Models: NB3630M, NB3630MI, NB3933M, NB3933MI, NB4236M, NB4236MI, NB4842M, NB4842MI B-Vent Gas Appliance

Owner’s Manual

Installation and Operation

CAUTION

DO NOT DISCARD THIS MANUAL

•

• Important operating and maintenance instructions included.

Read, understand and follow these instructions for safe installation and operation.

WARNING

If the information in these instructions is not followed exactly, a ﬁ re may result causing property damage, personal injury, or death.

• Do not store or use gasoline or other ﬂ am- mable vapors and liquids in the vicinity of this or any other appliance.

• What to do if you smell gas:

- Do not try to light any appliance.

- Do not touch any electrical switch. Do not use any phone in your building.

- Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

- If you cannot reach your gas supplier, call the ﬁ re department.

• Installation and service must be performed by a qualiﬁ ed installer, service agency, or

the gas supplier.

This appliance may be installed as an OEM installation in manufactured home (USA only) or mobile home and must be installed in accordance with the manufacturer’s instructions and the manufactured home construction and safety standard, Title 24 CFR, Part 3280 or Standard for

Installation in Mobile Homes, CAN/CSA Z240MH.

This appliance is only for use with the type(s) of gas indicated on the rating plate.

DO NOT

DISCARD

•

Leave this manual with party responsible for use and operation.

WARNING

HOT SURFACES!

Glass and other surfaces are hot during operation and cool down.

Hot glass will cause burns.

• Do not touch glass until it is cooled

• NEVER allow children to touch glass

• Keep children away

• CAREFULLY SUPERVISE children in same room as appliance.

• Alert children and adults to hazards of high temperatures.

High temperatures may ignite clothing or other ﬂ ammable materials.

• Keep clothing, furniture, draperies and other combustibles away.

This appliance has been supplied with an integral barrier to prevent direct contact with the ﬁ xed glass panel. Do NOT operate the appliance with the barrier removed.

Contact your dealer or Hearth & Home Technologies if the barrier is not present or help is needed to properly install one.

In the Commonwealth of Massachusetts:

• installation must be performed by a licensed plumber or gas ﬁ tter.

• a CO detector shall be installed in the room where the appliance is installed.

Installation and service of this appliance should be performed by qualified personnel. Hearth & Home Technologies suggests NFI certiﬁ ed or factory-trained professionals, or technicians supervised by an NFI certiﬁ ed professional.

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 1

Read this manual before installing or operating this appliance.

Please retain this owner’s manual for future reference.

Congratulations

Congratulations on selecting a Heatilator gas appliance—an elegant and clean alternative to wood burning appliances. The Heatilator gas appliance you have selected is designed to provide the utmost in safety, reliability, and efﬁ ciency.

As the owner of a new appliance, you’ll want to read and carefully follow all of the instructions contained in this owner’s

The information contained in this owner’s manual, unless noted otherwise, applies to all models and gas control systems.

Your new Heatilator gas appliance will give you years of durable use and trouble-free enjoyment. Welcome to the Heatilator family of appliance products!

manual. Pay special attention to all cautions and warnings.

This owner’s manual should be retained for future reference. We suggest you keep it with your other important documents and product manuals.

We recommend that you record the following pertinent

Homeowner Reference Information

information about your appliance:

Model Name: Date purchased/installed:

Serial Number: Location on appliance:

Dealership purchased from: Dealer phone:

Notes:

Listing Label Information/Location

The model information regarding your speciﬁ c appliance can be found on the rating plate located in the control area of the appliance.

Serial #

XXXXXXXXX

XXXX

CERTIFIED

FOR CANADA

CERTIFIÉ POUR LE

CANADA

Orifice Size

Model #

Gas Type

Hearth & Home Technologies Inc

1915 W. Saunders Street Mt. Pleasant, IA 52641

ANSI Standard

MODEL MFG. DATE MODÈLE DATE DE FAB.

GAS TYPE/TYPE DE GAZ NATURAL/NATUREL PROPANE ALTITUDE 0-2000 2000-4000 FT/PI 0-2000 2000-4000 FT/PI MAX INPUT/DÉBIT XX,XXX XX,XXX BTUH XX,XXX XX,XXX BTUH MIN INPUT/DÉBIT XX,XXX XX,XXX BTUH XX,XXX XX,XXX BTUH MANIFOLD PRESSURE/PRESSION TUBULAIRE MAX. XX IN. W.C./C. D'EAU XX IN. W.C./C. D'EAU MIN. XX IN. W.C./C. D'EAU XX IN. W.C./C. D'EAU MIN. INLET PRESS. XX IN. W.C./C. D'EAU 1XX IN. W.C./C. D'EAU FOR THE PURPOSE OF INPUT ADJUSTMENT PRESS. MIN. D'ALIMENTATION ORIFICE SIZE DIAM. DE L'INJECTEUR XX/XX DIA. in./mm XX/XX DIA. in./mm

XXXXXX

SERIAL NO. DE SÉRIE

LESS THAN/MOINS DE 3 AMPÈRES., 115V., 60 Hz

DO NOT REMOVE OR COVER THIS LABEL. VENTED GAS FIREPLACE - NOT FOR USE WITH SOLID FUEL. FOYER À GAZ À ÉVACUATION - NE DOIT PAS ÊTRE UTILISÉ AVEC UN COMBUSTIBLE SOLIDE.

2 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Table of Contents

1 Listing and Code Approvals 4

A. Appliance Certiﬁ cation . . . . . . . . . . . . . . . . . . . . . . . . . 4

B. Glass Speciﬁ cations . . . . . . . . . . . . . . . . . . . . . . . . . . 4

C. BTU Speciﬁ cations . . . . . . . . . . . . . . . . . . . . . . . . . . .4

D. High Altitude Installations . . . . . . . . . . . . . . . . . . . . . . 4

E. Non-Combustible Materials . . . . . . . . . . . . . . . . . . . . . 4

F. Combustible Materials . . . . . . . . . . . . . . . . . . . . . . . . . 4

2 Getting Started 5

A. Design and Installation Considerations . . . . . . . . . . . . 5

B. Negative Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

C. Tools and Supplies Needed . . . . . . . . . . . . . . . . . . . . . 7

D. Inspect the Appliance and Components . . . . . . . . . . . 7

3 Framing and Clearances 8

A. Select Appliance Location . . . . . . . . . . . . . . . . . . . . . . 8

B. Construct the Appliance Chase . . . . . . . . . . . . . . . . . . 9

C. Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

D. Mantel Projections . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

4 Termination Locations 12

A. Vent Termination Minimum Clearances . . . . . . . . . . . 12

5 Vent Information and Diagrams 13

A. Vent Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

B. Vent System Conﬁ guration . . . . . . . . . . . . . . . . . . . . 13

6 Vent Clearances and Framing 15

A. Pipe Clearances to Combustibles . . . . . . . . . . . . . . . 15

B. Wall Penetration Framing . . . . . . . . . . . . . . . . . . . . . 15

C. Vertical Penetration Framing . . . . . . . . . . . . . . . . . . . 15

7 Appliance Preparation 16

A. Installing Outside Air Kit Damper Assembly . . . . . . . 16

B. Gas and Electrical Connections . . . . . . . . . . . . . . . . 17

C. Securing and Leveling Appliance . . . . . . . . . . . . . . . 17

8 Installing Vent Pipe 18

A. Assemble Vent Sections . . . . . . . . . . . . . . . . . . . . . . 18

B. Attach Vent to Firebox Assembly . . . . . . . . . . . . . . . 18

C. Securing Vent Sections . . . . . . . . . . . . . . . . . . . . . . . 18

9 Gas Information 19

A. Fuel Conversion . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

B. Gas Pressure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

C. Gas Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

D. High Altitude Installations . . . . . . . . . . . . . . . . . . . . . 20

10 Electrical Information 21

A. Recommendation for Wire . . . . . . . . . . . . . . . . . . . . . 21

B. Connecting to the Appliance . . . . . . . . . . . . . . . . . . . 21

C. Intelliﬁ re Ignition System Wiring . . . . . . . . . . . . . . . .21

D. Standing Pilot Ignition System Wiring . . . . . . . . . . . . 22

E. Junction Box Installation . . . . . . . . . . . . . . . . . . . . . . 23

F. Wall Switch Installation for Fan (Optional) . . . . . . . . . 23

11 Finishing 24

A. Mantel Projections . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

B. Facing Material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

12 Appliance Setup 25

A. Remove the Shipping Materials. . . . . . . . . . . . . . . . . 25

E. Clean the Appliance. . . . . . . . . . . . . . . . . . . . . . . . . . 25

B. Remove the Clean Face Components . . . . . . . . . . . 25

C. Remove Glass Assembly. . . . . . . . . . . . . . . . . . . . . .25

D. Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

F. Lava Rock, Vermiculite, Rockwool Placement . . . . .25

G. Replace Glass Assembly . . . . . . . . . . . . . . . . . . . . . . 26

H. Install Clean Face Components . . . . . . . . . . . . . . . . 26

I. Air Shutter Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

13 Operating Instructions 29

A. Before Lighting Appliance . . . . . . . . . . . . . . . . . . . . . 29

B. Check Appliance Draft . . . . . . . . . . . . . . . . . . . . . . . . 30

C. Lighting the Appliance . . . . . . . . . . . . . . . . . . . . . . . . 31

D. After the Appliance is Lit . . . . . . . . . . . . . . . . . . . . . . 33

E. Frequently Asked Questions . . . . . . . . . . . . . . . . . . . 33

14 Troubleshooting 34

A. Standing Pilot Ignition System . . . . . . . . . . . . . . . . . . 34

B. Intelliﬁ re Ignition System . . . . . . . . . . . . . . . . . . . . . .36

15 Maintaining and Servicing the Appliance 38

16 Reference Materials 40

A. Appliance Dimension Diagram . . . . . . . . . . . . . . . . . 40

B. Service Parts List. . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

C. Optional Components . . . . . . . . . . . . . . . . . . . . . . . . 58

D. Limited Lifetime Warranty . . . . . . . . . . . . . . . . . . . . . 67

E. Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Note: An arrow (¨) found in the text signiﬁ es change in content.

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 3

Listing and Code Approvals

A. Appliance Certiﬁ cation

MODELS: NB3630M, NB3630MI, NB3933M, NB3933MI, NB4236M, NB4236MI, NB4842M, NB4842MI LABORATORY: Underwriters Laboratories, Inc. (UL) TYPE: B-Vent Gas Appliance STANDARD: ANSI Z21.88-2005/CSA2.33-2005

This product is listed to ANSI standards for “Vented Gas Fireplaces” and “Gas Fired Appliances for Use at High Altitudes”.

This model (natural gas and propane) can be installed in a bedroom (in the United States) which has a total volume of unconﬁ ned space appropriate to the particular installation. Refer to the National Fuel Gas Code ANSI Z223.1/NFPA54

(current edition), The Uniform Mechanical Code - (current edition), and local building ofﬁ cials for the options al-

lowed in obtaining an effective bedroom volume of unconﬁ ned space.

This model (natural gas and propane) can be installed in a bedroom (in Canada) if a thermostat is installed with the appliance. Consult local code authorities.

NOT INTENDED FOR USE AS A PRIMARY HEAT SOURCE. This appliance is tested and approved as either

supplemental room heat or as a decorative appliance. It should not be factored as primary heat in residential heating calculations.

B. Glass Speciﬁ cations

Hearth & Home Technologies appliances manufactured with tempered glass may be installed in hazardous locations such as bathtub enclosures as deﬁ ned by the Consumer Product Safety Commission (CPSC). The tempered glass has been tested and certiﬁ ed to the requirements of ANSI Z97.1 and

CPSC 16 CFR 1202 (Safety Glazing Certiﬁ cation Council SGCC# 1595 and 1597. Architectural Testing, Inc. Reports 02-31919.01 and 02-31917.01).

This statement is in compliance with CPSC 16 CFR Section

1201.5 “Certiﬁ cation and labeling requirements” which refers

to 15 U.S. Code (USC) 2063 stating “…Such certiﬁ cate shall accompany the product or shall otherwise be furnished to any distributor or retailer to whom the product is delivered.”

Some local building codes require the use of tempered glass with permanent marking in such locations. Glass meeting this requirement is available from the factory. Please contact your dealer or distributor to order.

C. BTU Speciﬁ cations

Novus BV NB3630M NB3933M

Standing Pilot or IPI

Max/Min Input Rate (NG) 20,000/14,000 22,000/15,000

Oriﬁ ce Size (NG) 0.083 0.089

Max/Min Input Rate (LP) 20,000/15,000 22,000/15,000

Oriﬁ ce Size (LP) 0.052 0.055

Novus BV NB4236M NB4842M

Standing Pilot or IPI

Max/Min Input Rate (NG) 25,000/17,000 30,000/20,500

Oriﬁ ce Size (NG) 0.094 0.104

Max/Min Input Rate (LP) 25,000/17,000 30,000/20,500]

Oriﬁ ce Size (LP) 0.058 0.064

D. High Altitude Installations

U.L. Listed gas appliances are tested and approved without requiring changes for elevations from 0 to 2000 feet in the U.S.A. and Canada.

When installing this appliance at an elevation above 2000 ft, it may be necessary to decrease the input rating by changing the existing burner oriﬁ ce to a smaller size. Input rate should be reduced by 4% for each 1000 ft above a 2000 ft elevation in the U.S.A., or 10% for elevations between 2000 and 4500 ft in Canada. If the heating value of the gas has been reduced, these rules do not apply. To identify the proper oriﬁ ce size, check with the local gas utility.

If installing this appliance at an elevation above 4500 ft (in Canada), check with local authorities.

WARNING

Do NOT use this appliance if any part has been under water. Immediately call a qualiﬁ ed service technician to inspect the appliance and to replace any part of the control system and any gas control which has been under water.

E. Non-Combustible Materials

Material which will not ignite and burn. Such materials are those consisting entirely of steel, iron, brick, tile, concrete, slate, glass or plasters, or any combination thereof.

Materials that are reported as passing ASTM E 136, Stan-

dard Test Method for Behavior of Materials in a Vertical Tube Furnace at 750° C, shall be considered non-combus-

tible materials.

Note: This installation must conform with local codes. In the absence of local codes you must comply with the National Fuel Gas Code, ANSI Z223.1-latest edition in the U.S.A. and the CAN/CGA B149 Installation Codes in Canada.

4 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

F. Combustible Materials

Materials made of or surfaced with wood, compressed paper, plant ﬁ bers, plastics, or other material that can ignite and burn, whether ﬂ ame proofed or not, or whether plastered or unplastered shall be considered combustible materials.

Getting Started

A. Design and Installation Considerations

Heatilator B-vent gas appliances are designed to operate with all exhaust gases expelled to the outside of the building, and combustion air pulled from the room.

CAUTION

Check building codes prior to installation.

• Installation MUST comply with local, regional, state and national codes and regulations.

• Consult insurance carrier, local building, fire ofﬁ cials or authorities having jurisdiction about restrictions, installation inspection, and permits.

When planning an appliance installation, it’s necessary to determine the following information before installing:

• Where the appliance is to be installed. See Sections 3

and 4.

• The vent system conﬁ guration to be used. See Sections

5 and 6.

• Gas supply piping. See Sections 7 and 9.

• Electrical wiring. See Sections 7 and 10

• Framing and finishing details. See Sections 3, 6

and 11.

• Whether optional accessories—devices such as a fan, wall switch, or remote control—are desired. See Section 16.

WARNING

Keep appliance dry.

• Mold or rust may cause odors.

• Water may damage controls.

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 5

B. Negative Pressure

WARNING

Asphyxiation Risk

• Negative pressure can cause spillage of combustion fumes and soot.

• Fire needs to draft properly for safe operation.

Draft is the pressure difference needed to vent ﬁ replaces successfully. Considerations for successful draft include:

• Preventing negative pressure.

• Location of ﬁ replace and chimney.

Negative Pressure

Negative pressure results from the imbalance of air available for the ﬁ replace to operate properly. Causes for this imbalance include:

• Exhaust fans (kitchen, bath, etc.).

• Range hoods.

• Combustion air requirements for furnaces, water heaters and other combustion appliances.

• Clothes dryers.

• Location of return-air vents to furnace or air conditioning.

• Imbalances of the HVAC air handling system.

• Upper level air leaks (recessed lighting, attic hatch opening, duct leaks).

To minimize the effects of negative air pressure, the following must be considered:

• Install the outside air kit. Install the intake on the side of the house towards prevailing winds during the heating season.

• Ensure adequate outdoor air is supplied for combustion appliances and exhaust equipment.

• Ensure furnace and air conditioning return vents are not located in the immediate vicinity of the ﬁ replace.

• Avoid installing the ﬁ replace near doors, walkways or small isolated spaces.

• Recessed lighting should be a “sealed can” design; attic hatches weather stripped or sealed; attic mounted duct work and air handler joints and seams taped or sealed.

• Basement installations should be avoided due to stack effect. Stack effect creates negative pressure in lower levels. Hearth & Home Technologies recommends the use of direct vent ﬁ replaces in basements.

Location of the ﬁ replace and chimney will affect performance. As shown in Figure 2.1 the chimney should:

• Be installed through the warm airspace enclosed by the building envelope. This helps to produce more draft, especially during lighting and die-down of the ﬁ re.

• Penetrate the highest part of the roof. This minimizes the effects of wind turbulence.

• Be located away from trees, adjacent structures, uneven roof lines and other obstructions.

Offsets can restrict draft so their use should be minimized. Consider the ﬁ replace location relative to ﬂ oor and ceiling and attic joists.

Location

Not

Recommended

Windward

Outside Air Intake

Figure 2.1 Recommended Chimney Locations

Marginal Location

Recommended

Location

Multi-level Roofs

Recommended

Location

Not

Recommended

Leeward

6 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

C. Tools and Supplies Needed

Before beginning the installation be sure that the following tools and building supplies are available.

Reciprocating saw Framing material Pliers Hi temp caulking material Hammer Gloves Phillips screwdriver Framing square Flat blade screwdriver Electric drill and bits (1/4 in.) Plumb line Safety glasses Level Manometer Voltmeter Tape measure Non-corrosive leak check solution 1/2 - 3/4 in. length, #6 or #8 Self-drilling screws One 1/4 in. female connection (for optional fan).

D. Inspect the Appliance and Components

WARNING

Inspect appliance and components for damage. Damaged parts may impair safe operation.

• Do NOT install damaged components.

• Do NOT install incomplete components.

• Do NOT install substitute components.

Report damaged parts to dealer.

The following B-vent components are needed for installation. See Figure 2.2.

• Appliance

• Pipe components

• Firestops

• Attic Insulation Shield

• Elbows

• Strapping

• Roof ﬂ ashing or chase top

• Termination cap

• Storm Collar

• Carefully remove the appliance and components from the packaging.

• The vent system components and trim doors are shipped in separate packages.

• The gas logs may be packaged separately and must be ﬁ eld installed.

• Report to your dealer any parts damaged in shipment, particularly the condition of the glass.

• Read all of the instructions before starting the installation. Follow these instructions carefully during the installation to ensure maximum safety and beneﬁ t.

Vertical

Termination

Cap

Storm Collar

Roof

Flashing

Ceiling

Firestop

B-Vent Pipe

Sections

Figure 2.2 Typical Vertical Installation

WARNING

Hearth & Home Technologies disclaims any responsibility for, and the warranty will be voided by, the following actions:

• Installation and use of any damaged appliance or vent system component.

• Modiﬁ cation of the appliance or vent system.

• Installation other than as instructed by Hearth & Home Technologies.

• Improper positioning of the gas logs or the glass door.

• Installation and/or use of any component part not approved by Hearth & Home Technologies.

Any such action may cause a ﬁ re hazard.

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 7

Framing and Clearances

Note:

• Illustrations reﬂ ect typical installations and are FOR DESIGN PURPOSES ONLY.

• Illustrations/diagrams are not drawn to scale.

• Actual installation may vary due to individual design preference.

A. Select Appliance Location

When selecting a location for your appliance it is important to consider the required clearances to walls (See Figure 3.1).

WARNING

Fire Risk

Provide adequate clearance:

• Around air openings.

• For service access.

Locate appliance away from trafﬁ c areas.

Note: For actual appliance dimensions refer to Section 16.

1/2 in. (13 mm) min.

appliance

to combustibles

Drywall

In addition to these framing dimensions, also reference the following sections:

• Clearances and Mantel Projections (Sections 3.C. and 3.D.)

• Vent Clearances and Framing (Section 6)

Alcove

Installation

48 in.

(1219 mm)

max.

Model A B C D

NB3630M/MI

NB3933M/MI

NB4236M/MI

NB4842M/MI

Figure 3.1 Appliance Locations

8 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

inches 36 33-1/2 19-5/8 37

mm 914 851 498 940

inches 39 35-1/2 19-5/8 40

mm 991 902 498 1016

inches 42 37-5/8 19-5/8 43

mm 1067 956 498 1092

inches 48 41-7/8 19-5/8 49

mm 1219 1064 498 1245

B. Construct the Appliance Chase

A chase is a vertical boxlike structure built to enclose the gas appliance and/or its vent system. Vertical vents that run on the outside of a building may be, but are not required to be, installed inside a chase.

Construction of the chase may vary with the type of building. These instructions are not substitutes for the requirements of local building codes. Local building codes MUST be checked.

Chases should be constructed in the manner of all outside walls of the home to prevent cold air drafting problems. The chase should not break the outside building envelope in any manner.

Walls, ceiling, base plate and cantilever ﬂ oor of the chase should be insulated. Vapor and air inﬁ ltration barriers should be installed in the chase as per regional codes for the rest of the home. Additionally, Hearth & Home Technologies recommends that the inside surfaces be sheet rocked and taped (or the use of an equivalent method) for maximum air tightness.

To further prevent drafts gas line holes and other openings should be caulked with high temp caulk or stuffed with unfaced insulation. If the appliance is being installed on a cement slab, we recommend that a layer of plywood be placed underneath to prevent conducting cold up into the room.

WARNING

Fire Risk

• Construct chase to all clearance speciﬁ cations in manual.

• Locate and install appliance to all clearance speciﬁ cations in manual.

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 9

C. Clearances

Note: If the inside of the framed cavity is to be

ﬁ nished, the framing dimensions must include the ﬁ nished sur face. If drywall is to be attached to the

rear wall, the depth must be measured from the drywall surface.

1/2 in.

(13 mm)

Combustible flooring may be installed next to the front of the appliance.

1/2 in.

(13 mm)

Drywall

0 in.

WARNING

Fire Risk Odor Risk

• Install appliance on hard metal or wood surfaces extending full width and depth of appliance.

• Do NOT install appliance directly on carpeting, vinyl, tile or any combustible material other than wood.

• Do NOT place furniture or any other combustible household objects within 36 in. of the appliance front.

Per

Manufacturer’s

Specifications

32-1/2 in. (826 mm)

to ceiling

36 in.

(914 mm)

Combustible Object

0 in. TO LEVEL

OF STANDOFFS

0 in.

Rough Opening

Model

NB3630M/MI in. 36 34-7/8 19-5/8

mm 914 886 498

NB3933M/MI in. 39 34-7/8 19-5/8

mm 991 886 498

NB4236M/MI in. 42 34-7/8 19-5/8

mm 1067 886 498

NB4842M/MI in. 48 34-7/8 19-5/8

mm 1219 886 498

(Width)

Rough Opening

(Height)

Rough Opening

(Depth)

Figure 3.2 Clearances to Combustibles

10 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

D. Mantel Projections

32-1/2 in. minimum

to ceiling

11- 1/2

12-1/4

9-1/4

10-3/4

6-1/4

5-1/2

8-1/2

7-3/4

Measured from top of hood (in inches)

14-1/2

13-3/4

15-1/4

Figure 3.3 Clearances to Mantels or Other Combustibles Above Appliance

Top o f Appliance

Drywall

48 in.

(1219 mm)

max.

Mantel Leg or

Perpendicular Wall

1 in. (25 mm) min.

to perpendicular wall 3-1/2 in. (89 mm) min.

from fireplace opening to perpendicular wall

Figure 3.4 Clearances to Combustible Mantel Legs or Wall Projec-

tions (acceptable on both sides of opening)

WARNING

Fire Risk

• Comply with all minimum clearances to combustibles as speciﬁ ed.

• Framing or ﬁ nishing material used on the front of, or in front of, the appliance closer than the minimums listed, must be constructed entirely of noncombustible materials (i.e., steel studs, concrete board, etc.).

Failure to comply may cause ﬁ re.

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 11

Termination Locations

A. Vent Termination Minimum Clearances

WARNING

Fire Risk Explosion Risk

Maintain vent clearance to combustibles as speciﬁ ed.

• Do not pack air space with insulation or other materials.

Failure to keep insulation or other materials away from vent pipe may cause ﬁ re.

8 ft

Termination

Cap

(2.44 m)

Lowest

Discharge

Opening

Vertical wall

B-Vent Gas, Wood or Fuel

Oil Termination

8 ft

18 in.

(457 mm)

Gas

Termination

Termination Caps Staggered Height

A Gas Termination Wood or Fuel Oil Termination B 6 in.

(152 mm) min. 20 in. (508 mm) min.

B-Vent Gas, Wood or Fuel

Oil Termination

(2.44 m)

(minimum) to

Perpendicular

Wall

(gas only)

Storm Collar

Roof

Flashing

H (min.) - Minimum height from roof to lowest discharge opening.

Roof Pitch H (Min.) Ft. Roof Pitch H (Min.) Ft.

Flat to 6/12 1.0* Over 11/12 to 12/12 4.0 Over 6/12 to 7/12 1.25* Over 12/12 to 14/12 5.0 Over 7/12 to 8/12 1.5* Over 14/12 to 16/12 6.0 Over 8/12 to 9/12 2.0* Over 16/12 to 18/12 7.0 Over 9/12 to 10/12 2.5 Over 18/12 to 20/12 7.5 Over 10/12 to 11/12 3.25 Over 20/12 to 21/12 8.0

* 3 ft. minimum in snow regions

Roof Pitch is X / 12

8 ft

(2.44 m)

(minimum) to

Wood or

Gas Termination

Termination Caps Same Height

* If using decorative cap cover(s), this distance may need to be increased. Refer to the installation instruc tions supplied with the decorative cap cover.

Figure 4.2 Multiple Vertical Termination

20 in. min. *

(508 mm)

Perpendicular

Wall

(gas only)

Figure 4.1

Minimum Height from Roof to Lowest Discharge Opening

Figure 4.1 speciﬁ es minimum vent heights for various pitched roofs.

12 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Vent Information and Diagrams

A. Vent Guidelines

WARNING

Fire Risk Asphyxiation Risk

This appliance requires the speciﬁ ed pipe

for operation.

• Incorrect pipe may cause spillage,

condensation and overheating.

These models require the following size B-Vent double wall vent pipe.

Model Pipe Size

NB3630M/NB3630MI/NB3933M/NB3933MI 5 in. (127 mm)

NB4236M/NB4236MI/NB4842M/NB4842MI 5 in. (127 mm)

• Follow pipe manufacturer’s installation guidelines when installing the appliance.

B. Vent System Conﬁ guration

• Rise to Run Ratio: 2:1

• Maximum Total Horizontal Run: 30 ft (9.14 m)

• Minimum Total Vertical Rise: 12 ft (3.66 m)

• Maximum Total Vertical Rise: 60 ft (18.29 m)

• Maximum Number of Elbows: Four 90° or Eight 45°

Minimum

clearances are

per vent

manufacturer's

specifications

Metal

12 ft (3.66 m) min.

60 ft (18.29 m) max.

plumber's strap

secured to

framing

Vent supports are per

vent manufacturer's

specifications

WARNING

Fire Risk Explosion Risk Asphyxiation Risk

Do NOT connect this gas appliance to a chimney ﬂ ue serving a separate solid-fuel or gas burning appliance.

• Vent this appliance directly outside.

• Use separate vent system for this appliance.

May impair safe operation of this appliance or other appliances connected to the ﬂ ue.

CAUTION

ALL vent configuration specifications MUST be followed.

• This product is tested and listed to appliance and vent manufacturer’s speciﬁ cations.

• Appliance performance will suffer if speciﬁ cations are not followed.

Figure 5.1 Vertical Termination Clearances

Vent supports

are per vent

manufacturer’s

specifications.

Maximum horizontal run is 50% of vertical. Horizontal run cannot be

more than 30 ft. (9.14 m).

Figure 5.2 Maximum Horizontal Run

Metal

Plumbers'

Strap

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 13

WARNING

Fire Risk Explosion Risk

Insulation and other combustibles must not infringe on clearances.

• ALWAYS maintain speciﬁ ed clearances around venting and ﬁ restop systems.

• Install ﬁ restops as speciﬁ ed.

Failure to keep insulation or other material away from vent pipe may cause ﬁ re.

Maximum horizontal

30 ft (9.14 m)

45°

Elbow

90°

Elbow

Figure 5.3 Maximum Horizontal Run

Offsets exceeding

45° adapt horizontal

Note: Maximum horizontal distance is 50% of vertical vent height.

limitations

14 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Vent Clearances and Framing

A. Pipe Clearances to Combustibles

WARNING

Fire Risk Explosion Risk

Maintain vent clearance to combustibles as speciﬁ ed.

• Do not pack air space with insulation or other materials.

• National building codes recommend using attic shield to keep loose materials/ insulation from contacting vent.

Failure to keep insulation or other materials away from vent pipe may cause ﬁ re.

Follow vent pipe manufacturer’s instructions for all clearances around pipe.

B. Wall Penetration Framing

Do not pack with insulation or other materials.

Use manufacturer's installation instructions for framing dimensions

Figure 6.1 Exterior Wall Hole

For a wall penetration consult B-vent pipe manufacturer’s instructions. Use same dimensional framing materials as those used in the wall construction.

Note: MUST terminate vertically.

C. Vertical Penetration Framing

Use B-vent manufacturer’s ﬁ restops to provide adequate clearances.

WARNING

Fire Risk

Keep loose materials or blown insulation

from touching the vent pipe.

• National building codes recommend using attic shield to keep loose materials/ insulation from contacting vent.

• Hearth & Home Technologies requires the use of an attic shield.

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 15

Appliance Preparation

CAUTION

Sharp Edges

• Wear protective gloves and safety glasses during installation.

A. Installing Outside Air Kit Damper Assembly

WARNING

Fire Risk Asphyxiation Risk

Maintain vent clearance to combustibles as speciﬁ ed.

• Do not pack air space with insulation or other materials.

• National building codes recommend using attic shield to keep loose materials/ insulation from contacting vent.

Failure to keep insulation or other materials away from vent pipe may cause ﬁ re.

CAUTION

Risk of Smoke Spillage

Outside air inlet must be located to prevent blockage from:

• Leaves

• Snow/ice

• Other debris Blockage may cause combustion air starvation.

This appliance will operate correctly only if adequate ventiation is provided to allow proper draft to the system.

An outside air kit is available as an optional feature with this appliance. An outside air kit helps to decrease the amount of room air taken by utilizing outside air for combustion. We strongly recommend that it be installed.

Note: the outside air kit inlet thimble should be positioned in a manner that will not allow snow, leaves, etc. to block the inlet. A 3 ft. (.91 m) minimum height difference must be maintained from the top of the uppemost chimney section to the outside combustion air inlet. Reference Section 2.

• The outside air kit can only be installed on the left side of the appliance.

• Refer to the installation instructions provided with the kit.

WARNING

Fire Risk Asphyxiation Risk

Do not draw outside combustion air from:

• Wall, ﬂ oor or ceiling cavity.

• Enclosed space such as an attic or garage.

• Close proximity to exhaust vents or chimneys.

Fumes or odor may result.

Figure 7.1 Outside Air Kit Installation

Outlet blocked by

snow, leaves, etc.

YES

Clear area

outside

house or in

ventilated

crawl space

Figure 7.2 Outside Combustion Air Placement

Garage or

combustible

liquids storage

Factory-built

Use only duct materials specified by manufacturer (preferably with short run or mainly straight duct, except small dip for cold air trap which will help prevent flow of cold air).

Attic space

fireplace

Outlet placed

higher than 3 ft

below the

termination cap

16 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

B. Gas and Electrical Connections

Ensure that gas and electrical connections are installed at this time. Refer to Sections 9 and 10.

C. Securing and Leveling Appliance

WARNING

Fire Risk!

• Prevent contact with sagging, loose insulation.

• Do NOT install against combustible materials such as exposed insulation, plastic and insulation backer.

The diagram shows how to properly position, level, and secure the appliance (see Figure 7.3). Nailing tabs are provided to secure the appliance to the framing members.

• Place the appliance into position.

• Level the appliance from side to side and front to back.

• Shim the appliance as necessary. It is acceptable to use wood shims.

• Bend out nailing tabs on each side.

• Keep nailing tabs ﬂ ush with the framing.

• Secure the appliance to the framing by using nails or screws through the nailing tabs.

Nailing Flanges

(both sides)

Figure 7.3 Proper Positioning, Leveling and Securing of an

Appliance

Note: Once appliance is set up for top or rear venting, it

CANNOT be changed at a later time.

CAUTION

Do NOT notch into the framing around the appliance spacers.

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 17

Installing Vent Pipe

A. Assemble Vent Sections

This B-Vent appliance requires 5 in. B-vent double-wall pipe. Follow the pipe manufacturer’s installation guidelines when installing the appliance. This will ensure proper operation and prevent safety hazards.

WARNING

Fire Risk Exhaust Fumes Risk Impaired Performance of Appliance.

• Assemble pipe sections per B-Vent manufacturer’s instructions.

• Use support tabs for screws.

• Screws must not exceed 1 in. long and must not penetrate inner lining.

• Pipe may separate if not properly joined.

B. Attach Vent to Firebox Assembly

Three tabs extend from appliance collar shield. Attach tabs to ﬁ rst section of B-vent pipe using self-tapping 1/4 in. screws supplied with appliance. See Figure 8.1.

C. Securing Vent Sections

Secure vent sections with vent supports following B-vent manufacturer’s instructions.

WARNING

Fire Risk Explosion Risk Asphyxiation Risk

Use vent run supports per vent manufacturer’s installation instructions. Connect vent sections per vent manufacturer’s

installation instructions.

• Maintain all clearances to combustibles.

• Maintain speciﬁ ed slope (if required). Improper support may allow vent to sag or

separate.

Figure 8.1 Attaching Vent to Firebox

Ta bs

18 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Gas Information

A. Fuel Conversion

Before making gas connections ensure appliance being installed is compatible with the available gas type.

Any natural or propane gas conversions necessary to meet the appliance and locality needs must be made by a qualiﬁ ed technician using Hearth & Home Technologies speciﬁ ed and approved parts.

B. Gas Pressure

Proper input pressures are required for optimum appliance performance. Gas line sizing requirements need to be made following NFPA51.

WARNING

Fire Risk Explosion Risk

High pressure will damage valve.

• Disconnect gas supply piping BEFORE pressure testing gas line at test pressures above 1/2 psig.

• Close the manual shutoff valve BEFORE pressure testing gas line at test pressures equal to or less than 1/2 psig.

C. Gas Connection

Note: Have the gas supply line installed in accordance with local building codes, if any. If not, follow ANSI

223.1. Installation should be done by a qualiﬁ ed installer

approved and/or licensed as required by the locality. (In the Commonwealth of Massachusetts installation must be performed by a licensed plumber or gas ﬁ tter.)

Note: A listed (and Commonwealth of Massachusetts approved) 1/2 in. (13 mm) T-handle manual shut-off valve and ﬂ exible gas connector are connected to the 1/2 in. (13 mm) control valve inlet.

• If substituting for these components, please consult local codes for compliance.

Refer to Reference Section 16 for location of gas line access in appliance.

Note: Gas line may be run from either side of appliance using one of the knockouts provided. Hole in outer shell NOT to exceed 2-1/2 in. and should never penetrate the ﬁ rebox.

WARNING

Fire Risk Explosion Risk

Verify inlet pressures.

• High pressure may cause overfire condition.

• Low pressure may cause explosion.

• Verify minimum pressures when other household gas appliances are operating.

Install regulator upstream of valve if line pressure is greater than 1/2 psig.

Pressure requirements for appliance are shown in table below. Minimum pressures must be met when other household gas appliances are operating.

Pressure Natural Gas Propane

Minimum Inlet Pressure 5.0 in. w.c. 11.0 in. w.c.

Maximum Inlet Pressure 7.0 in. w.c. 14.0 in. w.c.

Manifold Pressure 3.5 in. w.c. 10.0 in. w.c.

WARNING

Gas Leak Risk

• Support control when attaching pipe to prevent bending gas line.

Note: The gap between supply piping and gas access hole may be caulked with high temperature caulk or stuffed with non-combustible, unfaced insulation to prevent cold air inﬁ ltration.

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 19

• Ensure that gas line does not come in contact with outer wrap of appliance. Follow local codes.

• Incoming gas line should be piped into the valve compartment and connected to the 1/2 in. connection on the manual shutoff valve.

WARNING

Fire Risk Explosion Risk

• Gas build-up during line purge may ignite.

• Purge should be performed by qualiﬁ ed technician.

• Ensure adequate ventilation.

• Ensure there are no ignition sources such as sparks or open ﬂ ames.

• A small amount of air will be in the gas supply lines. When ﬁ rst lighting appliance it will take a short time for air to purge from lines. When purging is complete the appliance will light and operate normally.

D. High Altitude Installations

U.L. listed gas appliances are tested and approved without requiring changes for elevations from 0 to 2000 ft in the USA and Canada.

If installing this appliance at an elevation above 4500 ft (in Canada), check with local authorities.

WARNING

CHECK FOR GAS LEAKS

Fire Risk Explosion Risk Asphyxiation Risk

• Check all ﬁ ttings and connections.

• Do not use open ﬂ ame.

• After the gas line installation is complete, all connections must be tightened and checked for leaks with a commercially available, non-corrosive leak check solution. Be sure to rinse off all leak check solution following testing.

Fittings and connections may have loosened during shipping and handling.

WARNING

Fire Risk Explosion Risk

Do NOT change the valve settings.

• This valve has been preset at the factory.

• Changing valve settings may result in ﬁ re hazard or bodily injury.

20 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Electrical Information

A. Recommendation for Wire

This appliance requires 110-120 VAC to be wired to the junction box either for use of optional accessories (standing pilot ignition) or for proper operation of the appliance (Intelliﬁ re ignition).

Open the control access panel to view wiring system and gas valve. If this appliance has a red or black ignitor button this appliance has a standing pilot ignition system. If there is no red or black ignitor button, this appliance has an Intelliﬁ re ignition system.

Note: This appliance must be electrically wired and grounded in accordance with local codes or, in the absence of local codes, with National Electric Code ANSI/NFPA

70-latest edition or the Canadian Electric Code CSA C22.1.

B. Connecting to the Appliance

WARNING

Shock Risk Explosion Risk

Do NOT wire 110V to valve. Do NOT wire 110V to wall switch

• Incorrect wiring will damage millivolt values.

• Incorrect wiring will override IPI safety lockout and may cause explosion.

• This appliance may be used with a wall switch, wall mounted thermostat and/or a remote control.

• If using thermostat use one compatible with a millivolt gas valve system.

• Follow parameters for locating thermostat (see individual thermostat instructions) to ensure proper operation of appliance.

• Use low resistance thermostat wire for wiring from ignition system to the wall switch and thermostat.

• Keep wire lengths short as possible by removing any excess wire length.

• Low voltage and 110 VAC voltage cannot be shared within the same wall box.

C. Intelliﬁ re Ignition System Wiring

This appliance requires a 110 VAC supply to the appliance junction box for operation. (See Figure 10.1 for a wiring diagram and Figure 10.3 for junction box wiring.)

This appliance is equipped with an Intelliﬁ re control valve which operates on a 3 volt system.

This appliance is supplied with a battery pack and a 3 volt AC transformer, which requires the installation of the supplied junction box. It is highly recommended that the junction box be installed at this time to avoid reconstruction.

The battery pack requires two D cell batteries (not included). Batteries cannot be placed in the battery pack while using the 3 volt AC transformer. Conversely, the transformer must be unplugged if the battery pack is used.

CAUTION

Battery polarity must be correct or module damage will

occur.

Optional Accessories Requirements

Wiring for optional accessories should be done now to avoid reconstruction.

CAUTION

Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing.

CAUTION

Shock Risk

• Replace damaged wire with type 105° C rated wire.

• Wire must have high temperature insulation.

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 21

Optional SPST

Wall Switch

Optional Remote

GRN*

BLU

WHT

GRN wire only used with optional wall switch WSK-MLT-HTL

Limit

Switch

BLK

RED

Battery

Pack

Adaptor

BLK

RED

Junction

Box

BRN

Valve

Control

Box

BLK

ORG

GRN

Ignitor

ORG

Flame

Sensor

Pilot Assembly

WHT

Figure 10.1 Intelliﬁ re Pilot Ignition (IPI) Wiring Diagram

D. Standing Pilot Ignition System Wiring

• This standing pilot ignition system wiring does not require a 110 VAC supply to operate.

HIGH LIMIT SWITCH

Flame Sensor

BLU

Push Button Ignitor

BLK

Ignitor

Copper Tubing

ORG

Gas Inlet

Pilot

GAS

VALV E

• It is recommended that a 110 VAC junction box be installed for use with a fan or remote control. (See Figure 10.2 for a wiring diagram and Figure 10.3 for junction box wiring.)

Thermopile

Wall Switch (or

thermostat if

heater-listed)

WHT

GRN wire only used with optional wall switch WSK-MLT-HTL

WHT

Pilot Tube

TAN

WHT

RED

BLU

To Burner

Inlet Tap

BLK

Figure 10.2 Standing Pilot Ignition Wiring Diagram

22 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Outlet Tap

E. Junction Box Installation

If the box is being wired from the OUTSIDE of the appliance:

• Remove the cover plate located on the outer shell - right side (see Figure 10.3).

• Install the supplied Romex™ connector in the cover plate.

• Feed the necessary length of wire through the connector.

• Make all necessary wire connections and reattach the cover plate to the outer shell.

If the box is being wired from the INSIDE of the appliance:

• Remove the screw attaching the junction box/receptacle to the outer shell, rotate the junction box inward to disengage it from the outer shell (see Figure 10.3).

• Pull the electrical wires from outside the appliance through this opening into the valve compartment.

• Feed the necessary length of wire through the connector.

• Make all necessary wire connections to the junction box/ receptacle and reassemble the junction box/receptacle to the outer shell.

WHT

BLK

WHT

BLK

Figure 10.3 Junction Box Detail

GRN wire inside box

Romex Connector

14/2WG

Cover Plate outside firebox

Copper ground attached to GRN screw with GRN wire

Note: Do NOT wire 110 VAC to wall switch.

F. Wall Switch Installation for Fan (Optional)

If the box is being wired to a wall mounted switch for use with a fan (See Figure 10.4):

• The power supply for the appliance must be brought into a switch box.

• The power can then be supplied from the switch box to the appliance using a minimum of 14-3 with ground wire.

• At the switch box connect the black (hot) wire and red (switch leg) wire to the wall switch as shown.

• At the appliance connect the black (hot), white (neutral) and green (ground) wires to the junction box as shown.

• Add a 1/4 in. insulated female connector to the red (switch leg) wire, route it through the knockout in the face of the junction box, and connect to the top fan switch connector (1/4 in. male) as shown.

Minimum 14-3 AWG with Ground

Junction Box

Red

Figure 10.4 Fan Control Switch Wiring

Red

Black

Green

White

Red

Black

White

Green

Knockout

Switch Box

Black

White

Green

Switch

Power

Supply

Wires

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 23

Finishing

A. Mantel Projections

Figure 11.1 shows the minimum vertical and corresponding maximum horizontal dimensions of appliance mantels or other combustible projections above the top front edge of the appliance.

32-1/2 in. minimum

to ceiling

14-1/2

15-1/4

12-1/4

13-3/4

5-1/2

6-1/4

9-1/4

8-1/2

7-3/4

Measured from top of hood (in inches)

11- 1/2

10-3/4

B. Facing Material

WARNING

Fire Risk

Do NOT obstruct air inlet or outlet grilles. Do NOT modify grilles.

• Modifying or covering grilles could cause temperature rise and ﬁ re hazard.

Finishing materials must not interfere with:

• Air ﬂ ow through grilles or louvers.

• Operation of louvers or doors.

• Access for service.

Finish wall material may be combustible - Top and Sides

0 in.

Figure 11.1 Clearances to Mantels or other Combustibles above

Appliance.

Top o f Appliance

Drywall

48 in.

(1219 mm)

max.

Mantel Leg or

Perpendicular Wall

1 in. (25 mm) min.

to perpendicular wall 3-1/2 in. (89 mm) min.

from fireplace opening to perpendicular wall

0 in.

High Temperature Sealant (300° F/149° C min.)

Top and Side Seal Joint

Figure 11.3 Noncombustible Facing Diagram

0 in.

WARNING

Fire Risk

Finish all edges and fronts to clearances and speciﬁ cations listed in manual.

• Metal appliance front may be covered with noncombustible material only.

• Do NOT overlap combustible materials onto appliance front.

• Install combustible materials only up to speciﬁ ed clearances on top, front and sides.

• Seal joints between the ﬁ nished wall and appliance top and sides using only a 300° F minimum sealant.

Figure 11.2 Mantel Leg or Wall Projections (Acceptable on both sides of opening)

24 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Appliance Setup

A. Remove the Shipping Materials

Remove shipping materials from inside or underneath the ﬁ rebox.

B. Remove the Clean Face Components

Carefully remove skin pack from face of unit. Set aside.

C. Remove Glass Assembly

• Pull the four (30/33/36 in. appliances) or seven (42 in. appliance) glass assembly latches out of the groove on the glass frame. See Figure 12.1.

• Remove the glass panel from the appliance.

• Lay aside out of the way on a non-abrasive surface.

Latches

(both bottom

and top)

Glass

Assembly

Figure 12.1 Glass Assembly

D. Accessories

Install approved accessories per instructions included with accessories. Refer to Section 16 for available optional accessories.

E. Clean the Appliance

Clean/vacuum any sawdust that may have accumulated inside the ﬁ rebox or underneath in the control cavity.

WARNING

Explosion Risk

• Follow rockwool placement instructions in this manual.

• Do NOT place rockwool directly over burner ports.

• Replace rockwool material annually.

Improperly placed rockwool interferes with proper burner operation.

F. Lava Rock, Vermiculite, Rockwool Placement

See Figure 12.2 for placement location.

Placing the Rockwool

Rockwool is shipped with this gas appliance. To place the rockwool:

• Place a small amount of 1/2 in. diameter pieces (dime-size) of rockwool on the burner pan so that the rockwool touches but does not cover the holes in the burner pan. This will provide the “glowing embers” look. It is not necessary to use the entire bag. Save the remaining rockwool for future use.

Placing the Lava Rock

• See Figure 12.2.

Placing the Vermiculite

• Sprinkle on top of lava rock.

WARNING

Shock Risk Fire Risk

Use ONLY optional accessories approved for this appliance.

• Using non-listed accessories voids warranty.

• Using non-listed accessories may result in a safety hazard.

• Only Hearth & Home Technologies approved accessories may be used safely.

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 25

Figure 12.2 Placement of Rockwool, Lava Rock and Vermiculite

Rockwool

Lava Rock & Vermiculite

WARNING

Handle glass with care.

• Inspect the gasket to ensure it is

undamaged.

• Inspect the glass for cracks, chips or

scratches.

• Do NOT strike, slam or scratch glass.

• Do NOT operate appliance with glass

assembly removed, cracked, broken or scratched.

• Replace glass assembly as a complete

assembly.

Install Hood

• Bend screen rod tabs down at a 90-deg. angle. See Figure

12.4.

G. Replace Glass Assembly

• Set the glass panel on the lower two or four glass assembly latches, ensuring the glass panel is centered in the opening.

• Pull out and latch all four or seven glass assembly latches into the groove on the glass frame.

H. Install Clean Face Components

Carefully remove components from skin pack. See Figure

12.3 for identiﬁ cation of components.

Bottom Latch Cover

Top Latch Cover

Hood

Figure 12.4 Screen Rod Tab

• Install above the glass panel.

• Hood must be attached or a ﬁ re hazard may result.

• Locate the four screws just inside the upper section of the appliance.

• Position hood and slide notches over screw heads.

• Tighten the four screws.

• See Figure 12.5.

Figure 12.5 Installing the Hood

Install Top Latch Cover

Firescreen

(Lower Floor Cover-not shown-

shipped underneath)

Figure 12.3 Clean Face Components/Skin Pack

26 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Firescreen Rod

• Insert top latch cover tabs into slots. See Figure 12.6.

• Rotate top latch cover down till the tabs lock in place.

Figure 12.6 Installing Top Latch Cover

Slot

Top Latch

Cover Tab

Install Floor Cover

• Install ﬂ oor cover with brake ﬂ ange up and towards back of unit. See Figure 12.7. Do not to place cover on top of any components. Move components back if necessary.

Figure 12.7 Installing Floor Cover

Install Bottom Latch Cover

• Insert bottom latch cover over existing shoulder screws. See Figure 12.8.

• Push down till the tabs lock in place.

Screen Rod

Hole in

Side Column

Screen Rod

Figure 12.9 Insert Rod Into Side Columns

• Flex the rod and insert it into the hole in the column on the other side.

• Hook the center of the rod into the screen rod tabs (shown in Figure 12.4).

• Spread ﬁ rescreen to the edges of the ﬁ rebox opening.

• Hairpin clips are shipped in place in a hole in the bottom of each column. After the screen is in place, squeeze clips and remove from holes. Thread clip through screen (one on each side), squeeze slip and re-insert into holes.

Figure 12.8 Installing Bottom Latch Cover

Install Firescreen Assembly

• Thread screen onto screen rod making sure to thread all screen rings.

• Hold the mesh ﬁ rescreen in one hand until you get the rod inserted into the side columns to prevent the mesh from falling off the rod.

• Insert one end of screen rod into the hole located in the column as far as it will go. See Figure 12.9

WARNING

HOT! DO NOT TOUCH. SEVERE BURNS MAY RESULT. CLOTHING IGNITION MAY RESULT.

Glass and other surfaces are hot during operation and cool down.

• Keep children away.

• CAREFULLY SUPERVISE children in same room as appliance.

• Alert children and adults to hazards of high temperatures.

• To avoid burns or clothing ignition, the mesh must remain closed if children will be present during the operation and cool down of the ﬁ replace.

• Mesh supplied from factory clipped shut for child safety.

• Do NOT operate with protective barriers removed or door open.

• Mesh may be made operable only upon request of a person responsible for the use and operation of the ﬁ replace.

• Keep clothing, furniture, draperies and other combustibles away.

Note: The ﬂ oor cover in the bottom front of the ﬁ replace may be covering the UL labels. It is loose and can be removed/replaced.

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 27

I. Air Shutter Setting

This appliance has an adjustable air shutter (which controls the primary air) factory set for the minimum vertical vent run (see Figure 12.10). If your installation has more than the minimum required vertical vent length, adjustment of the air shutter may be necessary to obtain optimal ﬂ ame appear- ance. This should be adjusted by a qualiﬁ ed installer at

the time of installation.

• If the vent configuration is installed incorrectly, the vent may cause the ﬂ ames inside the appliance to lift or “ghost,” which is a dangerous situation. Inspect the ﬂ ames after installation to ensure proper performance. If the vent conﬁ guration is correct, yet the ﬂ ames are lifting or ghosting, shut off the gas to the appliance and contact the dealer.

• Your air shutter is provided at 1/8 in. open for natural gas, 3/8 in. open for propane (30 in./33 in. appliances), and full open for 36 in. and 42 in. propane appliances. In the event soot is accumulating in your appliance, the air shutter should be opened farther. This can be done by opening the control access panel and locating the two wing studs and two wing nuts attaching the valve assembly to the ﬁ rebox. Remove the wing nuts and wing studs, slide the valve assembly to the left and lower. Rotate the valve assembly horizontally and remove from underneath the appliance. See Figure 12.11.

Figure 12.10 Air Shutter

Note: To avoid damage to the pilot assembly,

remove the valve assembly pilot side ﬁ rst. If the valve assembly gasket is damaged, it should be replaced.

• Locate the air shutter mounted on the end of the main burner. Loosen the locking screw, open the air shutter, and retighten the locking screw. See Figure 12.10.

• Replace the valve assembly, wing nuts and wing studs as removed, making sure to line the oriﬁ ce up with the main burner neck.

Figure 12.11 Valve Assembly

28 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Operating Instructions

A. Before Lighting Appliance

Before lighting this appliance, determine if it has a standing pilot or Intelliﬁ re ignition system by opening the control access panel to view wiring system and gas valve. If this appliance has a red or black ignitor button (See Figure 10.1) this appliance has a standing pilot ignition system. If there is no red or black ignitor button, this appliance has an Intelliﬁ re ignition system.

WARNING

CAUTION

If installing Intelliﬁ re Ignition battery backup:

• Do not install batteries if the backup mode may not be used for extended time.

• Batteries may leak.

• Install batteries only when needed for power outage.

Before operating this appliance, have a qualiﬁ ed technician:

• Remove all shipping materials from inside and/or underneath the ﬁ rebox.

• Review proper placement of logs, rockwool, lava rock and vermiculite.

• Check the wiring.

• Check the air shutter adjustment.

• Ensure that there are no gas leaks.

• Ensure that the glass is sealed and in the proper position.

• Ensure that the ﬂ ow of combustion and ventilation air is not obstructed (front grilles and vent caps).

WARNING

HOT SURFACES!

Glass and other surfaces are hot during operation and cool down.

Hot glass will cause burns.

• Do not touch glass until it is cooled

• NEVER allow children to touch glass

• Keep children away

• CAREFULLY SUPERVISE children in same room as appliance.

• Alert children and adults to hazards of high temperatures.

High temperatures may ignite clothing or other ﬂ ammable materials.

• Keep clothing, furniture, draperies and other combustibles away.

This appliance has been supplied with an integral barrier to prevent direct contact with the ﬁ xed glass panel. Do NOT operate the appliance with the barrier removed.

Contact your dealer or Hearth & Home Technologies if the barrier is not present or help is needed to properly install one.

WARNING

Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to the owner’s information manual provided with this

WARNING

Fire Risk Combustion Fumes Risk

Glass door MUST be in place when appliance is operating.

Do NOT operate appliance with glass door removed.

• Open viewing glass for servicing only.

• Glass door MUST be in place and sealed before operating appliance.

• Only use glass doors certiﬁ ed for use with the appliance.

• Glass replacement should be done by qualiﬁ ed technician.

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 29

appliance. For assistance or additional information consult a qualiﬁ ed installer, service agency or the gas supplier.

B. Check Appliance Draft

Check draft of appliance to verify proper venting conditions.

• Close all windows and doors, turn on all exhaust fans in home.

• Appliance is to be completely assembled to normal operating condition.

• Turn on appliance and allow to operate for at least 10 minutes.

• Check draft as shown in Figure 13.1. This can be done using a smoke or ﬂ ame producing match.

• Hold lit match at bottom edge of draft hood opening and observe ﬂ ame/smoke per the ﬁ gure.

Flame up-Acceptable

Flame in-Good

Flame out-Bad

Without

doors.

Flame up-Acceptable

Flame in-Good

Flame out-Bad

With doors

closed.

Figure 13.1 Checking Appliance Draft

30 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

C. Lighting the Appliance

Intelliﬁ re Ignition

FOR YOUR SAFETY READ BEFORE LIGHTING

WARNING: If you do not follow these instructions exactly, a fire

or explosion may result causing property damage, personal injury or loss of life.

A. This appliance is equipped with an ignition device which

automatically lights the pilot. Do not try to light the pilot by hand.

B. BEFORE LIGHTING smell all around the appliance area for

gas. Be sure to smell next to the floor because some gas is heavier than air and will settle on the floor.

WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electric switch; do not use any phone in your building.

• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.

LIGHTING INSTRUCTIONS

1. STOP! Read the safety information above on this label.

2. Turn wall switch to the "OFF" position or thermostat to the lowest setting.

3. Turn off all electric power to the appliance.

4. This appliance is equipped with an ignition device which automatically lights the pilot. Do NOT try to light the pilot by hand.

This appliance needs fresh air for safe operation and must be installed so there are provisions for adequate combustion and ventilation air.

This appliance must be installed in accordance with local codes, if any; if not, follow ANSI Z223.1 or, in Canada, current CAN/CGA-B149.

• If you cannot reach your gas supplier, call the fire department.

C. Use only your hand to push in and move the gas control

valve or turn the gas control knob. Never use tools. If the lever or knob will not move by hand, don't try to repair it, call a qualified service technician. Force or attempted repair may result in a fire or explosion.

D. Do not use this appliance if any part has been under water.

Immediately call a qualified service technician to inspect the appliance and to replace any part of the control system and any gas control which has been under water.

This appliance must be properly connected to a venting system in accordance with the manufacturer's installation instructions.

WARNING:

adjustment, alteration, service or maintenance can cause injury or property damage. Refer to the owner's information manual provided with the appliance. For assistance or additional information consult a qualified installer, service agency or the gas supplier.

CAUTION:

not touch. Keep children, clothing, furniture, gasoline and other liquids having flammable vapors

5. Wait five minutes to clear out any gas. If you then smell gas, STOP!

Follow "B" in the safety information above on this label. If you don't smell gas, go to the next step.

6. To turn on the burner, turn on all electric power to this appliance and

turn on the wall switch or set the thermostat to the desired setting.

7. If the appliance will not operate, follow the instructions "TO TURN OFF

GAS TO APPLIANCE" and call your service technician or gas supplier.

away.

WARNING RISK OF FIRE

This appliance is intended to burn a specified gas fuel only. Do not attempt to use with solid wood fuel or another type of fuel. Do not attempt to modify or use any other type of gas burner system.

Improper installation,

Hot while in operation. Do

TO TURN OFF GAS TO APPLIANCE

1. Turn off wall switch or set thermostat to lowest setting.

2. Turn off all electric power to the appliance if service is to be performed.

Due to high surface temperatures, keep children, clothing and furniture away. Keep burner and control compartment clean. See installation and operating instructions accompanying the appliance.

3. Push the gas control lever in and move to the "OFF" position or push the gas control lever to the "OFF" position. Do not force.

4. Replace the control access panel.

WARNING: Disconnect the electric power

before servicing. If for any reason the original wire supplied with the appliance must be replaced, it must be replaced with 105° C or its equivalent.

For use with natural gas or propane. A conversion kit as supplied by the manufacturer shall be used to convert this appliance to the alternative fuel.

* Also certified for installation in a bedroom or a

bed-sitting room.

* For U.S. only!

NATURAL GAS

33631D

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 31

Standing Pilot Ignition

Improper installation,

This appliance must be properly connected to a

venting system in accordance with the

This appliance must be installed in accordance with

local codes, if any; if not, follow ANSI Z223.1 or, in

This appliance needs fresh air for safe operation

and must be installed so there are provisions for

adequate combustion and ventilation air.

Canada, current CAN/CGA-B149.

manufacturer's installation instructions.

adjustment, alteration, service or maintenance can

cause injury or property damage. Refer to the owner's

information manual provided with the appliance. For

assistance or additional information consult a

WARNING:

qualified installer, service agency or the gas supplier.

Hot while in operation. Do

CAUTION:

not touch. Keep children, clothing, furniture,

gasoline and other liquids having flammable vapors

WARNING RISK OF FIRE

away.

This appliance is intended to burn a specified gas

fuel only. Do not attempt to use with solid wood fuel

or another type of fuel. Do not attempt to modify or

Disconnect the electric power

use any other type of gas burner system.

WARNING:

For use with natural gas or propane. A conversion

before servicing. If for any reason the original wire

supplied with the appliance must be replaced, it must be

replaced with 105° C or its equivalent.

VENT

OFF

NATURAL GAS

bed-sitting room.

* Also certified for installation in a bedroom or a

PIL

OFF

PILOT

OFF

PILOT

* For U.S. only!

29097D

kit as supplied by the manufacturer shall be used to

convert this appliance to the alternative fuel.

the manual gas valve will not push in or turn by hand, don't try

to repair it; call a qualified service technician. Force or

attempted repair may result in a fire or explosion.

Immediately call a qualified service technician to inspect the

appliance and to replace any part of the control system and any

gas control which has been under water.

C. Use only your hand to push in or turn knob. Never use tools. If

• If you cannot reach your gas supplier, call the fire department.

explosion may result causing property damage, personal

injury or loss of life.

D. Do not use this appliance if any part has been under water.

Stop! Read the safety information above on this label.

3. CLOSED

LIGHTING INSTRUCTIONS

WARNING: If you do not follow these instructions exactly, a fire or

FOR YOUR SAFETY READ BEFORE LIGHTING

lighting the pilot, follow these instructions exactly.

Be sure to smell next to the floor because some gas is heavier

than air and will settle on the floor.

A. This appliance has a pilot which must be lighted by hand. When

B. BEFORE LIGHTING smell all around the appliance area for gas.

32 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

building.

Follow the gas supplier's instructions.

• Immediately call your gas supplier from a neighbor's phone.

• Do not try to light any appliance.

• Do not touch any electric switch; do not use any phone in your

WHAT TO DO IF YOU SMELL GAS

lowest setting.

clear out any gas. If you then smell gas, STOP! Follow "B" in the

safety information above on this label. If you don't smell gas, go

to next step.

depressed to pass "PILOT" position.)

1. Turn wall switch to the "OFF" position or thermostat to the

2. Remove control access panel.

3. Turn manual gas valve to CLOSED. Wait five [5] minutes to

4. Turn gas line to "OPEN".

5. Turn pilot knob clockwise to "OFF". (Knob may have to be

6. Locate pilot assembly inside appliance.

7. Locate red ignitor button.

8. Turn pilot knob to "PILOT" and push in.

9. Continue to hold in pilot knob and push the red ignitor button

12-15 times until small blue pilot flame appears.

should remain lit. If pilot goes out, wait 5 minutes and repeat

Steps 3-9.

10. Continue to hold in pilot knob for approximately one minute. Pilot

11. Release and turn knob counterclockwise to "ON".

4. OPEN

3. Turn manual gas valve to "CLOSED position. Do not force.

4. Replace control access panel.

TO TURN OFF GAS TO APPLIANCE

OFF GAS TO APPLIANCE" and call your service technician or

gas supplier.

hand.

1. Turn off wall switch or set thermostat to lowest setting.

2. Remove control access panel.

Due to high surface termperatures, keep children, clothing and furniture away.

12. If appliance will not operate, follow the instructions "TO TURN

NOTE: To light main burner, turn wall switch to "ON". Do not light by

Keep burner and control compartment clean. See installation and operating instructions accompanying the appliance.

D. After the Appliance is Lit

Initial Break-in Procedure

When you light the appliance, you may notice that it produces heat which does have an associated odor or smell. If you feel this odor is excessive it may require the initial three to four hour continuous burn on high followed by a second burn up to 12 hours to fully drive off any odor from paint and lubricants used in the manufacturing process. Condensation of the glass is normal

CAUTION

• Prevent accidental appliance operation when not attended.

• Unplug or remove batteries from remote control if absent or if appliance will not be used for an extended period of time.

• Property damage possible from elevated temperatures.

Note: This appliance should be run three to four hours on the initial start-up. Turn it off and let it cool completely. Remove and clean the glass. Replace the glass and run the appliance for an additional 12 hours. This will help cure the products used in the paint and logs.

During this break-in period it is recommended that some windows in the house be opened for air circulation. This will help avoid setting off smoke detectors, and help eliminate any odors associated with the appliance’s initial burning.

WARNING

Fire Risk High Temperatures

Keep combustible household items away from appliance.

Do NOT obstruct combustion and ventilation air.

• Do NOT place combustible items on top of or in front of appliance.

• Keep furniture, draperies away from appliance.

CAUTION

Smoke and odors are released during initial operation.

• Open windows for air circulation.

• Leave room during initial operation.

• Smoke may set off smoke detectors.

Smoke and odors may be irritating to sensitive individuals.

WARNING

Fire Risk

Keep combustible materials, gasoline and other ﬂ ammable vapors and liquids clear of appliance.

• Do NOT store ﬂ ammable materials in the vicinity of the appliance.

• Do NOT use gasoline, lantern fuel, kerosene, charcoal lighter ﬂ uid or similar liquids in this appliance.

Combustible materials may ignite.

E. Frequently Asked Questions

Issue Solutions

Condensation on the glass This is a result of gas combustion and temperature variations. As the appliance warms, this condensation will

Blue ﬂ ames This is a result of normal operation and the ﬂ ames will begin to yellow as the appliance is allowed to burn for 20 to

Odor from appliance When ﬁ rst operated, this appliance may release an odor for the ﬁ rst several hours. This is caused by the curing of

Film on the glass This is a normal result of the curing process of the paint and logs. Glass should be cleaned within 3 to 4 hours of

Metallic noise Noise is caused by metal expanding and contracting as it heats up and cools down, similar to the sound produced

Is it normal to see the pilot ﬂ ame burn continually?

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 33

disappear.

40 minutes.

the paint and the burning off of any oils remaining from manufacturing.

initial burning to remove deposits left by oils from the manufacturing process. A non-abrasive cleaner such as gas ﬁ replace glass cleaner may be necessary. See your dealer.

by a furnace or heating duct. This noise does not affect the operation or longevity of the ﬁ replace.

In an Intelliﬁ re ignition system it is normal to see the pilot ﬂ ame, but it should turn off when ON/OFF is turned off. In a standing pilot system the pilot will always stay on.

Troubleshooting

With proper installation, operation and maintenance your gas appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist a qualiﬁ ed service person in the diagnosis of a problem and the corrective action to be taken. This troubleshooting guide can only be used by a qualiﬁ ed service technician.

A. Standing Pilot Ignition System

Symptom Possible Causes Corrective Actions

1. After repeated triggering of the red or black piezo ignitor button, the spark ignitor will not light the pilot.

2. The pilot will not stay lit after carefully following the lighting instructions

3. The pilot is burning, there is no gas burning, the valve knob is in the ON position, and the ON/ OFF switch is in the ON position.

A. Defective ignitor. Check the spark at the electrode and pilot. If there is no spark and the

B. Defective pilot or

misaligned electrode (spark at electrode).

C. No gas or low gas

pressure.

D. No LP in tank. Check the LP (propane) tank. You may be out of fuel.

A. Defective thermocouple. Check that the pilot ﬂ ame impinges on the thermocouple. Clean and/or

B. Defective valve. If the thermocouple is producing more than 15 millivolts, replace faulty valve.

A. ON/OFF switch or wires

are defective.

B. Thermopile may not be

generating sufﬁ cient millivoltage.

C. Defective valve. Turn the valve knob to the ON position. Place the ON/OFF switch in the ON

D. Plugged burner oriﬁ ce. Check the burner oriﬁ ce for stoppage. Remove stoppage.

E. Wall switch or wires are

defective.

electrode wire is properly connected, replace the ignitor.

Using a match, light the pilot. If the pilot lights, turn off the pilot and trigger the red or black piezo ignitor button again. If the pilot lights, an improper gas/air mixture caused the bad lighting and a longer purge period is recommended. If the pilot will not light, ensure the gap at the electrode and pilot is 1/8 in. to have a strong spark. If the gap is OK, replace the pilot.

Check the remote shut-off valves from the appliance. There is usually a valve near the gas main. There can be more than one valve between the appliance and the main.

adjust the pilot for maximum ﬂ ame impingement.

Ensure that the thermocouple connection at the gas valve is fully inserted and tight (hand tighten plus 1/4 turn).

Disconnect the thermocouple from the valve, place one millivolt meter lead wire on the tip of the thermocouple and the other meter lead wire on the thermocouple copper lead. Start the pilot and hold the valve knob in. If the millivolt reading is less than 15mV, replace the thermocouple.

Check the ON/OFF switch and wires for proper connections. Place the jumper wires across the terminals at the switch. If the burner comes on, replace the defective switch. If the switch is OK, place the jumper wires across the switch wires at the gas valve. If the burner comes on, the wires are faulty or connections are bad.

If the pilot ﬂ ame is not close enough physically to the thermopile, adjust the pilot ﬂ ame.

Be sure the wire connections from the thermopile at the gas valve terminals are tight and that the thermopile is fully inserted into the pilot bracket.

Check the thermopile with a millivolt meter. Take the reading at TH-TP&TP terminals of the gas valve. The meter should read 325 millivolts minimum while holding the valve knob depressed in the pilot position, with the pilot lit, and the ON/OFF switch in the OFF position. Replace the faulty thermopile of the reading is below the speciﬁ ed minimum.

With the pilot in the ON position, disconnect the thermopile leads from the valve. Take a reading at the thermopile leads. The reading should be 325 millivolts minimum. Replace the thermopile if the reading is below the minimum.

position. Check the millivolt meter at the thermopile terminals. The millivolt meter should read greater than 125mV. If the reading is acceptable, and if the burner does not come on, replace the gas valve.

Follow the corrective action in Symptom and Possible Cause 1.A. above. Check the switch and wiring. Replace where defective.

34 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Symptom Possible Causes Corrective Actions

4. Frequent pilot outage problem.

5. The pilot and main burner extinguish while in operation.

6. Glass soots. A. Flame impingement. Adjust the log set so that the ﬂ ame does not excessively impinge on it.

7. Flame burns blue and lifts off burner.

A. Pilot ﬂ ame may be too

high, too low, or blowing (high), causing pilot safety to drop out.

A. No LP in the tank. Check the LP (propane) tank. Reﬁ ll the fuel tank.

B. Inner vent pipe is leaking

exhaust gases back into the system.

C. Glass is too loose and

air tight packet leaks in corners after usage.

D. Bad thermopile or

thermocouple.

E. Improper vent cap

installation.

B. Improper air shutter

setting.

C. Debris around air shutter. Inspect the opening at the base of the burner. NO MATERIAL SHOULD BE

A. Insufﬁ cient oxygen being

supplied.

Clean and adjust the pilot ﬂ ame for maximum ﬂ ame impingement on thermocouple. Follow lighting instructions carefully.

Check venting system for damage. Replace/repair improperly assembled pipe sections.

Replace glass panel assembly.

Replace if necessary.

Check for proper installation and freedom from debris or blockage.

Adjust the air shutter located on the control panel.

PLACED IN THIS OPENING.

Ensure that the vent cap is installed properly and free of debris.

Ensure that the vent system joints are tight and have no leaks.

Ensure that no debris has been placed at the base of, or in the area of the air holes in the center of, the base pan beneath the burner.

Ensure that the glass is tightened properly on the appliance, particularly on top corners.

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 35

B. Intelliﬁ re Ignition System

Symptom Possible Causes Corrective Actions

1. The ignitor/module makes noise, but no spark.

2. Pilots won’t light, there is no noise or spark.

3. Pilot lights but continues to spark, and main burner will not ignite. (If the pilot continues to spark after the pilot ﬂ ame has been lit, ﬂ ame rectiﬁ cation has not occurred.)

A. Incorrect wiring. Verify “S” wire (white) for sensor and “I” wire (orange) for ignitor are

B. Loose connections or

C. Ignitor gap is too large. Verify gap of ignitor to pilot hood. The gap should be approximately .17 in. or

D. Faulty module. Turn ON/OFF rocker switch or wall switch to OFF position. Remove ignitor

A. Transformer installed

B. A shorted or loose

C. Improper wall switch

D. Module not grounded. Verify black ground wire from module wire harness is grounded to metal

E. Faulty module. Turn ON/OFF rocker switch or wall switch to OFF position. Remove ignitor

A. A shorted or loose

B. Poor ﬂ ame rectiﬁ cation or

C. Module is not grounded. Verify that module is securely grounded to metal chassis of appliance. Verify

D. Damaged pilot assembly

E. Faulty module. Turn ON/OFF rocker switch or wall switch to OFF position. Remove ignitor

electrical shorts in the wiring.

incorrectly.

connection in wiring conﬁ guration or wiring harness.

wiring.

connection in sensor rod.

contaminated sensor rod.

or dirty sensor rod.

connected to the correct terminals on the module and the pilot assembly. Reversed wires at the module may cause the system to make a sparking noise, but the spark may not be present at pilot hood.

Verify there are no loose connections or electrical shorts in wiring from module to pilot assembly. The rod closest to the pilot hood should be ignitor. Verify connections underneath pilot assembly are tight; also verify the connections are not grounding out to the metal chassis, pilot burner, pilot enclosure, mesh screen if present, or any other metal object.

1/8 in.

wire “I” from module. Place ON/OFF rocker switch or wall switch in ON position. Hold ground wire about 3/16 in. away from “I” terminal on module. If there is no spark at “I” terminal, module must be replaced. If there is a spark at “I” terminal, module is ﬁ ne. Inspect pilot assembly for shorted sparker wire or cracked insulator around electrode.

Verify that transformer is installed and plugged into module. Check voltage of transformer under load at space connection on module with ON/OFF switch in ON position. Acceptable readings of a good transformer are between 3.2 and 2.8 volts AC.

Remove and reinstall the wiring harness that plugs into module. Verify there is a tight ﬁ t. Verify pilot assembly wiring to module. Remove and verify continuity of each wire in wiring harness.

Verify wall switch is wired correctly.

chassis of appliance.

wire “I” from module. Place ON/OFF rocker switch or wall switch in ON position. Hold ground wire about 3/16 in. away from “I” terminal on module. If there is no spark at “I” terminal module must be replaced. If there is a spark at “I” terminal, module is ﬁ ne. Inspect pilot assembly for shorted sparker wire or cracked insulator around electrode.

Verify all connections to wiring diagram in manual. Verify connections underneath pilot assembly are tight. Verify connections are not grounding out to metal chassis, pilot burner, pilot enclosure or screen if present, or any other metal object.

Verify ﬂ ame is engulﬁ ng sensor rod. If the pilot assembly does not have a ground strap, consider installing one to increase ﬂ ame rectiﬁ cation. Verify correct pilot oriﬁ ce is installed and inlet gas speciﬁ cations are met. Flame carries rectiﬁ cation current, not the gas. If ﬂ ame lifts from pilot hood, the circuit is broken. A wrong oriﬁ ce or too high an inlet pressure can cause pilot ﬂ ame to lift. The sensor rod may be contaminated. Clean sensor rod with emery cloth.

that the wire harness is ﬁ rmly connected to module.

Verify that ceramic insulator around the sensor rod is not cracked, damaged, or loose. Verify connection from sensor rod to white sensor wire. Clean sensor rod with emery cloth to remove any contaminants that may have accumulated on sensor rod. Verify continuity with a multimeter with ohms set at lowest range.

36 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Symptom Possible Causes Corrective Actions

4. Pilot sparks, but pilot will not light.

A. Correct gas supply. Verify that incoming gas line ball valve is “open”. Verify that inlet pressure

B. Ignitor gap is too large. Verify that spark gap from ignitor to pilot hood is .17 in. or 1/8 in.

C. Module is not grounded. Verify module is securely grounded to metal chassis of appliance.

D. Module voltage output/

valve/pilot solenoid ohms readings.

reading is within acceptable limits, inlet pressure must not exceed 14 in. w.c.

Replace module.

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 37

Although the frequency of appliance servicing and maintenance will depend on use and the type of installation, a qualiﬁ ed service technician should perform an appliance check-up at the beginning of each heating season.

Maintaining and Servicing the Appliance

WARNING

Risk of injury or property damage Before servicing:

• Turn off gas.

• Turn off electricity to appliance.

• Disable remote control, if one is present.

• Ensure appliance is completely cooled.

After Servicing:

• Replace any screen or barrier that was removed.

• Reseal and reinstall any venting removed for

servicing.

WARNING

Annual inspection by qualified technician recommended.

Check:

• Condition of doors, surrounds and fronts.

• Condition of glass, glass assembly and glass seal.

• Obstructions of combustion and ventilation air.

• Condition of logs.

• Condition of ﬁ rebox.

• Burner ignition and operation.

• Burner air shutter adjustment.

• Gas connections and ﬁ ttings.

• Obstructions of termination cap.

Clean:

• Glass.

• Air passageways, grilles, control compartment.

• Burner, burner ports.

Risk of:

• Fire

• Delayed ignition or explosion

• Exposure to combustion fumes

• Odors

CAUTION

Handle glass assembly with care. Note: Clean glass after initial 3-4 hours

operation. Longer operation without

cleaning glass may cause a permanent white ﬁ lm on glass.

When cleaning glass door:

• Avoid striking, scratching or slamming doors.

• Do NOT use abrasive cleaners.

• Use a hard water deposit glass cleaner on white ﬁ lm.

• Do NOT clean glass when it is hot.

• Turn off appliance after 3-4 hours of operation and ALLOW TO COOL.

• Remove and clean glass assembly.

• Replace glass assembly and operate appliance for an additional 12 hours.

Refer to maintenance instructions.

WARNING

Fire Risk Explosion Risk

Inspect external vent cap regularly.

• Ensure no debris blocks cap.

• Combustible materials blocking cap may ignite.

• Restricted air flow affects burner operation.

38 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Maintenance and Service Tasks:

Inspect Maintenance Tasks

Doors, surrounds and fronts 1. Assess condition of screen and replace as necessary. Recommend addition of screen if

Gasket seal, glass assembly and glass 1. Inspect gasket seal and its condition.

Valve compartment and ﬁ rebox top 1. Vacuum and wipe out dust, cobwebs, debris or pet hair. Use caution when cleaning these

Logs 1. Inspect for broken, damaged, or missing logs. Replace as necessary.

Firebox 1. Inspect for paint condition, warpage, corrosion or perforation. Sand and repaint as necessary.

Burner ignition and operation 1. Verify burner is properly secured and aligned with pilot or ignitor.

Venting 1. Inspect venting for blockage or obstruction such as birds’ nests, leaves, etc.

Remote controls 1. Verify operation of remote.

one is not present.

2. Inspect for scratches, dents or other damage and repair as necessary.

3. Verify no obstructions to airﬂ ow through the louvers.

4. Verify proper clearance to combustible household objects is maintained.

2. Inspect glass panels for scratches and nicks that can lead to breakage when exposed to heat.

3. Conﬁ rm there is no damage to glass or glass frame. Replace as necessary.

4. Verify that latches engage properly, clip studs are not stripped, and glass attachment components are intact and operating properly. Replace as necessary.

5. Clean glass using a nonabrasive cleaner such as Brasso®. Replace glass assembly if severely coated with silicate deposits that cannot be removed.

areas. Screw tips that have penetrated the sheet metal are sharp and should be avoided.

2. Remove any foreign objects.

3. Verify unobstructed air circulation.

2. Verify correct log placement and no ﬂ ame impingement causing sooting. Correct as necessary.

2. Replace appliance if ﬁ rebox has been perforated.

2. Clean off burner top, inspect for plugged ports, corrosion or deterioration. Replace burner if necessary.

3. Replace rockwool with new dime-sized and shaped pieces. Do not block ports or obstruct lighting paths.

4. Check for smooth lighting and ignition carryover to all ports. Verify there is no ignition delay.

5. Inspect for lifting or other ﬂ ame problems.

6. Verify air shutter is clear of dust and debris.

7. Inspect oriﬁ ce for soot, dirt or corrosion.

8. Verify manifold and inlet pressures. Adjust regulator as required.

9. Inspect pilot ﬂ ame strength. Clean or replace oriﬁ ce as necessary.

10. Inspect thermocouple/thermopile or IPI sensor rod for soot, corrosion and deterioration. Clean with emery cloth or replace as required.

11. Verify millivolt output. Replace as necessary.

2. Conﬁ rm that termination cap remains clear and unobstructed by plants, etc.

3. Verify that termination cap clearance to subsequent construction (building additions, decks, fences or sheds) has been maintained.

4. Inspect for corrosion or separation.

5. Verify weather stripping, sealing and ﬂ ashing remain intact.

6. Inspect draft shield to verify it is not bent, damaged or missing.

2. Replace batteries in remote transmitters and battery-powered receivers.

3. Verify batteries have been removed from battery back-up in IPI systems to prevent premature battery failure or leaking.

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 39

Reference Materials

A. Appliance Dimension Diagram

Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 3.

19-1/8 in.

(486 mm)

Gas Line

Access

(165 mm)

6-1/2 in.

3 in

(76 mm).

1-1/2 in. (38 mm)

Model A B C

NB3630M/MI inches 35 30 8-5/8

mm 889 762 219

NB3933M/MI inches 38 33 11-5/8

mm 965 838 295

NB4236M/MI inches 41 36 14-5/8

mm 1041 914 371

NB4842M/MI inches 47 42 20-5/8

mm 1194 1067 524

11-5/8 in.

(295 mm)

(864 mm)

34 in.

31-1/2 in.

(800 mm)

2-3/8 in.

(60 mm)

8 in.

(203 mm)

Gas Line

Access

Electrical

Access

34-1/2 in.

(876 mm)

2 in.

(51 mm) 13-1/4 in. (337 mm)

Figure 16.1 Appliance Dimensions

40 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

This page intentionally left blank.

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 41

B. Service Parts List

Service Parts

NB3630M SERIES

Service Parts Diagram 30 in. Novus Clean Face - BV

Beginning Manufacturing Date: Jan 07

Ending Manufacturing Date: Active

Log/Grate Assembly

42 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Service Parts

NB3630M SERIES

Service Parts List 30 in. Novus Clean Face - BV

# Description of Part NB3630M NB3630MI Qty.

1 Top Standoff

2 Collar Shield Leg

3 Glass Clip Support Assembly

4 Nailing Flange

5 Grommet

6 Junction Box Radiation Shield

7 Cover Plate

8 Junction Box (plastic)

9 30 in. Glass Shield

10 Fan Shield

11 Burner Assembly

12 Hearth Pan

13 Valve Assembly

14 Glass Frame Assembly

15 Screen Assembly

Screen Rod

16 30 in. Hood

17 Top Latch Cover

18 Bottom Latch Cover

19 Floor cover

30 in. Drywall Lip

Handle Bracket

Limit Switch

Beginning Manufacturing Date: Jan 2007

Ending Manufacturing Date: Active

31779 31779

4031-255 4031-255

33858 33858

4044-161 4044-161

25741 25741

4031-193 4031-193

4031-222 4031-222

4021-013 4021-013

4031-217 4031-217

4031-289 4031-289

4031-059 4031-059

4031-198 4031-198

4031-510 4031-512

4031-539 4031-539

4031-828 4031-828

4031-836 4031-836

4031-804 4031-804

4031-816 4031-816

4031-820 4031-820

4031-824 4031-824

4031-205 4031-205

34636 34636

4021-383 4021-383

Log/Grate Assembly

30/33 in. Front Right Log

30 in. Middle Log

30 in. Back Log

30/33 in. Front Left Log

Wool, Rock, Vermiculite

Lava Rock (1lb bag)

Mineral Wool

Vermiculite

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 43

4031-084 4031-084

4031-501 4031-501

4031-502 4031-502

4031-504 4031-504

4031-500 4031-500

30831 30831

4021-295 4021-295

14333B 14333B

28746 28746

Service Parts

NB3630M SERIES

Service Parts Diagram 30 in. Novus Clean Face - BV

#13 SP VALVE ASSEMBLY

Beginning Manufacturing Date: Jan 2007

Ending Manufacturing Date: Active

#13 IPI VALVE ASSEMBLY

44 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Service Parts

NB3630M SERIES

Service Parts List 30 in. Novus Clean Face - BV

# Description of Part NB3630M NB3630MI Qty.

1 Valve Plate Gasket

2 Pilot Assembly

3 Pilot Gasket

4 Bulkhead

5 Bulkhead Gasket

6 Valve Plate

7 Valve Bracket

8 ON/OFF Valve

9 16 in. Flex Gas Line

10 Brass Fitting - 3/8 NPT to 3/8 Flare

11 Valve w/Regulator

11 Variable Dexen Valve

12 Brass Connector - 90 Flex

13 Push Button Ignitor

14 Wire Assembly

15 Control Module

16 3V Adaptor Plug

17 Oriﬁ ce (.083) - NG

Wall Switch Wire Assembly

Beginning Manufacturing Date: Jan 2007

Ending Manufacturing Date: Active

4031-149 4031-149

2103-010 4021-422

4021-042 4021-042

4031-547 4031-547

4021-043 4021-043

4031-146 4031-146

4031-507 4031-507

15697 15697

17245B 17245B

17069 17069

230-0710 ---

--- 750-500

4021-045 4021-045

291-513 ---

--- 593-590A

--- 593-592

--- 593-593A

4031-161 4031-161

4018-018 4018-018

24 in. Replacement Pilot Tube Assembly

Shoulder Screws

4021-193 4021-193

501-836/25 501-836/25

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 45

Service Parts

NB3933M SERIES

Service Parts Diagram 33 in. Novus Clean Face - BV

Beginning Manufacturing Date: Jan 2007

Ending Manufacturing Date: Active

Log/Grate Assembly

46 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Service Parts

NB3933M SERIES

Service Parts List 33 in. Novus Clean Face - BV

# Description of Part NB3933M NB3933MI Qty.

1 Top Standoff

Collar Shield Leg

3 Glass Clip Support Assembly

4 Nailing Flange

5 Grommet

6 Junction Box Radiation Shield

7 Cover Plate

8 Junction Box (Plastic)

9 33 in. Glass Shield

10 Fan Shield

11 Burner Assembly

12 Hearth Pan

13 Valve Assembly

14 Glass Frame Assembly

15 Screen Assembly

Screen Rod

16 33 in. Hood

17 Top Latch cover

18 Bottom Latch Cover

19 Floor Cover

33 in. Drywall Lip

Handle Bracket

Screen Bracket

Limit Switch

Beginning Manufacturing Date: Jan 2007

Ending Manufacturing Date: Active

31779 31779

4031-255 4031-255

33858 33858

4044-161 4044-161

25741 25741

4031-193 4031-193

4031-222 4031-222

4021-013 4021-013

4021-218 4021-218

4031-290 4031-290

4031-061 4031-061

4031-199 4031-199

4031-510 4031-512

4031-540 4031-540

4031-829 4031-829

4031-837 7031-837

4031-805 4031-805

4031-817 4031-817

4031-821 4031-821

4031-825 4031-825

4031-206 4031-206

34636 34636

28159 28159

4021-383 4021-383

Log/Grate Assembly

30/33 in. Front Right Log

30/33 in. Front Left Log

33 in. Middle Log

33 in. Back Log

Wool, Rock, Vermiculite

Lava Rock (1lb Bag)

Mineral Wool

Vermiculite 28746 28746 1

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 47

4031-085 4031-085

4031-501 4031-501

4031-500 4031-500

4031-503 4031-503

4031-505 4031-505

30831 30831

4021-295 4021-295

14333B 14333B

Service Parts

NB3933M SERIES

Service Parts Diagram 33 in. Novus Clean Face - BV

#13 SP VALVE ASSEMBLY

Beginning Manufacturing Date: Jan 2007

Ending Manufacturing Date: Active

#13 IPI VALVE ASSEMBLY

48 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Service Parts

NB3933M SERIES

Service Parts List 33 in. Novus Clean Face - BV

# Description of Part NB3933M NB3933MI Qty.

1 Valve Plate Gasket

2 Pilot Assembly

3 Pilot Gasket

4 Bulkhead

5 Bulkhead Gasket

6 Valve Plate

7 Valve Bracket

8 ON/OFF Valve

9 16 in. Flex Gas Line

10 Brass Fitting - 3/8 NPT to 3/8 Flare

Valve w/Regulator

Variable Dexen Valve

12 Brass Connector - 90 Flex

13 Push Button Ignitor

14 Wire Assembly

15 Control Module

16 3V Adaptor Plug

17 Oriﬁ ce (.089) - NG

Battery Pack*

Wall Switch Wire Assembly

24 in. Replacement Pilot Tube Assembly

Shoulder Screws

Beginning Manufacturing Date: Jan 2007

Ending Manufacturing Date: Active

4031-149 4031-149

2103-010 4021-422

4021-042 4021-042

4031-547 4031-547

4021-043 4021-043

4031-146 4031-146

4031-507 4031-507

15697 15697

17245B 17245B

17069 17069

230-0710 ---

--- 750-500

4021-045 4021-045

291-513 ---

--- 593-590A

--- 593-592

--- 593-593A

4031-160 4031-160

--- 593-594A

4018-018 4018-018

4021-193 4021-193

501-836/25 501-836/25

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 49

Service Parts

NB4236M SERIES

Service Parts Diagram 36 in. Novus Clean Face - BV

Beginning Manufacturing Date: Jan 2007

Ending Manufacturing Date: Active

Log/Grate Assembly

50 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Service Parts

NB4236M SERIES

Service Parts List 36 in. Novus Clean Face - BV

# Description of Part NB4236M NB4236MI Qty.

1 Top Standoff

2 Collar Shield Leg

3 Glass Clip Support Assembly

4 Nailing Flange

5 Grommet

6 Junction Box Radiation Shield

7 Cover Plate

8 Junction Box (plastic)

9 36 in. Glass Shield

10 Fan Shield

11 Burner Assembly

12 Hearth Pan

13 Valve Assembly

14 Glass Frame Assembly

15 Screen Assembly

Screen Rod

16 36 in. Hood

17 Top Latch Cover

18 Bottom Latch cover

19 Floor Cover

36 in. Drywall Lip

Screen Bracket

Limit Switch

Beginning Manufacturing Date: Jan 2007

Ending Manufacturing Date: Active

31779 31779

4031-255 4031-255

33858 33858

4044-161 4044-161

25741 25741

4031-193 4031-193

4031-222 4031-222

4021-013 4021-013

4031-219 4031-219

4031-290 4031-290

4031-062 4031-052

4031-497 4031-497

4031-510 4031-512

4000-052 4000-052

4031-830 4031-830

4031-838 4031-838

4031-806 4031-806

4031-818 4031-082

4031-822 4031-078

4031-826 4031-826

4031-207 4031-207

28159 28159

4021-383 4021-383

Log/Grate Assembly

Grate Assembly

36 in./42 in. Front Left Log

36 in./42 in. Front Right Log

36 in./42 in. Middle Log

36 in./42 in. Top Log

36 in. Back Log

Screw Sleeve

Wool, Rock, Vermiculite

Lava Rock (1lb Bag)

Mineral Wool

Vermiculite

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 51

4031-090 4031-090

4031-092 4031-092

4031-273 4031-273

4031-274 4031-274

4031-280 4031-280

4031-276 4031-276

4031-277 4031-277

4021-057 4021-057

30831 30831

4021-295 4021-295

14333B 14333B

28746 28746

Service Parts

NB4236M SERIES

Service Parts Diagram 36 in. Novus Clean Face - BV

#13 SP VALVE ASSEMBLY

Beginning Manufacturing Date: Jan 2007

Ending Manufacturing Date: Active

#13 IPI VALVE ASSEMBLY

52 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Service Parts

NB4236M SERIES

Service Parts List 36 in. Novus Clean Face - BV

# Description of Part NB4236M NB4236MI Qty.

1 Valve Plate Gasket

2 Pilot Assembly

3 Pilot Gasket

4 Bulkhead

5 Bulkhead Gasket

6 Valve Plate

7 Valve Bracket

8 ON/OFF Valve

9 16 in. Flex Gas Line

10 Brass Fitting - 3/8 NPT to 3/8 Flare

Valve w/Regulator

Variable Dexen Valve

12 Brass Connector - 90 Flex

13 Push Button Ignitor

14 Wire Assembly

15 Control Module

16 3V Adaptor Plug

17 Threaded Oriﬁ ce (.0935) - NG

Battery Pack

Wall Switch Wire Assembly

Beginning Manufacturing Date: Jan 2007

Ending Manufacturing Date: Active

4031-149 4031-149

2103-010 4021-422

4021-042 4021-042

4031-547 4031-547

4021-043 4021-043

4031-146 4031-146

4031-507 4031-507

15697 15697

17245B 17245B

17069 17069

230-0710 ---

--- 750-500

4021-045 4021-045

291-513 ---

--- 593-590A

--- 593-592

--- 593-593A

4031-159 4031-159

--- 593-594A

4018-018 4018-018

24 in. Replacement Pilot Tube Assembly

Shoulder Screws

4021-193 4021-193

501-836/25 501-836/25

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 53

Service Parts

NB4842M SERIES

Service Parts Diagram 42 in. Novus Clean Face - BV

Beginning Manufacturing Date: Jan 2007

Ending Manufacturing Date: Active

Log/Grate Assembly

54 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Service Parts

NB4842M SERIES

Service Parts List 42 in. Novus Clean Face - BV

# Description of Part NB4842M NB4842MI Qty.

1 Top Standoff 31779 31779 4

2 Collar Shield Leg 4031-255 4031-255 3

3 Glass Clip Support Assembly 33858 33858 7

4 Nailing Flange 4044-161 4044-161 4

5 Grommet 25741 25741 1

6 Junction Box Radiation Shield 4031-193 4031-193 1

7 Cover Plate 4031-222 4031-222 1

8 Junction Box (plastic) 4021-013 4021-013 1

9 42 in. Glass Shield 4031-220 4031-220 1

10 Fan Shield 4031-290 4031-290 1

11 Burner Assembly 4031-062 4031-062 1

12 Hearth Pan 4031-498 4031-498 1

13 Valve Assembly 4031-510 4031-512 1

14 Glass Frame Assembly 4000-053 4000-053 1

15 Screen Assembly 4031-831 4031-831 1

Screen Rod 4031-939 4031-939 1

16 42 in. Hood 4031-807 4031-807 1

17 Top Latch Cover 4031-819 4031-819 1

18 Bottom Latch Cover 4031-823 4031-823 1

19 Floor Cover 7031-208 7031-208 1

42 in. Drywall Lip 4031-208 4031-208 1

Screen Bracket 28159 28159 2

Limit Switch 4021-383 4021-383 1

Beginning Manufacturing Date: Jan 2007

Ending Manufacturing Date: Active

Log/Grate Assembly 4031-091 4031-091 1

Grate Assembly 4021-057 4021-057 1

36 in./42 in. Front Left Log 4031-273 4031-273 1

36 in./42 in. Front Right Log 4031-274 4031-274 1

36 in./42 in. Middle Log 4031-280 4031-280 1

36 in./42 in. Top Log 4031-276 4031-276 1

42 in. Back Log 4031-278 4031-278 1

Screw Sleeve 4021-057 4021-057 1

Wool, Rock, Vermiculite 30831 30831 1

Lava Rock (1lb Bag) 4021-295 4021-295 1

Mineral Wool 14333B 14333B 1

Vermiculite 28746 28746 1

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 55

Service Parts

NB4842M SERIES

Service Parts Diagram 42 in. Novus Clean Face - BV

#13 SP VALVE ASSEMBLY

Beginning Manufacturing Date: Jan 2007

Ending Manufacturing Date: Active

#13 IPI VALVE ASSEMBLY

56 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Service Parts

NB4842M SERIES

Service Parts List 42 in. Novus Clean Face - BV

# Description of Part NB4842M NB4842MI Qty.

1 Valve Plate Gasket 4031-149 4031-149 1

2 Pilot Assembly 2103-010 4021-422 1

3 Pilot Gasket 4021-042 4021-042 1

4 Bulkhead 4031-192 4031-192 1

5 Bulkhead Gasket 4021-043 4021-043 1

6 Valve Plate 4031-146 4031-146 1

7 Valve Bracket 4031-507 4031-507 1

8 ON/OFF Valve 15697 15697 1

9 16 in. Flex Gas Line 17245B 17245B 1

10 Brass Fitting - 3/8 NPT to 3/8 Flare 17069 17069 1

11 Valve 230-0710 750-500 1

12 Brass Connector - 90 Flex 4021-045 4021-045 1

13 Push Button Ignitor 291-513 1

14 Wire Assembly 593-590A 1

15 Control Module 593-592 1

16 3V Adapter Plug 593-593A 1

17 Threaded Oriﬁ ce (.104) - NG 4031-158 4031-158 1

Beginning Manufacturing Date: Jan 2007

Ending Manufacturing Date: Active

Battery Pack 593-594A 1

Wall Switch Wire Assembly 4018-018 4018-018 1

24 in. Replacement Pilot Tube Assembly 4021-193 4021-193 1

Shoulder Screws 501-836/25 501-836/25 1

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 57

C. Optional Components

Model # Description

NB3630M B-vent standing pilot, natural gas, 36” framing width, 30” viewing glass

NB3630MI B-vent, Intelliﬁ re ignition system, natural gas, 36” framing width, 30” viewing glass

TB30 Traditional brick pattern refractory, to be modiﬁ ed in the ﬁ eld

HB30 Herringbone brick pattern refractory, to be modiﬁ ed in the ﬁ eld

AK14 Outside air kit

ID4 4” I.D. Insulated ﬂ ex-duct, for use with outside air kits, two 42” sections

UD4 4” I.D. Uninsulated ﬂ ex-duct, for use with outside air kits, two 42” sections

BC10 Fan motor rheostat control, wall mounted

GFK21B Transaxial fan kit

GFK21MB Multi-pak of 12 GFK21B transaxial fan kits

RCTS-MLT-HTL Remote Control Kit (SIT valve only)

WSK-MLT-HTL Multi-function wall switch (standing pilot or Intelliﬁ re ignition, Robertshaw valve only)

RC-BATT-HTL Battery operated remote control (standing pilot or Intellﬁ re ignition)

RC-SMART-HTL Remote control (requires 110v or prewiring)

RCT-MLT-HTL Multi-functional remote: On/Off, high/low ﬂ ame, room temp., fan speed (standing pilot or

SMART-STAT-HTL Multi-functional remote: On/Off, room temp., thermostat temp., timer (standing pilot or

SMART-BATT-HTL Battery operated remote control (standing pilot or Intellﬁ re ignition)

CKVP L.P. gas conversion kit (Robertshaw valve only)

CKVN Natural gas conversion kit (Robertshaw valve only)

DCKVP L.P. gas conversion kit for Intelliﬁ re ignition system

DCKVN Natural gas conversion kit for Intelliﬁ re ignition system

SCKVP-B LP Gas Conversion Kit

SCKVN-B Natural Gas Conversion Kit

TKN02S Full face stainless steel trim kit (13 pieces)

TKN03B Polished brass louver trim kit (6 pieces)

TKN03S Stainless steel louver trim kit (6 pieces)

TKN05B Polished brass accent trim kit (2 pieces)

TKN05S Stainless steel accent trim kit (2 pieces)

DFN0B Fixed bi-fold polished brass glass doors

DFN0S Fixed bi-fold stainless steel glass doors

DFA30 Fixed, cabinet-style, black ﬁ nish arched glass doors

DFA30B Fixed, cabinet-style, polished brass arched glass doors

DFA30S Fixed, cabinet-style, stainless steel arched glass doors

SSHND Stainless steel door handles

BRSHND Brass door handles

FFM30 Modernist-style black column decorative faux front with black handles

FFAC30 Arts & Crafts style black column decorative faux front with black handles

Optional Accessories (shipped separately)

Intelliﬁ re ignition, Robertshaw valve only)

Intelliﬁ re ignition)

58 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Model # Description

NB3933M B-vent, standing pilot, natural gas, 39” framing width, 33” viewing glass

NB3933MI B-vent, Intelliﬁ re ignition system, natural gas, 39” framing width, 33” viewing glass

Optional Accessories (shipped separately)

TB33 Traditional brick pattern refractory, to be modiﬁ ed in the ﬁ eld

HB33 Herringbone brick pattern refractory, to be modiﬁ ed in the ﬁ eld

AK14 Outside air kit

ID4 4” I.D. Insulated ﬂ ex-duct, for use with outside air kits, two 42” sections

UD4 4” I.D. Uninsulated ﬂ ex-duct, for use with outside air kits, two 42” sections

BC10 Fan motor rheostat control, wall mounted

GFK4B Transaxial fan kit

GFK4MB Multi-pak of 12 GFK4B transaxial fan kits

RCTS-MLT-HTL Remote Control Kit (SIT valve only)

WSK-MLT-HTL Multi-function wall switch (standing pilot or Intelliﬁ re ignition, Robertshaw valve only)

RC-BATT-HTL Battery operated remote control (standing pilot or Intellﬁ re ignition)

RC-SMART-HTL Remote control (requires 110v or prewiring)

RCT-MLT-HTL Multi-functional remote: On/Off, high/low ﬂ ame, room temp., fan speed (standing pilot or

SMART-STAT-HTL Multi-functional remote: On/Off, room temp., thermostat temp., timer (standing pilot or

SMART-BATT-HTL Battery operated remote control (standing pilot or Intellﬁ re ignition)

CKVP L.P. gas conversion kit (Robertshaw valve only)

CKVN Natural gas conversion kit (Robertshaw valve only)

DCKVP L.P. gas conversion kit for Intelliﬁ re ignition system

DCKVN Natural gas conversion kit for Intelliﬁ re ignition system

SCKVP-B LP Gas Conversion Kit

SCKVN-B Natural Gas Conversion Kit

TKN32S Full face stainless steel trim kit (13 pieces) (decorative unit only)

TKN33B Polished brass louver trim kit (6 pieces)

TKN33S Stainless steel louver trim kit (6 pieces)

TKN35B Polished brass accent trim kit (2 pieces)

TKN35S Stainless steel accent trim kit (2 pieces)

DFN3B Fixed bi-fold polished brass glass doors

DFN3S Fixed bi-fold stainless steel glass doors

DFA33 Fixed cabinet-style, arched, black ﬁ nish glass doors

DFA33B Fixed cabinet-style, arched, polished brass glass doors

DFA33S Fixed cabinet-style, arched, stainless steel glass doors

SSHND Stainless steel door handles

BRSHND Brass door handles

FFM33 Modernist-style black column decorative faux front with black handles

FFAC33 Arts & Crafts style black column decorative faux front with black handles

Intelliﬁ re ignition, Robertshaw valve only)

Intelliﬁ re ignition)

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 59

Model # Description

NB4236M B-vent standing pilot, natural gas, 42” framing width, 36” viewing glass

NB4236MI B-vent, Intelliﬁ re ignition system, natural gas, 42” framing width, 36” viewing glass

Optional Accessories (shipped separately)

TB36 Traditional brick pattern refractory, to be modiﬁ ed in the ﬁ eld

HB36 Herringbone brick pattern refractory, to be modiﬁ ed in the ﬁ eld

AK14 Outside air kit

ID4 4” I.D. Insulated ﬂ ex-duct, for use with outside air kits, two 42” sections

UD4 4” I.D. Uninsulated ﬂ ex-duct, for use with outside air kits, two 42” sections

BC10 Fan motor rheostat control, wall mounted

GFK4B Transaxial fan kit

GFK4MB Multi-pack of 12 GFK4B transaxial fan kits

RCTS-MLT-HTL Remote Control Kit (SIT valve only)

WSK-MLT-HTL Multi-function wall switch (standing pilot or Intelliﬁ re ignition, Robertshaw valve only)

RC-BATT-HTL Battery operated remote control (standing pilot or Intellﬁ re ignition)

RC-SMART-HTL Remote control (requires 110v or prewiring)

RCT-MLT-HTL Multi-functional remote: On/Off, high/low ﬂ ame, room temp., fan speed (standing pilot or

SMART-STAT-HTL Multi-functional remote: On/Off, room temp., thermostat temp., timer (standing pilot or

SMART-BATT-HTL Battery operated remote control (standing pilot or Intellﬁ re ignition)

CKVP L.P. gas conversion kit (Robertshaw valve only)

CKVN Natural gas conversion kit (Robertshaw valve only)

DCKVP L.P. gas conversion kit for Intelliﬁ re ignition system

DCKVN Natural gas conversion kit for Intelliﬁ re ignition system

SCKVP-B LP Gas Conversion Kit

SCKVN-B Natural Gas Conversion Kit

TKN62B Full face polished brass trim kit (13 pieces)

TKN63B Polished brass louver trim kit (6 pieces)

TKN63S Stainless steel louver trim kit (6 pieces)

TKN65B Polished brass accent trim kit (2 pieces)

TKN65S Stainless steel accent trim kit (2 pieces)

DFN6B Fixed bi-fold polished brass glass doors

DFN6S Fixed bi-fold stainless steel glass doors

DFA36 Fixed cabinet-style, arched, black ﬁ nish glass doors

DFA36B Fixed cabinet-style, arched, polished brass glass doors

DFA36S Fixed cabinet-style, arched, stainless steel glass doors

SSHND Stainless steel door handles

BRSHND Brass door handles

FFM36 Modernist-style black column decorative faux front with black handles

FFAC36 Arts & Crafts style black column decorative faux front with black handles

Intelliﬁ re ignition, Robertshaw valve only)

Intelliﬁ re ignition)

60 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Model # Description

NB4842M B-vent standing pilot, natural gas, 48” framing width, 42” viewing glass

NB4842MI B-vent, Intelliﬁ re ignition system, natural gas, 48” framing width, 42” viewing glass

Optional Accessories (shipped separately)

TB42 Traditional brick pattern refractory, to be modiﬁ ed in the ﬁ eld

HB42 Herringbone brick pattern refractory, to be modiﬁ ed in the ﬁ eld

AK14 Outside air kit

ID4 4” I.D. Insulated ﬂ ex-duct, for use with outside air kits, two 42” sections

UD4 4” I.D. Uninsulated ﬂ ex-duct, for use with outside air kits, two 42” sections

BC10 Fan motor rheostat control, wall mounted

GFK4B Transaxial fan kit

GFK4MB Multi-pack of 12 GFK4B transaxial fan kits

RCTS-MLT-HTL Remote Control Kit (SIT valve only)

WSK-MLT-HTL Multi-function wall switch (standing pilot or Intelliﬁ re ignition, Robertshaw valve only)

RC-BATT-HTL Battery operated remote control (standing pilot or Intellﬁ re ignition)

RC-SMART-HTL Remote control (requires 110v or prewiring)

RCT-MLT-HTL Multi-functional remote: On/Off, high/low ﬂ ame, room temp., fan speed (standing pilot or

SMART-STAT-HTL Multi-functional remote: On/Off, room temp., thermostat temp., timer (standing pilot or

SMART-BATT-HTL Battery operated remote control (standing pilot or Intellﬁ re ignition)

CKVP L.P. gas conversion kit (Robertshaw valve only)

CKVN Natural gas conversion kit (Robertshaw valve only)

DCKVP L.P. gas conversion kit for Intelliﬁ re ignition system

DCKVN Natural gas conversion kit for Intelliﬁ re ignition system

SCKVP-B LP Gas Conversion Kit

SCKVN-B Natural Gas Conversion Kit

TKN22B Full face polished brass trim kit

TKN22S Full face stainless steel trim kit

TKN23B Polished brass trim kit (5 pieces)

TKN23S Stainless steel trim kit (5 pieces)

TKN25B Polished brass trim kit (2 pieces)

TKN25S Stainless steel trim kit (2 pieces)

DFC2B Fixed bi-fold polished brass glass doors

DFC2S Fixed bi-fold stainless steel glass doors

DFA42 Fixed cabinet-style, arched, black ﬁ nish glass doors

DFA42B Fixed cabinet-style, arched, polished brass glass doors

DFA42S Fixed cabinet-style, arched, stainless steel glass doors

SSHND Stainless steel door handles

BRSHND Brass door handles

FFM42 Modernist-style black column decorative faux front with black handles

FFAC42 Arts & Crafts style black column decorative faux front with black handles

Intelliﬁ re ignition, Robertshaw valve only)

Intelliﬁ re ignition)

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 61

Arts & Crafts-Style

Faux Front

Modernist-Style

Faux Front

Fixed, Cabinet-Style Arched Glass Doors

Fixed Bi-Fold Doors

62 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Center piece is not

part of the refractory

for the 3630 model

Traditional Brick Refractory

TB33

Center piece is not part

of the refractory for the

3630 model.

Herringbone Brick Refractory

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 63

HB33

This page intentionally left blank.

64 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

This page intentionally left blank.

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 65

This page intentionally left blank.

66 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

D. Limited Lifetime Warranty

Gas Appliance (Fireplace) Limited Lifetime Warranty

HEARTH & HOME TECHNOLOGIES INC. (“HHT”) extends the following warranty for HEATILATOR® gas

appliances installed in the United States of America or Canada (the "Appliance"). Dealers and employees of HHT have no authority to make any warranty or authorize any remedies in addition to or inconsistent with the terms of this warranty.

Limited Lifetime Warranty

HHT warrants the Appliance for component failure due to a manufacturing defect of any of the following components: combustion chamber, burner pan, and logs. The Limited Lifetime Warranty speciﬁ ed above is subject to the conditions, exclusions and limitations listed below, is for the period the Appliance is owned by the original homeowner only, and is nontransferable.

1 Year Limited Warranty

HHT warrants the Appliance to be free from failure of any of the following components for a period of one year after installation: valve, ﬂ exible gas line connector, glass panel, fan, direct vent chimney components, factory paint, gasket, piezo ignitor, thermopile, thermocouple, junction box, pilot assembly, shutoff valve, high limit switch, refractory liners, transformer, and control box. If the Heatilator Appliance is found to be defective in either material or workmanship within one year of the date of original installation, HHT will provide replacement parts at no charge and pay reasonable labor and freight costs, and is for the period of one year following the date of original installation of the Appliance.

Conditions, Exclusions, & Limitations of Liability

A. Both the Limited Lifetime and 1 Year Limited Warranties supplied by HHT apply only while the Appliance is in its location of original

installation. HHT’s obligation under this warranty does not extend to damages resulting from (1) installation, operation or maintenance of the Appliance not in accordance with the Installation Instructions, Operating Instructions, and the Listing Agent Identiﬁ cation Label furnished with the Appliance; (2) installation which does not comply with local building codes; (3) shipping, improper handling, improper operation, abuse, misuse, accident or unworkmanlike repairs; (4) environmental conditions, inadequate ventilation or drafting caused by tight sealing construction of the structure, air handling devices such as exhaust fans or forced air furnaces, or other causes; (5) use of fuels other than those speciﬁ ed in the Operating Instructions; (6) installation or use of components not supplied with the Appliance or any other components not expressly authorized and approved by HHT; and/or (7) modiﬁ cation of the Appliance not expressly authorized and approved by HHT in writing. This warranty is limited to only the component parts manufactured or supplied by HHT.

B. HHT’s liability under both the Limited Lifetime Warranty and the 1 Year Limited Warranty is limited to the replacement and repair of

defective components or workmanship during the applicable period. HHT may fully discharge all of its obligations under such warranties by repairing the defective component(s) or at HHT’s discretion, providing replacement parts at no charge and paying reasonable labor and freight costs.

C. EXCEPT TO THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY

SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE WARRANTY SPECIFIED ABOVE.

D. Some states do not allow exclusions or limitations of incidental or consequential damages, so those limitations may not apply to you.

This warranty gives you speciﬁ c rights; you may also have other rights which vary from state to state.

How to Obtain Service

To obtain service under this warranty you must:

1. Send written notice of the claimed condition to Heatilator Technical Service Department, Hearth & Home Technologies, 1915 W. Saunders Street, Mt. Pleasant, Iowa 52641-1563. You may also register your claim online at www.heatilator.com.

2. Provide proof of purchase, model number, serial number, and manufacturing date code to HHT.

3. Provide HHT reasonable opportunity to investigate the claim, including reasonable opportunity to inspect the Appliance prior to any

repair or replacement work and before the Appliance or any component of the Appliance has been removed from the place of original installation.

4. Obtain HHT’s consent to any warranty work before the work is done.

ADDITIONAL INFORMATION:

If you would like information on current HEATILATOR products or want to locate a dealer in your area, call 1-800-927-6841.

Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07 67

E. Contact Information

Please contact your Heatilator dealer with any questions or concerns.

For the number of your nearest Heatilator dealer, please visit www.heatilator.com.

Hearth & Home Technologies Inc.

1915 W. Saunders Street

Mt. Pleasant, Iowa 52641

www.heatilator.com

- NOTES -

CAUTION

DO NOT DISCARD THIS MANUAL

•

• Important operating and maintenance instructions included.

This product may be covered by one or more of the following patents: (United States) 4593510, 4686807, 4766876, 4793322, 4811534, 5000162, 5016609, 5076254, 5113843, 5191877, 5218953, 5263471, 5328356, 5341794, 5347983, 5429495, 5452708, 5542407, 5601073, 5613487, 5647340, 5688568, 5762062, 5775408, 5890485, 5931661, 5941237, 5947112, 5996575, 6006743, 6019099, 6048195, 6053165, 6145502, 6170481, 6237588, 6296474, 6374822, 6413079, 6439226, 6484712, 6543698, 6550687, 6601579, 6672860, 6688302B2, 6715724B2, 6729551, 6736133, 6748940, 6748942, 6769426, 6774802, 6796302, 6840261, 6848441, 6863064, 6866205, 6869278, 6875012, 6880275, 6908039, 6919884, D320652, D445174, D462436; (Canada) 1297749, 2195264, 2225408, 2313972; (Australia) 780250, 780403, 1418504 or other U.S. and foreign patents pending.

68 Heatilator • Novus BV-Mesh • 4031-553 Rev F • 11/07

Read, understand and follow these instructions for safe installation and operation.

Leave this manual with party responsible for use and operation.

DO NOT

DISCARD

Heatiator NB4236MI, NB3933MI, NB4236M, NB4842MI, NB4842M User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
