1 Introduction
1.1 Box Content
Handheld Thermal Camera (×1)
Power
Adapter (×1)
USB Cable
(×1)
Wrist Strap
(x1)
DISK
Manual (×1)
Disk (×1)
Note: The Handheld Thermography Camera
includes one battery and one Micro SD card.
1.2 Product Introduction
The handheld Thermography camera is a camera
with thermal images. It can do thermometry,
and snapshot capturing. The built-in
high-sensitivity IR detector and
high-performance sensor detects the
temperature change and measure the real-time
temperature. The temperature measurement
range is -20°C to 550 °C (-4 °F to 1022 °F) with
thermometry accuracy ±2 °C.
It helps the users to find the risky part and lower
their property loss. The device supports live
viewing, and capturing, etc.
The handheld Thermography camera, adopting
ergonomic design, is easy to use. The device is
mainly applied to various industries, such as
Building, HVAC, and auto industry, etc.
2 Appearance
2.1 Dimensions
59mm(2.32")
196mm(7.72")
78mm(3.07")
The dimension may vary according to different
camera model.
2.2 Interfaces
Screen
Charging
Indicator
Back
Navigation
On/OK/Menu
Hold: Power On/Off
Press: Display menu or confirm
operation
Exit the menu or return to
previous menu.
Navigation Button
Press the ▽, △button to select
parameters.
Press the button to
confirm.
Laser
IR Lens
Cover
Trigger
USB Interface
Micro SD Slot
Tripod
Interface
Charging
Indicator
When the device is charging,
the LED indicator is red.
When the device is fully
charged, the LED indicator is
green.
USB
Interface
Charge the battery and export
snapshots with the USB cable.
Trigger
Pull the trigger to capture
snapshots.
When the Laser function is
switched on, pull the trigger to
turn on/off the laser light.
Warning:
The laser radiation emitted from the device can
cause eye injuries, burning of skin or
inflammable substances. Before enabling the
Light Supplement function, make sure no human
or inflammable substances are in front of the
laser lens.
3 Basic Operations
3.1 Charging the Device
Steps:
1. Open the top cover of the camera.
2. Connect the USB interface and the power
adaptor with USB cable.
USB interface
3.2 Interface Description
Color-
Temperature
Scale
Min. Temperature
Display
Emissivity
Real-time
Temperature
Center Temperature
Display
Unit
Status Icons
Max. Temperature Display
Real-time Center
Temperature
3.3 Format Micro SD Card
Before you start:
Confirm the Micro SD card is properly installed
before use.
Steps:
1. In the live view interface, press
button to show the menu bar.
2. Press / button to select
Format Micro SD.
3. Press button and select OK to
start format Micro SD Card.
Note:
Format Micro SD Card before first use of it.
3.4 Capture Snapshots
Steps:
1. In the live view interface, pull the trigger
to capture snapshot. The live view
freezes and device displays the snapshot
with temperature information.
2. Press button to save the picture,
press button to cancel it.
Note:
You can not capture when the device is
connected with PC.
3.5 View Snapshots
Steps:
1. Go to Menu > Picture to view the
capture snapshots.
2. Press button to view the selected
picture, press / button to
switch pictures.
3. (Optional) Press button to delete
picture in picture view interface.
3.6 Export File
Purpose:
Connect the handheld Thermography camera
to your PC with USB cable, you can export the
captured snapshots.
Steps:
1. Open the USB cover.
2. Connect the camera to your PC with
USB cable and open the detected disk.
3. Select and copy the snapshots to PC and
view the files.
4. Disconnect the device from your PC.
Note:
For the first time connection, the driver will be
installed automatically.
Do not disconnect the USB connection from
PC or pull out the Micro SD card during drive
installation or it may cause the device damage.
3.7 Upgrade
Steps:
1. Connect the thermography camera to
your PC with USB cable and open the
detected disk.
2. Copy the upgrade file and replace it to
the root directory of the device.
3. Disconnect the device from your PC.
4. Reboot the device and then it will
upgrade automatically. The upgrading
process will be displayed in the main
interface.
Note: After the upgrading, the device
automatically reboot. You can view the current
version in Menu > About.
4 Main Configurations
4.1 Temperature
Measurement
Purpose:
The thermometry (temperature measurement)
function provides the real-time temperature of
the scene and display it on the left of your
screen. The thermometry function is turned on
by default.
The thermometry parameters affect the
accuracy of temperature measurement.
Steps:
1 In the live view interface, press
button show the menu bar.
2 Press / button to select
desired setting bar.
3 Press button to go to the setting
interface.
Emissivity: Set the emissivity of your
target as the effectiveness in emitting
energy as thermal radiation.
Note: Refer to the 6.1 Common
Material Emissivity Reference for
emissivity values.
Temperature: Set the average
temperature of the environment.
Distance (m/feet): Set the straight-line
distance between the target and the
device.
Note: The recommended
thermometry distance is 0.2 m to 2
m with target size 80 × 80 mm.
Rule: Select Hot Spot, Cold Spot to
show the max. temperature, min.
temperature in the live view interface.
4 Press / button to select
desired parameter, and press
button to enable it.
5 If necessary, press / button
to increases / decrease the setting
values. Hold / button to
change the value quickly.
6 Press button to save and exit.
4.2 Other Configurations
Here is an example of setting laser light
function.
Steps:
1 In the live view interface, press
button show the menu bar.
2 Press / button to select
Laser.
3 Press button to turn on / turn off
laser light function.
4 Press button to save and exit.
5 In live view interface, pull the trigger to
turn on laser light, release the trigger to
turn off laser light.
Note: Other parameters, such as temperature
measurement range, unit, palettes and so on,
can be configured as steps above.
5 System Information
Go to Menu > About to view the device
information: Model, Version No., FPGA Version
No., Serial No., Capacity and so on.
You can also set the auto power-off duration,
date and time in Menu.
6 Appendix
6.1 Common Material
Emissivity Reference
Material
Emissivity
Human Skin
0.98
PCB
0.91
Cement Concrete
0.95
Ceramics
0.92
Rubber
0.95
Paint
0.93
Wood
0.85
Asphalt
0.96
Brick
0.95
Sand
0.90
Soil
0.92
Cotton
0.98
Cardboard
0.90
White Paper
0.90
Water
0.96
6.2 Frequently Asked
Questions (FAQ)
Q: The charge indicator flashes red.
A: Examine the items below.
1. Examine whether the device is charged with
the standard power adapter.
2. Plug and unplug the battery once.
3. Make sure the environment temperature is
above 0°C (32°F).
Q: Capturing or recording fails.
A: Examine the items below:
1. Whether the device is connected to your PC
and the capture function is unavailable.
2. Whether the storage space is full.
3. Whether the device is low-battery.
Q: The PC cannot identify the camera.
A: Examine whether the device is connected to
your PC with standard USB cable.
Q: The camera can not be operated or no
responding.
A: Hold button to reboot the camera.
Loading...
