DS-2CD2363G0-I
6 MP IR Fixed Turret Network Camera
BLC/3D DNR/ROI/HLC
IP67
Built-in micro SD/SDHC/SDXC card slot,
up to 128 GB
1/2.9" Progressive Scan CMOS
3072 × 2048@20 fps
2.8/4/6/8 mm fixed lens
Color: 0.01 lux @(F1.2, AGC ON), 0.028
lux @(F2.0, AGC ON), 0 lux with IR
H.265+, H.265, H.264+, H.264
2 Behavior analyses
120dB WDR
Key Features
Specifications
Camera
Image Sensor
1/2.9" Progressive Scan CMOS
Min. Illumination
Color: 0.01 lux @(F1.2, AGC ON), 0.028 lux @(F2.0, AGC ON), 0 lux with IR
Shutter Speed
1/3 s to 1/100,000 s
Slow Shutter
Yes
Auto-Iris
No
Day & Night
IR Cut Filter
Digital Noise Reduction
3D DNR
WDR
120dB
3-Axis Adjustment
Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Lens
Focal Length
2.8/4/6/8 mm
Aperture
F2.0
Focus
Fixed
FOV
2.8 mm, horizontal FOV: 97°, vertical FOV: 63°, diagonal FOV: 120°
4 mm, horizontal FOV: 78°, vertical FOV: 50°, diagonal FOV: 97°
6 mm, horizontal FOV: 60°, vertical FOV: 39°, diagonal FOV: 75°
8 mm, horizontal FOV: 39.5°, vertical FOV: 26°, diagonal FOV: 48°
Lens Mount
M12
IR
IR Range
Up to 30 m
Wavelength
850nm
Compression Standard
Video Compression
Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
H.264 Type
Main Profile/High Profile
H.264+
Main stream supports
H.265 Type
Main Profile
H.265+
Main stream supports
Video Bit Rate
32 Kbps to 16 Mbps
Smart Feature-set
Behavior Analysis
Line crossing detection, intrusion detection
Face Detection
Yes
Region of Interest
Support 1 fixed region for main stream and sub-stream
Max. Resolution
3072 × 2048
Main Stream
50Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656), 25 fps (2560 × 1440, 1920 × 1080, 1280 ×
720)
60Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656), 30fps (2560 × 1440, 1920 × 1080, 1280 ×
720)
Sub-Stream
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream
50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288)
60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240)
