DS-2CD2043G0-I
4 MP IR Fixed Bullet Network Camera
BLC/3D DNR/ROI/HLC
IP67
Built-in micro SD/SDHC/SDXC card slot,
up to 128 GB
3-Axis adjustment
1/3" Progressive Scan CMOS
2688 × 1520 @30fps
2.8/4/6/8 mm fixed lens
Color: 0.01 Lux @ (F1.2, AGC ON),
0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR
H.265+, H.265, H.264+, H.264
Three streams
120dB WDR
2 Behavior analyses, and face detection
Key Features
Specifications
Camera
Image Sensor
1/3" Progressive Scan CMOS
Min. Illumination
Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR
Shutter Speed
1/3 s to 1/100,000 s
Slow Shutter
Yes
Auto-Iris
No
Day & Night
IR Cut Filter
Digital Noise Reduction
3D DNR
WDR
120dB
3-Axis Adjustment
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Lens
Focal length
2.8/4/6/8 mm
Aperture
F1.6
Focus
Fixed
FOV
2.8 mm, horizontal FOV: 103°, vertical FOV: 58°, diagonal FOV: 123°
4 mm, horizontal FOV: 83°, vertical FOV: 45°, diagonal FOV: 99°
6 mm, horizontal FOV: 51°, vertical FOV: 29°, diagonal FOV: 58°
8 mm, horizontal FOV: 39°, vertical FOV: 22°, diagonal FOV: 45°
Lens Mount
M12
IR
IR Range
Up to 30 m
Wavelength
850nm
Compression Standard
Video Compression
Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
H.264 Type
Main Profile/High Profile
H.264+
Main stream supports
H.265 Type
Main Profile
H.265+
Main stream supports
Video Bit Rate
32 Kbps to 16 Mbps
Smart Feature-set
Behavior Analysis
Line crossing detection, intrusion detection
Face Detection
Yes
Region of Interest
1 fixed region for main stream and sub-stream
Max. Resolution
2688 × 1520
Main Stream
50Hz:25fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080)
60Hz: 30fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080)
Sub-Stream
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream
50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288)
60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240)
Image Enhancement
BLC/3D DNR/HLC
Image Setting
Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client
software or web browser
Target Cropping
No
Day/Night Switch
Day/Night/Auto/Schedule
Network
Network Storage
Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Alarm Trigger
Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD
full, HDD error
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP,
SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
General Function
One-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask,
watermark, IP address filter
Firmware Version
V5.5.80
API
ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View
Up to 6 channels
User/Host
Up to 32 users
3 levels: Administrator, Operator and User
Client
iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
Web Browser
Plug-in required live view:
IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11
Plug-in free live view:
Chrome 45.0+, Firefox 52.0+
Interface
Communication Interface
1 RJ45 10M/100M self-adaptive Ethernet port
Video Output
No
On-board storage
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
SVC
H.264 and H.265 encoding
Reset Button
Yes
General
Operating Conditions
-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
Power Supply
12 VDC ± 25%, Φ 5.5 mm coaxial power plug
PoE (802.3af, class 3)
Power Consumption and
Current
12 VDC, 0.5 A, max. 6 W
PoE (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, max. 7.5 W
Protection Level
IP67
Material
Metal
Dimensions
Camera: Φ 70 × 155.03 mm (Φ 2.8" × 6.1")
Package: 216 × 121 × 118 mm (8.5" × 4.8" × 4.7")
Weight
Camera: Approx. 420 g (0.9 lb.)
With Package: Approx. 700 g (1.5 lb.)
Available Model:
DS-2CD2043G0-I (2.8/4/6/8 mm)
155.03(6.10″ )
81.09(3.19″ )
Φ
55
(
2
.
17
″
)
Φ
70
(
2
.
76
″
)
DS-1280ZJ-XS
Junction Box
DS-1280ZJ-XS(Black)
Junction Box
Accessory
Dimension
