Hikvision Technical Manual
DS-2DF1-401E Mini IP Speed Dome
Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
1
Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
2
Notices
The information in this documentation is subject to change without notice and does not represent any
commitment on behalf of HIKVISION. HIKVISION disclaims any liability whatsoever for incorrect data
that may appear in this documentation. The product(s) described in this documentation are furnished
subject to a license and may only be used in accordance with the terms and conditions of such license.
Copyright © 2006-2010 by HIKVISION. All rights reserved.
This documentation is issued in strict confidence and is to be used only for the purposes for
which it is supplied. It may not be reproduced in whole or in part, in any form, or by any means or
be used for any other purpose without prior written consent of HIKVISION and then only on the
condition that this notice is included in any such reproduction. No information as to the contents or
subject matter of this documentation, or any part thereof, or arising directly or indirectly therefrom,
shall be given orally or in writing or shall be communicated in any manner whatsoever to any third party
being an individual, firm, or company or any employee thereof without the prior written consent of
HIKVISION. Use of this product is subject to acceptance of the HIKVISION agreement required to use
this product. HIKVISION reserves the right to make changes to its products as circumstances may
warrant, without notice.
This documentation is provided “as-is,” without warranty of any kind.
Please send any comments regarding the documentation to:
overseabusiness@hikvision.com
Find out more about HIKVISION at www.hikvision.com
Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
3
Contents
1. Key Features
2. Specifications
3. Dimension
Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
4
1. Key Features
z High Performance Sony CCD
z ±0.1° Preset Accuracy
z 400°/s Pan Preset Speed and 150°/s Tilt Preset Speed
z 0.6-160°/s Manual Pan Speed and 0.7-90°/s Manual Tilt Speed
z Park Action: Start to Call Preset / Patrol / Pattern / Auto Scan / Random Scan /
Frame Scan, after a Defined Time of Inactivity
z Parameter Restore: PTZ & Lens Status after Reboot
z Patterns: Up to 4 On-Screen, User-defined Progr ammable Patterns; Including Pan,
Tilt, Zoom and Preset Functions
z Proportional Pan / Tilt: Continually Decreases Pan / Tilt Speeds, in Proportion to
Depth of Zoom.
z Freeze Frame between Presets
z Programmable Zoom Speeds
z Variable Scan Speed: Scan Speed Can Be Programmable between 1 to 40°/sec
z Programmable Limit Stops for Auto / Random Scan / Fr ame Scan / Manual Modes
z Built-in Menu System for Setup of Programmable Functions
z On-Screen Compass, Pan , Tilt and Zoom Display
z Support Mouse Drag and Zoom
z Alarm I/O: 1 Channel Input and 1 Channel Relay Output
z Alarm Actions: 200 Presets, 8 Patrols, 4 Patterns, Auto Scan, Alarm output, SD
Memory Recording and Notification on PC Client
z Resume after Alarm: Allow the Dome Return to Previously State after Alarm
Acknowledgement
z Built-in Surge Protection
z Working temperature -10℃ ~50℃ (Indoor Models)
Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
5
2. Specifications
Parameter DS-2DF1-401E
Image Sensor 1/4 Inch Interline Transfer SONY CCD
Effective Pixels PAL: 752 (H)×582 (V)
Horizontal
Resolution (TVL)
500 (Color), 570 (B/W)
Signal System PAL
Min. Illumination 0.7Lux / F1.4, 0.02Lux / F1.4 (ICR ON)
White Balance Auto / Indoor / Outdoor / ATW / Manual
AGC Auto / Manual
S/N ratio Better than 50dB
BLC ON / OFF
Electronic Shutter PAL: 1/50~1/120,000s
Day & Night ICR
Digital Zoom Up to 10x
Privacy Blank Up to 4 zones
Camera
Auto Focus Auto / Manual
Focal Length 3.8-38mm, 10x zoom
Zoom Speed 1.7sec (Optical WIDE-TELE )
Angular of View 51.2-5.58 degree (WIDE-TELE)
Lens
Min. Working
distance
200-1000mm
Pan Range 360° endless
Pan Speed
Manual: approx. 0.7°/s-90°/s or 0.7°/s-120°/s, 0.7°/s-160°/s, Programmable in
Menu
Preset: up to approx. 400°/s
Tilt Range 0°~90° (Auto flip)
Tilt Speed
Manual: approx. 0.7°~40°/s or 0.7°~60°/s, 0.7°~90°/s, Programmable in Menu
Preset: up to approx. 150°/s
Proportional Pan /
Tilt Control
YES
Number of Presets 200
Auto Mode OFF / Preset / Patrol / Pattern / Auto Scan / Random Scan / Frame Scan
Patrol 1 / 2 / 3 / 4 / 5 / 6 / 7 / 8
Pattern 1 / 2 / 3 / 4
Freeze Frame Freeze Frame during Preset.
Pan and
Tilt
Auto Flip YES
Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
6
Parameter Restore
Go to the speed dome last status after reboot
Park Action
Start to Call Preset / Patrol / Pattern / Auto Scan / Random Scan / Frame Scan,
after a Defined Time of Inactivity
PTZ Position Display
ON / OFF
Ethernet 10Base-T / 100Base-TX,RJ45 connector
Image Resolution PAL: 704×576, NTSC: 704×480
Frame Rate 25fps (704 × 576), 30fps(704 × 480)
Compression
H.264
Audio
Compression
OggVorbis /16kbps
Audio Mode OFF / Audio input / Audio output
Protocols TCP / IP, HTTP, DHCP, DNS, RTP / RTCP, PPPoE (FTP,SMTP,NTP,SNMP addible)
No. of
Simultaneous Users
Up to 6 users
Dual Streams Support dual streams simultaneously
Mini SD Memory
Card
Manual REC / Alarm REC
Compatible SDHC Standard Cards
User / Host Level 3 Levels: Administrator, Camera control, Live only
Network
Security Measures
User authentication (ID and PW),
Host authentication (MAC address)
Camera Control
Pan / Tilt, Zoom, Focus, Click centering, Drag zoom, Iris, Preset position call and
program, Auto mode.
Camera Title Up to 18 characters
Client
GUI
Clock Display Time: Week: Date, 6 formats on the client
Alarm Input 1channels input
Alarm Output 1 channels output
Alarm
Alarm Actions
Preset position 1 ~ 200, Preset Patrol 1 ~ 8, PATROL 1 ~ 4, SD card recording,
Terminal output, Notification on Client.
Monitor Output 1.0V[p-p] / 75Ω, PAL composite, BNC
Microphone Input
Mic. In (Applicable microphone; Plug-in power type)
2-2.4V[p-p],Input impedance: 1KΩ, ±10%
Input /
Output
Audio Output Audio out, Line level
Menu Language English, Chinese
RS-485 Protocols HIKVISION, PELCO-P, PELCO-D (addible), self-adaptive
Power Supply 12VDC or PoE.
Power
Consumption
12W max
General
Working
-10℃ ~ 50℃ (indoor),
Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
7
Temperature /
Humidity
90% or less (without condensation)
Dimensions 4 inch, Φ145 (mm)×159.8 (mm)
Weight (approx.) 2kg
Hikvision Technical Manual
3. Dimension
©2006 – 2010 by HIKVISION. All rights reserved.
8
