Hitachi CML155XW User Manual

COLOUR/COLOR LCD MONITOR

MANUEL D’UTILISATION

BEDIENUNGSANLEITUNG

MANUAL DE USUARIO

CML155XW

MANUALE DI ISTRUZIONI

USER MANUAL

THE INSTRUCTIONS INSIDE CAREFULLY.

READ
KEEP THIS USER MANUAL FOR FUTURE REFERENCE.

For future reference, record the serial number of your colour monitor.

SERIAL No.

The serial number is located on the rear of the monitor.

This monitor is E

computer equipped with VESA DPMS.

NERGY STAR

The E

of any product or service.

NERGY STAR

E

As an

product meets the E

NERGY STAR

®

emblem does not represent EPA endorsement

®

Partner, Hitachi, Ltd. has determined that this

NERGY STAR

®

compliant when used with a

®

guidelines for energy efficiency.

)

(

)

Limited Warranty for USA Customers Only

Hitachi America, Ltd. warrants our Hitachi CRT color monitor to be free from defects in
material and workmanship for 36 months from the date you purchased it if your
purchase was made prior to 1/31/01 or 60 months if your purchase was made after
1/31/01 from your authorized Hitachi America, Ltd. dealer.
If you purchase a Hitachi Liquid Crystal Display (LCD) color monitor, Hitachi provides a
warranty of 36 months for the panel and 12 months for the backlight if purchased before
1/31/01 or 36 months for both panel and backlight if purchased after 1/31/01. In the
event of a defect during this 12 month, 36 month or 60 month period, Hitachi America,
Ltd. will, at its option, repair or replace the monitor at no charge except as set forth
below. If proof of purchase cannot be provided by owner, the warranty period will start to
run from the date of manufacture.

Hitachi America, Ltd. may repair your monitor with new or reconditioned parts or replace
it with a new or reconditioned monitor of the same or similar kind, and any replaced
monitors or parts become Hitachi America, Ltd.'s property.

Exclusions from this warranty:

LCD display backlights to decrease in brightness as they age. This is a natural process
in CRTs & LCDs due to the degradation of the LCD backlight and the degradation of the
CRT phosphors that create the image and is not covered by this warranty. This warranty
excludes decreased image clarity or reduced brightness due to natural aging of the
monitor/display. In addition, this warranty does not cover phosphor burn. Phosphor burn
can occur when a monitor is left with one static image for extended periods of time
during which the image may become burned into the phosphors.

This limited warranty does not cover damage occurring in shipping or in storage after
you purchase the monitor or damage caused by abuse, accident, disaster, misuse,
mishandling, mispackaging or shipping, improper installation, unauthorized repair or
modification, or failure to follow the manufacturer's instruction with respect to the proper
handling, operation, installation, service and maintenance of the monitor.

To obtain warranty service, call 1-800-536-6721 to obtain a return authorization and the
location of your Hitachi service center or return the monitor to the dealer from whom you
bought it (subject to that dealers' return policy). If you choose to ship the monitor
rather than delivering it in person, you must assume the risk of damage or loss in transit.
You must also use the original shipping container (or equivalent packaging), pay
shipping charges, and enclose a copy of the proof of purchase date with the monitor.
For additional information, please write to:

Hitachi America, Ltd.
200 Lowder Brook Drive, Suite 2200, Westwood, MA 02090

NEVER open the monitor cabinet. If the monitor is not operating properly, contact
Hitachi America Ltd. service center (Call 1-800-536-6721).
Do not open the monitor housing under any circumstances. By opening the monitor
housing you will expose yourself to high voltage and possible severe electrical shocks
and void all warranties.

It is normal for Cathode Ray Tube (CRT) monitors and

ENGLISH

1

ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE ON THIS MONITOR IS LIMITED TO THE 12, 36 or 60
MONTH DURATION OF THIS WRITTEN WARRANTY, AS APPLICABLE. ALL
WARRANTIES SET FORTH IN THIS WARRANTY ARE LIMITED TO 12, 36 OR 60
MONTHS FROM THE DATE OF PURCHASE. NO WARRANTIES WHATSOEVER
WILL COVER THIS MONITOR BEYOND THE STATED 12, 36 OR 60 MONTHS.
HOWEVER, SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO
YOU.

IF THIS MONITOR IS DEFECTIVE, YOUR ONLY REMEDY IS REPAIR OR
REPLACEMENT, AS DESCRIBED ABOVE. UNDER NO CIRCUMSTANCES WILL
HITACHI AMERICA, LTD. BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES, INCLUDING ANY LOST SAVINGS, LOST PROFITS, OR ANY OTHER

ENGLISH

DAMAGES CAUSED BY THE USE OF THIS MONITOR OR INABILITY TO USE IT,
EVEN IF THE DEALER OR HITACHI AMERICA, LTD. HAS BEEN ADVISED OF SUCH
LIABILITY OR OTHER CLAIMS.

SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES SO THE ABOVE LIMITATION OR EXCLUSION
MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY HAVE OTHER RIGHTS WHICH VARY STATE TO STATE.

THIS WARRANTY APPLIES TO NEW, CURRENT, PRODUCTS ONLY AND
DOES NOT APPLY TO PRODUCTS SOLD AFTER THEY ARE
DISCONTINUED OR REFURBISHED.

For Canadian Customers only Warranty Policy

Hitachi Industrial Products are guaranteed to be free from defects in workmanship and
material. If any failure, resulting from either workmanship or material defects should
occur under normal and proper usage within the period stated hereunder from the
original provable date of purchase, such failure should be repaired at no cost to the
buyer for labor and parts if the defective product is brought to an AUTHORIZED
HITACHI SERVICE CENTRE in Canada.

WARRANTY PERIOD

COMPUTER MONITOR 3 year parts and 3 year labour

WARRANTY DOES NOT COVER

1. Products received for repair without sales or delivery receipt showing date of
purchase by original customer.

2. Damages caused by incorrect use, carelessness, unauthorized alteration, improper
storage or unauthorized service or repairs.

3. Damages caused by fire, flood, lightning, vandalism, collision, acts of God, or other
events beyond the control of Hitachi.

2

)

(

)

4. External parts such as cabinet.

5. Products purchased outside Canada.

6. Products used outside Canada.

7. In transit damage claims, improper handling by carrier or post offices.

8. Products or parts there of which have serial numbers removed, altered or defaced.

9. Damage defect or failure caused by, or resulting from, the operation of the unit by
incorrect voltages.

10. The use of components that do not meet Hitachi specifications.

11. Products sold in Canada by another organization which is not authorized by
HITACHI CANADA LTD

12. Picture tube damages resulting from extended exposure of the video characters.

IMPORTANT : This warranty is in lieu of all other warranties, guarantees or agreements
whether expressed or implied and no person, dealer, or Company is authorized to
change, modify, or extend its terms in any manner whatsoever.

Hitachi Canada Inc. shall not be responsible for any damages or loss of any kind
attributed to the product rendered defective during usage, or attributed to incompatibility
problems of any linked equipment including software.

NEVER open the monitor cabinet. If the monitor is not operating properly, contact Hitachi
Service Center. DO NOT open the monitor housing under any circumstances. by
opening the monitor housing you will expose yourself to high voltage and possible
severe electrical shocks, and void all warranties.

HITACHI CANADA LTD.

For service, please call your Dealer or your 1-800-HITACHI.

TORONTO

6740 Campobello Road, Mississauga, Ont. L5N 2L8
Tel.: [phone]
Fax No.: [phone]

ENGLISH

3

Colour/Color Monitor

CML155XW USER MANUAL

Congratulations on your selection of the HITACHI Colour Monitor.

Read the instructions inside carefully, and keep this user manual for future reference.

ENGLISH

NOTE:

* The information in this manual is subject to change without notice. The manufacturer

assumes no responsibility for any errors that may appear in this manual.

* The reproduction, transmission or use of this documents or contents is not permitted

without express written authority.

TRADEMARK ACKNOWLEDGEMENT:

VGA is a registered trademark of International Business Machines Corporation.
VESA is a trademark of a nonprofit organisation, Video Electronics Standard Association.

NERGY STAR

E

®

is a trademark of Environmental Protection Agency (EPA).

CONTENTS

Introduction ............................................................................................. 6

Features ................................................................................................................... 6

Using This Display Safely ......................................................................................... 7

Warning................................................................................................................. 8

Caution.................................................................................................................. 11

FCC Statement Warning............................................................................................. 13

For the Customers in CANADA .................................................................................. 13

For the Customers in the UK ...................................................................................... 14

Installation .............................................................................................. 15

Unpacking the Display .............................................................................................. 15

Locations and Functions of Controls ........................................................................ 15

Making the Connections ........................................................................................... 16

Using Your Display ................................................................................. 18

Turning the Display On and Off .................................................................................. 18

Tilting the Display ..................................................................................................... 19

Setting the Video Mode ............................................................................................ 19

4

)

(

)

Setting the Refresh Rate .......................................................................................... 19

Minimizing Power Consumption ............................................................................... 20

Caring for and Cleaning the Display ......................................................................... 20

Adjusting Your Display ........................................................................... 21

Summary of Control Buttons .................................................................................... 21

Displaying the OSD “Main Menu” ............................................................................. 21

Selecting Items in the OSD Menu ............................................................................. 22

Doing Adjustment in the OSD Menu ......................................................................... 22

Using the Direct Keys ............................................................................................... 27

Troubleshooting ...................................................................................... 29

Technical Information ............................................................................. 30

Display Information ................................................................................................... 30

Video Modes ............................................................................................................. 31

Unknown Video Modes ............................................................................................. 32

ENGLISH

5

Introduction

This latest LCD monitor has a 15-inch active matrix TFT (thin film transistor) liquid
crystal display module. It is designed for use with any Windows
monitor’s compact-sized design provides great space savings on your computer desk.

®

-based PC. The

Features

ENGLISH

Important features include:

Ö Automatic configuration to the PC video settings with maximum XGA resolution.

Ö Three control buttons plus OSD (on-screen display) for monitor settings adjustment

and configuration with ease and instant feedback.

Ö Support analog and digital video input for direct and immediate replacement of CRT

displays.

Ö Build-in speakers, microphone and earphone jack.

Ö A tilt feature to optimize viewing position.

Ö An anti-glare coating on the panel to reduce the reflection of ambient light.

Ö Flicker-free performance across all recommended video modes.

Ö Support for high refresh rates up to 75 Hz.

Ö VESA DDC2B Plug-and-Display compliant.

Ö

A Power-saving feature that is compatible with Microsoft

Ö Compliance with Swedish MPR II guidelines for reduced electromagnetic emissions.

Ö Compliance with TCO95.

®

Windows

6

)

(

)

Using this Display Safely

Common Safety Precautions

Please read carefully and make sure you fully understand the following safety
precautions:

Operations should be done according to instructions and procedures described in

-

this manual.

Make sure to heed all warnings displayed on the device and manual. Neglecting to

-

do so may result in fire or damage the device.

Symbols

Safety notifications are presented as shown below. These are indicated by “Warning”
and “Caution” in combination with a caution symbol (graphic symbol). Additionally,
details are depicted within the graphic symbols.

Warning

Caution

Handling and Operation

Do not handle or operate in ways other than what is depicted in the manual. If there are
any problems with the device, turn OFF the power, unplug the cord then notify the dealer
where the product was purchased or call a service person.

Taking ample care

The cautions noted on the device and manual have been carefully considered. Even so,
unforeseen incidents may happen. When operating the device, in addition to following
instructions, takes ample care during handling and operation.

This symbol is used to indicate a hazard that may result in death
or grave injury.

This symbol is used to indicate a hazard that may result in minor
injury or significant damage to the product

[ Notice example 1] Shock Caution

This (Ì) symbol indicates that caution should be taken and within
the triangle (Ì) is a picture depicting “Shock caution”.

[Notice Example 2] Disassembly Prohibited

In the ( [ ) barred circle is an action that must not be done and
the picture in this ( [ ) one depicts “Disassembly Prohibited”.

[Notice Example 3] Unplug power Cord from Socket

In the (z) symbol is an action that should be taken. This (z) one
is a picture depicting “ Unplug Power Cord from Socket’ and other
mandatory actions.

ENGLISH

7

Warning

Abnormal heat, smoke, sounds or smells.

If anything abnormal should happen, turn OFF the power and unplug the power
cord. Continued use in this condition may lea

around the cord should be clear to allow the cord to be easily unplugged.

d to electrical shock or fire. The area

Repair, Modification, Disassembly

DO NOT attempt to repair, modify or disassemble the product. This may result

ENGLISH

in fire or electrical shock.

Air vents

The air vents are to prevent the internal temperature from rising. To not place items

-

on or so that they block the air vents. Also do not place in racks where the air vents
will be blocked. This will cause the internal temperature to rise and result in fire or
malfunction.

Do place on racks that fix the display in leaning position. This will change the flow of

-

air through the air vents and cause the internal temperature to rise resulting in fire
or malfunction.

Placing Objects in Device

DO NOT put paper clips, pins, metallic objects or combustible items in the ventilation
holes. Using the device in this condition may result in electrical shock or fire.

Removing the Case Cover

DO NOT remove the case cover. There are many high voltage parts inside and are very
dangerous.

Placing Objects on the Device

DO NOT put flower vases, planters, vessels containing water, pins and paper clips or
other metal items on the device. If anything should fall in, using the product in this
condition may result in electrical shock.

8

)

(

)

Handling of the power cord

Use the power cord supplied with the product and be careful of the following during use.
If handled improperly, the cord may be damaged resulting in electrical shock or fire.

Never place objects on it.

DO NOT pull

-

DO NOT apply pressure

-

DO NOT fold

-

DO NOT wrap

-

DO NOT use next to heating device

Plugging and Unplugging

When plugging or unplugging the power cord in the socket, make sure to hold the

-

plug. Pulling on the power cord may cause a partial breakage resulting in fire.

When taking a holiday or vacation and leaving the device unused for prolonged

-

periods, unplug the power cord. Leaving it plugged in may result in fire.

When unplugging or plugging in the power cord, insure that your hands are dry.

-

Handling with wet hands may result in electrical shock.

Poor Electrical Contact in Electric Plug, etc.

The following must be done to prevent bad contact in the electrical plug that may result
in fire.

Insure that electric plug is inserted in fully.

-

-

Check to see if there is no dust accumulated on the plug before plugging in.

DO NOT use a socket that is loose or wobbles.

-

Impact from Dropping

To not drop, bang or subject to physical shock. Using after such incidents may result in
electrical shock or fire.

Power Usage

The usable voltage is 100-120V / 200-240VAC. DO NOT use any other voltage. This
may result in electrical shock or fire.

ENGLISH

9

Handling the AC adapter

DO NOT wet or handle with wet hands. This may result in electrical shock.

-

DO NOT use with devices other than this display. This may result in shock, fire, or

-

damage to the device.

DO NOT use or place in areas where heat accumulates. This may result in fire.

-

Multi-Tap Usage

TO not attach multiple extension plugs into one outlet. This may result in fire and
overloading lines will activate the circuit breakers causing data loss or damage to the
product.

ENGLISH

Usage in Humid or Dusty Areas

DO NOT use or store in areas that are humid, dusty or have abundant moisture such as
a bathroom. This may cause fire or electrical shock.

Moving to Areas of Different Temperature

Moving the device to areas that are very different in temperature may cause
condensation on the outside and internally. Using the device in this condition may result
in fire or electrical shock. Leave the device at the location for a few hours before using.

Aluminium Electrolysis Condenser

The electrolyte condenser used in the AC adapter has a limited life. If used past the life
span (approximately 5 years), replace the AC adapter. Leakage or drying up of the
electrolyte liquid may result in fire, electrical shock. This may also cause the device itself
to malfunction.

Damage to the Display Unit

-

Liquid may leak out of the display when damaged. DO NOT touch the liquid. If you
should touch the liquid, wash your hands thoroughly with water. If the liquid should
get into your mouth or eyes, gargle or rinse your eyes and promptly see a doctor for
treatment.

The display unit is made of glass. If the display unit should break, avoid handling

-

the glass fragments. The fragments are dangerous and can cause injury.

10

)

(

)

CAUTION

Contact with Metal and Other Edges

When moving the computer be careful when coming in contact with the plastic and metal
edges. It is possible to be injured.

Use in Unstable Places

DO NOT place on sloping or narrow areas that are unstable. The device may drop or fall
and cause injury.

Display Cable

Arrange the cables so that they are out of the way. If a cable is tripped on, it may

-

cause injury and damage to the connected devices.

-

DO NOT place heavy objects on the cable. Additionally, do not place objects that
generate heat near the cables. The cable casing may break and cause damage to
the devices that are connected.

Stand

-

When adjusting the angle, hold the top left and right edges with both hands and
move slowly. Using only one hand may cause it to fall.

DO NOT place your hand near the stand when adjusting the LCD forward or back.

-

Your fingers may get caught and cause injury.

Eyestrain

When continuously looking at the display while working, keep the work area lighted at
300 – 1000 Lexes. Additionally, for every hour of work, rest 10 to 15 minutes.
Continuously looking at the display for prolonged periods will cause accumulated eye
fatigue.

Disposal of this Product

When disposing of this product, confer with the dealer where this product was
purchased or refer to laws of the local government or regulations regarding disposal.

ENGLISH

11

Electronic Interference

If used in the vicinity of other electronic devices, they may interfere with each other’s
performances. Especially for devices such as radios and televisions, noise may enter
their sound reception. If this should happen, try the following:

Place in a location as far away from radios and televisions as possible.

-

-

Change the facing of the antenna on the radio or television.

-

Use a different electrical socket.

ENGLISH

Storing the Plastic Bag

Keep the plastic bag used to wrap the display away from young children. The bag may
cause suffocation.

12

FCC Statement Warning

WARNING : This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:

Reorient or relocate the receiving antenna.

-

-

Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.
Consult the dealer or an experienced radio / TV technician for help.

-

INSTRUCTIONS TO USERS : This equipment complies with the requirements of FCC
(Federal Communication Commissio n) equip ments provided that following conditions are met.

(1) Power cord: Unshielded power cord must be used.
(2) Video inputs: The input signal amplitude must not exceed the specified level.

GLISH
EN

CAUTION : Changes or modifications not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

For the Custom ers in CANADA

NOTICE : This C lass B digital apparatus complies with Canadian ICES-003.

13

For the Customers in the UK

THIS PRODUCT IS SUPPLIED WITH A TWO PIN MAINS PLUG FOR USE IN
MAINLAND EUROPE. FOR THE UK PLEASE REFER TO THE NOTES ON THIS
PAG E.

IMPORTANT FOR UNITED KINGDOM

WORDING FOR CLASS IIII EQUIPMENT INSTRUCTION BOOKS AND LABELS

The mains lead on this equipment is supplied with a moulded plug incorporating a fuse,
the value of which is indicated on the pin face of the plug. Should the fuse need to
be replaced, an ASTA or BSI approved BS 1362 fuse must be used of the same rating.
If the fuse cover is detachable never use the plug with the cover omitted. If a

ENGLISH

replacement fuse cover is required, ensure it is of the same colour as that visible on the
pin face of the plug. Fuse covers are available from your dealer.

DO NOT cut off the mains plug from this equipment. If the plug fitted is not suitable for
the power outlets in your home or the cable is too short to reach a power outlet, then
obtain an appropriate safety approved extension lead or consult your dealer.

Should it be necessary to change the mains plugs, this must be carried out by a
competent person, preferably a qualified electrician.

If there is no alternative to cutting off the mains plug, ensure that you dispose of it
immediately, having first removed the fuse, to avoid a possible shock hazard by
inadvertent connection to the mains supply.

WARNING: THIS EQUIPMENT MUST BE EARTHED

IMPORTANT
The wires in the mains lead are coloured in accordance with the following code:

Green and Yellow = Earth, Blue = Neutral, Brown = Live.

As these colours may not correspond with the coloured markings identifying the
terminals in your plug, proceed as follows:

The wire which is coloured GREEN and YELLOW must be connected to the terminal in
the plug which is marked with the letter E or by the earth symbol

GREEN or GREEN and YELLOW.

The wire coloured BLUE must be connected to the terminal marked with the letter N or

coloured BLUE or BLACK. The wire coloured BROWN must be connected to the
terminal marked with the letter L or coloured BROWN or RED

or coloured

14

Installation

Please follow the instructions in this chapter to install your LCD Monitor.

Note:

Before connecting your display, first read through the instructions in this

chapter and the safety precautions in the previous chapter.

Unpacking the Display

When you are unpacking the display, make sure that you have the following items:

Ö The LCD monitor

Ö AC power adapter with attached power cable

Ö A power cord

Ö Analog video signal cable

Ö Digital video signal cable

Ö Audio-mic cable

Ö The User’s Manual

Note: Place the display on a flat, sturdy surface. Choose an area free from

excessive heat, moisture, and sunlight.

ENGLISH

Locations and Functions of Controls

There are three control buttons and one power button on the front panel of the display, as
well as a LED for power status indication.

15

ENGLISH

You will use the power button located at the lower right side of the front panel of your
display to turn on and off the display.

The functions of the three control buttons, which are located at the lower middle-left side of
the front panel of your display, are described as below:

Button Function Description

Select

(1) Bring-up OSD Main Menu.

(2) Select item for user adjustment.

Right ( )

(1) Item selection move upward or user-adjustable value

increasing (in main menu).

(2) Bring-up Audio/Source Menu (Direct-key function).

Left ( )

(1) Item selection move downward, user-adjustable value

decreasing (in Main Menu) .

(2) Auto Setup (Direct-key function, Analog input signal only).

Making the Connections

Before connecting any cables, make sure that the computer and display are turn off.

To connect the power and video signal cables:

1. Locate the AC power adapter with attached power cable.

2. Connect the power cable to the power jack on the back of the display (“DC IN” as shown
below).

3. Plug the three-prong power cord into a power outlet, and plug the other end into the AC
power adapter.

16

4. Plug the analog (or digital) video signal cable into the Analog (or Digital) Video Input
port on the back of the display (“ANALOG IN” (or “DIGITAL IN”) as shown above).

5. Connect the other end of the video cable into your computer’s video port. (Please check
your computer’s documentation if you’re not sure where the port is located.)

6. Connect the audio-mic cable (green) from “AUDIO1” port of the display to the line-out
port of your PC and connect other wire (red) from “MIC” port of the display to the line-in
port of your PC.

Note: For best display performance, it is strongly recommended that you use Auto

Setup to automatically configure your display’s settings (only for Analog
input).

ENGLISH

17

Using Your Display

ENGLISH

This chapter contains information about using your LCD Monitor.

Turning the Display On and Off

Use the power button located at the lower right side of the front panel of the display to turn
the display on and off. When the display is on, the light (LED) near the Power button is
illuminated. The light is green when both the display and PC are active and amber when
the display is in a reduced power mode.

If your PC supplies power saving signals to the display, the display’s power management
features reduce power consumption to low levels when your PC goes into its
power-saving mode. See “Minimizing Power Consumption” on page 20 for more
information.

If your PC doesn’t use industry standard power-save signaling techniques, you can
reduce power consumption by turning off the display when it won’t be used for an
extended period. You can turn the display off even if you leave your PC in running.

Note:

Because of the technology used in LCD panels, screen savers will not

prolong the life of your display. So if the display will not be used for an
extended period, be sure to turn it off.

18

Warning

To completely disconnect power from your display, you must remove
the power cord from the wall outlet and then remove the power cable
from the display.

Tilting the Display

The monitors have a tilt feature that allows you to tilt the display back and forth as well as
left and right to find the most comfortable viewing position. To tilt the display, grasp the
sides and push the display back or pull it toward you, or turn it left or right until it is in the
desired position. The display can be tilted 20º backward and 5º forward or 60º left and 60º
right.

ENGLISH

Note: Do not tilt the display by grasping the top edge.

Setting the Video Mode

Since the inherent format of this display is 1024 pixels by 768 lines, the display will
perform best when your PC is set to a screen resolution of 1024 x 768. If you use a lower
resolution (such as 640 x 480), the image is expanded to fill the screen

Your display supports many common video modes, as shown in “Video Modes” on page

31. Check the documentation supplied with your PC and video adapter card to find out

which modes they support.

To see what the video mode in your Microsoft Windows, please check Windows’ settings
in your PC.

Setting the Refresh Rate

The image refresh rate is the number of times per second that the image is refreshed; it is
also known as the vertical frequency.

On standard CRT displays, we recommend that you should use the highest possible
refresh rate supported by your PC at the current screen resolution. This is necessary to
avoid screen flickering and to minimize eyestrain. However, with your LCD Monitor, flicker
is not an issue. It is flick-free at all supported refresh rates.

19

ENGLISH

The table in “Video Mode” on page 31shows the image refresh rates supported by the
display at different screen resolution. Although your LCD monitor supports up to 75 Hz for
analog video input, we recommend that you use

To set the refresh rate with a standard Windows installation, follow the steps mentioned in
your Windows’s or graphic card’s user’s manual.

60 Hz

refresh rate for best performance.

Minimizing Power Consumption

Many PCs support industry standard power-save signaling techniques. Power
management features reduce the display’s power consumption after a period of keyboard
inactivity.

When the display is in a power-saving mode, the screen is blank and the power indicator
is amber. Pressing a key on the keyboard or moving the mouse restores the image in
several seconds. Consult your PC documentation for information about setting the
power-saving modes.

The display accepts the signals for the three standard power-saving modes – Standby,
Suspend, and Sleep. For any of these conditions, the display will go into Sleep mode.

Caring for and Cleaning the Display

To maximize screen life and prevent damage to the LCD panel, we recommend that you:

Ö Use the display power management system (if available on your PC).
Ö If you don’t use a power management system, turn off the display when you won’t be

using it for an extended period.

Ö Don’t press, rub, or poke the display with your finger or other object.
Ö Handle your display with care.

Your LCD module is a high-quality optical device that requires special care when
cleaning.

Warning

Don’t use liquid, aerosol, or abrasive cleaning solutions to
clean the screen.

To clean the screen:

1. Shut down the PC.

2. Turn off and unplug the display.

3. Gently dust the screen with a dry, soft, line-free cloth.

Note: If the screen is still dirty, you can dampen the cloth with several drops of

distilled water. Make sure the LCD panel is completely dry before you turn
the display back on.

4. Plug in the display.

5. Turn on your PC and display.

20

Adjusting Your Display

This chapter contains information about how to changing display settings for your LCD
Monitor. It is designed with an OSD menu to help you easily adjust to its optimum
performance.

Note: You must perform auto setup before making any adjustment.

Summary of Control Buttons

There are three control buttons located at the lower part of the front panel of your display:

Ö Select: Display the On-Screen Display (OSD) “Main Menu” and selects items for user

adjustment.

Note: Hold down this key for 2 seconds will clear OSD menu.

Ö Right( ): Move upward through the choice in the OSD submenu. If an adjustment

bar is displayed, this button increases the setting value.

Note: This key is also used as ‘direct key’ to bring-up OSD “Audio/Source”.

ENGLISH

Ö Left( ): Move downward through the choice in the OSD submenu. If an adjustment

bar is displayed, this button decreases the setting value.

Note: This key is also used as ‘direct key’. When the OSD “Main Menu” is inactive,

press this key will bring-up ‘Auto Setup’ submenu.

Displaying the OSD “Main Menu”

You can use the OSD features to change the screen settings of your display. To display
the OSD “Main Menu”, please press the ‘Select’ button.

Brightness

•

•

100

21

The following table briefly describes each of the items in the OSD “Main Menu”.

ENGLISH

Item Description

Brightness Controls the brightness of the display by adjusting the light output of the

backlight. The default setting of brightness is at maximum.

Contrast Adjust the level of difference between light and dark areas of the image.

you can use the Contrast item to adjust the contrast which your likes. The
default setting of contrast is at 50.

Display

Color

Clock/Phase

Management

Open the “Display” submenu where you can select horizontal (H.) or
vertical (V.) position for further adjustment.

Open the “Color” submenu where you can select Color Temperature,
Luminance, Hue, and Color for further adjustment. See “Doing
Adjustment in the OSD Menu” on page 22.

Open the “
select Clock or Phase for further adjustment.

Open the “Management” submenu where you can select to display mode
information (Mode Info), select OSD Display, select scale/center, choose
language you preferred, select input signal (source), and recall factory
settings for further adjustment. See “Doing Adjustment in the OSD Menu”
on page 22.

Clock/Phase

” submenu where you can do Auto Setup or

Selecting Items in the OSD Menu

To select items in the OSD “
panel of the display.

To select items in the OSD submenus, you will use all three control buttons. To select a
specific submenu, you shall use ‘
corresponding to that submenu. Then you can choose any item in that submenu by using

Right

‘

’ or ‘

Left

’ buttons, and then select it by press ‘

Main Menu

Select

”, you will use the ‘

’ button to move forward to the item

Select

Select

’ button.

’ button on the front

Doing Adjustment in the OSD Menu

Adjusting the Brightness Setting

To adjust Brightness setting you should follow the steps below:

1. Bring-up the OSD “Main Menu”.

2. The brightness icon should be highlighted (to red) already.

3. Use ‘

100. ‘Right’ button will increase the Brightness setting and ‘Left’ will decrease it.

22

Right

’ and ‘

Left

’ buttons to adjust its value. The range for adjustment is from 0 to

Adjusting the Contrast Setting

To adjust Contrast setting you should follow the steps below:

1. Bring-up the OSD “

2. Use ‘Select’ button to move forward to the contrast icon and highlight it.

3. Use ‘Right’ and ‘Left’ button to adjust its value. The range for adjustment is from 0 to

100. ‘Right’ button will increase the Contrast setting and ‘Left’ will decrease it.

Adjustment in the “Display” submenu

To adjust Display settings you should follow the steps below:

1. Bring-up the OSD “

2. Use ‘Select’ button to move forward to ‘Display’ icon and highlight it. This will bring-up

Display

the “
Position and V. Position.

3. Use ‘

highlight and select it.

If ‘Exit’ is selected, it will exit the “
“Main Menu”. (i.e., Color icon.)

If ‘H. Position’ is selected, then you can adjust it by ‘Right’ and ‘Left’ buttons. ‘Right’
button will move the image to the right and ‘Left’ button will move the image to the left.

Right

” submenu. There are three items for your choice in this submenu: Exit, H.

’ and ‘

Main Menu

Main Menu

Left

’ keys to choose the item you need and then press ‘

”.

”.

Display

” submenu and forward to the next item in the

Select

’ to

ENGLISH

If ‘V. Position’ is selected, then you can adjust it by ‘Right’ and ‘Left’ buttons. ‘Right’
button will move the image upward and ‘Left’ button will move the image downward.

Display

Exit

H. Position

V. P o s i t i o n

Adjustment in the “Color” submenu

To adjust Color settings you should follows the steps below:

1. Bring-up the OSD “Main Menu”.

2. Use ‘Select’ button to move forward to ‘Color’ icon and highlight it. This will bring-up

Color

the “
Temp, Luminance, Hue, and Color.

” submenu. There are five items for your choice in this submenu: Exit, Color

3. Use ‘

highlight and select it.

Right

’ and ‘

Left

’ buttons to choose the item you need and then press ‘

Select

’ to

23

ENGLISH

Color

Exit

Color Temp

Luminance

Hue

Color

If ‘Exit’ is selected, it will exit the “Color” submenu and forward to the next item in the
“Main Menu”. (i.e., Clock/Phase icon.)

If ‘Color Temperature’ is selected, it will bring-up “Color Temp” submenu. Use ‘Right’
and ‘Left’ buttons to activate one of the three options: Cool, Neutral and Warm. For
optimum viewing in your LCD monitor, we recommend you to use the Neutral option.

Note: As you choose an item, your screen will immediately updates to reflect

this setting.

If ‘Luminance’ is selected, use ‘
for adjustment is from 0 to 100. ‘Right’ button will increase the Luminance setting and
‘Left’ will decrease it. It will adjust the light of the color.

If ‘Hue’ is selected, use ‘Right’ and ‘Left’ button to adjust its value. The range for
adjustment is from 0 to 100. ‘Right’ button will increase the Hue setting and ‘Left’ will
decrease it. It will adjust the phase of the color.

If ‘Color’ is selected, use ‘
adjustment is from 0 to 100. ‘Right’ button will increase the Color setting and ‘Left’ will
decrease it. It will adjust the saturation of the color.

Adjustment in the “Clock/Phase” submenu

To adjust Clock and Phase settings you should follow the steps below:

1. Bring-up the OSD “Main Menu”.

2. Use ‘Select’ button to move forward to Clock/Phase icon and highlight it, this will

bring-up the “
submenu: Exit, Auto Setup, Clock and Phase.

3. Use ‘

highlight and select it.

Right

Clock/Phase

’ and ‘

Left

Right

’ buttons to choose the item you need and then press ‘

Right

’ and ‘

” submenu. There are four items for your choice in this

’ and ‘

Left

Left

’ button to adjust its value. The range

’ button to adjust its value. The range for

Select

’ to

24

Colok/Phase

Exit

Auto Setup

Clock

Phase

If ‘Exit’ is selected, it will exit the “Clock/Phase” submenu and forward to the next item
in the “

If ‘Auto Setup’ is selected, it will execute ‘Auto Setup’ function. Please refer to ‘Auto

Setup by Direct Key

If ‘Clock’ is selected, then you can adjust it by ‘Right’ and ‘Left’ buttons. ‘Right’ button
will increase the number of pixels per line and ‘Left’ button will decrease the number of
pixels per line.

Note: We recommend you do Auto Setup first. And adjusting the clock setting

If ‘Phase’ is selected, then you can adjust it by ‘Right’ and ‘Left’ buttons.

Main Menu

only if the image looks incorrect.

”. (i.e., Management icon.)

’ on page 27 for more detail information.

ENGLISH

Note:

We recommend you do Auto Setup and to see whether the phase needs to

adjust or not.

25

ENGLISH

Adjustment in the “Management” submenu

To adjust Management settings you should follow the steps below:

1. Bring-up the OSD “

Main Menu

”.

2. Use ‘Select’ button to move forward to Management icon and highlight it. This will

bring-up the “

Management

” submenu. There are seven items for your choice in this
submenu: Exit, Mode Info, OSD Display, Scale/Center, Language, Source and Recall
Factory Setting.

3. Use ‘Right’ and ‘Left’ keys to choose the item you need and then press ‘Select’ to
highlight and select it.

Management

Exit

Mode Info

OSD Display

Scale/Center

Language

Source

Recall Factory Setting

If ‘Exit’ is selected, it will exit and close the OSD.

If ‘Mode info’ is selected, it will show-up “

V. frequency information displayed in it.

If ‘OSD Display’ is selected, it will bring-up “
‘Left’ buttons to highlight and ‘Select’ key to select H. or V. Position. This will show-up
the corresponding bar on menu, and you can adjust its setting by ‘
buttons. ‘Right’ button will move the OSD menu to the right or upward, and ‘Left’
button will move the OSD menu to the left or downward.

Mode Info

” submenu with resolution, H. and

OSD Display

” submenu. Use ‘

Right

’ and ‘

Right

’ and

Left

’

If ‘Scale/Center’ is selected, it will bring-up “Scale/Center” submenu. Use ‘Right’ and
‘Left’ buttons to highlight and activate Center, Maintain Aspect Ratio, or Full Screen.
In general, full screen is preferred for using.

Note: As you choose an item, your screen immediately updates to reflect this

setting.

If ‘Language’ is selected, it will bring-up “

Language

” submenu. Use ‘

Right

’ and ‘
buttons to highlight and ‘Select’ key to activate the language you preferred and exit
this submenu.

If ‘Source’ is selected, it will bring-up “Source” submenu. Use ‘Right’ and ‘Left’

26

Left

’

buttons to highlight and switch Analog or Digital input signal. If your selected input
signal is missing it will search next input signal by automatic until get available.

Note: As you choose an item, your display immediately updates to reflect this

setting.

If ‘Recall Factory Setting’ is selected, it will bring-up “Recall Factory Setting”
submenu with ‘Yes’ and ‘No’ prompt for your confirmation. Use ‘Right’ and ‘Left’
buttons to choose and ‘
factory settings or not.

Select

’ button to make your confirmation for return back

Using the Direct Keys

ENGLISH

There are two direct keys that function while OSD “
direct keys are for bringing-up OSD “Auto Setup” and “ Audio/Source ” submenu.

Auto Setup by Direct Key

Use Auto Setup whenever you apply a new video mode or change the refresh rate. While
the Auto Setup routine is running, you should have a stable image displayed on the
screen. Do not move items around the screen, play games, or view video during Auto
Setup.

Once you have executed Auto Setup for a particular mode, the display will store the new
values in its permanent memory.

Main Menu

” is inactivated. The two

Auto Setup

Yes

To execute Auto Setup:

1. Press ‘Left’ button with no OSD “Main Menu” displayed on screen, this will show up

Auto Setup

“

” submenu.

No

2. Use ‘Right’ or ‘Left’ buttons to choose Yes and press ‘Select’ key to activate Auto
Setup.

The image will be muted during the Auto Setup routine running. After the routine is
complete, you are asked whether the image appears correct or not.

Auto Setup

Does this image

look correct?

Ye s

No

3. If the image looks correct, choose Yes, and then the submenu will close automatically.

OR

If the image requires further adjustment, choose No, it will shown up ‘Phase’ bar for

27

ENGLISH

your further adjustment by manual. Then you can adjust the phase by ‘
buttons. When all text appears well focused and there is no instability in the image,
press the ‘

Select

’ key to end the adjustment and close the OSD menu.

Right

’ or ‘

Left

’

•

Aaudio/Source Adjust by Direct Key

To adjust Audio and Video:

1. Press ‘Right’ button with no OSD “Main Menu” displayed on screen, this will show up

Aaudio/Source

“

Use ‘Right’ and ‘Left’ keys to choose the item you need and then press ‘Select’ to

2.

highlight and select it.

” submenu.

Phase

32

•

Audio/Source

Exit

Source

Audio Mute

Vo l u m e

If ‘Exit’ is selected, it will exit and close the OSD.

If ‘Source’ is selected, it will bring-up “Source” submenu. The description refer to
page 26.

If ‘Audio Mute’ is selected, it will bring-up “Audio Mute” submenu with ‘Yes’ and ‘No’
prompt for your confirmation. Use ‘
button to make your confirmation for mute audio output or not.

Note: As you choose an item, your display immediately updates to reflect this

setting.

If ‘Volume’ is selected, use ‘
adjustment is from 0 to 100. ‘Right’ button will increase the Volume setting and ‘Left’
will decrease it.

Right

Right

’ and ‘

’ and ‘

Left

Left

’ buttons to choose and ‘

’ button to adjust its value. The range for

Select

’

28

Troubleshooting

This chapter contains information about how to troubleshoot your LCD Monitor. If you
have tried all of the items listed below, please contact a qualified service personnel.

A. My display doesn’t work, even though the computer appears to work.

1. Make sure the power cable is securely plugged into the display.

2. Make sure the display is turned on.

3. Try turning the display off and then turning it on again.

4. Make sure the display’s power cord is plugged into a power outlet and into the AC
power adapter. Check to see whether the outlet works by plugging another device
(such as a lamp) into the outlet. (If the light on the front of the display is lighted, it is
getting power. Try the next item on this procedure.)

5. Check the cable connection between the display and the computer. The cable
connectors must be pushed in all the way.

B. The message “No Sync.” appears on my display.
This message appears when there is no video signal from the computer.

1. Make sure the analog (or digital) video cable is plugged into the Analog (or digital)
Video Input port on the back of the display.

2. Make sure the other end of analog (or digital) video cable is plugged into the PC’s
video port.

ENGLISH

3. Make sure that the computer's power is turn on.

4. Make sure that your graphic card has its output already.

C. The message “Signal Out of Range” appears on my display.
This message appears when the input signal is beyond the display's capability.

Set your PC to a supported video mode, preferably 1024 x 768 at 60 Hz. See “Setting the
Video Mode” on page 19.

D. The image is very unstable.

1. Set your PC to a supported video mode, preferably 1024 x 768 at 60 Hz. See “Setting
the Video Mode” on page 19.

2. Restore the original factory settings by choosing Recall Factory Setting in the OSD
“Management” submenu.

3. Perform the Auto Setup function. See “Auto Setup by Direct Key” on page 27.

Note: Even if your PC’s setting is out of the range of video modes that are

supported by your LCD monitor, it may still be displayed with reduced
quality. This provides you with an opportunity to change your PC’s setting
to a correct one.

29

ENGLISH

Technical Information

This chapter contains technical information about your LCD Monitor.

Display Information

LCD Module 15-in (38.1 cm), active matrix TFT, anti-glare coating, 0.297 mm pixel

pitch
Display Size 304.1 mm x 228.1 mm
Viewing Angle

Left/Right

Up/Down
Luminance
Contrast Ratio
Display Colors 16 Millions
Power Input 100 ~ 240 V

Maximum power
consumption

Signal Input

Video Signal

Sync signals

-65° ~ 65°

-60° ~ 50°

2

300 cd/m
500 : 1 (Typical)

< 1.2 A @ 110V; < 0.6 A @ 230V
< 40W

Analog: RGB positive 0.7V
Separate, TTL Level
Digital: TMDS

0.3Vp-p differential

(Typical)

Full Range, 50/60 Hz

AC

, 75•

PP

Line (horizontal)
frequency

Raster (vertical)
frequency

Pixel dot clock 79 MHz (maximum)

Recommended
mode

Pedestal tilt 30° forward, -5°backward

Dimensions
(W x H x D)

Net weight
Grass weight

Analog: 31.5 kHz ~ 60 kHz
Digital: 31.5 kHz ~ 48.4 kHz

Analog: 56 Hz ~ 75 Hz
Digital: 60 Hz

1024 x 768 @ 60 Hz

60° right, 60° left

376 x 381 x 204 mm

5.1 kg

6.8 kg

30

Operating
Conditions

Temperature

Humidity

Altitude

Storage Conditions

Temperature

Humidity

Altitude

5° ~ 40°C at altitude 0 ~ 2000m
5° ~ 30°C at altitude 2000 ~ 3000m
20% ~ 85% RH, non-condensing
3000m Max.

-20° ~ 60°C
5% ~ 95% RH
10000m Max.

Video Modes

Your LCD monitor supports the following industry-standard combinations of screen
resolution and refresh rates. Other combinations are possible, but may require
adjustments to the image.

For optimum performance, set your PC to a screen resolution of 1024 x 768 at a 60 Hz
refresh rate.

ENGLISH

Analog:

Supported Resolution

(dots x lines)

VGA 640 x 350

640 x 480

640 x 480

640 x 480

SVGA 800 x 600

800 x 600

800 x 600

800 x 600

XGA 1024 x 768

1024 x 768

Vertical Frequency

(Refresh Rate)

70 Hz

60 Hz

72 Hz

75 Hz

56 Hz

60 Hz

72 Hz

75 Hz

60 Hz

70 Hz

1024 x 768

US TEXT 720 x 400 70 Hz

Power MAC 640 x 480

832 x 624

75 Hz

67 Hz

75 Hz

31

Digital:

ENGLISH

Supported Resolution

(dots x lines)

VGA 640 x 480

640 x 480

SVGA 800 x 600

800 x 600

XGA 1024 x 768 60 Hz

Note: The display is capable of going beyond these recommended modes.

Vertical Frequency

(Refresh Rate)

60 Hz

75 Hz

60 Hz

75 Hz

Unknown Video Modes

Like all other monitors, your LCD monitor is designed to work with standard video modes.
However, not all video/graphic cards use only standard display modes.

Your LCD monitor uses state-of-the-art technology, which is designed to synchronize to
any display mode. We recommend choosing one of the supported modes listed above. If
you choose an unknown mode, you will need to manually adjust the clock, phase, and
image position.

If you must use an unknown mode, you can run Auto Setup at first. If Auto Setup doesn’t
provide adequate image adjustment, then you must manually adjust the clock, phase,
horizontal position, and vertical position.

32

TCO’95 STATEMENT

Congratulations!

You have just purchased a TCO'95 approved and labelled product! Your choice has provided
you with a product developed for professional use. Your purchase h a s a l s o contributed t o
reducing the burden on the environment and also to the further development of
environmentally adapted electronics products.

This product meets the requirements for the TCO’95 scheme which provides for an
international environmental and quality labelling of personal computers. The labelling scheme
was developed as a joint effort by the TCO (The Swedish Confederation of Professional
Employees), Svenska Naturskyddsforeningen (The Swedish Society for Nature Conservation),
Statens Energimyndighet (The Swedish National Energy Administration) and SEMKO AB.

The requirements cover a wide range of issues: environment, ergonomics, usability,
reduction of electric and magnetic fields, energy consumption and electrical safety.

Why do we have env ironm entally la belled comput ers?

In many countries, environmental labelling has become an established method for
encouraging the adaptation of goods and services to the environment. The main problem, as
far as computers and other electronics equipment are concerned, is that environmentally
harmful substances are used both in the products and during their manufacture. Since it is
not so far possible to satisfactorily recycle the
majority of electronics equipment, most of these potentially damaging substances sooner or
later enter nature.

There are also other characteristics of a computer, such as energy consumption levels, that
are important from the viewpoints of both the work (internal) and natural (external)
environments. Since all methods of electricity generation have a negative effect on the
environment (e.g. acidi c and climate-influ encing e mi s s i o n s , r a d io a c t ive waste), it is vital to
save energy. Electronics equipment in offices is often left running continuously and thereby
consumes a lot of energy.

What does the environmenal labelling invol v e?

The environmental demands has been developed by Svenska Naturskyddsforeningen (The
Swedish Society for Nature Conservation). These demands impose restrictions on the
presence and use of heavy metals, brominated and chlorinated flame retardants, CFCs
(freons) and chlorinated solvents, among other things. The product must be prepared for
recycling and the manufacturer is obliged to have an environmental policy which must be
adhered to in each country where the company implements its operational policy.

The energy requirements include a demand that the computer and/or display, after a certain
period of inactivity, shall reduce its power consumption to a lower level in one or more stages.
The length of time to reactivate the computer shall be reasonable for the user.

Below you will find a brief summary of the environmental requirements met by this product.
The complete environmental criteria document may be ordered from:

TCO Development

SE-114 94 Stockholm, Sweden
Fax: [phone]

Email (Internet): [e-mail]
Current information regarding TCO’95 approved and labelled products may also be
obtained via the Internet, using the address: http://www.tco-info.com/

Environmental requirements

Flame retardants

Flame retardants are present in printed circuit boards, cables, wires, casings and housings.
Their
purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a
computer casing can consist of flame retardant substances. Most flame retardants contain
bromine or chloride, and those flame retardants are chemically related to another group of
environmental toxins, PCBs. Both the flame retardants containing bromine or chloride and the
PCBs are suspected of giving rise to severe health effects, including reproductive damage in
fish-eating b i r d s and mammals, due to the bio-accumulative
have been found in human blood and researchers fear that disturbances in foetus
development may occur.

The relevant TCO’95 demand requires that plastic components weighing more than 25 grams
must not contain flame retardants with organically bound bromine or chlorine. Flame
retardants are allowed in the printed circuit boards since no substitutes are available.

Cadmium**

Cadmium is present in rechargeable batteries and in the colour-generating layers of certain
computer displays. Cadmium damages the nervous system and is toxic in high doses. The
relevant TCO’95 requirement states that batteries, the colour-generating layers of display
screens and the electrical or electronics components must not contain any cadmium.

*

processes. Flame retardants

Mercury**

Mercury is sometimes found in batteries, relays and switches. It damages the nervous
system and is toxic in high doses. The relevant TCO’95 requirement states that batteries may
not contain any mercury. It also demands that mercury is not present in any of the electrical
or electronics components associated with the labelled unit. There is however one exception.
Mercury is, for the time being, permitted in the back light system of flat panel monitors as
there today is no commercially available alternative. TCO aims on removing this exception
when a mercury free alternative is available.

CFCs (freons)

The relevant TCO’95 requirement states that neither CFCs nor HCFCs may be used during
the manufacture and assembly of the product. CFCs (freons) are sometimes used for washing
printed circuit boards. CFCs break down ozone and thereby damage the ozone layer in the
stratosphere, causing increased reception on earth of ultraviolet light with e.g. increased
risks of skin cancer (malignant melanoma) as a consequence.
