QuickSpecs

Overview

HP EliteBook 820 G4 Notebook PC

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

Front / Right

1. WLAN antennas (2) 13.

2. WWAN antennas (2) 14.

3. Internal microphones (2) 15. Fingerprint reader (select models)

4. Webcam LED (select models) 16. NFC (select models)

5. Webcam (select models) 17. Touchpad buttons (4)

6. SIM card slot 18. Indicator LEDs: Wireless Light, Power Light, AC

7. Power connector 19. Touchpad

8. Docking connector 20. Pointstick

DisplayPort™ 1.2 USB-C™ port

Adapter/Battery Light, Storage Usage Light

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 1

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC

QuickSpecs

HP EliteBook 850 G4 Notebook PC

Overview

Left



1. Security lock slot 3. USB 3.1 Gen 1 Charging port

2. VGA port 4. Smart Card Reader

 

  

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 2

QuickSpecs

Overview

HP EliteBook 840 G4 Notebook PC

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

Front / Right

1. WLAN antennas (2) 13. Microphone/ headphones combo jack

2. WWAN antennas (2) 14. SD card slot

3. Internal microphones (2) 15.

4. Webcam LED (select models) 16.

5. Webcam (select models) 17. Fingerprint reader (select models)

6. Wireless on/off button 18. NFC (select models)

7. Speaker mute button 19. Touchpad buttons (4)

8. SIM card slot 20. Indicator LEDs: Wireless Light, Power Light, AC

9. Power connector 21. Touchpad

10. Docking connector 22. Pointstick

11. Ethernet port 23. Power button

12. USB 3.1 Gen 1 port

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



DisplayPort™ 1.2 USB-C™ port

Adapter/Battery Light, Storage Usage Light

Page 3

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC

QuickSpecs

HP EliteBook 850 G4 Notebook PC

Overview

Left



1. Security lock slot 3. USB 3.1 Gen 1 Charging port

2. VGA port 4. Smart Card Reader



Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 4

QuickSpecs

Overview

HP EliteBook 850 G4 Notebook PC

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

Front / Right

1. WLAN antennas (2) 13. SD card slot

2. WWAN antennas (2) 14. Microphone/ headphones combo jack

3. Internal microphones (2) 15.

4. Webcam LED (select models) 16.

5. Webcam (select models) 17. Fingerprint reader (select models)

6. Wireless on/off button 18. NFC (select models)

7. Speaker mute button 19. Touchpad buttons (4)

8. SIM card slot 20. Indicator LEDs: Wireless Light, Power Light, AC

9. Power connector 21. Touchpad

10. Docking connector 22. Pointstick

11. Ethernet port 23. Power button

12. USB 3.1 Gen 1 port

DisplayPort™ 1.2 USB-C™ port

Adapter/Battery Light, Storage Usage Light

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 5

QuickSpecs

Overview

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

Left



1. Security lock slot 3. USB 3.1 Gen 1 Charging port

2. VGA port 4. Smart Card Reader



Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 6

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC

QuickSpecs

HP EliteBook 850 G4 Notebook PC

Overview

AT A GLANCE

 Stylish magnesium and aluminum chassis provides optimal durability with minimal weight  Thin design but no adapters are needed with built-in VGA, drop-jaw RJ-45 Ethernet port, USB 3.1 Gen 1 Ports, USB Type-

C™, and full-size DisplayPort™ 1.2 for high resolution support

 Design allows memory, storage, wireless modules, and battery to be customer serviceable and upgradeable  Choice of 7  Integrated Intel® HD Graphics 620 or AMD Radeon™ R7 M465 discrete graphics (HP EliteBook 850 option only)  Optimize your audio experience for conference calls and remote collaboration with optional HD webcam, dual-array

microphones, premium speakers, HP Noise Cancellation Software, HP Audio Boost, and audio custom-tuned by HP and Bang & Olufsen

 Featuring HP Premium Keyboard with Pointstick and 10-key numeric keypad available on HP EliteBook 850  Optional back-lit keyboard keeps you productive in all settings with HP DuraKeys to help protect keys from fading  Passed MIL-SPEC 810G testing, plus an additional 120,000 hours of reliability testing through HP's Total Test Process  Enhanced security features including TPM2.0, SmartCard Reader, HP Sure Start self-healing BIOS, HP Client Security,

Self-Encrypting storage drives, and optional Fingerprint reader

 HP Touchpoint Manager

efficient manageability

 LED-backlit displays:

o HP EliteBook 820: 31.75 cm (12.5”) diagonal HD, FHD Non-Touch or FHD Touch o HP EliteBook 840: 35.56 cm (14”) diagonal HD, FHD, QHD Non-Touch or FHD Touch o HP EliteBook 850: 39.6 cm (15.6”) diagonal HD, FHD, UHD Non-Touch or FHD Touch

 Flexible wireless connectivity options including 4G LTE mobile broadband  Easily dock with the optional HP UltraSlim Docking Station  Choice of hard drives up to 1 TB and solid state drives up to 512 GB  DDR4 memory up to 32 GB  Preinstall Windows 10, FreeDOS 2.0 or NeoKylin Linux 64 versions

th

generation Intel® Core™ i7, i5 and i3 processors

3

, HP Image Assistant and HP Management Integration Kit provide additional tools for more

1

1. MIL STD 810G testing is not intended to demonstrate fitness for Department of Defense contracts requirements or for military use. Test results are not a guarantee of future performance under these test conditions. Damage under the MIL STD test conditions or any accidental damage requires an optional HP Accidental Damage Protection Care Pack.

2. Recharges your battery up to 50% within 30 minutes when the system is off or in standby mode. Power adapter with a minimum capacity of 65 watts is required. After charging has reached 50% capacity, charging will return to normal. Charging time may vary +/-10% due to System tolerance.

3. HP Touchpoint Manager requires purchase of a subscription and supports Android™, iOS and Windows 7 or higher operating systems and PCs, notebooks, tablets and smartphones from various manufacturers. Not available in all countries see www.hp.com/touchpoint for availability information.

NOTE: See important legal disclosures for all listed specs in their respective features sections.

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 7

QuickSpecs

Technical Specifications



PRODUCT NAMES

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

OPERATING

Preinstalled

Web Supported

Note: Your product does not support Windows 8 or Windows 7

In accordance with Microsoft’s support policy, HP does not support the Windows 8 or Windows 7 operating system on products configured with Intel and AMD 7th generation and forward processors or provide any Windows 8 or Windows 7 drivers on http://www.support.hp.com.

1. Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is automatically updated, which is always enabled. ISP fees may apply and additional requirements may apply over time for updates. See http://www.windows.com.

SYSTEM

1

Windows 10 Pro 64 Windows 10 Home 64 FreeDOS 2.0 NeoKylin Linux 64

Windows 10 Enterprise 64

1

PROCESSOR

Intel® Core™ i7-7600U (2.8 GHz, up to 3.9 GHz with Intel Turbo Boost Technology, 4 MB cache, 2 cores)

Intel® Core™ i7-7500U (2.7 GHz, up to 3.5 GHz with Intel Turbo Boost Technology, 4 MB cache, 2 cores) Intel® Core™ i5-7300U (2.6 GHz, up to 3.5 GHz with Intel Turbo Boost Technology, 3 MB cache, 2 cores) Intel® Core™ i5-7200U (2.5 GHz, up to 3.1 GHz with Intel Turbo Boost Technology, 3 MB cache, 2 cores) Intel® Core™ i3-7100U (2.4 GHz, 3 MB cache, 2 cores)

1. Multicore is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and software configurations. Intel’s numbering is not a measurement of higher performance.

2. Not available with Intel iAMT (Not available with vPro™)

NOTE: Processor speed denotes maximum performance mode; processors will run at lower speeds in battery optimization mode.

1,2

1

1,2

1

1,2

CHIPSET

Chipset integrated with processor

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 8

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC

QuickSpecs

HP EliteBook 850 G4 Notebook PC

Technical Specifications



INTEL® CORE I5 WITH VPRO/CORE I7 WITH VPRO TECHNOLOGY CAPABLE

Intel® Core™ i5 with vPro™ and Intel® Core® i7 with vPro™ technology is a selectable feature that is available on units configured with select processors, on select Intel® Wireless WLAN module and a preinstalled Windows operating system.

1. Requires a Windows operating system, network hardware and software, connection with a power source, and a direct (non-VPN) corporate network connection which is either cable or wireless LAN.

NOTE: Some functionality of this technology, such as Intel® Active management technology and Intel Virtualization technology, requires additional 3rd party software in order to run. Availability of future "virtual appliances" applications for Intel vPro technology is dependent on 3rd party software providers. Microsoft Windows required.

GRAPHICS

Integrated

Intel® HD Graphics 620

Discrete AMD Radeon™ R7 M465 2 GB GDDR5 dedicated (HP EliteBook 850 only)

DISPLAY

HP EliteBook 820 Internal Non-Touch

31.75 cm (12.5”) diagonal HD SVA anti-glare slim LED-backlit non-touch (1366 x 768)

31.75 cm (12.5”) diagonal HD SVA anti-glare slim LED-backlit non-touch with camera (1366 x 768)

31.75 cm (12.5”) diagonal FHD UWVA anti-glare ultra-slim LED-backlit non-touch (1920 x 1080)

31.75 cm (12.5”) diagonal FHD UWVA anti-glare ultra-slim LED-backlit non-touch with camera (1920 x 1080) Touch

31.75 cm (12.5”) diagonal FHD UWVA ultra slim with camera, Corning® Gorilla® Glass 4 LED-backlit touch screen (1920 x 1080)

HP EliteBook 840 Internal Non-Touch

35.56 cm (14”) diagonal HD SVA anti-glare slim LED-backlit non-touch (1366 x 768)

35.56 cm (14”) diagonal HD SVA anti-glare slim LED-backlit non-touch with camera (1366 x 768)

35.56 cm (14”) diagonal FHD SVA anti-glare slim LED-backlit non-touch (1920 x 1080)

35.56 cm (14”) diagonal FHD SVA anti-glare slim LED-backlit non-touch with camera (1920 x 1080)

35.56 cm (14”) diagonal QHD UWVA anti-glare ultraSlim LED-backlit non-touch (2560 x 1440)

35.56 cm (14”) diagonal QHD UWVA anti-glare ultraSlim LED-backlit non-touch with camera (2560 x 1440)

HP Sure View integrated privacy screen 35.56 cm (14”) diagonal FHD SVA anti-glare slim LED-backlit non-touch with camera (1920 x 1080) (Planned to be available first quarter 2017 and must be configured at purchase.) Touch

35.56 cm (14") diagonal FHD SVA slim with camera, Corning® Gorilla® Glass 4 LED-backlit touch screen (1920 x 1080)

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 9

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC

QuickSpecs

HP EliteBook 850 G4 Notebook PC

Technical Specifications



HP EliteBook 850 Internal Non-Touch

39.6 cm (15.6”) diagonal HD SVA anti-glare slim LED-backlit non-touch (1366 x 768)

39.6 cm (15.6”) diagonal HD SVA anti-glare slim LED-backlit non-touch with camera (1366 x 768)

39.6 cm (15.6”) diagonal FHD SVA anti-glare slim LED-backlit non-touch (1920 x 1080)

39.6 cm (15.6”) diagonal FHD SVA anti-glare slim LED-backlit non-touch with camera (1920 x 1080)

39.6 cm (15.6”) diagonal UHD UWVA anti-glare slim LED-backlit non-touch (3840 x 2160)

39.6 cm (15.6”) diagonal UHD UWVA anti-glare slim LED-backlit non-touch with camera (3840x 2160) Touch

39.6 cm (15.6") diagonal FHD SVA slim with camera, Corning® Gorilla® Glass 4 LED-backlit touch screen (1920 x 1080)

VGA Port supports resolutions up to 1920 x 1200 external resolution @60 Hz

DisplayPort™ 1.2 Supports resolutions up to 4096 x 2304 @ 60Hz Resolutions are dependent upon monitor capability, and resolution and color depth settings.

Displays support Supports dual display through the dock Supports 3 independent displays if used with optional HP UltraSlim Docking Station.

2

NOTE: Resolutions are dependent upon monitor capability, and resolution and color depth settings.

1. HD content required to view HD images.

2. Sold separately or as an optional feature.

STORAGE AND DRIVES

SATA, 7 mm 2.5" Hard Drives

500 GB 7200 rpm Hard Drive 500 GB 7200 rpm Self-Encrypting Hard Drive (Opal 2) 500 GB 7200 rpm Self-Encrypting Hard Drive FIPS-140-2 500 GB Hybrid 8 GB Cache 1 TB 5400 rpm Hard Drive

M.2 (NGFF) 2280 Solid State Drives

128 GB SATA-3 Value Solid State Drive 256 GB PCIe Gen3x4 NVMe TLC Solid State Drive 360 GB PCIe Gen3x4 NVMe TLC Solid State Drive (Planned to be available first quarter 2017.) 512 GB PCIe Gen3x4 NVMe TLC Solid State Drive 512 GB PCIe Gen3x4 NVMe MLC Solid State Drive 256 GB SATA-3 TLC Self-Encrypting Solid State Drive (Opal 2) 512 GB PCIe Gen 3x4 NVMe TLC Self-Encrypting Solid State Drive (Opal 2) 512 GB SATA-3 TLC Solid State Drive FIPS-140-2 (Planned to be available first quarter 2017.)

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 10

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC

QuickSpecs

HP EliteBook 850 G4 Notebook PC

Technical Specifications



NOTE: For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30GB of system disk is reserved for system recovery software.

HP 3D DriveGuard (Windows and Hard Drives only)

The hard drive is mounted directly to the notebook frame, reducing the transmission of shock to the hard drive

Dual Drive Configuration

HP EliteBook 840 & 850 can be configured with a hard drive and M.2 SSD drive.

MEMORY

Supports the following configurations

DDR4 – 2400 SDRAM (Transfer rates up to 2133 MT/s) Two SODIMM slots supporting dual-channel memory Both slots are customer accessible / upgradeable

Standard 4096 MB Total System Memory (4096 MB x 1) 8192 MB Total System Memory (4096 MB x 2) 8192 MB Total System Memory (8192 MB x 1) 16384 MB Total System Memory 16384 MB x 1) 16384 MB Total System Memory (8192 MB x 2) 32768 MB Total System Memory (16384 MB x 2)

Maximum Memory Up to 32 GB

Dual-channel

Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory slots.

NOTE: Improved system performance when memory is added in pairs (dual channel). Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.

NETWORKING/COMMUNICATIONS

Wireless

Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring support for the latest industry standards. Optional Broadband Wireless (WWAN) requires a Windows operating system and is available in select countries as a standard, factory configurable feature only. Integrated Bluetooth® is also available with any of the supported wireless LAN and wireless WAN options.

Broadband Wireless (WWAN) Via M.2 Minicard

HP lt4120 Qualcomm® Snapdragon™ X5 LTE Mobile Broadband Module HP lt4132 LTE/HSPA+ 4G Mobile Broadband Module HP hs3210 WW HSPA+ with GPS Mobile Broadband

Note: The HP EliteBook 850 G4 UHD panel is not compatible with WWAN.

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



1

Page 11

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC

QuickSpecs

HP EliteBook 850 G4 Notebook PC

Technical Specifications



Wireless LAN (WLAN) Via M.2 Minicard

Intel® Dual Band Wireless-AC 8265 802.11 a/b/g/n/ac (2x2) WiFi and Bluetooth® 4.2 combo (vPro and non-vPro)

2

Intel® Dual Band Wireless-AC 3168 802.11 a/b/g/n/ac (1x1) WiFi and Bluetooth® 4.2 combo (non-vPro)

2

Near Field Communication (NFC)

HP Module with NXP NFC Controller NPC100 I2C NCI

Support for Miracast

1. Sold separately or as an optional feature.

2. Wireless access point and Internet service is required and is not included. Availability of public wireless access points limited.

3. WWAN module requires separately purchased service contract. Check with service provider for coverage and availability in your area. Connection speeds will vary due to location, environment, network conditions, and other factors. 4G LTE not available on all products, in all regions.

Communications Intel® Ethernet Connection I219-V 10/100/1000 Ethernet(With Intel® i3-7100U, i5-7200U, and i7-7500U) Intel® Ethernet Connection I219-LM 10/100/1000 Ethernet(With Intel® i5-7300U and i7-7600U)

NOTE: The term "10/100/1000" or "Gigabit" Ethernet indicates compatibility with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server and network infrastructure is required.

1



AUDIO/MULTIMEDIA

Audio

Audio by Bang & Olufsen HP Audio Boost HP Noise Cancellation Software Digital Microphones (Dual Array) 2 Premium Stereo Speakers

Webcam Optional

1. Sold separately or as an optional feature.

2. HD content required to view HD images.

3. Internet access required.

1

720p HD2 webcam3

KEYBOARDS/POINTING

Keyboard HP Premium Keyboard

The HP Premium, spill-resistant keyboard with drain is designed using a thin layer of Mylar film under the keyboard and includes an all-metal keyboard deck for greater rigidity. Backlit keyboard with HP DuraKeys is available as an option.



DEVICES/BUTTONS & FUNCTION KEYS

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016

Page 12

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC

QuickSpecs

HP EliteBook 850 G4 Notebook PC

Technical Specifications



The 820 has 79/80-key, 840 has 85-86-key, the 850 has 100/101-key compatible keyboard and features a full-pitch key layout with desktop keyboard features, such as editing keys, both left and right control and alt keys, and function keys. US and International key layouts are available.

Pointing Devices

Glass Touchpad On/Off button Taps enabled as default Gestures enabled by default - 2 Finger Scrolling, 2 Finger Zoom (Pinch)

Function Keys HP EliteBook 820

F1 - Sleep F2 - Blank F3 - Backlit Keyboard Toggle F4 - Display Switching F5 - Brightness Down F6 - Brightness Up F7 - Audio Mute F8 - Volume Down F9 - Volume Up F10 - Mic Mute F11 - Wireless F12 - Num Lock

Hidden Function Keys Fn+R - Break Fn+S - Sys Rq Fn+C - Scroll Lock

HP EliteBook 840

F1 - Sleep F2 - Blank (Privacy Key for configurations with HP Sure View integrated privacy screen) F3 - Backlit Keyboard Toggle F4 - Display Switching F5 - Brightness Down F6 - Brightness Up F7 - Blank F8 - Volume Down F9 - Volume Up F10 - Mic Mute F11 - Blank F12 - Num Lock

Hidden Function Keys

Fn+R - Break Fn+S - Sys Rq Fn+C - Scroll Lock

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 13

QuickSpecs

Technical Specifications



HP EliteBook 850

F1 - Sleep F2 - Blank F3 - Backlit Keyboard Toggle F4 - Display Switching F5 - Brightness Down F6 - Brightness Up F7 - Blank F8 - Volume Down F9 - Volume Up F10 - Mic Mute F11 - Blank F12 - Blank

Hidden Function Keys

Fn+R - Break Fn+S - Sys Rq Fn+C - Scroll Lock

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

SOFTWARE AND SECURITY

Preinstalled Software BIOS

HP BIOSphere HP Sure Start Gen3 HP DriveLock | HP Automatic DriveLock BIOS Update via Network Master Boot Record Security Power On Authentication Secure Erase Pre-boot Authentication

Communication/Connectivity

HP Mobile Connect Pro (Windows 10 only) Native Miracast Support4 HP LAN-WLAN Protection HP MAC Address Manager HP Wireless Wakeup

HP Value Add Software

HP 3D DriveGuard (requires Windows)

HP ePrint Driver +JetAdvantage

HP Hotkey Support

HP Recovery Manager

HP Jumpstart

1

10

2

5

3

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 14

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC

QuickSpecs

HP EliteBook 850 G4 Notebook PC

Technical Specifications



HP Support Assistant

HP Noise Cancellation Software

Microsoft Products

Buy Office Bing Search

6

Skype

Manageability

HP Driver Packs HP SoftPaq Download Manager (SDM) HP System Software Manager (SSM) HP BIOS Config Utility (BCU) HP Client Catalog HP MIK for Microsoft SCCM HP Image Assistant LANDESK Management8

For more information on HP Client Management Solutions refer to: http://www.hp.com/go/clientmanagement.

Client Security Software

HP Client Security

 HP Security Manager (including Credential Manager and Password Manager)  HP Drive Lock  HP Fingerprint Sensor  HP Password Manager  Absolute Persistence Module  Power On Authentication  HP Device Access Manager

Microsoft Defender

Security

Trusted Platform Module (TPM) 2.0 (Infineon SLB9670). Common Criteria EAL4+ Certified.

Convertible to FIPS 140-2 Certified mode. (TPM 2.0 is not available for Win 7 32-bit.) Fingerprint Reader (On select models)

For more information on HP Client Security Software Suite, refer to http://www.hp.com/go/clientsecurity.

1. Available only on business PCs with HP BIOS. HP BIOSphere features may vary depending on the PC platform & configuration.

2. For the methods outlined in the National Institute of Standards and Technology Special Publication 800-88.

7

9

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 15

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC

QuickSpecs

HP EliteBook 850 G4 Notebook PC

Technical Specifications



3. HP Mobile Connect Pro is only available on preconfigured devices with WWAN. For geographic availability refer to www.hp.com/go/mobileconnect

4. Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming media players that also support Miracast. You can use Miracast to share what you’re doing on your PC and present a slide show. For more information: http://windows.microsoft.com/en-us/windows-8/project-wireless-

screen-miracast

5. Requires an Internet connection to HP web-enabled printer and HP ePrint account registration (for a list of eligible printers, supported documents and image types and other HP ePrint details, see www.hp.com/go/eprintcenter). Requires optional broadband module. Broadband use requires separately purchased service contract. Check with service provider for coverage and availability in your area. Separately purchased data plans or usage fees may apply. Print times and connection speeds may vary.

6. Skype is not offered in China.

7. Not preinstalled, however available for download in December 2015 at http://www.hp.com/go/clientmanagement

8. Subscription required.

9. Absolute agent is shipped turned off, and will be activated when customers activate a purchased subscription. Subscriptions can be purchased for terms ranging multiple years. Service is limited, check with Absolute for availability outside the U.S. The Absolute Recovery Guarantee is a limited warranty. Certain conditions apply. For full details visit: service provided by Absolute Software. If utilized, the Recovery Guarantee is null and void. In order to use the Data Delete service, customers must first sign a Pre-Authorization Agreement and either obtain a PIN or purchase one or more RSA SecurID tokens from Absolute Software.

10. Available on HP EliteBook products equipped with Intel® 7th generation processors.

https://www.absolute.com/en/about/legal/agreements/absolute. Data Delete is an optional

POWER

Power Supply

HP 45W Smart AC Adapter HP 45W 2-prong DC jack AC Adapter HP 65W Smart AC Adapter HP 65W Smart AC Adapter EM

1. Availability may vary by country.

2. Supports HP Fast Charging. Required for HP EliteBook 850 configured with optional discrete graphics.

Power cord is configurable; either 3.2 feet or 6 feet (1.0 or 1.8 meter) Total length including external AC adapter is 9.2 feet or 12 feet (2.86 or 3.66 meter)

Battery HP EliteBook 820

HP Long Life 3-cell, 49 WHr Li-ion polymer (Supports HP Fast Charging with 65W AC Adapter)

HP EliteBook 840 & 850

HP Long Life 3-cell, 51 WHr Li-ion polymer (Supports HP Fast Charging with 65W AC Adapter)

1

2

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 16

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC

QuickSpecs

HP EliteBook 850 G4 Notebook PC

Technical Specifications



1

Battery Life

Platform Other HW Details Battery UMA Graphics Discrete Graphics

HP EliteBook 820 G4 HDD 3-cell (49WHr) Up to 11 hrs 15 mins N/A

HP EliteBook 820 G4 SSD 3-cell (49WHr) Up to 14 hrs 45 mins N/A

HP EliteBook 840 G4 HDD 3-cell (51WHr) Up to 12 hrs 15 mins N/A

HP EliteBook 840 G4 SSD 3-cell (51WHr) Up to 15 hrs 15 mins N/A

HP EliteBook 850 G4 HDD 3-cell (51WHr) Up to 12 hrs 15 mins Up to 11 hrs 30 mins

HP EliteBook 850 G4 SSD 3-cell (51WHr) Up to 14 hrs 15 mins Up to 14 hrs 15 mins

1. Windows 10/MM14 battery life will vary depending on various factors including product model, configuration, loaded applications, features, use, wireless functionality, and power management settings. The maximum capacity of the battery will naturally decrease with time and usage. See www.bapco.com for additional details.

Power Conservation

Hibernation Standby ACPI compliance

WEIGHTS & DIMENSIONS

HP EliteBook 820 Weight

Starting at 2.78 lbs (1.26 kg) (3-cell battery (49WHr), UMA, no FPR, 1 SODIMM, WLAN, M.2 SSD, no camera, no WWAN, Non-Touch panel) Starting at 3.05 lbs (1.38 kg) (3-cell battery (49WHr), UMA, no FPR, 1 SODIMM, WLAN, M.2 SSD, no camera, no WWAN, Touch)

Dimensions

12.2 x 8.6 x 0.74 in (Front) 31 x 21.89 x 1.89 cm

HP EliteBook 840 Weight

1

2

(w x d x h)

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 17

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC

QuickSpecs

HP EliteBook 850 G4 Notebook PC

Technical Specifications



Starting at 3.27 lbs (1.48 kg) (3-cell battery (51WHr), UMA, no FPR, 1 SODIMM, WLAN, M.2 SSD, no camera, no WWAN, Non-Touch panel) Starting at 3.76 lbs (1.70 kg) (3-cell battery (51WHr), UMA, no FPR, 1 SODIMM, WLAN, M.2 SSD, no camera, no WWAN, Touch)

2

1



(w x d x h)

Dimensions

13.3 x 9.3 x 0.74 in (Front)

33.8 x 23.7 x 1.89 cm

HP EliteBook 850 Weight

Starting at 4.06 lbs (1.84 kg) (3-cell battery (51WHr), UMA, no FPR, 1 SODIMM, WLAN, M.2 SSD, no camera, no WWAN, Non-Touch panel)

Starting at 4.54 lbs (2.06 kg) (3-cell battery (51WHr), UMA, no FPR, 1 SODIMM, WLAN, M.2 SSD, no camera, no WWAN, Touch)

Dimensions

15.10 x 10.10 x 0.76 in (Front)

38.36 x 25.77 x1.94 cm

1. Weight varies by configuration and components.

2. Height varies depending upon where on the notebook the measurement is made.

2

(w x d x h)

PORTS/SLOTS

Ports

1 USB 3.1 Gen 1 Charging Port

1 USB 3.1 Gen 1 Port 1 USB-C™ port (Up to 5 Gbps data transfer and 15W power) 1 DisplayPort™ 1.2 1 VGA 1 RJ-45 / Ethernet 1 Docking connector 1 Headphone/Microphone Combo 1 AC Port

NOTE: Cables are not included.

Slots SD Media Card Reader Slot Supports SD, SDHC, SDXC

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 18

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC

QuickSpecs

HP EliteBook 850 G4 Notebook PC

Technical Specifications



SERVICE AND SUPPORT

Limited 3-year or 1-year limited warranty options available, depending on country. Batteries have a default one year limited

warranty except for Long Life batteries which will have same 1-year or 3-year limited warranty as the platform.Optional HP Care Pack Services

1. HP Care Packs are sold separately. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on date of hardware purchase. Restrictions and limitations apply. For details, visit www.hp.com/go/cpc. HP services are governed by the applicable HP terms and conditions of service provided or indicated to Customer at the time of purchase. Customer may have additional statutory rights according to applicable local laws, and such rights are not in any way affected by the HP terms and conditions of service or the HP Limited Warranty provided with your HP Product.

1

are extended service contracts which go beyond your standard limited warranties.

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 19

QuickSpecs

Technical Specifications



SYSTEM UNIT

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

Stand-Alone Power Requirements (AC Power)

Max Operating Power

Temperature Operating

Non-operating

Relative Humidity

Shock Operating

Non-operating

Random Vibration Operating

Nominal Operating Voltage

Average Operating Power Windows 10 (64-bit)

Integrated graphics 12.9 W

19.5 V

Discrete < 90W UMA < 65W

32° to 95° F (0° to 35° C) (not writing optical)

41° to 95° F (5° to 35° C) (writing optical)

-4° to 140° F (-20° to 60° C)

10% to 90%, non-condensing

5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature

40 G, 2 ms, half-sine

200 G, 2 ms, half-sine

0.75 grms

Non-operating

Altitude (unpressurized) Operating

Non-operating

Planned Industry Standard

Certifications

ENERGY STAR

EPEAT®

ICES



UL

CSA

FCC Compliance

®

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016

1.50 grms

-50 to 10,000 ft (-15.24 to 3,048 m)

-50 to 15,000 ft (-15.24 to 12,192 m)

Yes

Select models*

Registered Gold in United States**

Yes

Page 20

QuickSpecs

Technical Specifications



Australia / NZ RCM Compliance

Yes

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

CCC

Japan VCCI Compliance

KC

BSMI

CE Marking Compliance

CIT

EAC

SABS

UKRSERTCOMPUTER

For accessibility information on HP products, please visit: http://www.hp.com/accessibility.

Saudi Arabian Compliance (SASO)

Yes



Displays

Note: All specifications represent the typical specifications provided by HP's component manufacturers; actual performance may

vary either higher or lower.

31.75 cm (12.5”) diagonal LED backlight HD Slim eDP SVA Antiglare non-touch (1366 x 768)



Outline Dimensions (W x H x D)

Active Area Weight Diagonal Size Surface Treatment Contrast Ratio

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016

291.0 x 181.9 X3.0 mm (max)

276.62 mm x 155.52 mm 250g max

31.75 cm (12.5”) AG 300:1 (typ)

Page 21

QuickSpecs

Technical Specifications



Refresh Rate Response time Pixel Per Inch (PPI) Brightness

Pixel Resolution

Interface LCD Mode Viewing Angle

60Hz 16ms typ. 125 220nits

Format Configuration

eDP 1.2  TN SVA 45/45/25/35

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

1366 x 768 (HD) RGB

31.75 cm (12.5”) diagonal LED backlight FHD UltraSlim eDP UWVA Anti-glare non-touch (1920 x 1080)

31.75 cm (12.5”) diagonal LED backlight FHD UltraSlim eDP UWVA (1920 x 1080) Touch

Outline Dimensions

(W x H x D)

Active Area Weight Diagonal Size Surface Treatment Contrast Ratio Refresh Rate Response time Pixel Per Inch (PPI) Brightness

Pixel Resolution

Interface LCD Mode Viewing Angle

Outline Dimensions

(W x H x D)

Active Area Weight Diagonal Size

Touch Enabled Yes TSP Type Capacitive

Surface Treatment Contrast Ratio Refresh Rate Response time Pixel Per Inch (PPI) Brightness

282.7 x 179.82 x 2.3 (mm) max

276.48 x 155.52 mm 170g max

31.75 cm (12.5”) AG 600:1 (typ) 60Hz 25ms typ. 176 300nits

Format Configuration

eDP 1.3 + PSR IPS/FFS/VA UWVA 85/85/85/85

282.7 x 179.82 x 2.3 (mm) max

276.48 x 155.52 mm 170g max

31.75 cm (12.5”)

Anti-smudge/fingerprint coating 600:1 (typ) 60Hz 25ms typ. 176 300nits

1920 x 1080 (FHD) RGB

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 22

QuickSpecs

Technical Specifications



Pixel Resolution

Interface LCD Mode Viewing Angle

Format Configuration

eDP 1.3 + PSR IPS/FFS/VA UWVA 85/85/85/85

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

1920 x 1080 (FHD) RGB

35.56 cm (14”) diagonal LED backlight FHD Slim eDP SVA Anti-glare (1920 x 1080) Non-Touch Integrated Privacy Screen

Outline Dimensions

(W x H x D)

Active Area

Weight

Diagonal Size

Surface Treatment

Contrast Ratio

Refresh Rate

Response time

Pixel Per Inch (PPI)

Brightness

Pixel Resolution

Interface

LCD Mode

Viewing Angle

320.9 x 205.6 (max) x 3.6 (max) mm

309.14 x 173.89 mm

<305 g max

35.56 cm (14”)

Anti-Glare (AG)

200:1 (typ) - AG

60Hz

16ms typ.

157

Privacy 85nits typ. (system) Sharing 275nits typ. (system)

Format

Configuration

eDP 1.2 (2 lane)

TN

Sharing 45/45/15/30 (CR>10) Privacy 40/40/15/30 (CR>10)

1920 x 1080 (FHD)

RGB Stripe

35.56 cm (14”) diagonal LED backlight HD Slim eDP SVA Anti-glare nontouch (1366 x 768)



Outline Dimensions (W x H x D)

Active Area Weight Diagonal Size Surface Treatment Contrast Ratio Refresh Rate Response time Pixel Per Inch (PPI) Brightness

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016

320.9 x 205.6 (max) x 3.0mm max

309.4 x 173.95 (mm) 290 g max

35.56 cm (14”) Anti-Glare (AG) 300:1 (typ) 60Hz 16ms typ. 112 220nits

Page 23

QuickSpecs

Technical Specifications



Pixel Resolution

Interface LCD Mode Viewing Angle

Format Configuration

eDP 1.2 TN SVA 45/45/25/35

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

1366 x 768 (HD) RGB

35.56 cm (14”) diagonal LED backlight FHD Slim eDP SVA Anti-glare nontouch (1920 x 1080)

35.56 cm (14”) diagonal LED backlight QHD UltraSlim eDP UWVA Antiglare non-touch (2560 x 1440)

Outline Dimensions

(W x H x D)

Active Area Weight Diagonal Size Surface Treatment Contrast Ratio Refresh Rate Response time Pixel Per Inch (PPI) Brightness

Pixel Resolution

Interface LCD Mode Viewing Angle

Outline Dimensions

(W x H x D) Active Area Weight Diagonal Size Surface Treatment Contrast Ratio Refresh Rate Response time Pixel Per Inch (PPI) Brightness

Pixel Resolution

320.9 x 205.6 (max) x 3.0(max) mm

309.40 x 173.95 (mm) 270 g max 14” Anti-Glare (AG) 300:1 (typ) 60Hz 16ms typ. 157 300nits

Format Configuration

eDP 1.2 TN SVA 45/45/25/35

320.9 x 205.6 (mm) max x 2.6 (mm) max

309.50 x 174.10 (mm) 270g max

35.56 cm (14”) Anti-Glare (AG) 600:1 (typ.) 60Hz 30 ms typ. 210 340 nits

Format Configuration

1920 x 1080 (FHD) RGB

2560x1440 (QHD) RGB

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 24

QuickSpecs

Technical Specifications



Interface LCD Mode Viewing Angle

35.56 cm (14”) diagonal LED backlight FHD Slim eDP SVA (1920 x 1080) Touch

Outline Dimensions

(W x H x D)

Active Area Weight Diagonal Size Surface Treatment Touch Enabled TSP Type Contrast Ratio Refresh Rate Response time Pixel Per Inch (PPI) Brightness

Pixel Resolution

Interface LCD Mode Viewing Angle

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

eDP 1.3 + PSR IPS/FFS/VA UWVA 85/85/85/85

320.9 x 205.6 (mm) max x 3.0 (mm) max

309.40 x 173.95 (mm) 270 g max 14” Anti-smudge/fingerprint coating Yes Capacitive 300:1 (typ) 60 Hz 16ms typ. 157 300nits

Format Configuration

eDP 1.2  TN SVA 45/45/25/35

1920 x 1080 (FHD) RGB

39.6 cm (15.6”) diagonal LED backlight HD Slim eDP SVA Anti-glare nontouch (1366 x 768)



Outline Dimensions

(W x H x D)

Active Area Weight Diagonal Size Surface Treatment Contrast Ratio Refresh Rate Response time Pixel Per Inch (PPI) Brightness Pixel Resolution Format

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016

360.0 x 224.3 x 3.2 (mm) max

344.2 x 193.5 (mm) 370g max

39.6 cm (15.6”) Anti-Glare (AG) 300:1 (typ) 60Hz 16ms typ. 101 220 nit typ

1366 x 768 (HD)

Page 25

QuickSpecs

Technical Specifications



Interface LCD Mode Viewing Angle

Configuration

eDP 1.2 TN SVA 45/45/25/35

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

RGB

39.6 cm (15.6”) diagonal LED backlight FHD Slim eDP SVA Anti-glare nontouch (1920 x 1080)

Outline Dimensions

(W x H x D)

Active Area Weight Diagonal Size Surface Treatment Contrast Ratio Refresh Rate Response time Pixel Per Inch (PPI) Brightness

Pixel Resolution

Interface LCD Mode Viewing Angle

360.0 x 224.3 x 3.2 (mm) max

344.2 x 193.5 (mm) 360 g max.

39.6 cm (15.6”) Anti-Glare (AG) 400:1 (typ) 60Hz 16ms typ. 142 300nits

Format Configuration

eDP 1.2 TN SVA 45/45/25/35

1920 x 1080 (FHD) RGB

39.6 cm (15.6”) diagonal LED backlight UHD Slim eDP UWVA Anti-glare non-touch (3840 x 2160)



Dimensions (W x H x D) Diagonal Size Weight Surface Treatment Contrast Ratio Refresh Rate Brightness Pixel Resolution

Backlight

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016

368.48 x 218.81 x 3.14 (mm) max

15.6 in (39.6 cm) 345 g (max) Anti-glare (AG) 1000:1 (typ) 60 Hz 340 nit

Format Configuration

LED

3840x2160 (UHD) RGB

Page 26

QuickSpecs

Technical Specifications



PPI Viewing Angle

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

282 80° Horizontal, ±80° Vertical (minimum)

80/80/80/80 (Left/Right/Down/Up) (min) UWVA 85/85/85/85

39.6 cm (15.6”) diagonal LED backlight FHD Slim eDP SVA (1920 x 1080) Touch

Outline Dimensions

(W x H x D)

Active Area Weight Diagonal Size Surface Treatment Contrast Ratio

Touch Enabled Yes TSP Type Capacitive

Refresh Rate Response time Pixel Per Inch (PPI) Brightness

Pixel Resolution

Interface LCD Mode Viewing Angle

360.0 x 224.3 x 3.2 (mm) max

344.2 x 193.5 (mm) 360 g max.

39.6 cm (15.6”) Anti-smudge/fingerprint coating 400:1 (typical)

60Hz 16ms typ. 142 300nits

Format Configuration

eDP 1.2  TN SVA 45/45/25/35

1920 x 1080 (FHD) RGB

NETWORKING

Technology/Operating bands



HP lt4120 Qualcomm® Snapdragon™ X5 LTE Mobile Broadband Module

LTE: 2100 (Band 1), 1900 (Band 2), 1800 (Band 3), 1700/2100 (Band 4), 850 (Band 5), 2600 (Band 7), 900 (Band 8), 700 (Band 12 lower), 700 (Band 13 upper), 700 (Band 17 lower), 800 (Band 20), 700 (Band 28). HSPA+: 2100 (Band 1), 1900 (Band 2), 1700/2100 (Band 4), 850 (Band 5), 900 (Band 8) MHz EV-DO: 850 (BC0), 1900 (BC1) MHz (Only work with Verizon network) E-GPRS: 1900 (Band 2), 1800 (Band 3), 850 (Band 5), 900 (Band 8) MHz

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016

Page 27

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC

QuickSpecs

HP EliteBook 850 G4 Notebook PC

Technical Specifications



Wireless protocol standards

GPS GPS bands Maximum data rates

Maximum output power

Maximum power consumption

Form Factor Weight Dimensions

(Length x Width x Thickness)

* Mobile Broadband is an optional feature. Connection requires wireless data service contract, network support, and is not available in all areas. Contact service provider to determine the coverage area and availability. Connection speeds will vary due to location, environment, network conditions, and other factors. 4G LTE not available on all products or in all countries.

Technology/Operating bands

Wireless protocol standards

3GPP Release 10 LTE Specification CAT.4, 20MHz BW WCDMA R99, 3GPP Release 5, 6, 7 and 8 UMTS Specification 1xEVDO Release 0, A and B. E-GPRS: Class B, Multi-slot class 12, coding schemes CS1 - CS4 and MSC1 - MSC9

Standalone, A-GPS (MS-A, MS-B and XTRA)

1575.42 MHz ± 1.023 MHz, GLONASS 1596-1607MHz LTE: 150 Mbps (Download), 50 Mbps (Upload)

DC-HSPA+: 42 Mbps (Download), 5.76 Mbps (Upload) HSPA+: 21Mbps (Download), 5.76 Mbps (Upload) CDMA 1xRTT: 153.6 kbps (Download), 153.6 kbps (Upload) EVDO Rel.A: 3.1 Mbps (Download), 1.8 Mbps (Upload) EVDO Rel.B: 14.7 Mbps (Download), 5.4Mbps (Upload) EDGE: 236.8 kbps (Download), 236.8 kbps (Upload)

GPRS: 85.6 kbps(Download), 85.6 kbps (Upload LTE: 23 dBm

HSPA+: 23.5 dBm 1xRTT/EVDO: 24dBm E-GPRS 1900/1800: 26 dBm E-GPRS 900/850: 27 dBm GPRS 1900/1800: 29.5 dBm GPRS 900/850: 32.5 dBm

LTE: 1,200 mA (peak); 900 mA (average) HSPA+: 1,100 mA (peak); 800 mA (average) 1xRTT/EVDO: 1,000 mA (peak); 700 mA (average) E-GPRS: 2,800 mA (peak); 500 mA (average)

M.2, 3042-S3 Key B

6.2 g 42 x 30 x 2.3 mm

HP lt4132 LTE/HSPA+ 4G Mobile Broadband Module

LTE: 2100 (Band 1), 1900 (Band 2), 1800 (Band 3) MHz, 850 (Band 5), 2600 (Band 7), 900 (Band 8) MHz, 800 (Band 20), 700 (Band 28) MHz. HSPA+: 2100 (Band 1), 1900 (Band 2), 850 (Band 5), 900 (Band 8) MHz E-GPRS: 1900 (Band 2), 1800 (Band 3), 850 (Band 5), 900 (Band 8) MHz

3GPP Release 10 LTE Specification CAT.4, 20MHz BW WCDMA R99, 3GPP Release 5, 6, 7 and 8 UMTS Specification E-GPRS: Class B, Multi-slot class 12, coding schemes CS1 - CS4 and MSC1 - MSC9

)

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 28

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC

QuickSpecs

HP EliteBook 850 G4 Notebook PC

Technical Specifications



GPS GPS bands Maximum data rates

Maximum output power

Maximum power consumption

Form Factor Weight Dimensions

(Length x Width x Thickness)

* Mobile Broadband is an optional feature. Connection requires wireless data service contract, network support, and is not available in all areas. Contact service provider to determine the coverage area and availability. Connection speeds will vary due to location, environment, network conditions, and other factors. 4G LTE not available on all products or in all countries.

HP hs3210 WW HSP with GPS Mobile Broadband

Technology/Operating bands

Wireless protocol standards

Maximum data rates

Maximum output power

Maximum power consumption

Form Factor

Standalone, A-GPS (MS-B and LTO)

1575.42 MHz ± 1.023 MHz, GLONASS 1596-1607MHz LTE: 150 Mbps (Download), 50 Mbps (Upload)

DC-HSPA+: 42 Mbps (Download), 5.76 Mbps (Upload) HSPA+: 21Mbps (Download), 5.76 Mbps (Upload) EDGE: 236.8 kbps (Download), 236.8 kbps (Upload)

GPRS: 85.6 kbps(Download), 85.6 kbps (Upload LTE: 23 dBm

HSPA+: 23.5 dBm E-GPRS 1900/1800: 26 dBm E-GPRS 900/850: 27 dBm GPRS 1900/1800: 29.5 dBm GPRS 900/850: 32.5 dBm

LTE: 1,200 mA (peak); 900 mA (average) HSPA+: 1,100 mA (peak); 800 mA (average) E-GPRS: 2,600 mA (peak); 500 mA (average)

M.2, 3042-S3 Key B 6 g 42 x 30 x 2.3 mm

HP hs3210 HSPA+ Mobile Broadband Module*

HSPA+: 2100 (Band1), 1900 (Band 2), 850 (Band 5), 900 (Band 8) MHz E-GPRS: 1900 (Band 2), 1800 (Band 3), 850 MHz (Band 5), 900 (Band 8) MHz

WCDMA R99, 3GPP Release 5, 6 and 7 UMTS Specification E-GPRS: Class B, Multi-slot class 33, coding schemes CS1 - CS4 and MSC1 - MSC9

HSPA+: 21.6 Mbps (Download), 5.76 Mbps (Upload)

E-GPRS: 296 kbps (Download), 236.8 kbps (Upload) GPRS: 107 kbps (Download), 85.6 kbps (Upload)

HSPA+: 24 dBm E-GPRS 1800/1900: 26 dBm

E-GPRS 850/900: 27 dBm GPRS 1800/1900: 30 dBm GPRS 850/900: 33 dBm

HSPA+: 1,100 mA (peak); 800 mA (average) E-GPRS: 2,800 mA (peak); 700 mA (average)

M.2, 2242-S3 Key B

)

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 29

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC

QuickSpecs

HP EliteBook 850 G4 Notebook PC

Technical Specifications



Weight Dimensions

(Length x Width x Thickness)

* Mobile Broadband is an optional feature. Connection requires wireless data service contract, network support, and is not available in all areas. Contact service provider to determine the coverage area and availability. Connection speeds will vary due to location, environment, network conditions, and other factors.

Note: Wireless access point and Interet service required. Availability of public wireless access points limited. The specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ac WLAN devices."

Intel® Dual Band Wireless-AC 8265 802.11 a/b/g/n/ac (2x2) WiFi and Bluetooth® 4.2 combo

6 g

1.65 x 8.66 x 0.09 in (42 x 22 x 2.38 mm)

Wireless LAN Standards

Interoperability

Frequency Band

Data Rates

IEEE 802.11a

IEEE 802.11b IEEE 802.11g

IEEE 802.11n

IEEE 802.11ac

Wi-Fi certified

802.11b/g/n

 2.402 – 2.482 GHz

Note:

The FCC has declared as of January 1, 2015 products that utilize passive scanning on channel 12/13 and are capable of transmitting must fully comply with requirements of 15.247 or otherwise disable those channels.

802.11a/n

 4.9 – 4.95 GHz (Japan)  5.15 – 5.25 GHz  5.25 – 5.35 GHz  5.47 – 5.725 GHz  5.825 – 5.850 GHz

Note: Indonesia no support this band)

 802.11b: 1, 2, 5.5, 11 Mbps  802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 30

QuickSpecs

Technical Specifications



HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps  802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)  802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz,

and 80MHz)

Modulation

1

Security

Network Architecture

Models

Roaming

Output Power

2

Direct Sequence Spread Spectrum BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM

 IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g

mode only

 AES-CCMP: 128 bit in hardware  802.1x authentication  WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.  WPA2 certification  IEEE 802.11i  Cisco Certified Extensions, all versions through CCX4 and CCX

Lite

 WAPI Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)

IEEE 802.11 compliant roaming between access points

 802.11b : +16dBm minimum

 802.11g : +14dBm minimum

 802.11a : +14dBm minimum

 802.11n HT20(2.4GHz) : +14dBm minimum

 802.11n HT40(2.4GHz) : +12dBm minimum

 802.11n HT20(5GHz) : +14dBm minimum

 802.11n HT40(5GHz) : +12dBm minimum

Power Consumption

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Transmit: 2.0 W (max)

Receive: 1.6 W (max)

Idle mode (PSP): 180 mW (WLAN Associated)

Idle mode: 50 mW (WLAN unassociated)

Page 31

QuickSpecs

Technical Specifications



HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

Connect Standby: 10 mW (WLAN+BT)

Radio disabled: 5 mW

Power Management

Receiver Sensitivity

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

3

802.11b, 1Mbps : -94dBm maximum

802.11b, 11Mbps : -86dBm maximum

802.11g, 6Mbps : -88dBm maximum

802.11g, 54Mbps : -74dBm maximum

802.11a, 6Mbps : -88dBm maximum

802.11a, 54Mbps : -74dBm maximum

802.11n, MCS07 : -69dBm maximum

802.11n, MCS15 : -66dBm maximum

802.11ac, 1SS, MCS-0 : -86dBm maximum

802.11ac, 1SS, MCS-9 : -61dBm maximum

802.11ac, 2SS, MCS-0 : -83dBm maximum

802.11ac, 2SS, MCS-9 : -58dBm maximum

Antenna type

Form Factor

Dimensions

Weight

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



High efficiency antenna with spatial diversity, mounted in the display enclosure

Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN MIMO communications and Bluetooth communications

PCI-Express M.2 MiniCard

Type 2230 : 2.3 x 22.0 x 30.0 mm

Or Type 1630 : 2.3 x 16.0 x 30.0 mm

Type 2230 : 2.8g

Or

Page 32

QuickSpecs

Technical Specifications



Type 1630 : 2g

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

Operating Voltage

Temperature

Humidity

Altitude

LED Activity

HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology

Bluetooth Specification

Frequency Band

1. Check latest software/driver release for updates on supported security features.

2. Maximum output power may vary by country according to local regulations.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation).

3.3v +/- 9%

Operating Non-operating

LED Amber – Radio OFF; LED White – Radio ON

4.0/4.1/4.2 Compliant

2402 to 2480 MHz

14° to 158° F (–10° to 70° C) –40° to 176° F (–40° to 80° C)

10% to 90% (non-condensing) 5% to 95% (non-condensing)

0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)

Number of Available Channels

Data Rates and Throughput

Transmit Power



Receiver Sensitivity

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016

Legacy : 0~79 (1 MHz/CH)

BLE : 0~39 (2 MHz/CH)

Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps

BLE : 1 Mbps data rate; throughput up to 0.2 Mbps

Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels

Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)

The Bluetooth component shall operate as a Class II Bluetooth device with a maximum transmit power of + 4 dBm for BR and EDR.

Modulation 0.01% BER 0.001% BER

Page 33

QuickSpecs

Technical Specifications



Legacy

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

GFSK -80 dBm -70 dBm

π/4-DQPSK -80 dBm -70 dBm

8DPSK -80 dBm -70 dBm

Power Consumption

Range

Electrical Interface

Bluetooth Software Supported

Link Topology

Electrical Interface

Bluetooth Software Supported

Security

Power Management

Certifications

Peak (Tx) 330 mW Peak (Rx) 230 mW Selective Suspend 17 mW

Legacy Up to 33 ft (10 m)

BLE Up to 99 ft (30 m)

USB 2.0 compliant

Microsoft Windows Bluetooth Software

Point to Point, Multipoint Pico Nets up to 7 slaves

Full support of Bluetooth Security Provisions

Microsoft Windows ACPI, and USB Bus Support

Self-configurable to optimize power conservation in all operating modes, including Standby, Hold, Park, and Sniff

Security

Certifications

Bluetooth Profiles Supported

Power Management

Certifications

Bluetooth Profiles Supported

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



All necessary regulatory approvals for supported countries, including:

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

ETS 300 328, ETS 300 826

Low Voltage Directive IEC950

UL, CSA, and CE Mark

1

Serial Port Profile (SPP) Service Discovery Application Profile (SDAP) Dial-Up Networking (DUN) Generic Object Exchange Profile (GOEP)

1,2

Page 34

QuickSpecs

Technical Specifications



HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

Object Push Profile (OPP) Hard Copy Cable Replacement (HCRP) Personal Area Networking Profile (PAN) Human Interface Device Profile (HID) Hands Free Profile (HFP) Advanced Audio Distribution Profile (A2DP)

Audio Video Remote Control Profile (AVRCP)

1,2

Bluetooth V4.1/V4.2 support feature

Intel® Dual Band Wireless-AC 3168 802.11 a/b/g/n/ac (1x1) WiFi and Bluetooth® 4.2 combo

Wireless LAN Standards

Interoperability

V4.1: ESR5/6/7 compliant

V4.2: ESR8 compliant, LE Secure Connection – Basic.

IEEE 802.11a

IEEE 802.11b IEEE 802.11g

IEEE 802.11n

IEEE 802.11ac

Wi-Fi certified

Frequency Band

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



802.11b/g/n

 2.402 – 2.482 GHz

Note:

The FCC has declared as of January 1, 2015 products that utilize passive scanning on channel 12/13 and are capable of transmitting must fully comply with requirements of 15.247 or

Page 35

QuickSpecs

Technical Specifications



Data Rates

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

otherwise disable those channels.

802.11a/n

 4.9 – 4.95 GHz (Japan)  5.15 – 5.25 GHz  5.25 – 5.35 GHz  5.47 – 5.725 GHz  5.825 – 5.850 GHz

Note: Indonesia only supports 5.725 - 5.825 GHz (CH149 - CH161)

 802.11b: 1, 2, 5.5, 11 Mbps  802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps  802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps  802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)  802.11ac : MCS0 ~ MCS7, (1SS) (20MHz, 40MHz, and

80MHz)

Modulation

Security

Network Architecture Models

Roaming

Output Power

1

2

Direct Sequence Spread Spectrum BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM

 IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g

mode only

 AES-CCMP: 128 bit in hardware  802.1x authentication  WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.  WPA2 certification  IEEE 802.11i  Cisco Certified Extensions, all versions through CCX4 and CCX

Lite

 WAPI Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)

IEEE 802.11 compliant roaming between access points

 802.11b : +16dBm minimum

 802.11g : +14dBm minimum

 802.11a : +14dBm minimum

 802.11n HT20(2.4GHz) : +14dBm minimum

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 36

QuickSpecs

Technical Specifications



Power Consumption

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

 802.11n HT40(2.4GHz) : +12dBm minimum

 802.11n HT20(5GHz) : +14dBm minimum

 802.11n HT40(5GHz) : +12dBm minimum

 802.11ac 80MHz(5GHz) : +11dBm minimum

Transmit: 2.0 W (max)

Receive: 1.6 W (max)

Idle mode (PSP): 180 mW (WLAN Associated)

Idle mode: 50 mW (WLAN unassociated)

Connect Standby: 10 mW (WLAN+BT)

Power Management

Receiver Sensitivity

Radio disabled: 5 mW

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

3

802.11b, 1Mbps : -94dBm maximum

802.11b, 11Mbps : -86dBm maximum

802.11g, 6Mbps : -88dBm maximum

802.11g, 54Mbps : -74dBm maximum

802.11a, 6Mbps : -88dBm maximum

802.11a, 54Mbps : -74dBm maximum

802.11n, MCS07 : -69dBm maximum

802.11n, MCS15 : -66dBm maximum

802.11ac, 1SS, MCS-0 : -86dBm maximum

802.11ac, 1SS, MCS-9 : -61dBm maximum

802.11ac, 2SS, MCS-0 : -83dBm maximum

802.11ac, 2SS, MCS-9 : -58dBm maximum

Antenna type

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



High efficiency antenna with spatial diversity, mounted in the display enclosure

Page 37

QuickSpecs

Technical Specifications



HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN MIMO communications and Bluetooth communications

Form Factor

Dimensions

Weight

Operating Voltage

Temperature

Humidity

Altitude

LED Activity

PCI-Express M.2 MiniCard

Type 2230 : 2.3 x 22.0 x 30.0 mm

Or Type 1630 : 2.3 x 16.0 x 30.0 mm

Type 2230 : 2.8g

Or

Type 1630 : 2g

3.3v +/- 9%

Operating Non-operating

LED Amber – Radio OFF; LED White – Radio ON

14° to 158° F (–10° to 70° C) –40° to 176° F (–40° to 80° C)

10% to 90% (non-condensing) 5% to 95% (non-condensing)

0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)

HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology

Bluetooth Specification

Frequency Band

Number of Available Channels

Data Rates and Throughput



1.Check latest software/driver release for updates on supported security features.

2. Maximum output power may vary by country according to local regulations.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation).

4.0/4.1/4.2 Compliant

2402 to 2480 MHz

Legacy : 0~79 (1 MHz/CH)

BLE : 0~39 (2 MHz/CH)

Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016

Page 38

QuickSpecs

Technical Specifications



HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

BLE : 1 Mbps data rate; throughput up to 0.2 Mbps

Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels

Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)

Transmit Power

Receiver Sensitivity

Legacy

Power Consumption

Range

Electrical Interface

Bluetooth Software Supported

The Bluetooth component shall operate as a Class II Bluetooth device with a maximum transmit power of + 4 dBm for BR and EDR.

Modulation 0.01% BER 0.001% BER

GFSK -80 dBm -70 dBm

π/4-DQPSK -80 dBm -70 dBm

8DPSK -80 dBm -70 dBm

Peak (Tx) 330 mW Peak (Rx) 230 mW Selective Suspend 17 mW

Legacy Up to 33 ft (10 m)

BLE Up to 99 ft (30 m)

USB 2.0 compliant

Microsoft Windows Bluetooth Software

Link Topology

Electrical Interface

Bluetooth Software Supported

Security

Power Management

Certifications

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Point to Point, Multipoint Pico Nets up to 7 slaves

Full support of Bluetooth Security Provisions

Microsoft Windows ACPI, and USB Bus Support

Self-configurable to optimize power conservation in all operating modes, including Standby, Hold, Park, and Sniff

Page 39

QuickSpecs

Technical Specifications



Security

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

All necessary regulatory approvals for supported countries, including:

Certifications

Bluetooth Profiles Supported

Power Management

Certifications

Bluetooth Profiles Supported

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

ETS 300 328, ETS 300 826

Low Voltage Directive IEC950

UL, CSA, and CE Mark

1

Serial Port Profile (SPP) Service Discovery Application Profile (SDAP) Dial-Up Networking (DUN) Generic Object Exchange Profile (GOEP) Object Push Profile (OPP) Hard Copy Cable Replacement (HCRP) Personal Area Networking Profile (PAN) Human Interface Device Profile (HID) Hands Free Profile (HFP) Advanced Audio Distribution Profile (A2DP)

Audio Video Remote Control Profile (AVRCP)

1,2

Bluetooth V4.1/V4.2 support feature



Intel® I219-V Gigabit Network Connection

Ethernet Features

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



V4.1: ESR5/6/7 compliant

V4.2: ESR8 compliant, LE Secure Connection – Basic.

10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14) 100 10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE

802.3 clauses 13-14)

Page 40

QuickSpecs

Technical Specifications



HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE

802.3 clauses 21-30) 1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE

8023. Clauses 40) Auto-Negotiation (Automatic Speed Selection) Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s IEEE 802.1p QoS (Quality of Service) Support IEEE 802.1q VLAN support IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable) IEEE 802.3az EEE(Energy Efficient Ethernet) Jumbo Frame 9K Auto MDI/MDIX Crossover cable detection

Power Management

Performance Features

Manageability

Interface

ACPI compliant - multiple power modes

Energy Detect Low Power Mode(Green Ethernet)

TCP/IP/UDP Checksum Offload (configurable) Protocol Offload( ARP & NS) Large send offload and Giant send offload Receiving Side Scaling MACSec Offload (802.3ae) Intel Non-vPro iSCSI Boot

Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft Wake-Up Frame); Wake-on-LAN from off (Magic Packet only) PXE 2.1 Remote Boot Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30)) Comprehensive diagnostic and configuration software suite Virtual Cable Doctor for Ethernet cable status

PCI Express 1.1 x1 to fully support ASPM L0s/L1 and CLKREQ.

NOTE: Intel 82579 PCIe interface is not PCIe compliant. It operates at half of PCIe specification V1.1 (2.5GT/S) speed.

NIC Device Driver Name

Intel® I219-LM Gigabit Network Connection

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Intel 82579LM/82579V Ethernet Network Connection

Page 41

QuickSpecs

Technical Specifications



Ethernet Features

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14) 100 10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14) 100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30) 1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023. Clauses 40) Auto-Negotiation (Automatic Speed Selection) Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s IEEE 802.1p QoS (Quality of Service) Support IEEE 802.1q VLAN support IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable) IEEE 802.3az EEE(Energy Efficient Ethernet) Jumbo Frame 9K Auto MDI/MDIX Crossover cable detection

Power Management

Performance Features

Manageability

Interface

ACPI compliant - multiple power modes Energy Detect Low Power Mode(Green Ethernet)

TCP/IP/UDP Checksum Offload (configurable) Protocol Offload( ARP & NS) Large send offload and Giant send offload Receiving Side Scaling MACSec Offload (802.3ae) Intel vPro iSCSI Boot

Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft Wake-Up Frame); Wake-on-LAN from off (Magic Packet only) PXE 2.1 Remote Boot Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30)) Comprehensive diagnostic and configuration software suite Virtual Cable Doctor for Ethernet cable status

PCI Express 1.1 x1 to fully support ASPM L0s/L1 and CLKREQ.

NOTE: Intel 82579 PCIe interface is not PCIe compliant. It operates at half of PCIe specification V1.1 (2.5GT/S) speed.

NIC Device Driver Name



Near Field Communications Controller (optional)

Dimensions (L x W x H)

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Intel 82579LM/82579V Ethernet Network Connection

Module 25 mm by 10 mm by 2.0 mm

Page 42

QuickSpecs

Technical Specifications



HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

Chipset

System interface

NFC RF standards

NFC Forum Support

Reader (PCD-VCD) Mode(1)

NPC100

2

C

I

ISO/IEC 14443 A

ISO/IEC 14443 B

ISO/IEC 15693

ISO/IEC 18092

ECMA-340 NFCIP-1 Target and Initiator

ECMA-320 NFCIP-2

Tag Type 1, Type 2, Type3 and Type 4, NFCIP-1 and NFCIP-2

ISO/IEC 14443 A

ISO/IEC 14443 B

ISO/IEC 15693

MIFARE 1K

MIFARE 4K

Card Emulation (PICC-VICC) Mode(1)

Frequency

NFC Modes Supported

Raw RF Data Rates

Operating temperature

Storage temperature

MIFARE DESFire

FeliCa

Jewel and Topaz cards

ISO/IEC 14443 A

ISO/IEC 14443 B and B’

MIFARE

FeliCa

13.56 MHz

Reader/Writer, Peer-to-Peer

106, 212, 424, 848 kbps

0°C to 70°C

-20°C to 125°C

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 43

QuickSpecs

Technical Specifications



HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

Humidity

Supply Operating voltage

I/O Voltage

Power Consumption

(Booster enable, VBAT= 3.3V, VCC_BOOST = 5V)

10-90% operating 5-95% non-operating

2.97 to 5.5 Volts

1.8V or 3.3V

Mode Power Consumption,

Typical

Polling 7.3 mA

Detected Test Tag Type 1 Total 283.8 mA

Net Module 236.8 mA

Detected Test Tag Type 2 Total 288.8 mA

Net Module 241.8 mA

Detected Test Tag Type 3 Total 287.7 mA

Net Module 240.7 mA

Detected Test Tag Type 4 Total 282.3 mA

Net Module 235.3 mA

(2)

Antenna



S

TORAGE AND DRIVES

500 GB 7200rpm Self Encrypting Drive (FIPS140-2) (Opal 2)



Antenna connector, 0.5mm pitch, 7 connector FPC. Antenna matching is external to module.

Drive Weight Capacity Height Width Interface Transfer Rate Synchronous (maximum)

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016

0.21 lbs (95 g) 500 GB

0.28 in (7 mm)

2.75 in (69.85 mm) ATA-8, SATA 3.0

600 MB/s

Page 44

QuickSpecs

Technical Specifications



Seek Time (typical reads, including settling)

Cache Rotational Speed Logical Blocks Operating Temperature Features



HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

Single Track Average Maximum

32 MB 7200 rpm 976,773,168 32° to 140° F (0° to 60° C) [top cover temp] ATA Security; TCG Opal 2.x, FIPS, S.M.A.R.T., NCQ, Ultra DMA ,

1.5 ms 12 ms 21 ms

500 GB 7200rpm Hard Drive



500 GB 7200rpm SelfEncrypting Drive (Opal 2)

Drive Weight Capacity Height Width Interface Transfer Rate Synchronous (maximum) Seek Time

(typical reads, including settling)

Cache Rotational Speed Logical Blocks Operating Temperature Features

Drive Weight Capacity Height Width Interface Transfer Rate Synchronous (maximum) Seek Time

(typical reads, including settling)

Cache Rotational Speed Logical Blocks Operating Temperature

0.20 lbs (92 g) ~ 0.21 lbs (95 g) 500 GB

0.28 in (7 mm)

2.75 in (69.85 mm) ATA-8, SATA 3.0

Single Track Average Maximum

32 MB 7200 rpm 976,773,168 32° to 140° F (0° to 60° C) [case temp] ATA Security, S.M.A.R.T., NCQ, Ultra DMA

0.21 lbs (95 g) 500 GB

0.28 in (7 mm)

2.75 in (69.85 mm) ATA-8, SATA 3.0

Single Track Average Maximum

32 MB 7200rpm 976,773,168 32° to 140° F (0° to 60° C) [top cover temp]

600 MB/s

1.5 ms ~ 2 ms 11 ms ~ 13 ms 18 ms ~ 22 ms

600 MB/s

1.5ms 12ms 21 ms

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 45

QuickSpecs

Technical Specifications



Features



HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

ATA Security; TCG Opal 2.x,S.M.A.R.T., NCQ, Ultra DMA

1 TB 5400rpm Hard Drive



500 GB Hybrid, 8 GB cache



Drive Weight Capacity Height Width Interface Transfer Rate Synchronous (maximum) Seek Time

(typical reads, including settling)

Cache Rotational Speed Logical Blocks Operating Temperature Features

Drive Weight Capacity Height Width Interface Transfer Rate Synchronous (maximum) Seek Time

(typical reads, including settling)

Cache Rotational Speed Logical Blocks Operating Temperature Features

0.21 lbs (94 g)- 0.21 lbs ( 95 g) 1TB

0.28 in (7 mm)

2.75 in (69.85 mm) ATA-8, SATA 3.0

Single Track Average Maximum

Up to 32 MB 5400rpm 1,953,525,168 32° to 140° F (0° to 60° C) [case temp] ATA Security, S.M.A.R.T., NCQ, Ultra DMA

0.20 lbs (92 g) ~ 0.21 lbs (95 g) 500 GB

0.28 in (7 mm)

2.75 in (69.85 mm) ATA-8, SATA 3.0

Single Track Average Maximum

64 MB 5400 rpm 976,773,168 32° to 140° F (0° to 60° C) [case temp] ATA Security, S.M.A.R.T., NCQ, Ultra DMA

600 MB/s 2ms 12ms-13ms 18ms- 22ms

600 MB/s 2 ms 12 ms 22 ms

128 GB SATA-3 Value Solid State Drive



Drive Weight Capacity Height Width Interface

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016

0.01 lb (6 g) ~ 0.02 lb (10 g) 128 GB

0.09 in (2.3 mm)

0.87 in (22 mm) ATA-8, SATA 3.0

Page 46

QuickSpecs

Technical Specifications



Performance Maximum Sequential Read Maximum Sequential Write

Logical Blocks Operating Temperature Features



HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

Up To 535 MB/s Up To 515 MB/s 250,069,680 32° to 158°F (0° to 70°C) [ambient temp] DIPM; TRIM; DEVSLP

256 GB PCIe Gen3x4 NVMe TLC Solid State Drive



512 GB PCIe Gen3x4 NVMe TLC Solid State Drive



Drive Weight Capacity Height Width Interface Performance Maximum Sequential Read Maximum Sequential Write

Logical Blocks Operating Temperature Features

Drive Weight Capacity Height Width Interface Performance Maximum Sequential Read Maximum Sequential Write

Logical Blocks Operating Temperature Features

M.2 2280 256 GB

0.09 in (2.3 mm)

0.87 in (22 mm) PCIe NVMe Gen3X4

Up to 2600 MB/s Up to 900 MB/s 500,118,192 32° to 158°F (0° to 70°C) [ambient temp] ATA Security (Option); TRIM; L1.2

M.2 2280 512 GB

0.09 in (2.3 mm)

0.87 in (22 mm) PCIe NVMe Gen3X4

Up to 2600 MB/s Up to 1400 MB/s 1,000,215,216 32° to 158°F (0° to 70°C) [ambient temp] ATA Security (Option); TRIM; L1.2



512 GB PCIe Gen3x4 NVMe MLC Solid State Drive



Drive Weight Capacity Height Width Interface Performance Maximum Sequential Read Maximum Sequential Write

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016

M.2 2280 512 GB

0.09 in (2.3 mm)

0.87 in (22 mm) PCIe NVMe Gen3X4

Up to 2288 MB/s Up to1600 MB/s

Page 47

QuickSpecs

Technical Specifications



Logical Blocks Operating Temperature Features

‐



HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

1,000,215,216 32° to 158°F (0° to 70°C) [ambient temp] ATA Security (Option); TRIM; L1.2

256 GB SATA-3 TLC SelfEncrypting Solid State Drive (Opal 2)



512 GB PCIe Gen3x4 NVMe TLC SelfEncrypting Solid State Drive (Opal 2)



Drive Weight Capacity Height Width Interface Performance Maximum Sequential Read Maximum Sequential Write

Logical Blocks Operating Temperature Features

Drive Weight Capacity Height Width Interface Performance Maximum Sequential Read Maximum Sequential Write

Logical Blocks Operating Temperature Features

M.2 2280 256 GB

0.09 in (2.3 mm)

0.87 in (22 mm) ATA-8, SATA 3.0

Up to 530 MB/s Up to 515 MB/s 500,118,192 32° to 158°F (0° to 70°C) [ambient temp] ATA Security; TCG Opal 2.0; DIPM; TRIM; DEVSLP

M.2 2280 512 GB

0.09 in (2.3 mm)

0.87 in (22 mm) PCIe NVMe Gen3X4

Up to 2600 MB/s Up to 1400 MB/s 1,000,215,216 32° to 158°F (0° to 70°C) [ambient temp] ATA Security (Option) ; TCG Opal 2.0; TRIM; L1.2



Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 48

QuickSpecs

Technical Specifications



POWER

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

HP 45W Smart AC Adapter



Dimensions (H x W x D) Weight

Input

Output Output power

AC Connector (Ac Inlet) Environmental Design Operating

EMI and Safety Certifications

9.5 x 4.0 x 2.65 cm) unit: 200g +/- 10g 90 to 265 VAC

Input Efficiency Input frequency range Input AC current

DC output Hold-up time Output current limit

C6 (3pin/with grounded, with Smart ID DC connector)

temperature Non-operating (storage)

temperature Altitude Humidity Storage Humidity

*CE Mark - full compliance with LVD and EMC directives * Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. * MTBF - over 200,000 hours at 25°C ambient condition.

87.74% at 115Vac and 88.4% at 230Vac 47 to 63 Hz Max. 1.4 A at 90 Vac 45W

19.5V 5 ms at 115 Vac input <8.0A

32° to 95° F (0° to 35° C)

-4° to 185° F (-20° to 85° C)

0 to 16,400 ft (0 to 5,000 m) 20% to 95% 10% to 95%



HP 45W Smart AC Adapter (2 Prong)



Dimensions (H x W x D) Weight

Input

Output Output power

AC Connector (Ac Inlet) Environmental Design Operating

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016

95.0x40.0x26.5mm unit: 200g +/- 10g 90 to 265 VAC

Input Efficiency Input frequency range Input AC current

DC output Hold-up time Output current limit

C8 (2 pin/non-grounded, with Smart ID DC connector)

87.74% at 115Vac and 88.4% at 230Vac 47 to 63 Hz Max. 1.4 A at 90 Vac 45W

19.5V 5 ms at 115Vac input <8.0A

32° to 95° F (0° to 35° C)

Page 49

QuickSpecs

Technical Specifications



EMI and Safety Certifications



HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

temperature Non-operating (storage)

temperature Altitude Humidity Storage Humidity

*CE Mark - full compliance with LVD and EMC directives * Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. * MTBF - over 200,000 hours at 25°C ambient condition.

-4° to 185° F (-20° to 85° C)

0 to 16,400 ft (0 to 5,000 m) 20% to 95% 10% to 95%

HP 65W Smart AC Adapter



Dimensions Weight Input

Output Output power

AC Connector (Ac Inlet) Environmental Design Operating

EMI and Safety Certifications

107.0x47.0x30.0mm unit: 250g +/- 10g 90 to 265 VAC

Input Efficiency Input frequency range Input AC current

DC output Hold-up time Output current limit

C6 (3pin/with grounded, with Smart ID DC connector)

temperature Non-operating (storage)

temperature Altitude Humidity Storage Humidity

Eg: *CE Mark - full compliance with LVD and EMC directives * Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. * MTBF - over 200,000 hours at 25°C ambient condition.

88.0 % at 115 Vac and 89.0 % at 230 Vac 47 to 63 Hz

1.7 A at 90 Vac 65W

19.5V 5 ms at 115 Vac input <11.0A

32° to 95° F (0° to 35° C)

-4° to 185° F (-20° to 85° C)

0 to 16,400 ft (0 to 5,000 m) 20% to 95% 10% to 95%



Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 50

QuickSpecs

Technical Specifications



HP 65W Smart AC Adapter EM

HP 3-cell Long Life Li-Ion (49 WHr) – HP EliteBook 820 G4

HP 3-cell Long Life Li-Ion (51 WHr) – HP

Dimensions Weight Input

Output Output power

AC Connector (Ac Inlet) Environmental Design Operating

EMI and Safety Certifications

Dimensions (H x W x L) Weight Cells/Type Energy Voltage

Temperature Operating (Charging)

Fuel Gauge LED Warranty Optional Travel Battery

Available

Dimensions (H x W x L) Weight

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

102.0x55.0x30.0mm unit: 350g +/- 10g 90 to 265 VAC

Input Efficiency Input frequency range Input AC current

DC output Hold-up time Output current limit

C6 (3pin/with grounded, with Smart ID DC connector)

temperature Non-operating (storage)

temperature Altitude Humidity Storage Humidity

*CE Mark - full compliance with LVD and EMC directives * Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. * MTBF - over 200,000 hours at 25°C ambient condition.

8.30 mm x127.5 mm x 160.25 mm 225g 3 cell Lithium-Ion Polymer cell / 505295

Amp-hour capacity Watt-hour capacity

Operating (Discharging)

NA 1000 cycles > 65% (at 23˚C) No

6.8mm x 102.8mm x 198mm 235g

87.0% min at 115 VAC and 230Vac 47 to 63 Hz

1.7 A at 90 VAC 65W

19.5V 5 ms at 115 Vac input <11.0A

32° to 95° F (0° to 35° C)

-4° to 185° F (-20° to 85° C)

0 to 16,400 ft (0 to 5,000 m) 20% to 95% 10% to 95%

11.55V 4250mAh 49Wh 0~45 C

-10~60 C

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 51

QuickSpecs

Technical Specifications



EliteBook 840 & 850 G4 Cells/Type

Energy Voltage

Temperature Operating (Charging)

Fuel Gauge LED Warranty Optional Travel Battery

Available

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

3cell Lithium-Ion Polymer cell / 506480

11.55V

Amp-hour capacity Watt-hour capacity

Operating (Discharging)

NA 1000 cycles > 65% (at 23˚C) No

4420mAh 51wh 0~45 C

-10~60 C

ENVIRONMENTAL

HP EliteBook 820 G4 Notebook PC

Eco-Label Certifications & declarations

System Configuration

Energy Consumption (in accordance with US ENERGY STAR® test method) 115VAC, 60Hz 230VAC, 50Hz 100VAC, 50Hz

Normal Operation (Short idle)

This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks:

 IT ECO declaration  US ENERGY STAR®  EPEAT

The configuration used for the Energy Consumption and Declared Noise Emissions data for the Notebook model is based on a “Typically Configured Notebook”.



Gold registered in the United States. See http://www.epeat.net for registration status in

your country.

5.15 W 5.15 W 4.66 W

Normal Operation (Long idle)

Sleep 0.74 W 0.83 W 0.77 W



2.80 W 3.23 W 2.80 W

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016

Page 52

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC

QuickSpecs

HP EliteBook 850 G4 Notebook PC

Technical Specifications



Off 0.40 W 0.48 W 0.40 W

Heat Dissipation* 115VAC, 60Hz 230VAC, 50Hz 100VAC, 50Hz

Normal Operation (Short idle)

Normal Operation (Long idle)

Sleep 3 BTU/hr 3 BTU/hr 3 BTU/hr

Off 1 BTU/hr 2 BTU/hr 1 BTU/hr

Note:

Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the model family. HP computers marked with the ENERGY STAR® Logo are compliant with the applicable U.S. Environmental Protection Agency (EPA) ENERGY STAR® specifications for computers. If a model family does not offer ENERGY STAR® compliant configurations, then energy efficiency data listed is for a typically configured PC featuring a hard disk drive, a high efficiency power supply, and a Microsoft Windows® operating system.

18 BTU/hr 18 BTU/hr 16 BTU/hr

10 BTU/hr 11 BTU/hr 10 BTU/hr

Declared Noise Emissions (in accordance with ISO 7779 and ISO 9296)

Typically Configured – Idle

Fixed Disk – Random writes

Batteries



*NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one hour.

This battery(s) in this product comply with EU Directive 2006/66/EC

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016

SoundPower

(L

,bels)

WAd



3.2 26

3.5 27

SoundPressure

(L

,decibels)

pAm



Page 53

QuickSpecs

Technical Specifications



Batteries used in the product do not contain:

Mercury greater the1ppm by weight Cadmium greater than 20ppm by weight

Battery size: CR2320 (coin cell) Battery type: Lithium

Additional Information

Packaging Materials External:

 This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive -

 This HP product is designed to comply with the Waste Electrical and Electronic Equipment

 This product is in compliance with California Proposition 65 (State of California; Safe Drinking

 This product is in compliance with the IEEE 1680 (EPEAT) standard at the gold level, see

 Plastics parts weighing over 25 grams used in the product are marked per ISO11469 and

 This product contains 0% post-consumer recycled plastic (by wt.)  This product is 96.7% recycle-able when properly disposed of at end of life.

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

2011/65/EC.

(WEEE) Directive – 2002/96/EC.

Water and Toxic Enforcement Act of 1986).

www.epeat.net

ISO1043.

PAPER/Corrugated 328 g

Material Usage

Internal:

The plastic packaging material contains at least 50% recycled content.

The corrugated paper packaging materials contains at least 70% recycled content. This product does not contain any of the following substances in excess of regulatory limits (refer to the HP General Specification for the Environment at

http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):

 Asbestos  Certain Azo Colorants  Certain Brominated Flame Retardants – may not be used as flame retardants in plastics  Cadmium  Chlorinated Hydrocarbons  Chlorinated Paraffins  Formaldehyde  Halogenated Diphenyl Methanes  Lead carbonates and sulfates  Lead and Lead compounds  Mercuric Oxide Batteries  Nickel – finishes must not be used on the external surface designed to be frequently handled or

 Ozone Depleting Substances  Polybrominated Biphenyls (PBBs)  Polybrominated Biphenyl Ethers (PBBEs)

PLASTIC/Expanded Polyethylene - EPE 38 g PLASTIC/Polyethylene low density - LDPE 14 g

PLASTIC/Polypropylene - PP 3 g

carried by the user.

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 54

QuickSpecs

Technical Specifications



 Polybrominated Biphenyl Oxides (PBBOs)  Polychlorinated Biphenyl (PCB)  Polychlorinated Terphenyls (PCT)  Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been

 Radioactive Substances  Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)



voluntarily removed from most applications.

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

Packaging Usage

End-of-life Management and Recycling

HP Inc.

Corporate Environmental Information

HP follows these guidelines to decrease the environmental impact of product packaging:

 Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging

materials.

 Eliminate the use of ozone-depleting substances (ODS) in packaging materials.  Design packaging materials for ease of disassembly.  Maximize the use of post-consumer recycled content materials in packaging materials.  Use readily recyclable packaging materials such as paper and corrugated materials.  Reduce size and weight of packages to improve transportation fuel efficiency.  Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.

Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas. To recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers. These instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.

For more information about HP’s commitment to the environment:

Global Citizenship Report

http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html

Eco-label certifications

http://www8.hp.com/us/en/hp-information/environment/ecolabels.html

ISO 14001 certificates:

http://h20195.www2.hp.com/V2/GetDocument.aspx?docname=c04755842

and

http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 55

QuickSpecs

Technical Specifications



HP EliteBook 840 G4 Notebook PC

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

Eco-Label Certifications & declarations

System Configuration

Energy Consumption (in accordance with US ENERGY STAR® test method) 115VAC, 60Hz 230VAC, 50Hz 100VAC, 50Hz

Normal Operation (Short idle)

Normal Operation (Long idle)

Sleep 0.66 W 0.66 W 0.67 W

This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks:

 IT ECO declaration  US ENERGY STAR®  EPEAT <Gold> registered in the United States. See http://www.epeat.net for registration status

in your country.

The configuration used for the Energy Consumption and Declared Noise Emissions data for the Notebook model is based on a “Typically Configured Notebook”.

5.12 W 5.47 W 5.18 W

3.00 W 3.26 W 3.50 W

Off 0.40 W 0.40 W 0.40 W

Heat Dissipation* 115VAC, 60Hz 230VAC, 50Hz 100VAC, 50Hz



Note:

Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the model family. HP computers marked with the ENERGY STAR® Logo are compliant with the applicable U.S. Environmental Protection Agency (EPA) ENERGY STAR® specifications for computers. If a model family does not offer ENERGY STAR® compliant configurations, then energy efficiency data listed is for a typically configured PC featuring a hard disk drive, a high efficiency power supply, and a Microsoft Windows® operating system.

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016

Page 56

QuickSpecs

Technical Specifications



Normal Operation (Short idle)

18 BTU/hr 19 BTU/hr 18 BTU/hr

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

Normal Operation (Long idle)

Sleep 2 BTU/hr 2 BTU/hr 2 BTU/hr

Off 1 BTU/hr 1 BTU/hr 1 BTU/hr

Declared Noise Emissions (in accordance with ISO 7779 and ISO 9296)

Typically Configured – Idle

Fixed Disk – Random writes

*NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one hour.

10 BTU/hr 11 BTU/hr 12 BTU/hr

SoundPower

(L

,bels)

WAd



2.9 21

3.2 22

SoundPressure

(L

,decibels)

pAm



Batteries



This battery(s) in this product comply with EU Directive 2006/66/EC

Batteries used in the product do not contain:

Mercury greater the1ppm by weight Cadmium greater than 20ppm by weight

Battery size: CR2032 (coin cell) Battery type: Lithium

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 57

QuickSpecs

Technical Specifications



Additional Information

Packaging Materials External:

 This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive -

 This HP product is designed to comply with the Waste Electrical and Electronic Equipment

 This product is in compliance with California Proposition 65 (State of California; Safe Drinking

 This product is in compliance with the IEEE 1680 (EPEAT) standard at the <Gold> level, see

 Plastics parts weighing over 25 grams used in the product are marked per ISO11469 and

 This product contains 0% post-consumer recycled plastic (by wt.)  This product is 94.6% recycle-able when properly disposed of at end of life.

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

2011/65/EC.

(WEEE) Directive – 2002/96/EC.

Water and Toxic Enforcement Act of 1986).

www.epeat.net

ISO1043.

PAPER/Corrugated 323 g

Material Usage

Internal:

The plastic packaging material contains at least 50% recycled content.

The corrugated paper packaging materials contains at least 70% recycled content. This product does not contain any of the following substances in excess of regulatory limits (refer to the HP General Specification for the Environment at

http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):

 Asbestos  Certain Azo Colorants  Certain Brominated Flame Retardants – may not be used as flame retardants in plastics  Cadmium  Chlorinated Hydrocarbons  Chlorinated Paraffins  Formaldehyde  Halogenated Diphenyl Methanes  Lead carbonates and sulfates  Lead and Lead compounds  Mercuric Oxide Batteries  Nickel – finishes must not be used on the external surface designed to be frequently handled or

 Ozone Depleting Substances  Polybrominated Biphenyls (PBBs)  Polybrominated Biphenyl Ethers (PBBEs)  Polybrominated Biphenyl Oxides (PBBOs)  Polychlorinated Biphenyl (PCB)  Polychlorinated Terphenyls (PCT)  Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been

 Radioactive Substances  Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)

PLASTIC/Polyethylene Expanded - EPE 38 g PLASTIC/Polyethylene low density - LDPE 15 g

PLASTIC/Polypropylene - PP 4 g

carried by the user.

voluntarily removed from most applications.

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 58

QuickSpecs

Technical Specifications



HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

Packaging Usage

End-of-life Management and Recycling

Hewlett-Packard Corporate Environmental Information

HP follows these guidelines to decrease the environmental impact of product packaging:

 Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging

materials.

 Eliminate the use of ozone-depleting substances (ODS) in packaging materials.  Design packaging materials for ease of disassembly.  Maximize the use of post-consumer recycled content materials in packaging materials.  Use readily recyclable packaging materials such as paper and corrugated materials.  Reduce size and weight of packages to improve transportation fuel efficiency.  Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.

Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas. To recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers. These instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.

For more information about HP’s commitment to the environment:

Global Citizenship Report

http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html

Eco-label certifications

http://www8.hp.com/us/en/hp-information/environment/ecolabels.html

ISO 14001 certificates:

http://h20195.www2.hp.com/V2/GetDocument.aspx?docname=c04755842

and

http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf

HP EliteBook 850 G4 Notebook PC

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 59

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC

QuickSpecs

HP EliteBook 850 G4 Notebook PC

Technical Specifications



Eco-Label Certifications & declarations

System Configuration

Energy Consumption (in accordance with US ENERGY STAR® test method) 115VAC, 60Hz 230VAC, 50Hz 100VAC, 50Hz

This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks:

 IT ECO declaration  US ENERGY STAR®  EPEAT <Gold> registered in the United States. See http://www.epeat.net for registration status

in your country.

The configuration used for the Energy Consumption and Declared Noise Emissions data for the Notebook model is based on a “Typically Configured Notebook”.

Normal Operation (Short idle)

Normal Operation (Long idle)

Sleep 0.71 W 0.79 W 0.72 W

Off 0.40 W 0.48 W 0.40 W

Heat Dissipation* 115VAC, 60Hz 230VAC, 50Hz 100VAC, 50Hz

Note:

Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the model family. HP computers marked with the ENERGY STAR® Logo are compliant with the applicable U.S. Environmental Protection Agency (EPA) ENERGY STAR® specifications for computers. If a model family does not offer ENERGY STAR® compliant configurations, then energy efficiency data listed is for a typically configured PC featuring a hard disk drive, a high efficiency power supply, and a Microsoft Windows® operating system.

5.86 W 5.86 W 5.99 W

3.14 W 3.73 W 3.40 W

Normal Operation (Short idle)

Normal Operation (Long



20 BTU/hr 20 BTU/hr 20 BTU/hr

11 BTU/hr 13 BTU/hr 12 BTU/hr

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016

Page 60

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC

QuickSpecs

HP EliteBook 850 G4 Notebook PC

Technical Specifications



idle)

Sleep 2 BTU/hr 3 BTU/hr 2 BTU/hr

Off 1 BTU/hr 2 BTU/hr 1 BTU/hr

Declared Noise Emissions (in accordance with ISO 7779 and ISO 9296)

Typically Configured – Idle

Fixed Disk – Random writes

Batteries

Additional Information

Packaging Materials External:

*NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one hour.

This battery(s) in this product comply with EU Directive 2006/66/EC

Batteries used in the product do not contain:

Mercury greater the1ppm by weight Cadmium greater than 20ppm by weight

Battery size: CR2032 (coin cell) Battery type: Lithium

 This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive -

 This HP product is designed to comply with the Waste Electrical and Electronic Equipment

 This product is in compliance with California Proposition 65 (State of California; Safe Drinking

 This product is in compliance with the IEEE 1680 (EPEAT) standard at the <Gold> level, see

 Plastics parts weighing over 25 grams used in the product are marked per ISO11469 and

 This product contains 0% post-consumer recycled plastic (by wt.)  This product is 95.2% recycle-able when properly disposed of at end of life.

SoundPower

,bels)

(L

WAd



2.9 22

3.5 28

2011/65/EC.

(WEEE) Directive – 2002/96/EC.

Water and Toxic Enforcement Act of 1986).

www.epeat.net

ISO1043.

PAPER/Corrugated 348 g

SoundPressure

(L

,decibels)

pAm



Internal:

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016

PLASTIC/Polyethylene Expanded - EPE 38 g

Page 61

QuickSpecs

Technical Specifications



The plastic packaging material contains at least 50% recycled content.

The corrugated paper packaging materials contains at least 70% recycled content.

Material Usage

This product does not contain any of the following substances in excess of regulatory limits (refer to the HP General Specification for the Environment at

http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):

 Asbestos  Certain Azo Colorants  Certain Brominated Flame Retardants – may not be used as flame retardants in plastics  Cadmium  Chlorinated Hydrocarbons  Chlorinated Paraffins  Formaldehyde  Halogenated Diphenyl Methanes  Lead carbonates and sulfates  Lead and Lead compounds  Mercuric Oxide Batteries  Nickel – finishes must not be used on the external surface designed to be frequently handled or

 Ozone Depleting Substances  Polybrominated Biphenyls (PBBs)  Polybrominated Biphenyl Ethers (PBBEs)  Polybrominated Biphenyl Oxides (PBBOs)  Polychlorinated Biphenyl (PCB)  Polychlorinated Terphenyls (PCT)  Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been

 Radioactive Substances  Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)



HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

PLASTIC/Polyethylene low density - LDPE 15 g PLASTIC/Polypropylene - PP 5 g

carried by the user.

voluntarily removed from most applications.

Packaging Usage



HP follows these guidelines to decrease the environmental impact of product packaging:

 Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging

materials.

 Eliminate the use of ozone-depleting substances (ODS) in packaging materials.  Design packaging materials for ease of disassembly.  Maximize the use of post-consumer recycled content materials in packaging materials.  Use readily recyclable packaging materials such as paper and corrugated materials.  Reduce size and weight of packages to improve transportation fuel efficiency.  Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016

Page 62

QuickSpecs

Technical Specifications



End-of-life Management and Recycling

Hewlett-Packard Corporate Environmental Information

Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas. To recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers. These instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.

For more information about HP’s commitment to the environment:

Global Citizenship Report

Eco-label certifications

ISO 14001 certificates:

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC HP EliteBook 850 G4 Notebook PC

http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html

http://www8.hp.com/us/en/hp-information/environment/ecolabels.html

COUNTRY OF ORIGIN

China

http://h20195.www2.hp.com/V2/GetDocument.aspx?docname=c04755842

and

http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 63

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC

QuickSpecs



HP EliteBook 850 G4 Notebook PC

Options and Accessories (Sold separately and availability may vary by country.)

Type Description Part Number

Docking HP USB Travel Dock HP UltraSlim Docking Station HP Elite USB-C Docking Station HP Adjustable Dual Display Stand AW664AA HP Display and Notebook Stand II E8G00AA

Input/Output

HP USB Essential Keyboard and Mouse H6L29AA HP Conferencing Keyboard K8P74AA HP Ultrathin Wireless Mouse L9V78AA

Memory

Power

Storage Security

Displays

HP USB-C Travel Dock

HP Slim Wireless Keyboard and Mouse T6L04AAxxx

HP UC Speaker Phone K7V16AA HP UC Wired Headset K7V17AA HP Stereo 3.5mm Headset T1A66AA HP Stereo USB Headset T1A67AA HP UC Wireless Mono Headset W3K08AA HP UC Wireless Duo Headset W3K09AA HP USB Speaker Phone X7N17AA HP 4GB 2133MHz DDR4 Memory T7B76AA HP 8GB 2133MHz DDR4 Memory T7B77AA HP 65W Slim AC Adapter H6Y82AA#xxx HP 90W Slim AC Adapter H6Y83AA#xxx HP 90W Slim Combo AC Adapter w/ USB H6Y84AA#xxx HP 45W Smart AC Adapter H6Y88AA#xxx HP 65W Smart AC Adapter H6Y89AA#xxx HP 90W Smart AC Adapter H6Y90AA#xxx HP Notebook Power Bank N9F71AA#xxx HP USB External DVDRW Drive F2B56AA HP Combination Lock T0Y15AA HP Keyed Cable lock T0Y14AA HP EliteDisplay E232 23-inch Monitor M1N98AA HP EliteDisplay S231d 23-inch Notebook Docking Monitor F3J72AA HP Elite Display S140u 14-inch USB Portable Monitor G8R65AA

T0K29AA#xxx T0K30AA#xxx D9Y32AA#xxx X7W54AA

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 64

HP EliteBook 820 G4 Notebook PC HP EliteBook 840 G4 Notebook PC

QuickSpecs



HP EliteBook 850 G4 Notebook PC

Change Log

Date of change Version History Description of change

December 19, 2016 V1 Launch Quickspecs launched

Copyright © 2016 HP Development Company, L.P. The only warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

Intel, Core and Thunderbolt are trademarks of Intel Corporation in the U.S. and/or other countries. Bluetooth is a trademark owned by its proprietor and used by HP Inc. under license. Microsoft and Windows are are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.USB Type-C™ and USB-C™ are trademarks of USB Implementers Forum.

Not all configuration components are available in all regions/countries.

c05240684 – DA15669 – World Wide – Version 1 – December 19, 2016



Page 65

Hewlett Packard Z2W95EA Quick Start Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
