Hewlett Packard 204L9EA Getting Started Guide

Datasheet

HP EliteBook 855 G7 Notebook PC

Move through your day with confidence

Ease through your multi-task, multi-place day with the beautifully designed, powerful, highly secure HP EliteBook 855. Created for people on the move, this thin and light laptop helps people confidently connect and stay productive in almost any setting.

HP recommends Windows 10 Pro for business

Designed for comfort

Easy to carry from meeting to meeting, the ultrathin and light 15.6-inch diagonal HP EliteBook 855 boasts an 86-percent screen-to-body ratio. It also includes a new keyboard and clickpad that are quiet and comfortable to work on.

Work with peace of mind

Security features from HP work together to create an always-on, always-acting, resilient defense. From the BIOS to the browser, above and below the OS, these constantly evolving solutions help protect your PC from threats.

Easy connections

How we work is evolving quickly. Help drive connectivity and productivity with a premium AMD Ryzen™ PRO processor with Radeon™ VEGA graphics, Wi-Fi 6 , and long battery life.

Work with a powerful, highly secure, and reliable AMD Ryzen™ PRO processor with Radeon™ VEGA graphics and AMD Memory Guard that helps defend against cold boot attacks with real-time encryption and decryption of your system’s memory.

Instantly block prying eyes’ ability to view your screen with optional HP Sure View Reflect that produces a copper reflective finish when the screen is viewed from the side making it appear unreadable.

Malware is evolving rapidly, and traditional antivirus can’t always recognize new attacks. Protect your PC against never-before-seen attacks with HP Sure Sense, which uses deep learning AI to provide exceptional protection against advanced malware.

With 4G LTE powered with 2x2 antennas, your “office” can be where you need it, letting you stay connected almost everywhere.

The portability of your PC and the reliability of a fast connection determines where you can work. Get a fast and reliable connection in dense wireless environments with gigabit-speed Wi-Fi 6.

Never wonder if someone is watching you with the added peace-of-mind that comes from the optional HP Privacy Camera, with a physical shutter to protect from malicious surveillance.

Make well-being measurable and actionable at work with HP WorkWell. Designed to coach you to take breaks, exercise, and to provide productivity tips, this app recommends healthy habits personalized to you.

Enjoy the consistent feel and extremely quiet typing experience of the redesigned keyboard with rubber dome keys.

Firmware attacks can completely devastate your PC - stay protected with HP Sure Start Gen6 self-healing BIOS.

2 4

Data sheet | HP EliteBook 855 G7 Notebook PC

HP recommends Windows 10 Pro for business

HP EliteBook 855 G7 Notebook PC Specifications Table

Available Operating Systems

Windows 10 Pro 64 Windows 10 Home 64 – HP recommends Windows 10 Pro for business Windows 10 Home Single Language 64 Windows 10 Pro (Windows 10 Enterprise available with a Volume Licensing Agreement) FreeDOS

Processor family AMD Ryzen™ PRO APU processor

Available Processors

AMD Ryzen™ 3 PRO 4450U APU with Radeon™ Graphics (2.5 GHz base clock, up to 3.8 GHz max boost clock, 4 MB L3 cache, 4 cores); AMD Ryzen™ 5 PRO 4650U APU with Radeon™ Graphics (2.1 GHz base clock, up to 4 GHz max boost clock, 8 MB L3 cache, 6 cores); AMD Ryzen™ 7 PRO 4750U APU with Radeon™ Graphics (1.7 GHz base clock, up to 4.2 GHz max boost clock, 8 MB L3 cache, 8 cores)

Maximum memory

32 GB DDR4-3200 SDRAM Both slots are customer accessible/upgradeable. Supports dual channel memory.

Memory slots 2 SODIMM

Internal storage

256 GB up to 1 TB PCIe® Gen3x4 NVMe™ M.2 SSD TLC 256 GB up to 512 GB PCIe® Gen3x4 NVMe™ M.2 SED SSD TLC 256 GB up to 512 GB PCIe® NVMe™ Value M.2 SSD up to 128 GB M.2 SATA SSD TLC

Display

39.6 cm (15.6") diagonal FHD, IPS, anti-glare, WLED-backlit, eDP, 250 nits, 45% NTSC (1920 x 1080); 39.6 cm (15.6") diagonal FHD, IPS, anti-glare, WLED-backlit, touch screen, eDP, 250 nits, 45% NTSC (1920 x 1080); 39.6 cm (15.6") diagonal, FHD (1920 x

1080), IPS, anti-glare, 1000 nits, 72% NTSC, HP Sure View Reflect integrated privacy screen; 39.6 cm (15.6") diagonal, FHD (1920 x 1080), IPS, anti-glare, 400 nits, low power, 72% NTSC

Available Graphics

Integrated: AMD Radeon™ Vega Graphics (Support HD Decode, DX12, and HDMI.)

Audio Audio by Bang & Olufsen, dual stereo speakers, 3 multi array microphone

Wireless technologies

Intel®AX200Wi-Fi 6 (2x2) and Bluetooth® 5 Combo, non-vPro™; Intel® XMM™ 7360 LTE-Advanced Cat 9; Realtek RTL8822BE

802.11 b/g/n/ac (2x2) Wi-Fi® and Bluetooth® 5 combo (Compatible with Miracast-certified devices.)

Expansion slots 1 external SIM; 1 smart card reader

Ports and Connectors

2 USB Type-C® (Alt mode); 1 USB 3.1 Gen 1 (charging); 1 USB 3.1 Gen 1; 1 headphone/microphone combo; 1 HDMI 2.0; 1 AC power (HDMI cable sold separately.)

Input devices

HP Premium Keyboard – spill resistant, optional backlit keyboard with drain and DuraKeys ; Clickpad with multi-touch gesture support, taps enabled as default; Precision Touchpad with multi-touch gesture support; Ambient light sensor; Hall sensor

Communications HP Module with NXP NFC Controller NPC300 I2C NCI (select models) ;

Camera 720p HD camera; HD IR webcam

Security management

Absolute persistence module; HP DriveLock and Automatic DriveLock; HP Secure Erase; Power-on authentication; TPM 2.0 embedded security chip shipped with Windows 10 (Common Criteria EAL4+ Certified); HP Sure Click; Windows Defender; HP BIOSphere Gen5; HP Sure Sense; BIOS Update via Network; HP Client Security Manager Gen6; HP Sure Start Gen6; HP Sure Run Gen3; HP Sure Recover Gen3

Fingerprint reader Fingerprint sensor (select models)

Management features

HP Driver Packs; HP System Software Manager (SSM); HP BIOS Config Utility (BCU); HP Client Catalog; Ivanti Management Suite; HP Manageability Integration Kit Gen4

Power HP Smart 65 W External AC power adapter; HP Smart 45 W External AC power adapter; 65 W USB Type-C® adapter

Battery type HP Long Life 3-cell, 53 Wh Li-ion

Battery life Up to 25 hours and 15 minutes

Dimensions 35.97 x 23.38 x 1.92 cm (non-touch); 35.97 x 23.38 x 2 cm (touch)

Weight Starting at 1.7 kg (non-touch); Starting at 1.78 kg (touch) (Weight will vary by configuration.)

Energy efficiency compliance

ENERGY STAR® certified; EPEAT® registered where applicable. EPEAT registration varies by country. See www.epeat.net for registration status by country.

Environmental specifications Low halogen; TCO 8.0 Certified

Warranty 3 year limited parts, labor (3-3-0) warranty. Certain restrictions and exclusions apply.



3,4,5

12,15,16,41

8,9,10

11,42

12,13,14

21,22,23,24,25,26,27,28,29,30,31,32,33

18,19,20
