Hikvision HWC-P120-D-W User Manual

HWC-P120-D/W
2.0 MP Network PT Camera
Key Features
Two video streams
2.8mm fixed lens
Digital Wide Dynamic Range
3D Digital Noise Reduction
Built-in microphone and speaker, support
two-way audio
Support on-board storage, up to 128 GB
Up to 5 m IR range
Built-in Wi-Fi
DC 5V ± 10 %, micro USB interface
Mobile Monitoring via Hik-Connect
Specifications
Camera
Image Sensor
1/2.8" Progressive Scan CMOS
Min. Illumination
0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Speed
1/3 s to 1/100,000 s
Slow Shutter
Support
Iris
F2.0
Lens
2.8 mm, horizontal field of view 105.8°
Lens Mount
M12
Day &Night
IR cut filter with auto switch
DNR
3D DNR
Wide Dynamic Range
Digital WDR
Pan/Tilt
Pan: 0° to 355°; Tilt: -10° to 90°
Compression Standard
Video Compression
Main stream: H.264 Sub-stream: H.264
H.264 Type
Baseline Profile/Main Profile
Video Bit Rate
32 Kbps – 8 Mbps
Audio Compression
G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2)
Max. Resolution
1920 × 1080
Main Stream Max. Frame Rate
50Hz: 25fps (1920 × 1080, 1280 ×720) 60Hz: 30fps (1920 × 1080, 1280 ×720)
Sub-Stream Max. Frame Rate
50Hz: 25fps (704 × 576, 352 × 288, 640 × 480, 320 × 240) 60Hz: 30fps (704 × 480, 352 × 240, 640 × 480, 320 × 240)
Image Settings
Brightness, saturation, sharpness, contrast are adjustable via client software
Day/Night Switch
Support auto/scheduled
Backlight Compensation
Support, zone optional
Region of Interest
Support 1 fixed region for each stream
Audio
Environment Noise Filter
Support
Audio I/O
Support mono soundtrack
Audio Sampling Rate
Max. 16 kHz
Network
Network Storage
Support micro SD/SDHC/SDXC card, up to 128 GB local storage
Detection
Motion detection
Alarm Trigger
Video tampering alarm, HDD full, HDD error, network disconnected, IP address conflicted, illegal login
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, UPnP, IGMP, QoS, IPv6, Bonjour, SMTP, 802.1x
Standard
ISAPI
General Function
One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark
Interface
Communication Interface
1 RJ45 10M/100M self-adaptive Ethernet port
On-board Storage
Built-in micro SD/SDHC/SDXC slot, up to 128 GB
