HP 290 G2 Microtower PC
Maximize your investment
Take on your everyday work at an affordable price with the HP 290 MT. Get the reliable computing power you need while minimizing the total cost of ownership—now that’s a smart investment.
HP recommends Windows 10 Pro.
Windows 10 Pro
1TB hard drive
1
2
Ready for work
The HP 290 MT provides a powerful PC with the features you rely onto accomplish your everyday tasks.
Progressive style
The scalable and functional design of the HP 290 MT makes it easy to set up and use.
Powered up processing
Help optimize performance with an 8th Gen Intel® Core™ processor3, optional NVIDIA® or AMD discrete graphic support4, up to
16GB DDR4 memory4, PCIe x1 and PCIe x16 slots for future growth and support for optional PCIe NVME storage.
Help keep data safe
Help protect your investment and your data with firmware or discrete TPM and a security lock slot.
Featuring
Help secure the future of your business. PCs from HP make the most of Windows 10 Pro to protect you from today’s security
threats and maximize management and productivity features for business. Get fast and easy connections with optional Gigabit LAN and WLAN featuring 802.11ac protocol and Bluetooth® 4.2 connectivity.
Support two independent displays with VGA and HDMI connectivity. Make connections to peripherals with eight USB ports on the
HP 290 MT with two front and two rear USB 3.1 Gen1 ports, four rear USB 2.0 ports and an optional serial port. Spend less time and get right to the updates you need with HP Support Assistant.
With the clean, professional software image on the HP 290 MT, you will be productive in no time!
Make better use of your workspace. HP ePrint makes wireless printing simple, no need for drivers.
1
4
6
5
Datasheet
HP 290 G2 Microtower PC Specifications Table
HP recommends Windows 10 Pro.
Form Factor
Available Operating System
Available Processors
19
Maximum Memory
Memory slots
Internal Storage
Optical Storage
Available Graphics
Audio
Communications
Expansion Slots
Ports and Connectors
Internal Drive Bays
Input Device
Available Software
Security Management
Power
Dimensions
Weight
Energy Efficiency Compliance
Warranty
Microtower
Windows 10 Pro 64 – HP recommends Windows 10 Pro. Windows 10 Home 64 FreeDOS 2.0
Intel® Core™ i7-8700 with Intel® UHD Graphics 630 (3.2 GHz base frequency, up to 4.6 GHz with Intel® Turbo Boost Technology, 12 MB cache, 6 cores); Intel® Core™ i3-8100 with Intel® UHD Graphics 630 (3.6 GHz, 6 MB cache, 4 cores); Intel® Celeron® G4900 with Intel® UHD Graphics 610 (3.1 GHz, 2 MB cache, 2 cores); Intel® Core™ i5-8500 with Intel® UHD Graphics 630 (3 GHz base frequency, up to 4.1 GHz with Intel® Turbo Boost Technology, 9 MB cache, 6 cores); Intel® Pentium® Gold G5400 with Intel® UHD Graphics 610 (3.7 GHz, 4 MB cache, 2 cores)
Up to 16 GB DDR4-2666 SDRAM Standard memory note: Transfer rates up to 2666 MT/s.
2 DIMM
500 GB up to 1 TB 7200 rpm SATA 128 GB up to 256 GB M.2 SSD
HP 9.5 mm Slim DVD-Writer
Integrated: Intel® HD Graphics 610; Intel® UHD Graphics 630
Realtek ALC3601 codec, internal speaker, combo microphone/headphone jack
LAN: Integrated 10/100/1000M GbE WLAN: Realtek 802.11a/b/g/n/ac (1x1) and Bluetooth® 4.2 Combo
1 PCIe; 1 PCIe x1; 1 PCIe x16; 1 SD media reader; 2 M.2 (1 M.2 slot for WLAN and 1 M.2 2230/2280 slot for storage.)
Front: 1 headphone/microphone combo; 1 SD 3 card reader; 2 USB 3.1 Gen 1 Rear: 1 audio-in; 1 audio-out; 1 HDMI; 1 microphone-in; 1 power connector; 1 RJ-45; 1 serial; 1 VGA; 2 USB 3.1 Gen 1; 4 USB 2.0 Internal: 1 parallel; 1 PS/2
One 3.5" HDD; One 3.5" (2.5") HDD
HP USB Keyboard HP USB Optical Mouse
HP Audio Switch; HP Documentation; HP ePrint Driver + JetAdvantage; HP Jumpstart; HP Recovery Manager; HP Setup Integrated OOBE Win10; HP Support Assistant; HP System Event Utility; McAfee LiveSafe™; Buy Office (sold separately)
Lock slot; Trusted Platform Module TPM 2.0 Embedded Security Chip (SLB9670 - Common Criteria EAL4+ Certified)
180 W internal power supply, up to 87% efficiency, active PFC
17 x 33.8 x 27.75 cm (System dimensions may fluctuate due to configuration and manufacturing variances.)
5.4 kg (Exact weight depends on configuration.)
ENERGY STAR®certified; EPEAT® Silver
1 year (1-1-1) limited warranty and service offering includes 1 year of parts, labor and on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply.
1
13
3
3
4
23
5
8
1
2,12
11
9,10,24
22,25
16,17
20,21
14
Datasheet
HP 290 G2 Microtower PC
Accessories and services (not included)
HP USB Slim Business Keyboard
Get fast data entry and quick USB connectivity with the HP USB Business Slim Keyboard, designed to complement the 2015 class of HP Business PCs.
Product number: N3R87AA
HP recommends Windows 10 Pro.
HP TLC 256 GB SATA SSD Expand the storage capabilities of your desktop with the HP TLC 256 GB SATA SSD1, which includes TLC flash and the
HP USB Optical Scroll Mouse Utilizing the latest optical sensing technology, the HP USB Optical Scroll Mouse records precise motion over a variety of
NVIDIA GT 730 2GB DP Card Get impressive graphics and high resolution quad-display performance from the NVIDIA® GT 730 2GB DP Card.
HP 3 year Next business day Onsite Desktop Only Hardware Support
same reliability you already get from current from SSD drives.
Product number: P1N68AA
surfaces without a mouse pad.
Product number: QY777AA
Product number: Z9H51AA
Receive 3 years of next business day onsite HW Support from an HP-qualified technician for your computing device, if the issue cannot be solved remotely.
Product number: U6578E
Datasheet
HP recommends Windows 10 Pro.
HP 290 G2 Microtower PC
Messaging Footnotes
1
Not all featuresare available in all editionsor versionsof Windows. Systems may requireupgraded and/or separatelypurchased hardware, drivers, softwareor BIOSupdate to take fulladvantage ofWindows functionality. Windows 10 is automaticallyupdated,
which is alwaysenabled. ISPfees may apply and additional requirementsmay apply over time forupdates. See http://www.windows.com.
2
For hard drives,GB =1 billion bytes. TB= 1trillion bytes. Actual formattedcapacity isless. Up to 36GB of systemdisk (for Windows 10) is reservedfor system recovery software.
3
Multicore isdesigned toimprove performance of certainsoftware products. Not allcustomers orsoftware applications will necessarilybenefit fromuse of this technology. Performanceand clock frequency will varydepending onapplication workload and your
hardware andsoftware configurations. Intel’s numbering,branding and/or naming isnot ameasurement of higher performance.
4
Sold separatelyor asan optional feature.
5
Sold separatelyor asan optional feature. Wirelessaccess point ad internet service required. Availability ofpublic wireless accesspoints limited.The specifications for the 802.11ac WLAN aredraft specifications and are notfinal. Ifthe final specifications differ
from the draft specifications,it may affect the ability ofthe notebook to communicatewith other 802.11ac WLAN devices.
6
Requires an Internetconnection to HP web-enabledprinter andHP ePrintaccount registration (fora listof eligible printers, supported documents andimage typesand other HP ePrint details, seewww.hpconnected.com). May require wirelessaccess point.
Separately purchaseddata plans or usage feesmay apply. Print times andconnection speedsmay vary. Some HP LaserJet printers mayrequire firmware upgrades.
Technical specifications disclaimers
1
Not all featuresare available in all editionsor versionsof Windows. Systems may requireupgraded and/or separatelypurchased hardware, drivers, softwareor BIOSupdate to take fulladvantage ofWindows functionality. Windows 10 is automaticallyupdated,
which is alwaysenabled. ISPfees may apply and additional requirementsmay apply over time forupdates. See http://www.windows.com/
2
HD content requiredto view HD images.
3
For hard drivesand solidstate drives, GB = 1 billionbytes. TB = 1 trillion bytes. Actualformatted capacity is less. Up to36 GB(for Windows 10) of systemdisk isreserved for the system recoverysoftware.
4
Optical drives areoptional oradd on features. Duplication ofcopyrighted material is strictly prohibited.Actual speeds may vary. Double Layermedia compatibility will widelyvary withsome homeDVD players and DVD-ROM drives.
5
Keyboards and miceare optional or add-on features.
8
EPEAT® registered where applicable.EPEAT registration variesby country. See www.epeat.net forregistration status by country. Searchkeyword generator on HP’s 3rdparty optionstore for solar generatoraccessories at www.hp.com/go/options
9
Card sold separately.
10
1 full-height PCI:Optional onseparated PCA.
11
Wireless cardsare optional or add-on featuresand requires separatelypurchased wireless accesspoint andinternet service. Availability of publicwireless access points limited.
12
Integrated IntelWi-Di software is availableon selectmodels only and requires separately purchased projector,tv orcomputer monitor with an integratedor external Wi-Di receiver.External Wi-Direceivers connect to the projector,tv orcomputer monitor via a
standard VGA, HDMIcable, also sold separately.
13
Full availability of4 GBor more of memory requires a64-bit operating system. With Windows32-bit operating systems, the amountof usable memory is dependent uponyour configuration, so that above3 GB all memory may not beavailable due to system
resource requirements.Memory modules support data transferrates upto 2400 MT/s;actual data rate is determined bythe system’s configured processor.See processor specifications for supportedmemory datarate.
14
All power suppliesare not available inevery region.
16
McAfee LiveSafe™:1 yearsubscription.
17
HP ePrint Driver +JetAdvantage: Requires an Internet connectionto HPweb-enabled printer and HP ePrint accountregistration (for a list ofeligible printers, supported documents and imaget ypesand otherHP ePrint details, see www.hp.com/go/eprintcenter).
Print times and connectionspeeds mayvary.
18
Your productdoes not support Windows 8or Windows7, Inaccordance with Microsoft’s supportpolic y, HP does notsupport theWindows 8or Windows 7 operating system onproducts configured with Intel® 8th generationand forward processorsor provide
any Windows 8 orWindows 7drivers onhttp://www.support.hp.com
19
Multi-Core isdesigned toimprove performance of certain softwareproducts. Not all customers orsoftware applications will necessarily benefitfrom useof this technology. Performanceand clockfrequency will vary depending onapplication workload and your
hardware andsoftware configurations. Intel’s numbering,branding and/or naming isnot ameasurement of higher performance.
20
Security cable locksupported (sold separately).
21
TPM 2.0support (eitherdTPM orfTPM): TPM feature willnot be supported on machine pre-configuredwith FreeDOS. In same cases,machines pre-configured with WindowsOS mightship withTPM turned off.
22
HDMI Port: port willbe covered up whendiscrete graphic card is configuredon shipped machine. VGA Port: port willbe covered up whendiscrete graphic card is configuredon shippedmachine.
23
PS/2 Port: optionalon sameseparated PCA with serial port availableas well.Parallel Port: optional viaPCIe x1slot.
24
1 PCIe for selectedconfigurations only.
25
1 serial for selectedconfigurations only.
Sign up for updates
www.hp.com/go/getupdated
© Copyright 2018 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. Microsoft and Windows are registered trademarks or trademarks of Microsoft Corporation in the U.S. and/or other countries. Intel, Celeron®, Core, Pentium are registered trademarks or trademarks of Intel Corporation in the U.S. and/or other countries. Bluetooth is a trademark of its proprietor, used by HP Inc. under license. NVIDIA, GeForce, Kepler and NVS are trademarks and/or registered trademarks of NVIDIA Corporation in the U.S. and other countries. AMD and Radeon are trademarks of Advanced Micro Devices, Inc. ENERGY STAR is a registered trademark owned by the U.S. Environmental Protection Agency.
4AA7-2594EEE, May 2018
