Hikvision DS-2CD2142FWD-IS-4 Specsheet

DS-2CD2142FWD-I (S)
4MP WDR Fixed Dome Network Camera

 Up to 4 megapixel high resolution
 Dual stream
 2.8mm/4mm/6mm fixed lens
 120dB Wide Dynamic Range
 3D Digital Noise Reduction
 Language: Portuguese, English and Chinese
 Support on-board storage, up to 128GB

 DC12V & PoE
 Support H.264+
 Up to 30m IR range
 IP67 weather-proof protection
 IK10
 -S: Audio/Alarm IO
 Bit rate mode: CBR and VBR

Camera Accessories

Inclined ceiling mount

DS-1259ZJ

Wall mount

DS-1272ZJ-110

Wall mount + Junction Box

DS-1272ZJ-110B

Pendant mount

DS-1271ZJ-110B

Junction Box

DS-1280ZJ-DM18

Corner mount

DS-1276ZJ

Vertical Pole mount

DS-1275ZJ

Rain-proof Cap

DS-1250ZJ

Specification

Camera

Image Sensor

1/3" Progressive Scan CMOS

Min. Illumination

0.05Lux @ (F1.2, AGC ON) in the color mode and 0.01Lux @ (F1.2, AGC ON) in B/W mode, 0 Lux with IR

Shutter Speed

1/3 s to 1/10,000 s

Lens

2.7mm, 4mm, 6mm @ F2.0 angle of view: 106°(2.7mm), 83°(4mm), 55.4°(6mm)

Lens Mount

M12

Day &Night

IR cut filter with auto switch

DNR

3D DNR

White Balance

Automatic/Manual

Wide Dynamic Range

120dB

P&T rotation

Pan: 0° ~ 355°, Tilt: 0° ~ 75°, Rotation: 0° ~ 355°

Compression Standard

Video Compression

H.264 / MJPEG/H.264+

H.264 Type

Main Profile

Video Bit Rate

32 Kbps ~ 16 Mbps

Dual streams

Support


Max. Resolution

2688×1520

Max Frame Rate

60Hz: Main stream:20fps(2688×1520), 25fps (2048x1536), 30fps(1920×1080), 30fps (1280x960), 30fps(1280×720),Sub
stream: 30fps(352×240),30fps(704×480)

Image Setting

Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
and AGC

BLC

Support, zone configurable

ROI Codec

Support

Network

Network Storage

NAS (Support NFS,SMB/CIFS), ANR

Detection

Intrusion detection, Line crossing detection, Motion detection, Dynamic analysis

Alarm Trigger

Tampering alarm, Network disconnect, IP address conflict, Storage exception

Protocols

IPV4 and IPV6, TCP/IP, UDP, ICMP, HTTP, HTTPS, SSL, DHCP, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE,
NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour, ARP

General Function

Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering,

Anonymous access, log access of the user, 10 simultaneous connection.
Standard

ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI

Interface

Communication
Interface

1 RJ45 10M/100M Ethernet port, Base T
On-board storage

Built-in Micro SD/SDHC/SDXC slot, up to 128GB

Alarm interface

1x alarm I/O *only for –S models

Audio interface

1x audio I/O *only for –S models

Reset

Yes

DS-2CD2142FWD-I (W)(S)

Network Camera

4MP WDR Fixed Dome
