Hikvision DS-2CE56D8T-VPITE User Manual

Key Features

 2 MP high performance COMS
 Ultra-Low Light

 1920 × 1080 resolution
 2.8 mm, 3.6 mm, 6 mm fixed focal lens

 120 dB true WDR, 3D DNR
 EXIR 2.0, Smart IR, up to 20 m IR distance
 PoC.af
 IP67, IK10
 Up the Coax (HIKVISION-C)

DS-2CE56D8T-VPITE
2 MP Ultra-Low Light PoC Dome Camera

.

Camera

Image Sensor

2.0 megapixel progressive scan CMOS

Signal System

PAL/NTSC

Frame Rate

PAL: 1080p@25fps
NTSC: 1080p@30fps

Resolution

1920 (H) × 1080 (V)

Min. illumination

Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR

Shutter Time

PAL: 1/25 s to 1/50, 000 s
NTSC: 1/30 s to 1/50, 000 s

Slow Shutter

Max. 16 times

Lens

2.8 mm, 3.6 mm, 6 mm fixed focal lens

Horizontal Field of View

103.5° (2.8 mm), 82.6° (3.6 mm), 54.4° (6 mm)

Lens Mount

M12

Day & Night

IR cut filter

Angle Adjustment

Pan: 0° to 355°, Tilt:0° to 75°, Rotate: 0° to 355°

Synchronization

Internal synchronization

WDR (Wide Dynamic Range)

> 120 dB

Menu

AGC

Support

Day/Night Mode

Auto/Color/BW (Black and White)

White Balance

ATW/MANUAL

Privacy Mask

ON/OFF, 4 programmable privacy masks

Motion Detection

4 programmable motion areas

Backlight Compensation

WDR/BLC/OFF

3D DNR (Digital Noise Reduction)

Level 1 to 10

Language

English, Chinese

Functions

Brightness, Sharpness, Mirror, Smart IR

Interface

Video Output

1 HD analog output

General

Operating Conditions

-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)

Power Supply

12 VDC ;25%/PoC.af

Power Consumption

Max. 3.2 W

Protection Level

IP67, IK10

Material

Metal

IR Range

Up to 20 m

Communication

Up the coax, Protocol: HIKVISION-C (TVI output)

Dimensions

Φ 111 mm × 82.4 mm (Φ 4.4" × 3.2")

Weight

Approx. 350 g (0.77 lb.)

Specification
