DS-2CD2085FWD-I
8 MP Network Bullet Camera
Key Features
Up to 8 megapixel high resolution
Max. 3840 × 2160 @20fps
2.8 mm/4 mm/6 mm/8 mm/12 mm fixed
lens, optional
H.265, H.265+, H.264+, H.264
120dB Wide Dynamic Range
3D Digital Noise Reduction
12 VDC & PoE (802.3af)
IR range: up to 30 m
Support on-board storage, up to 128 GB
IP67
Specification
Camera
Image Sensor
1/2.5" Progressive Scan CMOS
Min. Illumination
Color: 0.01 lux @(F1.2, AGC ON), 0 lux with IR
Shutter Speed
1/3 s to 1/100,000 s
Slow Shutter
Support
Lens
2.8 mm, horizontal field of view: 102°
4 mm, horizontal field of view: 79°
6 mm, horizontal field of view: 50°
8 mm, horizontal field of view: 40°
12 mm, horizontal field of view: 23°
Lens Mount
M12
Iris
F2.0
Day &Night
IR cut filter
DNR
3D DNR
Wide Dynamic Range
120dB
3-Axis Adjustment(bracket)
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Compression Standard
Video Compression
Main stream: H.265/H.264
Sub stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
H.264 Type
Main Profile/High Profile
H.264+
Support
H.265 Type
Main Profile
H.265+
Support
Video Bit Rate
32 Kbps to 16 Mbps
Max. Resolution
3840 × 2160
Main Stream
50Hz: 20 fps (3840 × 2160), 25 fps (3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)
60Hz: 20 fps (3840 × 2160), 30fps (3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720)
Sub Stream
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream
50Hz: 25fps (1280 ×720, 640 × 360, 352 × 288)
60Hz: 30fps (1280 ×720, 640 × 360, 352 × 240)
Image Enhancement
BLC/3D DNR
Image Settings
Support rotate mode. Brightness, contrast, saturation, and sharpness are adjustable via web
browser and client software
ROI (Region of Interest)
Support 1 fixed region for main stream and sub stream separately
Day/Night Switch
Auto/Scheduled
Network
Network Storage
Support microSD/SDHC/SDXC card (128G) local storage, NAS (NFS,SMB/CIFS), ANR
Alarm Trigger
Motion Detection, Tampering Alarm, Network Disconnected, IP Address Conflict, Illegal Login,
HDD full, HDD error
Protocols
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP,
SMTP, SNMP, IGMP, 802.1X, QoS, IPv6
Standard
ONVIF (PROFILE S, PROFILE G), ISAPI
155.03(6.10″ )
81.09(3.19″ )
Φ
55
(
2
.
17
″
)
Φ
70
(
2
.
76
″
)
General Function
One-key Reset, Anti-Flicker, Heartbeat, Mirror, Password Protection, Privacy Mask, Watermark,
IP Address Filter
Interface
Communication Interface
1 RJ45 10M/100M self-adaptive Ethernet port
On-board Storage
Built-in microSD/SDHC/SDXC slot, up to 128 GB
Smart Feature-set
Behavior Analysis
Line crossing detection, intrusion detection, unattended baggage detection, object removal
detection
Line Crossing Detection
Cross a pre-defined virtual line, up to 1 pre-defined virtual lines supported
Intrusion Detection
Enter and loiter in a pre-defined virtual region, up to 1 pre-defined virtual regions supported
Object Removal Detection
Objects removed from the pre-defined region, such as the exhibits on display.
Unattended Baggage Detection
Objects left over in the pre-defined region such as the baggage, purse, dangerous materials
Face Detection
Human face appears in the image can be detected and trigger linkage method
General
Operating Conditions
-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
Power Supply
12 VDC ± 25%, 7W
PoE(802.3af, class 3), 7.5W
IR Range
Up to 30 m
Protection Level
IP67
Dimensions
Camera: Φ70 × 155.03 mm (Φ2.76″ × 6.1″)
Package: 216 × 121 × 118 mm (8.5″ × 4.76″ × 4.65″)
Weight
Camera: 410 g (0.9 lb.)
Available Models
DS-2CD2085FWD-I
Dimensions
Unit: mm
DS-1280ZJ-XS
Junction Box
05050320171023
