00 00

(Example of Return)

00 00 01 00 02 00 03 00

(Normal) (Cover-error) (Fan-error) (Lamp-error)

04 00 05 00 06 00 07 00 08 00

(Temp-error) (Air flow- (Lamp- (Cool-error) (Filter-Error)

error) Time-over)

(This table is continued to the following page.)

15

RS-232C Communication (continued)

RS-232C Communication (continued)

Command Data Chart

(continued)

Names Operation type Header

Command data

CRC Action Type Setting code

PinP Size

Set

Off BE EF 03 06 00 FE 22 01 00 00 23 00 00

Large BE EF 03 06 00 6E 23 01 00 00 23 01 00

Small BE EF 03 06 00 9E 23 01 00 00 23 02 00

Get BE EF 03 06 00 CD 22 02 00 00 23 00 00

PinP Position

Set

Upper Left BE EF 03 06 00 02 23 01 00 01 23 00 00
Upper Right BE EF 03 06 00 92 22 01 00 01 23 01 00
Bottom Left BE EF 03 06 00 62 22 01 00 01 23 02 00
Bottom Right BE EF 03 06 00 F2 23 01 00 01 23 03 00

Get BE EF 03 06 00 31 23 02 00 01 23 00 00

PinP Audio Ch

Set

RGB BE EF 03 06 00 BA 22 01 00 03 23 00 00

Video BE EF 03 06 00 2A 23 01 00 03 23 01 00

Get BE EF 03 06 00 89 22 02 00 03 23 00 00

PinP Input

Set

Video BE EF 03 06 00 D6 22 01 00 02 23 01 00

S-Video BE EF 03 06 00 26 22 01 00 02 23 02 00

Get BE EF 03 06 00 75 23 02 00 02 23 00 00

Myscreen Lock

Set

Off BE EF 03 06 00 3B EF 01 00 C0 30 00 00
On BE EF 03 06 00 AB EE 01 00 C0 30 01 00

Get BE EF 03 06 00 08 EF 02 00 C0 30 00 00

IR Remote Front

Set

Off BE EF 03 06 00 FF 32 01 00 00 26 00 00
On BE EF 03 06 00 6F 33 01 00 00 26 01 00

Get BE EF 03 06 00 CC 32 02 00 00 26 00 00

IR Remote Rear

Set

Off BE EF 03 06 00 03 33 01 00 01 26 00 00
On BE EF 03 06 00 93 32 01 00 01 26 01 00

Get BE EF 03 06 00 30 33 02 00 01 26 00 00

IR Remote Top

Set

Off BE EF 03 06 00 47 33 01 00 02 26 00 00
On BE EF 03 06 00 D7 32 01 00 02 26 01 00

Get BE EF 03 06 00 74 33 02 00 02 26 00 00

(This table is continued to the following page.)

16

RS-232C Communication (continued)

RS-232C Communication (continued)

Names Operation type Header

Command data

CRC Action Type Setting code

Power Up Source

Set

Last Ch BE EF 03 06 00 9E D9 01 00 18 20 10 00

M1-D BE EF 03 06 00 AE D4 01 00 18 20 03 00

RGB BE EF 03 06 00 5E D4 01 00 18 20 00 00
BNC BE EF 03 06 00 9E D6 01 00 18 20 04 00

Component BE EF 03 06 00 0E D7 01 00 18 20 05 00

S-Video BE EF 03 06 00 3E D5 01 00 18 20 02 00

Video BE EF 03 06 00 CE D5 01 00 18 20 01 00

Get BE EF 03 06 00 6D D4 02 00 18 20 00 00

Auto Adjust Enable

Set

DISABLE BE EF 03 06 00 A2 D5 01 00 19 20 00 00

ENABLE BE EF 03 06 00 32 D4 01 00 19 20 01 00

Get BE EF 03 06 00 91 D5 02 00 19 20 00 00

Internal Speaker

Set

TURN OFF BE EF 03 06 00 6E D5 01 00 1C 20 00 00

TURN ON BE EF 03 06 00 FE D4 01 00 1C 20 01 00
Get BE EF 03 06 00 5D D5 02 00 1C 20 00 00

Lens Lock

Set

TURN OFF BE EF 03 06 00 FF 97 01 00 10 24 00 00

TURN ON BE EF 03 06 00 6F 96 01 00 10 24 01 00
Get BE EF 03 06 00 CC 97 02 00 10 24 00 00

Remote ID

Set

All BE EF 03 06 00 9F 30 01 00 08 26 00 00

1 BE EF 03 06 00 0F 31 01 00 08 26 01 00
2 BE EF 03 06 00 FF 31 01 00 08 26 02 00
3 BE EF 03 06 00 6F 30 01 00 08 26 03 00

Get BE EF 03 06 00 AC 30 02 00 08 26 00 00

Lens

Set

AUTO BE EF 03 06 00 3F D8 01 00 70 25 00 00

1 BE EF 03 06 00 AF D9 01 00 70 25 01 00
2 BE EF 03 06 00 5F D9 01 00 70 25 02 00
3 BE EF 03 06 00 CF D8 01 00 70 25 03 00
4 BE EF 03 06 00 FF DA 01 00 70 25 04 00
5 BE EF 03 06 00 6F DB 01 00 70 25 05 00

Get BE EF 03 06 00 0C D8 02 00 70 25 00 00

Command Data Chart

(continued)

Hitachi, Ltd. Tokyo, Japan

International Sales Division

THE HITACHI ATAGO BUILDING,

No. 15 –12 Nishi Shinbashi, 2 – Chome,

Minato – Ku, Tokyo 105-8430, Japan.

Tel: [phone]

HITACHI EUROPE LTD,

Whitebrook Park
Lower Cookham Road
Maidenhead
Berkshire
SL6 8YA

UNITED KINGDOM

Tel: [phone]
Fax: [phone]
Email: [e-mail]

HITACHI EUROPE GmbH

Munich Office
Dornacher Strasse 3
D-85622 Feldkirchen bei München

GERMANY

Tel: [phone]
Fax: [phone]
Hotline: [phone] (12ct/min)
Email: [e-mail]

HITACHI EUROPE srl

Via Tommaso Gulli N.39, 20147
Milano, Italia

ITALY

Tel: [phone]
Tel: [phone] Servizio Clienti
Fax: [phone]

Email: [e-mail]

HITACHI EUROPE S.A.S

Lyon Office
B.P. 45, 69671 BRON CEDEX
FRANCE
Tel: [phone]
Fax: [phone]
Email: [e-mail]

HITACH EUROPE AB

Egebækgård
Egebækvej 98
DK-2850 Nærum

DENMARK

Tel: [phone]
Fax: [phone]
Email: [e-mail]

Hitachi Europe Ltd

Bergensesteenweg 421
1600 Sint-Pieters-Leeuw

BELGIUM

Tel: [phone]
Fax: [phone]
Email: [e-mail]

www.hitachidigitalmedia.com

HITACHI EUROPE S.A.

364 Kifissias Ave. & 1, Delfon Str.
152 33 Chalandri
Athens

GREECE

Tel: [phone]
Fax: [phone]
Email: [e-mail]

HITACHI EUROPE S.A.

Gran Via Carlos III, 86, planta 5
Edificios Trade - Torre Este
08028 Barcelona

SPAIN

Tel: [phone]
Fax: [phone]
Email: [e-mail]

HITACHI Europe AB
Box 77 S-164 94 Kista

SWEDEN

Tel: [phone]
Fax: [phone]
Email: [e-mail]

HITACHI EUROPE LTD (Norway) AB
STRANDVEIEN 18
1366 Lysaker
NORWAY
Tel: [phone]
Fax: [phone]
Email: [e-mail]

HITACHI EUROPE AB

Neopoli / Niemenkatu 73
FIN-15140 Lahti

FINLAND

Tel : [phone]
Fax: [phone]
Email: [e-mail]

HITACHI EUROPE LTD

Na Sychrove 975/8
101 27 Pr aha 10 – Bohdalec

CZECH REPUBLIC

Tel: [phone]
Fax: [phone]
Email: [e-mail]
