Key Features
1/2.8" progressive scan CMOS
BLC/3D DNR/ROI
1920 × 1080@30fps
Up to 30 m IR range
2.8 mm to 12 mm varifocal lens
IP67
H.265+, H.265, H.264+, H.264
Digital WDR
Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 Lux
@ (F1.6, AGC ON)
Built-in micro SD/SDHC/SDXC card slot,
up to 128 GB
HWI-B620H-V/Z
2 MP EXIR VF Bullet Network Camera
Camera
Image Sensor
1/2.8" Progressive Scan CMOS
Min. Illumination
Color: 0.01 Lux @(F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON)
Shutter Speed
1/3 s to 1/100, 000 s, support slow shutter
Slow Shutter
Yes
Auto-Iris
No
Day & Night
IR cut filter
Digital Noise Reduction
3D DNR
WDR
Digital WDR
Angle Adjustment
Pan: 0° to 360°, tilt: 0° to 90°, rotation: 0° to 360°
Lens
Focal Length
2.8 to 12 mm
Aperture
F1.6
Focus
-V: Manual
-Z: Auto
FOV
Horizontal field of view: 98° to 34°
Vertical field of view: 51° to 19°
Diagonal field of view: 115° to 40°
Lens Mount
Φ14
IR
IR Range
Up to 30 m
Wavelength
850 nm
Compression Standard
Video Compression
Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG
H.264 Type
Baseline Profile/Main Profile/High Profile
H.264+
Main stream supports
H.265 Type
Main Profile
H.265+
Main stream supports
Video Bit Rate
32 Kbps to 8 Mbps
Smart Feature-set
Region of Interest
1 fixed region for main stream and sub-stream
Max. Resolution
1920 × 1080
Main Stream
Max. Frame Rate
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-stream
Max. Frame Rate
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Image Enhancement
BLC, 3D DNR
Image Settings
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or
web browser
Day/Night Switch
Auto, scheduled
Network
Network Storage
Support micro SD/SDHC/SDXC card (128G ), local storage and ANR
Alarm Trigger
Motion detection, video tampering alarm, network disconnected, IP address conflicted, illegal
login
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP,
Specification
Available Models
HWI-B620H-V (2.8 mm to 12 mm), HWI-B620H-Z (2.8 mm to 12 mm)
802.1X, QoS, IPv6, UDP, Bonjour
General Function
One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark
API
ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View
Up to 6 channels
User/Host
Up to 32 users
3 levels: Administrator, Operator and User
Client
iVMS-4200, iVMS-4500, iVMS-5200
Web Browser
IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
Interface
Communication Interface
1 RJ45 10M/100M self-adaptive Ethernet port
Video Output (Without -Z)
1Vp-p composite output (75 Ω/BNC)
Reset Button
Yes
General
Operating Conditions
-30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing)
Power Supply
12 VDC ± 25%, 5.5 mm coaxial power plug
PoE (802.3af, class 3)
Power Consumption and Current
-Z: 12 VDC, 0.9 A, max. 11 W; PoE: (802.3af, 36 V to 57 V), 0.4 A to 0.2 A, max. 12.9 W
-V: 12 VDC, 0.6 A, max. 7 W; PoE: (802.3af, 36 V to 57 V), 0.3 A to 0.1 A, max. 9 W
Protection Level
IP67
Material
Metal
Dimensions
Φ 105 mm × 244.4 mm (Φ 4.1" × 9.6")
Weight
Camera: approx. 1015 g (2.2 lb.)
With package: approx. 1540 g (3.4 lb.)
Dimension
Φ83.3(3.3")
244.4(9.6")
226.9(8.9")
136(5.4")
Φ105(4.1")
62.6(2.5")
62.6(2.5")
4-Φ4.2(0.2")
Unit: mm
Accessory
DS-1260ZJ
