Hewlett-Packard 810 Getting Started
Getting Started
HP Notebook
© Copyright 2012 Hewlett-Packard
Development Company, L.P.
Bluetooth is a trademark owned by its
proprietor and used by Hewlett-Packard
Company under license. Microsoft and
Windows are U.S. registered trademarks of
Microsoft Corporation. SD Logo is a
trademark of its proprietor.
The information contained herein is subject
to change without notice. The only
warranties for HP products and services are
set forth in the express warranty statements
accompanying such products and services.
Nothing herein should be construed as
constituting an additional warranty. HP shall
not be liable for technical or editorial errors
or omissions contained herein.
First Edition: January 2013
Document Part Number: 709343-001
Product notice
This guide describes features that are
common to most models. Some features
may not be available on your computer.
To obtain the latest information in this
guide, contact support. For U.S. support, go
to
http://www.hp.com/go/contactHP. For
worldwide support, go to
http://welcome.hp.com/country/us/en/
wwcontact_us.html.
Software terms
By installing, copying, downloading, or
otherwise using any software product
preinstalled on this computer, you agree to
be bound by the terms of the HP End User
License Agreement (EULA). If you do not
accept these license terms, your sole
remedy is to return the entire unused
product (hardware and software) within 14
days for a refund subject to the refund
policy of your place of purchase.
For any further information or for requesting
a full refund of the computer, please
contact your local point of sale (the seller).
Safety warning notice
WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not
place the computer directly on your lap or obstruct the computer air vents. Use the computer only on
a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft
surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to
come into contact with the skin or a soft surface, such as pillows or rugs or clothing, during operation.
The computer and the AC adapter comply with the user-accessible surface temperature limits defined
by the International Standard for Safety of Information Technology Equipment (IEC 60950).
iii
iv Safety warning notice
Table of contents
1 Welcome .......................................................................................................................................................... 1
Finding information ............................................................................................................................... 2
2 Getting to know your computer ..................................................................................................................... 4
Top ....................................................................................................................................................... 4
TouchPad ............................................................................................................................ 4
Lights ................................................................................................................................... 5
Keys ..................................................................................................................................... 6
Right ..................................................................................................................................................... 7
Left ....................................................................................................................................................... 8
Rear ...................................................................................................................................................... 8
Display ................................................................................................................................................ 10
Bottom ................................................................................................................................................ 12
3 Networking .................................................................................................................................................... 13
Using an Internet service provider (ISP) ............................................................................................ 13
Connecting to a wireless network ....................................................................................................... 14
Connecting to an existing WLAN ....................................................................................... 14
Setting up a new WLAN network ....................................................................................... 14
Configuring a wireless router ............................................................................ 15
Protecting your WLAN ....................................................................................... 15
Using HP Mobile Broadband (select models only) ............................................................ 15
Inserting and removing a SIM ........................................................................... 16
Using GPS (select models only) ........................................................................................ 17
Using Bluetooth wireless devices (select models only) ..................................................... 17
Connecting to a wired network ........................................................................................................... 18
Connecting to a local area network (LAN) ......................................................................... 18
4 Multimedia ..................................................................................................................................................... 19
Using the media activity controls ........................................................................................................ 19
Audio .................................................................................................................................................. 19
v
Adjusting the volume ......................................................................................................... 20
Checking audio functions on the computer ........................................................................ 20
Webcam (select models only) ............................................................................................................ 21
Video .................................................................................................................................................. 21
DisplayPort ........................................................................................................................ 21
5 External cards and devices .......................................................................................................................... 23
Using Media Card Reader cards (select models only) ....................................................................... 23
Inserting a digital card ........................................................................................................ 23
Removing a digital card ..................................................................................................... 24
Using a USB device ........................................................................................................................... 24
Connecting a USB device .................................................................................................. 25
Removing a USB device .................................................................................................... 25
Using optional external devices .......................................................................................................... 25
Using optional external drives ............................................................................................ 26
Using the docking connector (select models only) ............................................................ 26
6 Power management ...................................................................................................................................... 27
Shutting down the computer ............................................................................................................... 27
Setting power options ......................................................................................................................... 28
Using power-saving states ................................................................................................. 28
Intel Rapid Start Technology (select models only) ............................................ 28
Initiating and exiting Sleep ................................................................................ 28
Initiating and exiting Hibernation ....................................................................... 29
Using the power meter ....................................................................................................... 29
Using power plans ............................................................................................................. 29
Viewing the current power plan ......................................................................... 29
Selecting a different power plan ........................................................................ 29
Customizing power plans .................................................................................. 30
Setting password protection on wakeup ............................................................................ 30
Using battery power ........................................................................................................................... 30
Finding additional battery information ................................................................................ 31
Using Battery Check .......................................................................................................... 31
Displaying the remaining battery charge ........................................................................... 31
Maximizing battery discharge time .................................................................................... 31
Managing low battery levels .............................................................................................. 31
Identifying low battery levels ............................................................................. 32
Resolving a low battery level ............................................................................. 32
Resolving a low battery level when external power is available ....... 32
Resolving a low battery level when no power source is available .... 32
vi
Resolving a low battery level when the computer cannot exit
Hibernation ....................................................................................... 32
Conserving battery power .................................................................................................. 32
Storing a user-replaceable battery (select models only) .................................................... 33
Disposing of a user-replaceable battery (select models only) ........................................... 33
Replacing a user-replaceable battery (select models only) ............................................... 33
Using external AC power .................................................................................................................... 33
Testing an AC adapter ....................................................................................................... 34
7 Keyboard and pointing devices ................................................................................................................... 35
Using the keyboard ............................................................................................................................ 35
Identifying the Hot keys ..................................................................................................... 35
Using keypads ................................................................................................................... 37
Using the embedded numeric keypad ............................................................... 37
Turning the embedded numeric keypad on and off .......................... 37
Switching key functions on the embedded numeric keypad ............. 38
Using an optional external numeric keypad ...................................................... 38
Using pointing devices ....................................................................................................................... 38
Setting pointing device preferences ................................................................................... 38
Using the TouchPad .......................................................................................................... 38
Turning the TouchPad off and on ...................................................................... 39
Navigating ......................................................................................................... 39
Selecting ........................................................................................................... 40
Using TouchPad gestures ................................................................................. 40
Scrolling ............................................................................................ 41
Pinching/Zooming ............................................................................. 41
Rotating (select models only) ........................................................... 42
8 Maintenance .................................................................................................................................................. 43
Inserting or removing the battery ........................................................................................................ 43
Removing or replacing the service door ............................................................................................. 45
Removing the service door ................................................................................................ 45
Replacing the service door ................................................................................................ 46
Replacing or upgrading the hard drive ............................................................................................... 47
Removing the hard drive .................................................................................................... 47
Installing a hard drive ......................................................................................................... 48
Adding or replacing memory modules ............................................................................... 49
Updating programs and drivers .......................................................................................................... 51
Cleaning your computer ..................................................................................................................... 52
Cleaning products .............................................................................................................. 52
Cleaning procedures .......................................................................................................... 52
vii
Cleaning the display .......................................................................................... 52
Cleaning the sides and cover ............................................................................ 52
Cleaning the TouchPad and keyboard .............................................................. 53
9 Backup and recovery .................................................................................................................................... 54
Creating recovery media with HP Recovery Disc Creator .................................................................. 55
Creating recovery media .................................................................................................... 55
Backing up your information ............................................................................................................... 55
Performing a system recovery ............................................................................................................ 56
Using the Windows recovery tools ..................................................................................... 56
Using f11 recovery tools .................................................................................................... 57
Using a Windows 7 operating system DVD (purchased separately) ................................. 58
10 Support ........................................................................................................................................................ 59
Contacting support ............................................................................................................................. 59
Labels ................................................................................................................................................. 60
11 Specifications .............................................................................................................................................. 61
Input power ......................................................................................................................................... 61
Operating environment ....................................................................................................................... 62
Index ................................................................................................................................................................... 63
viii
1Welcome
After you set up and register the computer, it is important to take the following steps:
● Connect to the Internet—Set up your wired or wireless network so that you can connect to the
Internet. For more information, see
● Update your antivirus software—Protect your computer from damage caused by viruses. The
software is preinstalled on the computer and includes a limited subscription for free updates. For
more information, see the HP Notebook Reference Guide. For instructions on accessing this
guide, see
Finding information on page 2.
Networking on page 13.
● Get to know your computer—Learn about your computer features. See
computer on page 4 and Keyboard and pointing devices on page 35 for additional
information.
Find installed software—Access a list of the software preinstalled on the computer. Select
●
Start > All Programs. For details about using the software included with the computer, see the
software manufacturer's instructions, which may be provided with the software or on the
manufacturer's website.
Getting to know your
1
Finding information
The computer comes with several resources to help you perform various tasks.
Resources For information about
Setup Instructions poster
HP Notebook Reference Guide
To access this guide on your computer:
Select Start > Help and Support > User Guides.
Help and Support
To access Help and Support, select Start > Help and
Support.
NOTE: For U.S. support, go to
go/contactHP. For worldwide support, go to
http://welcome.hp.com/country/us/en/
wwcontact_us.html.
Regulatory, Safety, and Environmental Notices
http://www.hp.com/
How to set up the computer
●
● Help to identify computer components
Power management features
●
● How to maximize battery life
● How to use the multimedia features of the computer
● How to protect the computer
How to care for the computer
●
How to update the software
●
How to install certain components
●
How to create a wired and/or wireless network
●
Operating system information
●
● Software, driver, and BIOS updates
● Troubleshooting tools
● How to access support
● Regulatory and safety information
To access this guide:
Select Start > Help and Support > User Guides.
Safety & Comfort Guide
To access this guide:
Select Start > Help and Support > User Guides.
– or –
Go to
http://www.hp.com/ergo.
Worldwide Telephone Numbers booklet
This booklet is provided with your computer.
HP website
For U.S. support, go to
contactHP. For worldwide support, go to
http://welcome.hp.com/country/us/en/
wwcontact_us.html.
http://www.hp.com/go/
Battery disposal information
●
Proper workstation setup, posture, health, and work habits
●
● Electrical and mechanical safety information
HP support telephone numbers
Support information
●
● Ordering parts and finding additional help
● Accessories available for the device
2 Chapter 1 Welcome
Resources For information about
Limited Warranty*
To access the warranty:
Select Start > Help and Support > User Guides >
View Warranty Information.
– or –
Go to
http://www.hp.com/go/orderdocuments.
*You can find the expressly provided HP Limited Warranty applicable to your product located with the user guides on your
computer and/or on the CD/DVD provided in the box. In some countries/regions, HP may provide a printed HP Limited
Warranty in the box. For some countries/regions where the warranty is not provided in printed format, you may request a
printed copy from
North America: Hewlett-Packard, MS POD, 11311 Chinden Blvd., Boise, ID 83714, USA
●
Europe, Middle East, Africa: Hewlett-Packard, POD, Via G. Di Vittorio, 9, 20063, Cernusco s/Naviglio (MI), Italy
●
● Asia Pacific: Hewlett-Packard, POD, P.O. Box 200, Alexandra Post Office, Singapore 9115077
When you request a printed copy of your warranty, please include your product number, warranty period (found on your
service label), name, and postal address.
IMPORTANT: Do NOT return your HP product to the addresses above. For U.S. support, go to
contactHP. For worldwide support, go to http://welcome.hp.com/country/us/en/wwcontact_us.html.
http://www.hp.com/go/orderdocuments or write to:
Warranty information
http://www.hp.com/go/
Finding information 3
2 Getting to know your computer
Top
TouchPad
NOTE: Your computer may look slightly different from the illustration in this section.
Component Description
(1) TouchPad on/off button Turns the TouchPad on and off.
(2) TouchPad zone Moves the pointer and selects or activates items on the
(3) Left TouchPad button Functions like the left button on an external mouse.
(4) Right TouchPad button Functions like the right button on an external mouse.
screen.
4 Chapter 2 Getting to know your computer
Lights
NOTE: Your computer may look slightly different from the illustration in this section.
Component Description
(1) Caps lock light On: Caps lock is on.
(2)
(3)
(4)
(5) Num lock light On: Num lock is on.
(6) TouchPad light
Mute light ● Amber: Computer sound is off.
Off: Computer sound is on.
●
Microphone mute light ● Amber: Microphone is muted.
Off: Microphone is on.
●
Wireless light ● Amber: An integrated wireless device, such as a
wireless local area network (WLAN) device and/or a
Bluetooth® device, is on.
● Off: All wireless devices are off.
Amber: The TouchPad is off.
●
● Off: The TouchPad is on.
Top 5
Keys
NOTE: Your computer may look slightly different from the illustration in this section.
Component Description
(1) esc key Displays system information when pressed in
combination with the fn key.
(2) fn key Executes frequently used system functions when
pressed in combination with a function key, the num lk
key, the esc key, or the b key.
(3)
(4) Function keys Execute frequently used system functions when pressed
(5) Embedded numeric keypad When the keypad is turned on, it can be used like an
(6)
Windows key Returns you to the Start screen from an open app or the
Windows desktop.
NOTE: Pressing the Windows key again will return you
to the previous screen.
in combination with the fn key.
external numeric keypad.
Each key on the keypad performs the function indicated
by the icon in the upper-right corner of the key.
Windows applications key Displays options for a selected object.
6 Chapter 2 Getting to know your computer
Right
Component Description
(1) Power button Turns power on and off.
(2)
(3) Rotation lock button Locks screen orientation in either Landscape or Portrait
(4) Volume button Lowers the volume.
(5) Volume button Raises the volume.
(6) Speaker Produces sound.
(7)
(8)
Power light
Digital Media Card Reader Supports a micro SD High Capacity (SDHC) memory card
Audio-out (headphone) jack/Audio-in
(microphone) jack
On: The computer is on.
●
● Blinking: The computer is in the Sleep state.
● Off: The computer is off.
mode.
NOTE: When you move between notebook and tablet
configuration, the computer screen will automatically
change to vertical or horizontal. To lock the current
screen orientation, slide the screen orientation button.
or an optional wireless micro subscriber identity module
(SIM)
Produces sound when connected to optional powered
stereo speakers, headphones, earbuds, a headset, or
television audio. Also connects an optional headset
microphone.
WARNING! To reduce the risk of personal injury, adjust
the volume before putting on headphones, earbuds, or a
headset. For additional safety information, see the
Regulatory, Safety, and Environmental Notices. To
access the user guides, select the HP Support Assistant
app on the Start screen, select My computer, and then
select User guides.
NOTE: When a device is connected to the jack, the
computer speakers are disabled.
NOTE: Be sure that the device cable has a 4-conductor
connector that supports both audio-out (headphone) and
audio-in (microphone).
(9) Docking port Connects an optional docking device.
Right 7
Left
Rear
NOTE: Your computer may look slightly different from the illustration in this section.
Component Description
(1) Vent Enables airflow to cool internal components.
NOTE: The computer fan starts up automatically to cool
internal components and prevent overheating. It is normal
for the internal fan to cycle on and off during routine
operation.
(2) Speaker Produces sound.
NOTE: Your computer may look slightly different from the illustration in this section.
Component Description
(1)
(2)
(3)
(4)
RJ-45 (network) jack Connects a network cable.
USB 3.0 ports (1) Connect optional USB 3.0 devices and provide
enhanced USB power performance.
NOTE: For details about different types of USB
ports, see
Security cable slot Attaches an optional security cable to the
computer.
NOTE: The security cable is designed to act as
a deterrent, but it may not prevent the computer
from being mishandled or stolen.
DisplayPort Connects an optional digital display device, such
as a high-performance monitor or projector.
Using a USB device on page 24.
8 Chapter 2 Getting to know your computer
(5) USB 3.0 charging port Connects an optional USB device. The USB 3.0
(6) Power connector Connects an AC adapter.
charging port can also charge select models of
cell phones and MP3 players, even when the
computer is off.
NOTE: A USB charging port (also referred to as
a powered USB port) allows you to charge
connected USB devices. Standard USB ports will
not charge all USB devices or will charge using a
low current. Some USB devices require power
and require you to use a powered port.
NOTE: For details about different types of USB
ports, see
Using a USB device on page 24.
(7)
AC adapter light ● White: The AC adapter is connected and the
battery is charged.
Amber: The AC adapter is connected and
●
the battery is charging.
Off: The computer is using DC power.
●
Rear 9
Display
Your computer can serve as both a standard notebook and can rotate into a tablet configuration,
allowing you to use its touchscreen capabilities with a large number of apps.
CAUTION: To prevent damage to the display hinges, never force the rotating action.
10 Chapter 2 Getting to know your computer
CAUTION: To prevent damage to the display hinges, when in notebook configuration, do not rotate
the display counterclockwise.
To change your notebook to a tablet
1. Rotate the display clockwise 180 degrees until the display faces backwards.
2. Lower the display over the keyboard.
To change the tablet back into a notebook, reverse these steps.
Component Description
(1) Ambient light sensor Brightens or dims the display in response to ambient light.
(2) WLAN antennas (2)* Send and receive wireless signals to communicate with wireless
(3) WWAN antennas (2)* Send and receive wireless signals to communicate with wireless
(4) Internal microphones (2) Record sound.
(5) Webcam light On: The webcam is in use.
(6) Webcam Records video and captures still photographs.
(7) Windows Home button Returns you to the Start screen.
*The antennas are not visible on the outside of the computer. For optimal transmission, keep the areas immediately around
the antennas free from obstructions. To see wireless regulatory notices, see the section of the Regulatory, Safety, and
Environmental Notices that applies to your country or region. To access the user guides, select the HP Support Assistant
app on the Start screen, select My computer, and then select User guides.
local area networks (WLAN).
wide area networks (WWAN).
For information on using the webcam, access Help and Support.
From the Start screen, type h, and then select Help and
Support.
Display 11
Bottom
NOTE: Your computer may look slightly different from the illustration in this section.
Component Description
(1) Service cover Contains the hard drive, the wireless LAN module slot,
(2) Vents (2) Enable airflow to cool internal components.
(3)
(4) Battery bay Holds the battery.
(5)
Near Field Communication (NFC)
antenna
Battery bay cover release latch Releases the battery cover over the battery bay.
the WWAN module slot (select models only), and the
memory module slots.
CAUTION: To prevent an unresponsive system,
replace the wireless module only with a wireless
module authorized for use in the computer by the
governmental agency that regulates wireless devices
in your country or region. If you replace the module
and then receive a warning message, remove the
module to restore computer functionality, and then
contact support through Help and Support.
NOTE: The computer fan starts up automatically to
cool internal components and prevent overheating. It
is normal for the internal fan to cycle on and off during
routine operation.
With HP TouchZone, you can wirelessly connect,
communicate and transfer data/info to and from your
Near Field Communication (NFC)-compatible devices.
12 Chapter 2 Getting to know your computer
3Networking
NOTE: Internet hardware and software features vary depending on computer model and your
location.
Your computer may support one or both of the following types of Internet access:
Wireless—For mobile Internet access, you can use a wireless connection. For more information,
●
Connecting to an existing WLAN on page 14 or Setting up a new WLAN network
see
on page 14.
Wired—You can access the Internet by connecting to a wired network. For information on
●
connecting to a wired network, see the HP Notebook Reference Guide.
Using an Internet service provider (ISP)
Before you can connect to the Internet, you must establish an ISP account. Contact a local ISP to
purchase Internet service and a modem. The ISP will help set up the modem, install a network cable
to connect your wireless computer to the modem, and test the Internet service.
NOTE: Your ISP will give you a user ID and password to access the Internet. Record this
information and store it in a safe place.
The following features will help you set up a new Internet account or configure the computer to use an
existing account:
Internet Services & Offers (available in some locations)—This utility assists with signing up
●
for a new Internet account and configuring the computer to use an existing account. To access
this utility, select Start > All Programs > Communication and Chat.
ISP-provided icons (available in some locations)—These icons may be displayed either
●
individually on the Windows desktop or grouped in a desktop folder named Online Services. To
set up a new Internet account or configure the computer to use an existing account, double-click
an icon, and then follow the on-screen instructions.
● Windows Connect to the Internet Wizard—You can use the Windows Connect to the Internet
Wizard to connect to the Internet in any of these situations:
You already have an account with an ISP.
◦
◦ You do not have an Internet account and want to select an ISP from the list provided within
the wizard. (The list of ISP providers is not available in all regions.)
You have selected an unlisted ISP, and the ISP has provided you with information such as
◦
a specific IP address and POP3 and SMTP settings.
Using an Internet service provider (ISP) 13
To access the Windows Connect to the Internet Wizard and instructions for using it, select
Start > Control Panel > Network and Internet > Network and Sharing Center.
NOTE: If you are prompted within the wizard to choose between enabling or disabling
Windows Firewall, choose to enable the firewall.
Connecting to a wireless network
Wireless technology transfers data across radio waves instead of wires. Your computer may be
equipped with one or more of the following wireless devices:
Wireless local area network (WLAN) device
●
HP Mobile Broadband Module, a wireless wide area network (WWAN) device
●
Bluetooth device
●
For more information on wireless technology and connecting to a wireless network, see the
HP Notebook Reference Guide and information and website links provided in Help and Support.
Connecting to an existing WLAN
1. Turn on the computer.
2. Be sure that the WLAN device is on.
3. Click the network icon in the notification area, at the far right of the taskbar.
4. Select a WLAN to connect to.
NOTE: If no WLANs are listed, you may be out of range of a wireless router or access point.
NOTE: If you do not see the WLAN you want to connect to, click Open Network and Sharing
Center, and then click Set up a new connection or network. A list of options is displayed. You
can choose to manually search for and connect to a network or to create a new network
connection.
5. Click Connect.
6. If the network is a security-enabled WLAN, you are prompted to enter a network security code.
Type the code, and then click OK to complete the connection.
Setting up a new WLAN network
Required equipment:
A broadband modem (either DSL or cable) (purchased separately) (1) and high-speed Internet
●
service purchased from an Internet service provider (ISP)
A wireless router (purchased separately) (2)
●
Your new wireless computer (3)
●
NOTE: Some modems have a built-in wireless router. Check with your ISP to determine what type
of modem you have.
14 Chapter 3 Networking
Loading...
