Instruction Manual
HI 38034
Total Hardness
0-20 gpg range
0-20 ppm range
Test Kit
www.hannainst.com
Dear Customer,
Thank you for choosing a Hanna Product.
Please read the instruction sheet carefully before using the
test kit. It will provide you with the necessary information
for correct use of the kit. If you need additional information,
do not hesitate to e-mail us at tech@hannainst.com.
Remove the chemical test kit from the packing material and
examine it carefully to make sure that no damage has
occurred during shipping. If there is any noticeable damage, notify your Dealer or the nearest Hanna office
immediately.
Each kit is supplied with:
Buffer Solution pH 10.2±0.2, 2 bottles with drop-
•
per (2x30 mL);
Calmagite Indicator, 1 bottle with dropper (10 mL);
•
EDTA Solution 0-20 gpg range, 1 bottle (100 mL);
•
• EDTA Solution 0-20 ppm range, 1 bottle (100 mL);
1 calibrated plastic vessel (50 mL) with cap;
•
2 syringes (1 mL) with tips.
•
Note: Any damaged or defective item must be returned in
its original packing materials.
SPECIFICATIONSSPECIFICATIONS
SPECIFICATIONS
SPECIFICATIONSSPECIFICATIONS
Range 0 to 20 gpg CaCO
0 to 20 ppm CaCO
Smallest Increment 0.2 gpg CaCO
0.2 ppm CaCO
Analysis Method EDTA titration
Sample Size 25 mL
Number of Tests 100 for the gpg range
100 for the ppm range
Case Dimensions 235x175x115 mm (9.2x6.9x4.5")
Shipping Weight 567 g (20.0 oz.)
SIGNIFICANCE AND USESIGNIFICANCE AND USE
SIGNIFICANCE AND USE
SIGNIFICANCE AND USESIGNIFICANCE AND USE
Water hardness has traditionally been defined as the
capacity of water to precipitate soap. The ionic species in
water causing the precipitation were later found to be
primarily calcium and magnesium. At the present time,
water hardness is a quantitative measure of these ions in
the water sample. Now it is also known that certain other
ion species, such as iron, zinc and manganese, contribute to
the overall hardness of water. The measure and subsequent
control of water hardness is essential to prevent scaling and
clogging in water pipes. The Hanna hardness test kit makes
monitoring easy and quick. The compact size provides the
versatility to use the kit anywhere and the design makes
the kit easy to handle.
Note: 1 gpg (grains per gallon) CaCO
ppm CaCO
equivalent to mg/L).
The hardness level is determined by an EDTA (ethylenediamine-tetraacetic acid) titration. The solution is first adjusted
to a pH of 10 using a buffer solution. The indicator chelates
with metal ions such as magnesium or calcium to form a red
colored complex. As EDTA is added, metal ions complex with it.
After all the free metal ions have been complexed, an excess
EDTA removes the metal ions complexed with the indicator to
form a blue colored solution. This color change from red to
blue is the endpoint of the titration.
ISTR38034 09/00 PRINTED IN ITALY
(where ppm - parts per million - is
3
CHEMICAL REACTIONCHEMICAL REACTION
CHEMICAL REACTION
CHEMICAL REACTIONCHEMICAL REACTION
3
3
3
3
is equivalent to 17
3
INSTRUCTIONSINSTRUCTIONS
INSTRUCTIONS
INSTRUCTIONSINSTRUCTIONS
READ ALL THE INSTRUCTIONS BEFORE USING THE TEST KIT
• Remove the cap from the plastic
vessel. Rinse the plastic vessel with
the water sample, fill to the 25 mL
mark and replace the cap.
• Add 5 drops of Buffer Solution through the cap port
and mix carefully by swirling the vessel in tight circles.
x 5
• Add 1 drop of Calmagite Indicator through the cap port
and mix as described above. The solution becomes a redviolet color.
x 1
• Take the syringe and push the
plunger completely down into the
syringe. Insert tip into the EDTA
solution gpg range (or EDTA solution ppm range) and pull the
plunger out until the lower edge
of the seal is on the 0.0 mL
mark of the syringe.
• Place the syringe tip
into the cap port of
the plastic vessel and
slowly add the titration solution drop by
drop, swirling after
each drop.
• Continue adding the
25 mL
EDTA Solution until the solution in the vessel becomes
purple. Then mix for 15 seconds after each additional
drop until the solution in the vessel turns blue.
• Read off the milliliters of titration solution used from the
syringe and multiply by 20 to obtain the hardness level
of your sample as gpg (or as ppm) CaCO
If it has been used EDTA Solution 0-20 gpg range:
mL of titrant x 20 = gpg CaCO
If it has been used EDTA Solution 0-20 ppm range:
mL of titrant x 20 = ppm CaCO
REFERENCESREFERENCES
REFERENCES
REFERENCESREFERENCES
Standard Methods for the Examination of Water and
Wastewater, 16
1987 Annual Book of ASTM Standard, vol. 11.01 Water
(1), p. 212-215.
The chemicals contained in this test kit may be hazardous if
improperly handled. Read the relevant Health and Safety
Data Sheets before performing the test.
th
Edition, 1985, p. 210-214.
HEALTH AND SAFETYHEALTH AND SAFETY
HEALTH AND SAFETY
HEALTH AND SAFETYHEALTH AND SAFETY
.
3
3
