Hilti UD 4 User Manual
UD 4
English
Printed: 03.08.2017 | Doc-Nr: PUB / 5358787 / 000 / 02
Printed: 03.08.2017 | Doc-Nr: PUB / 5358787 / 000 / 02
English 1
1 Information about the documentation
1.1 About this documentation
• Read this documentation before initial operation or use. This is a prerequisite for safe, trouble-free
handling and use of the product.
• Observe the safety instructions and warnings in this documentation and on the product.
• Always keep the operating instructions with the product and make sure that the operating instructions
are with the product when it is given to other persons.
1.2 Explanation of symbols used
1.2.1 Warnings
Warnings alert persons to hazards that may occur when handling or using the product. The following signal
words are used in combination with a symbol:
DANGER! Draws attention to an imminent hazard that will lead to serious personal injury or
fatality.
WARNING! Draws attention to a potential hazard that could lead to serious personal injury or
fatality.
CAUTION! Draws attention to a potentially dangerous situation that could lead to minor personal
injury or material damage.
1.2.2 Symbols in the documentation
The following symbols are used in this document:
Read the operating instructions before use
Instructions for use and other useful information
1.2.3 Symbols in the illustrations
The following symbols are used in illustrations:
These numbers refer to the corresponding illustrations found at the beginning of these operating
instructions.
The numbering reflects the sequence of operations shown in the illustrations and may deviate
from the steps described in the text.
Item reference numbers are used in the overview illustration and refer to the numbers used in
the key in the product overview section.
This symbol is intended to draw special attention to certain points when handling the product.
1.3 Symbols on the product
1.3.1 Symbols on the product
The following symbols are used on the product:
Protection class II (double-insulated)
1.4 Product information
Hilti products are designed for professional use and may be operated, serviced and maintained only by
trained, authorized personnel. This personnel must be informed of any particular hazards that may be
encountered. The product and its ancillary equipment can present hazards if used incorrectly by untrained
personnel or if used not in accordance with the intended use.
The type designation and serial number are stated on the rating plate.
Printed: 03.08.2017 | Doc-Nr: PUB / 5358787 / 000 / 02
2 English
▶ Write down the serial number in the table below. You will be required to state the product details when
contacting Hilti Service or your local Hilti organization to inquire about the product.
Product information
Drill UD 4
Generation: 01
Serial no.:
1.5 Declaration of conformity
We declare, on our sole responsibility, that the product described here complies with the applicable directives
and standards. A copy of the declaration of conformity can be found at the end of this documentation.
The technical documentation is filed and stored here:
Hilti Entwicklungsgesellschaft mbH | Tool Certification | Hiltistrasse 6 | 86916 Kaufering, Germany
2 Safety
2.1 General safety precautions for power tools
WARNING Read all safety warnings, instructions, illustrations and specifications provided with this
power tool. Failure to follow the instructions below may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated
(cordless) power tool.
Work area safety
▶ Keep your work area clean and well lit. Cluttered or dark work areas invite accidents.
▶ Do not operate the power tool in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
▶ Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control.
Electrical safety
▶ Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools. Unmodified plugs and matching power outlets reduce the
risk of electric shock.
▶ Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
▶ Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the
risk of electric shock.
▶ Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the
risk of electric shock.
▶ When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
▶ If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
Personal safety
▶ Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A
moment of inattention while operating the power tool may result in serious personal injury.
▶ Use personal protective equipment. Always wear eye protection. Protective equipment such as a
dust mask, non-skid safety shoes, hard hat or hearing protection used for appropriate conditions will
reduce personal injuries.
▶ Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power
source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on
the switch or energising power tools that have the switch on invites accidents.
▶ Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
▶ Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
Printed: 03.08.2017 | Doc-Nr: PUB / 5358787 / 000 / 02
English 3
▶ Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
▶ If devices are provided for the connection of dust extraction and collection facilities, ensure these
are connected and properly used. Use of dust collection can reduce dust-related hazards.
▶ Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore
tool safety principles. A careless action can cause severe injury within a fraction of a second.
Power tool use and care
▶ Do not force the power tool. Use the correct power tool for your application. The correct power tool
will do the job better and safer at the rate for which it was designed.
▶ Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
▶ Disconnect the plug from the power source and/or remove the battery pack, if detachable, from
the power tool before making any adjustments, changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of starting the power tool accidentally.
▶ Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands
of untrained users.
▶ Maintain power tools and accessories. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tool’s operation. If damaged,
have the power tool repaired before use. Many accidents are caused by poorly maintained power
tools.
▶ Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
▶ Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
▶ Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.
Service
▶ Have your power tool serviced by a qualified repair person using only identical replacement parts.
This will ensure that the safety of the power tool is maintained.
2.2 Safety instructions for power drills
Safety instructions for work of all kinds
▶ Wear ear protection when hammer drilling. Exposure to noise can cause hearing loss.
▶ Always support the power tool firmly in preparation for use. This power tool produces high torque. If
the power tool is not securely supported at all times during operation loss of control can result and lead
to injuries.
▶ Hold the power tool by the insulated gripping surfaces only, when carrying out work in which the
accessory tool or the screws can come into contact with concealed wiring or the tool's own supply
cord. If the accessory tool comes into contact with a live wire, metal parts of the power tool can also
become live, resulting in an electric shock.
Safety instructions for using long drill bits
▶ Do not under any circumstances attempt to work with the power tool operating at a speed higher
than the maximum permissible speed for the drill bit. A drill bit spinning at a speed higher than its
maximum permissible speed when not in contact with the workpiece can develop a slight curvature and
this can lead to injuries.
▶ Always start drilling at a low speed and with the drill bit in contact with the workpiece. A drill bit
spinning at a speed higher than its maximum permissible speed when not in contact with the workpiece
can develop a slight curvature and this can lead to injuries.
▶ Do not apply too much pressure to the drill bit and apply pressure only along the drill bit's
longitudinal axis. Drill bits can bend and subsequently break or cause a loss of control and resultant
injury.
2.3 Additional safety instructions for torquing threaded fasteners
Personal safety
▶ Use the product only when it is in perfect working order.
▶ Never tamper with or modify the tool in any way.
▶ Always hold the tool firmly with both hands on the grips provided. Keep the grips clean and dry.
Printed: 03.08.2017 | Doc-Nr: PUB / 5358787 / 000 / 02
4 English
▶ Do not touch rotating parts – risk of injury!
▶ Wear suitable protective glasses, a hard hat, ear protection, protective gloves and light respiratory
protection while using the power tool.
▶ Wear protective gloves also when changing the tool. Touching the accessory tool can result in cuts and
burns.
▶ Wear eye protection. Flying fragments can injure the body and eyes.
▶ Before starting work, check the hazard class of the dust that will be produced when working. Use
an industrial vacuum cleaner with an officially approved protection class in compliance with the locally
applicable dust protection regulations. Dust from materials such as lead-based paint, certain types of
wood and concrete/masonry/stone containing quartz, minerals or metal can be harmful to health.
▶ Make sure that the workplace is well ventilated and, where necessary, wear a respirator appropriate for
the type of dust generated. Contact with or inhalation of the dust may cause allergic reactions and/or
respiratory or other diseases among operators or bystanders. Certain kinds of dust are classified as
carcinogenic such as oak and beech dust, especially in conjunction with additives for wood conditioning
(chromate, wood preservative). Only specialists are permitted to handle material containing asbestos.
▶ Take breaks and do physical exercises to improve the blood circulation in your fingers. Exposure to
vibration during long periods of work can lead to disorders of the blood vessels and nervous system in
the fingers, hands and wrists.
Electrical safety
▶ Before beginning work, check the working area for concealed electric cables or gas and water pipes.
External metal parts of the power tool can become live, presenting a risk of electric shock, if you
accidentally damage an electric cable.
▶ Check the condition of the supply cord and the plug. Have the power cord or the plug checked, and if
necessary replaced, by a trained electrical specialist.
Power tool use and care
▶ Immediately switch off the power tool if the accessory tool jams. The power tool might twist off-line.
▶ Wait until the power tool stops completely before you lay it down.
Printed: 03.08.2017 | Doc-Nr: PUB / 5358787 / 000 / 02
