Hikvision DS-2TP23-10VM-W User Manual

Handheld Thermography Camera

User Manual

Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its

subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or

distributed, partially or wholly, by any means, without the prior written permission of Hikvision. Unless otherwise stipulated, Hikvision does not make any warranties, guarantees or representations, express or implied, regarding to the Manual.

About this Manual

This Manual is applicable to Handheld Thermography Camera.

The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons. Please find the latest version in the company website (http://overseas.hikvision.com/en/).

Please use this user manual under the guidance of professionals.

Trademarks Acknowledgement

and other Hikvision’s trademarks and logos are the properties of

Hikvision in various jurisdictions. Other trademarks and logos mentioned below are the properties of their respective owners.

Legal Disclaimer

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, IS PROVIDED

“AS IS”, WITH ALL FAULTS AND ERRORS, AND HIKVISION MAKES NO

WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL HIKVISION, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION,

iii

IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.

SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.

IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS.

Regulatory Information

FCC Information Please take attention that changes or modification not expressly approved by the

party responsible for compliance could void the user’s authority to operate the

equipment. FCC compliance: This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

—Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. This equipment should be installed and operated with a minimum distance 20cm

between the radiator and your body.

FCC Conditions This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation

EU Conformity Statement

This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the EMC Directive

2014/30/EU, the RoHS Directive 2011/65/EU.

2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at

designated collection points. For more information see: www.recyclethis.info.

2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to

indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info.

Industry Canada ICES-003 Compliance This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le pré sent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radioexempts de licence. L'exploitation est autorisé e aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioé lectrique subi, mê me si le brouillage est susceptible d'en compromettre le fonctionnement. Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the

antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.

Conformé ment à la ré glementation d'Industrie Canada, le pré sent é metteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou infé rieur) approuvé pour l'é metteur par Industrie Canada. Dans le but de ré duire les risques de brouillage radioé lectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonné e é quivalente (p.i.r.e.) ne dé passe pas l'intensité né cessaire à l'é tablissement d'une communication satisfaisante.

This equipment should be installed and operated with a minimum distance 20cm between the radiator and your body. Cet é quipement doit ê tre installé et utilisé à une distance minimale de 20 cm entre le radiateur et votre corps.

Safety Instruction

These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss.

The precaution measure is divided into Warnings and Cautions: Warnings: Neglecting any of the warnings may cause serious injury or death. Cautions: Neglecting any of the cautions may cause injury or equipment damage.

Warnings

 The device should be used in compliance with local laws and electrical safety

regulations. Refer to the appropriate documentation for detailed information.

 The device should be used in the environment within temperature range from

-20 °C to 50 °C (-4 °F to 122 °F), and humidity ≤90%

 The input voltage should conform to IEC60825-1 standard: SELV (Safety Extra

Low Voltage) and the Limited Power Source ((Input 12 VDC, 1.5A, output 5 VDC, 2A). Refer to the appropriate documentation for detailed information.

Warnings Follow these safeguards to prevent serious injury or death.

Cautions Follow these precautions to prevent potential injury or material damage.

 Make sure the plug is properly connected to the power socket.  If smoke, odor, or noise arises from the device, immediately turn off the power,

unplug the power cable, and contact the service center.

 The installer and user are responsible for password and security configuration

and its settings.

Cautions

 Do not drop the device or subject it to physical shock.  Wipe the device gently with a clean cloth and a small quantity of ethanol, if

necessary.

 Do not aim the lens at the sun or any other bright light.  When any laser equipment is in use, make sure that the device lens is not

exposed to the laser beam, or it may burn out.

 Do not expose the device to high electromagnetic radiation or extremely hot,

cold, dusty, or damp environments.

 Place the device in a dry and well-ventilated environment.  Keep non-waterproof devices away from liquids.  Keep the device in original or similar packaging while transporting it.  A few device components (e.g., electrolytic capacitor) require regular

replacement. The average lifespan varies, so periodic checking is recommended. Contact your dealer for details.

 Improper use or replacement of the battery may result in explosion hazard.

Replace with the same or equivalent type only. Dispose of used batteries in conformance with the instructions provided by the battery manufacturer.

 Never attempt to disassemble the device.

Safety Instruction

CAUTION: THE PRODUCT IS BUILT IN A REPLACEABLE BATTERY. RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

Laser Light Supplement Warning

Warning: The laser radiation emitted from the device can cause eye injuries, burning of skin or inflammable substances. Before enabling the Light Supplement function, make sure no human or inflammable substances are in front of the laser lens.

vii

Table of Contents

About This Manual .................................................................................... 1

Overview of Contents ........................................................................................ 1

1 Overview ........................................................................................... 2

1.1 Box Content ............................................................................................. 2

1.2 Product Introduction ................................................................................ 3

1.3 Functions ................................................................................................ 3

2 Appearance ...................................................................................... 5

2.1 Dimensions ............................................................................................. 5

2.2 Components ............................................................................................ 6

3 Basic Functions ................................................................................ 7

3.1 Charging the Device ................................................................................. 7

3.1.1 Charging via the charging base ......................................................... 7

3.1.2 Charging via the USB interface .......................................................... 9

3.2 Power On and Off .................................................................................. 10

3.3 Interface Description .............................................................................. 11

3.4 Focus Lens ............................................................................................ 12

3.5 File Exporting ......................................................................................... 13

3.6 Upgrade ................................................................................................. 14

3.7 Operation ............................................................................................... 14

4 Main Configurations ....................................................................... 16

4.1 Temperature Measurement ................................................................... 16

4.1.1 Thermometry Settings .................................................................... 16

4.1.2 Thermometry Rule Configuration .................................................... 18

4.2 Network Configuration ........................................................................... 20

4.2.1 Wi-Fi Settings .................................................................................. 20

4.2.2 WLAN Hot Spot Settings ................................................................. 21

4.2.3 Bluetooth settings ........................................................................... 22

4.3 Storage Settings .................................................................................... 22

4.3.1 Recording Settings .......................................................................... 23

4.3.2 Capturing Settings........................................................................... 24

4.3.3 View recorded files .......................................................................... 25

4.4 Image Configuration .............................................................................. 26

4.4.1 Temperature Difference/Range ....................................................... 26

4.4.2 Palettes Settings ............................................................................. 27

4.4.3 Thermal/Optical Configuration ........................................................ 28

4.5 Alarm Configuration .............................................................................. 29

4.6 Other Configurations ............................................................................. 30

4.6.1 Digital Zoom .................................................................................... 30

4.6.2 LED Light Supplement ..................................................................... 30

4.6.3 Laser Settings ................................................................................. 31

viii

4.6.4 Client Software ................................................................................ 31

5 System Settings ............................................................................. 33

5.1 Unit Settings .......................................................................................... 33

5.2 Display Settings ..................................................................................... 33

5.3 Auto Power-off Duration Settings .......................................................... 34

5.4 Device Initialization ................................................................................ 34

5.5 Device Information ................................................................................ 34

6 Appendix ......................................................................................... 35

6.1 Common Material Emissivity Reference ................................................ 35

6.2 Frequently Asked Questions (FAQ) ........................................................ 36

About This Manual

This document introduces the way to perform and maintain the Handheld

Thermography Camera.

It covers what is Handheld Thermography Camera, how to set up alarm and rules for Handheld Thermography Camera, concrete functions and descriptions of the camera. It shows you how to record and capture with the camera, and export the files. It also advices basic handling methods of frequently happened errors.

Overview of Contents

This document contains the following chapters, and appendixes:

Chapter 1 Overview introduces the handheld Thermography camera, including the box content, product introduction, and major functions.

Chapter 2 Appearance shows the dimensions of the camera and explains the functions of all components.

Chapter 3 Basic Functions describes how to charge, power on and off the camera, focus the thermal lens, and export file. It also tells the lens assembling procedure and how to operate it with touch-screen and by buttons.

Chapter 4 Main Configurations shows you the way to measure temperature and set temperature alarms. Besides, it describes how to record videos and capture snapshots. You can do Wi-Fi settings, palettes selection, temperature section settings, digital zoom, LED light control, and remote control via client software according to this chapter.

Chapter 5 System Settings indicates the unit settings, display settings, and device initialization, etc.

Chapter 6 Appendix lists the emissivity value of common materials for reference and the frequently asked questions.

1 Overview

Handheld Thermography Camera (× 1)

Charging Base (× 1)

Box (× 1)

power Adapter (x1)

USB Cable (× 1)

1.1 Box Content

See the table below for the box content.

Battery (x2)

DISK

User Manual (× 1)

Disk (× 1)

Note: The Handheld Thermography Camera includes one lens cover, one battery and one SD card.

1.2 Product Introduction

The handheld Thermography camera is a camera with both optical images and thermal images. It can do thermometry, video recording, snapshot capturing, alarm, and it can connect to Wi-Fi, Hotspot and Bluetooth. The built-in high-sensitivity IR detector and high-performance sensor detects the variation of temperature and measure the real-time temperature.

The Picture-in-picture technique of the Thermography camera and the fusion of optical view and thermal view, enhances the details of the images display. It supports multiple palettes and alarm types. When the detected temperature in the scene does not match with the alarm rules, the device alarms by color of the palette mode automatically. It helps the users to find the risky part and lower your property loss. The device supports Wi-Fi connection, live viewing, recording, and capturing, etc.

The handheld Thermography camera is easy to use, and adopts ergonomic design. It is widely applied to substations, electricity prevention detection of companies, and reconnaissance survey of construction field.

1.3 Functions

Thermometry

Device detects the real-time temperature, and display it on the screen.

Storage

Device is equipped with memory module to store recorded videos, captured snapshots, and important data.

Fusion

Device can display fusion of thermal view and optical view.

Palette and Alarm

Device supports multiple palettes, and you can set the palette mode according to the alarm function

Wi-Fi Function

Device can be connected to Wi-Fi. You can connect the device via Wi-Fi hot spot, and you can view live view, capture, and recording, etc.

Digital Zoom

Device supports 1× , 2× and 4× digital zoom.

LED Light:

LED light supplement makes the device a torch in required scenarios.

Laser Light Supplement:

Long-distance laser light supplement.

2 Appearance

2.1 Dimensions

244mm (9.6'')

100mm (3.94'')

104mm (4.1'')

2.2 Components

Touch Screen

LED Indicator

Audio

Loudspeaker

ON/OFF

Laser

Lens Sheet

Back

Navigation

USB

Interface SD Slot

LED Light

Supplement

Lens Cover

Laser

Optical Lens

Battery

Focus Knob

Thermal

Lens

Tripod

Interface

Trigger

Laser Button

Hold the Laser button to turn on laser, and release the button to turn off laser.

Navigation Button

Menu Button:

Press the ▽ , △ , ▷ , and ◁ button to

select parameters.

Press the OK button to confirm.

Non-Menu Button:

Press the △ button to turn on/off the

LED light supplement.

Hold the ▽ button to digital zoom.

Lens Sheet Button

Cover the lens to perform the correction.

Back Button

Exit the menu or return to previous menu.

Focus Knob

Adjust lens focal length, refer to 3.4 Focus
