DS-2CD2063G0-I
6 MP IR Fixed Bullet Network Camera

 BLC/3D DNR/ROI/HLC
 IP67
 Built-in micro SD/SDHC/SDXC card slot,

up to 128 GB

 1/2.9" Progressive Scan CMOS
 3072 × 2048@20 fps
 2.8/4/6/8 mm fixed lens
 Color: 0.01 lux @(F1.2, AGC ON), 0.028

lux @(F2.0, AGC ON), 0 lux with IR

 H.265+, H.265, H.264+, H.264
 2 Behavior analyses
 120dB WDR

Key Features

Specifications

Camera

Image Sensor

1/2.9" Progressive Scan CMOS

Min. Illumination

Color: 0.01 lux @(F1.2, AGC ON), 0.028 lux @(F2.0, AGC ON), 0 lux with IR

Shutter Speed

1/3 s to 1/100,000 s

Slow Shutter

Yes

Day & Night

IR Cut Filter

Digital Noise Reduction

3D DNR

WDR

120dB

3-Axis Adjustment

Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°

Lens

Focal Length

2.8/4/6/8 mm

Aperture

F2.0

Focus

Fixed

FOV

2.8 mm, horizontal FOV: 97°, vertical FOV: 63°, diagonal FOV: 120°
4 mm, horizontal FOV: 78°, vertical FOV: 50°, diagonal FOV: 97°
6 mm, horizontal FOV: 60°, vertical FOV: 39°, diagonal FOV: 75°
8 mm, horizontal FOV: 39.5°, vertical FOV: 26°, diagonal FOV: 48°

Lens Mount

M12

IR

IR Range

Up to 30 m

Wavelength

850nm

Compression Standard

Video Compression

Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264

H.264 Type

Main Profile/High Profile

H.264+

Main stream supports

H.265 Type

Main Profile

H.265+

Main stream supports

Video Bit Rate

32 Kbps to 16 Mbps

Smart Feature-set

Smart Event

Line crossing detection, intrusion detection, face detection

Basic Event

Motion detection, video tampering alarm, exception (network disconnected, IP address conflict,
illegal login, HDD full, HDD error)

Linkage Method

Trigger recording: memory card, network storage, pre-record and post-record
Trigger captured pictures uploading: FTP, HTTP, NAS, Email
Trigger notification: HTTP, ISAPI, Email

Region of Interest

Support 1 fixed region for main stream and sub-stream


Max. Resolution

3072 × 2048

Main Stream

50Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656), 25 fps (2560 × 1440, 1920 × 1080, 1280 ×

720)
60Hz: 20 fps (3072 × 2048, 3072 × 1728, 2944 × 1656), 30 fps (2560 × 1440, 1920 × 1080, 1280 ×

720)

Sub-Stream

50Hz: 25 fps (640 × 480, 640 × 360, 320 × 240)
