Hikvision ECT-B32V2 Quick Start Guide

ECT-B32V2

TurboHD Bullet Camera

Quick Start Guide

ECT-B32V2 Quick Start Guide

Manual Illustrations and Features

Graphics (screen shots, product pictures, etc.) in this document are for illustrative purposes only.
Your actual product may differ in appearance. Your product might not support all features
discussed in this document.

Hikvision USA Inc., 18639 Railroad St., City of Industry, CA 91748, USA • Hikvision Canada, 4848
rue Levy, Saint Laurent, Quebec, Canada, H4R 2P1

Telephone: [phone] • Toll Free in USA: [phone] • E-Mail:
[e-mail] • www.hikvision.com

COPYRIGHT ©2017-2018 Hangzhou Hikvision Digital Technology Co., Ltd.

ALL RIGHTS RESERVED.

Any and all information, including, among others, wordings, pictures, graphs are the properties of
Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be
“Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced,
changed, translated, or distributed, partially or wholly, by any means, without the prior written
permission of Hikvision. Unless otherwise stipulated, Hikvision does not make any warranties,
guarantees or representations, express or implied, regarding to the Manual.

About this Manual

This manual may contain technical incorrect places or printing errors, and the content is subject to
change without notice. The updates will be added to the new version of this manual. We will
readily improve or update the products or procedures described in the manual.

Regulatory Information

FCC Information

Please take attention that changes or modification not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.

FCC Compliance: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause
undesired operation.

EU Conformity Statement

This product and, if applicable, the supplied accessories too are marked with “CE” and
comply therefore with the applicable harmonized European standards listed under the
Low Voltage Directive 2014/35/EU, the EMC Directive 2014/30/EU.

2012/19/EU (WEEE Directive): Products marked with this symbol cannot be disposed of
as unsorted municipal waste in the European Union. For proper recycling, return this
product to your local supplier upon the purchase of equivalent new equipment, or
dispose of it at designated collection points. For more information see:
www.recyclethis.info.

2006/66/EC (Battery Directive): This product contains a battery that cannot be disposed
of as unsorted municipal waste in the European Union. See the product documentation

QSG ECT-B32V2 031518NA 2

ECT-B32V2 Quick Start Guide

for specific battery information. The battery is marked with this symbol, which may
include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper
recycling, return the battery to your supplier or to a designated collection point. For more
information see: www.recyclethis.info.

Industry Canada ICES-003 Compliance

This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.

Warning

This is a class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.

Safety Instruction

These instructions are intended to ensure that user can use the product correctly to avoid danger
or property loss.

The precaution measure is divided into “Warnings” and “Cautions”.

Warnings: Serious injury or death may occur if any of the warnings are neglected.
Cautions: Injury or equipment damage may occur if any of the cautions are neglected.

Warnings Follow these safeguards to

prevent serious injury or death.

Warnings

• In the use of the device, you must be in strict compliance with the electrical safety regulations of
the nation and region.

•

Input voltage should meet both the SELV (S

with 12 VDC according to the IEC60950-1 standard. Refer to technical specifications for detailed
information.

• Do not connect multiple devices to one power adapter to avoid over-heating or a fire hazard
caused by overload.

• Make sure that the plug is firmly connected to the power socket.

• Make sure that the device is firmly fixed if wall mounting or ceiling mounting is adopted.

• If smoke, odor or noise rise from the device, turn off the power at once and unplug the power

cord, and then contact the service center.

• Never attempt to disassemble the camera by unprofessional personal.

afety Extra Low Voltage) and the Limited Power Source

Cautions Follow these precautions to
prevent potential injury or material damage.

Cautions

• Do not drop the camera or subject it to physical shock.

• Do not place the camera in extremely hot, cold (the operating temperature shall be -40°C to

60°C), dusty or damp locations, and do not expose it to high electromagnetic radiation.

• Do not touch senor modules with fingers.

• If cleaning is necessary, use clean cloth with a bit of ethanol and wipe it gently.

QSG ECT-B32V2 031518NA 3

ECT-B32V2 Quick Start Guide

• Do not aim the camera at the sun or extra bright places.

• The sensor may be burned out by a laser beam, so when any laser equipment is in using, make

sure that the surface of sensor will not be exposed to the laser beam.

• Do not expose the device to high electromagnetic radiation or extremely hot, cold, dusty or
damp environment.

• To avoid heat accumulation, good ventilation is required for the operating environment.

• Keep the camera away from liquid while in use for non-water-proof device.

• While in delivery, the camera shall be packed in its original packing, or packing of the same

texture.

Mark Description

Mark Description

DC Voltage

QSG ECT-B32V2 031518NA 4

ECT-B32V2 Quick Start Guide

Contents

1 Introduction .......................................................................... 6

1.1 Product Features ............................................................... 6

1.2 Overview ........................................................................... 6

1.2.1 Camera Overview..................................................... 6

2 Installation ............................................................................ 6

2.1 Installation of Camera ....................................................... 7

3 Menu Description ................................................................ 10

3.1 FORMAT .......................................................................... 11

3.2 EXPOSURE ....................................................................... 12

3.3 DAY/NIGHT ...................................................................... 12

3.4 VIDEO SETTINGS ............................................................. 15

3.5 FACTORY DEFAULT ........................................................... 16

3.6 EXIT ................................................................................. 17

3.7 SAVE & EXIT ..................................................................... 17

QSG ECT-B32V2 031518NA 5

ECT-B32V2 Quick Start Guide

1 Introduction

1.1 Product Features

The main features are as follows:



High performance CMOS sensor



IR cut filter with auto switch



OSD menu with configurable parameters



Internal synchronization



SMART IR mode



3-axis adjustment

1.2 Overview

1.2.1 Camera Overview

Figure 1-1 Overview of Camera

2 Installation

Before You Start:



Make sure that the device in the package is in good condition

and all the assembly parts are included.



Make sure that all the related equipment is power-off during

the installation.

QSG ECT-B32V2 031518NA 6
