Key Features
1/3" progressive scan CMOS
3D DNR
2560 × 1440@20fps
Up to 30 m IR range
2.8 mm/4 mm fixed lens
PoE
H.265+, H.265, H.264+, H.264
IP67
Dual stream
120 dB WDR
HWI-B140H(-M)
4.0 MP IR Network Bullet Camera
Camera
Image Sensor
1/3" progressive scan CMOS
Min. Illumination
Color: 0.01 Lux @(F1.2, AGC ON), 0.028 Lux @ (F2.0, AGC ON)
Shutter Speed
1/3 s to 1/100, 000 s
Slow Shutter
Yes
Auto-Iris
No
Day &Night
IR cut filter
DNR (Digital Noise Reduction)
3D DNR
WDR (Wide Dynamic Range)
120 dB
Angle Adjustment (Bracket)
Pan: 0° to 360°, tilt: 0° to 180°, rotation: 0° to 360°
Lens
Focal Length
2.8 mm, 4 mm
Aperture
F2.0
Focus
Fixed
FOV
2.8 mm, horizontal FOV 100°, vertical FOV 55°, diagonal FOV 117°
4 mm, horizontal FOV 77°, vertical FOV 42°, diagonal FOV 88°
Lens Mount
M12
IR
IR Range
Up to 30 m
Wavelength
850 nm
Compression Standard
Video Compression
Main stream: H.265/H.264
Sub stream: H.265/H.264/MJPEG
H.264 Type
Baseline Profile/Main Profile/High Profile
H.264+
Main stream supports
H.265 Type
Main Profile
H.265+
Main stream supports
Video Bit Rate
32 Kbps to 8 Mbps
Smart Feature-set
Region of Interest
1 fixed region for main stream and sub-stream
Max. Resolution
2560 × 1440
Main Stream
Max. Frame Rate
50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
Sub-stream
Max. Frame Rate
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Image Enhancement
BLC, 3D DNR
Image Settings
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or
web browser
Day/Night Switch
Auto, scheduled, day, night
Network
Network Storage
NAS (NFS, SMB/CIFS)
Alarm Trigger
Motion detection, video tampering alarm, illegal login
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP,
SNMP, IGMP, 802.1X, QoS, IPv6 UDP, Bonjour
General Function
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
API
ONVIF (PROFILE S, PROFILE G), ISAPI
Available Models
HWI-B140H (2.8/4 mm), HWI-B140H-M (2.8/4 mm)
Simultaneous Live View
Up to 6 channels
User/Host
Up to 32 users
3 levels: Administrator, Operator, and User
Client
iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
Web Browser
IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
Interface
Communication Interface
1 RJ45 10M/100M self-adaptive Ethernet port
General
Operating Conditions
-30 °C to 50 °C (-22 °F to 122 °F), humidity: 95% or less (non-condensing)
Power Supply
12 VDC ± 25%, 5.5 mm coaxial power plug
PoE (802.3af, class 3)
Power Consumption and Current
12 VDC, 0.4 A, Max: 5 W
PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, Max: 6.5 W
Protection Level
IP67
Material
Without –M model:
Front cover: metal, camera body: plastic, bracket: plastic
-M model:
Front cover: metal, camera body: metal, bracket: metal
Dimensions
Camera: Ø 70 mm × 191.3mm (Ø 2.7" × 7.5")
With package: 216 mm × 121 mm × 118 mm (8.5" × 4.8" × 4.6")
Weight
Without –M model:
Camera: approx. 280 g (0.6 lb.)
With package: approx: 530 g (1.2 lb.)
–M model:
Camera: approx. 402 g (0.9 lb.)
With package: approx: 641 g (1.4 lb.)
Dimension
191.3 mm (7.5" )
71.4 mm (2.8" )
66.7 mm (2.6 " )
Ø 70 mm
(2.8 " )
120
°
Accessory
DS-1280ZJ-XS
Junction Box
